Tait T2000 PCB Information Pack 31 October 2001 Copyright Tait Electronics Limited
IPN 403-01210-04 PCB Information Pack
Parts List 225-01210-04 Hands Free
PCB Information Pack IPN 403-01210-04
Hands Free Parts List 225-01210-04
C1 020-57470-10 CAP ELCT AI RDL 4U7 50V LO ESR
C2 015-25220-08 CAP CER 0805 22N 10% X7R 50V
C3 015-24470-08 CAP CER 0805 4N7 10% X7R 50V
C4 020-08470-45 CAP ELE RA 47M16V 6.3*6.5 5LS
C5 015-25150-08 CAP CER 0805 15N 10% X7R 50V
C6 015-25150-08 CAP CER 0805 15N 10% X7R 50V
C7 015-23150-01 CAP CER 0805 150P 5% NPO 50V
C8 015-25150-08 CAP CER 0805 15N 10% X7R 50V
C9 015-25150-08 CAP CER 0805 15N 10% X7R 50V
C10 015-23150-01 CAP CER 0805 150P 5% NPO 50V
C11 015-23680-08 CAP CER 0805 680P 10% X7R 50V
C12 015-06100-08 CAP CER 1206 100N 10% X7R 50V
C13 015-06100-08 CAP CER 1206 100N 10% X7R 50V
C14 015-21470-02 CAP 0805 4P7 1% NPO 50V
C15 015-06100-08 CAP CER 1206 100N 10% X7R 50V
C16 020-08470-45 CAP ELE RA 47M16V 6.3*6.5 5LS
C17 020-08470-45 CAP ELE RA 47M16V 6.3*6.5 5LS
C18 015-06100-08 CAP CER 1206 100N 10% X7R 50V
C19 015-06100-08 CAP CER 1206 100N 10% X7R 50V
C20 015-06100-08 CAP CER 1206 100N 10% X7R 50V
C21 020-57470-10 CAP ELCT AI RDL 4U7 50V LO ESR
C22 015-06100-08 CAP CER 1206 100N 10% X7R 50V
C23 020-08470-45 CAP ELE RA 47M16V 6.3*6.5 5LS
C24 015-23150-01 CAP CER 0805 150P 5% NPO 50V
C25 015-25150-08 CAP CER 0805 15N 10% X7R 50V
C26 015-25150-08 CAP CER 0805 15N 10% X7R 50V
C27 015-06100-08 CAP CER 1206 100N 10% X7R 50V
C28 020-09100-07 CAP ELECT 100M 10V 6.3*7MM
C29 015-06100-08 CAP CER 1206 100N 10% X7R 50V
C30 020-57470-10 CAP ELCT AI RDL 4U7 50V LO ESR
C31 020-58100-04 CAP ELE AI RDL 10M 16V 4X7MM
C32 015-06100-08 CAP CER 1206 100N 10% X7R 50V
C33 015-25150-08 CAP CER 0805 15N 10% X7R 50V
C34 015-23150-01 CAP CER 0805 150P 5% NPO 50V
C35 015-25150-08 CAP CER 0805 15N 10% X7R 50V
C36 015-06100-08 CAP CER 1206 100N 10% X7R 50V
C37 015-06100-08 CAP CER 1206 100N 10% X7R 50V
C38 020-57470-10 CAP ELCT AI RDL 4U7 50V LO ESR
C39 015-23150-01 CAP CER 0805 150P 5% NPO 50V
C40 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C41 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C42 015-23150-01 CAP CER 0805 150P 5% NPO 50V
C43 020-57470-10 CAP ELCT AI RDL 4U7 50V LO ESR
C44 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C45 015-25150-08 CAP CER 0805 15N 10% X7R 50V
C46 015-25150-08 CAP CER 0805 15N 10% X7R 50V
C47 015-06100-08 CAP CER 1206 100N 10% X7R 50V
C48 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C49 015-23150-01 CAP CER 0805 150P 5% NPO 50V
C50 015-25100-08 CAP CER 0805 10N 10% X7R 50V
C51 015-27100-10 CAP CER 0805 1M+80-20% Y5V 16V
C52 015-23150-01 CAP CER 0805 150P 5% NPO 50V
C53 015-23150-01 CAP CER 0805 150P 5% NPO 50V
C54 015-23150-01 CAP CER 0805 150P 5% NPO 50V
C55 015-23150-01 CAP CER 0805 150P 5% NPO 50V
C56 015-23150-01 CAP CER 0805 150P 5% NPO 50V
C57 015-23150-01 CAP CER 0805 150P 5% NPO 50V
C58 015-23150-01 CAP CER 0805 150P 5% NPO 50V
C59 015-23150-01 CAP CER 0805 150P 5% NPO 50V
C60 015-23150-01 CAP CER 0805 150P 5% NPO 50V
C61 020-57470-10 CAP ELCT AI RDL 4U7 50V LO ESR
C62 015-23150-01 CAP CER 0805 150P 5% NPO 50V
C63 015-25100-08 CAP CER 0805 10N 10% X7R 50V
C64 015-06100-08 CAP CER 1206 100N 10% X7R 50V
C65 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C66 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C67 015-24100-08 CAP CER 0805 1N 10% X7R 50V
C2A 015-25100-08 CAP CER 0805 10N 10% X7R 50V
