Tadano GR-1000XL-4 User manual

GENERAL DIMENSIONS
Note: Dimension is with boom angle at -1.5 degree.
( ) Reference dimensions in mm.
Form NO. GR-1000-4-00101/US-01
Overall length
Overall width
Overall height
approx. 47' 2"
approx. 10' 10-1/2"
approx. 12' 5-13/16"
Feet Meters
14.375
3.315
3.805
Turning radius (29.5–25 Tires)
4 wheel steer
2 wheel steer
Feet
6.8
10.9
22' 4"
35' 9-3/32"
Meters
GR-1000XL-4
100 Ton (90.7 Metric Ton) Capacity
HYDRAULIC ROUGH TERRAIN CRANE
Specications are subject to change without notice.
DIMENSIONS
- 1 -
15'9" (4,790)
8'3-15/16" (2,538)
Min.: 39.4'–Max.: 154.2' (12,000–47,000)
13'9" (4,190)
12'5-13/16" (3,805)
10'10-1/2" (3,315) 28'1-13/16" (8,580)
47'2" (14,375)
26'3-3/4" (8,020) 7'10-5/8" (2,405)12'11-1/2" (3,950)
23'11-3/8" (7,300) 21'11-3/4" (6,700) 18'1/2" (5,500) 8'10-1/4" (2,700)
1'6-1/8"
(460)
15.8°
13.7°
7'2-5/8" (2,200)
11'7-3/4" (3,550) 12'4-7/8" (3,780)
6'1-7/8"
(1,875)

CRANE SPECIFICATIONS
BOOM
5 section full power synchronized telescoping boom, 39.4'–154.2'
(12.0 m–47.0 m), of round box construction with 7 sheaves,
17-5/16" (0.44 m) root diameter, at boom head.
The synchronization system consists of 2 telescope cylinders, an
extension cable and retraction cable. Hydraulic cylinder tted with
holding valve. 2 easily removable wire rope guards, rope dead
end provided on both sides of boom head. Boom telescope
sections are supported by wear pads both vertically and
horizontally. Extension speed 114.8’ in 155 seconds.
BOOM ELEVATION - By a double acting hydraulic cylinder
with holding valve. Elevation -1.5º-80.5º, combination controls for
hand or foot operation. Boom angle indicator.
Automatic speed reduction and slow stop function.
Boom raising speed 20º to 60º in 46 seconds.
JIB - 2 stage bi-fold lattice type, 3.5º, 25º or 45º offset (tilt type).
Single sheave, 15-5/8" (0.396 m) root diameter, at the head of
both jib sections. Stored alongside base boom section. Jib length
is 33.2' (10.1 m) or 58.1' (17.7 m). Assistant cylinders for mounting
and stowing, controlled at right side of superstructure. Self
stowing jib mounting pins.
AUXILIARY LIFTING SHEAVE (SINGLE TOP)
Single sheave, 15-5/8" (0.396 m) root diameter. Mounted to main
boom head for single line work (stowable).
ANTI-TWO BLOCK - Pendant type over-winding cut out
device with audio-visual (FAILURE lamp/BUZZER) warning
system.
SLEWING
Hydraulic axial piston motor through planetary slewing
speed reducer. Continuous 360º full circle slewing on ball bearing
turn table at 1.5 min
-1
{rpm}. Equipped with manually
locked/released slewing brake. A 360º positive slewing lock for
pick and carry and travel modes, manually engaged in cab.
Twin slewing system: Free slewing or lock slewing controlled by
selector switch on front console.
WINCH
MAIN WINCH - Variable speed type with grooved drum driven
by hydraulic axial piston motor through speed reducer.
Power load lowering and raising. Equipped with automatic
brake (neutral brake) and counterbalance valve. Controlled
independently of auxiliary winch. Equipped with cable follower
and drum rotation indicator.
DRUM - Grooved 14-1/4" (0.362 m) root diameter x 26-13/16"
(0.681 m) wide. Wire rope: 830' of
3/4" diameter rope (253 m of
19 mm). Drum capacity: 1135' (346 m) 7 layers. Maximum single
line pull:1st layer 20,000 lbs (9,090 kg). Maximum permissible line
pull wire strength: 14,600 lbs (6,600 kg).
AUXILIARY WINCH - Variable speed type with grooved drum
driven by hydraulic axial piston motor through speed reducer.
Power load lowering and raising. Equipped with
automatic brake (neutral brake) and counterbalance valve.
Controlled independently of main winch. Equipped with cable
follower and drum rotation indicator.
DRUM - Grooved 14-1/4" (0.362 m) root diameter x 26-13/16"
(0.681 m) wide. Wire rope: 456' of 3/4" diameter rope (139 m of 19
mm). Drum capacity: 1135' (346 m) 7 layers. Maximum single line
pull: 1st layer 20,000 lbs (9,090 kg). Maximum permissible line pull
wire strength: 14,600 lbs (6,600 kg).
WIRE ROPE - Non-rotating 3/4" (19 mm) P･S (19) + 39 x P･7
Breaking Strength 72,800 lbs (33,000 kg)
HOOK BLOCKS
100 ton (90.7 metric ton)-8 sheaves with swivel hook and safety
latch, for 3/4" (19 mm) wire rope.
7.3 ton (6.6 metric ton) - Weighted hook with swivel and
safety latch, for 3/4" (19 mm) wire rope.
COUNTERWEIGHT
Self-removable counterweight ............... 20,100 lbs (9,100 kg)
HYDRAULIC SYSTEM
PUMPS - 2 variable piston pumps for crane functions.
Tandem gear pump for steering, slewing and optional equipment.
Powered by carrier engine. Pump disconnect for crane is
engaged/ disengaged by rotary switch from operator's cab.
CONTROL VALVES - Multiple valves actuated by pilot
pressure with integral pressure relief valves.
RESERVOIR - 210 gallon (795 lit.) capacity. External sight
level gauge.
FILTRATION - BETA10=10 return lter, full ow with bypass
protection, located inside of hydraulic reservoir. Accessible for
easy replacement.
OIL COOLER - Air cooled fan type.
CAB AND CONTROLS
Both crane and drive operations can be performed from one
cab mounted on rotating superstructure.
20
º tilt, Left side, 1 man type, steel construction with sliding door
access and safety glass windows opening at side. Door
window is powered control. Windshield glass window and roof
glass window are shatter-resistant. Tilt-telescoping steering
wheel. Adjustable control lever stands for slewing, boom
elevating, boom telescoping, auxiliary winch and main winch.
Control lever stands can change neutral positions and tilt for easy
access to cab. 3 way adjustable operator's seat with high back,
headrest and armrest. Engine throttle knob. Foot operated
controls: boom elevating boom telescoping, service brake and
engine throttle. Hot water cab heater and air conditioning.
Dash-mounted Instrument panel, Multi Function Display, Starter
switch (engine start/stop), 12 V power outlelet, USB port, drive
selector switch, parking brake switch, steering mode select
switch, power window switch, pump engaged/disengaged switch,
slewing brake switch, telescoping/auxiliary winch select switch,
outrigger controls, free slewing/lock slewing selector switch, air
conditioning control switch.
Instruments panel - Torque converter oil temperature, engine
water temperature, air pressure, fuel, speedometer, tachometer,
hour meter and odometer/tripmeter.
Multi Function Display - DEF level gauge, Fuel consumption
monitor.
Form No. GR-1000-4-00101/US-01
- 2 -

Tadano electronic LOAD MOMENT INDICATOR system
(AML-E2) including:
• Control lever lockout function with audible and visual
pre-warning
• Number of parts of line
• Boom position indicator
• Outrigger state indicator
• Slewing angle
• Boom angle / boom length / jib offset angle / jib length /
load radius / rated lifting capacities / actual loads read out
• Potential lifting height
• Ratio of actual load moment to rated load moment
indication
• Automatic Speed reduction and slow stop function on
boom elevation and slewing
• Working condition register switch
• Load radius / boom angle / tip height / slewing range preset
function
• External warning lamp
• Tare function
• Main Hydraulic oil pressure
• Fuel consumption monitor
• Main winch / auxiliary winch select
• Drum rotation indicator (audible and visible type) main and
auxiliary winch
• On rubber indicator
TADANO AML-E2 monitors outrigger extended length and
automatically programs the corresponding "RATED LIFTING
CAPACITIES" table.
Operator's right hand console includes transmission gear
selector, slewing lock lever and sight level bubble.
Upper console includes,
roof washer and wiper switch,
emergency outrigger set up key switch,
jib equipped / removed select switch,
high speed winch (main / aux) switch, Cab tilt switch,
Pump disconnect enable switch and boom emergency
telescoping switch (2nd and 3rd-top).
NOTE: Each crane motion speed is based on unladen conditions.
CARRIER SPECIFICATIONS
TYPE - Rear engine, left hand steering, driving axle 2-way
selected type by manual switch, 4 x 2 front drive, 4 x 4 front and
rear drive.
FRAME - High tensile steel, all welded mono-box construction.
TRANSMISSION - Electronically controlled full automatic
transmission. Torque converter driving full powershift with
driving axle selector. 6 forward and 2 reverse speeds, constant
mesh.
3 speeds - high range - 2 wheel drive; 4 wheel drive
3 speeds - low range - 4 wheel drive
TRAVEL SPEED - 22 mph (36 km/h)
AXLE - Front: Full oating type, steering and driving axle with
planetary reduction. Rear: Full oating type, steering and driving
axle with planetary reduction and non-spin rear differential.
STEERING - Hydraulic power steering controlled by steering
wheel. Four steering modes available: 2 wheel front, 2 wheel
rear, 4 wheel coordinated and 4 wheel crab.
SUSPENSION - Front: Rigid mounted to frame. Rear: Pivot
mounted with hydraulic lockout device.
BRAKE SYSTEMS - Service: Air over hydraulic disc brakes on
all 4 wheels. Parking / Emergency: Spring applied-air released
brake acting on input shaft of front axle. Auxiliary: Electro-
pneumatic operated exhaust brake.
TIRES - 29.5-25 36PR (OR) Air pressure: 68 psi (470 kPa)
29.5-25 40PR (OR) Air pressure: 67 psi (465 kPa)
OUTRIGGERS- Four hydraulic, beam and jack outriggers.
Vertical jack cylinders equipped with integral holding valve. Each
outrigger beam and jack is controlled independently from cab.
Beams extend to 23' 11-3/8" (7.3 m) center-line and retract to
within 10' 10-1/2" (3.315 m) overall width with oats. Outrigger
jack oats are attached thus eliminating the need of manually
attaching and detaching them. Controls and sight bubble located
in superstructure cab. Four outrigger extension lengths are
provided with corresponding "RATED LIFTING CAPACITIES" for
crane duty in conned areas.
Min. Extension 8' 10-1/4" (2.7 m) center to center
Mid. Extension 18' 1/2" (5.5 m) center to center
Mid. Extension 21' 11-3/4" (6.7 m) center to center
Max. Extension 23' 11-3/8" (7.3 m) center to center
Float size (Diameter) 1' 11- 5/8" (0.6 m)
ENGINE
ModelCummins B6.7
Type Direct injection diesel
No. of cylinders 6
Combustion 4 cycle, turbo charged and after cooled
BoreXStroke, in. (mm) 4.212 X 4.882 (107 X 124)
Displacement, cu. in (liters) 409 (6.7)
Air inlet heater 24 volt preheat
Air cleaner Dry type, replaceable element
Oil lter Full ow with replaceable element
Fuel lter Full ow with replaceable element
Fuel tank, gal. (liters) 79.2 (300), right side of carrier
Cooling Liquid pressurized, recirculating by-pass
Radiator
Fin and tube core, thermostat controlled
Fan, in. (mm) Suction type, 9-blade, 28 (711) dia.
Starting 24 volt
Charging 24 volt system, negative ground
Battery  2-120 amp. Hour
Compressor, air, CFM (l /min)17.0 CFM (481) at 2,400 rpm
Output, Max. HP (kW) Gross 280 (209) at 2,200 rpm
Torque, Max. ft-lb (Nm) 850 (1,152) at 1,500 rpm
Capacity, gal. (liters)
Cooling water 2.7 (10)
Lubrication 4.0 (15)
Fuel 79.2 (300)
DEF/AdBlue 15.0 (57)
Form No. GR-1000-4-00101/US-01
- 3 -

