Taurus TF-ADB-80 User manual

TF
TFADB80.01.03
CM
max. 180 kg
~ 90 Min.
54,1 kg
L 22,5 | W 22,5 | H 32
Taurus SelectaBell Barbell
TF-ADB-80
Assembly and Operating Instructions

SelectaBell Barbell
2

SelectaBell Barbell
3
Content
1 GENERAL INFORMATION 6
1.1 Technical Data 6
1.2 Personal Safety 7
1.3 Set-Up Place 8
2 ASSEMBLY 9
2.1 General Instructions 9
2.2 Scope of Delivery 9
2.3 Assembly 10
3 OPERATING INSTRUCTIONS 12
4 STORAGE AND TRANSPORT 13
4.1 General Instructions 13
5 TROUBLESHOOTING, CARE AND MAINTENANCE 13
5.1 General Instructions 13
5.2 Faults and Fault Diagnosis 13
5.3 Maintenance and Inspection Calendar 16
6 DISPOSAL 16
7 RECOMMENDED ACCESSORIES 17
8 ORDERING SPARE PARTS 18
8.1 Serial Number and Model Name 18
8.2 Parts List 19
8.3 Exploded Drawing 19
9 WARRANTY 20
10 CONTACT 22

SelectaBell Barbell
4
Dear customer,
Thank you for choosing a high-quality equipment of the brand Taurus®. Taurus® oers sports and
tness equipment for the sophisticated home sport and the equipment of tness studios and
business customers.WithTaurus® tness equipment, the focus is on what sport is all about: maximum
performance! Therefore, the equipment is developed in close consultation with athletes and sports
scientists. Because athletes know best what makes perfect tness equipment.
Further information can be found at www.sport-tiedje.com.
Legal Notice
Sport-Tiedje GmbH
Europe’s No. 1 for home tness
International Headquarters
Flensburger Straße 55
24837 Schleswig
Germany
Management:
Christian Grau
Sebastian Campmann
Dr. Bernhard Schenkel
No. HRB 1000 SL
Local Court Flensburg
European VAT Number: DE813211547
Disclaimer
©2010 Taurus® is a registered brand of the company SportTiedje GmbH. All rights
reserved. Any use of this trademark without the explicit written permission of Sport-
Tiedje is prohibited.
Product and manual are subject to change. Technical data can be changed without
advance notice.
Intended Use
The equipment may only be used for its intended purpose.
The equipment is suitable for home use and semi-professional use (e.g. hospitals, clubs, hotels,
schools, etc.). The equipment is not suitable for commercial or professional use (e.g. tness
studio).

SelectaBell Barbell
5
ABOUT THIS MANUAL
Please carefully read the entire manual before installation and rst use. The manual will help you to
quickly set up the system and explains how to safely use it. Make sure that all persons exercising with
the equipment (especially children and persons with physical, sensory, mental or motor disabilities)
are informed about this manual and its contents in advance. In case of doubt, responsible persons
must supervise the use of the equipment.
This equipment has been manufactured according to the latest safety knowledge.
As far as possible, potential safety hazards which could cause injury have been
eliminated. Make sure to carefully follow the instructions and that all parts are
securely in place. If required, read through the instructions again to correct any
mistakes.
Please pay close attention to the safety and maintenance instructions given here. The contract
partner cannot be held liable for damage to health, accidents or damage to the equipment when it
is not used in accordance with these instructions.
The following safety instructions may appear in this manual:
࣑ATTENTION
This notice indicates potentially hazardous situations which, if not avoided, may result in
property damage.
⚠CAUTION
This notice indicates potentially hazardous situations which, if not avoided, may result in slight
or minor injuries!
⚠WARNING
This notice indicates potentially hazardous situations which, if not avoided, may result in death
or serious injuries!
⚠DANGER
This notice indicates potentially hazardous situations which, if not avoided, will result in death
or serious injuries!
LNOTICE
This notice indicates further useful information.
Retain these instructions in a safe place for future reference, maintenance or when ordering
replacement parts.

SelectaBell Barbell
6
1 GENERAL INFORMATION
1.1 Technical Data
Packaging dimensions (L x W x H): approx. Box 1: 22.5 cm x 22.5 cm x 32 cm
Box 2: 133 cm x 44 cm x 26.5 cm
Set-up dimensions (L x W x H): approx. 130.1 cm x 42.8 cm x 74.8 cm
Article weight (gross, incl. packaging): Box 1: 28.2 kg
Box 2: 31.2 kg
Article weight (net, excl. packaging): 54.1 kg