C40A 015-23150-01 CAP CER 0805 150P 5% NPO 50V
C41A 015-23150-01 CAP CER 0805 150P 5% NPO 50V
D1 001-10000-99 DIODE SMD BAV99 D-SW SOT23
D2 001-10000-99 DIODE SMD BAV99 D-SW SOT23
D3 001-10000-99 DIODE SMD BAV99 D-SW SOT23
D4 001-10084-51 DIODE ZENSMD BZX84C5V1 SOT23
D5 001-10000-99 DIODE SMD BAV99 D-SW SOT23
D6 001-10000-99 DIODE SMD BAV99 D-SW SOT23
D7 001-10084-36 DIODE ZENSMD BZX84C3V6 SOT23
D8 001-10000-99 DIODE SMD BAV99 D-SW SOT23
IC1 002-10003-24 IC SMD 324 4X O-AMP SO14
IC2 002-10040-53 IC 4053B SMD BREAK B4 MAKE
IC3 002-10003-24 IC SMD 324 4X O-AMP SO14
IC4 002-10003-24 IC SMD 324 4X O-AMP SO14
IC5 002-74900-00 IC SMD 74HC00 4X 2 I/P NAND
IC6 002-10078-08 IC SMD 78L08 8V REG SO8
IC7 002-10003-24 IC SMD 324 4X O-AMP SO14
IC8 002-00014-62 IC 317L 100MA REG 3TER TO92
P13 240-00026-26 CONN PADLE BRD 12 W M-MATCH
P13A 240-00020-51 PLUG 12 W 2*6 FLAT CABLE TERMN
Q1 000-10008-47 XSTR BC847B NPN SOT23
Q2 000-10008-47 XSTR BC847B NPN SOT23
Q3 000-10008-57 XSTR SMD BC857 PNP SOT23 SS
Q4 000-10008-47 XSTR BC847B NPN SOT23
Q5 000-10008-47 XSTR BC847B NPN SOT23
Q6 000-10008-47 XSTR BC847B NPN SOT23
Q7 000-10008-57 XSTR SMD BC857 PNP SOT23 SS
Q8 000-10008-57 XSTR SMD BC857 PNP SOT23 SS
Q9 000-10008-47 XSTR BC847B NPN SOT23
Q10 000-10008-57 XSTR SMD BC857 PNP SOT23 SS
Q11 000-10008-47 XSTR BC847B NPN SOT23
Q12 000-10008-47 XSTR BC847B NPN SOT23
Q13 000-10008-57 XSTR SMD BC857 PNP SOT23 SS
Q14 000-10008-47 XSTR BC847B NPN SOT23
R1 036-14470-10 RES M/F 0805 4K7 1%
R2 036-14270-10 RES M/F 0805 2K7 1%
R3 036-14100-10 RES M/F 0805 1K 1%
R4 036-14680-10 RES M/F 0805 6K8 1%
R5 036-14270-10 RES M/F 0805 2K7 1%
R6 036-15100-10 RES M/F 0805 10K 1%
R7 036-13220-10 RES M/F 0805 220E 1%
R8 036-14220-00 RES M/F 0805 2K2 5%
R9 036-15390-10 RES M/F 0805 39K 1%
R10 036-15330-10 RES M/F 0805 33K 1%
R11 036-15470-10 RES M/F 0805 47K 1%
R13 036-15100-10 RES M/F 0805 10K 1%
R14 036-15820-00 RES M/F 0805 82K 5%
R15 036-15150-10 RES M/F 0805 15K 1%
R16 036-14100-10 RES M/F 0805 1K 1%
R17 036-16100-10 RES M/F 0805 100K 1%
R18 036-15100-10 RES M/F 0805 10K 1%
R19 036-15100-10 RES M/F 0805 10K 1%
R20 036-12100-10 RES M/F 0805 10E 1%
R21 036-15100-10 RES M/F 0805 10K 1%
R22 036-16100-10 RES M/F 0805 100K 1%
R23 036-15100-10 RES M/F 0805 10K 1%
R24 036-15470-10 RES M/F 0805 47K 1%
R25 036-15220-00 RES M/F 0805 22K 5%
R26 036-17100-10 RES M/F 0805 1M 1%
R27 036-17100-10 RES M/F 0805 1M 1%
R28 036-17100-10 RES M/F 0805 1M 1%
R29 036-15100-10 RES M/F 0805 10K 1%
R30 036-14180-00 RES M/F 0805 1K8 5%
R31 036-17100-10 RES M/F 0805 1M 1%
R32 036-15100-10 RES M/F 0805 10K 1%
R33 036-14270-10 RES M/F 0805 2K7 1%
R34 036-14470-10 RES M/F 0805 4K7 1%
R35 036-10000-00 RES M/F 0805 ZERO OHM
R36 036-16150-00 RES M/F 0805 150K 5%
R37 036-14100-10 RES M/F 0805 1K 1%
R38 036-16100-10 RES M/F 0805 100K 1%
R39 036-16220-00 RES M/F 0805 220K 5%
R40 036-17100-10 RES M/F 0805 1M 1%
R41 036-14100-10 RES M/F 0805 1K 1%
R42 036-15100-10 RES M/F 0805 10K 1%
R43 036-16100-10 RES M/F 0805 100K 1%
R44 036-15470-10 RES M/F 0805 47K 1%
R45 036-14100-10 RES M/F 0805 1K 1%
R46 036-13470-00 RES M/F 0805 470E 5%
R47 036-15220-00 RES M/F 0805 22K 5%
R48 036-16150-00 RES M/F 0805 150K 5%
R49 036-15180-10 RES M/F 0805 18K 1%
R50 036-15100-10 RES M/F 0805 10K 1%
R51 036-16150-00 RES M/F 0805 150K 5%
R52 036-15470-10 RES M/F 0805 47K 1%
R53 036-15100-10 RES M/F 0805 10K 1%
R54 036-17100-10 RES M/F 0805 1M 1%
R55 036-15100-10 RES M/F 0805 10K 1%
R56 036-15100-10 RES M/F 0805 10K 1%
