Taylor C712 User manual

SERVICE
MANUAL
Model C712 & C713
Soft Serve Freezers
Original Service Instructions
062179-S
6/15/05 (Original Publication)
(Updated 7/1/16)

Models C712/C713 Table of Contents
Table of Contents
Section 1: Introduction 1...............................................
Safety 2.............................................................
Model C712 Specifications 4...........................................
Model C713 Specifications 5...........................................
Running Specifications 6...............................................
General Installation Instructions 7.......................................
Environmental Notices 11...............................................
Important to the Operator 12............................................
Section 2: Controls, Systems and Operations 15..........................
Universal Control Programming 16.......................................
Power Interrupt 28.....................................................
Pump Operation 29....................................................
Timers 30.............................................................
Beater Stir Cycles 30...................................................
Setting Viscosity 30....................................................
Jumper Pin Charts 31..................................................
Control Overview - UVC4 33............................................
Universal Control Board - UVC4 34.......................................
Refrigeration Schematic 39..............................................
Refrigeration System Components 40....................................
Section 3: Troubleshooting 41...........................................
General Troubleshooting Guide 42.......................................
Electrical Troubleshooting Guide 46......................................
C712/C713 Electrical Troubleshooting Guide 47...........................
Pump Style Freezer Troubleshooting 48..................................
Bacteria Troubleshooting 49.............................................
Section 4: Parts 51......................................................
Parts Warranty Explanation 52...........................................
Model C712 Exploded View 54..........................................
Operator Parts (Model C712) 56........................................
Model C713 Exploded View 58..........................................
Operator Parts (Model C713) 60........................................
Control A. - X67560-27 (Model C712) 62..................................

Table of Contents Models C712/C713
Table of Contents - Page 2
Control A. - X67561-27- (Model C713) 64.................................
Box A.-Cap & Relay - X6540227SP - (Model C712 & C713/Bristol) 66........
Box A.-Cap & Relay - X81081-27 (Model C713/Copeland) 67................
Pump A.-Mix Simplified - X57029- (Model C712) 68........................
Door and Beater Assembly (Model C712) 69..............................
Door and Beater Assembly (Model C713) 70..............................
Plate A.-Dec (Model C712) 71...........................................
Plate A.-Dec (Model C713) 72...........................................
Rail-Syrup - X63883-27 (Optional) 73.....................................
Switch A.-Dual Lever - X69838 (Model C712 & C713) 74....................
Actuator A.-Draw Switch - X69835 (Model C712 & C713) 75.................
Blower A. X53725-27 (Model C712 & C713) 76...........................
Condenser A. - X68077-27G (Model C712 & C713) 77......................
Accessories (Model C712 & C713) 78....................................
Brushes (Model C712 & C713) 79........................................
Parts List 80...........................................................
Wiring Diagrams 94....................................................
CAUTION: Information in this manual is intended to be used by Taylor Authorized
Service Technicians only.
Note: Only instructions originating from the factory or its authorized translation
representative(s) are considered to be the original set of instructions.
Note: Continuing research results in steady improvements; therefore, information
in this manual is subject to change without notice.
!2005 Carrier Commercial Refrigeration, Inc. (Original Publication)
(Updated July, 2016)
062179-S
Any unauthorized reproduction, disclosure, or distribution of copies by any person of any portion of this
work may be a violation of Copyright Law of the United States of America and other countries, could result
in the awarding of Statutory Damages of up to $250,000 (17 USC 504) for infringement, and may result
in further civil and criminal penalties.
All rights reserved.
Taylor Company
a division of Carrier Commercial Refrigeration, Inc.
750 N. Blackhawk Blvd.
Rockton, IL 61072

1
Models C712/C713 Introduction
Section 1: Introduction
!Safety
!Refrigerant
!Specifications
!General Installation Instructions
!Running Specifications
!Important to the Operator

