Tandem 70 User manual

One World. One Smart Choice.™
Owner’s Manual
TANDEM®70
A7595-0310 Rev G
Charger / Power Supply
®

1 INTRODUCTION
 FEATURES
 SAFEGUARDS
 GROUNDING/EARTHING

2 OPERATION
 Charging
 Applications
 ThreeStageChargingMethodology
3 LedIndications
4 OPERATIONASDCCAMERASUPPLYFROMMAINS
 POWERLOSS
 FCCNOTICE
 SPECIFICATIONS
 FUSE/TYPEREPLACEMENT

5 WARRANTY
TABLE OF CONTENTS

1
INTRODUCTION
TheTandem®70isthesmallestandlightestpackageavailableinboth
achargerandon-camerapowersupply.ItincorporatesalloftheLogic
Series®circuitsthatareemployedineveryAnton/Bauercharger.The
fastchargefeaturemakesitaperfectcomplementtoacurrentAnton/
Bauerbatterysystemandgivenitssmallsizeisidealfortravel.
LikeallAnton/Bauerchargers,everythingisautomatic.Onceabattery
isplacedontothecharger,itwillautomaticallygointooneoftheThree
StageChargingmodes.Iftheunitandbatteryarethenattachedtoa
pieceofequipment,thepowersupplymodewillprevail,stoppingall
charging.Oncethecamera/camcorderisturnedoff,theTandem®70
will continue charging the battery, remembering where it previously
stopped.
FEATURES
• 70WattPowerSupply@16.4VDC
• FastCharging

• LogicSeriestechnology
• WideRangeInput(100-240vac50/60Hz)
• Seven(7)IndependentChargeTerminationSystems
• Lightweight(16oz.)
WARNING:
Tandem®70isa70wattpowersupply.Exceeding70wattsmaycause
fusetoshortleavingunitunabletofunction.Pleasecheckequipment
tobepoweredtoensureunder70wattsoftotaldraw.
This symbol indicates the presence of
un-insulated, dangerous voltage inside
the enclosure of the charger.  There is
a risk of shock if the charger case is
opened.
This symbol indicates that important
operating and maintenance instructions
areintheaccompanyingliterature.
SAFEGUARDS
Power Sources:Thisunitwasdesignedtooperateatmainsvoltages
from100to240VoltsAC,50/60Hz.
Risk of Electrical Shock:Referservicingtoqualiedservicepersonnel.
TO PREVENT FIRE OR SHOCK HAZARD, DO
NOT EXPOSE THIS UNIT TO RAIN OR
MOISTURE.
GROUNDING/EARTHING
IMPORTANT WARNING: THIS APPARATUS MUST
BE EARTHED.
Toensuresafeoperation,thethreepinplugsuppliedmustbein-
sertedonlyintoastandardthree-pinpowerpointwhichiseffectively
groundedthroughthenormalhouseholdwiring.Extensioncords
usedwiththeequipmentmustbethree-conductorandbecorrectly
wiredtoprovideconnectiontoearthground.Improperlywiredexten-
sioncordsareadangerouselectricalhazard.
Thefactthattheequipmentoperatessatisfactorilydoesnotimply
thatthepowerpointisproperlygroundedandthattheinstallationis
completelysafe.Ifanydoubtexistsaboutthecorrectgroundingof
thepowerpoint,consultaqualiedelectrician.
IMPORTANT:Thewiresinthismainsleadarecoloredinaccordance
withthefollowingcode:
Greenandyellow Earth
Blue Neutral
Brown Live