R57 036-15820-00 RES M/F 0805 82K 5%
R58 036-15100-10 RES M/F 0805 10K 1%
R59 036-16100-10 RES M/F 0805 100K 1%
R60 036-15100-10 RES M/F 0805 10K 1%
R61 036-15100-10 RES M/F 0805 10K 1%
R62 036-16330-00 RES M/F 0805 330K 5%
R63 036-16100-10 RES M/F 0805 100K 1%
R64 036-14100-10 RES M/F 0805 1K 1%
R65 036-14100-10 RES M/F 0805 1K 1%
R66 036-15100-10 RES M/F 0805 10K 1%
R67 036-15470-10 RES M/F 0805 47K 1%
R68 036-14120-00 RES M/F 0805 1K2 5%
R69 036-16470-00 RES M/F 0805 470K 5%
R70 036-15100-10 RES M/F 0805 10K 1%
R71 036-15100-10 RES M/F 0805 10K 1%
R72 036-15100-10 RES M/F 0805 10K 1%
R73 036-14470-10 RES M/F 0805 4K7 1%
R74 036-15470-10 RES M/F 0805 47K 1%
R75 036-15470-10 RES M/F 0805 47K 1%
R76 036-16220-00 RES M/F 0805 220K 5%
R77 036-10000-00 RES M/F 0805 ZERO OHM
R78 036-14470-10 RES M/F 0805 4K7 1%
R79 036-10000-00 RES M/F 0805 ZERO OHM
R80 036-15470-10 RES M/F 0805 47K 1%
R81 036-14100-10 RES M/F 0805 1K 1%
R82 036-15100-10 RES M/F 0805 10K 1%
R83 036-14470-10 RES M/F 0805 4K7 1%
R84 036-15220-00 RES M/F 0805 22K 5%
R85 036-15220-00 RES M/F 0805 22K 5%
R86 036-14270-10 RES M/F 0805 2K7 1%
R87 036-15220-00 RES M/F 0805 22K 5%
R88 036-15100-10 RES M/F 0805 10K 1%
R89 036-15220-00 RES M/F 0805 22K 5%
R90 036-15120-00 RES M/F 0805 12K 5%
R91 036-15100-10 RES M/F 0805 10K 1%
R92 036-15100-10 RES M/F 0805 10K 1%
R93 036-15100-10 RES M/F 0805 10K 1%
R94 036-16100-10 RES M/F 0805 100K 1%
R95 036-15100-10 RES M/F 0805 10K 1%
R96 036-15100-10 RES M/F 0805 10K 1%
R97 036-16330-00 RES M/F 0805 330K 5%
R98 036-15100-10 RES M/F 0805 10K 1%
R99 036-16100-10 RES M/F 0805 100K 1%
R100 036-15100-10 RES M/F 0805 10K 1%
R101 036-15100-10 RES M/F 0805 10K 1%
R102 036-16330-00 RES M/F 0805 330K 5%
R103 036-16100-10 RES M/F 0805 100K 1%
R104 036-14100-10 RES M/F 0805 1K 1%
R105 036-15470-10 RES M/F 0805 47K 1%
R106 036-15470-10 RES M/F 0805 47K 1%
R107 036-13100-10 RES M/F 0805 100E 1%
R108 036-13100-10 RES M/F 0805 100E 1%
R109 036-15100-10 RES M/F 0805 10K 1%
R110 036-13560-10 RES M/F 0805 560E 1%
R111 036-14470-10 RES M/F 0805 4K7 1%
R112 036-14100-10 RES M/F 0805 1K 1%
R113 036-15470-10 RES M/F 0805 47K 1%
R114 036-15180-10 RES M/F 0805 18K 1%
R115 036-14100-10 RES M/F 0805 1K 1%
R116 036-17100-10 RES M/F 0805 1M 1%
R117 036-15100-10 RES M/F 0805 10K 1%
R118 036-16330-00 RES M/F 0805 330K 5%
R119 036-14100-10 RES M/F 0805 1K 1%
R120 036-15470-10 RES M/F 0805 47K 1%
R121 036-14680-10 RES M/F 0805 6K8 1%
R122 036-14680-10 RES M/F 0805 6K8 1%
R123 036-15220-00 RES M/F 0805 22K 5%
R124 036-16470-00 RES M/F 0805 470K 5%
R125 036-16220-00 RES M/F 0805 220K 5%
R126 036-14100-10 RES M/F 0805 1K 1%
R127 036-15100-10 RES M/F 0805 10K 1%
R128 036-12100-10 RES M/F 0805 10E 1%
R129 036-14100-10 RES M/F 0805 1K 1%
R131 036-15100-10 RES M/F 0805 10K 1%
R132 036-16100-10 RES M/F 0805 100K 1%
R133 036-15100-10 RES M/F 0805 10K 1%
R134 036-16100-10 RES M/F 0805 100K 1%
R135 036-16100-10 RES M/F 0805 100K 1%
R136 036-16820-10 RES M/F 0805 820K 1%
R70A 036-18100-00 RES M/F 0805 10M 5%
R83A 036-15470-10 RES M/F 0805 47K 1%
RV67 042-05100-06 RES PRE 10K CARBON 6MM FLAT
S1 240-10000-06 CONN SMD SKT 12W 2R M-MATCH
S5 240-10000-07 CONN SMD SKT 16W 2R M-MATCH
Parts List Amendments
Parts List
Parts List
Ref IPN Description Ref IPN Description Ref IPN Description
PCB
Information
Pack
Tait T2000
PCB Layout – Hands Free
Parts List 225-01210-04
IPN 403-01210-04
This document can be printed on
A3 as single-sided, double-
sided, unfolded or z-folded.