STANDARD EQUIPMENT
- 5 section full power partially synchronized boom
39.4'–154.2' (12.0 m–47.0 m)
- 33.2' or 58.1' (10.1 m or 17.7 m) bi-fold lattice jib (tilt type)
with 3.5º, 25º or 45º pinned offsets and self storing pins.
- Quick reeving type bi-fold jib
- Anti-Two block device (overwind cutout)
- Winch drum camera with light
- LED work lights
-
Variable speed main winch with grooved drum, cable follower, drum
rotation indicator (audible,visible and thumper type) and 830' of 3/4" cable.
- Variable speed auxiliary winch with grooved drum, cable follower, drum
rotation indicator (audible, visible and thumper type) and 456' of 3/4" cable.
- Auxiliary lifting sheave (single top) stowable
- 2-speed winch
- 100 ton (90.7 metric ton) hook block - 8 sheaves with swivel hook
and safety latch for 3/4" (19 mm) wire rope
- 7.3 ton (6.6 metric ton) hook with swivel
- Tadano twin slewing system and 360º positive slewing lock
- Positive control
- Hydraulic oil cooler
-
3 way adjustable cloth seat with armrests, high back and seat belt
- Tilt-telescoping steering wheel
- Tinted safety glass and sun visor
- Front windshield wiper and washer
- Roof window wiper and washer
- Power window (cab door)
- 12V power outlet
- Ashtray
- Cab oor mat
- Pump disconnect in operator's cab
- Air conditioner (hot water heater and cooler)
- Full instrumentation package
- Self centering nger control levers with pilot control
- Control pedals for boom elevating and boom telescoping
- Low oil pressure / high water temp. warning device (visual)
- Air cleaner dust indicator
- Cup holder
- Battery disconnect
- USB port
- 20º tilt cab
- Emergency steering system
- Tadano electronic load moment indicator system (AML-E2)
- Boom angle indicator
- Outrigger extension length detector
- Electronic crane monitoring system
- Rear view camera
- Right front view camera
- Fenders
- Air dryer
- Complete highway light package
- Towing hooks-Front and rear
- Hook block tie down (front bumper)
- Weighted hook storage compartment
- Halogen head lamp
- Independently controlled outriggers
- Four outrigger extension positions
- Self-storing outrigger pads
-
Electronic controlled automatic transmission driven by torque converter
- 4 X 4 X 4 drive / steer
- Non-spin rear differential
- Automatic rear axle oscillation lockout system
- 29.5-25 36 PR tires
- 29.5-25 40 PR tires
- Disc brakes
- Water separator with lter (high ltration)
- Back-up alarm
- 24 volt electric system
- Tool storage compartment
- Tire ination kit
- Cummins B6.7 turbo charged
after cooled engine (280 HP) with exhaust brake
- Engine over-run alarm
- Lifting eyes
- Telematics (machine data logging and monitoring system)
with HELLO-NET via internet (availability depends on countries)
- Fuel consumption monitor
- Eco mode system
- Self-removable counterweight
- Radiator cover
- Clearance sonar (Rear side)
- Automatic pump disconnect
- Over unwinding prevention
HOISTING PERFORMANCE
LINE SPEEDS AND PULLS DRUM WIRE ROPE CAPACITIES
- Maximum permissible line pull wire strength
14,600 lbs (6,600 kg).
1Line speeds based only on hook block, not loaded.
2Developed by machinery with each layer of wire rope, but not based
on rope strength or other limitation in machinery or equipment.
3Seventh layer of wire rope are not recommended
for hoisting operations.
DRUM DIMENSIONS
Inch mm
Root diameter
Length Flange
diameter
14-1/4"
26-13/16"
25-7/8"
362
681
657
Feet Meters Feet Meters
1 128.0 39.0 128.0 39.0
2 139.4 42.5 267.4 81.5
3 150.9 46.0 418.3 127.5
4 162.1 49.4 580.4 176.9
5 173.9 53.0 754.3 229.9
6 185.4 56.5 939.6 286.4
7 196.9 60.0 1,136.5 346.4
Total wire rope mRope per layer m
3/4" (19 mm) wire rope
Main and auxiliary drum grooved lagging
Wire
rope
layer
Layer
Low High Low High
F.P.M
m/min
Lbs. kgf Lbs. kgf
1st 278 84 118 20,000 9,090 14,400 6,520
2nd 302 92 128 18,100 8,230 13,000 5,900
3rd 327 99 139 16,600 7,520 11,900 5,390
4th 352 107 149 15,300 6,920 10,900 4,960
5th 377 115 160 14,100 6,410 10,100 4,600
6th 402 122 170 13,200 5,970 9,400 4,280
7th3427 130 181 12,300 5,590 8,800 4,010
Main or auxiliary hoist - 14'-1/4" (0.362 m) drum
Line speeds1 Line pulls Available2
F.P.M m/min
387
421
456
491
526
560
595
Form No. GR-1000-4-00101/US-01
- 4 -

Approx.
8.1'
Approx.
7.7'
1.9'
0°
10°
80°
70°
30°
40°
50°
20°
60°
78.3
101.5
3.7
6.3
8.4
11.4
14.1
20.2
28.3
3.3
4.2
3.9
4.7
4.5
5.3
5.1
6.0
7.0
5.8
6.7
7.7
6.6
7.5
8.5
7.5
8.4
9.5
9.3
8.6
9.5
10.3
10.4
9.8
10.6
11.0
11.6
11.1
12.0
11.8
13.0
12.7
12.7
13.6
12.7
14.6
14.4
14.4
15.0
14.0
16.4
16.2
15.9
18.1
15.8
16.5
16.1
17.7
18.5
19.1
20.2
21.6
21.6
23.1
24.2
23.5
23.2
24.9
26.5
28.8
30.2
33.8
33.2
24.9
31.5
33.3
35.5
39.7
42.5
44.4
45.7
33.3
35.5
40.1
42.5
68.5
77.6
42.5
90.2
102.5
133.8
90.2
102.5
159.7
102.5
200
17.3
18.3
18.8
19.2
21.2
20.8
21.1
22.3
23.9
25.7
25.1
28.4
27.7
24.9
28.1
29.8
32.3
35.0
36.4
40.1
35.5
31.5
33.3
35.5
40.1
42.5
58.7
59.9
40.1
35.5
42.5
81.5
100.8
90.2
102.5
181.9
60.8
2.4
2.8
2.0
1.7
NOTE: Boom geometry shown is for unloaded condition and
machine standing level on rm supporting surface.
Boom deection and subsequent radius and boom angle change
must be accounted for when applying load to hook.
When boom length is same as telescoping mode 1 and 2, it show large load.
Axis of Rotation
BOOM SINGLE TOP
160'
160'
150'
10'
20'
30'
40'
50'
60'
70'
80'
90'
100'
110'
180'
120'
130'
140'
130'10' 20' 30' 40' 50' 60' 70' 80' 140'90' 100' 110' 120'
170'
150'
111.1'
(33.9 m)
82.4'
(25.1 m)
53.7'
(16.4 m)
68.1'
(20.8 m)
96.8'
(29.5 m)
125.5'
(38.3 m)
154.2'
(47.0 m)
139.8'
(42.6 m)
39.4'
(12.0 m)
Unit: klbs
Load Radius from Axis of Rotation in Feet
Lifting Height in Feet
SMART COUNTERWEIGHT
360° ROTATION
GR-1000XL-4 WORKING RANGE CHART
Form No. GR-1000-4-00101/US-01
- 5 -

Approx.
8.1'
Approx.
7.7'
1.9'
2.8
3.2
4.1
3.6
60.8
181.9
102.5
90.2
100.8
81.5
42.5
35.5
40.1
59.9
58.7
42.5
40.1
35.5
33.3
31.5
39.4
40.1
38.7
35.0
32.3
29.8
28.1
24.9
31.8
32.4
27.9
25.9
23.9
22.3
21.1
24.6
21.3
21.2
19.6
18.3
17.3
200
102.5
159.7
102.5
90.2
133.8
102.5
90.2
42.5
77.6
68.5
42.5
40.1
35.5
33.3
47.8
47.1
42.5
39.7
35.5
33.3
31.5
24.9
36.8
35.5
31.1
28.8
26.5
24.9
23.2
27.8
28.4
25.1
23.3
21.6
20.2
19.1
19.8
18.9
17.9
16.7
15.8
21.5
18.9
18.5
16.5
16.5
15.3
14.4
17.1
15.4
14.7
14.1
13.2
15.2
14.5
12.9
13.1
12.2
13.6
11.4
12.3
11.2
12.5
10.3
11.5
10.4
11.3
9.6
10.3
9.4
9.0
9.3
8.4
8.5
8.3
7.5
8.0
7.5
6.6
6.8
5.9
6.1
5.2
5.5
4.7
33.0
24.1
16.8
13.6
10.3
7.6
5.0
101.5
78.3
60°
20°
50°
40°
30°
70°
80°
10°
0°
Axis of Rotation
BOOM SINGLE TOP
NOTE: Boom geometry shown is for unloaded condition and
machine standing level on rm supporting surface.
Boom deection and subsequent radius and boom angle change
must be accounted for when applying load to hook.
When boom length is same as telescoping mode 1 and 2, it show large load.
39.4'
(12.0 m)
139.8'
(42.6 m)
154.2'
(47.0 m)
125.5'
(38.3 m)
96.8'
(29.5 m)
68.1'
(20.8 m)
53.7'
(16.4 m)
82.4'
(25.1 m)
111.1'
(33.9 m)
170'
140'
130'
120'
180'
110'
100'
90'
80'
70'
60'
50'
40'
30'
20'
10'
150'
160'
Unit: klbs
160'130'10' 20' 30' 40' 50' 60' 70' 80' 140'90' 100' 110' 120' 150'
Load Radius from Axis of Rotation in Feet
Lifting Height in Feet
SMART COUNTERWEIGHT
SMART CHART
GR-1000XL-4 WORKING RANGE CHART
Form No. GR-1000-4-00101/US-01
- 6 -

