Teac CR-H250 User manual

CCRR--HH225500
SERVICE MANUAL
CD Receiver
Effective : October, 2004 S-0130A
NOTES
●PC boards shown are viewed from parts side.
●The parts with no reference number or no parts number in the
exploded views are not supplied.
●As regards the resistors and capacitors, refer to the circuit diagrams
contained in this manual.
●£Parts marked with this sign are safety critical components. They
must be replaced with identical components - refer to the appropriate
parts list and ensure exact replacement.
CONTENTS
1 SPECIFICATIONS ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・2
2 MICROCOMPUTER PIN FUNCTIONS ・・・・・・・・・・・・・・・・・3
3 EXPLODED VIEWS AND PARTS LIST ・・・・・・・・・・・・・・・11
4 PC BOARDS AND PARTS LIST ・・・・・・・・・・・・・・・・・・・・・・13
5 INCLUDED ACCESSORIES ・・・・・・・・・・・・・・・・・・・・・・・・・・・17
For U.K.

1 SPECIFICATIONS
−2−
AMPLIFIER Section
Output Power .............................. 25 W/ch (6 ohms, 0.5 %,1 kHz)
Input Sensitivity................................................ 300 mV/47k ohms
Frequency Response ...................... 20 Hz to 60,000 Hz (+1/-3 dB)
TUNER Section
FM Section
Tuning Range .............. 87.50 MHz to 108.00 MHz (50 kHz steps)
Signal-to-Noise Ratio .............................................. 65 dB (Mono)
60 dB (Stereo)
Presets ...................................................................................... 30
AM Section
Tuning Range .......................... 522 kHz to 1629 kHz (9 kHz steps)
Signal-to-Noise Ratio............................................................ 35 dB
Presets ...................................................................................... 30
DAB Section
Tuning Range ...................................... Band 3, 174 MHz-240 MHz
Input.................................................................. 50 ohms, nominal
Max Signal .................................................................. –3 dBm typ
Sensitivity .................................................................. –96 dBm typ
Adjacent Channel Rejection ............................................ 35 dB typ
Presets ...................................................................................... 10
Audio Output........................................................ Stereo, 2.5 Vp-p
Digital Output .......................................... 24 bit/48 kHz resolution
CD PLAYER Section
Frequency Response .......................... 20 Hz to 20,000 Hz (±2 dB)
Signal-to-Noise Ratio .......................................... more than 85 dB
Wow and Flutter ...................................................... Unmeasurable
GENERAL
Power Requirements............................................ 230 V AC, 50 Hz
Power Consumption .............................................................. 75 W
(standby) .............................................................................. 2 W
Dimension (W x H x D) ................................ 215 x 110 x 359 mm
Weight ................................................................................ 4.4 kg
Standard Accessories
Remote Control Unit (RC-956) x 1
Batteries (AAA) x 2
AM Loop Antenna x 1
FM Lead-type Antenna x 1
DAB Antenna x 1
Owner’s Manual x 1
Warranty Card x 1
•Design and specifications are subject to change without notice.
•Weight and dimensions are approximate.