Parts List

Tait T2000 PCB Information Pack 31 October 2001 Copyright Tait Electronics Limited
IPN 403-01210-04 PCB Information Pack
Parts List 225-01210-04 Hands Free
PCB Information Pack IPN 403-01210-04
Hands Free Parts List 225-01210-04
C1 1:K2 1-B9
C2 1:K2 1-B8
C2A 1:K2 1-B8
C3 1:K1 1-C7
C4 1:K1 1-B8
C5 1:K1 1-C8
C6 1:K1 1-D8
C7 1:J1 1-C9
C8 1:J1 1-E8
C9 1:J1 1-F8
C10 1:A2 1-R1
C11 1:J1 1-H8
C12 1:J2 1-H8
C13 1:H2 1-J8
C14 1:H1 1-K9
C15 1:H2 1-J7
C16 1:G1 1-K7
C17 1:H2 1-K7
C18 1:G1 1-N9
C19 1:G1 1-N9
C20 1:C1 1-L0
C21 1:C1 1-P5
C22 1:C1 1-M0
C23 1:C1 1-M0
C24 1:F1 1-G6
C25 1:E1 1-B6
C26 1:E1 1-B6
C27 1:E1 1-C5
C28 1:K2 1-N1
C29 1:F1 1-D5
C30 1:E2 1-F4
C31 1:D2 1-H4
C32 1:H1 1-K4
C33 1:A1 1-K0
C34 1:K1 1-L1
C35 1:A1 1-H1
C36 1:A1 1-G1
C37 1:A2 1-E0
C38 1:A2 1-B0
C39 1:F2 1-E5
C40 1:H2 1-B2
C40A 1:H2 1-A2
C41 1:H2 1-B3
C41A 1:H2 1-A3
C42 1:A2 1-D0
C43 1:G2 1-P3
C44 1:J2 1-A8
C45 1:B2 1-H0
C46 1:B1 1-G0
C47 1:K2 1-L1
C48 1:K2 1-M1
C49 1:K2 1-N1
C50 1:B2 1-Q8
C51 1:C2 1-P6
C52 1:F2 1-P7
C53 1:G1 1-L8
C54 1:A1 1-G1
C55 1:F1 1-P0
C56 1:B2 1-B6
C57 1:F1 1-C6
C58 1:H1 1-H6
C59 1:H2 1-Q9
C60 1:D1 1-R6
C61 1:D1 1-K3
C62 1:B2 1-R7
C63 1:B2 1-Q8
C64 1:B2 1-N8
C65 1:J1 2-F2
C66 1:J1 2-F2
C67 1:J1 2-E2
D1 1:F2 1-F5
D1 1:F2 1-F5
D2 1:E2 1-H5
D2 1:E2 1-H5
D3 1:A2 1-C0
D3 1:A2 1-C1
D4 1:E2 1-A0
D5 1:E2 1-F4
D5 1:E2 1-E4
D6 1:B2 1-Q7
D6 1:B2 1-Q7
D7 1:B1 1-P6
D8 1:C2 1-N6
D8 1:C2 1-M6
IC1 1:J1 1-K8
IC1 1:J1 1-Q0
IC1 1:J1 1-H8
IC1 1:J1 1-F7
IC1 1:J1 1-E7
IC2 1:G2 1-M9
IC2 1:G2 1-E6
IC2 1:G2 1-F6
IC2 1:G2 1-P0
IC3 1:E2 1-B5
IC3 1:E2 1-G5
IC3 1:E2 1-C5
IC3 1:E2 1-E4
IC3 1:E2 1-R0
IC4 1:A2 1-D0
IC4 1:A2 1-J0
IC4 1:A2 1-F1
IC4 1:A2 1-H1
IC4 1:A2 1-R0
IC5 1:C2 1-L5
IC5 1:C2 1-P5
IC5 1:C2 1-M4
IC5 1:C2 1-N5
IC5 1:C2 1-R0
IC6 1:B1 1-L0
IC7 1:B2 1-Q7
IC7 1:B2 1-N0
IC7 1:B2 1-N6
IC7 1:B2 1-P8
IC7 1:B2 1-Q0
IC8 1:K2 1-M2
LNK1 1:F1 1-Q2
LNK1A 1:F1 1-P2
LNK1B 1:F1 1-Q2
LNK1C 1:F1 1-Q2
LNK1D 1:F1 1-Q2
LNK2 1:G1 1-L7
LNK2A 1:G2 1-L7
LNK3 1:C2 1-M4
LNK3A 1:C2 1-M4
LNK4 1:G2 1-N4
LNK4A 1:G2 1-N4
LNK4B 1:G2 1-N4
LNK5 1:C2 1-Q8
LNK5A 1:C2 1-Q8
LNK5B 1:C2 1-R8
P13 1:B1 2-L3
P14 1:E1 2-L4
Q1 1:K1 1-C8
Q2 1:H2 1-J8
Q3 1:G1 1-L8
Q4 1:H2 1-M7
Q5 1:G2 1-M8
Q6 1:E1 1-J5
Q7 1:D1 1-K5
Q8 1:D2 1-P5
Q9 1:D1 1-Q5
Q10 1:D2 1-K3
Q11 1:G2 1-G6
Q12 1:E2 1-C3
Q13 1:G2 1-R4
Q14 1:E1 1-J3
R1 1:K2 1-A9
R2 1:K2 1-C9
R3 1:K2 1-B8
R4 1:K1 1-B8
R5 1:K1 1-B7
R6 1:K1 1-C8
R7 1:K1 1-C9
R8 1:K1 1-C8
R9 1:H1 1-D7
R10 1:K1 1-E9
R11 1:G2 1-P3
R13 1:K1 1-E7
R14 1:J1 1-F7
R15 1:J1 1-F9
R16 1:G2 1-P4
R17 1:H1 1-K2
R18 1:J1 1-F7
R19 1:J1 1-G9
R20 1:C1 1-L0
R21 1:J2 1-G7
R22 1:J1 1-H8
R23 1:J2 1-H7
R24 1:J2 1-J8
R25 1:H2 1-J8
R26 1:J2 1-J7
R27 1:H1 1-K8
R28 1:H1 1-K9
R29 1:H1 1-K8
R30 1:H1 1-K7
R31 1:H1 1-K7
R32 1:G1 1-L8
R33 1:G1 1-L9