Approx.
7.7'
45°
25°
80°
70°
60°
50°
40°
30°
20°
10°
0°
3.5°
10.1
10.8
11.9
11.9
11.9
11.9
11.9
11.9
11.9
9.5
8.4
7.4
6.6
5.8
5.1
4.5
3.9
3.4
2.9
2.4
2.0
7.3
7.3
7.3
7.3
7.3
7.3
7.3
7.3
7.2
7.0
6.7
6.5
6.1
5.4
4.8
4.2
3.7
3.2
2.8
2.4
2.0
1.6
11.9
1.7
1.3
1.0
1.3
NOTE: Jib geometry shown are for unloaded condition and
machine standing level on rm supporting surface.
Boom deection and subsequent radius and boom angle change
must be accounted for when applying load to hook.
Axis of Rotation
JIB
154.2'
(47.0 m)
+ 58.1'
(17.7 m)
154.2'
(47.0 m)
+ 33.2'
(10.1 m)
170'160'130'10' 20' 30' 40' 50' 60' 70' 80' 140'90' 100' 110' 120' 150'
180'
170'
140'
130'
120'
110'
100'
90'
80'
70'
60'
50'
40'
30'
20'
10'
150'
160'
220'
210'
190'
200'
154.2'
(47.0 m)
180' 190'
Unit: klbs
Load Radius from Axis of Rotation in Feet
Lifting Height in Feet
SMART COUNTERWEIGHT
360° ROTATION
GR-1000XL-4 WORKING RANGE CHART
Form No. GR-1000-4-00101/US-01
- 7 -

Approx.
7.7'
1.2
1.5
1.8
2.1
2.4
1.4
1.7
2.1
2.4
2.8
11.9
2.8
3.1
3.5
4.0
4.5
5.0
5.4
5.6
6.0
6.3
6.5
6.7
7.0
7.2
7.3
7.3
7.3
7.3
7.3
7.3
7.3
7.3
3.2
3.7
4.2
4.7
5.3
6.0
6.7
7.4
7.9
8.4
8.9
9.5
11.9
11.9
11.9
11.9
11.9
11.9
11.9
10.8
10.1
3.5°
0°
10°
20°
30°
40°
50°
60°
70°
80°
25°
45°
NOTE: Jib geometry shown are for unloaded condition and
machine standing level on rm supporting surface.
Boom deection and subsequent radius and boom angle change
must be accounted for when applying load to hook.
Axis of Rotation
JIB
200'
190'
210'
220'
160'
150'
10'
20'
30'
40'
50'
60'
70'
80'
90'
100'
110'
120'
130'
140'
170'
180'
Unit: klbs
154.2'
(47.0 m)
+ 58.1'
(17.7 m)
154.2'
(47.0 m)
+ 33.2'
(10.1 m)
154.2'
(47.0 m)
170'160'130'10' 20' 30' 40' 50' 60' 70' 80' 140'90' 100' 110' 120' 150' 180' 190'
Load Radius from Axis of Rotation in Feet
Lifting Height in Feet
SMART COUNTERWEIGHT
SMART CHART
GR-1000XL-4 WORKING RANGE CHART
Form No. GR-1000-4-00101/US-01
- 8 -

200,000
GR-1000XL-4 RATED LIFTING CAPACITIES (IN POUNDS)
A: Boom length in feet
B: Load radius in feet
A
B
39.4'
(12 m)
53.7'
(16.4 m)
154.2'
(47 m)
8
10
12
15
20
25
30
35
40
45
50
55
60
65
70
75
80
85
90
95
100
105
110
115
120
125
130
135
140
145
Telescoping mode
2nd Boom 0 50 100 0 100 0 100 0 100 0 100 0 100 50 100
3rd Boom 0 0 0 33 16 50 33 66 50 83 66 100 83 100 100
4th Boom 0 0 0 33 16 50 33 66 50 83 66 100 83 100 100
Top Boom 0 0 0 33 16 50 33 66 50 83 66 100 83 100 100
360° ROTATION
COUNTERWEIGHT 20,100 lbs (9.1 t)
ON OUTRIGGERS FULLY EXTENDED 23' 11-3/8" (7.3 m) SPREAD
68.1'
(20.8 m)
82.4'
(25.1 m)
96.8'
(29.5 m)
111.1'
(33.9 m)
125.5'
(38.3 m)
139.8'
(42.6 m)
102,500
181,900 102,500 90,200 40,100
159,700 102,500 90,200 40,100
133,800 102,500 90,200 40,100 42,500 35,500
101,500 100,800 81,500 40,100 42,500 35,500 40,100 33,300 35,500 32,200
78,300 77,600 68,500 40,100 42,500 35,500 40,100 33,300 35,500 32,200 33,300 32,200
60,800 59,900 58,700 40,100 42,500 35,500 40,100 33,300 35,500 32,200 33,300 28,800 31,500 28,900
45,700 44,400 40,100 42,500 35,500 39,700 33,300 35,500 30,800 33,300 25,500 31,500 27,200 24,900
35,500 34,400 40,100 36,400 35,500 35,000 30,500 32,300 27,600 29,800 22,800 28,100 24,500 24,900
28,300 27,300 33,200 29,200 33,800 30,200 27,600 28,800 24,900 26,500 20,700 24,900 22,200 23,200
22,100 27,700 23,900 28,400 24,900 25,100 25,700 22,700 23,900 18,800 22,300 20,300 21,100
18,100 23,500 19,900 24,200 20,900 23,100 21,600 20,800 21,600 17,300 20,200 18,700 19,100
15,000 20,200 16,600 20,800 17,600 21,200 18,300 19,200 18,800 15,900 18,300 17,300 17,300
14,000 18,100 15,000 18,500 15,700 17,700 16,100 14,800 16,500 16,100 15,800
11,800 15,900 12,800 16,200 13,500 16,400 14,000 13,800 14,300 15,000 14,400
10,100 14,100 11,000 14,400 11,700 14,600 12,100 12,700 12,500 13,600 12,700
9,400 12,700 10,100 13,000 10,500 11,800 10,900 12,000 11,100
8,100 11,400 8,700 11,600 9,200 11,000 9,500 10,600 9,800
7,600 10,400 8,000 10,300 8,300 9,500 8,600
6,500 9,300 7,000 9,500 7,300 8,400 7,500
5,600 8,400 6,100 8,500 6,400 7,500 6,600
5,300 7,700 5,600 6,700 5,800
4,500 7,000 4,900 6,000 5,100
3,900 6,300 4,200 5,300 4,500
3,600 4,700 3,900
3,100 4,200 3,300
2,700 3,700 2,800
2,400
2,000
1,700
NOTE: The lifting capacity data stored in the LOAD MOMENT INDICATOR (AML-E2) is based on the standard number of parts of line listed in the chart.
Standard number of parts of line for each boom length should be according to the following table.
SMART COUNTERWEIGHT
1,2 1 1 2 1 2 2 2 1 2 1 2 1, 21 1
Form No. GR-1000-4-00101/US-01
39.4'
(12 m)
1, 2
16
39.4' to 68.1'
(12 m to 20.8 m)
68.1' to 154.2'
(20.8 m to 47 m)
1, 2
4
2
4
1
8
Single top
jib
1, 2
1
Boom length in feet
(meters)
Telescoping mode
Number of parts of line
- 9 -

200,000
GR-1000XL-4 RATED LIFTING CAPACITIES (IN POUNDS)
A: Boom length in feet
B: Load radius in feet
A
B
8
10
12
15
20
25
30
35
40
45
50
55
60
65
70
75
80
85
90
95
100
105
110
115
120
125
130
135
140
145
Telescoping mode
2nd Boom 0 50 100 0 100 0 100 0 100 0 100 0 100 50 100
3rd Boom 0 0 0 33 16 50 33 66 50 83 66 100 83 100 100
4th Boom 0 0 0 33 16 50 33 66 50 83 66 100 83 100 100
Top Boom 0 0 0 33 16 50 33 66 50 83 66 100 83 100 100
COUNTERWEIGHT 20,100 lbs (9.1 t)
ON OUTRIGGERS FULLY EXTENDED 23' 11-3/8" (7.3 m) SPREAD
39.4'
(12 m)
53.7'
(16.4 m)
154.2'
(47 m)
68.1'
(20.8 m)
82.4'
(25.1 m)
96.8'
(29.5 m)
111.1'
(33.9 m)
125.5'
(38.3 m)
139.8'
(42.6 m)
102,500
181,900 102,500 90,200 40,100
159,700 102,500 90,200 40,100
133,800 102,500 90,200 40,100 42,500 35,500
101,500 100,800 81,500 40,100 42,500 35,500 40,100 33,300 35,500 32,200
78,300 77,600 68,500 40,100 42,500 35,500 40,100 33,300 35,500 32,200 33,300 32,200
60,800 59,900 58,700 40,100 42,500 35,500 40,100 33,300 35,500 32,200 33,300 28,800 31,500 28,900
47,800 47,100 40,100 42,500 35,500 39,700 33,300 35,500 30,800 33,300 25,500 31,500 27,200 24,900
39,400 38,600 40,100 38,700 35,500 35,000 30,500 32,300 27,600 29,800 22,800 28,100 24,500 24,900
33,000 32,300 36,800 33,900 35,500 31,100 27,600 28,800 24,900 26,500 20,700 24,900 22,200 23,200
27,100 31,800 28,900 32,400 27,900 25,100 25,900 22,700 23,900 18,800 22,300 20,300 21,100
22,400 27,800 24,100 28,400 25,100 23,100 23,300 20,800 21,600 17,300 20,200 18,700 19,100
18,600 24,100 20,300 24,600 21,300 21,300 21,200 19,200 19,600 15,900 18,300 17,300 17,300
17,300 21,500 18,200 19,800 18,900 17,700 17,900 14,800 16,700 16,100 15,800
14,700 18,900 15,700 18,500 16,400 16,500 16,500 13,800 15,300 15,000 14,400
12,700 16,800 13,600 17,100 14,200 15,400 14,700 12,700 14,100 14,000 13,200
11,800 15,200 12,500 14,500 12,900 11,800 13,000 13,100 12,200
10,300 13,600 10,900 13,600 11,400 11,000 11,700 12,300 11,200
9,600 12,500 10,000 10,300 10,300 11,500 10,400
8,400 11,300 8,900 9,600 9,200 10,300 9,400
7,400 10,300 7,800 9,000 8,100 9,300 8,400
6,900 8,500 7,200 8,300 7,500
6,100 8,000 6,400 7,500 6,600
5,400 7,600 5,700 6,800 5,900
5,000 6,100 5,200
4,400 5,500 4,700
3,900 5,000 4,100
3,600
3,200
2,800
NOTE: The lifting capacity data stored in the LOAD MOMENT INDICATOR (AML-E2) is based on the standard number of parts of line listed in the chart.
Standard number of parts of line for each boom length should be according to the following table.
SMART COUNTERWEIGHT
SMART CHART
1,2 1 1 2 1 2 2 2 1 2 1 2 1, 21 1
Form No. GR-1000-4-00101/US-01
39.4'
(12 m)
1, 2
16
39.4' to 68.1'
(12 m to 20.8 m)
68.1' to 154.2'
(20.8 m to 47 m)
1, 2
4
2
4
1
8
Single top
jib
1, 2
1
Boom length in feet
(meters)
Telescoping mode
Number of parts of line
20º 20º
20º 20º
- 10 -

