Teac LT-1 User manual

9A09854000
LT-1
CD Receiver
OWNER’S MANUAL
Z
?

2
Important Safety Instructions
CAUTION
<Read all of these Instructions.
<Save these Instructions for later use.
<Follow all Warnings and Instructions marked on the audio
equipment.
1) Read Instructions — All the safety and operating instructions
should be read before the product is operated.
2) Retain Instructions —The safety and operating instructions
should be retained for future reference.
3) Heed Warnings —All warnings on the product and in the
operating instructions should be adhered to.
4) Follow Instructions —All operating and use instructions
should be followed.
5) Cleaning —Unplug this product from the wall outlet before
cleaning. Do not use liquid cleaners or aerosol cleaners. Use a
damp cloth for cleaning.
6) Attachments —Do not use attachments not recommended by
the product manufacturer as they may cause hazards.
7) Water and Moisture —Do not use this product near water —
for example, near a bath tub, wash bowl, kitchen sink, or laundry
tub; in a wet basement; or near a swimming pool; and the like.
8) Accessories —Do not place this product on an unstable cart,
stand, tripod, bracket, or table. The product may fall, causing
serious injury to a child or adult, and serious damage to the
product. Use only with a cart, stand, tripod, bracket, or table
recommended by the manufacturer, or sold with the product. Any
mounting of the product should follow the manufacturer’s
instructions, and should use a mounting accessory recommended
by the manufacturer.
9) A product and cart combination should be moved
with care. Quick stops, excessive force, and uneven
surfaces may cause the product and cart
combination to overturn.
10) Ventilation —Slots and openings in the cabinet are provided
for ventilation and to ensure reliable operation of the product and
to protect it from overheating, and these openings must not be
blocked or covered. The openings should never be blocked by
placing the product on a bed, sofa, rug, or other similar surface.
This product should not be placed in a built-in installation such as
a bookcase or rack unless proper ventilation is provided or the
manufacturer’s instructions have been adhered to.
11) Power Sources —This product should be operated only from
the type of power source indicated on the marking label. If you
are not sure of the type of power supply to your home, consult
your product dealer or local power company. For products
intended to operate from battery power, or other sources, refer to
the operating instructions.
12) Grounding or Polarization —This product may be equipped
with a polarized alternating-current line plug (a plug having one
blade wider than the other). This plug will fit into the power outlet
only one way. This is a safety feature. If you are unable to insert
the plug fully into the outlet, try reversing the plug. If the plug
should still fail to fit, contact your electrician to replace your
obsolete outlet. Do not defeat the safety purpose of the polarized
plug.
13) Power-Cord Protection —Power-supply cords should be
routed so that they are not likely to be walked on or pinched by
items placed upon or against them, paying particular attention to
cords at plugs, convenience receptacles, and the point where
they exit from the product.
14) Outdoor Antenna Grounding —If an outside antenna or
cable system is connected to the product, be sure the antenna or
cable system is grounded so as to provide some protection
against voltage surges and built-up static charges. Article 810 of
the National Electrical Code, ANSI/NFPA 70, provides information
with regard to proper grounding of the mast and supporting
structure, grounding of the lead-in wire to an antenna discharge
unit, size of grounding conductors, location of antenna-discharge
unit, connection to grounding electrodes, and requirements for
the grounding electrode.
Note to CATV system installer:
This reminder is provided to call the CATV system installer’s
attention to Section 820-40 of the NEC which provides guidelines
for proper grounding and, in particular, specifies that the cable
ground shall be connected to the grounding system of the
building, as close to the point of cable entry as practical."
15) Lightning —For added protection for this product during a
lightning storm, or when it is left unattended and unused for long
periods of time, unplug it from the wall outlet and disconnect the
antenna or cable system. This will prevent damage to the product
due to lightning and power-line surges.
16) Power Lines —An outside antenna system should not be
located in the vicinity of overhead power lines or other electric
light or power circuits, or where it can fall into such power lines
or circuits. When installing an outside antenna system, extreme
care should be taken to keep from touching such power lines or
circuits as contact with them might be fatal.
17) Overloading —Do not overload wall outlets, extension cords,
or integral convenience receptacles as this can result in risk of
fire or electric shock.
18) Object and Liquid Entry —Never push objects of any kind into
this product through openings as they may touch dangerous
voltage points or short-out parts that could result in a fire or
electric shock. Never spill liquid of any kind on the product.
19) Servicing —Do not attempt to service this product yourself
as opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified service
personnel.
20) Damage Requiring Service —Unplug this product from the
wall outlet and refer servicing to qualified service personnel
under the following conditions:
a ) when the power-supply cord or plug is damaged.
b ) if liquid has been spilled, or objects have fallen into the
product.
c ) if the product has been exposed to rain or water.
d)if the product does not operate normally by following the
operating instructions. Adjust only those controls that are
covered by the operating instructions as an improper adjustment
of other controls may result in damage and will often require
extensive work by a qualified technician to restore the product to
its normal operation.
e) if the product has been dropped or damaged in any way.
f)when the product exhibits a distinct change in performance _
this indicates a need for service.
21) Replacement Parts —When replacement parts are required,
be sure the service technician has used replacement parts
specified by the manufacturer or have the same characteristics
as the original part. Unauthorized substitutions may result in fire,
electric shock, or other hazards.
22) Safety Check —Upon completion of any service or repairs to
this product, ask the service technician to perform safety checks
to determine that the product is in proper operating condition.
23) Wall or Ceiling Mounting —The product should be mounted
to a wall or ceiling only as recommended by the manufacturer.
24) Heat —The product should be situated away from heat
sources such as radiators, heat registers, stoves, or other
products (including amplifiers) that produce heat.
ANTENNA
LEAD IN
WIRE
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250. PART H)
NEC - NATIONAL ELECTRICAL CODE
ELECTRIC
SERVICE
EQUIPMENT
Example of Antenna Grounding
as per National Electrical
Code, ANSI/NFPA 70
GROUND
CLAMP