2
Charging
As with all Anton/Bauer chargers, charging with Tandem® 70 is fully
automatic.MountanyLogicSeries®batterytotheTandem® 70 and
it will automatically determine and execute the appropriate charge
routine.
Applications
The Tandem® 70 will charge any Anton/Bauer Logic Series® Gold
Mount®batteryincludingmodel:ProPac®,Trimpac®,DigitalProPac®,
DigitalTrimpac®,HyTRON®,andDIONIC®series.
NOTE: Anton/Bauer always recommends that each battery has its
own charge position. A battery can remain on an Anton/
Bauer charger indenitely.
TheTandem®70incorporatestheexclusiveInterActive®communication
betweenbatteryandcharger,whichallowsthechargertoidentifyany
Anton/Bauerbatteryattachedanddeterminetheprecisechargeroutine
forthatbatteryundertheprevailingconditions.
NOTE: Due to the specialized communications between the
charger and the battery, batteries without the Logic Series®
construction and communication capability (manufactured
by Anton/Bauer before 1989 as well as so-called “rebuilds”)
can not be charged with this charger. The InterActive®
communication of Logic Series® batteries is the key which
allows the Tandem® 70 to safely identify and address new style
and chemistry batteries as they are developed. Moreover, this
communication ensures that batteries contain the quality cells,
workmanship and safety of genuine Anton/Bauer products. If
a non-Logic Series® battery is placed on the charger, the red
and green LED indicators will ash alternately. This indication
means that the battery cannot communicate its identity to the
Tandem® 70 and is not charging. After 30 seconds of ashing
green and red LED’s, the red LED will remain on, indicating a
HOLD state.
WARNING: USE OF THIS CHARGER WITH ANY BATTERY NOT
MANUFACTURED BY ANTON/BAUER MAY RESULT
IN BATTERY DAMAGE AND CAUSE RISK OF FIRE OR
PERSONAL INJURY.
THREE STAGE CHARGING METHODOLOGY
Ingeneral,theTANDEM®70willdeliverathree stage charge routine
toeachbattery.
1. STAGE ONE will deliver a high rate charge matched to the
capabilitiesofthebattery(typicallyaoneortwohourrate,depending
onbatterytype).Duringthisstage,sevenseparatecutoffmethods
areinoperation,simultaneously,ensuringthefastest,safestcharge
forthatbattery:
TCO - TemperaturecutoffwhichstopstheStageonechargeprecisely
OPERATION
whenatemperatureindicativeoffullchargeisreached;
Dt/dT - A microprocessor based algorithm which measures a
riseintemperatureoveraspecictime,veryaccuratelyindicating
full charge.  This method is also the recommended method for
chargingNi-MHtechnology;
-∆V - Amethodtodeterminetheendofstageonechargingby
identifyingacharacteristic“reverseslope”ofaNi-Cdcell.Since
thischaracteristiccanbedisguisedbytheage,temperatureand
the number of the cells in a battery, it can never be employed
alone;
CCO -Thismethodrequirestheidenticationoftheparticularbattery
size(capacity)andchemistry,anexclusiveAnton/BauerLogicSeries®
feature.Thechargerdeterminesthemaximumcharge time forthe
particularbatteryandusesthisinformationtoensurethatovercharge
conditionsareavoided.
FUL - This determination is made when a fully charged DIGITAL
battery is returned to a charger within specied parameters of
time, temperature, and battery voltage.  The DIGITAL battery
communicatesitsfullychargedconditionandthechargerconrms
theparametersandimmediatelyindicatesafullychargedcondition,
withoutadditionalverication.
TEMPERATURE COMPENSATED VCO – For HyTRON™ series
ofbatteries.OptimizesVCOcutofftooperateonlywithincertain
temperatureparameters.
I-Min – for DIONIC batteries, a seventh cutoff method is
employed.ThebatteryischargedtospecicvoltageandI-Min
currentuntilfullchargeisreached.I-Ministhe“minimumcurrent”
owrequiredforpropercutoff.
2. STAGE TWO charging is a BALANCING or “equalize” mode which
calculates each battery pack type to offset any imbalance of the
battery’s cells, created by unequal self discharge or any capacity
mismatchoftheindividualcellsinthepack.Thisstagecanvaryin
durationfromzerotoasmuchas16hours,dependingonthecondition
of the battery. AbatterywilltypicallyleaveStageTwoin2-4 hours
underaverageoperatingconditions.
3. STAGE THREE Charging is the Anton/Bauer exclusive Lifesaver®
maintenancemode.Thispatentedpulseroutinekeepsbatteriesfully
charged,freefromself-discharge-indenitely-withoutdamagingheat
associatedwithaso-called“tricklecharge”.
NOTE: Anton/Bauer strongly recommends that batteries are kept
on a charger until ready for use. The Lifesaver® mode will
keep them 100% charged and ready for use.