GR-1000XL-4 RATED LIFTING CAPACITIES (IN POUNDS)
B: Load radius in feet
3.5° Offset 25° Offset 45° Offset
45
50
55
60
65
70
75
80
85
90
95
100
105
110
115
120
125
130
135
140
145
150
155
160
165
170
Telescoping
mode
Telescoping
mode
154.2' (47 m) Boom + 33.2 ' (10.1 m) JIB
B
45
40 40
50
55
60
65
70
75
80
85
90
95
100
105
110
115
120
125
130
135
140
145
150
155
160
165
170
B3.5° Offset 25° Offset 45° Offset
154.2' (47 m) Boom + 58.1 ' (17.7 m) JIB
3.5° Offset 25° Offset 45° Offset
40
45
50
55
60
65
70
75
80
85
90
95
100
105
110
115
120
125
130
135
140
145
150
155
160
165
170
175
180
Telescoping
mode
139.8' (42.6 m) Boom + 33.2 ' (10.1 m) JIB
B3.5° Offset 25° Offset 45° Offset
40
35 35
45
50
55
60
65
70
75
80
85
90
95
100
105
110
115
120
125
130
135
140
145
150
155
160
165
170
175
180
Telescoping
mode
139.8' (42.6 m) Boom + 58.1 ' (17.7 m) JIB
B
3.5° Offset 25° Offset 45° Offset
30
35
40
45
50
55
60
65
70
75
80
85
90
95
100
105
110
115
120
125
130
135
140
145
150
155
160
165
170
Telescoping
mode
125.5' (38.3 m) Boom + 33.2 ' (10.1 m) JIB
B3.5° Offset 25° Offset 45° Offset
30
35
40
45
50
55
60
65
70
75
80
85
90
95
100
105
110
115
120
125
130
135
140
145
150
155
160
165
170
Telescoping
mode
125.5' (38.3 m) Boom + 58.1 ' (17.7 m) JIB
B
COUNTERWEIGHT 20,100 lbs (9.1 t)
ON OUTRIGGERS FULLY EXTENDED 23' 11-3/8" (7.3 m) SPREAD
360° ROTATION
SMART COUNTERWEIGHT
COUNTERWEIGHT 20,100 lbs (9.1 t)
ON OUTRIGGERS FULLY EXTENDED 23' 11-3/8" (7.3 m) SPREAD
360° ROTATION
SMART COUNTERWEIGHT
COUNTERWEIGHT 20,100 lbs (9.1 t)
ON OUTRIGGERS FULLY EXTENDED 23' 11-3/8" (7.3 m) SPREAD
360° ROTATION
SMART COUNTERWEIGHT
14,600 14,300
14,600 14,300
14,100 13,000
14,600 14,300
14,100 13,000
11,900
14,600 14,300 13,900 13,700
14,100 13,000
11,900
14,600 14,300 13,300 13,100 10,500 10,400
14,100 13,000 13,400 13,000
11,900
14,600 13,900 12,800 12,600 10,200 10,100
14,100 13,000 12,900 12,800 10,300
11,900 11,900
14,600 12,700 12,300 11,600 10,000 9,900
14,100 13,000 12,400 12,200 10,000 10,000
11,900 11,900 10,000
14,600 11,700 11,800 10,800 9,800 9,700
14,100 12,500 12,000 11,400 9,800 9,700
11,900 11,900 9,800
14,600 10,800 11,400 10,000 9,500 9,500
14,100 11,600 11,600 10,600 9,600 9,500
11,900 11,100 9,600
13,700 10,000 11,100 9,400 9,400 9,000
13,600 10,800 11,300 9,900 9,400 9,400
11,900 10,400 9,400
12,100 9,300 10,800 8,800 9,200 8,500
12,200 10,000 10,900 9,300 9,200 8,900
10,800 9,800 9,300
10,600 8,700 10,400 8,200 9,100 8,000
10,800 9,400 10,600 8,800 9,100 8,400
10,100 9,200 8,800
9,400 8,100 10,200 7,700 8,900 7,500
9,500 8,800 10,300 8,200 8,900 8,000
9,500 8,700 8,300
8,300 7,600 9,100 7,300 8,800 7,100
8,400 8,300 9,300 7,800 8,800 7,500
8,400 8,200 7,900
7,400 7,100 8,100 6,900 8,500 6,700
7,500 7,800 8,200 7,400 8,700 7,100
7,400 7,800 7,500
6,500 6,700 7,100 6,500 7,500 6,400
6,600 7,300 7,300 7,000 7,700 6,800
6,600 7,400 7,200
5,700 6,300 6,300 6,100 6,600 6,000
5,800 6,700 6,500 6,600 6,800 6,500
5,800 6,500 6,800
5,000 6,000 5,500 5,800 5,800 5,700
5,100 6,000 5,700 6,300 6,000 6,200
5,100 5,800 6,200
4,400 5,600 4,800 5,500
4,500 5,400 5,000 5,800 5,300 5,900
4,500 5,100 5,400
3,800 5,300 4,200 5,200
3,900 4,800 4,400 5,200 4,600 5,400
3,900 4,400 4,800
3,300 5,100 3,600 5,000
3,400 4,200 3,800 4,600 4,000 4,800
3,400 3,900 4,100
2,800 4,700 3,100 4,700
2,900 3,700 3,300 4,100
2,900 3,300 3,600
2,400 4,200 2,600 4,400
2,500 3,300 2,800 3,600
2,400 2,800 3,000
2,000 3,800
2,100 2,900 2,300 3,100
2,000 2,400
3,400
1,700 2,500 1,900 2,700
1,700 2,000
1,300 2,200 1,500 2,300
1,300 1,600
1,000 1,900
1,000 1,200
9,300 8,400
9,300 8,400
8,200
9,300 8,400
8,200 7,700
7,300
9,300 8,400
8,200 7,700
7,300
9,300 8,400 6,800 6,700
8,200 7,700
7,300
8,900 8,400 6,600 6,400
8,200 7,700 6,500
7,300
8,500 8,200 6,400 6,200
8,200 7,700 6,300 6,200
7,300 6,200
8,200 7,900 6,200 6,000 5,200 5,100
8,100 7,700 6,100 6,100
7,300 6,000
7,800 7,600 6,000 5,900 5,000 5,000
7,800 7,700 6,000 5,900 5,100 5,100
7,300 5,900 5,100
7,500 7,300 5,800 5,700 4,900 4,900
7,500 7,400 5,800 5,700 5,000 5,000
7,300 5,700 5,000
7,300 7,000 5,600 5,500 4,800 4,700
7,300 7,100 5,600 5,600 5,000 4,900
7,200 5,600 4,900
7,000 6,600 5,500 5,400 4,700 4,600
7,000 6,900 5,500 5,400 4,900 4,800
7,000 5,400 4,800
6,700 6,200 5,400 5,300 4,500 4,500
6,800 6,700 5,400 5,300 4,800 4,800
6,700 5,300 4,800
6,500 5,800 5,200 5,100 4,500 4,400
6,600 6,300 5,200 5,200 4,700 4,700
6,500 5,200 4,700
6,300 5,400 5,100 5,000 4,400 4,300
6,400 5,900 5,100 5,100 4,600 4,600
6,100 5,100 4,600
5,800 5,100 5,000 4,900 4,300 4,200
5,700 5,600 5,000 5,000 4,500 4,500
5,400 5,000 4,500
5,200 4,800 4,800 4,700 4,200 4,200
5,000 5,200 4,900 4,900 4,400 4,400
4,800 4,900 4,500
4,600 4,500 4,700 4,400 4,100 4,100
4,400 5,000 4,800 4,700 4,400 4,300
4,200 4,800 4,400
4,000 4,300 4,600 4,200 4,100 4,000
3,900 4,700 4,700 4,500 4,300 4,300
3,700 4,700 4,400
3,500 4,100 4,300 4,000 4,000 3,900
3,400 4,300 4,300 4,300 4,200 4,200
3,200 4,100 4,300
3,100 3,800 3,700 3,800 4,000 3,700
3,000 3,800 3,800 4,100 4,200 4,200
2,800 3,600 4,200
2,700 3,600 3,200 3,600
2,600 3,400 3,300 3,900 3,600 4,000
2,400 3,200 3,700
2,300 3,400 2,800 3,400
2,200 3,000 2,800 3,500 3,200 3,800
2,000 2,700 3,200
1,900 3,300 2,400 3,200
1,800 2,600 2,400 3,100
1,600 2,300 2,700
1,600 3,100 2,000 3,100
1,500 2,300 2,000 2,700
1,300 1,900 2,300
1,300 2,900 1,600 2,900
1,200 2,000 1,700 2,400
1,600 1,900
1,000 2,600
1,700 1,300 2,000
1,200
1,500 1,700
1,200 1,400
1, 21, 2
1 1 12 2 2 1 1 12 2 2
1 1 12 2 2 1 1 12 2 2
1, 2 1, 21, 2 1, 2
Form No. GR-1000-4-00101/US-01
- 11 -