3
Y
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK). NO USER-
SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
E
R
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of
uninsulated "dangerous voltage" within the
product’s enclosure that may be of
sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
WARNING : TO PREVENT FIRE OR SHOCK
HAZARD, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
AC POWER CORD CONNECTION
CAUTION:
TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE
OF PLUG TO WIDE SLOT, FULLY INSERT.
CORDE DE CONNEXION CA
ATTENTION:
POUR ÉVITER LES CHOCS ÉLECTRIQUES,
INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE
DANS LA BORNE CORRESPONDANTE DE LA PRISE
ET POUSSER JUSQU’AU FOND.
For CANADA
Pour le CANADA
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference will
not occur in a particular installation. If this
equipment does cause harmful interference to radio
or television reception, which can be determined by
turning the equipment off and on, the user is
encouraged to try to correct the interference by one
or more of the following measures:
•Reorient or relocate the equipment and/or the
receiving antenna.
•Increase the separation between the equipment
and receiver.
•Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
•Consult the dealer or an experienced radio/TV
technician for help.
CAUTION
Changes or modifications to this equipments not
expressly approved by TEAC CORPORATION for
compliance will void the user's warranty.
For U.S.A.
CAUTION
<DO NOT REMOVE THE PROTECTIVE HOUSING
USING SCREWDRIVER.
<USE OF CONTROLS OR ADJUSTMENTS OR
PERFORMANCE OF PROCEDURES OTHER THAN
THOSE SPECIFIED HEREIN MAY RESULT IN
HAZARDOUS RADIATION EXPOSURE.
<IF THIS PRODUCT DEVELOPS TROUBLE, MAKE A
CONTACT WITH OUR SERVICEMAN, AND DO NOT
USE THE PRODUCT IN A TROUBLED STATE.
This product has been designed and manufactured
according to FDA regulations “title 21, CFR, chapter 1,
subchapter J, based on the Radiation Control for Health
and Safety Act of 1968“, and is classified as class 1
laser product. There is not hazardous invisible laser
radiation during operation because invisible laser
radiation emitted inside of this product is completely
confined in the protective housings.
The label required in this regulation is shown ①.
For U.S.A.
①
Optical pickup :
Type : CMS-B31VG6
Manufacturer : SAMSUNG
Laser output : 0.5mW on the objective lens
Wavelength : 760 - 800 nm (rear panel of the unit)