2
Introduction Models C712/C713
131028
Safety
______________________________
We, at Taylor Company, are committed to
manufacturing safe operating and serviceable
equipment. The many built‐in safety features that
are part of all Taylor equipment are aimed at
protecting operators and trained service technicians
alike.
This manual is intended exclusively for Taylor
authorized service personnel.
Per IEC 60335-1 and its part 2 standards, “This
appliance is to be used only by trained personnel. It
is not intended for use by children or people with
reduced physical, sensory, or mental capabilities, or
lack of experience and knowledge, unless given
supervision or instruction concerning the use of the
appliance by a person responsible for their safety.”
DO NOT attempt to run the equipment
unless you have been properly trained to do so.
CAUTION: THIS EQUIPMENT MUST BE
PROPERLY GROUNDED! Do not operate this
freezer unless it is properly grounded and all service
panels and access doors are restrained with screws.
Failure to do so can result in severe personal injury
from electrical shock!
!DO NOT attempt any repairs unless the
main power supply to the freezer has been
disconnected.
!DO NOT operate the freezer with larger
fuses than specified on the data label.
!Stationary appliances which are not
equipped with a power cord and plug or
other device to disconnect the appliance
from the power source must have an all-pole
disconnecting device with a contact gap of
at least 3 mm installed in the external
installation.
!Appliances that are permanently connected
to fixed wiring and for which leakage
currents may exceed 10 mA, particularly
when disconnected, not used for long
periods, or during initial installation, shall
have protective devices such as a GFI to
protect against the leakage of current and
be installed by authorized personnel to the
local codes.
!Supply cords used with this unit shall be
oil-resistant, sheathed flexible cable, not
lighter than ordinary polychloroprene or
other equivalent synthetic
elastomer-sheathed cord (Code designation
60245 IEC 57) installed with the proper cord
anchorage to relieve conductors from strain,
including twisting, at the terminals and
protect the insulation of the conductors from
abrasion.
If the supply cord is damaged, it must be
replaced by an authorized Taylor service
technician in order to avoid a hazard.
!Cord Connected Units: Only Taylor
authorized service technicians may install a
plug on this unit.
Failure to follow these instructions may result in
electrocution or damage to the machine.
Note: This unit is provided with an equipotential
grounding lug that is to be properly attached to
either the rear of the frame or the under side of the
base pan near the entry hole for incoming power, by
the authorized installer. The installation location is
marked by the equipotential bonding symbol (5021
of IEC 604171) on both the removable panel and
the equipment's frame, as well as on the diagram.
DO NOT remove the freezer door or any
internal operating parts (examples: beater, scraper
blades, etc.) unless all control switches are in the
OFF position. Failure to follow these instructions
may result in severe personal injury from hazardous
moving parts.

3
Models C712/C713 Introduction
110725
THIS UNIT HAS MANY SHARP EDGES
THAT CAN CAUSE SEVERE INJURIES.
Examples:
!scraper blades
!condenser fins
!cup/cone dispenser (if applicable)
This unit must be installed on a level
surface to avoid the hazard of tipping. Extreme care
should be taken in moving this equipment for any
reason. Two or more people are required to safely
move this unit. Failure to comply may result in
personal injury or equipment damage.
This unit must NOT be installed in an area
where a water jet or hose can be used. NEVER use
a water jet or hose to rinse or clean this unit. Using a
water jet or hose on or around this equipment may
result in the electrocution of the user or damage to
the equipment.
Cleaning and sanitizing schedules are
governed by your state or local regulatory agencies
and must be followed accordingly. Please refer to
the cleaning section of the Operator Manual for the
proper procedure to clean this unit.
Authorized service personnel must ensure that the
proper PPE (Personal Protective Equipment) is
available and worn when required during installation
and service.

