TASKING iSYSTEM IC50130 User manual

Legacy Debug Adapters
User Manual
V1.5, August 2023
isystem.com/start

General safety instructions
Please read the following safety precautions carefully before putting this device to use to avoid
any personal injuries, damage to the instrument, or to the target system. Use this instrument
only for its intended purpose as specified by this manual to prevent potential hazards.
Use included power cord and power supply
The enclosed power supply has been approved for use by iSYSTEM. Please contact iSYSTEM if
you need to consider an alternative power.
Use grounding wire
Prior to applying power to either the BlueBox or the target, connect the device and the target
system together with the included grounding wire. This is to avoid potential damage caused by
any voltage difference between the device and the target system.
Use proper overvoltage protection
Ensure proper protection to avoid exposing the BlueBox device or the operator to overvoltage
surges (e.g. caused by thunderstorm, mains power).
Do not operate without cover
Do not operate the device with cover removed.
Avoid circuit and wire exposure
Do not touch exposed components or wires when the device is powered.
Do not operate with suspected damage
If you suspect damage may have occurred, the BlueBox device must be inspected by qualified
service personnel before further operation.
Do not operate the device outside its rated supply voltage or environmental range
Consult with iSYSTEM before using equipment outside of the parameters provided in this
manual.
This symbol is used within the manual to highlight further safety notices.

Contents
Legacy Debug Adapters ................................................................................................................. 4
26-pin 2.54 mm NXP ColdFire Debug Adapter .................................................................................. 5
6-pin 2.54mm NXP BDM Debug Adapter ........................................................................................... 7
6-pin 2.54mm NXP S12Z BDM Debug Adapter ................................................................................. 8
16-pin 2.54mm NXP COP Debug Adapter .......................................................................................... 9
38-pin Mictor PPC4xx RISCTrace Debug Adapter .......................................................................... 10
16-pin 2.54mm Renesas 78K0R Debug Adapter ........................................................................... 12
26-pin KEL Renesas V850 Debug Adapter ...................................................................................... 14
20-pin 2.54mm Renesas V850 Debug Adapter .............................................................................. 15
10-pin 2.54mm Renesas 78K0 Debug Adapter .............................................................................. 16
78K0 16-pin 2.54mm Converter ............................................................................................................................................................................ 17
4-pin ERNI ST STM8 Debug Adapter ................................................................................................. 18

Legacy Debug Adapters
This document provides detailed information on the debug adapters (used in conjunction with
the iC5000 or the iC5700) supporting legacy microcontroller architectures which are no longer
supported with winIDEA 9.17.0 or newer.
Listed Debug Adapters and belonging microcontroller architectures are supported with
winIDEA 9.12.288 or older.
Ordering Code
Description
IC50130
26-pin 2.54 mm NXP ColdFire
IC50140
6-pin 2.54mm NXP BDM
IC50141
6-pin 2.54mm NXP S12Z BDM
IC50153
16-pin 2.54mm NXP COP
IC50155
38-pin Mictor PPC4xx RISCTrace
IC50170
16-pin 2.54mm Renesas 78K0R
IC50171
20-pin 2.54mm Renesas V850 Debug Adapter
IC50172
26-pin KEL Renesas V850
IC50174
10-pin 2.54mm Renesas 78K0
IC50190
4-pin ERNI ST STM8
More information about our products on www.isystem.com or via [e-mail].
This symbol is used within the manual to highlight further safety notices.

26-pin 2.54 mm NXP ColdFire Debug Adapter
Ordering code
IC50130
This debug adapter is used to connect the iC5000 BlueBox to NXP ColdFire based target
featuring a 26-pin 2.54 mm pitch target debug connector with the ColdFire pinout.
This debug adapter is supported by the iC5000 BlueBox only.
The debug adapter connects to the 25cm 40-pin ribbon cable coming from the BlueBox and to
the target debug connector on the other side. Refer to the BlueBox User Manual for more details
on connecting the debug adapter.
The following pinout is valid on the target side:
Signal direction
Signal
Pin
Pin
Signal
Signal direction
I
Developer Reserved
1
2
~BKPT
O
GND
3
4
DSCLK
O
GND
5
6
Developer Reserved
RESET
7
8
DSI
O
I
VDD_IO
9
10
DSO
I
GND
11
12
PSTDDATA7
I
I
PSTDDATA6
13
14
PSTDDATA5
I
I
PSTDDATA4
15
16
PSTDDATA3
I
I
PSTDDATA2
17
18
PSTDDATA1
I
I
PSTDDATA0
19
20
GND
Motorola Reserved
21
22
Motorola Reserved
GND
23
24
PSTCLK
I
I
NC
25
26
~TEA
O
26-pin ColdFire target pinout
Blue colored signals are trace signals.
Signal Direction is described from the BlueBox perspective.
When connecting the BlueBox to a target for the first time, double check that the debug
adapter pinout matches the Target connector. A mismatch can result in a hardware
failure.
26-pin 2.54 mm NXP ColdFire Debug Adapter features resettable fuses on pins 2, 4, 7, 8, 9, 10,
24 and 26. These protect debug signals against overcurrent and cycle back to a conductive