4
Contents
Thank you for choosing TEAC. Read this manual
carefully to get the best performance from this unit.
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . 2
Before Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Compact Disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Names of Each Control . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Remote Control Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Reset Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
CD
Playing a CD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Programmed Playback . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Repeat Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Shuffle Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
TUNER
Listening to the Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
How to Preset Stations . . . . . . . . . . . . . . . . . . . . . . . . . . 15
How to select Preset Stations . . . . . . . . . . . . . . . . . . . . 15
Clock Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Sleep Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Before Use
Read this before operation
<As the unit may become warm during operation,
always leave sufficient space around the unit for
ventilation.
<The voltage supplied to the unit should match the
voltage as printed on the rear panel. If you are in
any doubt regarding this matter, consult an
electrician.
<Choose the installation location of your unit
carefully. Avoid placing it in direct sunlight or close
to a source of heat. Also avoid locations subject to
vibrations and excessive dust, heat, cold or
moisture.
<Do not place the unit on any high heat-producing
units like your amplifier/receiver.
<Do not use the unit in the hot place (over 85°F/30°C).
<Do not open the cabinet as this might result in
damage to the circuitry or electrical shock. If a
foreign object should get into the set, contact your
dealer or service agency.
<When removing the power plug from the wall outlet,
always pull directly on the plug, never yank the
cord.
<To keep the laser pickup clean, do not touch it, and
do not forget to close the flap lid when not using the
CD player.
<Do not attempt to clean the unit with chemical
solvents as this might damage the finish. Use a
clean, dry cloth.
<Keep this manual in a safe place for future
reference.
DO NOT MOVE THE UNIT DURING CD PLAYBACK
During playback, the disc rotates at high speed. Do
NOT lift or move the unit during playback. Doing so
may damage the disc.
WHEN MOVING THIS UNIT
When changing places of installation or packing the
unit for moving, be sure to remove the disc. Then,
press the power switch to turn the power off, and
disconnect the power cord. Moving this unit with the
disc loaded may result in damage to this unit.
Beware of condensation
When the unit (or a disc) is moved from a cold to a
warm place, or used after a sudden temperature
change, there is a danger of condensation; vapor in
the air could condense on the internal mechanism,
making correct operation impossible. To prevent
this, or if this occurs, leave the unit for one or two
hours with the power turned on. The unit will
stabilize at the temperature of its surroundings.
Maintenance
If the surface of the unit gets dirty, wipe with a soft
cloth or use diluted neutral cleaning liquid. Be sure
to remove any fluid completely. Do not use thinner,
benzine or alcohol as they may damage the surface
of the unit.
CAUTION
The product shall not be exposed to dripping or
splashing and that no object filled with liquids, such
as vases, shall be placed on the product.
Do not install this equipment in a confined space
such as a book case or similar unit.

5
Compact Disc
<Never use such chemicals as record sprays,
antistatic sprays or fluid, benzine or thinner to clean
the discs. Such chemicals will do irreparable
damage to the disc's plastic surface.
<Discs should be returned to their cases after use to
avoid dust and scratches that could cause the laser
pickup to "skip."
<Do not expose discs to direct sunlight or high
humidity and temperature for extended periods.
Long exposure to high temperatures will warp the
disc.
<CD-R discs are more sensitive to the effects of heat
and ultraviolet rays than ordinary CDs. It is
important that they are not stored in a location
where direct sunlight will fall on them, and which is
away from sources of heat such as radiators or
heat-generating electrical devices.
<Printable CD-R discs aren't recommended, as the
label side might be sticky and damage the unit.
<Do not stick papers or protective sheets on the
discs and do not use any protective coating spray.
<Use a soft oil-based felt-tipped pen to write the
information on the label side. Never use a ball-point
or hard-tipped pen, as this may cause damage to
the recorded side.
<Never use a stabilizer. Using commercially available
CD stabilizers with this unit will damage the
mechanisms and cause them to malfunction.
<Do not use irregular shape CDs (octagonal, heart-
shape, etc.). CDs of this sort can damage the unit.
Discs which can be played on this unit:
•Conventional audio CDs bearing the CD-DA logo
on the label:?
•Properly finalized CD-R discs
Note:
<Depending on the quality of the disc and/or the
condition of the recording, some CD-R discs may not
be playable.
<CD-RW discs cannot be played on this unit.
<Copy-protected discs and other discs which do not
conform to the CD standard may not play back
correctly in this player.
If you use such discs in this unit, TEAC Corporation
and its subsidiaries cannot be responsible for any
consequences or guarantee the quality of
reproduction. If you experience problems with such
non-standard discs, you should contact the
producers of the disc.
<Always place the disc on the disc tray with the label
side uppermost. (Compact discs can be played or
recorded only on one side.)
<To remove a disc from its storage case, press down
on the center of the case and lift the disc out,
holding it carefully by the edges.
How to remove the disc
How to hold the disc
<Should the disc become dirty, wipe the surface
radially with a soft, dry cloth.
<If you are in any doubt as to the care and handling
of a CD-R disc, read the precautions supplied with
the disc, or contact the disc manufacturer directly.