4
Introduction Models C712/C713
150512
Model C712 Specifications
Freezing Cylinder
Two, 3.4 quart (3.2 liter)
Mix Hopper
Two, 20 quart (18.9 liter)
Beater Motor
Two, 1.5 hp
Refrigeration Unit
Two, approximately 9,500 btu/hr compressors
Refrigerant R404A.
Electrical
Electrical
Maximum
Fuse Size
Minimum
Circuit
Ampacity
208-230/60/1 Air
Left Right Left Right
35 35 27 25
208-230/60/1 Air, Syrup 40 35 28 25
208-230/60/1 Water 35 35 26 25
208-230/60/3 Air 25 20 19 17
208-230/60/3 Water 25 20 18 17
220-240/50/1 Water 30 25 22 20
380-415/50/3N~Air 12 10 11 9
This unit may be manufactured in other electrical
characteristics. Refer to the local Taylor Distributor
for availability. (For exact electrical information,
always refer to the data label of the unit.)
Air Cooled
Clearance: A minimum of 3” (76 mm) is required
around all sides. Install the deflector provided to
prevent recirculation of warm air.
Water Cooled
Water inlet and drain connections under the side of
the base, 1/2” FPT.
Dimensions
Width: 25-7/16” (646 mm)
Height: 60” (1524 mm)
Depth: 36-3/16 (919 mm)
Floor Clearance*: 4-3/4 (121 mm)
*Mounted on standard casters
Approximate Weights
Net: 777 lbs. (352 kgs)
Crated: 855 lbs. (388 kgs)
Volume: 68.4 cu. ft. (1.94 cu. m.)

5
Models C712/C713 Introduction
150512
Model C713 Specifications
Freezing Cylinder
Two, 3.4 quart (3.2 liter)
Mix Hopper
Two, 20 quart (18.9 liter)
Beater Motor
Two, 1.5 hp
Refrigeration Unit
Two, approximately 9,500 btu/hr compressors
Refrigerant R404A.
Electrical
Electrical
Maximum
Fuse Size
Minimum
Circuit
Ampacity
208-230/60/1 Air
Left Right Left Right
35 35 25 23
208-230/60/1 Air, Syrup 35 35 26 23
208-230/60/1 Water 35 35 25 23
208-230/60/3 Air 25 25 19 17
208-230/60/3 Water 20 20 17 15
220-240/50/1 Water 25 25 21 19
380-415/50/3N~Air 12 10 9 8
This unit may be manufactured in other electrical
characteristics. Refer to the local Taylor Distributor
for availability. (For exact electrical information,
always refer to the data label of the unit.)
Air Cooled
Clearance: A minimum of 3” (76 mm) is required
around all sides. Install the deflector provided to
prevent recirculation of warm air.
Water Cooled
Water inlet and drain connections under the side of
the base, 1/2” FPT.
Dimensions
Width: 25-7/16” (646 mm)
Height: 60” (1524 mm)
Depth: 36-3/16 (919 mm)
Floor Clearance*: 4-3/4 (121 mm)
*Mounted on standard casters
Approximate Weights
Net: 733 lbs. (333 kgs)
Crated: 810 lbs. (367 kgs)
Volume: 67.5 cu. ft. (1.91 cu. m.)

6
Introduction Models C712/C713
070321
Running Specifications
Pressures/Temperatures
The following are the Taylor recommended settings
for various components within these models. The
freezers in this manual use refrigerant R404A.
Expansion Valve (AXV)
Air Cooled - 21 psi (145 kPa)
Water Cooled - 21 psi (145 kPa)
for a normal product of 16° to 18°F (‐8.8° to ‐7.7°C).
Expansion Valve Adjustment (AXV)
Place your gauge on the access valve on the suction
line (located at the compressor).
Adjust the pressure higher or lower by turning the
adjustment screw. Clockwise turns raise the
pressure and counterclockwise turns lower the
pressure.
Note: Make expansion valve adjustments with mix
in the cylinder and the freezer in the AUTO mode.
Be sure to allow adequate time for the pressure to
stabilize.
Low Side (Suction)
Suction pressure equals expansion valve setting.
High Side (Discharge)
High side pressure varies for air cooled units,
depending on the ambient temperature.
Ambient Temperature Normal Operating Head
Pressures
F C PSI
70° 21.1° 240 ‐270
(1,655 ‐1,862 kPa)
80° 26.7° 270 ‐300
(1,862 ‐2,069 kPa)
90° 32.2° 300 ‐340
(2,069 ‐2,344 kPa)
100° 37.8° 340 ‐380
(2,344 ‐2,620 kPa)
Water Valve
On a water cooled unit, the water valve should be
set to maintain a compressor head pressure of 255
PSI (1,758 kPa).
Water Valve Adjustment
Place your gauge on the high side access port of the
compressor. Turning the adjustment stem on the
water valve clockwise will lower the pressure.
Note: Make this adjustment with mix in the cylinder
and the freezer in the AUTO mode. Be sure to allow
adequate time for pressure to stabilize.

