Taylor 5736F Instruction Manual

IB5736FC
5736FC 9.17 WC
Model # 5736F
These instructions contain important and useful
information about this unit’s operation. Please read
instructions thoroughly to ensure that you have the full
benefit of all the unit’s features. Keep these instructions
handy for future reference.
Body Composition Scale
with Body Water and
Muscle Mass Estimation
18
MADE IN CHINA.
Five (5) Year Limited Warranty
This scale is warranted against defects in materials of workmanship for fi ve (5) years
for the original purchaser from date of retail purchase. It does not cover damages
or wear resulting from accident, misuse, abuse, commercial use, or unauthorized
adjustment and/or repair. Do not return to retailer. Should this scale require review
(or replacement at our option) while under warranty, please pack the item in the
original packaging and return it prepaid, along with store receipt showing date of
purchase and a note explaining reason for return to:
Not Legal for trade.
©2017 Taylor Precision Products and its affiliated companies, all rights reserved.
Taylor® is a registered trademark of Taylor Precision Products and its affi liated
companies. All rights reserved. 9.17 WC
Distributed By:
Taylor Precision Products
2220 Entrada Del Sol, Suite A
Las Cruces, New Mexico 88001,USA
1-866-843-3905
www.shoptaylorusa.com
email: [email protected]
Taylor Precision Products
2220 Entrada Del Sol, Suite A
Las Cruces, New Mexico 88001,USA
1-866-843-3905
www.shoptaylorusa.com
email: [email protected]
There are no express warranties except as listed above. This warranty gives you
specific legal rights, and you may have other rights which vary from state to state.
For additional product information please contact us through
www.shoptaylorusa.com. If review is required, do not return to retailer. For
information call 1 [phone] from 8:00 am to 5:00 pm, Mountain Standard
Time, Monday through Friday. To assist us in serving you, please have the model
number and date of purchase available.
Customer Service Information
Please Read!
For questions regarding this product,
please contact us at:
Taylor Precision Products
2220 Entrada Del Sol, Suite A
Las Cruces, New Mexico 88001, USA
1-866-843-3905
www.shoptaylorusa.com
Please contact us before returning to retailer.
INSTRUCTION MANUAL &
WARRANTY INFORMATION

Model # 5736F
FCC REGULATIONS ..........................................................................................................11
BODY COMPOSITION SCALE WITH BODY WATER
and MUSCLE MASS ESTIMATION
This body composition scale is designed and manufactured in a facility certified ISO
9001 Quality, ISO1 4001 Environment, OHSAS 18001 Health and Safety Management
Systems and ISO13485 Medical Devices Quality Management System. The scale
uses the method of Bioelectrical Impedance Analysis (BIA) to estimate body fat,
total body water and muscle mass percentage. It sends a harmless amount of
electricity into the body, then estimates from the measured impedance of the
body the percentage of body fat, the percentage of total body water and muscle
mass percentage. The body composition scale is also equipped with an “Athlete
Mode" for athletes whose body build is different from non-athletes.

This scale is intended to measure body weight and impedance and
estimate percentage of body fat, body water and muscle mass using BIA
(Bioelectrical Impedance Analysis). It is intended for use by healthy
children 10-17 years old and healthy adults with active, moderately
active, to inactive lifestyles for body composition assessment in the home
environment.
• This product is intended for adults and children (ages 10 to 85).
• The Athlete Mode is only available for those 15-85 years of age.
• Make sure to use only the type of battery stated (see Section
"PREPARATION BEFORE USE”).
• Body fat percentage estimates will vary with the amount of water in the
body, and can be affected by dehydration or over-hydration due to
such factors as alcohol consumption, menstruation, illness, intense
exercise, etc.
• Do not use on pregnant women. The result is inaccurate and effects on
the fetus are unknown.
• For body fat, body water and muscle mass percentage estimates,
always estimate in bare feet.
• Changes value of height and age, toggle between Male and Female,
toggle between Normal and Athlete mode in Body Fat function
• Select memory P0 - P3 in Memory mode
• Fast recall of memory locations
Platform with
electrodes
LCD
Readout
N
AAGE
FAT
TBW MM
%
kg
lb
cm
ft-in
Male & Female Icons
Body Height Display
Body Weight Display
Body Fat %
Normal Icon
Athlete Icon Total Body Water
& Muscle Mass %
Age Icon