3
OPERATION CONTINUED
LED INDICATIONS
TheTandem®70hasthreeLEDsonered(charger),twogreen(readyandstatus).ThestatusgreenLEDindicatesthreestates;
1. SolidgreenLEDindicatesTandem®70isoperatingasacharger.
2. FlashingstatusgreenLEDindicatesTandem®70isoperatingasapowersupply.
3. NogreenLEDindicatespowerhasbeenremovedfromTandem®70.
TheredandgreenLED’swillindicatethechargingstatusofthebattery.ThefollowingtableidentiesalloftheLEDindicationsandtheirmeaning:
LED INDICATION MEANING
Alternating
Red&Green
IndicatesthattheTandem®70isevaluatingthebatteryand/orcommunicatingwitha
DIGITALbattery, loading battery parameters and determining the appropriatecharge
routine.  A low voltage (<11V) battery will cause this indication to continue until the
batteryis“rejuvenated”toasafechargingvoltage.
NOTE:  This indication will continue if a non-Anton/Bauer Logic Series® battery is
mountedonthecharger.ThesebatteriescannotidentifythemselvestotheTandem70
andwillnotbecharged.
SteadyRed IndicatesthatthebatteryisbeingheldbytheTandem®70tostabilizeanout-of-range
temperaturecondition.
FlashingRed IndicatesthatthebatteryiscurrentlyunderStageOnecharge.
FlashingGreen(slowrate)IndicatesthatthebatteryiscurrentlyunderStageTwocharge.
FlashingGreen(fastrate) Indicatesafullycharged DIGITAL battery is placed on the chargerandaFULcutoff
conditioncannotbemet.ThechargerisVERIFYINGthatthebatteryisinafullcharge
condition.
SteadyGreen IndicatesthatthebatteryisREADYandinStageThreeLifesaver®mode.
Red/GreenChargeStatusLED
GreenStatusLED

