Definition Install DS15i sub
Tannoy adopts a policy of continuous improvement and product specification is subject to change Definition Install DS15i Sub data file // issue 1.06 // 15.01.08
The Definition Install DS15i sub has been designed to underpin a Definition install theatre
or media room system with truly remarkable low frequency performance. Massively
constructed around 380mm (15.00”) professional drive unit, this subwoofer will produce the
ultimate soundtrack experience, with spectacular and thunderous bass, yet still be agile
enough to maintain finer musical detail with precision and speed.
This 76 litre direct radiating design is robustly constructed MDF enclosure, using 15mm
(0.62”) for the panels and 36mm (1.42”) for the front baffle. Extensive internal bracing
minimises panel resonance ensuring a tight and responsive bass performance. Capable of
achieving 36Hz and with a sensitivity of 96dB (1W = 2.83V for 8 Ohms), the DS15i sub will
deliver an SP of 130dB peak. Recommended amplifier power is 600 – 1200W @ 8 Ohms.
Finished in rugged textured black paint, the enclosure is fitted with two binding posts, eight
M10 inserts and four rubber feet.
The DS15i sub is compact enough to bring class leading performance to a wide range of
installation applications; from media rooms to home theatre and boardrooms through to
high end marine interiors.
Product Description
• 1 x 380mm (15.00”) high power handling direct
radiating bass driver
• Immensely rugged 76 litre MDF enclosure is internally
braced, with 15mm (0.62") panels and a 36mm (1.37”)
front baffle
• Power handling 1200W programme
• Sensitivity 96dB (1W = 2.83V for 8 Ohms)
• Rated SP 130dB peak
• 2 x binding post connectors, 8 x M10 inserts and 4 x
rubber feet
• Media rooms
• Home theatre
• Boardrooms
• High end marine interiors
Features
Applications

Tannoy Un ted K ngdom
Tannoy North Amer ca
Tannoy Deutschland
Tannoy France
T: 00 44 (0) 1236 420199
T: 00 1 [phone]
T: 00 49 (180) 1111 881
T: 00 33 (0)1 7036 7473
E: enqu r [email protected]
E: nqu r [email protected]
E: [email protected]
E: [email protected]
Definition Install DS15i sub
Tannoy adopts a policy of continuous improvement and product specification is subject to change Definition Install DS15i Sub data file // issue 1.06 // 15.01.08
TECHNICAL SPECIFICATIONS
System Type Subwoofer - Direct Radiating
Frequency Range (1) 36Hz
System Sensitivity (1W @1m) (2) 96dB (1W = 2.83V for 8 Ohms)
Power Handling
Average 600W
Programme 1200W
Peak 2400W
Recommended Amplifier Power 600 - 1200 W / 8 Ohms
Rated Maximum SPL 2
Average 124dB
Peak 130dB
Nominal Impedance 8 Ohms
Driver Complement 1 x 380mm (15.00”) Bass driver
Recommended Crossover 70Hz - 300Hz, 24dB / octave
Recommended High-pass filter 35Hz, 24dB / octave
Distortion
10% Full Power (21.9V) 2nd Harmonic 3rd Harmonic
40Hz 0.83% 0.68%
100Hz 0.23% 0.44%
1% Full Power (6.9V) 2nd Harmonic 3rd Harmonic
40Hz 0.44% 0.28%
100Hz 0.15% 0.15%
Notes:
(1) Average over stated bandwidth. Measured at 1 metre on axis.
(2) Unweighted pink noise input, measured at 1 metre in an anechoic chamber
A full range of measurements, performance data, C F and Ease™ Data can be
downloaded from www.tannoy.com
Full independent verification of published specifications carried out by NWAA abs,
California can also be obtained from the downloads section of www.tannoy.com
Tannoy operates a policy of continuous research and development. The introduction
of new materials or manufacturing methods will always equal or exceed the
published specifications, which Tannoy reserves the right to alter without prior
notice. Please verify the latest specifications when dealing with critical applications.
Enclosure 76 litres, front 36mm (1.37”), other panels
15mm (0.62”) MDF internally braced.
Finish Textured black paint
Connectors 2 x Binding posts
Fittings 8 x M10 inserts.
4 x Rubber feet
Dimensions 525 x 460 x 430mm (H x W x D)
20.67 x 18.11 x 16.93” (H x W x D)
NET Weight 30kg (66.1lbs)
System Definition Instal DS15i sub Construction
8000 5210 Definition Install DS15i sub Black 1
PART N MBER PACKED Q ANTITYCOLO RMODEL NAME
Ordering Information

