tams elektronik LED Control Basic User manual

Manual
LED Control
LED Control Basic
LED constant current source
Item no. 53-00100
FB-11 | FB-12 | FB-13
Cab lig ting
Item no. 53-00110 | 53-00120 | 53-00130
ZSB-2
Train rear lig ting
Item no. 53-00180
tams elektronik
n n n

Englis LED-Control
Table of contents
1. Getting started............................................................................3
2. Safety instructions.......................................................................5
3. Safe and correct soldering...........................................................8
4. Operation overview.....................................................................9
5. Tec nical specifications..............................................................11
6. Connections..............................................................................12
7. C eck list for troubles ooting.....................................................17
8. Guarantee bond........................................................................18
9. Declaration of conformity...........................................................19
10. Declarations conforming to t e WEEE directive...........................19
© 12/2015 Tams Elektronik GmbH
All rig ts reserved. No part of t is publication may be reproduced or
transmitted in any form or by any means, electronic or mec anical,
including p otocopying, wit out prior permission in writing from Tams
Elektronik GmbH.
Subject to tec nical modification.
Page 2

LED-Control Englis
1. Getting started
T is manual applies to t e following lig ting modules, so for:
LED ControlBasic,
train rear lig ting ZSB-2,
driver´s cab lig ting FB-11, FB-12 and FB-13.
Provided t ere are no ot er details given for particular sections, t e
information given applies to all modules.
How to use this manual
T is manual gives step-by-step instructions for safe and correct fitting and
connecting of t e modules, and operation. Before you start, we advise you
to read t e w ole manual, particularly t e c apter on safety instructions
and t e c ecklist for trouble s ooting. You will t en know w ere to take
care and ow to prevent mistakes w ic take a lot of effort to correct.
Keep t is manual safely so t at you can solve problems in t e future. If
you pass t e module on to anot er person, please pass on t e manual
wit it.
Intended use
T e modules are designed for mounting and use in model railroad
ve icles driven in analogue or digital controlled layouts. Any ot er use
is inappropriate and invalidates any guarantees.
T e modules s ould not be mounted by c ildren under t e age of 14.
Reading, understanding and following t e instructions in t is manual
are mandatory for t e user.
Page 3

Englis LED-Control
Checking the package contents
PCBs Additional
components,
c aracteristics
CD (containing t e
manual and furt er
information)
LED ControlBasic 2 --- 1
ZSB-2 2 2 LEDs s aped like
train rear lanterns,
nominal size TT - H0
1
FB-11 2 equipped wit a
yellow LED
1
FB-12 2 equipped wit a
pure w ite LED
1
FB-13 2 equipped wit a
warm w ite LED
1
Required materials
For mounting and connecting t e module you need:
an electronic soldering iron (max. 30 Watt) or a regulated soldering
iron wit a fine tip and a soldering iron stand,
a tip-cleaning sponge,
a eat-resistant mat,
a small side cutter and wire stripper,
as necessary a pair of tweezers and long nose pliers,
t in connecting wire.
Wit LED ControlBasic: LEDs for t e ve icle´s lig ting.
If required: a bridging capacitor (> 100 µF) wit a voltage sustaining
capability of
> 16 V (w en connected to a power supply < 18 V) or
> 25 V (w en connected to a power supply > 18 V).
Page 4

LED-Control Englis
2. Safety instructions
Mechanical hazards
Cut wires can ave s arp ends and can cause serious injuries. Watc
out for s arp edges w en you pick up t e PCB.
Visibly damaged parts can cause unpredictable danger. Do not use
damaged parts: recycle and replace t em wit new ones.
Electrical hazards
Touc ing powered, live components,
touc ing conducting components w ic are live due to malfunction,
s ort circuits and connecting t e circuit to anot er voltage t an
specified,
impermissibly ig umidity and condensation build up
can cause serious injury due to electrical s ock. Take t e following
precautions to prevent t is danger:
Never perform wiring on a powered module.
Assembling and mounting t e kit s ould only be done in closed,
clean, dry rooms. Beware of umidity.
Only use low power for t is module as described in t is manual and
only use certified transformers.
Connect transformers and soldering irons only in approved mains
sockets installed by an aut orised electrician.
Observe cable diameter requirements.
After condensation build up, allow a minimum of 2 ours for
dispersion.
Use only original spare parts if you ave to repair t e kit or t e
ready-built module.
Page 5