2 MICROCOMPUTER PIN FUNCTIONS
−3−
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50
75
74
73
72
71
70
69
68
67
66
65
64
63
62
61
60
59
58
57
56
55
54
53
52
51
100 99 98 97969594939291908988878685848382818079787776
P8.4/AIN4
P8.3/AIN3
P8.2/AIN2
P8.1/AIN1/WKUP15
P8.0/AIN0/WKUP14
NC
P6.5/WKUP10/INTCLK
P6.4/NMI
P6.3/INT3/INT5
P6.2/INT2/INT4/DS2
P6.1/INT6/RW
P6.0/INT0/INT1/CLOCK2/8
P0.7/A7/D7
V
DD
V
SS
P0.6/A6/D6
P0.5/A5/D5
P0.3/A3/D3
P0.2/A2/D2
P0.1/A1/D1
P0.0/A0/D0
AS
DS
P0.4/A4/D4
P1.7/A15
A20/P9.6
WAIT/WKUP5/P5.0
WKUP6/WDOUT/P5.1
TXCLK/CLKOUT/P5.4
OCMPA1/P4.2
V
DD
A21/P9.7
WDIN/SOUT/P5.3
DCD/WKUP8/P5.6
V
SS
ICAPB1/OCMPB1/P4.3
SDA/P4.6
SIN/WKUP2/P5.2
RXCLK/WKUP7/P5.5
CLOCK2/P4.1
EXTCLK1/WKUP4/P4.4
ICAPB0/P3.1
ICAPA0/OCMPA0/P3.2
WKUP9/RTS/P5.7
ICAPA1/P4.0
EXTRG/STOUT/P4.5
WKUP1/SCL/P4.7
OCMPB0/P3.3
EXTCLK0/SS/P3.4
MISO/P3.5
P9.5/A19 P9.4/A18 P9.2/A16 HW0SW1 P7.7/AIN15/7/WKUP13 P7.4/AIN12/WKUP3 P9.3/A17 P9.0/RDI RESET P7.6/AIN14/WKUP12 P7.5/AIN13/WKUP11 P7.1/AIN9 P9.1/TDO OSCIN V
SS
P7.3/AIN11 P7.0/AIN8/CK_AF P8.7/AIN7 OSCOUT V
DD
P7.2/AIN10 AV
SS
AV
DD
P8.6/AIN6 P8.5/AIN5
MOSI/P3.6
SCK/WKUP0/P3.7
RW
TOUTA0/P2.2
V
SS
*V
TEST
V
REG
TINPB0/P2.1
TOUTB0/P2.3
V
DD
V
REG
A10/P1.2
TINPA0/P2.0 TINPB1/P2.5
TOUTB1/P2.7
A8/P1.0
A11/P1.3 A12/P1.4
TINPA1/P2.4
TOUTA1/P2.6
A9/P1.1 WKUP6
NC
A13/P1.5 A14/P1.6
* V
TEST
must be kept low in standard operating mode.
ST92F124V1
ST92F124V1
■PIN ASSIGNMENT

−4−
256 bytes
Register File
RAM
4 Kbytes
ST9 CORE
8/16 bits
CPU
Interrupt
Management
MEMORY BUS
RCCU
Ext. MEM.
ADDRESS
DATA
Port0
Ext. MEM.
ADDRESS
Ports
1,9
REGISTER BUS
WATCHDOG
AS
DS
RW
WAIT
NMI
DS2
RW
MISO
MOSI
SCK
SS
A[10:8]
A[21:11]
A[7:0]
D[7:0]
ST. TIMER
SPI
SDA
SCL
I
2
C BUS
FLASH
128 Kbytes
WDOUT
HW0SW1
STOUT
Fully
Prog.
I/Os
P0[7:0]
P1[7:3]
P1[2:0]
P2[7:0]
P3[7:4]
P3[3:1]
P4[7:4]
P4[3:0]
P5[7:0]
P6[5:2,0]
P6.1
P7[7:0]
P8[7:0]
P9[7:0]
MF TIMER 0
TINPA0
TOUTA0
TINPB0
TOUTB0
TINPA1
TOUTA1
TINPB1
TOUTB1
INT[6:0]
WKUP[15:0]
MF TIMER 1
E
3 TM
1 Kbyte
OSCIN
OSCOUT
RESET
CLOCK2/8
INTCLK
CK_AF
ADC
AV
DD
AV
SS
AIN[15:8]
AIN[7:0]
EXTRG
V
REG
VOLTAGE
REGULATOR
The alternate functions (Italic characters) are mapped on Port 0, Port 1, Port2, Port3, Port4, Port5, Port6, Port7,
Port8 and Port9.
ICAPA0
OCMPA0
ICAPB0
OCMPB0
EXTCLK0
ICAPA1
OCMPA1
ICAPB1
OCMPB1
EXTCLK1
EF TIMER 0
EF TIMER 1
SCI M
TXCLK
RXCLK
SIN
DCD
SOUT
CLKOUT
RTS
SCI A RDI
TDO
■BLOCK DIAGRAM