7
Models C712/C713 Introduction
110725
General Installation Instructions
CAUTION: Only trained, authorized service
technicians should install this equipment. Failure to
comply will void the factory warranty.
The following are general installation instructions.
For complete installation details, please see the
checkout card.
ALL WIRING AND PLUMBING MUST
CONFORM TO NATIONAL AND LOCAL CODES.
INSTALL POTABLE WATER CONNECTION
WITH ADEQUATE BACK-FLOW
PROTECTION TO COMPLY WITH
APPLICABLE NATIONAL, STATE AND
LOCAL CODES.
Site Preparation
Review the area where the unit will be installed
before uncrating the unit. Make sure that all possible
hazards to the user and the equipment have been
addressed.
Clearance: Air Cooled Units
This equipment requires a minimum of 3” (76 mm)
air clearance around all sides.
DO NOT obstruct air intake and discharge openings.
Install the deflector provided to prevent recirculation
of warm air.
Failure to allow proper clearance and airflow may
cause poor freezer performance and damage to the
machine.
For Indoor Use Only: This unit is designed to
operate indoors, under normal ambient
temperatures of 70"75"F (21"24"C). The
freezer has successfully performed in high ambient
temperatures of 104"F (40"C) at reduced
capacities.
This unit must NOT be installed in an area
where a water jet or hose can be used. NEVER use
a water jet or hose to rinse or clean this unit. Using a
water jet or hose on or around this equipment may
result in electrocution to the user or damage to the
equipment.
This unit must be installed on a level
surface to avoid the hazard of tipping. Extreme care
should be taken in moving this equipment for any
reason. Two or more people are required to safely
move this unit. Failure to comply may result in
personal injury or equipment damage.
Uncrate the machine. Inspect the unit for damage.
Report any damage to the Taylor factory
immediately.
This piece of equipment is made in the USA and has
USA sizes of hardware. All metric conversions are
approximate and vary in size.
Installer Safety
In all areas of the world, equipment should
be installed in accordance with existing local codes.
Please contact your local authorities if you have any
questions.
Care should be taken to ensure that all basic safety
practices are followed during the installation and
servicing activities related to the installation and
service of Taylor equipment.
!Only authorized Taylor service personnel
should perform installation and repairs on
the equipment.
!Cord Connected Units: Only Taylor
authorized service personnel may install a
plug on this unit.
!Authorized service personnel should consult
OSHA Standard 29CFRI910.147 or the
applicable code of the local area for the
industry standards on lockout/tagout
procedures before beginning any installation
or repairs.
!Authorized service personnel must ensure
that the proper PPE is available and worn
when required during installation and
service.
!Authorized service personnel must remove
all metal jewelry, rings, and watches before
working on electrical equipment.