This scale operates on 1 CR2032 lithium battery
(included). Remove any screws and open the battery
cover on the back of the scale unit. Take care when
removing and replacing the battery door screw.
Do not turn the screw in the wrong direction or over tighten it as this may strip the
screw threads in the plastic battery door. Remove the plastic strip for first use or
insert a new battery for replacement. Be sure the polarity of the battery is set
correctly for the scale to function properly. If you do not intend to use this unit for a
prolonged period of time, it is advisable to remove the battery before storing.
Slide Switch (Available on unit
conversion model only)
-kg/cm and Ib/in
Adjust the conversion switch located at the bottom of the scale to change
the measuring unit between kg/cm and Ib/in.
User selectable unit: kg/cm or Ib/in.
This scale is set to pounds. You can set the “kg/cm and Ib/in" unit of measure
switch located on the back of the scale for kilograms or pounds.
SETONSETON

A
A
1. Set Memory
Press the [ON] key to enter body fat and total body water estimation mode.
The memory number will blink (Fig.3). Press the [] or [] key to select a
memory location (P0-P3). Press [SET] to confi rm.
3. Set Gender
The gender icon blinks (Fig.4). Press the [] or [] key to toggle between male
and female. Press [SET] to confi rm.
4. Set Age
The age blinks (Fig.5). Press the [] or [] key to adjust the age. Press [SET] to
confi rm.
2. Set Normal or Athlete
The Normal icon blinks (Fig.4a). Press the [] or [] key to toggle between
Normal and Athlete. Press [SET] to confi rm. NOTE: The Athlete mode is
only available for those 15-85 years or age. (See "Why the Athlete Mode is
Neccessary in a Body Fat Analyzer.)
aNA
AA
6. Measuring
Then the scale shows “0.0” (Fig.8). Step on the scale with bare feet and stand
still while the weight is being measured.
5. Set Height
The height blinks (Fig.6). Press the [] or [] key to adjust the height. Press
[SET] to confi rm. The data is successfully memorized. Meanwhile, the screen
will display the memory location, height, age, gender and normal/athlete
selection (Fig.7).
7. Display
Weight, body fat percentage, total body water percentage and muscle
mass percentage will be displayed 3 times sequentially (Fig.10). The scale
turns off automatically.
Step On Scale
With Bare Feet!
MM
A
AA A A

Measurement error. Impedance cannot be measured. Please make sure that
you are standing still on the scale and maintaining maximum contact between
your feet and the metal contacts. If not, please refer to “Operation” section. You
may need to moisten your feet to improve the electrical contact.
7. After I tried the corrective actions from Er 1 to Er 3, I still can’t solve the
If Er 1 to Er 3 persists after following the corrective actions, remove and reinsert
8. I have tried all corrective actions, but still can’t solve the problem …
9. Why do I get a different body fat reading when I use a different brand of body
composition scale...
NOTE: Please recycle or dispose of batteries per local regulations.
WARNING: Batteries may pose a choking hazard. As with all small items, do not let
children handle batteries. If swallowed, seek medical attention immediately.
PRECAUTION: Do not dispose of batteries in fire. Batteries may explode or leak.
Remove the battery if the scale will not be used for a long period of time.
Different body composition scales take estimations around different parts of the
body and use different mathematic algorithums to estimate the precentage of
body fat. The best advice is not to make comparisons from one device to
another, but to use the same device each time to monitor and change.

