T&D RTR-600BD User manual

RTR-600BD is the battery charger dock for the RTR-601 Series data loggers. It also acts as a USB
communication interface dock between the RTR-601 and PC for registration and setup of the RTR-601.
• RTR-600BD is referred to as simply the “dock” in this document.
• RTR-601 Series is referred to as simply "RTR-601" or "Remote Unit" in this document.
• To use RTR-601 as a Remote Unit, it is necessary to have any of the compatible Base Units: RTR500BW, RTR-500NW, RTR-500AW, RTR500BC or RTR-500.
Make sure to charge the battery on a at surface without
vibration. Placing the dock on an unstable surface may result
in injury or damage from falling.
Battery cannot be charged by USB bus power. Make sure to use
the AC adaptor.
To mount the dock on a wall, rmly tighten the screws to
prevent it from falling.
1.
Connect the supplied AC adaptor to the dock.
2.
Place the RTR-601 into the dock and charging will begin.
• Once the RTR-601 is recognized, the Blue LED on the dock will light up.
• Once charging begins properly, the Green LED on the RTR-601 will light up
and the LCD display will turn o.
* Up to two Remote Units can be charged
at the same time.
• Once charging has been completed,
LEDs on both the dock and the Remote
Unit(s) will turn o.
Please stop using in the following situations.
• The Red LED on the dock is ON:
If the dock recognizes an irregular electrical activity, it automatically
stops charging and the Red LED will light up. Unplug the AC adaptor
and check the following:
(1) that there are no metallic objects between the dock and Remote
Unit(s), and
(2) if the Remote Unit(s) are properly placed on the dock.
The Red LED on the dock may light up for just a moment due to
power uctuation. There is no problem unless the Red LED remains
on.
• The Orange LED on RTR-601 is BLINKING:
If the body of the RTR-601 gets too hot (over 40°C), the Orange LED
will start blinking and battery charging will temporarily stop. Once
the body cools down, charging will restart.
• If, after checking the above and resetting the RTR-601 several
times, the Red LED on the dock remains on, please stop using the
dock and contact your distributor.
RTR-600BD Specications
Compatible
Devices
RTR-601 Series Data Loggers (Remote Unit)
RTR-601-110 / 130 / E10 / E30
Power AC Adaptor (AD-05A3)
Input Voltage 5V 2A
Communication
Interface USB / Optical Communication (For Setup)
Charging Method Electromagnetic Induction Type Non-Contact Charg-
ing System
Charging Time
(*1) Approx. 70 min.
Charging Current 700 mA (typical) per Remote Unit
Dimensions H 198.3 mm × W 136 mm × D 56.6 mm (including
protrusions)
Weight Approx. 330 g
Operating
Environment
Temperature: 0 to 40°C
Humidity: 90%RH or less (no condensation)
*1:This is the estimated time to complete a full charge after the battery charge warning
message appears. If the body of the Remote Unit gets hot and battery charging
temporarily stops, the charging time will be longer.
The specications listed above are subject to change without notice.
For details about registration and settings, refer to
[RTR500BW + RTR-601 Setup Guide (PDF)] that is available for
download from T&D Website.
tandd.com/manual/
Download and install the software "RTR500BW for Windows"
from T&D Website, and follow the directions as they appear to
complete the registration and setup process.
USB Connection
(2)
(1)
Place the RTR-601 into the right side (with communication
port) of the dock.
Make sure to push down on the RTR-601 until you hear a "click"
sound.
"click"
* Once the registration and setup are complete, make sure to remove the
RTR-601 from the dock to avoid wireless communication failures due to
battery charger noise.
RTR-600BD Part Names
LED (Blue/Red)
LED (Blue/Red)
USB Connector
Remote Unit
Communication Port
AC Adaptor Jack
Accessories Included in Package
• AC Adaptor (AD-05A3)
• USB Cable (US-15C)
• Wall Mount Screws (x 3)
• Manual Set (Warranty Included)
Battery Charge Dock for RTR-601
RTR-600BD User’s Manual
Use as a Battery Charger
Use for Remote Unit Registration
When the [Connect a Remote Unit] dialog box
appears, unplug the USB cable from the Base
Unit (1) and plug it into the dock (2).
Before placing the RTR-601 into the dock, make sure that RTR-601
is not greasy or dirty as the dock is not waterproof and cannot be
washed.

2020. 11 16504390046 (2nd Edition)
Safety Precautions and Instructions
The following items should be strictly obeyed for the safe usage of this product, and for protecting yourself and other people from bodily
harm and/or damage to property.
Explanation of Symbols
<Warning Symbols>
DANGER Failure to follow the instructions with this symbol could cause
serious injury or even death.
CAUTION Failure to follow the instructions with this symbol could cause
personal injury or physical damage to equipment.
<Picture Symbols>
Denotes an important warning or caution.
