Multifunction Tool
What your 1 year warranty means
Great care has gone into the manufacture of this product and it should therefore provide you with years
good service when used properly. In the event of product failure within its intended use over the course
of the rst 1 year after the date of purchase, we will remedy the problem as quickly as possible once
it has been brought to our attention. In the unlikely event of such an occurrence, or if you require any
information about the product, please contact us via our after sales support services, details of which
can be found in this manual and on the product itself.
Welcome Section
Congratulations on choosing to buy a TAURUS® product.
All products brought to you by TAURUS® are manufactured to the highest standards of performance and
safety, and, as part of our philosophy of customer service and satisfaction, are backed by our
comprehensive 1Year Warranty.
We hope you will enjoy using your purchase for many years to come.
Table of Contents
1. General safety rules Pg. 6
2. Layout Pg. 7
3. Items supplied Pg. 7
4. Proper use Pg. 7
5. Technical data Pg. 8
6. Before starting the machine Pg. 8
7. Starting up Pg. 9
8. Replacing the power cable Pg. 9
9. Cleaning, maintenance and ordering of spare parts Pg. 9
10. Disposal and recycling Pg. 10
11. Storage Pg. 10

AFTER SALES SUPPORT
1300 922 271 [email protected] MODEL NUMBER: E-MG 250E, 10/11
3
1
8e
23
14
3
5
2
10
8 7 6
9
5
b
8
57
b
a
6

AFTER SALES SUPPORT
1300 922 271 [email protected] MODEL NUMBER: E-MG 250E, 10/11
4
4 5
6
4
3
1
+-

AFTER SALES SUPPORT
1300 922 271 [email protected] MODEL NUMBER: E-MG 250E, 10/11
5
Caution
Read the operating instructions to reduce the risk of injury.
Wear ear-muffs.
The impact of noise can cause damage to hearing.
Wear safety goggles.
Sparks generated during working or splinters, chips and dust emitted by
the device can cause loss of sight.
Wear a breathing mask.
Dust which is injurious to health can be generated when working
on wood and other materials. Never use the device to work on any
materials containing asbestos!

AFTER SALES SUPPORT
1300 922 271 [email protected] MODEL NUMBER: E-MG 250E, 10/11
6
GENERAL SAFETY RULES
WARNING! Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, re and/or
serious injury. Save all warnings and instructions
for future reference.
The term “power tool” in the warnings refers to your
mains-operated (corded) power tool or battery-operated
(cordless) power tool.
1. Work area safety
a. Keep work area clean and well lit. Cluttered
and dark areas invite accidents.
b. Do not operate power tools in explosive
atmospheres, such as in the presence of
ammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or fumes.
c. Keep children and bystanders away while
operating a power tool. Distractions can cause
you to lose control.
2. Electrical safety
a. Power tools plugs must match the outlet.
Never modify the plug in any way. Do not use
any adapter plugs with earthed (grounded)
power tools. Unmodied plugs and matching
outlets will reduce risk of electric shock.
b. Avoid body contact with earthed or grounded
surfaces such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
c. Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
d. Do not abuse the cord. Never use the cord
for carrying, pulling or unplugging the power
tool. Keep cord away from heat, oil, sharp
edges or moving parts. Damaged or entangled
cords increase the risk of electric shock.
e. When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use
of a cord suitable for outdoor use reduces the risk
of electric shock.
f. If operating a power tool in a damp location
is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD reduces
the risk of electric shock.
3. Personal safety
a. Stay alert, watch what you are doing and
use common sense when operating a power
tool. Do not use a power tool while you are
tired or under the inuence of drugs, alcohol
or medication. A moment of inattention while
operating power tools may result in serious personal
injury.
b. Use personal protective equipment. Always
wear eye protection. Protective equipment such
as dust mask, non-skid safety shoes, hard hat, or
hearing protection used for appropriate conditions
will reduce personal injuries.
c. Prevent unintentional starting. Ensure the
switch is in the off-position before connecting
to power source and/or battery pack, picking
up or carrying the tool. Carrying power tools with
your nger on the switch or energising power tools
that have the switch on invites accidents.
d. Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key
left attached to rotating part of the power tool may
result in personal injury.
e. Do not overreach. Keep proper footing and
balance at all times. This enables better control
of the power tool in unexpected situations.
f. Dress properly. Do not wear loose clothing
or jewellery. Keep your hair, clothing and
gloves away from moving parts. Loose clothes,
jewellery or long hair can be caught in moving parts.
g. If devices are provided for the connection
of dust extraction and collection facilities,
ensure these are connected and properly
used. Use of these devices can reduce dust-related
hazards.
4. Power tool use and care
a. Do not force the power tool. Use the correct
power tool for your application. The correct
power tool will do the job better and safer at the
rate for which it was designed.
b. Do not use the power tool if the switch does
not turn it on and off. Any power tool that cannot
be controlled with the switch is dangerous and
must be repaired.
c. Disconnect the plug from the power source
and/or the battery pack from the power tool
before making any adjustments, changing
accessories, or storing power tools. Such
preventive safety measures reduce the risk of
starting the power tool accidentally.
d. Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions
to operate the power tool. Power tools are
dangerous in the hands of untrained users.
e. Maintain power tools. Check for misalignment
or binding of moving parts, breakage of parts
and any other condition that may affect the
power tools operation. If damaged, have the
power tool repaired before use. Many accidents
are caused by poorly maintained power tools.
f. Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
g. Use the power tool, accessories and tool bits
etc. in accordance with these instructions
and in the manner intended for the particular
type of power tool, taking into account
the working conditions and the work to be
performed. Use of the power tool for operations
different from those intended could result in a
hazardous situation.