state after the excessive current fades away. Signals on pins 1, 12-19 and 24 are protected via
47 ohm serial resistors.
The debug adapter connects to the target via a 26-pin 2.54 mm connector, for example
Yamaichi FAS-26-17. A target should feature a matching part, for example WÜRTH ELEKTRONIK
61202621621.

6-pin 2.54mm NXP BDM Debug Adapter
Ordering code
IC50140
This debug adapter is used to connect the iC5000 and the iC5700 BlueBox to NXP HCS08,
HC12, HCS12, S12X and ColdFire V1 based target featuring 6-pin 2.54mm pitch target debug
connector with the BDM pinout.
The debug adapter connects to the 25cm 40-pin ribbon cable coming from the BlueBox and to
the target debug connector on the other side. Refer to the BlueBox User Manual for more details
on connecting the debug adapter.
The following pinout is valid on the target side:
Signal direction
Signal
Pin
Pin
Signal
Signal direction
I/O
BGND
1
2
GND
NC
3
4
RESET
I/O
NC
5
6
VTref
I
6-pin BDM pinout
Signal Direction is described from the BlueBox perspective.
When connecting the BlueBox to a target for the first time, double check that the debug
adapter pinout matches the Target connector. A mismatch can result in a hardware
failure.
6-pin 2.54mm NXP BDM Debug Adapter features resettable fuses on pins 1, 2, 4 and 6. These
fuses protect debug signals against overcurrent and cycle back to a conductive state after the
excessive current fades away.
The debug adapter connects to the target via a 6-pin 2.54 mm connector, for example FCI
71600-006LF. A target should feature a matching part, for example WÜRTH ELEKTRONIK
61200621621.

6-pin 2.54mm NXP S12Z BDM Debug Adapter
Ordering code
IC50141
This debug adapter is used to connect the iC5000 and the iC5700 BlueBox to NXP S12Z based
target featuring 6-pin 2.54mm pitch target debug connector with the S12Z BDM pinout.
The debug adapter connects to the 25cm 40-pin ribbon cable coming from the BlueBox and to
the target debug connector on the other side. Refer to the BlueBox User Manual for more details
on connecting the debug adapter.
The following pinout is valid on the target side:
Signal direction
Signal
Pin
Pin
Signal
Signal direction
I/O
BGND
1
2
GND
I
PDO
3
4
RESET
I/O
I
PDOCLK
5
6
VTref
I
6-pin S12Z BDM pinout
Signal Direction is described from the BlueBox perspective.
When connecting the BlueBox to a target for the first time, double check that the debug
adapter pinout matches the Target connector. A mismatch can result in a hardware
failure.

16-pin 2.54mm NXP COP Debug Adapter
Ordering code
IC50153
This debug adapter is used to connect the iC5000 BlueBox to NXP MPC6xx, MPC82xx,
MobileGT, MPC7xx or MPC83xx based target featuring 16-pin 2.54mm pitch target debug
connector with NXP COP pinout
This debug adapter is supported by the iC5000 BlueBox only.
The debug adapter connects to the 25cm 40-pin ribbon cable coming from the BlueBox and to
the target debug connector on the other side. Refer to the BlueBox User Manual for more details
on connecting the debug adapter.
The following pinout is valid on the target side:
Signal direction
Signal
Pin
Pin
Signal
Signal direction
I
TDO
1
2
QACK#
O
O
TDI
3
4
TRST
O
I
HALTED
5
6
VTref
I
O
TCK
7
8
CKSTP_IN
O
O
TMS
9
10
NC
O
SRESET
11
12
GND
O
HRESET
13
14
NC
I
CKSTP_OUT
15
16
GND
16-pin COP target pinout
Signal Direction is described from the BlueBox perspective.
When connecting the BlueBox to a target for the first time, double check that the debug
adapter pinout matches the Target connector. A mismatch can result in a hardware
failure.
16-pin 2.54mm NXP COP Debug Adapter features resettable fuses on all pins except for the pin
15. These protect debug signals against overcurrent and cycle back to a conductive state after
the excessive current fades away. The signal on the pin 15 is protected via 100 ohm serial
resistor.
The debug adapter connects to the target via a 16-pin 2.54 mm connector, for example
Yamaichi FAS-1601-2101-2-OBF. A target should feature a matching part, for example WÜRTH
ELEKTRONIK 61201621621.