Tannoy Un ted K ngdom
Tannoy North Amer ca
Tannoy Deutschland
Tannoy France
T: 00 44 (0) 1236 420199
T: 00 1 [phone]
T: 00 49 (180) 1111 881
T: 00 33 (0)1 7036 7473
E: enqu r [email protected]
E: nqu r [email protected]
E: [email protected]
E: [email protected]
Definition Install DS15i sub
Tannoy adopts a policy of continuous improvement and product specification is subject to change Definition Install DS15i Sub data file // issue 1.06 // 15.01.08
PERFORMANCE MEAS REMENTS
60
70
80
90
100
110
0
0001000100101
0
20
40
60
80
100
120
140
160
000100101
p ( )
FREQ ENCY
RESPONSE
IMPEDANCE
1m on-axis frequency response
frequency (Hz)
SP , 1W/1m (dB)
frequency (Hz)
Impedance vs frequency
Impedance (ohms)

Tannoy Un ted K ngdom
Tannoy North Amer ca
Tannoy Deutschland
Tannoy France
T: 00 44 (0) 1236 420199
T: 00 1 [phone]
T: 00 49 (180) 1111 881
T: 00 33 (0)1 7036 7473
E: enqu r [email protected]
E: nqu r [email protected]
E: [email protected]
E: [email protected]
Definition Install DS15i sub
Tannoy adopts a policy of continuous improvement and product specification is subject to change Definition Install DS15i Sub data file // issue 1.06 // 15.01.08
DIMENSIONAL SKETCHES
460.0
[18.11"]
430.0
[16.93"]
525.0
[20.67"]
525.0mm
(20.67”)
460.0mm
(18.11”)
430.0mm
(16.93”)

Tannoy Un ted K ngdom
Tannoy North Amer ca
Tannoy Deutschland
Tannoy France
T: 00 44 (0) 1236 420199
T: 00 1 [phone]
T: 00 49 (180) 1111 881
T: 00 33 (0)1 7036 7473
E: enqu r [email protected]
E: nqu r [email protected]
E: [email protected]
E: [email protected]
Definition Install DS15i sub
Tannoy adopts a policy of continuous improvement and product specification is subject to change Definition Install DS15i Sub data file // issue 1.06 // 15.01.08
The bass loudspeaker shall consist of a 380mm (15.00”) low frequency transducer mounted within a vented direct radiating enclosure.
Performance of the loudspeaker, without any electronic control shall meet or exceed the following criteria: Frequency response measured at 1 metre on axis
with swept sine wave shall be 36Hz. Sensitivity shall be at least 96dB (half space) for 2.83 Volts @ 1 metre and shall be capable of producing a peak output
level of 130dB (half space) on axis at 1 metre.
The system shall have a nominal impedance of 8 Ohms and maximum power handling shall be 1200 Watts (programme). The enclosure shall be an
optimally tuned (76 litre) vented enclosure of MDF construction finished in a wear resistant textured black paint.
Input connectors shall be two binding posts and the enclosure shall be fitted with 8 x M10 flying inserts and 4 x rubber feet.
The enclosure shall not exceed the following dimensions:
525 x 460 x 430mm or 20.67 x 18.11 x 16.93” (H x W x D)
The bass loudspeaker shall be the Tannoy… Definition Install DS15i sub.