SelectaBell Barbell
7
1.2 Personal Safety
⚠DANGER
+ Before you start using the equipment, you should consult your physician that this type of
exercise is suitable for you from a health perspective. Particularly aected are persons who:
have a hereditary disposition to high blood pressure or heart disease, are over the age of 45,
smoke, have high cholesterol values, are overweight and/or have not exercised regularly in
the past year. If you are under medical treatment that aects your heart rate, medical advice
is absolutely essential.
+ Note that excessive training can seriously endanger your health. Please also note that
heart rate monitoring systems can be inaccurate. If you notice any signs of weakness,
nausea, dizziness, pain, shortness of breath, or other abnormal symptoms, stop exercising
immediately and seek advice from your doctor if necessary.
⚠WARNING
+ This equipment may not be used by children under the age of 14.
+ Children should not be allowed unsupervised access to the equipment.
+ Persons with disabilities must have a medical license and must be under strict observation
when using the equipment.
+ The equipment is strictly for use by one person at a time.
+ If your equipment provides a safety key, the clip of the safety key must be attached to your
clothing before starting your training. In the event of a fall, the EMERGENCY STOP of the
equipment can be initiated.
+ Keep your hands, feet and other body parts, hair, clothing, jewellery and other objects well
clear of moving parts.
+ During use, wear suitable sports clothing rather than loose or baggy clothing.When wearing
sports shoes, make sure they have suitable soles, preferably made of rubber or other non-
slip materials. Shoes with heels, leather soles, studs or spikes are unsuitable. Never exercise
barefoot.
⚠CAUTION
+ If your equipment needs to be connected to the power supply with a mains cable, make
sure that the cable is not a potential tripping hazard.
+ Make sure that nobody is within the range of motion of the equipment during training so as
not to endanger you or other persons.
࣑ATTENTION
+ Do not insert any objects of any kind into the openings of the device.

SelectaBell Barbell
8
1.3 Set-Up Place
⚠WARNING
+ Do not place the equipment in main corridors or escape routes.
⚠CAUTION
+ The training room should be well ventilated during training and not be exposed to any
draughts.
+ Choose the place in which to set up the equipment such that there is enough free space/
clearance to the front, the rear and to the sides of the equipment.
+ The set-up and mounting surface of the equipment should be at, loadable and solid.
࣑ATTENTION
+ The device may only be used in one building, in suciently tempered and dry rooms
(ambient temperatures between 10°C and 35°C). The equipment should not be used
outdoors or in rooms with high humidity (over 70%) like swimming pools.
+ A oor protective mat/equipment underlay can help to protect high-quality oor coverings
(parquet, laminate, cork, carpets) from dents and sweat and can help to level out slight
unevenness.

SelectaBell Barbell
9
2 ASSEMBLY
2.1 General Instructions
⚠DANGER
+ Do not leave any tools, packaging materials such as foils or small parts lying around,
as otherwise there is a danger of suocation for children. Keep children away from the
equipment during assembly.
⚠WARNING
+ Pay attention to the instructions attached to the equipment in order to reduce the risk of
injuries.
⚠CAUTION
+ Do not open the packaging when it is lying on its side.
+ Ensure to have sucient room for movement in each direction during assembly.
+ The assembly of the equipment must be carried out by at least two adults. If in doubt, seek
the help of a third technically skilled person.
࣑ATTENTION
+ To prevent damage to the equipment and the oor, assemble the equipment on a mat or
packaging board.
LNOTICE
+ In order to make the assembly as simple as possible, some screws and nuts to be used can
already be pre-assembled.
+ Ideally, assemble the equipment at its later set-up place.
2.2 Scope of Delivery
At the beginning, check whether all parts belonging to the device are included in the scope of
delivery and whether damage has occurred. In the event of complaints, the contractual partner must
be contacted directly.
⚠CAUTION
If parts of the scope of delivery are missing or damaged, the assembly must not be carried out.

SelectaBell Barbell
10
2.3 Assembly
Before assembly, take a close look at the individual assembly steps shown and carry out the assembly
in the order given.
LNOTICE
First loosely screw all parts together and check that they t properly. Tighten the screws using
the tool only when you are instructed to do so.
Step 1: Assembly of the base frame
1. Mount the legs (2) to the bottom cross
bar (3) with four screws (13) and four nuts
(14).
2. Tighten the screws and nuts (13 & 14).
Step 2: Assembly of the plate holders
LNOTICE
+ Make sure that the holders are
mounted in the correct direction.
+ The screws (10) for the plate holders
are pre-assembled.
1. Attach the holders (6) to the top cross
bar (1) with a total of four screws (10).
2. Tighten the screws (10).

SelectaBell Barbell
11
Step 3: Connecting the parts
1. Mount the top cross bar (1) to the
base frame with a total of four
screws (11) and four washers (12).
2. Tighten the screws (11).
Step 4: Inserting the weight plates
1. Place six weight plates (9) on each
side of the plate holders (4&5).
⚠CAUTION
Make sure that the weight plates (9)
are in exact position on the plate
holders(4&5).
Step 5: Placing the barbells
Insert the bar to be used into the
openings of the weight plates (9) and
hang the bar not to be used in the
holder (6) on the top cross bar(1).

