TABLE OF CONTENTS
INTRODUCTION
Table of contents . . . . . . . . . . . . . . . . . . 3
Quick Start Guide . . . . . . . . . . . . . . . . . 4
Introduction . . . . . . . . . . . . . . . . . . . . . . 5
Front Panel . . . . . . . . . . . . . . . . . . . . . . 6
Rear Panel . . . . . . . . . . . . . . . . . . . . . . 8
Signal flow diagram . . . . . . . . . . . . . . . . 9
DBMAX setup . . . . . . . . . . . . . . . . . . . 10
BASIC OPERATION
Reference Levels. . . . . . . . . . . . . . . . . 12
Reference Levels Illustration . . . . . . . . 14
Recall . . . . . . . . . . . . . . . . . . . . . . . . . 15
Store - Delete and Preset Names. . . . . 16
MAIN PAGE
Input . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Inserts
AGC. . . . . . . . . . . . . . . . . . . . . . . . 22
Parametric EQ . . . . . . . . . . . . . . . . 22
90 deg. mono . . . . . . . . . . . . . . . . . 22
Dynamic Equalizer . . . . . . . . . . . . . 24
Stereo Enhance . . . . . . . . . . . . . . . 24
Normalizer . . . . . . . . . . . . . . . . . . . 26
MS Decoding . . . . . . . . . . . . . . . . . 26
MS Encoding . . . . . . . . . . . . . . . . . 26
Expander . . . . . . . . . . . . . . . . . . . . . . 28
Compressor . . . . . . . . . . . . . . . . . . . . 30
Limiter . . . . . . . . . . . . . . . . . . . . . . . . 34
Inserts - Post Dynamic
Transmission Limiter. . . . . . . . . . . . 36
Production Limiter . . . . . . . . . . . . . 36
Output
Dither . . . . . . . . . . . . . . . . . . . . . . . 38
Fade . . . . . . . . . . . . . . . . . . . . . . . 38
Tools
Flow. . . . . . . . . . . . . . . . . . . . . . . . 40
Surround Meter . . . . . . . . . . . . . . . 40
Peak-Hold Meter . . . . . . . . . . . . . . 41
Phase Meter. . . . . . . . . . . . . . . . . . 41
Digital I/O . . . . . . . . . . . . . . . . . . . . 42
Calibration Tone . . . . . . . . . . . . . . . 42
Utility . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Reset page . . . . . . . . . . . . . . . . . . . . . 46
The WIZARD . . . . . . . . . . . . . . . . . . . . 47
APPENDIX
Trouble Shooting . . . . . . . . . . . . . . . . . 48
Self test . . . . . . . . . . . . . . . . . . . . . . . . 49
Technical specifications . . . . . . . . . . . 50
Tutorial . . . . . . . . . . . . . . . . . . . . . . . . 51
Glossary . . . . . . . . . . . . . . . . . . . . . . . 53
Note . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Soldering instructions. . . . . . . . . . . . . . 55
Preset list . . . . . . . . . . . . . . . . . . . . . . 57
Optional Master Fader . . . . . . . . . . . . . 59
TC Electronic, Sindalsvej 34, DK-8240 Risskov - [email protected] Rev 2 - SW - V 2.02

1 Connect analog and/or digital I/O and power to the unit.
The DBMAX will adapt to the power being used in your
area without you ha ing to select a oltage.
2 Turn on the POWER switch at the rear, and press the
POWER key on the front.
3 On LCD IN page 1, select analog, S/PDIF or AES/EBU
Input.
4 Press the REF. LEVELS key and set your I/O
le el conditions:
4.1 If you use analog Inputs or Outputs, adjust the analog le el
required for digital full scale by selecting a proper alue for
the In Le el parameter. When a correct In Le el is selected,
the red LEDs on the INPUT meter should ne er light up,
and indication should be in the -18 to -6dB range.