Englis LED-Control
Fire risk
Touc ing flammable material wit a ot soldering iron can cause fire,
w ic can result in injury or deat t roug burns or suffocation.
Connect your soldering iron or soldering station only w en actually
needed. Always keep t e soldering iron away from inflammable
materials. Use a suitable soldering iron stand. Never leave a ot
soldering iron or station unattended.
Thermal danger
A ot soldering iron or liquid solder accidentally touc ing your skin can
cause skin burns. As a precaution:
use a eat-resistant mat during soldering,
always put t e ot soldering iron in t e soldering iron stand,
point t e soldering iron tip carefully w en soldering, and
remove liquid solder wit a t ick wet rag or wet sponge from t e
soldering tip.
Dangerous environments
A working area t at is too small or cramped is unsuitable and can cause
accidents, fires and injury. Prevent t is by working in a clean, dry room
wit enoug freedom of movement.
Page 6

LED-Control Englis
Other dangers
C ildren can cause any of t e accidents mentioned above because t ey
are inattentive and not responsible enoug . C ildren under t e age of
14 s ould not be allowed to work wit t is kit or t e ready-built
module.
Caution: Little c ildren can swallow small components wit
s arp edges, wit fatal results! Do not allow components to reac
small c ildren.
In sc ools, training centres, clubs and works ops, assembly must be
supervised by qualified personnel.
In industrial institutions, ealt and safety regulations applying to
electronic work must be ad ered to.
Page 7

Englis LED-Control
3. Safe and correct soldering
Caution: Incorrect soldering can cause dangers t roug fires
and eat. Avoid t ese dangers by reading and following t e directions
given in t e c apter Safety instructions.
Use a small soldering iron wit max. 30 Watt. Keep t e soldering tip
clean so t e eat of t e soldering iron is applied to t e solder point
effectively.
Only use electronic tin solder wit flux.
W en soldering electronic circuits never use soldering-water or
soldering grease. T ey contain acids t at can corrode components
and copper tracks.
Solder quickly: olding t e iron on t e joints longer t an necessary can
destroy components and can damage copper tracks or soldering eyes.
Apply t e soldering tip to t e soldering spot in suc a way t at t e
wire and t e soldering eye are eated at t e same time.
Simultaneously add solder (not too muc ). As soon as t e solder
becomes liquid take it away. Hold t e soldering tip at t e spot for a
few seconds so t at t e solder flows into t e joint, t en remove t e
soldering iron.
T e joint s ould be eld still for about 5 seconds after soldering.
To make a good soldering joint you s ould use a clean and
unoxidised soldering tip. Clean t e soldering tip wit a damp piece of
clot , a damp sponge or a piece of silicon clot .
After soldering c eck (preferably wit a magnifying glass) tracks for
accidental solder bridges and s ort circuits. T is would cause faulty
operation or, in t e worst case, permanent damage. You can remove
excess solder by putting a clean soldering tip on t e spot. T e solder
will become liquid again and flow from t e soldering spot to t e
soldering tip.
Page 8

LED-Control Englis
4. Operation overview
LED ControlBasic
On t e PCB are integrated a constant current source, a rectifier and
connecting points for a bridging capacitor.
Constant current source: A transistor ensures, t at during operation a
constant current of approximately 20 mA is available. T is allows LEDs
to be connected directly wit out series resistors. T ey ave a constant
brig tness after reac ing t e required minimum voltage, independent
from t e voltage supplied. T e minimum voltage for blue and w ite
LEDs is approx. 4 V, for different-coloured LEDs approx. 3 V.
Rectifier: W en connecting t e PCB to analogue a.c. voltage or digital
voltage (so t e function output of a ve icle decoder) t e integrated
rectifier brings t e LEDs to lig t in bot directions of travel. W en
connecting t e PCB to analogue d.c. voltage an additional bridge
rectifier is required, w en required t at t e LEDs lig t in bot directions
of travel.
Connecting points for a bridging capacitor: Connecting a bridging
capacitor prevents t e connected LEDs from flickering at s ort current
interruptions (e.g. w en passing points). Wit an adequate
dimensioning of t e capacitor t e LEDs can also be supplied in longer
currentless sections.
Connecting LEDs
You can connect one LED or several LEDs in series to one LED
ControlBasic. T e maximum number of LEDs to be connected depends
on t e voltage supplied and t e fluorescent colour of t e LEDs.
Page 9