OPERATION AS DC CAMERA SUPPLY FROM MAINS
TheTandem®70willautomaticallyoperateasaDCpowersupplyoncethecamera,orotherdeviceisturnedon.Therearenoswitches,itis
fullyautomatic.ThesinglegreenLEDwilllightindicatingthattheunitisoperatingasapowersupply.
AbatterymaybeattachedtoTandem®70whilemountedtoacamera.WiththecameraOFF,thebatterywillcharge.Whencameraisturned
ON,Tandem®70willsupplypowertocamerarememberingthepointatwhichitleftcharging.Whencameraisturnedoff,Tandem®70will
againresumebatterycharging.
IfAClinevoltageisremovedfromtheTandem®70,andachargedbatteryismountedontheunit,powerfromthebatterywillberoutedtothe
camera.WhenAClinevoltageisrestored,thebatterywillbere-evaluatedforaproperchargeroutine.
TIP:Whencameraisusedonstakeout,(suchasindoorsonatripod)keepingabatterymountedtotheTandem®70allowsinstantswitchingto
handheld.Simplyremovethepowercordforanautomaticswitchtobatterypower.
AtalltimeswhentheTandem®70ismountedtothecamera,whetheronACorbattery,thetotalcontinuousloadlimitis70watts@16.4VDC.
WARNING: DO NOT OPERATE THIS UNIT IN THE RAIN.
POWER LOSS
IfACpowerislostduringoperationtheunitwillfunctioninthefollowingmanner:
-Whenpoweringacamerawithabatteryapplied,thegreenstatusLEDwillblinkonceeverythreeseconds.Thebatterywilltakeoverpoweringthe
cameraaslongasthebatteryischarged.
-Whenpoweringacameraandnobatteryisapplied,noLEDswillbelit.
FCC NOTICE
ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassAdigitaldevicepursuanttoPart15oftheFCCRules.These
limitsaredesignedtoprovidereasonableprotectionagainstharmfulinterferencewhentheequipmentisoperatedinacommercialenvironment.
Thisequipmentgenerates,uses,andcanradiateradiofrequencyand,ifnotinstalledandusedinaccordancewiththeinstructionmanual,may
causeharmfulinterferencetoradiocommunications.Operationofthisequipmentinaresidentialareaislikelytocauseharmfulinterferencein
whichcasetheuserwillberequiredtocorrecttheinterferenceathisownexpense.
Thisequipmenthasbeenapprovedbyoneormoreagencies.Allchangesand/ormodicationsnotexpresslyapprovedbyAntonBauer,Inc.
couldvoidtheusers’warrantyandauthoritytooperatethisequipment.Therearenoserviceablepartsinthisequipment.
SPECIFICATIONS
Size 5.2”x4.03”x2.19”
Weight 16oz(1lb.)
InputVoltage 100-240VAC50/60Hz
OutputVoltage 16.4VDC
FuseRating 7ampSurfaceMount
MaximumPower 70wattsat16.4volts
FUSE/TYPE REPLACEMENT
ThefuseoftheTandem®70isaPCBmounteddevicewhichshouldonlybereplacedbyaqualiedservicetechnician.
4