38-pin Mictor PPC4xx RISCTrace Debug Adapter
Ordering code
IC50155
This debug adapter is used to connect the iC5000 BlueBox to Applied Micro PPC4xx based
target featuring a 38-pin Mictor target debug connector with the PPC4xx RISCTrace pinout.
This debug adapter is supported by the iC5000 BlueBox only.
The debug adapter connects to the BlueBox through the two ribbon cables and to the target
debug connector on the other side. Refer to the BlueBox User Manual for more details on
connecting the debug adapter.
The following pinout is valid on the target side:
Signal direction
Signal
Pin
Pin
Signal
Signal direction
NC
1
2
NC
NC
3
4
NC
GND
5
6
TRCLK
I
O
HALT
7
8
NC
O
SRST
9
10
NC
I
TDO
11
12
VREF
I
NC
13
14
NC
O
TCK
15
16
NC
O
TMS
17
18
NC
O
TDI
19
20
NC
O
NTRST
21
22
NC
NC
23
24
NC
I
BS0
25
26
TS0
I
I
BS1
27
28
TS1
I
I
BS2
29
30
TS2
I
I
BS3
31
32
TS3
I
I
BS4
33
34
TS4
I
I
BS5
35
36
TS5
I
I
BS6
37
38
TS6
I
PPC4xx RISCTrace target pinout
Blue colored signals are trace signals.
Signal Direction is described from the BlueBox perspective.
When connecting the BlueBox to a target for the first time, double check that the debug
adapter pinout matches the Target connector. A mismatch can result in a hardware

failure.
38-pin Mictor PPC4xx RISCTrace Debug Adapter features resettable fuses on pins 7, 9, 11, 12, 15,
17, 19 and 21. These protect debug signals against overcurrent and cycle back to a conductive
state after the excessive current fades away. Signals on pins 6, 25, 26, 27, 28, 29, 30, 31, 32, 33,
34, 35, 36, 37 and 38 are protected via 47 ohm serial resistors.
The debug adapter connects to the target via a 38-pin Mictor connector Tyco Electronics
5767055-1. A target should feature a matching part, for example Tyco Electronics 5767081-1 in
the SMT technology.

16-pin 2.54mm Renesas 78K0R Debug Adapter
Ordering code
IC50170
This debug adapter is used to connect the iC5000 and the iC5700 BlueBox to Renesas 78K0R
based target featuring 16-pin 2.54mm pitch target debug connector with the 78K0R pinout.
The debug adapter connects to the 25cm 40-pin ribbon cable coming from the BlueBox and to
the target debug connector on the other side. Refer to the BlueBox User Manual for more details
on connecting the debug adapter.
The following pinout is valid on the target side:
Signal direction
Signal
Pin
Pin
Signal
Signal direction
GND
1
2
RESET OUT
O
I/O
TOOL0 (RxD/TxD)
3
4
Vcc
I/O
I/O
TOOL0 (RxD/TxD)
5
6
NC
NC
7
8
NC
NC
9
10
NC
NC
11
12
NC
NC
13
14
FLMD0
O
I
RESET IN
15
16
TOOL1 (CLK)
I
16-pin 78K0R target pinout
Signal Direction is described from the BlueBox perspective.
When connecting the BlueBox to a target for the first time, double check that the debug
adapter pinout matches the Target connector. A mismatch can result in a hardware
failure.
If the ‘Supply 5V to the target’ option is checked in the ‘Hardware/Emulation Options/CPU
Setup/Advanced’ tab, the debugger supplies 5V at the ‘Vcc’ pin (pin 4) on the target debug
connector, which can be used to power the target. Maximum target current consumption should
not exceed 50mA.
If ‘RESET IN’ (target reset detection) from the microcontroller is not connected to the target
debug connector pin 15, 10k ohm pull-up must be connected to this pin or the debugger may
exhibit unpredictable behavior.
16-pin 2.54mm Renesas 78K0R Debug Adapter features resettable fuses on all connected pins.
These protect debug signals against overcurrent and cycle back to a conductive state after the
excessive current fades away.