Englis LED-Control
Connecting train rear lanterns
W en using t e LED ControlBasic wit t e train rear lig ting (ZSB-2) it is
recommended to connect eac LED (train rear lantern) via a PCB to t e
carriage´s back board. It is possible as well to connect several train
rear lanterns or one train rear lantern and furt er LEDs in series to one
LED ControlBasic.
Driver´s cab lighting
T e driver´s cab lig ting is designed like t e LED ControlBasic, but is
equipped additionally wit a SMD-LED. Like t e LED ControlBasic t ere is
integrated a LED constant current source and it is possible to connect a
bridging capacitor and an additional rectifier. It is not possible to
connect furt er LEDs.
T e LEDs s ine in t e following colours:
FB-11: yellow
FB-12: pure w ite
FB-13: warm w ite
Page 10

LED-Control Englis
5. Tec nical specifications
Supply voltage analogue a.c. or d.c. voltage
or digital voltage
Minimum voltage appr. 3 V (yellow, red, green
LEDs)
or 4 V (w ite, blue LEDs)
Maximum voltage 20 V a.c. voltage or
24 V d.c. digital voltage
Current consumption (appr.) 20 mA
Connection for buffer capacitor
Capacity
Electric strengt
- voltage supply < 18 V
- voltage supply > 18 V
1
min. 100 µF
min. 16 V
min. 25 V
Protected to IP 00
Ambient temperature in use 0 ... +60 °C
Ambient temperature in storage -10 ... +80 °C
Comparative umidity allowed max. 85 %
Dimensions of t e PCB (approx.) 7.5 x 6.5 mm
Weig t of PCB:
LED ControlBasic
Driver´s cab lig ting
appr. 0.11 g
appr. 0.14 g
Page 11

Englis LED-Control
6. Connections
Preliminary work
Before mounting t e PCB into t e ve icle you s ould carry out all
required soldering:
wires for t e connection to t e power supply;
if required: connecting wires for external LEDs;
if required: additional bridging capacitor;
if required: additional rectifier.
W ile soldering avoid eating plastic parts of locomotives and
carriages. Parts mig t go out of s ape!
Connection diagram
Connection to (analogue) a.c. voltage
W en connecting t e PCB to (analogue) a.c. voltage, t e connections´
polarity is not relevant. T e LEDs s ine independently of t e direction
of travel.
Page 12

LED-Control Englis
Connection to (analogue) d.c. voltage
W en connecting t e PCB to (analogue) d.c. voltage, you ave to
observe t e connections´ polarity. T e LEDs s ine in one direction of
travel only w en connected to (analogue) d.c. voltage. If t ey ave to
work in bot directions of travel, mount an additional bridge rectifier
(e.g. item no. 83-19100-10, not included in delivery) according to t e
connection diagram.
Connection to a decoder output
Connect t e connecting point X4 on t e PCB to t e appropriate output
of t e locomotive or function decoder. Connect t e connecting point X3
to t e return conductor of t e output or t e return conductor for all
outputs.
Alternatively you can connect t e connecting point X3 to t e ve icle´s
ousing ground. Please note t at in t is case t e LEDs flicker due to
principle w en t e decoder is controlled in Motorola format.
Info: Light emitting diodes (LEDs)
W en operated in t e forward direction t e LEDs lig t. T ey are
available in several different versions (differing in colour, size, form,
luminosity, maximum current, voltage limits). T e longer lead of wired
LEDs (not wit LEDs for ZSB-2) is normally t e anode (positive pole).
Wit SMD-LEDs t e cat ode normally is s own by a mark on t e
ousing.
W en using LEDs you always ave to limit t e current conduction (e.g.
by mounting a series resistor), ot erwise t ey will be damaged after a
s ort operating duration. T e LED ControlBasic as an integrated
constant current source limiting t e current at t e output to 20 mA.
T us it is possible to connect LEDs directly (wit out series resistor).
Page 13