−5−
PIN No PIN Name I/O
1 SM_CE O
2 VFD_BLK O
3 DAB_DIN I
4 DAB_CLK O
5 DAB_DOUT O
6NC -
7NC -
8STANBY O
9 F_MUTE O
10 NC -
11 OPTION1 -
12 OPTION2 -
13 OPTION3 -
14 GND -
15 VDD1 -
16 OPTION4 -
17 RTC_DATA I/O
18 RTC_CLK O
19 RTC_P O
20 F_STB O
21 NC -
22 NC -
23 NC -
24 NC -
25 NC -
26 NC -
27 NC -
28 V_REG -
29 NC -
30 PROTECT I
31 SP_ON O
32 HP_IN I
33 V_STB O
34 T_MUTE O
35 V_CLK O
36 V_DATA O
37 BACK_UP I
38 VSS2 -
39 VDD2 -
40 V_REG2 -
DAB Data Output Port
No Connection
No Connection
Stanby LED On Control Port (Active "H")
GND
No Connection
No Connection
No Connection
No Connection
No Connection
Stabiliztion capacitor for internal voltage regulator.
No Connection
Function STB control port
Function Mute Port (Active "H")
Real Time Clock I.C_Square wave out port
FIP Driver(IC42) Chip enable Port
VFD Control Port
DAB Data Input Port
Function
DAB Data Clock Port
Real Time Clock I.C_Clock port
GND Port
Power Supply Port
Option port
Real Time Clock I.C_Data port
Volume IC(IC91) Clock output port
Volume IC(IC91) Data output port
No Connection
No Connection
BACKUP mode control port
No Connection
Power Supply port
Stabiliztion capacitor for internal voltage regulator.
Speaker On port
Headphone input control port
Volume IC(IC91) STB port
Tuner Mute port
Option port
Protect Control port (Active "L")
■PIN FUNCTIONS

−6−
PIN No PIN Name I/O
42 CD_OPEN_M O
43 CD_RW O
44 CD_CCE O
45 CD_BUCK O
46 NC -
47 NC -
48 CD_RESET O
49 CD_POWER O
50 CD_STBY O
51 NC -
52 NC -
53 NC -
Open Motor control port
CD Control Interface
CD DSP IC Chip enable port (Active "L")
CD DSP IC Clock port
CD Reset output port (Active "L")
CD Power control port
CD Stanby control port
No Connection
Function
No Connection
No Connection
No Connection
No Connection
54 CD_LIMIT_SW I
55 CD_CLOSE_SW I
56 CD_OPEN_SW I
57 CD_BUS3 I/O
58 CD_BUS2 I/O
59 CD_BUS1 I/O
60 CD_BUS0 I/O
61 VSS3 -
62 VDD3 -
63 CD_CLOSE_M O
64 BUS_IN I
65 REMOTE I
66 RDS_CLK I
67 NC -
68 NC -
69 BUS_OUT O
70 NC -
71 KEY2 I
72 KEY1 I
73 NC -
74 JOG1 I
75 JOG2 I
76 NC -
77 NC -
78 NC -
79 VDD4 -
80 VSS4 -
81 POWER_H O
JOG Data Input port(Master Volume)
No Connection
No Connection
No Connection
System remote Output port
KEY Data input port
No Connection
Remote Data input port
RDS Clock port
GND
Power Supply port
GND
Power on control port (Active "H")
No Connection
No Connection
No Connection
Close Motor control port
System remote Input port
CD Close Switch input port
CD Limit Switch input port
CD_BUS Interface port
CD Open Switch input port
Power Supply port
41 VTEST - GND

−7−
PIN No PIN Name I/O Function
83 P/F_CLK O
84 PLL_DIN I
85 PLL_CE O
86 TUNED_IN I
87 STEREO_IN I
88 RDS_DATA I
89 VSS5 -
90 VDD5 -
91 OSCIN -
92 OSCOUT -
93 RESET I
94 HWOSW1 -
95 SM_DATA0 O
96 SM_DATA1 O
97 SM_DATA2 O
98 SM_DATA3 O
99 SM_CLK O
100 SM_RESET O
FIP Driver Clock output port
FIP Driver Reset port
Reset Input port
Watchdog option port
RDS Data input port
GND
Power Supply port
4MHz Crystal Connection port
PLL/FUNCTION Clock Input port
PLL Data input port
FIP Data input/output port
PLL Chip enable port
Tuner Module Tuned control port
Tuner Module Stereo control port
82 P/F_DATA O PLL/FUNCTION Data Input port