AFTER SALES SUPPORT
1300 922 271 [email protected] MODEL NUMBER: E-MG 250E, 10/11
7
5. Service
Have your power tool serviced by a qualied repair
person using only identical replacement parts. This
will ensure that the safety of the power tool is maintained.
6. Recommendation
We recommend that the tool always be supplied via
residual curtrent device with a rated residual current of
30 mA or less.
Additional safety instructions
• This tool may only be used for dry grinding/
sanding operations.
• Always guide the power cable away from the back
of the tool.
• Use of the tool on materials containing asbestos is
prohibited.
• Always remove the plug from the power supply
socket before carrying out any work on the
machine (cleaning the sander, changing the
sandpaper, etc.).
• Always disconnect the machine by removing the
plug from the socket, not by pulling on the power
cable.
• To protect your health, always wear safety goggles
and a dust mask during sanding work.
• Keep your workplace clean and well illuminated.
• Make sure that the workpiece is secured so that it
cannot slip.
• Keep children away.
• For your own sake, keep the machine clean at all
times and check it for signs of damage each time
after using it.
• Make sure that the switch is set to OFF before you
insert the plug into the power supply socket.
• Make sure of your footing, particularly when
working on ladders and platforms.
• If you discover any damage to the machine, use
the exploded diagram and the spare parts list to
determine which parts need to be ordered from
Customer Service.
• Important! Wear safety goggles and a dust
mask.
Do not lose these safety instructions
Important!
When using equipment, a few safety precautions must
be observed to avoid injuries and damage. Please read
the complete operating manual with due care. Keep
this manual in a safe place, so that the information is
available at all times. If you give the equipment to any
other person, give them these operating instructions
as well. We accept no liability for damage or accidents
which arise due to non-observance of these instructions
and the safety information.
2. Layout (Fig. 1)
1. ON/OFF switch
2. Tool chuck
3. Dust extraction adapter
4. Speed controller
5. Allen key for changing tools
6. Saw Blade
7. Scraper
8. Triangular sanding/grinding plate
9. Diamond saw blade
10. HSS saw blade
3. Items Supplied
• Open the packaging and take out the equipment
• with care.
• Remove the packaging material and any packaging
and/or transportation braces (if available).
• Check to see if all items are supplied.
• Inspect the equipment and accessories for
transport damage.
• If possible, please keep the packaging until the
end of the guarantee period.
Important!
The equipment and packaging material are not toys.
Do not let children play with plastic bags, foils or small
parts. There is a danger of swallowing or suffocating!
• Multifunction Tool
• Triangular sanding/grinding plate
• Saw blade
• Scraper
• Dust extraction adapter
• Allen key
• 6x Sanding paper
• Diamond saw blade
• HSS saw blade
• User Guide
• Quick Start Guide
• Warranty Certicate
• Warranty Card
• Warranty Sticker
4. Proper use
The equipment is designed for the sanding/grinding
of wood, iron, plastic and similar materials using the
appropriate sanding/grinding paper. Furthermore, the
equipment is intended for sawing wood, plastic and
similar materials, as well as scraping off glued carpets,
lling compound residues, old paint and similar
applications.
The equipment is to be used only for its prescribed
purpose. Any other use is deemed to be a case of
misuse. The user / operator and not the manufacturer
will be liable for any damage or injuries of any kind
caused as a result of this.