4.2 Your normal operating le el, typically the le el at which you
would want a calibration tone, may be set as Reference
Le el. In a broadcast en ironment, the Reference Le el
would normally be set 18-20dB below your In Le el. If you
only want to relate to digital full scale, turn the Reference
Le el all the way up.
4.3 The Abs.Peak Output setting determines the maximum
instant peak Output le el from the DBMAX. If you work
against digital peak meters or in transmission, the setting
should be spot on. If you work in an en ironment depending
on analog PPM meters, this setting should be 3-4 dB abo e
the maximum le el allowed with the meter. If you work
against VU meters, the setting should be 12-20dB abo e the
0VU le el.
5. Press the WIZARD key and select the type of limiting/
compression you want by using the PARAMETER keys
and the ADJUST wheel.
QUICK START
6. Press the OK key. Play some program material and lea e
the Wizard working while you are playing a soft part and a
loud part of the type of signal the DBMAX will be
processing. 10 seconds of each will do.
7. Press the OK key again, and the DBMAX has loaded a
best fit parameter setting for your application and source
material.
8. If required, go to the COM block in the MAIN PAGE, and
adjust the More/Less setting to suit your taste. Turning the
control to Less makes the unit beha e as a Limiter.
Turning the control to More makes the unit beha e like a
maximizer.
9. No more o ers. Enjoy!
We recommend you read the entire manual before using the DBMAX, but if you’re anxious to get started we suggest
you take the following steps in the described sequence.
4

5
INTRODUCTION
Useful features for Production
Le el settings for a number of Radio and TV stations
5-band parametric EQ insert
Stereo Enhancer insert
90º mono insert
MS Decoding insert
MS Encoding insert
Dynamic EQ and De-esser insert
Production Final Limiter pro iding PPM attack response
Production Final Limiter pro iding adjustable Soft-Clip
Dedicated presets for Film and Post Pro Mastering
Dedicated presets for Production Recording
Dedicated presets for CD Mastering
Useful features for Continuity and Transmission
Final TX Limiter pro iding Emphasis compensated HF limiting
Final TX Limiter pro iding adjustable Soft-Clip
RS485 remote control
90º mono insert
AGC insert
Stereo Enhancer insert
5-band parametric EQ insert
Dynamic EQ and De-esser insert
Dedicated presets for Continuity Limiting
Dedicated presets for Continuity AGC (1-5 bands)
Dedicated presets for gentle Transmission processing
Dedicated presets for aggressi e Transmission processing
General features in the DBMAX version 2.02
Versatile multi-band Compressor/Limiter/Expander with switchable architecture between 1 and 5 bands
Minimum distortion algorithms utilizing 24 and 48 bit processing
New Less/More for control of multi-band compression
Processing at any Sample Rate between 32 and 48kHz
Relay bypass of analog I/O on power-down
Unlock detection of digital Input
Audio bandwidth to 24kHz, or ariable lo-pass filtered for FM transmission
24 bit resolution AD and DA con erters and built in optional Sample Rate con erter
Congratulations on the purchase of your new DBMAX.
We hope that you will have as much pleasure using it as we had making it.
The DBMAX V2.02 is the result of hard work by TC Electronics skilled de elopers, based upon the experience of some of the best
qualified transmission engineers in the business. The DBMAX V2.02 is TC Electronics second generation of broadcast compressors.
Stuffed with all the necessary tools, a strong collection of presets as well as a selection of predefined Le el setups, the DBMAX could be a
difficult unit to operate. But nicely wrapped in TCs award winning highly intuiti e design, you will soon be ready to operate it.
We in ite you to ha e your Input/Output and reference le el specifications included in later software releases. Other DBMAX owners will
then ery easily comply with your specifications when deli ering program material to your station or production house.
For suggestions please contact TC Electronic at: [e-mail]
Please keep informed on the latest updates either via our internet site at www.tcelectronic.com
or contact TC Electronic directly.