−8−
P1.7 P1.6 P1.5 P1.4 P1.3 P1.2 P1.1 P1.0
P0.7/PG7
P0.6/PG6 P0.5/PG5 P0.4/PG4 P0.3/PG3 P0.2/PG2 P0.1/PG1 P0.0/PG0
P2.7/TAOUT
P2.6/TACAP
P2.5/TACK
P2.4/TBPWM
P2.3/DAOUT
P2.2/SCK
P2.1/SI
P2.0/SO
P5.7
P5.6/SDAT
P5.5/SCLK
VDD1
VSS1
XOUT
XIN
TEST
P5.4
P5.3/RxD0
RESETB
P5.2/TxD0
P5.1/RxD1
P5.0/TxD1
P3.7/TCOUT1
P3.6/TCOUT0
(80-QFP-1420C)
64
63
62
61
60
59
58
57
56
55
54
53
52
51
50
49
48
47
46
45
44
43
42
41
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80
25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
P3.5/T1OUT1 P3.4/T1OUT0
P3.3/T1CAP1 P3.2/T1CAP0
P3.1/T1CK1 P3.0/T1CK0
P4.7/INT7 P4.6/INT6 P4.5/INT5 P4.4/INT4 P4.3/INT3 P4.2/INT2 P4.1/INT1 P4.0/INT0
P7.7/ADC7 P7.6/ADC6
P8.0
P8.1
P8.2
P8.3
P8.4/INT8
P8.5/INT9
P6.0
P6.1
P6.2
P6.3
P6.4
VDD2
VSS2
P6.5
P6.6
P6.7
P7.0/ADC0
P7.1/ADC1
P7.2/ADC2
P7.3/ADC3
AVSS
AVREF
P7.4/ADC4
P7.5/ADC5
S3C84BB/F84BB
S3F84BB
■PIN ASSIGNMENT

−9−
I/O Port and Interrupt Control
SAM88RC CPU
64K-Byte
ROM
2064-Byte
RAM
OSC/RESETB
8-Bit
Basic Timer
8-Bit
Timer
/CounterA,B
8-Bit
Timer/
CounterC0,C1
16-Bit
Timer
/Counter10,11
Port 0 Port 1A/D
Port 2 P2.0-P2.7
XIN
XOUT
RESETB
P2.7/TAOUT
P2.6/TACAP
P2.5/TACK
P3.6/TCOUT1
P2.4/TBOUT
P3.4/T1OUT0
P1.0-P1.7P0.0-P0.7 AVREF AVSS
Port 3 P3.0-P3.7
Port 4 P4.0-P4.7/
INT0~INT7
Port 5 P5.0-P5.7
Port 6 P6.0-P6.7
SIO/
UART0,1
PG
P3.7/TCOUT0
P0.0~P0.7/
PG0~PG7
P3.2/T1CAP0
P3.0/T1CK0
P3.5/T1OUT1
P3.3/T1CAP1
P3.1/T1CK1
P2.2/SCK
P2.1/SI
P2.0/SO
P5.3/RXD0
P5.2/TXD0
P5.1/RXD1
P5.0/TXD1
Port 8 Port 7D/A
P7.0-P7.7/
ADC0~ADC7
P8.0-P8.5/
INT8,INT9
P2.3/
DAOUT
■BLOCK DIAGRAM

−10−
PIN No. NAME I/O DESCRIPTION
5 VFD_CS O VFD STB port
6 VFD_CLK O VFD Clock port
8 VFD_DATA O VFD data port
10 DATA I UPDATE data port
11 CLK I UPDATE clock port
12 VDD 1 - Power input port
13 VSS 1 - GND
14 X OUT -
15 X IN -
16 TEST I Pull - down register connected internally
19 VFD_RESET I VFD Reset port
27 DATA 3 I FIP data in/out port
28 DATA 2 I
29 DATA 1 I
30 DATA 0 I FIP data output port
31 CS I FIP driver IC(IC42) chip enable port
32 CLK I FIP driver IC(IC42) clock in/out port
43 AVREF - A/D converter reference voltage
44 AVSS - A/D converter ground
52 VSS 2 - Power input port
53 VDD 2 - GND
10MHz Crystal Connection port
FIP data input port
■PIN FUNCTIONS

