Targus DVHD-SV2K User manual

UNIVERSAL
USB 3.0
DVHD-SV2K
DOCKING STATION
WITH POWER
QUICK START GUIDE
410-3569-001A / DOCK171USZ
Workstation Setup Power Setup
1. Connect all peripheral devices to the docking station.
2. Connect the Targus Universal Docking Station to your host device.
3. Windows will start installing the DisplayLink Driver automatically.
4. Follow the on-screen instructions until the installation is complete.
5. Identify the correct power tip (see chart above right), connect to
the DC power cable and then to the laptop.
NOTE: If your power tip is not included, contact Targus to order
the correct version.
+
Features and specifications are subject to change without notice. Microsoft and Windows are registered
trademarks of Microsoft Corporation in the United States and/or other countries. All trademarks and
registered trademarks are the property of their respective owners. ©2017 Targus, 1211 North Miller
Street, Anaheim, CA 92806
Contents
• Targus Universal USB 3.0 DVHD-SV2K
Docking Station with Power
• USB 3.0 Cable
• AC Power adapter
• DC output cable
• Power tip
Specifications
• DVI-I / HDMI Port (HDMI 2.0)
• 4 x USB 3.0 downstream ports (port marked with supports BC 1.2 and iOS device charging at 2.4A max)
• 1 x USB-C port (USB 3.0)
• Gigabit Ethernet
• Audio In/Out ports (3.5mm headset connector)
• Security lock slot
• USB 3.0 cable
• DC Power In: 19.5V, 6.15A
• DC Power Out: 19.5V 90W max
ACER 3A, 3P
3P
3P, 3W
3H, 3P, 3W
3P
3A, 3P
3H2, 3P, 3W
3I2, 3P, 3X9
3P
LAPTOP BRAND POWER TIP(S) LAPTOP BRAND POWER TIP(S)
ASUS
COMPAQ
DELL
FUJITSU
GATEWAY
HP
IBM/LENOVO
TOSHIBA
3A
ACER 3A, 3P
3P
3P, 3W
3H, 3P, 3W
3P
LAPTOP BRAND POWER TIP(S)
ASUS
COMPAQ
DELL
FUJITSU
1.Locate the correct power tip
(test fit in laptop if needed)
2. Connect to the power cord 3. Connect to your laptop

Docking Station Diagram
Windows Setup
To ensure the best Windows performance, please be sure to
update your host PC Display Adaptor and USB 3.0 Drivers.
These updates are often available from your IT department or
from the PC manufacturer if you have Administrator rights to
download and install drivers for your PC.
Welcome to your Targus Universal Docking Station DisplayLink
Manager. The DisplayLink Manager software, if not already
installed, can be downloaded from a Windows Update server or
from www.targus.com. It is represented by the icon in
the Windows Task Tray and allows you to easily connect
additional monitors to your laptop or desktop via the Targus
Docking Station. Using the Windows Control Panel Display
Screen Resolution window, the connected monitors can be
configured to either mirror your main screen, or extend the
Windows desktop allowing visibility of more applications at the
same time. The DisplayLink USB Graphics devices can also be
configured to be the main display.
The DisplayLink Manager allows full configuration of all
additional USB displays, including:
• Support for addition USB Displays in Windows 7, 8, 8.1, 10
and later
• Resolution up to 2560 X 1440 for HDMI and 2048 x 1152 for
DVI-I
• Display orientation and location modification
• Layout of displays
DisplayLink software also provides drivers for Sound and
Ethernet built-in. These can also be selected in the Windows
Control Panel.
OS-X Setup
Three Year Warranty
Regulatory Compliance
FCC Statement (Tested to Comply)
Upon installation of the DisplayLink software for OS-X
available at www.targus.com, Macbook users can use the
System Preferences for Displays to adjust the external
monitors. OS-X allows configuration of all additional USB
displays, including:
• Support for additional USB Displays in OS-X 10.9 or later
• Resolution up to 2560 X 1440 for HDMI and 2048 x 1152
for DVI-I
• Display orientation and location modification
• Layout of displays
DisplayLink software also provides drivers for Sound and
Ethernet built-in.