R34 1:H1 1-L7
R35 1:H1 1-L7
R36 1:H2 1-L7
R37 1:G1 1-M7
R38 1:F2 1-M8
R39 1:G2 1-H6
R40 1:G1 1-M9
R41 1:H2 1-M3
R42 1:G2 1-M8
R43 1:F2 1-G6
R44 1:E2 1-G3
R45 1:K1 1-M1
R46 1:K2 1-M2
R47 1:E1 1-A6
R48 1:F1 1-B6
R49 1:E1 1-B4
R50 1:E1 1-B4
R51 1:E1 1-B5
R52 1:E2 1-F4
R53 1:F1 1-C5
R54 1:F1 1-C5
R55 1:F1 1-C5
R56 1:F1 1-C6
R57 1:F1 1-D5
R58 1:F1 1-D4
R59 1:F1 1-E4
R60 1:F2 1-E4
R61 1:F2 1-E5
R62 1:F2 1-E4
R63 1:F2 1-F4
R64 1:F2 1-F5
R65 1:E2 1-D4
R66 1:D2 1-C4
R67 1:E2 1-G5
R68 1:F2 1-D3
R69 1:E2 1-H5
R70 1:E2 1-H4
R70A 1:E2 1-G4
R71 1:E1 1-J5
R72 1:D1 1-J5
R73 1:D1 1-K5
R74 1:D1 1-K4
R75 1:C2 1-L5
R76 1:F2 1-M7
R77 1:C2 1-N2
R78 1:D2 1-N5
R79 1:C1 1-R5
R80 1:D1 1-P4
R81 1:C1 1-Q5
R82 1:D2 1-Q5
R83 1:C2 1-L3
R83A 1:C2 1-L2
R84 1:B1 1-K1
R85 1:A1 1-K1
R86 1:A1 1-J0
R87 1:B2 1-H0
R88 1:B2 1-H1
R89 1:B2 1-H0
R90 1:A2 1-G1
R91 1:B2 1-G0
R92 1:B1 1-J0
R93 1:A1 1-F1
R94 1:A1 1-F1
R95 1:A1 1-F1
R96 1:A1 1-F2
R97 1:A1 1-E1
R98 1:A1 1-E0
R99 1:A2 1-E0
R100 1:A2 1-D0
R101 1:A2 1-D0
R102 1:A2 1-C0
R103 1:A2 1-C0
R104 1:A2 1-C0
R105 1:A2 1-B0
R106 1:D2 1-K2
R107 1:H2 1-B2
R108 1:H2 1-B3
R109 1:D2 1-C3
R110 1:E2 1-D3
R111 1:G2 1-R4
R112 1:D2 1-L3
R113 1:G2 1-M3
R114 1:A1 1-J1
R115 1:G2 1-R4
R116 1:B2 1-Q9
R117 1:B2 1-R6
R118 1:B2 1-Q6
R119 1:B2 1-P7
R120 1:B1 1-P6
R121 1:B2 1-N7
R122 1:C2 1-N6
R123 1:B2 1-N7
R124 1:C2 1-N7
R125 1:C2 1-M6
R126 1:C2 1-K4
R127 1:D1 1-J3
R128 1:E1 1-J4
R129 1:E1 1-H5
R131 1:B2 1-R7
R132 1:B2 1-Q7
R133 1:B2 1-N8
R134 1:F2 1-D6
R135 1:B2 1-P6
R136 1:F1 1-D5
RV67 1:E2 1-C3
S21 1:J2 2-J3
SKT2 1:J1 2-J4
T1:A12-L2
TP1 1:K1 1-C7
TP2 1:J2 1-J9
TP3 1:E1 1-C5
TP4 1:F2 1-D4
TP5 1:E2 1-G4
TP6 1:E2 1-G3
TP7 1:A1 1-F0
TP8 1:A2 1-D1
TP9 1:G1 1-P9
Device PCB Circuit Device PCB Circuit Device PCB Circuit Device PCB Circuit
Grid Reference Index
Grid Reference IndexGrid Reference Index
Mechanical Parts and
Miscellaneous Parts
201-00030-01 WIRE T/C 7/0.2MM PVC BROWN
201-00030-02 WIRE T/C WIRE 7/0.2MM PVC RED
201-00030-03 WIRE T/C 7/0.2MM PVC ORANGE
201-00030-06 WIRE T/C 7/0.2MM PVC BLUE
201-00030-07 WIRE T/C 7/0.2MM PVC VIOLET
201-00030-08 WIRE T/C 7/0.2MM PVC GREY
205-00010-12 CBLE FLAT 16CORE 16/7/0.1 GREY
225-01210-04 PCB T2000 HANDS FREE MIC
236-00000-10 SWITCH FOOT OPERATED
240-00010-40 PLUG 9 W DRANGE SUBMIN
240-00010-45 SKT 9 W D RANGE 90 DEG.PCB
240-00020-54 PLUG 16 W 2X8 M-MATCH
240-00026-24 CONN PADLE BRD 16 W M-MATCH
240-02020-37 SKT 2.5MM INLINE MIN JACK
240-04020-84 SKT 4W PCB MTG STAG PINS M-MAT
240-04021-63 CONN 2W 24AWG BLK INLINE
240-06010-29 HOOD/COV 9WLONG EAR THUMB SCR
252-00010-72 MIC ELEC UNIDIR 2.5MM PLUG
345-00051-00 SCRW PTDG 30*06 P/TORX BZ LUBE
349-00020-07 SCRW T/T 4-40*5/16" P/POZI BLK
354-01041-00 FASTENER SCREWLOCK KIT 4-40
365-00011-38 LABEL STATIC WARNING YELLOW