The debug adapter connects to the target via a 16-pin 2.54 mm connector, for example
Yamaichi FAS-1601-2101-2-OBF. A target should feature a matching part, for example WÜRTH
ELEKTRONIK 61201621621.

26-pin KEL Renesas V850 Debug Adapter
Ordering code
IC50172
This debug adapter is used to connect the iC5000 and the iC5700 BlueBox to Renesas V850
based target featuring 26-pin KEL target debug connector with the V850 pinout.
The debug adapter connects to the 25cm 40-pin ribbon cable coming from the BlueBox and to
the target debug connector on the other side. Refer to the BlueBox User Manual for more details
on connecting the debug adapter.
The following pinout is valid on the target side:
Signal direction
Signal
Pin
Pin
Signal
Signal direction
Ground
1
2
Reserved
Ground
3
4
Reserved
Ground
5
6
Reserved
Ground
7
8
Reserved
Ground
9
10
Reserved
Ground
11
12
Reserved
Ground
13
14
DDI
O
Ground
15
16
DCK
O
Ground
17
18
DMS
O
Ground
19
20
DDO
I
Reserved
21
22
DRST
O
Reserved
23
24
RESET
O
I
Reference Voltage
25
26
FLMD0
O
26-pin V850 target pinout
Signal Direction is described from the BlueBox perspective.
When connecting the BlueBox to a target for the first time, double check that the debug
adapter pinout matches the Target connector. A mismatch can result in a hardware
failure.
26-pin KEL Renesas V850 Debug Adapter features resettable fuses on all connected signals.
These fuses protect debug signals against overcurrent and cycle back to a conductive state
after the excessive current fades away.
The debug adapter connects to the target via a 26-pin KEL connector, part number 8825E-026-
175. A target should feature a matching part, for example KEL connector, part number 8830E-
026-170S. For more details see the 8825E Series at http://www.kel.jp/.

20-pin 2.54mm Renesas V850 Debug Adapter
Ordering code
IC50171
This debug adapter is used to connect the iC5000 and the iC5700 BlueBox to Renesas (former
NEC) V850 based target featuring a 20-pin 2.54 mm pitch target debug connector with the
V850 pinout.
The debug adapter connects to the 25 cm 40-pin ribbon cable coming from the BlueBox and to
the target debug connector on the other side.
The following pinout is valid on the target side:
Signal
Direction
Signal
Description
Signal
Pin
Pin
Signal
Signal
Description
Signal
Direction
Ground
GND
1
2
TCK
JTAG
O
Ground
GND
3
4
TMS
JTAG
O
Ground
GND
5
6
TDI
JTAG
O
Ground
GND
7
8
nTRST
JTAG
O
Ground
GND
9
10
NC
Not Connected
Ground
GND
11
12
nRESET
CPU Reset
I/O
Ground
GND
13
14
FLMD0
Flash Mode
O
Ground
GND
15
16
nRDY
Synchronizatio
n
I
Ground
GND
17
18
TDO
JTAG
I
Ground
GND
19
20
Vref
Reference
Voltage
I
20-pin V850 target pinout
Signal Direction is described from the BlueBox perspective.
When connecting the BlueBox to a target for the first time, double check that the debug
adapter pinout matches the Target connector. A mismatch can result in a hardware
failure.
20-pin 2.54mm V850 Debug Adapter features resettable fuses on all pins except for pin 16.
These fuses protect debug signals against overcurrent and cycle back to a conductive state
after the excessive current fades away. A signal on pin 16 is protected via 100 ohm serial
resistor.
The debug adapter connects to the target via a 20-pin 2.54 mm adapter, Yamaichi FAS-2001-
2101-2-OBF. A target should feature a matching part, for example WÜRTH ELEKTRONIK
61202021621.