GR-1000XL-4 RATED LIFTING CAPACITIES (IN POUNDS)
B: Load radius in feet
3.5° Offset 25° Offset 45° Offset
45
50
55
60
65
70
75
80
85
90
95
100
105
110
115
120
125
130
135
140
145
150
155
160
165
170
175
180
Telescoping
mode
Telescoping
mode
COUNTERWEIGHT 20,100 lbs (9.1 t)
ON OUTRIGGERS FULLY EXTENDED 23' 11-3/8" (7.3 m) SPREAD
SMART CHART
SMART COUNTERWEIGHT
COUNTERWEIGHT 20,100 lbs (9.1 t)
ON OUTRIGGERS FULLY EXTENDED 23' 11-3/8" (7.3 m) SPREAD
SMART CHART
SMART COUNTERWEIGHT
COUNTERWEIGHT 20,100 lbs (9.1 t)
ON OUTRIGGERS FULLY EXTENDED 23' 11-3/8" (7.3 m) SPREAD
SMART CHART
SMART COUNTERWEIGHT
B
45
40 40
50
55
60
65
70
75
80
85
90
95
100
105
110
115
120
125
130
135
140
145
150
155
160
165
170
175
180
B3.5° Offset 25° Offset 45° Offset
3.5° Offset 25° Offset 45° Offset
40
45
50
55
60
65
70
75
80
85
90
95
100
105
110
115
120
125
130
135
140
145
150
155
160
165
170
175
180
Telescoping
mode
B3.5° Offset 25° Offset 45° Offset
40
45
50
55
60
65
70
75
80
85
90
95
100
105
110
115
120
125
130
135
140
145
150
155
160
165
170
175
180
Telescoping
mode
B
3.5° Offset 25° Offset 45° Offset
30
35
40
45
50
55
60
65
70
75
80
85
90
95
100
105
110
115
120
125
130
135
140
145
150
155
160
165
170
Telescoping
mode
B3.5° Offset 25° Offset 45° Offset
30
35
40
45
50
55
60
65
70
75
80
85
90
95
100
105
110
115
120
125
130
135
140
145
150
155
160
165
170
Telescoping
mode
B
154.2' (47 m) Boom + 33.2 ' (10.1 m) JIB 154.2' (47 m) Boom + 58.1 ' (17.7 m) JIB
139.8' (42.6 m) Boom + 33.2 ' (10.1 m) JIB 139.8' (42.6 m) Boom + 58.1 ' (17.7 m) JIB
125.5' (38.3 m) Boom + 33.2 ' (10.1 m) JIB 125.5' (38.3 m) Boom + 58.1 ' (17.7 m) JIB
35 35
14,600 14,300
14,600 14,300
14,100 13,000
14,600 14,300
14,100 13,000
11,900
14,600 14,300 13,900 13,700
14,100 13,000
11,900
14,600 14,300 13,300 13,100 10,500 10,400
14,100 13,000 13,400 13,000
11,900
14,600 13,900 12,800 12,600 10,200 10,100
14,100 13,000 12,900 12,800 10,300
11,900 11,900
14,600 12,700 12,300 11,600 10,000 9,900
14,100 13,000 12,400 12,200 10,000 10,000
11,900 11,900 10,000
14,600 11,700 11,800 10,800 9,800 9,700
14,100 12,500 12,000 11,400 9,800 9,700
11,900 11,900 9,800
14,600 10,800 11,400 10,000 9,500 9,500
14,100 11,600 11,600 10,600 9,600 9,500
11,900 11,100 9,600
14,300 10,000 11,100 9,400 9,400 9,000
13,600 10,800 11,300 9,900 9,400 9,400
11,900 10,400 9,400
13,200 9,300 10,800 8,800 9,200 8,500
12,500 10,000 10,900 9,300 9,200 8,900
10,800 9,800 9,300
12,200 8,700 10,400 8,200 9,100 8,000
11,500 9,400 10,600 8,800 9,100 8,400
10,100 9,200 8,800
11,300 8,100 10,200 7,700 8,900 7,500
10,600 8,800 10,300 8,200 8,900 8,000
9,500 8,700 8,300
10,300 7,600 9,900 7,300 8,800 7,100
9,800 8,300 10,000 7,800 8,800 7,500
8,900 8,200 7,900
9,100 7,100 9,700 6,900 8,700 6,700
9,100 7,800 9,300 7,400 8,700 7,100
8,400 7,800 7,500
8,200 6,700 8,800 6,500 8,600 6,400
8,300 7,300 8,600 7,000 8,600 6,800
7,900 7,400 7,200
7,300 6,300 7,900 6,100 8,200 6,000
7,400 6,900 8,000 6,600 8,100 6,500
7,400 7,100 6,800
6,500 6,000 7,000 5,800 7,300 5,700
6,600 6,600 7,200 6,300 7,500 6,200
6,700 6,700 6,500
5,800 5,600 6,300 5,500
5,900 6,200 6,400 6,000 6,700 5,900
6,000 6,400 6,200
5,200 5,300 5,600 5,200
5,300 5,900 5,700 5,700 5,900 5,600
5,300 5,900 6,000
4,600 5,100 4,900 5,000
4,700 5,500 5,100 5,400 5,200 5,400
4,700 5,200 5,400
4,000 4,800 4,300 4,700
4,100 5,000 4,500 5,200
4,200 4,600 4,800
3,500 4,600 3,700 4,500
3,600 4,500 3,900 4,800
3,700 4,100 4,300
3,100 4,400
3,200 4,000 3,400 4,300
3,200 3,600
4,200
2,800 3,600 3,000 3,800
2,800 3,100
2,400 3,200 2,500 3,400
2,400 2,700
2,000 2,800
2,100 2,300
1,700 1,900
1,400
9,300 8,400
9,300 8,400
8,200
9,300 8,400
8,200 7,700
7,300
9,300 8,400
8,200 7,700
7,300
9,300 8,400 6,800 6,700
8,200 7,700
7,300
8,900 8,400 6,600 6,400
8,200 7,700 6,500
7,300
8,500 8,200 6,400 6,200
8,200 7,700 6,300 6,200
7,300 6,200
8,200 7,900 6,200 6,000 5,200 5,100
8,100 7,700 6,100 6,100
7,300 6,000
7,800 7,600 6,000 5,900 5,000 5,000
7,800 7,700 6,000 5,900 5,100 5,100
7,300 5,900 5,100
7,500 7,300 5,800 5,700 4,900 4,900
7,500 7,400 5,800 5,700 5,000 5,000
7,300 5,700 5,000
7,300 7,000 5,600 5,500 4,800 4,700
7,300 7,100 5,600 5,600 5,000 4,900
7,200 5,600 4,900
7,000 6,600 5,500 5,400 4,700 4,600
7,000 6,900 5,500 5,400 4,900 4,800
7,000 5,400 4,800
6,700 6,200 5,400 5,300 4,500 4,500
6,800 6,700 5,400 5,300 4,800 4,800
6,700 5,300 4,800
6,500 5,800 5,200 5,100 4,500 4,400
6,600 6,300 5,200 5,200 4,700 4,700
6,500 5,200 4,700
6,300 5,400 5,100 5,000 4,400 4,300
6,400 5,900 5,100 5,100 4,600 4,600
6,300 5,100 4,600
6,100 5,100 5,000 4,900 4,300 4,200
6,200 5,600 5,000 5,000 4,500 4,500
6,000 5,000 4,500
5,900 4,800 4,800 4,700 4,200 4,200
6,000 5,200 4,900 4,900 4,400 4,400
5,600 4,900 4,500
5,800 4,500 4,700 4,400 4,100 4,100
5,800 5,000 4,800 4,700 4,400 4,300
5,400 4,800 4,400
5,300 4,300 4,600 4,200 4,100 4,000
5,300 4,700 4,700 4,500 4,300 4,300
5,000 4,700 4,400
4,800 4,100 4,500 4,000 4,000 3,900
4,700 4,500 4,500 4,300 4,200 4,200
4,500 4,500 4,300
4,300 3,800 4,400 3,800 4,000 3,700
4,200 4,200 4,500 4,100 4,200 4,200
4,000 4,300 4,300
3,800 3,600 4,300 3,600
3,800 4,000 4,300 3,900 4,100 4,000
3,500 4,100 4,300
3,400 3,400 3,900 3,400
3,400 3,800 3,900 3,700 4,100 3,800
3,100 3,900 4,200
3,000 3,300 3,400 3,200
3,000 3,600 3,500 3,500
2,800 3,400 3,800
2,600 3,100 3,000 3,100
2,600 3,300 3,100 3,400
2,400 3,000 3,400
2,300 3,000 2,500 2,900
2,200 3,000 2,600 3,200
2,100 2,600 2,900
2,000 2,800
1,900 2,600 2,300 3,000
1,800 2,200
1,600 2,400 1,900 2,600
1,500 1,900
1,300 2,100 1,500 2,200
1,200 1,600
1, 21, 2
1 1 12 2 2 1 1 12 2 2
1 1 12 2 2 1 1 12 2 2
1, 2 1, 21, 2 1, 2
Form No. GR-1000-4-00101/US-01
- 12 -

GR-1000XL-4 RATED LIFTING CAPACITIES (IN POUNDS)
A: Boom length in feet
B: Load radius in feet
A
B
10
8
12
15
20
25
30
35
40
45
50
55
60
65
70
75
80
85
90
95
100
105
110
115
120
125
130
Telescoping mode
2nd Boom 0 50 100 0 100 0 100 0 100 0 100 0 100 50 100
3rd Boom 0 0 0 33 16 50 33 66 50 83 66 100 83 100 100
4th Boom 0 0 0 33 16 50 33 66 50 83 66 100 83 100 100
Top Boom 0 0 0 33 16 50 33 66 50 83 66 100 83 100 100
200,000
SMART COUNTERWEIGHT
360° ROTATION
COUNTERWEIGHT 20,100 lbs (9.1 t)
ON OUTRIGGERS MIDDLE EXTENDED 21' 11-3/4" (6.7 m) SPREAD
102,500
177,300 102,500 90,200 40,100
155,100 102,500 90,200 40,100
129,600 102,500 90,200 40,100 42,500 35,500
99,700 99,200 81,500 40,100 42,500 35,500 40,100 33,300 35,500 32,200
73,100 71,400 68,500 40,100 42,500 35,500 40,100 33,300 35,500 32,200 33,300 32,200
50,900 49,500 48,100 40,100 42,500 35,500 40,100 33,300 35,500 32,200 33,300 28,800 31,500 28,900
36,600 35,400 40,100 37,500 35,500 38,700 33,300 35,500 30,800 33,300 25,500 31,500 27,200 24,900
28,100 27,200 33,200 29,100 33,800 30,200 30,500 31,000 27,600 29,800 22,800 28,100 24,500 24,900
22,100 21,200 26,900 23,100 27,600 24,200 27,600 24,900 24,900 25,400 20,700 24,900 22,200 23,200
16,800 22,300 18,700 23,100 19,700 23,400 20,400 22,700 21,000 18,800 21,300 20,300 21,100
13,400 18,800 15,300 19,500 16,300 19,900 17,000 20,100 17,500 17,300 17,900 18,700 18,200
10,800 16,000 12,500 16,600 13,500 17,000 14,200 17,300 14,700 15,900 15,100 16,300 15,400
10,200 14,300 11,300 14,700 12,000 15,000 12,500 14,800 12,800 14,000 13,100
8,400 12,400 9,400 12,800 10,100 13,100 10,600 13,200 11,000 12,100 11,200
6,900 10,800 7,800 11,200 8,500 11,400 9,000 11,600 9,400 10,500 9,600
6,500 9,800 7,200 10,000 7,700 10,200 8,000 9,200 8,300
5,300 8,600 6,000 8,800 6,500 9,000 6,900 8,000 7,100
5,000 7,800 5,500 8,000 5,800 7,000 6,100
4,100 6,900 4,600 7,000 4,900 6,100 5,200
3,400 6,100 3,800 6,200 4,100 5,200 4,400
3,100 5,500 3,400 4,500 3,700
2,500 4,900 2,800 3,900 3,100
2,000 4,400 2,200 3,300 2,500
1,700 2,800 2,000
1,300 2,400 1,500
2,000 1,100
39.4'
(12 m)
53.7'
(16.4 m)
154.2'
(47 m)
68.1'
(20.8 m)
82.4'
(25.1 m)
96.8'
(29.5 m)
111.1'
(33.9 m)
125.5'
(38.3 m)
139.8'
(42.6 m)
NOTE: The lifting capacity data stored in the LOAD MOMENT INDICATOR (AML-E2) is based on the standard number of parts of line listed in the chart.
Standard number of parts of line for each boom length should be according to the following table.
1,2 1 1 2 1 2 2 2 1 2 1 2 1, 21 1
Form No. GR-1000-4-00101/US-01
39.4'
(12 m)
1, 2
16
39.4' to 68.1'
(12 m to 20.8 m)
68.1' to 154.2'
(20.8 m to 47 m)
1, 2
4
2
4
1
8
Single top
jib
1, 2
1
Boom length in feet
(meters)
Telescoping mode
Number of parts of line
- 13 -

