Taurus TF-KL120 User manual

TFKL120.01.01
Professional chin-up module
TF
Operating Instructions
1 GENERAL SAFETY INSTRUCTIONS
1.1 Personal Safety
⚠DANGER
+ Before you start using the equipment, you should consult your
physician that this type of exercise is suitable for you from a health
perspective. Particularly aected are persons who: have a hereditary
disposition to high blood pressure or heart disease, are over the age
of 45, smoke, have high cholesterol values, are overweight and/or
have not exercised regularly in the past year. If you are under medical
treatment that aects your heart rate, medical advice is absolutely
essential.
+ Note that excessive training can seriously endanger your health. Please
also note that heart rate monitoring systems can be inaccurate. If you
notice any signs of weakness, nausea, dizziness, pain, shortness of
breath, or other abnormal symptoms, stop exercising immediately and
seek advice from your doctor if necessary.
⚠WARNING
+ This equipment may not be used by children under the age of 14.
+ Children should not be allowed unsupervised access to the equipment.
+ People with disabilities must have a medical license and must be
under strict observation when using the equipment.
+ The equipment is strictly for use by one person at a time
+ Keep your hands, feet and other body parts, hair, clothing, jewellery
and other objects well clear of moving parts.
⚠CAUTION
+ Make sure that nobody is within the range of motion of the equipment
during training so as not to endanger you or other persons.
࣑ATTENTION
+ Do not insert any objects of any kind into the openings of the device.
+ Do not wear jewellery like rings while using the punching ball.
1.2 Set-Up Place
⚠WARNING
+ Do not place the equipment in main corridors or escape routes.
+ To prevent re, do not place the device near or in areas with high heat
(e.g. near a heater).
⚠CAUTION
+ Choose the set-up place so that there is sucient space around the
product. Please note that the product requires sucient space to the
rear when in the reclined position.
࣑ATTENTION
+ The device may only be used in one building, in suciently tempered
and dry rooms (ambient temperatures between 10°C and 35°C).
The equipment should not be used outdoors or in rooms with high
humidity (over 70%) like swimming pools
+ To avoid fading or faster wear of the cover, do not place the product in
places with direct sunlight and/or high heat.
2 TECHNICAL DATA
Max. user weight: 120 kg
Article weight (incl. packaging): 12 kg
Article weight (without packaging): 11 kg
Set-up dimensions (LxWxH): 45 cm x 120 cm x 60 cm
Packaging dimensions (LxWxH) approx.: 123 cm x 54 cm x 7 cm
Art. No. TF-KL120
1 MAIN SUPPORT 2
2 ARCHED BAR 1
3-1 EXPANSION SCREW M8x75 8
3-2 WASHER 8 8
3-3 SPRING WASHER 8 8
3-4 LOCK N UT M8 8
4 SET SCREW M10×10 4
3 ASSEMBLY
࣑ATTENTION
The supplied assembly material for wall mounting is not suitable for
every wall. Pay attention to the condition of your wall to determine
which assembly material is suitable for your wall.
The contractual partner accepts no liability for any damage to the wall.
Make sure that there are no cables or wires running in the wall where
you attach the training equipment.
LNOTICE
The supplied assembly material is not suitable for every wall, so you
may need to get assembly material that is suitable for your wall.
Assemble the training equipment on the wall with eight expansion screws
(3-1), eight washers (3-2), eight spring washers (3-3) and eight lock nuts
(3-4).
4 PARTS LIST
5 CARE, MAINTENANCE AND STORAGE
⚠WARNING
The storage location should be chosen so that improper use by third
parties or children can be prevented.
1. Clean the device with a dry soft cloth.
2. Store the device in the supplied carton in a dry environment.
6 WARRANTY INFORMATION
Training equipment from Taurus® is subject to strict quality control.
However, if a tness equipment purchased from us does not work
perfectly, we take it very seriously and ask you to contact our customer
service as indicated. We are happy to help you by phone via our service
hotline.
Warranty period
The warranty periods, shown on our web shop, begin on delivery
of the tness equipment. The respective warranty periods for your
equipment can be found on its product website.
Please refer to the website of your Taurus® device for the exact warranty
conditions.
Contact
DE
Technical Support
📞+49 4621 4210-900
📧[email protected]
Service
📞0800 20 20 277
(freecall)
📧[email protected]
UK
Technical Support
📞+44 141 876 3986
📧support@powerhousetness.co.uk
Service
📞+44 141 876 3972
FR
Technical Support & Service
📞+33 (0) 172 770033
+49 4621 4210-933
📧service-france@tshop.fr
DK
Technical Support & Service
📞80 90 16 50
+49 4621 4210-945
📧info@tshop.dk
INT
Technical Support & Service
📞+49 4621 4210-944
📧service[email protected]
BE
Technical Support & Service
📞02 732 46 77
+49 4621 42 10-932
📧info@tshop.be
NL
Technical Support & Service
📞+31 172 619961
📧info@tshop.nl
AT
Technical Support & Service
📞0800 20 20 277
(freecall)
+49 4621 42 10-0
📧[email protected]
CH
Technical Support & Service
📞0800 202 027
+49 4621 42 10-0
📧[email protected]
PL
Technical Support & Service
📞22 307 43 21
+49 4621 42 10-948
📧info@tshop.pl
No. Name Qty.