10-pin 2.54mm Renesas 78K0 Debug Adapter
Ordering code
IC50174
This debug adapter is used to connect the iC5000 and the iC5700 BlueBox to Renesas 78K0
based target featuring 10-pin 2.54mm pitch target debug connector with the 78K0 pinout.
The debug adapter connects to the 25cm 40-pin ribbon cable coming from the BlueBox and to
the target debug connector on the other side. Refer to the BlueBox User Manual for more details
on connecting the debug adapter.
The following pinout is valid on the target side:
Signal direction
Signal
Pin
Pin
Signal
Signal direction
I
RESET IN
1
2
RESET OUT
O
O
FLMD0
3
4
TARVCC
I
I/O
X2
5
6
GND
O
X1
7
8
GND
I
NC
9
10
5V OUT
O
10-pin 78K0 target pinout
Signal Direction is described from the BlueBox perspective.
When connecting the BlueBox to a target for the first time, double check that the debug
adapter pinout matches the Target connector. A mismatch can result in a hardware
failure.
If the ‘Supply 5V to the target’ option is checked in the ‘Hardware/Emulation Options/CPU
Setup/Advanced’ tab, the debugger supplies 5V at the ‘5V OUT’ pin (pin 10) on the target debug
connector, which can be used to power the target. Maximum target current consumption should
not exceed 50mA.
If ‘RESET IN’ (target reset detection) from the microcontroller is not connected to the target
debug connector pin 1, 10k ohm pull-up must be connected to this pin or the debugger may
exhibit unpredictable behavior.
10-pin 2.54mm Renesas 78K0R Debug Adapter features resettable fuses on all connected pins.
These protect debug signals against overcurrent and cycle back to a conductive state after the
excessive current fades away.
The debug adapter connects to the target via a 10-pin 2.54 mm connector, for example
Yamaichi FAS-1001-2101-2-OBF. A target should feature a matching part, for example WÜRTH
ELEKTRONIK 61201021621.

78K0 16-pin 2.54mm Converter
Ordering code
IAPIN10PIN16NEC78K
Embedded targets based on Renesas 78K0 microcontroller can also feature a 16-pin 2.54mm
target debug connector with the Renesas 78K0 pinout.
A converter connecting at the end of the 10-pin 2.54mm Renesas 78K0 Debug Adapter is
available for Renesas 78K0 16-pin pinout and must be ordered separately. Toward the BlueBox
the adapter features 10-pin 2.54 mm male connector featuring the 10-pin 78K0 pinout.
The following pinout is valid on the target side:
Signal direction
Signal
Pin
Pin
Signal
Signal direction
GND
1
2
RESET OUT
O
NC
3
4
TARVCC
I
NC
5
6
NC
NC
7
8
NC
O
X1
9
10
NC
NC
11
12
NC
I/O
X2
13
14
FLMD0
O
I
RESET IN
15
16
NC
16-pin 78K0 target pinout
Signal Direction is described from the BlueBox perspective.
The adapter connects to the target via a 16-pin 2.54 mm connector, for example Yamaichi FAS-
1601-2101-2-OBF. A target should feature a matching part, for example WÜRTH ELEKTRONIK
61201621621.

4-pin ERNI ST STM8 Debug Adapter
Ordering code
IC50190
This debug adapter is used to connect the iC5000 and the iC5700 BlueBox to ST STM8 based
target featuring 4-pin ERNI target debug connector with the STM8 pinout.
The debug adapter connects to the 25cm 40-pin ribbon cable coming from the BlueBox and to
the target debug connector on the other side. Refer to the BlueBox User Manual for more details
on connecting the debug adapter.
The following pinout is valid on the target side:
Pin
Signal
Signal direction
1
VDD
I
2
SWIO
I/O
3
GND
4
RST
O
4-pin ERNI ST STM8 target pinout
Signal Direction is described from the BlueBox perspective.
When connecting the BlueBox to a target for the first time, double check that the debug
adapter pinout matches the Target connector. A mismatch can result in a hardware
failure.
4-pin ERNI ST STM8 Debug Adapter features resettable fuses on all pins. These fuses protect
debug signals against overcurrent and cycle back to a conductive state after the excessive
current fades away.
The debug adapter connects to the target via the ERNI MiniBridge 4-pin connector female (P/N
839033). A target should feature a matching part, for example ERNI MiniBridge 4-pin connector
right angle male (P/N 214012) or ERNI MiniBridge 4-pin connector vertical male (P/N 284697).

www.isystem.com
Visit our website for:
· Support - isystem.com/support
· Tutorials - isystem.com/getting-started
· Knowledge Base - kb.isystem.com