8
Introduction Models C712/C713
131028
THIS UNIT HAS MANY SHARP EDGES
THAT CAN CAUSE SEVERE INJURIES.
Examples:
!scraper blades
!condenser fins
!cup/cone dispenser (if applicable)
Electrical Connections
In the United States, this equipment is
intended to be installed in accordance with the
National Electrical Code (NEC), ANSI/NFPA
701987. The purpose of the NEC code is the
practical safeguarding of persons and property from
hazards arising from the use of electricity. This code
contains provisions considered necessary for safety.
In all other areas of the world, equipment should be
installed in accordance with the existing local codes.
Please contact your local authorities.
Each unit requires one power supply for each data
label on the unit. Check the data label(s) on the unit
for branch circuit overcurrent protection or fuse,
circuit ampacity and other electrical specifications.
Refer to the wiring diagram provided inside of the
electrical box for proper power connections.
FOLLOW YOUR LOCAL ELECTRICAL CODES!
CAUTION: THIS EQUIPMENT MUST BE
PROPERLY GROUNDED! FAILURE TO DO SO
CAN RESULT IN SEVERE PERSONAL INJURY
FROM ELECTRICAL SHOCK!
Note: This unit is provided with an equipotential
grounding lug that is to be properly attached to
either the rear of the frame or the under side of the
base pan near the entry hole for incoming power, by
the authorized installer. The installation location is
marked by the equipotential bonding symbol (5021
of IEC 604171) on both the removable panel and
the equipment's frame, as well as on the diagram.
!DO NOT operate the freezer with larger
fuses than specified on the data label.
!Stationary appliances which are not
equipped with a power cord and a plug or
another device to disconnect the appliance
from the power source must have an allpole
disconnecting device with a contact gap of
at least 3 mm installed in the external
installation.
!Appliances that are permanently connected
to fixed wiring and for which leakage
currents may exceed 10 mA, particularly
when disconnected, not used for long
periods, or during initial installation, shall
have protective devices such as a GFI to
protect against the leakage of current and
be installed by authorized personnel to the
local codes.
!Supply cords used with this unit shall be
oilresistant, sheathed, flexible cable, not
lighter than ordinary polychloroprene or
other equivalent synthetic
elastomersheathed cord (Code designation
60245 IEC 57) installed with the proper cord
anchorage to relieve conductors from strain,
including twisting, at the terminals and
protect the insulation of the conductors from
abrasion.
If the supply cord is damaged, it must be
replaced by an authorized Taylor service
technician in order to avoid a hazard.
Failure to follow these instructions may result in
electrocution or damage to the machine.

9
Models C712/C713 Introduction
131028
Disconnect Switch
If the unit has no plug, a separate disconnect switch
must be installed, or another alternate means to
disconnect power must be implemented.
Water Connections
(Water Cooled Units, Only)
An adequate cold water supply must be provided
with a hand shut-off valve. The water inlet and drain
connections are located on the right side or the
underside of the base. These connections are either
3/8” or 1/2” FTP, depending on the model of the unit.
(Refer to “Model Specifications”.)
Flexible lines are recommended, if local codes
permit. In Europe, hose sets for connection of
appliances to the water mains must comply to the
international IEC 61770 standard.
The water expansion valve setting should be set at
255 PSIG (1758 kPa).
Depending on local water conditions, it may be
advisable to install a water strainer to prevent
foreign substances from clogging the automatic
water valve. There will be only one water “in” and
one water “out” connection.
DO NOT install a hand shut-off valve on the water
“out” line! Water should always flow in this order:
first, through the automatic water valve; second,
through the condenser; and third, through the outlet
fitting to an open trap drain.
A back flow prevention device is
required on the incoming water connection side.
Please refer to the applicable National, State, and
local codes for determining the proper configuration.
Refrigeration
In consideration of our environment, Taylor uses
only earth friendly HFC refrigerants. The HFC
refrigerant used in this unit is R404A. This
refrigerant is generally considered nontoxic and
nonflammable, with an Ozone Depleting Potential
(ODP) of zero (0).
However, any gas under pressure is potentially
hazardous and must be handled with caution.
NEVER fill any refrigerant cylinder completely with
liquid. Filling the cylinder to approximately 80% will
allow for normal expansion.
Use only R404A refrigerant that conforms
to the AHRI standard 700 specification. The use of
any other refrigerant may expose users and
operators to unexpected safety hazards.
Refrigerant liquid sprayed onto the skin may
cause serious damage to tissue. Keep eyes and skin
protected. If refrigerant burns should occur, flush
immediately with cold water. If burns are severe,
apply ice packs and contact a physician
immediately.
Taylor reminds technicians to be cautious of
government laws regarding refrigerant recovery,
recycling, and reclaiming systems. If you have any
questions regarding these laws, please contact the
factory Service Department.
WARNING: R404A refrigerant used in
conjunction with polyolester oils is extremely
moisture absorbent. When opening a refrigeration
system, the maximum time the system is open must
not exceed 15 minutes. Cap all open tubing to
prevent humid air or water from being absorbed by
the oil.
Main Compressor:
Air cooled units: 40 oz (1,134 g) of R404A.
Water cooled units: 38 oz (1,077g) of R404A.
Gear Alignment and Rear Shell Bearing
1. Make certain the drive shaft(s) can easily slide
in and out of the female socket on the gear
unit(s).
2. If a drive shaft is binding, the gear unit could be
out of alignment (loose). Check the bolts on the
gear unit to be sure they are tight.
3. Inspect the rear shell bearing for tightness. Be
sure the locking tab has been folded over to
prevent the nut from loosening.