GR-1000XL-4 RATED LIFTING CAPACITIES (IN POUNDS)
B: Load radius in feet
3.5° Offset 25° Offset 45° Offset
45
50
55
60
65
70
75
80
85
90
95
100
105
110
115
120
125
130
135
140
145
150
155
160
Telescoping
mode
Telescoping
mode
154.2' (47 m) Boom + 33.2 ' (10.1 m) JIB
B
45
40 40
50
55
60
65
70
75
80
85
90
95
100
105
110
115
120
125
130
135
140
145
150
155
160
B3.5° Offset 25° Offset 45° Offset
154.2' (47 m) Boom + 58.1 ' (17.7 m) JIB
3.5° Offset 25° Offset 45° Offset
40
45
50
55
60
65
70
75
80
85
90
95
100
105
110
115
120
125
130
135
140
145
150
155
160
165
Telescoping
mode
139.8' (42.6 m) Boom + 33.2 ' (10.1 m) JIB
B3.5° Offset 25° Offset 45° Offset
40
35 35
45
50
55
60
65
70
75
80
85
90
95
100
105
110
115
120
125
130
135
140
145
150
155
160
165
Telescoping
mode
139.8' (42.6 m) Boom + 58.1 ' (17.7 m) JIB
B
3.5° Offset 25° Offset 45° Offset
30
35
40
45
50
55
60
65
70
75
80
85
90
95
100
105
110
115
120
125
130
135
140
145
150
155
160
165
170
Telescoping
mode
125.5' (38.3 m) Boom + 33.2 ' (10.1 m) JIB
B3.5° Offset 25° Offset 45° Offset
30
35
40
45
50
55
60
65
70
75
80
85
90
95
100
105
110
115
120
125
130
135
140
145
150
155
160
165
170
Telescoping
mode
125.5' (38.3 m) Boom + 58.1 ' (17.7 m) JIB
B
COUNTERWEIGHT 20,100 lbs (9.1 t)
ON OUTRIGGERS MIDDLE EXTENDED 21' 11-3/4" (6.7 m) SPREAD
360° ROTATION
SMART COUNTERWEIGHT
COUNTERWEIGHT 20,100 lbs (9.1 t)
ON OUTRIGGERS MIDDLE EXTENDED 21' 11-3/4" (6.7 m) SPREAD
360° ROTATION
SMART COUNTERWEIGHT
COUNTERWEIGHT 20,100 lbs (9.1 t)
ON OUTRIGGERS MIDDLE EXTENDED 21' 11-3/4" (6.7 m) SPREAD
360° ROTATION
SMART COUNTERWEIGHT
14,600 14,300
14,600 14,300
14,100 13,000
14,600 14,300
14,100 13,000
11,900
14,600 14,300 13,900 13,700
14,100 13,000
11,900
14,600 14,300 13,300 13,100 10,500 10,400
14,100 13,000 13,400 13,000
11,900
14,600 13,900 12,800 12,600 10,200 10,100
14,100 13,000 12,900 12,800 10,300
11,900 11,900
14,600 12,700 12,300 11,600 10,000 9,900
14,100 13,000 12,400 12,200 10,000 10,000
11,900 11,900 10,000
14,200 11,700 11,800 10,800 9,800 9,700
14,100 12,500 12,000 11,400 9,800 9,700
11,900 11,900 9,800
12,200 10,800 11,400 10,000 9,500 9,500
12,300 11,600 11,600 10,600 9,600 9,500
11,900 11,100 9,600
10,500 10,000 11,100 9,400 9,400 9,000
10,600 10,800 11,300 9,900 9,400 9,400
10,800 10,400 9,400
9,100 9,300 10,200 8,800 9,200 8,500
9,200 10,000 10,300 9,300 9,200 8,900
9,300 9,800 9,300
7,900 8,700 8,900 8,200 9,100 8,000
8,000 8,900 9,000 8,800 9,100 8,400
8,100 9,100 8,800
6,800 8,100 7,700 7,700 8,300 7,500
6,900 7,800 7,800 8,200 8,500 8,000
7,000 8,000 8,300
5,900 7,600 6,700 7,300 7,200 7,100
6,000 6,900 6,800 7,600 7,400 7,500
6,100 6,900 7,500
5,000 7,000 5,800 6,900 6,200 6,700
5,200 6,000 5,900 6,700 6,400 7,100
5,300 6,000 6,500
4,300 6,200 5,000 6,500 5,300 6,400
4,400 5,300 5,100 5,900 5,500 6,300
4,500 5,200 5,700
3,600 5,500 4,200 6,000 4,500 6,000
3,700 4,600 4,400 5,200 4,700 5,500
3,800 4,500 4,900
3,000 4,900 3,500 5,300 3,800 5,500
3,200 4,000 3,700 4,500 4,000 4,800
3,200 3,900 4,200
2,500 4,400 3,000 4,700
2,600 3,500 3,100 3,900 3,400 4,200
2,700 3,200 3,500
2,000 3,900 2,400 4,200
2,100 3,000 2,600 3,400 2,800 3,600
2,200 2,700 3,000
1,500 3,400 1,900 3,700
1,700 2,500 2,100 2,900 2,200 3,000
1,700 2,200 2,400
1,100 3,000 1,400 3,200
1,200 2,100 1,600 2,400
1,300 1,700 1,900
2,600 2,800
1,700 1,200 2,000
1,300 1,500
2,200
1,300 1,600
1,900
1,000 1,200
9,300 8,400
9,300 8,400
8,200
9,300 8,400
8,200 7,700
7,300
9,300 8,400
8,200 7,700
7,300
9,300 8,400 6,800 6,700
8,200 7,700
7,300
8,900 8,400 6,600 6,400
8,200 7,700 6,500
7,300
8,500 8,200 6,400 6,200
8,200 7,700 6,300 6,200
7,300 6,200
8,200 7,900 6,200 6,000 5,200 5,100
8,100 7,700 6,100 6,100
7,300 6,000
7,800 7,600 6,000 5,900 5,000 5,000
7,800 7,700 6,000 5,900 5,100 5,100
7,300 5,900 5,100
7,500 7,300 5,800 5,700 4,900 4,900
7,500 7,400 5,800 5,700 5,000 5,000
7,300 5,700 5,000
7,300 7,000 5,600 5,500 4,800 4,700
7,300 7,100 5,600 5,600 5,000 4,900
7,200 5,600 4,900
6,700 6,600 5,500 5,400 4,700 4,600
6,700 6,900 5,500 5,400 4,900 4,800
6,700 5,400 4,800
5,900 6,200 5,400 5,300 4,500 4,500
5,900 6,600 5,400 5,300 4,800 4,800
5,900 5,300 4,800
5,100 5,800 5,200 5,100 4,500 4,400
5,100 5,900 5,200 5,200 4,700 4,700
5,100 5,200 4,700
4,400 5,400 5,100 5,000 4,400 4,300
4,400 5,200 5,100 5,100 4,600 4,600
4,400 5,100 4,600
3,800 5,100 4,900 4,900 4,300 4,200
3,800 4,600 4,900 5,000 4,500 4,500
3,800 4,900 4,500
3,300 4,800 4,200 4,700 4,200 4,200
3,300 4,000 4,300 4,900 4,400 4,400
3,200 4,300 4,500
2,800 4,400 3,600 4,400 4,100 4,100
2,800 3,500 3,700 4,300 4,300 4,300
2,700 3,700 4,400
2,300 3,900 3,100 4,200 3,500 4,000
2,300 3,000 3,100 3,800 3,700 4,300
2,300 3,200 3,800
1,900 3,500 2,600 4,000 3,000 3,900
1,900 2,600 2,600 3,300 3,100 3,700
1,900 2,700 3,200
1,500 3,100 2,100 3,600 2,400 3,700
1,500 2,200 2,200 2,900 2,600 3,200
1,500 2,200 2,700
1,100 2,700 1,700 3,200
1,100 1,900 1,800 2,400 2,100 2,800
1,100 1,800 2,200
2,400 1,300 2,800
1,500 1,400 2,100 1,700 2,300
1,400 1,800
2,100 2,400
1,200 1,000 1,700
1,100 1,400
1,800 2,000
1,300
1,000
1,500 1,700
1,000
1,300
1, 21, 2
1 1 12 2 2 1 1 12 2 2
1 1 12 2 2 1 1 12 2 2
1, 2 1, 21, 2 1, 2
Form No. GR-1000-4-00101/US-01
- 14 -

GR-1000XL-4 RATED LIFTING CAPACITIES (IN POUNDS)
A: Boom length in feet
B: Load radius in feet
SMART COUNTERWEIGHT
A
B
10
8
12
15
20
25
30
35
40
45
50
55
60
65
70
75
80
85
90
95
100
105
110
115
120
Telescoping mode
2nd Boom 0 50 100 0 100 0 100 0 100 0 100 0 100 50 100
3rd Boom 0 0 0 33 16 50 33 66 50 83 66 100 83 100 100
4th Boom 0 0 0 33 16 50 33 66 50 83 66 100 83 100 100
Top Boom 0 0 0 33 16 50 33 66 50 83 66 100 83 100 100
360° ROTATION
COUNTERWEIGHT 20,100 lbs (9.1 t)
ON OUTRIGGERS MIDDLE EXTENDED 18' 1/2" (5.5 m) SPREAD
193,500 102,500
165,800 102,500 90,200 40,100
144,000 102,500 90,200 40,100
119,400 102,500 90,200 40,100 42,500 35,500
82,300 80,500 78,800 40,100 42,500 35,500 40,100 33,300 35,500 32,200
52,900 51,600 50,200 40,100 42,500 35,500 40,100 33,300 35,500 32,200 33,300 32,200
37,600 36,400 35,300 40,100 37,400 35,500 38,500 33,300 35,500 32,200 33,300 28,800 31,500 28,900
26,900 26,000 32,000 27,900 32,600 29,000 32,900 29,800 30,800 30,400 25,500 30,800 27,200 24,900
20,500 19,700 25,300 21,600 26,000 22,600 26,400 23,300 26,600 23,900 22,800 24,300 24,500 24,600
15,900 15,100 20,500 17,000 21,200 18,000 21,600 18,700 21,800 19,200 20,700 19,600 20,900 19,900
11,600 16,900 13,400 17,600 14,500 18,000 15,200 18,200 15,700 18,400 16,100 17,300 16,400
9,000 14,100 10,700 14,700 11,800 15,200 12,500 15,400 12,900 15,600 13,300 14,500 13,600
6,900 11,900 8,500 12,500 9,500 12,900 10,200 13,200 10,700 13,300 11,100 12,200 11,400
6,700 10,600 7,700 11,000 8,400 11,300 8,900 11,500 9,300 10,400 9,500
5,200 9,100 6,200 9,400 6,900 9,700 7,400 9,900 7,700 8,900 8,000
3,900 7,800 4,900 8,100 5,600 8,400 6,100 8,600 6,500 7,600 6,700
3,800 7,000 4,500 7,200 4,900 7,400 5,300 6,400 5,600
2,800 6,000 3,500 6,300 4,000 6,400 4,300 5,400 4,600
2,600 5,400 3,100 5,600 3,500 4,600 3,800
1,900 4,700 2,400 4,800 2,800 3,800 3,000
1,300 4,000 1,700 4,100 2,100 3,200 2,400
1,200 3,500 1,500 2,600 1,800
3,000 2,100
2,600 1,600
1,200
39.4'
(12 m)
53.7'
(16.4 m)
154.2'
(47 m)
68.1'
(20.8 m)
82.4'
(25.1 m)
96.8'
(29.5 m)
111.1'
(33.9 m)
125.5'
(38.3 m)
139.8'
(42.6 m)
NOTE: The lifting capacity data stored in the LOAD MOMENT INDICATOR (AML-E2) is based on the standard number of parts of line listed in the chart.
Standard number of parts of line for each boom length should be according to the following table.
1, 2 1 1 2 1 2 2 2 1 2 1 2 1, 21 1
Form No. GR-1000-4-00101/US-01
39.4'
(12 m)
1, 2
16
39.4' to 68.1'
(12 m to 20.8 m)
68.1' to 154.2'
(20.8 m to 47 m)
1, 2
4
2
4
1
8
Single top
jib
1, 2
1
Boom length in feet
(meters)
Telescoping mode
Number of parts of line
- 15 -