6
Names of Each Control
A
B
U
FEC G
T S R Q L K J IP MO N
H H
C
R
Q
G
M
D
V
W
W
E
P
TOP
FRONT
REAR
REMOTE CONTROL

7
Names of Each Control
Disc cover
Press the Lmark on the disc cover to open it.
SNOOZE button
After the on time is reached, use this button to turn
the unit off for 5 minutes.
POWER switch
Press this switch to turn the unit on and off.
CD, TUNER buttons (FUNCTION button)
Press the CD button to play a disc.
Press the TUNER button to listen to the radio.
Press the FUNCTION button repeatedly when using
the remote control unit.
BAND button
Use this button to select FM or AM.
Display
CD operation buttons
When TUNER is selected, these buttons won't work.
STOP button (H)
Use this button to stop playback.
PLAY/PAUSE button (y/J)
Use this button to start or pause playback.
SKIP/SEARCH buttons (.m/,/)
Press these buttons to skip tracks.
Hold down these buttons to search for a part of a
track.
Speakers (stereo)
Remote sensor
SHUFFLE button
Use this button to select shuffle playback mode.
REPEAT/PRESET button
Use this button to change the repeat mode or select
a preset number and station.
MEMORY/CLOCK ADJUST button
Use this button to program tracks or to adjust the
clock.
L
K
J
I
H
G
F
E
D
C
B
AVOLUME knob
Turn this knob to adjust the volume.
Subwoofer
BASS CONTROL knob
Use this control knob to adjust the subwoofer level.
TUNING knob
Turn this knob to tune in a station.
MUTING button
To cut the sound temporarily, press the MUTING
button. Press the MUTING button again to restore
the sound. If you change the volume during the
muting, the muting will be canceled.
DISPLAY button
Use this button to change the display mode.
TIMER/SLEEP button
Use this button to set the timer or sleep timer.
PHONES
Insert the headphones plug into the PHONES jack,
and adjust the volume.
Both stereo and monaural earphones can be used
with this unit.
Holder for Remote Control Unit
Place the remote control unit when not in use.
You can detach the holder by using a screw driver,
if you don't need it.
FM feeder antenna
Tune in an FM station and extend the lead to find the
best position for the reception. Then fix it to the wall
with thumb tacks or the like.
AC Power Cord
Plug this AC power cord into an AC wall socket.
W
V
U
T
S
R
Q
P
O
N
M
The equipment draws nominal nonoperating power
from the AC outlet with its POWER switch in the OFF
position.