10
Introduction Models C712/C713
050829
Beater Rotation
Beater rotation must be clockwise as
viewed looking into the freezing cylinder.
REMEMBER TO DISCONNECT ALL
POWER TO THE FREEZER! Failure to follow this
instruction may result in electrocution or severe
personal injury from hazardous moving parts.
1. Remove the door assembly, beater, and
scraper blades.
2. Place a magnet over the door switch in the
front panel. This deactivates the safety feature,
which prevents the operation of the machine
when the door is not installed.
3. Place the power switch in the ON position.
4. Press the WASH symbol. This activates the
beater motor only.
5. Look into the freezing cylinder. The drive shaft
should be turning clockwise.
6. Press the WASH symbol again to stop the
beater motor.
To correct rotation on a single‐phase unit, exchange
leads inside the beater motor. (Follow the diagram
printed on the motor.)
To correct rotation on a three‐phase unit,
interchange any two incoming power supply lines at
freezer main terminal block only.
REMEMBER TO DISCONNECT ALL
POWER TO THE FREEZER! Failure to follow this
instruction may result in electrocution or severe
personal injury from hazardous moving parts.
Pump Motor Rotation (C712 Only)
1. Remove the air/mix pump assembly.
2. Connect power to the freezer and place the
power switch in the ON position.
3. Press the PUMP symbol. This will activate the
pump motor only.
4. Observe the pump ball crank. It should be
rotating counterclockwise.
If rotation is not correct, refer to the wiring diagram
on the pump motor and re‐wire accordingly.
REMEMBER TO DISCONNECT ALL
POWER TO THE FREEZER! Failure to follow this
instruction may result in electrocution or severe
personal injury from hazardous moving parts.
Syrup Rail Operating Instructions
1. Remove the stainless steel syrup jar with
topping pump from the syrup rail. Check the
water level in the well. Make sure the water is
filled to the indicating mark on the inside wall
(16 oz [454 g]). Check the water level daily.
2. Place the heater switch in the ON position. The
heating process will take approximately 1-1/4
hours.
3. Prepare a pail with an approved 100 PPM
sanitizing solution. USE WARM WATER AND
FOLLOW THE MANUFACTURER'S
SPECIFICATIONS.
4. Sanitize the pump by placing the entire
assembly in the solution and pump the solution
through the pump until sanitized.
5. Fill the heated and room temperature syrup jars
with toppings. Place the topping pump in the
heated syrup jar. Sanitize the ladle and place it
in the room temperature jar.