SelectaBell Barbell
12
3 OPERATING INSTRUCTIONS
LNOTICE
Familiarise yourself with all the functions and setting options of the device before starting
training. Have the proper use of this product explained to you by a specialist.
The straight barbell (A1) weighs 20lbs/9 kg and the curled
barbell (A2) weighs 15lbs/6.8 kg. Each weight plate (B)
weighs 5lbs/2.3 kg.
To select the desired weight plates (B), rst align the barbell
so that the adjustment levers (C) are at the top and the bar
is lowered straight down to the stand. To select the desired
outer weight plates (B), lift the adjustment lever (C), slide it
until it is aligned with one of the outer weight plates, and
then lower it. Move the selector back and forth to make
sure it is aligned with one of the outer weight plates and
locked into place. Repeat this step on the other side.
LNOTICE
To ensure the longevity of your dumbbell and to
prevent damage, grease the adjustment mechanisms
at regular intervals.

SelectaBell Barbell
13
4 STORAGE AND TRANSPORT
4.1 General Instructions
⚠WARNING
+ The storage location should be chosen so that improper use by third parties or children can
be prevented.
+ If your equipment does not have transportation wheels, the equipment must be
disassembled before transportation.
࣑ATTENTION
+ Make sure that the equipment is protected from moisture, dust and dirt in the selected
storage location. The storage location should be dry and well ventilated and have a constant
ambient temperature between 5°C and 45°C.
5 TROUBLESHOOTING, CARE AND MAINTENANCE
5.1 General Instructions
⚠WARNING
+ Do not make any improper changes to the equipment.
⚠CAUTION
+ Damaged or worn components may aect your safety and the life of the equipment.
Therefore, immediately replace damaged or worn components. In such a case, contact the
contract partner. The equipment must not be used until it has been repaired. If necessary,
use only original spare parts.
࣑ATTENTION
+ In addition to the instructions and recommendations for maintenance and care given here,
additional service and/or repair work may be necessary; this must only be carried out by
authorised service technicians.
5.2 Faults and Fault Diagnosis
The equipment undergoes regular quality controls during production. Nevertheless, faults or
malfunctions may occur. Frequently, individual parts are responsible for these disturbances, an
exchange is usually sucient. Please refer to the following overview for the most common errors and
how to correct them. If the equipment still does not function properly, contact your contract partner.
Fault Cause Solution
Squeak and creaking
noises
Loose or too tight screw
connection Check or lubricate screw connection

1
2
3
4
5
6
7
SelectaBell Barbell
14
The weight plates are not aligned correctly
If the weight plates are not properly aligned, the dumbbell may not be adjusted smoothly.
1. Check if there are any foreign objects (dirt/small parts) in the holders.
2. Select the maximum weight of 80lbs and lift the barbell 3-5 times.
3. Move the adjustment lever quickly back and forth 3-5 times.
4. Select 80lbs, turn the barbell over and put it back on the holders.
5. Press the two outer plates together 3-5 times.
6. Rearrange the weight plates.
7. Lift up the barbell and put it back on the holders 3-5 times
quickly. Make sure that the barbell is touching the bottom
of the holders.
Extended adjustment lever
If the adjustment lever is pulled out of the barbell, loosen
the screw at the bottom of the handle, push the lever back
in and tighten the screw.

SelectaBell Barbell
15
Outwardly tilted or stuck weight plates/diculties in inserting the dumbbell into the weight
plates
If the plates are tilted outwards, stuck in the holder or you have diculty inserting the barbell into the
weight plates, the plate holders may need to be adjusted.
⚠CAUTION
Make sure that the weight plates are always secured.
1. Loosen the screws underneath the holder and push or pull
the holder in the appropriate direction so that the weight
plates are correctly positioned in the holder again.
2. Tighten the screws again.
Loosened weight plate
Please make sure that the barbell does not drop. If
the barbell is dropped accidentally, the adjustment
lever could jump inwards and cause some weight
plates to pop out.
Lift the barbell carefully, slide the released weight
plate o carefully (be careful if the plate falls) and
put the weight plate back on the holder.
If the barbell is dropped and the adjustment lever
jumps out, pull the lever up, set it back to the
heaviest weight (all weight plates are engaged) and
put it back on the holder.