AFTER SALES SUPPORT
1300 922 271 [email protected] MODEL NUMBER: E-MG 250E, 10/11
8
m
Please note that our equipment has not been designed
for use in commercial, trade or industrial applications.
Our warranty will be voided if the machine is used
in commercial, trade or industrial businesses or for
equivalent purposes.
5. Technical data
Mains voltage: 240 V~ 50Hz
Power input: 250 W
Idling Speed: 15000 - 21000 rpm
Sanding/grinding: 90 x 90 x 90 mm
Oscillation angle: 3º
Protection Class: II/
Weight : 1.35 kg
Sound and vibration
Sound and vibration values were measured in
accordance with EN 60745.
LpA sound pressure level 87 dB(A)
KpA uncertainty 3 dB
LWA sound power level 98 dB(A)
KWA uncertainty 3 dB
Wear ear-muffs.
The impact of noise can cause damage to hearing.
Total vibration values (vector sum of three directions)
determined in accordance with EN 60745.
Total vibration values (vector sum of three directions)
determined in accordance with EN 60745.
Handle
Vibration emission value ah= 4.632 m/s²
K uncertainty = 1.5 m/s2
Warning!
The specied vibration value was established in
accordance with a standardized testing method. It may
change according to how the electric equipment is
used and may exceed the specied value in exceptional
circumstances.
The specied vibration value can be used to compare
the equipment with other electric power tools.
The specied vibration value can be used for initial
assessment of a harmful effect.
Keep the noise emissions and vibrations to a
minimum.
• Only use appliances which are in perfect working
• order.
• Service and clean the appliance regularly.
• Adapt your working style to suit the appliance.
• Do not overload the appliance.
• Have the appliance serviced whenever necessary.
• Switch the appliance off when it is not in use.
• Wear protective gloves
Residual risks.
Even if you use this power tool in accordance with
instructions, certain residual risks cannot be ruled
out. The following hazards may arise in connection
with the equipment’s construction and layout:
1. Lung damage if no suitable protective dust mask
is used.
2. Damage to hearing if no suitable ear protection is
used.
3. Health damage caused by hand-arm vibrations if
the equipment is used over a prolonged period or
is not properly guided and maintained.
6. Before starting the machine
• Before you connect the equipment to the mains
supply make sure that the data on the rating plate
is identical to the mains data.
• Always pull the power plug before making
adjustments to the equipment.
6.1 Choosing the right plug-in accessories
Saw Blade (Fig. 1/Item 6) and HSS saw blade (Fig. 1/
Item 10): Sawing wood and plastic.
Notes on working practice: When sawing, watch out
for foreign bodies in the workpiece and remove these if
necessary.
The saw blade (Fig. 1/Item 6) can be used for plunge
cutting. Important! Plunge cutting is allowed only in soft
materials such as wood or plasterboard.
Diamond saw blade (Fig 1/Item 9): For partial repair of
tiled surfaces indoors and brick walls. Notes on working
practices: Only to be used when the turning frequency
is high.
Triangular sanding/grinding plate (Fig 1/Item 8):
Surface sanding/grinding at edges, in corners or hard-
to-reach areas. Depending on choice of sanding/grinding
paper for the sanding/grinding of wood, paint, lacquer,
etc.
The Velcro fastener enables easy changing of sanding/
grinding paper. Make sure that the vacuum extraction
holes on the sanding/grinding paper and the triangular
sanding/grinding plate (Fig. 1/Item 8) are aligned.
Notes on working practice: This equipment offers
particularly high performance for the sanding/grinding of
hard-to-reach corners and edges. To sand/grind proles
and channels you can also work with just the tip or the