The provided Remote Control Unit allows the unit to be
operated from a distance.
When operating the remote control unit, point it
towards the REMOTE SENSOR on the front panel of the
unit.
<Even if the remote control unit is operated within the
effective range, remote control operation may be
impossible if there are any obstacles between the
unit and the remote control.
<If the remote control unit is operated near other
appliances which generate infrared rays, or if other
remote control devices using infrared rays are used
near the unit, it may operate incorrectly. Conversely,
the other appliances may operate incorrectly.
Battery Installation
Remove the battery compartment cover.
Insert two “AAA“(R03, SUM-4) dry batteries. Make
sure that the batteries are inserted with their
positive “+“and negative “_“poles positioned
correctly.
Close the cover.
Battery Replacement
If the distance required between the remote control
unit and main unit decreases, the batteries are
exhausted. In this case replace the batteries with new
ones.
3
2
1
Precautions concerning batteries
<Be sure to insert the batteries with correct positive
“+“and negative “_“polarities.
<Use batteries of the same type. Never use different
types of batteries together.
<Rechargeable and non-rechargeable batteries can
be used. Refer to the precautions on their labels.
<When the remote control unit is not to be used for a
long time (more than a month), remove the batteries
from the remote control unit to prevent them from
leaking. If they leak, wipe away the liquid inside the
battery compartment and replace the batteries with
new ones.
<Do not heat or disassemble batteries and never
dispose of old batteries by throwing them in a fire.
8
Remote Control Unit
RESET Switch
In the following cases, function buttons may not
work properly.
1) When the system is damaged by some electrical
shock.
2) When the power is irregular or has electrical
noise.
In these cases, press the RESET switch once or
twice lightly with a pencil or a ball-point pen when
the unit is on.

Press the POWER switch to turn the unit ON.
Press the CD button to select "CD".
Press the FUNCTION button repeatedly to select
"CD", when using the remote control unit.
<When no disc is in the unit, "no dISC" will be
displayed.
Press Lto open the disc cover.
3
2
1
9
Playing a CD (1)
Place a disc with the printed label face up, and
close the cover by hand.
<CD's must be pressed securely onto the Spindle,
until a "CLICK" is heard.
<Never place more than one disc in the CD player.
<When closing, press Lon the cover.
<The total number of the tracks and total play time of
the disc is displayed.
<It takes a few seconds for the unit to read the
contents of the disc. No button will work during
reading. Wait until the total number of the tracks
and total play time of the disc is displayed.
Press the PLAY/PAUSE button (y/J) to start
playback.
Playback starts from the first track.
When playback of all the tracks has finished, the
unit stops automatically.
5
4
1 52

To stop playback
Press the STOP button (H) to stop playback.
To suspend playback temporarily (pause mode)
Press the PLAY/PAUSE button (y/J). Playback
stops at the current position.
To resume playback, press the PLAY/PAUSE button
(y/J) again.
To skip to the next or a previous track
During playback, press the SKIP/SEARCH button
(.mor,/) repeatedly until the desired
track is found. The selected track will be played
from the beginning.
In the stop mode, press the SKIP/SEARCH button
(.mor,/) repeatedly until the desired
track is found, and press the PLAY/PAUSE button
(y/J) to start playback from the selected track.
<When the .mbutton is pressed once during
playback, the track being played will be played from
the beginning. To return to the beginning of the
previous track, press the .mbutton twice.
<During programmed playback, the next or previous
track in the program is played.
C
B
ASearch for a part of a track
During playback, hold down the SKIP/SEARCH
button (.mor ,/) and release it
when the part you want to listen to is found.
DISPLAY button
During playback, press this button repeatedly to
change the display mode as follows:
<Clock display and timer mode display appears for 4
seconds and returns to original display.
<In the stop mode, remaining time of the disc cannot
be selected.
E
D
10
Playing a CD (2)
BDC A
E
Playing time of the current track
Remaining time of the disc
Clock display
Timer mode display

Repeat step and to program more tracks.
<You can program up to 20 tracks.
<To cancel the program mode, press the STOP button
(H).
When the selection of track numbers has been
finished, press the PLAY/PAUSE button (y/J) to
start program playback.
If the PLAY/PAUSE button isn't pressed within 10
seconds, the MEMORY indicator will go off. In that
case, press the MEMORY/CLOCK ADJ button and
then press the PLAY/PAUSE button to start program
playback.
The programmed contents are kept in memory even
after the TUNER button is pressed or the power is
turned off.
4
32
Up to 20 tracks can be programmed in the desired
order.
<Shuffle playback does not work during program
playback.
<Insert a disc and select "CD" before beginning
programming.
Press the MEMORY/CLOCK ADJ button in the stop
mode.
"MEMORY" indicator blinks, and "P-01" appears on
the display.
Within 10 seconds, press the SKIP/SEARCH button
to select a track.
<If the SKIP/SEARCH button isn't pressed within 10
seconds, program mode will be canceled.
While "MEMORY" is blinking on the display, press
the MEMORY/CLOCK ADJUST button.
The track is programmed, and "P-02" is displayed.
3
2
1
11
Programmed Playback (1)
2 4
1 3