−11−
3
1
2
4
5
6
7
8
9
10
11
11
12 13
17
14
15
15
16
17
18
19
19
20
21
22
23
24
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
41
40
42
42
43
44
44
3 EXPLODED VIEWS AND PARTS LIST

−12−
EXPLODED VIEW LIST
REF.NO. PARTSNO. DESCRIPTION REMARKS
1CGR1A345M7ZG5 ORNAMENT,DOOR
2CGU1A347Z WINDOW,FIP
3KGB1A047Z BADGE,TEAC
4CGK1A098YA VOLUMEKNOBASSY
5CGR1A346MBC22 ORNAMENT,RING
6CKM1A144YC35 PANEL,FRONT
7CGL1A133 INDICATOR,STANDBY
8CGW1A386M7ZG5 PANEL,SUB
9CBT1A495M7G5 CAP,STANDBY
10 CBT1A483 KNOB,STANDBY
11 CBT1A493MBC22 KNOB,CPS
12 CBT1A942M7G5 KNOB,MODE
13 CBT1A943M7ZG5 KNOB,PLAY
14 HFLHCA‑17SM02T FIP
15 CMD1A468 BRACKET,FLT
16 CMD1A376 SUPPORT,LED
17 COP11721B PCB,MAINASSY
18 CJDKSL2130CCM CDSINGLEMECH
19 KMH1A092 SUPPORT,PCB
20 CKL2A055H45 FOOT
21 KHG1A050Y CUSHION,FOOT
22 CUA1A248 CHASSIS,BOTTOM
23 CMD1A395 BRACKET,PCB
24 CHE1A030 HOLDER,PCB
25 CMD1A530 BRACKET,PCB(A)
26 CMY1A233 HEATSINK
27 COP11720B PCB,POWERASSY
28£CLT5P040ZE TRANS,POWER
29 COP11720B PCB,POWERASSY
30 CMD1A531 BRACKET,PCB
31 COP11767C PCB,CDASSY
32 COP11721B PCB,MAINASSY
33 COP11721B PCB,MAINASSY
34 CNVMB114MA18L TUNERMODULE(EUR)
35 COP11720B PCB,POWERASSY
36 CKF2A282X PANEL,REAR
37£KHR1A028 BUSHING,ACCORD
38£CJA2E045ZA CORD,POWER
39 CKC1B156S35 CABINET,TOP
40 CGX1A361 SHEET,HIGH
41 CGX1A362 SHEET,LOW
42 KMC1A245 SHIELDCUSHION
43 HNVFS2020VENICE DABMODULE,FS2020VENICE1.1
44 CMH1A226 SUPPORT,PCB
F751£KBA2C2000TLEZ FUSE
CLZ9W003Z FERRITERING,29X7.7X19
CLZ9Z028Z FERRITECORE,21.2X6.4X12.7
CWC1F1A16A130A CARDCABLE,16P
CWC1C4A17B070B CARDCABLE,17P
CWC1B2A17A080B CARDCABLE,17P
CWC1C4A17B200B CARDCABLE,17P
CWC1B2A23A070B CARDCABLE,23P
CWC1B2A23A100B CARDCABLE,23P