Android Setup
Install the DisplayLink Desktop application for Android 5.0
and later from the Google Play Store. Enable USB
Debugging/Host mode on your Android device.
1. Targus warrants to the original purchaser that its products
are free from defects in materials and workmanship for three
years. This warranty is limited to defects, materials and
workmanship. 2. The benefits to the consumer given by the
warranty are in addition to other rights and remedies of the
consumer under law in relation to the goods to which the
warranty relates. 3. The warranty is given by (i) Targus Australia,
(ii) Targus Australia’s business address is: Suite 2, Level 8, 5
Rider Boulevard, Rhodes NSW 2138 Australia, (iii) Targus
Australia’s telephone number is 1800 641 645, Email:
[email protected] (iv) To make a warranty claim for goods
purchased in New Zealand, the telephone number is: 0800
633 222, or the goods may be returned to the supplier in New
Zealand. 4. What the purchaser must do to entitle the
purchaser to claim warranty:- (i) The purchaser must call the
telephone number for Australia or New Zealand set out above,
(ii) The purchaser must provide the purchaser’s name, daytime
contact number, business hours delivery address, the Targus
model number on the product, date and place of purchase with
receipt for purchase if required, and describe the fault
condition. 5. What Targus must do:- (i) Targus will provide the
purchaser with store return information or a return authorisation
so that the purchaser may return the product for warranty
inspection, (ii) If after inspection Targus finds the product is
defective in materials or workmanship, Targus shall replace (or
repair) the defective product at the discretion of Targus and
ship the product from Targus warehouse at its expense within
three business days (Monday to Friday excluding public
holidays) of receiving the returned goods. If the product is no
longer available Targus reserves the right to replace with the
nearest corresponding product of no lesser quality, (iii) Targus
will bear the cost of return delivery to the purchaser regardless
of the inspection test result. The purchaser must bear the cost
of the delivery to Targus. There is no charge for inspection. 6.
Our goods come with guarantees that cannot be excluded
under the Australian Consumer Law. You are entitled to a
replacement or refund for a major failure and for compensation
for any other reasonable foreseeable loss or damage. You are
also entitled to have the goods repaired or replaced if the
goods fail to be of acceptable quality and the failure does not
amount to a major failure. 7. Please note: (i) Features and
specifications of all Targus products are subject to change
without notification, (ii) In some instances: Goods presented for
repair may be replaced by refurbished goods of the same type
rather than being repaired. Refurbished parts may be used to
repair the goods, (iii) If goods accepted for repair retain
user-generated data: During the process of repair some or all
of your stored data may be lost. Please ensure that you have
saved this data elsewhere prior to repair.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) This device
must accept any interference received, including interference
that may cause undesired operations.
System Requirements
Hardware
• USB Port (USB 3.0 recommended)
Operating System (any of the following)
• Microsoft Windows®7, Windows®8, Windows®8.1, or
Windows®10 (32/64-bit)
• Mac OS®X v10.8 or later
• Android 5.0 or later (*with Host Mode enabled, with support
limitations applies, refer to HYPERLINK
"http://www.displaylink.com" www.displaylink.com for details)
• Chromebooks (*selected device only, refer to HYPERLINK
"http://www.displaylink.com" www.displaylink.com for device
compatibility)
• Ubuntu 14.04.x LTS and 16.04 LTS on x86 platform (*refer to
HYPERLINK "http://www.displaylink.com"
www.displaylink.com for compatibility and limitations)
This equipment has been tested and found to comply with the
limits of a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate
radio frequency energy and if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different
from the one that the receiver is connected
• Consult the dealer or an experienced radio/TV technician for
help
Changes or modifications not authorized by the party
responsible for compliance could void the user’s authority to
operate this product.
US Technical Support
• www.targus.com/support • www.targusblog.com
• 877-482-7487
Visit www.targus.com for a list of the latest compatible operating systems
Power On / Off USB 3.0
USB to Laptop Port
Gigabit
Ethernet
DVI HDMI
Lock Slot
Audio
Headset Connector
USB-C Port USB 3.0 Port
(supports charging)
DC Power In
DC Power Out