GR-1000XL-4 RATED LIFTING CAPACITIES (IN POUNDS)
B: Load radius in feet
3.5° Offset 25° Offset 45° Offset
45
50
55
60
65
70
75
80
85
90
95
100
105
110
115
120
125
130
135
Telescoping
mode
Telescoping
mode
154.2' (47 m) Boom + 33.2 ' (10.1 m) JIB
B
45
40 40
50
55
60
65
70
75
80
85
90
95
100
105
110
115
120
125
130
135
B3.5° Offset 25° Offset 45° Offset
154.2' (47 m) Boom + 58.1 ' (17.7 m) JIB
3.5° Offset 25° Offset 45° Offset
40
45
50
55
60
65
70
75
80
85
90
95
100
105
110
115
120
125
130
135
140
145
150
Telescoping
mode
139.8' (42.6 m) Boom + 33.2 ' (10.1 m) JIB
B3.5° Offset 25° Offset 45° Offset
40
35 35
45
50
55
60
65
70
75
80
85
90
95
100
105
110
115
120
125
130
135
140
145
150
Telescoping
mode
139.8' (42.6 m) Boom + 58.1 ' (17.7 m) JIB
B
3.5° Offset 25° Offset 45° Offset
30
35
40
45
50
55
60
65
70
75
80
85
90
95
100
105
110
115
120
125
130
135
140
145
150
155
Telescoping
mode
125.5' (38.3 m) Boom + 33.2 ' (10.1 m) JIB
B3.5° Offset 25° Offset 45° Offset
30
35
40
45
50
55
60
65
70
75
80
85
90
95
100
105
110
115
120
125
130
135
140
145
150
155
Telescoping
mode
125.5' (38.3 m) Boom + 58.1 ' (17.7 m) JIB
B
COUNTERWEIGHT 20,100 lbs (9.1 t)
ON OUTRIGGERS MIDDLE EXTENDED 18' 1/2" (5.5 m) SPREAD
360° ROTATION
SMART COUNTERWEIGHT
COUNTERWEIGHT 20,100 lbs (9.1 t)
ON OUTRIGGERS MIDDLE EXTENDED 18' 1/2" (5.5 m) SPREAD
360° ROTATION
SMART COUNTERWEIGHT
COUNTERWEIGHT 20,100 lbs (9.1 t)
ON OUTRIGGERS MIDDLE EXTENDED 18' 1/2" (5.5 m) SPREAD
360° ROTATION
SMART COUNTERWEIGHT
14,600 14,300
14,600 14,300
14,100 13,000
14,600 14,300
14,100 13,000
11,900
14,600 14,300 13,900 13,700
14,100 13,000
11,900
14,600 14,300 13,300 13,100 10,500 10,400
14,100 13,000 13,400 13,000
11,900
14,600 13,900 12,800 12,600 10,200 10,100
14,100 13,000 12,900 12,800 10,300
11,900 11,900
12,400 12,700 12,300 11,600 10,000 9,900
12,500 13,000 12,400 12,200 10,000 10,000
11,900 11,900 10,000
10,500 11,700 11,800 10,800 9,800 9,700
10,600 11,500 12,000 11,400 9,800 9,700
10,700 11,900 9,800
8,900 10,800 10,100 10,000 9,500 9,500
9,000 9,900 10,300 10,600 9,600 9,500
9,100 10,400 9,600
7,500 9,400 8,700 9,400 9,400 9,000
7,600 8,500 8,800 9,600 9,400 9,400
7,700 8,900 9,400
6,300 8,300 7,400 8,800 8,100 8,500
6,500 7,400 7,500 8,300 8,300 8,900
6,600 7,600 8,400
5,300 7,200 6,300 8,000 6,900 8,000
5,400 6,300 6,400 7,200 7,100 7,800
5,600 6,500 7,200
4,500 6,300 5,300 7,000 5,900 7,500
4,600 5,400 5,500 6,300 6,100 6,800
4,700 5,600 6,200
3,700 5,600 4,500 6,200 4,900 6,500
3,800 4,700 4,600 5,400 5,100 5,900
3,900 4,700 5,300
3,000 4,900 3,700 5,400 4,100 5,700
3,100 3,900 3,800 4,600 4,300 5,000
3,200 3,900 4,500
2,400 4,200 3,000 4,700 3,400 5,000
2,500 3,300 3,200 3,900 3,500 4,300
2,600 3,300 3,700
1,800 3,700 2,400 4,100 2,700 4,300
1,900 2,800 2,500 3,300 2,900 3,600
2,000 2,600 3,000
1,300 3,200 1,800 3,500 2,000 3,700
1,400 2,200 2,000 2,800 2,300 3,000
1,500 2,100 2,400
2,700 1,300 3,000
1,800 1,500 2,200 1,700 2,500
1,600 1,900
2,300 2,600
1,400 1,000 1,800 1,200 2,000
1,100 1,400
1,900 2,100
1,000 1,400 1,500
1,500 1,700
1,200 1,400
9,300 8,400
9,300 8,400
8,200
9,300 8,400
8,200 7,700
7,300
9,300 8,400
8,200 7,700
7,300
9,300 8,400 6,800 6,700
8,200 7,700
7,300
8,900 8,400 6,600 6,400
8,200 7,700 6,500
7,300
8,500 8,200 6,400 6,200
8,200 7,700 6,300 6,200
7,300 6,200
8,200 7,900 6,200 6,000 5,200 5,100
8,100 7,700 6,100 6,100
7,300 6,000
7,200 7,600 6,000 5,900 5,000 5,000
7,200 7,700 6,000 5,900 5,100 5,100
7,200 5,900 5,100
6,200 7,300 5,800 5,700 4,900 4,900
6,200 6,900 5,800 5,700 5,000 5,000
6,200 5,700 5,000
5,300 6,900 5,600 5,500 4,800 4,700
5,300 6,000 5,600 5,600 5,000 4,900
5,300 5,600 4,900
4,500 6,100 5,500 5,400 4,700 4,600
4,500 5,200 5,500 5,400 4,900 4,800
4,500 5,400 4,800
3,800 5,400 5,100 5,300 4,500 4,500
3,800 4,500 5,100 5,300 4,800 4,800
3,800 5,100 4,800
3,200 4,700 4,300 5,100 4,500 4,400
3,200 3,900 4,400 5,000 4,700 4,700
3,100 4,400 4,700
2,600 4,200 3,700 5,000 4,400 4,300
2,600 3,300 3,700 4,400 4,500 4,600
2,600 3,700 4,600
2,100 3,700 3,100 4,500 3,700 4,200
2,100 2,800 3,100 3,800 3,900 4,400
2,100 3,200 3,900
1,600 3,200 2,500 3,900 3,100 4,200
1,600 2,300 2,600 3,200 3,200 3,800
1,600 2,600 3,300
1,200 2,800 2,000 3,400 2,500 3,800
1,200 1,900 2,100 2,700 2,700 3,300
2,100 2,800
2,400 1,600 3,000 2,000 3,300
1,500 1,600 2,300 2,100 2,700
1,700 2,200
2,000 1,100 2,600 1,500 2,800
1,100 1,200 1,900 1,700 2,300
1,700
1,700 2,200 1,000 2,400
1,500 1,200 1,800
1,300 1,800
1,100 1,400
1,100 1,500
1,000
1,100
1, 21, 2
1 1 12 2 2 1 1 12 2 2
1 1 12 2 2 1 1 12 2 2
1, 2 1, 21, 2 1, 2
Form No. GR-1000-4-00101/US-01
- 16 -

GR-1000XL-4 RATED LIFTING CAPACITIES (IN POUNDS)
A: Boom length in feet
B: Load radius in feet
SMART COUNTERWEIGHT
A
B
12
10
8
15
20
25
30
35
40
45
50
55
60
65
70
75
80
Telescoping mode
2nd Boom 0 50 100 0 100 0 100 0 100 0 100 0 100 50 100
3rd Boom 0 0 0 33 16 50 33 66 50 83 66 100 83 100 100
4th Boom 0 0 0 33 16 50 33 66 50 83 66 100 83 100 100
Top Boom 0 0 0 33 16 50 33 66 50 83 66 100 83 100 100
360° ROTATION
COUNTERWEIGHT 20,100lbs (9.1 t)
ON OUTRIGGERS MINNIMUM EXTENDED 8' 10-5/16" (2.7 m) SPREAD
143,100 102,500
108,800 102,500 90,200 40,100
77,200 75,500 73,900 40,100
51,900 50,700 49,400 40,100 42,500 35,500
31,300 30,400 29,300 35,500 31,400 35,500 32,500 33,300 33,300 32,200
20,800 19,900 19,100 24,700 21,000 25,300 22,000 25,700 22,800 25,900 23,300 26,100
14,500 13,500 12,700 18,100 14,700 18,800 15,600 19,100 16,300 19,400 16,800 19,500 17,200 18,400
9,200 8,400 13,500 10,300 14,200 11,300 14,700 12,000 14,900 12,500 15,100 12,800 14,000 12,800
6,100 5,400 10,300 7,100 11,000 8,200 11,400 8,900 11,800 9,300 11,900 9,700 10,800 9,800
3,800 3,000 7,900 4,800 8,600 5,800 9,000 6,500 9,300 7,000 9,500 7,300 8,500 7,500
6,000 2,900 6,700 3,900 7,100 4,600 7,400 5,100 7,600 5,500 6,600 5,700
4,600 5,200 2,400 5,600 3,100 5,800 3,600 6,000 4,000 5,100
3,400 3,900 4,300 4,600 4,800 3,900
2,900 3,300 3,500 3,700
2,100 2,400 2,700 2,800
1,400 1,700 1,900 2,100
1,100 1,300
39.4'
(12 m)
53.7'
(16.4 m)
154.2'
(47 m)
68.1'
(20.8 m)
82.4'
(25.1 m)
96.8'
(29.5 m)
111.1'
(33.9 m)
125.5'
(38.3 m)
139.8'
(42.6 m)
NOTE: The lifting capacity data stored in the LOAD MOMENT INDICATOR (AML-E2) is based on the standard number of parts of line listed in the chart.
Standard number of parts of line for each boom length should be according to the following table.
1, 2 1 1 2 1 2 2 2 1 2 1 2 1, 21 1
Form No. GR-1000-4-00101/US-01
39.4'
(12 m)
1, 2
16
39.4' to 68.1'
(12 m to 20.8 m)
68.1' to 154.2'
(20.8 m to 47 m)
1, 2
4
2
4
1
8
Single top
jib
1, 2
1
Boom length in feet
(meters)
Telescoping mode
Number of parts of line
- 17 -