365-00011-54 LABEL R1556/2 90*24MM WHITE
365-01689-00 LABEL RED VOX 20X5MM
369-00010-13 TIE CABLE NYLON 175*5MM
399-00010-52 BAG PLASTIC 100*150MM
399-00010-88 BAG STATIC SHIELDING 152*254MM
410-00010-60 CTN 150X112X56MM VICTOR
418-25000-04 FTTNG INS T2000-50/-A51 HF
458-25000-02 USER GUIDE T2000-A50/A51
IPN Description

Tait T2000 PCB Information Pack 31 October 2001 Copyright Tait Electronics Limited
IPN 403-01210-04 PCB Information Pack
Parts List 225-01210-04 Hands Free
PCB Information Pack IPN 403-01210-04
Hands Free Parts List 225-01210-04
PCB Layout – Top Side
PCB Layout – Top SidePCB Layout – Top Side
C1
C10
C11
C12
C13
C14
C15
C16
C17
C18 C19
C2
C20
C21
C22
C23
C24
C25
C26
C27
C28
C29
C2A
C3
C30
C31
C32
C33
C34
C35
C36
C37
C38
C39
C4
C40
C40A
C41
C41A
C42
C43
C44
C45
C46
C47
C48 C49
C5
C50
C51
C52
C53
C54
C55
C56
C57
C58
C59
C6
C60
C61
C62
C63
C64
C65
C66
C67
C7
C8
C9
D1
D2
D3 D4
D5
D6
D7
D8
IC1
IC2
IC3
IC4 IC5
IC6
IC7
IC8
LNK1
LNK1A LNK1BLNK1CLNK1D
LNK2
LNK2A
LNK3
LNK3A
LNK4
LNK4A
LNK4B
LNK5
LNK5A LNK5B
P13 P14
Q1
Q10
Q11
Q12
Q13
Q14
Q2
Q3
Q4
Q5
Q6
Q7
Q8
Q9
R1
R10
R100
R101
R102 R103
R104
R105
R106
R107
R108
R109
R11
R110
R111
R112
R113
R114
R115
R116
R117
R118
R119
R120
R121
R122
R123
R124
R125
R126
R127
R128 R129
R13
R131
R132 R133
R134
R135
R136
R14
R15
R16
R17
R18
R19
R2
R20
R21
R22
R23
R24
R25 R26
R27
R28
R29
R3
R30
R31
R32
R33
R34 R35
R36
R37
R38
R39
R4
R40
R41
R42
R43
R44
R45
R46
R47
R48
R49
R5
R50
R51
R52
R53 R54
R55
R56
R57
R58
R59
R6
R60
R61
R62
R63
R64
R65
R66
R67
R68
R69
R7
R70
R70A
R71
R72
R73
R74
R75
R76
R77
R78
R79
R8
R80
R81
R82
R83
R83A
R84
R85 R86
R87
R88
R89
R9
R90
R91
R92
R93
R94
R95
R96
R97R98
R99
RV67
S21
SKT2
TBADMARK
TP1
TP2
TP3
TP4
TP5
TP6
TP7
TP8
TP9
A
2
1
MLKJHGF
4
E
3
DBC
TAIT ELECTRONICS
T2000HNDSFRE PCB LAYOUT - TOP SIDE
IPN: ISS: ID: DATE:
225-01210-04 A 1.TA 20 Oct 1998

Tait T2000 PCB Information Pack 31 October 2001 Copyright Tait Electronics Limited
IPN 403-01210-04 PCB Information Pack
Parts List 225-01210-04 Hands Free
PCB Information Pack IPN 403-01210-04
Hands Free Parts List 225-01210-04
PCB Layout – Bottom Side
PCB Layout – Bottom SidePCB Layout – Bottom Side
225-01210-04 A
TAIT ELECTRONICS
T2000HNDSFRE PCB LAYOUT - BOTTOM SIDE
IPN: ISS: ID: DATE:
225-01210-04 A 2.BA 20 Oct 1998

Tait T2000 PCB Information Pack 31 October 2001 Copyright Tait Electronics Limited
IPN 403-01210-04 PCB Information Pack
Parts List 225-01210-04 Hands Free
PCB Information Pack IPN 403-01210-04
Hands Free Parts List 225-01210-04
Schematic #1
Schematic #1Schematic #1
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
ABCDEFGHJ KLMNPQR
REV/ISS AMENDMENTS DATEAPVDD.O.CHKDDRAWN
NO.SHEETS:FILE NAME:
TAIT ELECTRONICS
IPN:
FILE DATE:
ISSUE: ID:.