11
Models C712/C713 Introduction
Compressor Warranty Disclaimer
The refrigeration compressor(s) on this machine are
warranted for the term indicated on the warranty
card accompanying this machine. However, due to
the Montreal Protocol and the U.S. Clean Air Act
Amendments of 1990, many new refrigerants are
being tested and developed, thus seeking their way
into the service industry. Some of these new
refrigerants are being advertised as drop-in
replacements for numerous applications. It should
be noted that in the event of ordinary service to this
machine's refrigeration system, only the refrigerant
specified on the affixed data label should be used.
The unauthorized use of alternate refrigerants will
void your compressor warranty. It will be the owners'
responsibility to make this fact known to any
technicians they employ.
It should be noted that Taylor does not warrant the
refrigerant used in its equipment. For example, if the
refrigerant is lost during the course of ordinary
service to this machine, Taylor has no obligation to
either supply or provide its replacement either at
billable or unbillable terms. Taylor does have the
obligation to recommend a suitable replacement if
the original refrigerant is banned, obsoleted, or no
longer available during the five year warranty of the
compressor.
Taylor will continue to monitor the industry and test
new alternates as they are being developed. Should
a new alternate prove, through our testing, that it
would be accepted as a drop-in replacement, then
the above disclaimer would become null and void.
To find out the current status of an alternate
refrigerant as it relates to your compressor, call the
local Taylor Distributor or the Taylor Factory. Be
prepared to provide the model/serial number of the
unit in question.
Environmental Notices
______________________________
In consideration of our environment, Taylor proudly
uses only earth friendly HFC refrigerants. The HFC
refrigerant used in this unit is R404A. This
refrigerant is generally considered nontoxic and
nonflammable, with an Ozone Depleting Potential
(ODP) of zero (0).
However, any gas under pressure is potentially
hazardous and must be handled with caution.
If the crossed-out wheeled bin symbol is
affixed to this product, it signifies that this product is
compliant with the EU Directive, as well as other
similar legislation in effect after August 13, 2005.
Therefore, it must be collected separately after its
use is completed and cannot be disposed as
unsorted municipal waste.
The user is responsible for returning the product to
the appropriate collection facility as specified by your
local code.
For additional information regarding applicable local
laws, please contact the municipal facility and/or
local Taylor Distributor.
NOISE LEVEL: Airborne noise emission does not
exceed 78 dB(A) when measured at a distance of
1.0 meter from the surface of the machine and at a
height of 1.6 meters from the floor.

12
Introduction Models C712/C713
Important to the Operator
C712/C713
ITEM DESCRIPTION
1POWER SWITCH
2FLUORESCENT DISPLAY
3 KEYPADS
4MIX OUT INDICATOR
5STANDBY KEY
ITEM DESCRIPTION
6MIX LOW INDICATOR
7SELECT KEY
8SERVICE MENU KEY
9BRUSH CLEAN COUNTER
10 ARROW KEYS
NOTE: *C713 DOES NOT HAVE THE MIX PUMP KEY.

13
Models C712/C713 Introduction
050916
Symbol Definitions
To better communicate in the International arena,
symbols have replaced words on many of our
operator switches, function, and fault indicators.
Your Taylor equipment is designed with these
International symbols.
The following chart identifies the symbol definitions.
= SELECT
= UP ARROW
= DOWN ARROW
= AUTO
= WASH
= MIX LOW
= MIX OUT
= MENU DISPLAY
= MIX PUMP (C712 ONLY)
= STANDBY
Power Switch
When placed in the ON position, the power switch
allows control panel operation.
Fluorescent Display
The fluorescent display is located on the front
control panel. During normal operation, the display is
blank. The display is used to show menu options
and notifies the operator if a fault is detected. On
International models, the display will indicate the
temperature of the mix in each hopper.
Indicator Lights
MIX LOW ‐When the MIX LOW symbol is
illuminated, the mix hopper has a low supply of mix
and should be refilled as soon as possible.
MIX OUT ‐When the MIX OUT symbol is
illuminated, the mix hopper has been almost
completely exhausted and has an insufficient supply
of mix to operate the freezer. At this time, the AUTO
mode is locked out and the freezer will be placed in
the STANDBY mode. To initiate the refrigeration
system, add mix to the mix hopper and touch the
AUTO symbol . The freezer will automatically
begin operation.
Adjustable Draw Handle
This equipment features an adjustable draw
handle(s) to provide the best portion control, giving a
better, consistent quality to your product and
controlling food costs. The draw handle should be
adjusted to provide a flow rate of 5 to 7‐1/2 oz (142
to 213 g) of product by weight per 10 seconds. To
INCREASE the flow rate, turn the screw
CLOCKWISE, and COUNTERCLOCKWISE to
DECREASE the flow rate. (See Figure 1.)
Figure 1