−13−
4 PC BOARDS AND PARTS LIST
MAIN PCB

−14−
POWER PCB

CD PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
COP11767C PCB,CDASSY
CUP11767Z PCB,CD
CN10 KJP05GA19ZM WAFER,MOLEX53014‑0510
CN11 KJP06GA19ZM WAFER,MOLEX53014‑0610
CN12 KJP16GB113ZG WAFER,16P
CN13 KJP17GB116ZG WAFER,GF120‑17S‑LS
D102 HVD1SS133MT DIODE,1SS133T‑77
IC10 HVITC9462F IC,TC9462F
IC12 HVITA2153FN IC,TA2153FN
IC13 HVITA2125AF IC,TA2125AF
IC15£HVIKA78L05AZT IC,KA78L05AZT
L100 HLQ02C100KT COIL,AXAIL
Q100 HVTKTA1266YT TR,KTA1266Y
X101 HOX16934E120C CRYSTAL,16.934MHZ
MAIN PCB ASSY (GATHER)
REF.NO. PARTSNO. DESCRIPTION
COP11721B PCB,MAINASSY
CUP11721Y PCB,MAIN
BK81 CMD1A376 SUPPORT,LED
BK82 CMD1A468 BRACKET,FLT
BK83 CMD1A468 BRACKET,FLT
BN16 KJP23GA117ZG WAFER,GF102‑23S‑TS
C410 BCES0HD104 C,GOLDEECS0HD104V
CN15 KJP23GA117ZG WAFER,GF102‑23S‑TS
CN16 KJP23GA117ZG WAFER,GF102‑23S‑TS
CN17 CJP04GA19ZY WAFER,4P00906‑0027
CN18 CJP04GA19ZY WAFER,4P00906‑0027
CN20 CJP04GA19ZY WAFER,4P00906‑0027
CN23 CJP02GA19ZY WAFER,2P
CN25 CJP06GA19ZY WAFER,6P
CN26 CJP07GA19ZY WAFER,7P
CN61 KJP17GA117ZG WAFER,GF102‑17S‑TS
D401 HVD1SS133MT DIODE,1SS133T‑77
D403 HVD1SS133MT DIODE,1SS133T‑77
D404 HVD1SS133MT DIODE,1SS133T‑77
D405 HVD1SS133MT DIODE,1SS133T‑77
D406 HVD1SS133MT DIODE,1SS133T‑77
D407 HVDMTZJ4.3CT DIODE,ZENERMTZJ4.3C
D408 HVD1SS133MT DIODE,1SS133T‑77
D409 HVD1SS133MT DIODE,1SS133T‑77
D801 HVD342YCTB7T089 LED,YELLOWSLR342YCTB7
FIP2 HFLHCA‑17SM02T FIP
IC41 HVIST92F124V1T6 IC,ST92F124V1T6
IC42 HVIS3F84BB IC,S3F84BB
IC43 HVIDS1307Z IC,DS1307Z
IC44 HVIRE5VL28CATZ IC,RE5VL28CATZ
MAIN PCB ASSY (GATHER)
REF.NO. PARTSNO. DESCRIPTION
IC51 HVILC75343M IC,LC75343M
IC52 HVITC9163AF IC,TC9163AF
IC53 HVINJM2068MDTE1 IC,NJM2068MD‑TE1
JK21 CJJ4M046Z JACK,BOARD
JK22 CJJ4P014W JACK,IN/OUT
JK23 CJJ4R019W TERMINAL,IN/OUT
JK61 HJJ2E027Z JACK,HEADPHONE
L401 HLQ02C220KT COIL,22UHK
L402 KLZ9H001Z BEAD,CORE
Q401 HVTKRC107MT TR,KRC107M
Q402 HVTKRA107MT TR,KRA107M
Q403 HVTKRA107MT TR,KRA107M
Q404 HVTKSB811YT TR,KSB811Y
Q405 HVTKRC107MT TR,KRC107M
Q406 HVTKRC107MT TR,KRC107M
Q407 HVTKRC107MT TR,KRC107M
Q408 HVTKRC107MT TR,KRC107M
Q409 HVTKRC107MT TR,KRC107M
Q501 HVTKTD1302T TR,KTD1302
Q502 HVTKTD1302T TR,KTD1302
Q503 HVTKRA107MT TR,KRA107M
Q504 HVTKRA107MT TR,KRA107M
Q505 HVTKTD1302T TR,KTD1302
Q506 HVTKTD1302T TR,KTD1302
RC61 KRVHIM602H32 SENSOR,REMOCON
S801 CST1A012ZT SW,TACT00802‑0005
S802 CST1A012ZT SW,TACT00802‑0005
S803 CST1A012ZT SW,TACT00802‑0005
S804 CST1A012ZT SW,TACT00802‑0005
S805 CST1A012ZT SW,TACT00802‑0005
S806 CST1A012ZT SW,TACT00802‑0005
S807 CST1A012ZT SW,TACT00802‑0005
S808 CST1A012ZT SW,TACT00802‑0005
S809 CST1A012ZT SW,TACT00802‑0005
S810 CST1A012ZT SW,TACT00802‑0005
S811 CST1A012ZT SW,TACT00802‑0005
S812 CST1A012ZT SW,TACT00802‑0005
S813 CST1A012ZT SW,TACT00802‑0005
S814 CST1A012ZT SW,TACT00802‑0005
VR61 HSR2A011Z VR,ENCODEREC16B243040F
WF10 CJP03GA19ZY WAFER,3P
WF13 KJP17GA115ZG WAFER,GF120‑17S‑TS
WF61 KJP17GB113ZG WAFER
WF64 KJP17GA115ZG WAFER,GF120‑17S‑TS
X401 HOX04000E150C CRYSTAL,4MHZ
X402 HOX10000E220TF CRYSTAL
X403 HOX00032K120I CRYSTAL,32.768KHZ
−15−