2.SC.
PROJECT: DESIGNER:
1
2
HANDSFREE
T2000-VOX
121004A
225-01210-04
30/7/97
A
T2000 RPS
P2 ORIGINAL J.F. J.F. 9/3/92
1A/B,2A (1B 9/5/92)2A-VARIOUS MODS3/2/93 J.F. J.F. 7/5/92’
3A ADD +4V REG(IC8),Q14,IC7,ETC J.F. J.F. 3/2/93
3B ADDED LINK-TABLE & SHEET-2 J.F. J.F. S.HEALD 12/5/93
4A ADD DATA INTERFACE DECOUPING RPS 30/07/97
C1
4U7
C10
150P
C11
680P
C12
100N
C13
100N
C14
4P7
C15
100N
C16
47U
C17
47U
C18
100N
C19
100N
C2
22N
C2A
10N
C20
100N
C21
4U7
C22
100N
C23
47U
C24
150P
C25
15N
C26
15N
C27
100N
C28
4U7
C29
100N
C3
4N7
C30
4U7
C31
10U
C32
100N
C33
15N
C34
150P
C35
15N
C36
100N
C37
100N
C38
4U7
C39
150P
C4
47U
C40
1N0
C40A
150P
C41
1N0
C41A
150P
C42
150P
C43
4U7
C44
1N0
C45
15N
C46
15N
C47
100N
C48
1N0
C49
150P
C5
15N
C50
10N
C52
150P
C53
150P
C54
150P
C55
150P
C56
150P
C57
150P
C58
150P
C59
150P
C6
15N
C60
150P
C61
4U7
C62
150P
C63
10N
C64
100N
C7
150P
C8
15N
C9
15N
BAV99
D1
31
BAV99
D1
2
3
BAV99
D2
23
BAV99
D2
3
1
BAV99
D3 3
1
BAV99
D3
23
D4
5V1
BAV99
D5
31
BAV99
D5
2
3
BAV99
D6
3
1
BAV99
D6
23
D7
3V6
BAV99
D82
3
BAV99
D8
3
1
IC1
LM324D
V-
11
V+
4
+
-
IC1
LM324D
3
2
1
+
-
IC1
LM324D
5
6
7
+
-
IC1
LM324D
10
9
8
+
-
IC1
LM324D
12
13
14
IC2
4053BD
INH
6
V-
8
V+
16
VEE 7
IC2
4053BD
3
9
5
4
IC2
4053BD
13
11
12
14
IC2
4053BD
1
10
2
15
IC3
LM324D
V-
11
V+
4
+
-
IC3
LM324D
3
2
1
+
-
IC3
LM324D
5
6
7
+
-
IC3
LM324D
10
9
8
+
-
IC3
LM324D
12
13
14
IC4
LM324D
V-
11
V+
4
+
-
IC4
LM324D
5
6
7
+
-
IC4
LM324D
10
9
8
+
-
IC4
LM324D
3
2
1
+
-
IC4
LM324D
12
13
14
IC5
74HC00
V-
7
V+
14
IC5
74HC00
1
23
IC5
74HC00
4
56IC5
74HC00
10
98IC5
74HC00
13
12 11
GROUND
VIN VOUT
IC6
78L08
8
2367
1
IC7
LM324D
V-
11
V+
4
+
-
IC7
LM324D
3
2
1
+
-
IC7
LM324D
5
6
7
+
-
IC7
LM324D
12
13
14
+
-
IC7
LM324D
10
9
8
VREG
IC8
LM317L
VIN
3
ADJ
2
VOUT
1
LNK1
LINK
LNK1A
LINK
LNK1B
LINK
LNK1C
LINK
LNK1D
LINK
LNK2
LINK
LNK2A
LINK
LNK3
LINK
LNK3A
LINK
LNK4
LINK
LNK4A
LINK
LNK4B
LINK
LNK5
LINK
LNK5A
LINK
LNK5B
LINK
Q1
BC848
Q10
BC857
Q11
BC848
Q12
BC848
Q13
BC857
Q14
BC848
Q2
BC848
Q3
BC857
Q4
BC848
Q5
BC848
Q6
BC848
Q7
BC857
Q8
BC857
Q9
BC848
CW RV67
10K
2
3
1
R1
4K7
R10
33K
R100
10K
R101
10K
R102
330K R103
100K
R104
1K0
R105
47K
R106
47K
R107
100
R108
100
R109
10K
R11
47K
R110
560
R111
4K7
R112
1K0
R113
47K
R114
18K
R115
10K
R116
1M0
R117
10K
R118
330K
R119
1K0
R120
47K
R121
6K8
R122
6K8
R123
22K
R124
470K
R125
220K
R126
1K0
R127
10K
R128
10
R129
1K0
R13
10K
R131
10K
R132
100K
R133
10K
R134
100K
R135
100K
R136
820K
R14
82K
R15
15K
R16
1K0
R17
100K
R18
10K
R19
10K
R2
2K7
R20
10
R21
10K
R22
100K
R23
10K
R24
47K
R25
22K
R26
1M0
R27
1M0
R28
1M0
R29
10K
R3
1K0
R30
1K8
R31
1M0
R32
10K
R33
2K7
R34