1. Bioelectrical Impedance Analysis (BIA) technology for body fat and body water
percentage
2. High precision STRAIN GAUGE technology for weight measurement
3. Athlete (for ages 15 years or older) or Normal Mode selection
4. Slim design
5. 4-user memories
6. 4-button operation
7. Integrated information read out
8. Fast recall function
9. Auto-on and auto-off functions
10. Power saving LCD readout
11. Low battery indicator
12. Capacity: 400lb or 181kg
13. Graduation, 0.2lb or 100g
14. Body fat graduation: 0.1%
15. Body water graduation: 0.1%
16. Muscle mass graduation: 0.1%
17. Age range from 10 to 85 years
18. Height range from 2'5.5" to 7'4.5" (75 to 225cm)
19. Body fat range: 4 to 60%
20. Operates with 1 CR2032 Lithium battery (included)
21. Product dimension: 12.2” x 11.8” x 1.3” (Approx.)
22. Gift box dimension: 12.7” x 12.4” x 1.7” (Approx.)
23. Product weight: 3.63 lb (Approx.)
24. Total weight (product &gift box): 4.22 lb (Approx.)
25. Accuracy of weight measurement: ±1.1 lb (11 lb ~ 143.3 lb);
±1.8 lb (143.3 lb ~ 297.6 lb); ±2.6 lb (297.6 lb ~ 400 lb);
26. Output power for Body Fat Analyzer: <300uA
IMPORTAT INFORMATION TO KNOW BEFORE USING YOUR BODY COMPOSITION SCALE

The estimates provided are not substitutes for the physician assessments.
Consult your physician to determine what body fat percentage and total
body water percentage are most ideal for you.
The optimal %TBW and average %SM of an individual varies according to
age and gender.
%BF Range Optimal % TBW Range %SM Range
Men
4 to 14% 70 to 63% 52 to 41%
15 to 21% 63 to 58% 46 to 38%
22 to 24% 58 to 56% 42 to 37%
25 to 60% 56 to 29% 40 or below
Women
4 to 20% 70 to 59% 46 to 37%
21 to 29% 59 to 52% 38 to 33%
30 to 32% 52 to 50% 34 to 31%
33 to 60% 50 to 29% 32 to below

5. Why is the Athlete Mode necessary in a Body Composition Scale?
It has been found that body fat estimation using BIA could overestimate the
percentage body fat of adult elite athletes. The physiological variation of
athletes in bone density and level of hydration are two of the reasons said to
account for the difference. The Athlete mode is selectable only for people 15
years of age or older.
6. Defi nition of an Athlete
The general consensus among researchers is that a quantitative dimension
could be used in defi ning an athlete. For example, an athlete could be defi ned
as a person who consistently trains a minimum of three times per week for two
hours each time, in order to improve specifi c skills required in the performance
of their specifi c sport and/or activity.
7. What is Muscle Mass?
Our Body Composition Scale estimates the weight of Skeletal Muscle Mass in your body.
You have around 650 muscles in your body, and they make up roughly half of
your body weight. These muscles can be divided into three different groups:
skeletal, smooth and cardiac. All of these muscles can stretch and contract, but
they perform very different functions.
Skeletal muscle: Produces movement, maintains posture, stabilizes joints and
generates heat
Smooth muscle: Found in the walls of hollow organs
Cardiac muscle: Exists only in your heart
Skeletal muscle
The tissue most commonly thought of as muscle is skeletal muscle. Skeletal
muscles cover your skeleton, giving your body its shape. They are attached to
your skeleton by strong, springy tendons or are directly connected to rough
patches of bone. Skeletal muscles are under voluntary control, which means
you consciously control what they do.
Just about all body movement, from walking to nodding your head, is
caused by skeletal muscle contraction. Your skeletal muscles function
almost continuously to maintain your posture, making one tiny adjustment
after another to keep your body upright. Skeletal muscle is also important
for holding your bones in the correct position and prevents your joints from
dislocating. Some skeletal muscles in your face are directly attached to your
skin. The slightest contraction of one of these muscles changes your facial
expression.
Skeletal muscle generates heat as a by-product of muscle activity. This heat is
vital for maintaining your normal body temperature.
Skeletal muscle represents approximately 30% of body weight of a healthy
127.8 lb woman or 40% of a 154.3 lb man. (International Commission on
Radiological Protection, 1975)
FCC REGULATIONS
16 17
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Caution: Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate the
equipment.
Note: This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation. This equipment has been
tested and found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