AFTER SALES SUPPORT
1300 922 271 [email protected] MODEL NUMBER: E-MG 250E, 10/11
9
edge of the sanding/grinding plate. Various sanding/
grinding papers are available, specially designed for
the different types of material you may be working on
and the amount you wish to remove from the surface.
The amount removed will depend largely on the choice
of sanding/grinding paper and pressure applied to the
sanding/grinding plate.
Scraper (Fig 1/Item 7): Scraping off old paint or
adhesives. Notes on working practice: Move the plug-in
accessory against the area you want to remove. Begin
with a at angle of incidence and little pressure. The
surface (e.g. wood, plaster) may be damaged if too
much pressure is used.
6.2 Fitting the plug-in accessories (Figs. 1/2/3)
• To t the plug-in accessories safely you should
hold the multifunction tool so that the ON/OFF
switch (Fig. 1/Item 1) points down and the tool
chuck (Fig. 1/Item 2) faces up.
• Place the plug-in accessory (e.g. the triangular
sanding/grinding plate) on the tool chuck (Fig. 1/
Item 2) so that the pins of the tool chuck (Fig.
1/Item 2) t into the recesses in the plug-in
accessory.
• Secure the plug-in accessory using the supplied
screw (Fig. 2 & 3/Item b) and tighten the screw
securely with the provided Allen key (Fig. 1/Item 5).
• Make sure that the washer (Fig. 3/Item a) is used
for the screw (Fig. 2 & 3/Item b) only in connection
with the saw blade (Fig. 3/Item 6) and the scraper
(Fig. 3/Item 7). The corrugated face of the washer
must be placed against the plug-in accessory.
Check that the plug-in accessory is secure.
6.3 Assembly of the dust extraction adapter
The dust extraction system prevents the accumulation of
dirt and high dust loads in the air, and it makes it easier
to dispose of the dust.
• Insert the dust extraction adapter (Fig. 5/Item 3)
into the opening until both projections are locked
into place.
• Connect your appliance to an extraction unit
or vacuum cleaner. This will provide excellent
extraction of chips and dust from the workpiece.
7. Starting up (Fig. 6)
7.1 Switching ON/OFF
Slide the ON/OFF switch (1) forwards to switch on the
equipment.
7.2 Practical tips
• Switch on the equipment.
• Work away from the body.
• Never move your hands into the direct vicinity of
the work area.
• Use only plug-in accessories which are in good
working order and undamaged.
7.3 Speed controller
To pre-select the speed turn the knurled screw (Fig. 4/
Item 4) on the switch.
Plus direction Higher speed
Minus direction Lower speed
8. Replacing the power cable
If the power cable for this equipment is damaged, it
must be replaced by the manufacturer or its aftersales
service or similarly trained personnel to avoid danger.
Please call our After Sales Support Number on 1300 922
271.
9. Cleaning, maintenance and
ordering of spare parts
Always pull out the power plug before starting
any cleaning work.
9.1 Cleaning
• Keep all safety devices, air vents and the motor
housing free of dirt and dust as far as possible.
• Wipe the equipment with a clean cloth or blow it
with compressed air at low pressure.
• We recommend that you clean the device
immediately each time you have nished using it.
• Clean the equipment regularly with a moist cloth
and some soft soap. Do not use cleaning agents
or solvents; these could attack the plastic parts of
the equipment. Ensure that no water can seep into
the device.
9.2 Carbon brushes
In case of excessive sparking, have the carbon brushes
checked only by a qualied electrician.
Important! The carbon brushes should not be replaced
by anyone but a qualied electrician.
9.3 Maintenance
There are no parts inside the equipment which
require additional maintenance.
9.4 Ordering spare parts:
Please quote the following data when ordering
spare parts:
• Type of machine
• Article number of the machine
• Identication number of the machine
• Replacement part number of the part required
Please call our After Sales Support Number on 1300 922
271.

AFTER SALES SUPPORT
1300 922 271 [email protected] MODEL NUMBER: E-MG 250E, 10/11
10
10. Disposal and recycling
The unit is supplied in packaging to prevent its being
damaged in transit. This packaging is raw material and
can therefore be reused or can be returned to the raw
material system.
The unit and its accessories are made of various types
of material, such as metal and plastic.
Defective components must be disposed of as special
waste. Ask your local council.
11. Storage
Store the equipment and accessories out of children’s
reach in a dark and dry place at above freezing
temperature. The ideal storage temperature is between
5 and 30 °C. Store the electric tool in its original
packaging.

AFTER SALES SUPPORT
1300 922 271 [email protected] MODEL NUMBER: E-MG 250E, 10/11
11

AFTER SALES SUPPORT
1300 922 271 [email protected] MODEL NUMBER: E-MG 250E, 10/11
12
TAURUS®is a registered trademark of ALDI Stores.
ALDI Guarantee
Specially made for ALDI Stores to our stringent quality specications. If you are not entirely satised with this
product, please return it to your nearest ALDI store, within 60 days from the date of purchase, for a full refund or
replacement, or take advantage of our after sales support by calling the Customer Service Hotline.
ALDI STORES
1 SARGENTS ROAD
MINCHINBURY NSW 2770
AUSTRALIA
www.aldi.com.au
10/2011
Art.Nr: 44.650.22_11011