SelectaBell Barbell
16
5.3 Maintenance and Inspection Calendar
To avoid damage from body sweat, the equipment must be cleaned with a damp towel (no solvents!)
after each training session.
The following routine tasks must be performed at the specied intervals:
Part Weekly Monthly Quarterly Half-yearly Yearly
Lubricating the
adjustment pin I
Screw connections I
Legend: C = clean; I = inspect
6 DISPOSAL
At the end of its operational life, this equipment cannot be disposed of in normal household waste.
Instead, it must be disposed of via an recycling centre. Further information can be obtained from
your local authority‘s recycling service.
The materials can be recycled as per their symbols. Through the reuse, recycling
of materials or other forms of recovery of old equipment, you make an important
contribution to the protection of the environment.
Additional weight plate
If you pull a weight plate up too much (a
higher weight than you have chosen), it
may be because the adjustment lever is not
in the right place.
Align the adjustment lever correctly and lift
and lower the barbell 3-5 times.

SelectaBell Barbell
17
7 RECOMMENDED ACCESSORIES
To make your training experience even more ecient and pleasant, we recommend that you add
suiting accessories to your tness equipment. This could be a oor mat, for example, which makes
your tness equipment stand more securely and also protects the oor from falling sweat, but it
could also be additional handrails on some treadmills or silicone spray to keep moving parts in good
shape.
If you have purchased a tness machine with pulse training and want to train your heart rate, we
strongly recommend that you use a compatible chest strap, as this ensures optimum transmission of
the heart rate. You may want to buy additional grips or weights for multi gyms.
Our range of accessories oers the highest quality and makes training even better. If you would like
to nd out more about compatible accessories, please go to the detail page of the product in our
webshop (the easiest way is to enter the article number in the search eld above) and go to the
recommended accessories on this page. Of course, you can also contact our customer service: by
telephone, e-mail, in one of our branches or via our social media channels. We will be happy to advise
you!
oor mat
chest strap
towels
silicone spray
chest strap contact gel


SelectaBell Barbell
18
8 ORDERING SPARE PARTS
8.1 Serial Number and Model Name
In order to provide you with the best possible service, please have the model name, article number,
serial number, exploded drawing and parts list ready. The corresponding contact options can be
found in chapter 10 of this operating manual.
LNOTICE
The serial number of your equipment is unique. It's
located on a white sticker. The exact position of this
sticker is shown in the following illustration.
Enter the serial number in the appropriate eld.
Serial number:
Brand / Category:
Taurus / Barbell
Model Name:
SelectaBell Barbell
Article Number:
TF-ADB-80

1 Top Cross Bar 1
2 Legs 2
3 Bottom Cross Bar 1
4 Plate Holder (Left) 1
5 Plate Holder (Right) 1
6 Barbell Holder 2
7 I bar 1
8 W Bar 1
9 Weight Plate 5LB 12
10 Screw M6x10mm 16
11 Screw M6x45mm 4
12 M6 Washer 4
13 Screw M6x80mm 4
14 M6 Nut 4
SelectaBell Barbell
19
8.2 Parts List
No. Name Qty. No. Name Qty.
8.3 Exploded Drawing

SelectaBell Barbell
20
9 WARRANTY
Training equipment from Taurus® is subject to strict quality control. However, if a tness equipment
purchased from us does not work perfectly, we take it very seriously and ask you to contact our
customer service as indicated. We are happy to help you by phone via our service hotline.
Error Descriptions
Your tness equipment is developed for long-term, high-quality training. However, should a problem
arise, please rst read the operating instructions. For further assistance, please contact your contract
partner or call our service hotline. To ensure your problem is solved as quickly as possible, please
describe the defect as exactly as possible.
In addition to the statutory warranty, we provide a warranty for every tness equipment purchased
from us according to the following provisions.
Your statutory rights are not aected.
Warrantee
The warrantee is the rst/original buyer and/or any person who received a newly purchased product
as a gift from the original buyer.
Warranty period
The warranty periods, shown on our web shop, begin on delivery of the tness equipment. The
respective warranty periods for your equipment can be found on its product website.
Repair Costs
According to our choice, there will either be a repair, a replacement of individual damaged parts or
a complete replacement. Spare parts, that have to be mounted while assembling the equipment,
have to be replaced by the warrantee personally and are not a part of repair. After the expiration of
the warranty period for repair costs, a pure parts warranty applies, which does not include the repair,
installation and delivery costs.
The terms of use are dened as follows:
+ Home use: solely for private use in private households up to 3 hours per day
+ Semi-professional use: up to 6 hours per day (e. g. rehabilitation centres, hotels, clubs,
company gyms)
+ Professional use: more than 6 hours per day (e. g. commercial gyms)
Warranty Service
Within the warranty period, equipment which develops faults as a result of material or manufacturing
defects, will be repaired or replaced at our discretion. Ownership of equipment or parts of equipment
which have been replaced is transferred to us. The warranty period is not extended nor does a new
warranty period begin following repair or replacement under the warranty.