Englis LED-Control
Connecting LEDs
You can connect one LED or several LEDs in series directly (wit out
series resistor) to one LED ControlBasic. T e maximum number of LEDs
you can connect to one PCB depends on t e voltage supplied and t e
fluorescent colour of t e LEDs.
Notice: It is not possible to connect external LEDs to a driver´s cab
lig ting.
Caution: T e legs of a LED s ould not be mounted crosswise to
avoid s ort circuits!
Maximum number of LEDs per PCB connected in series
Forward
voltage of
t e LEDs*1
Nominal /
operating voltage
of t e transformer
(=)*2
Max.
number
of
LEDs*3
Nominal /
operating voltage
of t e transformer
(~)*2
Max.
number
of
LEDs*3
2 V 12 V / 12 V 5 12 V / approx. 17 V 7
4 V 12 V / 12 V 2 12 V / approx. 17 V 3
2 V 16 V / 16 V 7 16 V / approx. 22 V 10
4 V 16 V / 16 V 3 16 V / approx. 22 V 5
2 V 18 V / 18 V 8 18 V / approx. 25 V 11
4 V 18 V / 18 V 4 18 V / approx. 25 V 5
*1 T e forward voltage of w ite and blue LEDs is approx. 4 V, differing coloured LEDs approx.
2 V.
*2 Nominal voltage and operating voltage: T e operating voltage wit a.c. transformers is
approx. 1,4 times t e nominal voltage given on t e transformer. Wit d.c. power packs t e
operating voltage corresponds to t e given nominal voltage.
*3 Tolerance and / or voltage fluctuations in practice often cause t e calculated operating
voltage not being available. For t at reason it is recommended to connect one LED less t an
possible in t eory.
Page 14

LED-Control Englis
Connect t e LED(s) according
to t e connection diagramm to
t e connecting points X1 and
X2.
Connecting train rear lanterns:
Caution:
T e LEDs s aped like train
rear lanterns ave to be
mounted according to t e
connection diagram! T e
longer lead is not in general
t e anode (+)!
Mounting the train rear lanterns
In order to fix a LED s aped like a train rear lantern safely, it is
recommended to use a PCB of its own for eac LED.
Fix t e PCB on t e inside of t e carriage´s board beside t e oles
needed to feed t roug t e legs of t e LED. Take care to mount t e
connecting points for t e LED directly beside t e oles. Bend t e legs of
t e LED in direction of t e PCB, w en fed t roug t e ole. S orten t e
legs so t at t ey end directly above t e connecting points and t en
solder t em.
Page 15

Englis LED-Control
Note: T e LED s ould be mounted wit a small distance to t e back of
t e carriage like in reality. Use a matc as a spacer w ile mounting t e
LED.
Info: Electrolytic capacitors
Electrolytic capacitors are often used to store energy. One of t e two
leads is marked wit a minus sign w ic indicates t e mounting
orientation. T e value is given on t e casing.
Electrolytic capacitors are available wit different voltage sustaining
capabilities and capacities. T e maximum capacity only depends on t e
space available for mounting t e capacitor (t e ig er t e capacity t e
bigger t e capacitor). Using an electrolytic capacitor wit a voltage
sustaining capability ig er t an required is always possible.
Connecting a bridging capacitor
In order to supply t e LEDs in currentless parts you can mount an
additional capacitor to t e PCB. It is recommended to c oose a
capacitor wit a capacity as ig as possible. T e minimum voltage
sustaining capability of t e capacitor depends on t e power supply:
Power supply Voltage sustaining capability of t e bridging
capacitor
< 18 V > 16 V
> 18 V > 25 V
Please note: W en connecting t e PCB to a decoder output intended to
be dimmed, you s ould not mount a bridging capacitor.
Page 16