14
Introduction Models C712/C713
Beater Motor Overload
The beater motor overloads are located in the rear
panel.
The beater motor overload protects the beater motor
from an overload condition. Should an overload
occur, the reset mechanism will trip. To properly
reset the freezer, place the power switch in the OFF
position. Press the reset button firmly. Turn the
power switch to the ON position. Touch the WASH
symbol and observe the freezer's performance.
WARNING: Do not use metal objects to
press the reset button. Failure to comply may result
in severe personal injury or death from electrical
shock.
If the beater motor is turning properly, touch the
WASH symbol to cancel the cycle. Touch the AUTO
symbol to resume normal operation. If the freezer
shuts down again, contact your authorized service
technician.
Air/Mix Pump Reset Mechanism
(C712 Only)
The reset buttons for the pumps are located in the
rear panel.
The reset protects the pump from an overload
condition. Should an overload occur, the reset
mechanism will trip. To reset the pump, press the
reset button firmly.
WARNING: Do not use metal objects to
press the reset button. Failure to comply may result
in severe personal injury or death.
Condenser Fan Motor
The condenser fan motor is driven by the software.
The L1 to the fan is connected to the interface board
at J6-6. The condenser fan is programmed to run
any time the compressor is on and to stay running
for 30 seconds after the compressor cycles off.

15
Models C712/C713 Controls, Systems and Operations
Section 2:
Controls, Systems and Operations
!Universal Control Programming
!Power Interrupt
!Pump Operation
!Timers
!Beater Stir Cycles
!Setting Viscosity
!Jumper Pin Function and Configuration Chart
!Control Overview
!Refrigeration Schematic
!Refrigeration System Components

16
Controls, Systems and Operations Models C712/C713
Universal Control Programming
Operating Screen
Descriptions
______________________________
The fluorescent display located in the center of the
control panel is normally blank during the daily
operation of the unit. The display is activated when
the SEL key or the Manager's Menu is selected. The
display screen will also alert the user of specific
faults detected by the control.
Power Up Memory (Initializing)
The seven segment display should display “00”
during the initializing sequence.
When the unit is powered, the control system will
initialize to perform a system check. The screen will
display “INITIALIZING”. There will be three types of
data the system will check: LANGUAGE, SYSTEM
DATA, and CONFIG DATA.
Language Initialization
The UVC platform supports multiple languages by
keeping specific strings in battery backed RAM.
After power-up or a CPU reset, the strings are
tested to see if the language strings are present and
not corrupted. If the strings are present and not
corrupted, initialization continues. Otherwise, the
operator is prompted to select a language. While
language strings are being checked for integrity, the
following screen is displayed.
Initializing
Language
Note: If there is a language initialization fault, the
unit will force a language selection prior to the
initializing sequence. The standard menu LED's
should light, as if it were in a menu. If a language
has been selected, the unit is powered down. The
unit should not ask for a language unless there is
another language initialization fault. English is the
factory default setting.
System Data
System data is protected separately from the rest of
the data in memory. System data includes variables
that change frequently, such as the mode the unit is
in, lockout status, serving counters, fault codes, and
others. While System Data is being checked the
following screen is displayed.
Initializing
System Data
If the System Data is corrupted, the unit is set to
OFF, the serving counters are set to zero, and the
faults are cleared. A “SYSTEM CRC ERR” fault is
set and displayed on the VFD. An acknowledgement
(SEL key) is required.
Configuration Data
Configuration data is separate from the rest of the
data in the memory. Configuration data is
information entered through operator and service
menus. While the Configuration Data is being
checked, the following screen is displayed.
Initializing
Config Data
If the Configuration Data is corrupted, all user and
service settings are set to defaults. A “CONFIG
CRC ERR” fault is set and displayed on the VFD.
The system will continue to operate in its previous
mode, but according to default settings.
After the memory integrity has been tested, the
Safety Timeout screen will be displayed.