To add a track to the end of the program
In the stop mode, press the MEMORY/CLOCK ADJ
button repeatedly until "00" appears on the display.
Select a track number by pressing the
SKIP/SEARCH button, and then press the
MEMORY/CLOCK ADJ button.
The track is added to the end of the program.
12
Programmed Playback (2)
To clear program
In the stop mode, do either of the following to clear
the program:
Press Lon the disc cover and open it.
Press the MEMORY/CLOCK ADJ button and then
the STOP (H) button.
<If the unit is disconnected from the power supply for
more than 3 minutes, the programmed contents will
be cleared.
To cancel the program playback mode
Press the STOP (H) button. "MEMORY" indicator
disappears, but the programmed contents aren’t
lost.
To return to the program mode, press the
MEMORY/CLOCK ADJ button.
To check the programmed order
In the stop mode, press the MEMORY/CLOCK ADJ
button repeatedly to show the track numbers that
have been stored in memory.
To overwrite the program
In the stop mode, press the MEMORY/CLOCK ADJ
button repeatedly until the track number to be
changed appears on the display.
Select a track number by pressing the
SKIP/SEARCH button, and then press the
MEMORY/CLOCK ADJ button.
MEMORY/CLOCK ADJ
STOPSKIP/SEARCH

13
Repeat Playback
Repeat one track
Press the REPEAT/PRESET button once during
playback. The repeat indicator blinks.
The track being played will be played repeatedly. If
you press the SKIP/ SEARCH button and select
another track, the track you select will be played
repeatedly.
It is also possible to select a track to be repeated in
the stop mode. Press the REPEAT/PRESET button
and then select the track number by pressing the
SKIP/SEARCH button or the numeric buttons. Press
the PLAY/PAUSE button to start playback.
Repeat All the Tracks
All the tracks of the disc will be played repeatedly.
Press the REPEAT/PRESET button twice. The repeat
indicator lights steadily.
<During program playback, only the programmed
tracks will be played in order repeatedly.
<If one of the following buttons is pressed or the disc
cover is opened, repeat mode will be canceled:
STOP button (H)
POWER switch
TUNER button
FUNCTION button
repeat one track
repeat all the tracks
(off)
Every time the REPEAT/PRESET button is pressed, the
REPEAT indicator lights or blinks, and the mode is
changed as follows :
REPEAT/PRESET
Shuffle Playback
Tracks can be played randomly.
Press the SHUFFLE button in the stop or play mode.
<If you press the SKIP/SEARCH button (,/)
during shuffle playback, next track will be randomly
selected and played.
If you press the SKIP/SEARCH button (.m),
the currently played track will be played from the
beginning.
A track cannot be replayed during shuffle playback.
<To stop shuffle playback, press the STOP button (H).
<To cancel the shuffle playback mode, press the
SHUFFLE button.
<If one of the following buttons is pressed or the disc
cover is opened, shuffle mode will be canceled:
STOP button (H), POWER switch
TUNER button, FUNCTION button
SHUFFLE

14
Listening to the Radio
Press the POWER switch to turn the unit ON.
Press the TUNER button to select "TUNER".
Or, press the FUNCTION button repeatedly to select
"TUNER", when using the remote control unit.
Press the BAND button to select FM or AM.
Select the station you want to listen to (auto
selection).
Turn the TUNING knob to left or right until the
frequency display begins to change.
When a station is tuned in, the tuning process will
stop automatically.
<Turn the TUNING knob to stop the auto selection.
<Use the TUNING button, when using the remote
control unit.
4
3
2
1Selecting stations which cannot be tuned
automatically (manual selection).
Turn the TUNING knob to left or right and hold to
change the frequency continuously. Release it when
the station you want to listen to is found.
Use the TUNING button, when using the remote
control unit.
If the reception is poor
AM broadcast
Turn around the unit to find the best position for AM
stations.
FM broadcast
For a good reception, turn around the antenna so
that you can get the stations clearly.
1 32
4