LIMITED WARRANTY
This three (3) year limited warranty for the product specied in this
document (“Product”) is given by Anton/Bauer, Inc. (“Anton/Bauer”),
14ProgressDrive,Shelton,Connecticut06484.Ifyou(thepurchaser
oftheProductfromAnton/Bauer,orthepersonforwhomtheProduct
waspurchased,ifitwasagift)haveanyquestionsregardingProduct
applications, Product specication, or to obtain warranty service on
thisoranyAnton/Bauerproduct,contactthecompanyattheaddress
above.
THISPRODUCTMUSTBEREGISTEREDWITHANTON/BAUERWITHIN
30DAYSOFPURCHASETOASSUREWARRANTYCOVERAGE.TO
REGISTERYOUMAYEITHER:
1. MAILWARRANTYREGISTRATIONCARDor
2. REGISTERONLINEATwww.antonbauer.com
TheliabilityofAnton/Bauerhereunderisexpresslylimitedtoaclaimfor
repairorreplacementoftheProductorasotherwisestatedhereinat
Anton/Bauer’ssolediscretion.Noticeofanyclaimunderthiswarranty
shall be delivered to Anton/Bauer during the period of the warranty
andtheProductshallbereturnedwithitspackagingpromptly,atyour
expense,toanAnton/BauerCustomerSupportCenterortotheaddress
above.UponreceiptoftheProductandarecordofyourcompliance
withtheconditionsofthiswarranty,Anton/Bauerwillrepairorreplace
theProductandreturnittoyou,orissueacredit,asapplicable.You
are responsible for all shipping and handling charges to and from
authorizedfacility.
THISWARRANTYDOESNOTAPPLYTOANDISVOIDINTHECASEOF
DEFECTSORDAMAGERESULTINGFROMACCIDENTS,DISASTER,
NEGLECT, MISUSE, IMPROPER INSTALLATION, IMPROPER OR
UNAUTHORIZED SERVICE OR MAINTENANCE, UNAUTHORIZED
REPLACEMENT PARTS OR ATTACHMENTS; OR DYSFUNCTION
OR MALFUNCTION OF, OR CAUSED BY, ANY OTHER PRODUCT
OR DEVICE.  Misuse includes any use of the Product in other
than its intended application, including the use of this Product
with any charging device or accessory not manufactured by and/
or specied by Anton/Bauer. This warranty does not cover, and
Anton/Bauer assumes no responsibility for, any equipment or
devices used in conjunction with the Product.
ANTON/BAUER DISCLAIMS ANY LIABILITY FOR INCIDENTAL OR
CONSEQUENTIAL DAMAGES FOR BREACH OF ANY WRITTEN
OR IMPLIED WARRANTY OF THE PRODUCT.  UNDER NO
CIRCUMSTANCES WILL ANTON/BAUER BE RESPONSIBLE FOR
ANYSPECIAL,INCIDENTALORCONSEQUENTIALDAMAGES.
ThisWarrantyistobeconstruedandenforcedinaccordancewiththe
lawoftheStateofConnecticut,includingtheprovisionsoftheUniform
CommercialCodeasadoptedandfromtimetotimeamendedinthe
State of Connecticut, and not the Convention for the International
Sale of Goods.  This choice of Connecticut law is exclusive of any
Connecticut law that would require reliance on any law foreign to
Connecticut.Shouldanyactionoflaworinequitybebroughtbyany
person under this Warranty, such action shall be brought only in the
United States District Court for the District of Connecticut, or in any
SuperiorCourtinFaireldCounty,Connecticut,USA.Somestatesdo
notallowlimitationsonhowlongawarrantylasts,sothetimeperiod
limitationhereinmaynotapplytoyou.Somestatesdonotallowthe
exclusionorlimitationofincidentalorconsequentialdamages,sothe
abovelimitationorexclusionmaynotapplytoyou.Thiswarrantygives
youspeciclegalrightsandyoumayhaveotherlegalrightswhichmay
varyfromstatetostate.
Use of unauthorized equipment in conjunction with Anton/Bauer
products constitutes misuse under our warranties and may limit or
void those warranties.  Anton/Bauer does not authorize, condone,
recommend, or otherwise assume any liability or responsibility
resultingfromtheuseofanybattery,chargeroraccessorymadeby
Anton/Bauermanufacturewithanybattery,chargeroraccessorynot
manufactured,producedor soldbyAnton/Bauer.Anton/Baueronly
authorizestheuseoforiginalAnton/Bauerproductwiththisproduct.
UseonlyoriginalAnton/Bauerequipmentwiththisproduct.
5

Anton/Bauer
A Vitec Group brand
The following are trademarks of Anton/Bauer, Inc.:
Anton/Bauer, Anton/Bauer logo and parallelogram design, Aspekt, Automatique,
DataTap, DIONIC, Elipz, Egripz, Elightz, Essentialz, Gold Mount, HubZ, HyTRON, Impac,
Interactive and design, LifeSaver, Logic Series, Logic Series Logo, Maxx man logo design,
Nexus, PowerStrap, Proformer, Probe, ProPac, RealTime, Satellight, Snap-On, Stasis, Stasis
Flex, Tandem, TrimPac, Ultrakit, Ultralight, “One World. One Smart Choice”, “The power
behind the best cameras capturing the best images in the world.”, “The quality standard
of the video industry”, “The worldwide standard”, and “There should always be choices. It
makes it easier to recognize the best.”
Lexan is a registered trademark of G.E. Company Corp.
Cordura is a registered trademark of E.I. duPont de Nemours
Anton/Bauer, Inc.
World Headquarters
14 Progress Drive, Shelton, CT U.S.A.
Tel [phone] or [phone]
Fax [phone]
[e-mail]
Anton/Bauer Europe, B.V.
Eurode Business Center, Eurode - Park 1-2
6461KB Kerkrade, The Netherlands
Tel [phone]
Fax [phone]
[e-mail]
www.antonbauer.com
Anton/Bauer, Inc. - Signapore Oce
6 New Industrial Road, # 02-02 Hoe
Huat Ind. Bld., Singapore 536199
Tel [phone]
Fax [phone]
[e-mail]