POWER PCB ASSY (GATHER)
REF.NO. PARTSNO. DESCRIPTION
COP11720B PCB,POWERASSY
CUP11720Y PCB,POWER
CMC1A253 PLATE,EARTH
CMH1A226 SUPPORT,PCB
HNVFS2020VENICE DABMODULE,FS2020VENICE1.1
BK71 CMD1A387 BRACKET,PCB
BK72 CMD1A387 BRACKET,PCB
BK73 CMD1A387 BRACKET,PCB
BK74 CMD1A387 BRACKET,PCB
BN21 KJP06HB60ZY HOUSING,BMH250
BN41 CJP44TT153ZY PINHEADER,DAB2025
BN42 KJP02TT155ZY PINHEADER
C225£HCEA1VH332E C,ELECT3300UF35V
C226£HCEA1VH332E C,ELECT3300UF35V
C227£HCEA1EH222E C,ELECT2200UF25V
C237£CCEA1EH222E C,ELECT2200UF25V
C238£CCEA1EH222E C,ELECT2200UF25V
C247£CCEA1CH221T C,ELECT220UF16V
C250£KCKDKS472ME C,CERAMIC0.0047UF2.5KV
C253£HCEA1EH471T C,ELECT470UF25V
C260£CCEA1CH221T C,ELECT220UF16V
CN14 CJP05GA19ZY WAFER,5P
CN19 CJP04GA01ZY WAFER,4P
CN21 KJP06GA63ZY WAFER,BMW250
CN22 CJP02GA19ZY WAFER,2P
CN91 KJP02KA060ZY WAFER
CN92 KJP02GA89ZM WAFER,MOLEX35328‑02
CN93 CJP06GA01ZY WAFER,6P
CN95 KJP03GA90ZM WAFER,MOLEX35313‑0310
D202 HVDMTZJ6.2BT DIODE,ZENERMTZJ6.2B
D203 HVDMTZJ9.1BT DIODE,ZENERMTZJ9.1B
D204£BVDPBU604F DIODE,BRIDGEPBU604F
D205£KVD1N4003SRT DIODE,1N4003
D206£KVD1N4003SRT DIODE,1N4003
D207£KVD1N4003SRT DIODE,1N4003
D208£KVD1N4003SRT DIODE,1N4003
D209£KVD1N4003ST DIODE,1N4003
D210 HVDMTZJ33BT DIODE,ZENERMTZJ33B
D211 HVDMTZJ2.7BT DIODE,ZENERMTZJ2.7B
D212 HVD1SS133MT DIODE,1SS133T‑77
D213£KVD1N4003ST DIODE,1N4003
D214£KVD1N4003ST DIODE,1N4003
D215£KVD1N4003ST DIODE,1N4003
D216£KVD1N4003ST DIODE,1N4003
D218 HVD1SS133MT DIODE,1SS133T‑77
D219 HVDMTZJ6.8BT DIODE,ZENERMTZJ6.8B
D220 KVD1N4003SRT DIODE,1N4003
D221£KVD1N4003ST DIODE,1N4003
D222£KVD1N4003SRT DIODE,1N4003
D223£KVD1N4003SRT DIODE,1N4003
D224 HVDMTZJ4.3CT DIODE,ZENERMTZJ4.3C
D601 HVD1SS133MT DIODE,1SS133T‑77
D602 HVD1SS133MT DIODE,1SS133T‑77
D603 HVD1SS133MT DIODE,1SS133T‑77