Press the BAND button to select FM or AM.
Press the REPEAT/PRESET button repeatedly and
select a preset channel.
2
1
In each band, up to 10 stations can be stored in preset
memories.
Press the BAND button to select FM or AM.
Turn the TUNING knob and tune in a station to be
stored as a preset station.
Press the MEMORY/CLOCK ADJUST button.
Within 10 seconds, select a preset channel to store
the station using the REPEAT/PRESET button, and
then press the MEMORY/CLOCK ADJUST button.
To store more stations, repeat steps to .
41
4
3
2
1
15
How to Preset Stations How to select Preset Stations
1
2 43
4
1
2

16
Clock Adjustment
Press the DISPLAY button to select clock display.
":" blinks in the clock display.
<If the unit is off, press and hold the MEMORY/CLOCK
ADJUST button for 2 or more seconds, and continue
the procedure from step .
<Press the STOP button to cancel the time setting. (In
the TUNER mode, press the DISPLAY button.)
Within 4 seconds, press and hold the
MEMORY/CLOCK ADJUST button for 2 or more
seconds.
Press the .m or ,/ button to select
"12H" or "24H".
If you select "12H", "AM" or "PM" appears on the
display.
<In the TUNER mode, use the TUNING knob.
Press the MEMORY/CLOCK ADJUST button.
4
3
2
3
1Press the .mor,/ button to set the
current hour.
<In the TUNER mode, use the TUNING knob.
Press the MEMORY/CLOCK ADJUST button.
Press the .mor,/ button to set the
current minute.
<In the TUNER mode, use the TUNING knob.
Press the MEMORY/CLOCK ADJUST button to finish
the time setting mode.
The clock starts from 00 second.
<If the unit is disconnected from the power supply for
more than 3 minutes, the clock and timer setting will
be reset.
<If the unit is disconnected for less than 3 minutes
the time displayed may not be correct.
8
7
6
5
MEMORY/CLOCK ADJDISPLAY
.m,/

Adjust the clock before setting the timer.
Setting the timer
Press the DISPLAY button once or twice to select
the timer mode.
The "TIMER" indicator blinks on the display.
Within 4 seconds, press and hold the
MEMORY/CLOCK ADJUST button for 2 or more
seconds.
The "TIMER" and hour blinks on the display.
Press the .m or ,/ button to set the
start time (hour).
In the TUNER mode, use the TUNING knob.
3
2
1
Press the MEMORY/CLOCK ADJUST button.
The minute blinks on the display.
Press the .m or ,/ button to set the
start time (minute).
In the TUNER mode, use the TUNING knob.
Press the MEMORY/CLOCK ADJUST button.
Time setting is finished and blinking of the "TIMER"
indicator will stop.
6
5
4
17
MEMORY/CLOCK ADJDISPLAY
.m,/
Timer (1)

Activating the timer
Press and hold the TIMER/SLEEP button for 2 or more
seconds, and press the POWER switch to turn the unit
off.
The unit will turn on at the specified time every day,
and will turn off one hour after the start time.
For the timer to start playback of a CD, press the CD
button to select CD, insert a disc and adjust the
volume before turning the unit off.
For the timer to start the radio, tune in a station and
adjust the volume before turning the unit off.
Don't forget to turn the unit off, or the timer won't
work.
<If you want to turn off the unit anytime within 1 hour
from the start time, press the POWER switch to turn
the unit off.
<If the unit is disconnected from the power supply for
more than 3 minutes, the clock and timer settings
will be reset.
To cancel the timer mode
Press the TIMER/SLEEP button.
The "TIMER" indicator disappears from the display.
How to Use the Snooze function
After the on time is reached, press the SNOOZE
button and the unit will turn off for 5 minutes then
turn on again.
The "SNOOZE" indicator appears on the display
while snooze function is activated.
You can use this function repeatedly.
B
A
18
Timer (2)
B
A
Sleep Timer
The power can be switched off at the specified time.
When the power is on, press the TIMER/SLEEP button
repeatedly until the desired time appears on the
display.
Use the SLEEP button when using the remote control
unit.
The sleep time can be changed at 10-minute intervals.
When the sleep timer is activated, "SLEEP" appears on
the display.
(OFF)
90 80 10
70
TIMER/SLEEP

