408-35328
18 APR 2023 Rev A
Figure 1: Crimping die and ferrule locator assembly for HVA HD400 ferrules
1 Introduction
The crimping die assembly (Figure 1) is designed to be installed into the modular tool holders listed in Table 1.
The crimping die assembly is designed to crimp HVA HD400 ferrules.
Table 1: Crimping specifications
Crimping die
assembly
Wire size
mm²
Ferrule
part number
Application
specification
Modular
tool holders
2374311-1
2.5
2371242-1
2371243-1
114-160093
2305470-1
4
2371242-2
2371243-1
6
2371242-3
2371243-1
2326378-1
NOTE
Dimensions in this instruction sheet are in millimeters with [inches in brackets]. Figures are for reference only and are not
drawn to scale.
Read these instructions thoroughly before crimping ferrules.
Crimping Die and Ferrule Locator
Assembly for HVA HD400 Ferrules

408-35328
Rev A
2 of 7
2 Description
Each crimping die assembly consists of a crimper, a nest, a terminal stopper, a ferrule locator, and a ferrule
locator assembly (Figure 2).
NOTE
The rear locator and the ferrule locator assembly maintain the ferrule position during the crimping process. They are supplied
pre-assembled to the crimping die.
Figure 2: Components
1
Shank
4
Nest
2
Crimper
5
Terminal stopper
3
Ferrule locator
6
Ferrule locator assembly

408-35328
Rev A
3 of 7
3 Installing the die set and locator assembly
For information concerning die installation, removal, and general performance of each modular tool holder,
refer to the applicable 408 series instruction sheet packaged with the tool holder (Table 2).
Table 2: Instruction sheets
Modular tool holder
Instruction sheet
2305470-1
408-35048
2326378-1
408-35049
Disconnect electrical power before performing maintenance or repair on this equipment.
Disconnect air supply before performing maintenance or repair on this equipment.
To achieve proper orientation of the dies during installation, ensure that the alignment dots are facing in the
direction of the wire clamp on the modular tool holder (Figure 3).
Figure 3: Alignment dots
1
Alignment dots
2
Wire clamp
3
Lever

408-35328
Rev A
4 of 7
4 Crimping
For strip length and specific crimp information for each terminal being crimped using this die assembly, refer to
the application specification listed in Table 1.
CAUTION
If the tool holder is equipped with a crimp height (fine adjust) adjustment, you can avoid damage to the terminator, modular
tool holder, or die assembly by starting at setting A on the crimp disc and incrementally adjusting to the specified crimp height.
If the machine has crimp height/shut height adjustment, refer to the applicable 412 series customer manual for guidance.
1. Assemble the ferrule to the prepared wire assembly according to the 114 series application
specification listed in Table 1.
2. Open the wire clamp by pressing down on the lever (Figure 3).
3. Insert the prepared assembly into the crimping die (Figure 4).
Figure 4: Inserting the assembly into the crimping die

408-35328
Rev A
5 of 7
4. Refer to Figure 5 and verify that:
The outer ferrule butts against the ferrule locator.
The crimped contact is inserted in the terminal block (stopper).
The latch on the contact body is in the pocket of the terminal stopper.
NOTE
The crimped contact must fit within the identified surfaces to ensure proper spacing and orientation (see Figure 4).
Figure 5: Positioning the ferrule

408-35328
Rev A
6 of 7
5. Close the wire clamp to hold the wire in place.
6. Cycle the terminator to complete the crimp.
7. Open the wire clamp to remove the crimped assembly from the tooling.
Figure 6: Closing and opening the wire clamp
5 Inspecting the crimp
For crimp inspection information, refer to the 114 series application specification listed in Table 1 for the ferrule
being crimped.
6 Maintenance and inspection
Each die assembly is inspected before shipment. When it arrives at your facility, inspect it immediately to
ensure that it was not damaged during shipping.
6.1 Daily maintenance
Make each operator aware of (and responsible for) the following daily maintenance requirements:
Remove dust, moisture, and other contaminants with a clean, soft brush or soft, lint-free cloth. Do not
use objects that could damage the dies or tool.
When the dies are not in use, store them in a clean, dry area.
6.2 Periodic inspection
Regular inspections should be performed by quality control personnel. A record of scheduled inspections
should remain with the dies or be supplied to personnel responsible for the dies. Perform at least one
inspection per month. Base your inspection frequency on the amount of use, ambient working conditions,
operator training and skill, and established company standards. Perform the inspection as follows:
1. Remove all contaminants with a clean, soft brush or soft, lint-free cloth. Do not use objects that could
damage the dies.
2. Inspect the crimp area for flattened, chipped, cracked, worn, or broken areas.
3. If damage or abnormal wear is evident, replace the tool or dies. Refer to section Error! Reference s
ource not found., Error! Reference source not found..

408-35328
Rev A
7 of 7
7 Replacement and repair
If the dies are damaged or worn excessively, they must be replaced. Order replacement dies through your TE
representative. You can also order parts by any of the following methods:
Go to TE.com and click the Shop TE Store link at the top of the page.
Call [phone].
Write to:
CUSTOMER SERVICE (038-035)
TE CONNECTIVITY CORPORATION
PO BOX 3608
HARRISBURG PA 17105-3608
For customer repair services, call [phone].
8 Revision summary
Since the last revision of this document, the following changes were made:
Initial release