4K7
R35
0
R36
150K
R37
1K0
R38
100K
R39
220K
R4
6K8
R40
1M0
R41
1K0
R42
10K
R43
100K
R44
47K
R45
1K0
R46
470
R47
22K
R48
150K
R49
18K
R5
2K7
R50
10K
R51
150K
R52
47K
R53
10K
R54
1M0
R55
10K
R56
10K
R57
82K
R58
10K
R59
100K
R6
10K
R60
10K
R61
10K
R62
330K
R63
100K
R64
1K0
R65
1K0
R66
10K
R67
47K
R68
1K2
R69
470K
R7
220
R70
10K
R70A
10M
R71
10K
R72
10K
R73
4K7
R74
47K
R75
47K
R76
220K
R77
0
R78
4K7
R79
0
R8
2K2
R80
47K
R81
1K0
R82
10K
R83
4K7
R83A
47K
R84
22K
R85
22K
R86
2K7
R87
22K
R88
10K
R89
22K
R9
39K
R90
12K
R91
10K
R92
10K
R93
10K
R94
100K
R95
10K
R96
10K
R97
330K
R98
10K
R99
100K
TP1
I/OPAD
TP2
I/OPAD
TP3
I/OPAD
TP4
I/OPAD
TP5
I/OPAD
TP6
I/OPAD
TP7
I/OPAD
TP8
I/OPAD
TP9
I/OPAD
C51
1U0
P13 GND
11
P13 GTD-AF
7
P13 TX-LINE-IN
6
P14 +13.8V
1
P14 +5V
2
P14 AUX
13
P14 BUSY
3
P14 CALL
11
P14 EMRGNCY
10
P14 EXTERNAL
16
P14 HORN
14
P14 HUSH
12
P14 IN/LOOK
7
P14 MIC-MUTE
8
P14 PTT
6
P14 PTT-IN
5
S21
FT-SWCH 6
S21
TXD 5
S21
DGND 9
S21
GND 1
S21
GND 3
S21
GND 8
S21
RXD 4
S21
MIC 2
S21
VOX 7
+13.8V
+13.8V
+5V
+5V
+5V
+5V
+5V
+8V
+8V
+8V
+8V
+8V
+8V
+8V
+8V
+8V
+8V
HALF-RAIL
HALF-RAIL
HALF-RAIL
DGND
2E3
RXD
2E3
TXD
2E3
SK9DR
PDL12M
+5V
HALF-RAIL +4V
ALC DISABLE
+4V-REG
PDL16M
+4V REGULATOR
+8V REGULATOR
+4V-REG
HALF-RAIL +4V
BUSY
VOX-LOCK
TRUNKING
+4V-REG

Tait T2000 PCB Information Pack 31 October 2001 Copyright Tait Electronics Limited
IPN 403-01210-04 PCB Information Pack
Parts List 225-01210-04 Hands Free
PCB Information Pack IPN 403-01210-04
Hands Free Parts List 225-01210-04
Schematic #2
Schematic #2Schematic #2
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
ABCDEFGHJ KLMNPQR
REV/ISS AMENDMENTS DATEAPVDD.O.CHKDDRAWN
NO.SHEETS:FILE NAME:
TAIT ELECTRONICS
IPN:
FILE DATE:
ISSUE: ID:.
2.SC.
PROJECT: DESIGNER:
2
2
T2000 HANDS FREE PCB
LINK-TABLE
121004A
225-01210-04
30/7/97
A
T2000 JOE
3B ADDED LINK-TABLE, SHEET-2 J.F. J.F. S.HEALD 12/5/93
4A ADD DATA INTERFACE DECOUPLING RPS 30/07/97
P13
12 WAY PADDLE CONNECTOR
P14
16 WAY PADDLE CONNECTOR
S21
9 WAY SIDE ENTRY DRANGE SKT
TBADMARK
BADMARK
SKT2
2X2 WAY TOP ENTRY SKT
C65
1N0
C66
1N0
C67
1N0
DGND
1A2
TXD
1B4
RXD
1B4 SKT2 RXD
2
SKT2 TXD
3
SKT2 DGND
1
SKT2 DGND
4
FUNCTION EXTERNAL ALC-CONTROL
LINK NO 1
VOX-CONTROL BUSY-CONTROL RX-AUDIO INHIBIT
B
NO LINK
C
D
AUXILLARY
EMERGENCY
HUSH
HORN
DISABLED
DISABLED
DISABLED
DISABLED LOCKEDON VOX-MUTED
VOX-INHIBIT
AUX-CONTROL
ENABLED
ENABLED
2 3 4 5
POSITION A
--
-
--
--
--
-
-
SIGNAL TO POWER-CONNECTOR P3/PIN-1 (ON MAIN RF PCB).
*
*
DATAMODEM
THIS SECTION IS ONLY USED IN CONJUCTION
WITH THE UART PCB (220-01348-04)
T2000 SERIES II
DATA INTERFACE DECOUPLING SECTION