19
Troubleshooting
If you have problems with your system, look through
this chart and see if you can solve the problem yourself
before calling your dealer or TEAC service center.
General
No power
eCheck the connection to the AC power supply.
No sound.
eAdjust the volume.
eIf muting is on, press the MUTING button.
The sound is noisy.
eThe unit is too close to a TV set or similar
appliances. Install the unit further from them, or
turn them off.
Tuner
Cannot listen to any station, or signal is too weak.
eTune in the station properly.
eIf a TV is near the unit, turn it off.
eRotate the unit or antenna wire for the best
reception position.
CD Player
Cannot play.
eLoad a disc with label side up.
eIf the disc is dirty, clean the surface of the disc.
eDon’t use scratched, damaged or warped discs.
eDepending on the quality of the disc and/or the
condition of the recording, some CD-R discs may
not be playable.
eCD-RW discs cannot be played on this unit.
eCopy-protected discs may not be playable.
Sound skips.
ePlace the unit on a stable place to avoid vibration
and shock.
eIf the disc is dirty, clean the surface of the disc.
eDon’t use scratched, damaged or warped discs.
Remote Control Unit
Remote control doesn’t work.
eIf the batteries are dead, change the batteries.
eUse remote control unit within the range (5m/15ft)
and point at the front panel.
eClear obstacles between the remote control unit
and the main unit.
eIf a fluorescent light is near the unit, put it off.
Specifications
TUNER Section
Frequency Range(FM):
87.50 MHz to 108.00 MHz
Frequency Range(AM):
520 kHz to 1,710 kHz
CD PLAYER Section
Frequency Response:
20 Hz to 20 kHz(±1dB)
Wow and Flutter:
Unmeasurable
SPEAKER SYSTEM Section
Type:1-way
Impedance:
8 ohms (L & R)
8 ohm (subwoofer)
GENERAL
Total Output Power:
15 W
Power Requirements:
120 V, 60 Hz
Power Consumption:
40 W
Dimension ( W x H x D ):
14-1/16" x 8-1/16" x 9-3/4" (357 x 205 x 247.5 mm)
(including the remote holder)
Weight:
12-13/16 lbs (5.8 kg)
Standard Accessories:
Remote Control Unit (RC-910) x 1
Owner's Manual x 1
Warranty Card x 1
<Design and specifications are subject to change
without notice.
<Illustrations may differ slightly from production
models.

0503.MA-0804A
This appliance has a serial number located on the rear panel. Please
record the model number and serial number and retain them for your
records.
Model number Serial number
Z
TEAC CORPORATION 3-7-3, Nakacho, Musashino-shi, Tokyo 180-8550, Japan Phone: [phone]
TEAC AMERICA, INC. 7733 Telegraph Road, Montebello, California 90640 Phone: [phone]
TEAC CANADA LTD. 5939 Wallace Street, Mississauga, Ontario L4Z 1Z8, Canada Phone: [phone]
TEAC MEXICO, S.A. De C.V Campesinos N°184, Colonia Granjas Esmeralda, Delegacion Iztapalapa, CP 09810 México DF
Phone: [phone]
TEAC UK LIMITED 5 Marlin House, Croxley Business Park, Watford, Hertfordshire, WD18 8TE, U.K. Phone: [phone]
TEAC DEUTSCHLAND GmbH Bahnstrasse 12, 65205 Wiesbaden-Erbenheim, Germany Phone: [phone]
TEAC FRANCE S.A. 17, Rue Alexis-de-Tocqueville, CE 005 92182 Antony Cedex, France Phone: [phone]
TEAC ITALIANA S.p.A. Via C. Cantù 11, 20092 Cinisello Balsamo, Milano, Italy Phone: [phone]
TEAC AUSTRALIA PTY., LTD. 280 William Street, Melbourne, Victoria 3000, Australia Phone: [phone]
A.B.N. 80 005 408 462