WARNING AND OPERATING INSTRUCTIONS
FOR LIFTING CAPACITIES
GENERAL
RATED LIFTING CAPACITIES apply only to the machine as
originally manufactured and normally equipped by TADANO LTD.
Modications to the machine or use of optional equipment other
than that specied can result in a reduction of capacity.
Hydraulic cranes can be hazardous if improperly operated or
maintained. Operation and maintenance of this machine must be
in compliance with information, in the Operation and Mainte-
nance Manual supplied with the crane.If this manual is missing,
order a replacement through the distributor.
The operator and other personnel associated with this machine
shall fully acquaint themselves with the latest American National
Standards Institute (ANSI) safety standards for cranes.
SET UP
Rated lifting capacities on the chart are the maximum allowable
crane capacities and are based on the machine standing level on
rm supporting surface under ideal job conditions. Depending on
the nature of the supporting surface,it may be necessary to have
structural supports under the outrigger oats or tires to spread
the loads to a larger bearing surface.
For outrigger operation, outriggers shall be properly extended
with tires free of supporting surface before operating crane.
OPERATION
Rated lifting capacities have been tested to and meet minimum
requirements of SAE J1063-Cantilevered Boom Crane Structures
Method of Test.
Rated lifting capacities do not exceed 85% of the tipping load on
outriggers fully extended as determined by SAE J765-Crane
Stability Test Code.
Rated lifting capacities for partially extended outriggers are
determined from the formula, Rated Lifting Capacities = (Tipping
Load - 0.1 × Tip Reaction)/ 1.25.
Rated lifting capacities are based on actual load radius increased
by boom deection.
The weight of handling device such as hook blocks, slings, etc.,
must be considered as part of the load and must be deducted
from the lifting capacities.
Rated lifting capacities are based on freely suspended loads and
make no allowance for such factors as the effect of wind,sudden
stopping of loads,supporting surface conditions, ination of tires,
operating speeds,side loads, etc. Side pull on boom or jib is
extremely dangerous.
Such action can damage the boom, jib or slewing mechanism,
and lead to overturning of the crane.
Rated lifting capacities do not account for wind on lifted load or
boom. We recommend against working under the condition that
the load is out of control due to a strong wind. During boom
lift,consider that the rated lifting capacity is reduced by 50%
when the wind speed is 20 mph (9 m/s) to 27 mph (12 m/s);
reduced by 70% when the wind speed is 27 mph (12 m/s) to 31
mph (14 m/s). If the wind speed is 31 mph (14 m/s) or over, stop
operation. During jib lift, stop operation if the wind speed is 20
mph (9 m/s) or over.
Rated lifting capacities at load radius shall not be exceeded.
Do not tip the crane to determine allowable loads.
Do not operate at boom lengths, radii,or boom angle, where no
capacities are shown. Crane may overturn without any load on
the hook.
When boom length is between values listed, refer to the rated
lifting capacities of the next longer and next shorter booms for
the same radius. The lesser of the two rated lifting capacities
shall be used.
When making lifts at a load radius not shown, use the next
longer radius to determine allowable capacity.
Load per line should not exceed 14,600 lbs. (6,600 kg) for main
winch and auxiliary winch.
Check the actual number of parts of line with LOAD MOMENT
INDICATOR (AML-E2) before operation. Maximum lifting capacity
is restricted by the number of parts of line of LOAD MOMENT
INDICATOR (AML-E2). Limited capacity is as determined from
the formula, Single line pull for main winch 14,600 lbs. (6,600 kg)
× number of parts of line.
The boom angle before loading should be greater to account for
deection. For rated lifting capacities,the loaded boom angle and
the load radius is for reference only.
The 39.4' (12.0 m) boom length capacities are based on boom
fully retracted. If not fully retracted [less than 53.7' (16.4 m) boom
length], use the rated lifting capacities for the 53.7' (16.4 m)
boom length.
Extension or retraction of the boom with loads may be attempted
within the limits of the RATED LIFTING CAPACITIES.
The ability to telescope loads is limited by hydraulic pressure,
boom angle, boom length,crane maintenance, etc.
For lifting capacity of single top, deduct the weight of the load
handling equipment from the rated lifting capacity of the boom.
For the lifting capacity of single top, the net capacity shall not
exceed 14,600 lbs. (6,600 kg) including the main boom hook
mass attached to the boom.
When the base jib or top jib or both jibs are removed, set the jib
state switch to the REMOVED position.
When erecting and stowing jib, be sure to retain it by hand or by
other means to prevent its free movement.
Use ”ANTI-TWOBLOCK" disable switch when erecting and
stowing jib and when stowing hook block. While the switch is
pushed,the hoist does not stop,even when overwind condition
occurs.
When lifting a load by using jib (aux. winch)and boom (main
winch) simultaneously,do the following:
･Enter the operation status as jib operation, not as boom
operation.
･Before starting operation,make sure that mass of load is within
rated lifting capacity for jib.
Before telescoping the boom,set the telescoping mode selector
switch to mode 1 or mode 2 fully retracted.
A change of the telescoping mode is not permissible when the
boom has been partially or fully extended.
Crane operation is prohibited without full counterweight 20,100
lbs. (9.1 ton) installed.Outriggers shall be extended 23' 11-3 / 8”
(7.3 m) spread when installing or removing removable counter-
weight.
DEFINITIONS
Load Radius: Horizontal distance from a projection of the axis of
rotation to supporting surface before loading to the center of the
vertical hoist line or tackle with load applied.
Loaded Boom Angle: The angle between the boom base section
and the horizontal, after lifting the rated lifting capacity at the
load radius.
Working Area: Area measured in a circular arc about the
centerline of rotation.
Freely Suspended Load: Load hanging free with no direct
external force applied except by the hoist line.
Side Load: Horizontal side force applied to the lifted load either
on the ground or in the air.
1.
2.
3.
1.
2.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
21.
22.
1.
2.
3.
4.
5.
Form No. GR-1000-4-00101/US-01
- 18 -

GR-1000XL-4 RATED LIFTING CAPACITIES (IN POUNDS)
A
B
39.4'
(12 m)
53.7'
Over front
(16.4 m)
82.4'
(25.1 m)
96.8'
(29.5 m)
12
15
20
25
30
35
40
45
50
55
60
65
70
75
80
85
Telescoping mode
2nd Boom 0 0 0 0
3rd Boom 0 33 50 66
4th Boom 0 33 50 66
Top Boom 0 33 50 66
COUNTERWEIGHT 20,100 lbs (9.1 t)
ON RUBBER STATIONARY
64,300
53,000
40,000 35,000 28,400
30,500 33,300 28,400 24,700
21,900 24,800 25,200 24,700
19,100 19,600 20,000
15,100 15,600 16,000
12,100 12,600 13,000
99,00 10,300 10,700
8,000 8,600 8,900
6,600 7,100 7,400
5,900 6,200
4,900 5,200
4,100 4,300
3,500
2,900
A
B
39.4'
(12 m)
53.7'
360° Rotation
(16.4 m)
82.4'
(25.1 m)
96.8'
(29.5 m)
12
15
20
25
30
35
40
45
50
55
60
65
70
75
80
85
Telescoping mode
2nd Boom 0 0 0 0
3rd Boom 0 33 50 66
4th Boom 0 33 50 66
Top Boom 0 33 50 66
40,900
31,700
19,200 22,400 22,400
12,500 15,400 16,000 16,400
8,200 11,000 11,600 12,000
8,000 8,600 8,900
5,800 6,400 6,700
4,200 4,700 5,000
2,900 3,400 3,700
1,900 2,400
1,500
2,700
1,800
49,800
40,700
30,200 32,200 28,400
23,000 25,700 26,200 24,700
17,900 20,600 21,100 21,600
16,700 17,300 17,600
13,800 14,300 14,700
11,400 11,900 12,300
9,400 10,000 10,300
7,800
6,400
8,300
6,800
5,600
4,700
3,900
8,600
7,200
6,000
5,000
4,100
3,400
2,800
A: Boom length in feet
B: Load radius in feet
A
B
39.4'
(12 m)
53.7'
Over front
(16.4 m)
82.4'
(25.1 m)
96.8'
(29.5 m)
12
15
20
25
30
35
40
45
50
55
60
65
70
75
80
85
Telescoping mode
2nd Boom 0 0 0 0
3rd Boom 0 33 50 66
4th Boom 0 33 50 66
Top Boom 0 33 50 66
COUNTERWEIGHT 20,100 lbs (9.1 t)
ON RUBBER CREEP
NOTE: The lifting capacity data stored in the LOAD MOMENT INDICATOR (AML-E2) is based on the standard number of parts of line listed in the chart.
Standard number of parts of line for on-rubber operation should be according to the chart.
1, 2 2 2 2 1, 2 2 2 2
1, 2 2 2 2
Over
front
Rear
360˚
approx.
2˚
Working area
Form No. GR-1000-4-00101/US-01
39.4'
(12 m)
6
39.4' to 96.8'
(12 m to 29.5 m)
4
Single top
jib
1
Boom length in feet
(meters)
Number of parts of line
- 19 -

GR-1000XL-4 RATED LIFTING CAPACITIES (IN POUNDS)
A
B
39.4'
(12 m)
53.7'
Over front
(16.4 m)
82.4'
(25.1 m)
96.8'
(29.5 m)
12
15
20
25
30
35
40
45
50
55
60
65
70
75
80
85
Telescoping mode
2nd Boom 0 0 0 0
3rd Boom 0 33 50 66
4th Boom 0 33 50 66
Top Boom 0 33 50 66
COUNTERWEIGHT 20,100 lbs (9.1 t)
ON RUBBER STATIONARY
A
B
39.4'
(12 m)
53.7'
360° Rotation
(16.4 m)
82.4'
(25.1 m)
96.8'
(29.5 m)
12
15
20
25
30
35
40
45
50
55
60
65
70
75
80
85
Telescoping mode
2nd Boom 0 0 0 0
3rd Boom 0 33 50 66
4th Boom 0 33 50 66
Top Boom 0 33 50 66
A
B
39.4'
(12 m)
53.7'
Over front
(16.4 m)
82.4'
(25.1 m)
96.8'
(29.5 m)
12
15
20
25
30
35
40
45
50
55
60
65
70
75
80
85
Telescoping mode
2nd Boom 0 0 0 0
3rd Boom 0 33 50 66
4th Boom 0 33 50 66
Top Boom 0 33 50 66
ON RUBBER CREEP
SMART COUNTERWEIGHT
COUNTERWEIGHT 20,100 lbs (9.1 t)
SMART COUNTERWEIGHT
66,400
54,900
41,500 35,000 28,400
32,200 34,900 28,400 24,700
23,300 26,200 26,600 24,700
20,200 20,700 21,000
16,000 16,600 16,900
12,900 13,500 13,800
10,600 11,100 11,400
8,700 9,200 9,500
7,200 7,700 8,000
6,400 6,700
5,400 5,700
4,500 4,800
4,000
3,300
21,000
13,800 16,800
9,300 12,100 12,700 12,700
9,000 9,500 9,900
6,700 7,200 7,500
4,900 5,400 5,800
3,500 4,100 4,400
2,400 3,000 3,300
1,600 2,000 2,400
51,900
42,600
31,600 32,200 28,400
24,300 27,000 27,500 24,700
19,000 21,700 22,200 22,600
17,700 18,200 18,600
14,600 15,100 15,500
12,100 12,700 13,000
10,100 10,600 11,000
8,400 9,000 9,300
7,000 7,500 7,800
6,200 6,500
5,200 5,500
4,300 4,600
3,800
3,200
A: Boom length in feet
B: Load radius in feet
NOTE: The lifting capacity data stored in the LOAD MOMENT INDICATOR (AML-E2) is based on the standard number of parts of line listed in the chart.
Standard number of parts of line for on-rubber operation should be according to the chart.
1, 2 2 2 2 1, 2 2 2 2
1, 2 2 2 2
Over
front
Rear
360˚
approx.
2˚
Working area
Form No. GR-1000-4-00101/US-01
39.4'
(12 m)
6
39.4' to 96.8'
(12 m to 29.5 m)
4
Single top
jib
1
Boom length in feet
(meters)
Number of parts of line
- 20 -