Denotes a forbidden action.
Denotes an action that should be carried out.
DANGER To Prevent Serious Accidents
Do not place metal or other foreign objects on the unit. Doing
so may cause heat or re, which can lead to serious injury or
damage.
If you have a pacemaker, please consult your doctor before
using this product. Also, when using this product, make sure
that there is ample distance between the unit and the
pacemaker. Electromagnetic waves can interfere with the
operation of your pacemaker.
Do not disassemble, repair or modify the unit and accessories.
Do not use the unit in any environment that is exposed to
chemicals and harmful gases. Doing so may cause corrosion
and/or other danger to the unit. Also, coming in contact with
hazardous substances may cause bodily harm to the user or
people nearby.
This product is not water resistant. Do not use the unit in any
place exposed to liquids, such as water and oil, and/or areas
with high humidity. If the unit gets wet, immediately unplug
the AC adaptor and stop using.
Do not handle the unit or the plug with wet hands.
This product has been designed for private and/or industrial
use only. It should not be used in situations where strict safety
precautions are necessary such as with medical equipment,
or in systems directly or indirectly connected with human life
or well-being.
Do not drop or expose the unit to a strong impact.
Do not connect any communication cables connected to the
unit to telephone line outlets. Continued use may cause re
or electrocution.
Do not cut or process power cords or cables. Also, do not
twist, pull or swing any of the cords or cables.
To prevent damage to the unit from static electricity, remove
static electricity from your body by touching metal around
you (such as a door knob and window frame) before touching
the unit.
Place and store the unit and accessories out of the reach of
children.
Do not place the unit near precision equipment such as a
magnetic cards, magnetic recording media, and/or watches.
Electromagnetic waves can cause loss of or damage to your
important data.
Make sure to place the unit on a at, stable surface during the
charging process. Placing the unit on an unstable surface may
result in injury or damage to the unit from falling.
We are not responsible for any damage, malfunction or
trouble, whether direct or indirect, caused by the use of our
product.
Do not use any power or cables other than those specied by
T&D Corporation.
Do not place objects on the unit. This may cause overheating.
Do not disconnect the USB cable during USB communication.
Doing so may cause adverse eects to the unit and/or PC.
Make sure that power and cable plugs are inserted fully, so as
not to cause an improper connection. Also, when unplugging
the cable from the unit, do not pull the cord, but hold the
connector to disconnect.
If the unit produces heat, emits smoke or a strange smell, or
makes unusual noises, immediately unplug the AC adaptor
and stop using it. Also, disconnect the unit from the PC.
CAUTION Do not place or store in the following areas:
• Areas exposed to direct sunlight
• Areas subject to direct ames or heaters, as well as areas in which
hot air accumulates and creates extremely high temperatures
• Areas exposed to static electricity
• Areas exposed to strong magnetic elds
• Areas exposed to dampness
• Areas subject to condensation or wet areas
• Unstable areas exposed to vibration
• Areas exposed to excessive smoke, dust or dirt.
CAUTION Other Precautions
• Use the unit in the specied operating environment. Do not use it for
any purpose other than for which it was designed.
• When connecting the unit to your PC, make sure to follow all
warnings and directions from your computer manufacturer.
• We shall not guarantee the unit's operation if it has been connected
to a PC using a USB hub or a USB extension cable.
• Do not insert any foreign objects into any of the units' jacks.
• If the unit gets dirty, wipe it with a clean cloth.
• Make sure to remove dust and dirt from plugs of any cables.
• If charging the battery interferes with your TV or radio, move the
unit at least one meter away and try charging again.
Important Notices and Disclaimers
In order to properly use this product, please carefully read all attached
documents before using.
• All rights of the attached documents belong to T&D Corporation. It
is prohibited to use, duplicate and/or arrange a part or whole of the
attached documents without the permission of T&D Corporation.
• All registered trademarks, company names, product names and
logos mentioned herein or for products being used are the property
of T&D Corporation or of their respective owners.
• Specications, design and other contents outlined in the attached
documents are subject to change without notice.
• Please follow the safety precautions outlined in the attached
documents carefully. We cannot guarantee nor are we responsible
for safety if this product is used in any manner other than was
intended.
• On-screen messages in the attached documents may vary slightly
from the actual messages.
• Please notify the shop where you purchased this product or T&D
Corporation of any mistakes, errors or unclear explanations in the
attached documents.
T&D Corporation accepts no responsibility for any damage or loss
of income caused by the use of our product.
• Accompanying documents cannot be reissued, so please keep them
in a safe place.
• Please read the warranty and provisions for free repair carefully.
For product infomation or questions contact us at:
For product inquiries, please contact your local distributor. Visit T&D Website for the
distributors list. If you can not nd a distributor in your area, please contact our main
oce in Japan or one of our branch oces in Europe or America.
tandd.com/purchasing/