D604 HVD1SS133MT DIODE,1SS133T‑77
POWER PCB ASSY (GATHER)
REF.NO. PARTSNO. DESCRIPTION
ET91 CNE75 PLATE,EARTH
F751 KJCFC5S HOLDER,FUSE
IC21 BVI74HC4066D IC,74HC4066D
IC22 BVISTK442‑050 IC,STK442‑050
IC91 CMY1A043 HEATSINK
IC91£HVINJM7812FA IC,NJM7812FA
IC92 CMY1A025 HEATSINK
IC92£HVINJM7912FA IC,NJM7912FA
IC93 CMY1A043 HEATSINK
IC93£HVINJM7805FA IC,NJM7805FA
IC94 CMY1A025 HEATSINK
IC94£HVINJM7805FA IC,NJM7805FA
IC95£HVIRC1117ST IC,RC1117ST
JK45 CJJ4N064Z JACK,BOARD
JK46 HJSTOTX179L MODULE,OPTICALTOTX179L
JK47 CJJ3G012Z ANT,TERMINALRF‑055A
L201 HLQ02C2R7KT COIL,2.7UHK
L601 CLEY0R5KAK COIL,SPEAKER0.5UHK
L602 CLEY0R5KAK COIL,SPEAKER0.5UHK
Q201 HVTKRC107MT TR,KRC107M
Q202 CMY2A048 HEATSINK
Q202£HVTKTC2026Y TR,KTC2026Y
Q203£HVTKTC2026Y TR,KTC2026Y
Q204 HVTKRA107MT TR,KRA107M
Q205 HVTKRC107MT TR,KRC107M
Q206£HVTKSC2316YT TR,KSC2316Y
Q207 HVTKRC107MT TR,KRC107M
Q208£HVTKSC2316YT TR,KSC2316Y
Q209 HVTKRA107MT TR,KRA107M
Q210 HVTKRC107MT TR,KRC107M
Q211£HVTKSC2316YT TR,KSC2316Y
Q601 KVTKSA1175YT TR,KSA1175Y
Q602 KVTKSA1175YT TR,KSA1175Y
Q603 HVTKRC107MT TR,KRC107M
R211£CRG1ANJ331H R,METAL330OHM1WJ
R219£KRQ1AJR47H R,FUSE0.47OHM1WJ
R220£KRQ1AJR47H R,FUSE0.47OHM1WJ
R305£CRG1ANJ391H R,METAL390OHM1WJ
R306£CRG1ANJ391H R,METAL390OHM1WJ
R609£CRG1ANJ101H R,METAL100OHM1WJ
R610£CRG1ANJ101H R,METAL100OHM1WJ
R613£CRF5EKR22H R,CEMENT0.22OHM5WK
R614£CRF5EKR22H R,CEMENT0.22OHM5WK
RY71£HSL1A008ZE RELAY,SDT‑S‑112DMR
RY72 HSL4A004ZU RELAY,OSA‑SS‑212DM3
SP71 CJJ5P012Z TERMINAL,SPEAKER
T701£CLT5I003ZE TRANS,SUB
WF15 KJP23GA117ZG WAFER,GF102‑23S‑TS
−16−

5 INCLUDED ACCESSORIES
−17−
INCLUDED ACCESSORIES
REF.NO. PARTSNO. DESCRIPTION REMARKS
CQX1A941Z OWNER'SMANUAL
CARTCRH250 REMOCONTRANSMITTERASSY
HABAAAM1.5V BATTERY
CSA1A018Z FM1POLEANT
CSA1A020Z AMLOOPANT
CSA272 ANT,DABT
