Taurus TF-MASSAGER User manual

Massager
Art.-Nr. TF-MASSAGER TFMASSAGER.01.01
Operating Instructions
❙CAUTION
If parts of the scope of delivery are missing or damaged, the equipment
must not ne used.
Charging
ATTENTION
Charge the equipment for up to six hours before rst use. During
charging, the battery may be disconnected or connected.
Connect the DC connector of the supplied 24V adapter to the appropriate
connector on the unit and the AC connector to a wall outlet.
+ The LED band on the battery indicates active charging and battery
status.
+ When the battery is connected to the device, the LED lights on the
device ash and indicate charging.
+ When the LED lights stop ashing, the battery is fully charged.
+ The battery can be recharged at any time.
+ Depending on the selected settings, the battery life is 2+ hours.
ATTENTION
It is not recommended to fully discharge the battery to the red LED
display.
Inserting and Removing the Battery
1. To insert the battery, press the bulge at the top of the battery and slide
the battery into the battery lock position.
The battery locks into place.
2. To remove the battery, press lightly on the battery lock with your thumb
and pull the battery/handle slightly downwards.
Switching the Equipment On/O
1. Insert the battery and set the power switch on the bottom of the battery
to ON.
2. Press the on/o button on the equipment once to set the unit to level 1.
Press the button twice to set the equipment to level 2. Press the button
three times to set the equipment to level 3. Press the button again to
turn o the equipment.
LNOTICE
To change the speed level (1-5), press the +/- buttons.
3. To turn o the unit completely, set the power switch on the bottom of
the battery to OFF.
Changing the Massage Head
1. To insert an massage head, switch o the equipment and push the
attachment completely into place.
2. To remove an massage head, turn o the power and pull out the
massage head.
Specication
The Massage Gun is a portable, rechargeable massage device with
vibration for use on deep-set muscle fasciae. The various massage heads
and adjustment options allow the device to eectively reduce pain
caused by the accumulation of lactic acid after training.
Technical Data
Nominal Voltage: DC 24V
Rated Frequency: 20-58Hz
Battery Life: 24V - 4H
Charger: 25,2V 1A
Massage Heads: 4 Pcs
Amplitude: 10mm
Overview
LED band: red Battery charge is less than 20%.
Charge the battery.
green The battery is fully charged. The charging
process can be stopped.
ashing Battery is charging.
Error “E1”: The battery charge is less than 10%. Charge the battery.
Battery Lock
Bulge with Push
Button
Display of Speed
Speed + Speed -
On/O
Battery Status
Operating Instructions
TF-MASSAGER

Massager
Massage Heads General Safety Instructions
+ This equipment may not be used by children
+ Children should not be allowed unsupervised access to the equipment
+ The equipment may only be connected directly to an earthed socket
using the supplied mains cable. Extension cables must conform to VDE
guidelines. Always completely unwind the mains cable.
+ The socket must be protected by a fuse with a minimum fuse rating of
“16 amps”.
+ Do not make any changes to the mains cable or the mains plug.
+ Keep the mains cable away from water, heat, oil and sharp edges.
Care, Maintenance and Storage
❙WARNING
The storage location should be chosen so that improper use by third
parties or children can be prevented.
1. Clean the device with a dry soft cloth.
2. For storage, remove the battery and store the device in the supplied
carton in a dry environment.
Warranty Information
Training equipment from Taurus® is subject to strict quality control.
However, if a tness equipment purchased from us does not work perfectly,
we take it very seriously and ask you to contact our customer service as
indicated. We are happy to help you by phone via our service hotline.
Model Usage Full Warranty
GUN Home use 24 Moths
Please refer to the website of your Taurus® device for the exact warranty
conditions.
Contact
DE
Technical Support
ᔍ+49 4621 4210-900
៽[email protected]
Service
ᔍ0800 20 20 277
(freecall)
៽[email protected]
UK
Technical Support
ᔍ+44 141 876 3986
៽support@powerhousetness.co.uk
Service
ᔍ+44 141 876 3972
FR
Technical Support & Service
ᔍ+33 (0) 172 770033
[phone]
៽service-france@tshop.fr
DK
Technical Support & Service
ᔍ80 90 16 50
[phone]
៽nfo@tshop.dk
INT
Technical Support & Service
ᔍ+49 4621 4210-944
៽service[email protected]
BE
Technical Support & Service
ᔍ02 732 46 77
[phone]
៽info@tshop.be
NL
Technical Support & Service
ᔍ+31 172 619961
៽info@tshop.nl
AT
Technical Support & Service
ᔍ0800 20 20 277
(freecall)
[phone]
៽[email protected]
CH
Technical Support & Service
ᔍ0800 202 027
[phone]
៽[email protected]
PL
Technical Support & Service
ᔍ22 307 43 21
[phone]
៽info@tshop.pl
Ball shape
The ball head has been specially developed for general
use and the massage of trigger points and is particularly
suitable for the treatment of large muscle groups.
Flat shape
The head with the at shape can be used for large body
regions and is particularly suitable for beginners due to its
large surface. With the at attachment, an even pressure is
created on the treated surface.
U-shape
The U-shaped head is particularly suitable for the
treatment of body regions where tendons or bones are to
be massaged. The neck muscles, the muscles to the left
and right of the spine and around the Achilles tendon are
possible areas of application for this head. Please note that
you should not massage directly onto the bone.
Finger shape
The nger head serves the massage of very specic body
regions. Use the nger head for the targeted massage of
trigger points and fasciae. Wherever you would otherwise
massage with a nger.