LED-Control Englis
7. C eck list for troubles ooting
Parts are getting very ot and/or start to smoke.
Disconnect t e system from t e mains immediately!
Possible cause: T e connections to t e power supply are connected
t e wrong round. à C eck t e connection. In t is case t e PCB and
t e connected LEDs are probably damaged irreparably.
T e LED(s) does / do not lig t.
Possible cause: T e connection to t e power supply is interrupted.
à C eck t e connections.
Possible cause: If connected to direct (analogue) voltage t e
connections "+" and "-" are incorrectly connected. à C eck t e
connections.
T e LED(s) only lig ts / lig t in one direction of motion.
Possible cause: T ere is no rectifier mounted in series alt oug
connected to direct voltage. à Mount a rectifier.
Hotline: If problems wit your module occur, our otline is pleased to
elp you (mail address on t e last page).
Repairs: You can send in a defective module for repair (address on t e
last page). In case of guarantee t e repair is free of c arge for you.
Wit damages not covered by guarantee, t e maximum fee for t e
repair is 50 % of t e sales price according to our valid price list. We
reserve t e rig t to reject t e repairing of a moduel w en t e repair is
impossible for tec nical or economic reasons.
Please do not send in modules for repair c arged to us. In case of
warranty we will reimburse t e forwarding expenses up to t e flat rate
we c arge according to our valid price list for t e delivery of t e
product. Wit repairs not covered by guarantee you ave to bear t e
expenses for sending back and fort .
Page 17

Englis LED-Control
8. Guarantee bond
For t is product we issue voluntarily a guarantee of 2 years from t e
date of purc ase by t e first customer, but in maximum 3 years after
t e end of series production. T e first customer is t e consumer first
purc asing t e product from us, a dealer or anot er natural or juristic
person reselling or mounting t e product on t e basis of self-
employment. T e guarantee exists supplementary to t e legal warranty
of merc antability due to t e consumer by t e seller.
T e warranty includes t e free correction of faults w ic can be proved
to be due to material failure or factory flaw. Wit kits we guarantee
t e completeness and quality of t e components as well as t e function
of t e parts according to t e parameters in not mounted state. We
guarantee t e ad erence to t e tec nical specifications w en t e kit
as been assembled and t e ready-built circuit connected according to
t e manual and w en start and mode of operation follow t e
instructions.
We retain t e rig t to repair, make improvements, to deliver spares or
to return t e purc ase price. Ot er claims are excluded. Claims for
secondary damages or product liability consist only according to legal
requirements.
Condition for t is guarantee to be valid, is t e ad erence to t e
manual. In addition, t e guarantee claim is excluded in t e following
cases:
if arbitrary c anges in t e circuit are made,
if repair attempts ave failed wit a ready-built module or device,
if damaged by ot er persons,
if damaged by faulty operation or by careless use or abuse.
Page 18

LED-Control Englis
9. Declaration of conformity
T is product conforms wit t e EC-directives mentioned below
and is t erefore CE certified.
2004/108/EG on electromagnetic. Underlying standards: EN 55014-1
and EN 61000-6-3. To guarantee t e electromagnetic tolerance in
operation you must take t e following precautions:
Connect t e transformer only to an approved mains socket installed
by an aut orised electrician.
Make no c anges to t e original parts and accurately follow t e
instructions, connection diagrams and PCB layout included wit t is
manual.
Use only original spare parts for repairs.
2011/65/EG on t e restriction of t e use of certain azardous
substances in electrical and electronic equipment (ROHS). Underlying
standard: EN 50581.
10. Declarations conforming to t e WEEE directive
T is product conforms wit t e EC-directive 2012/19/EG on
waste electrical and electronic equipment (WEEE).
Don´t dispose of t is product in t e ouse refuse, bring it to t e next
recycling bay.
Page 19

n
n
n
Information and tips:
n
ttp://www.tams-online.de n
n
n
n
Warranty and service:
n
Tams Elektronik GmbH n
Fu rberger Straße 4
DE-30625 Hannover
n
fon: +49 (0)511 / 55 60 60
fax: +49 (0)511 / 55 61 61
n
e-mail: modellba [email protected] n
n
