Teac SB20204M User manual

Mini Wireless BT Soundbar
SB20204M
Call us between Monday to Friday - 8.30AM to 5PM
AEST
*Please have your purchase receipt and the product's
serial number ready
For other enquiries and support please visit
www.teac.com.au
TEAC Warranty Service Hotline
1300 553 315
USER MANUAL

IMPORTANT SAFETY INSTRUCTIONS
PACKAGE CONTENTS
CONTROL PANEL
USB POWER CABLE
To recharge and power on the soundbar, use the provided USB cable and then connect to a
power outlet or USB slot of a computer.
• Heed all warnings and follow all instrucons.
• Do not use this mini soundbar near water.
• Clean the unit with a dry cloth.
• Do not block any venlaon openings. Install in accordance with the
manufacturer’s instrucons.
• Do not install near any heat sources such as radiators, heat registers,
stoves, or other devices (including ampliers) that produce heat.
• Use only aachments / accessories specied by the manufacturer.
• To reduce the risk of electric shock, do not remove cover (or back).
There are no userserviceable parts inside.
• Do not expose the mini soundbar to dripping or splashing liquids.
Do not place objects lled with liquids (such as vases) on the soundbar.
•Mini Soundbar x1
•Line-in Cable x1
Indicator light
Short press for Power On/Off
DC 5V
USB Mode
LINE IN
Connect any
audio device with
a 3.5mm plug
Short press for PLAY/PAUSE
Long press to switch MODE
Short press for NEXT
Long press for V+
Short press for PREV
Long press for V-
•USB Power Cable x1
•User Manual x1

FUNCTION MODE
Bluetooth Funcon
Long press the MODE buon to switch to Bluetooth mode. Turn on the Bluetooth feature on
your audio device, locate the Bluetooth name “SB20204M”, and pair the mini soundbar with
your audio device.
USB Funcon
Insert the USB into the USB port, and then press the MODE buon unl it is in USB mode.
LINE IN
Use the provided LINE IN cable (3.5mm to 3.5mm) to directly connect smart phones, tablets,
and other music devices. Its corresponding signal source is LINE IN in the soundbar MODES.
LED INDICATOR LIGHTS
FUNCTION/MODE COLOUR
Bluetooth Blue
USB Blinking Green
Line-In Blue and Green
Power charging Red
Built-in Rechargeable Baery 1500mAh
Power Input DC 5V
RMS Power 2 x 2.5W
Speaker Output Power 10W
Speaker Size & Number 2.0” Full range speaker x 2 + Passive speaker x 1
Bluetooth Version 5.0
Bluetooth Distance 10M
Frequency Response 160HZ - 18KHZ
Supported Prole A2DP / AVRCP
Audio Input Line-in / USB / Bluetooth
Soundbar Dimensions 43 x 6.5 x 5.5cm
Net Weight 730g
PRODUCT SPECIFICATIONS

TERMS AND CONDITIONS
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.
You are entled to a replacement or refund for a major failure and for compensaon for any
other reasonably foreseeable loss or damage. You are also entled to have the goods repaired or
replaced if the goods fail to be of acceptable quality and the failure does not amount to a major
failure.
1. TEAC warrants that this product is free from defects in material and workmanship under
normal domesc use with reasonable care and skill. Maintenance and cleaning (i.e. laser head) is
not covered by this warranty. The TEAC warranty only applies to TEAC products purchased NEW
from a TEAC Authorised Retailer in Australia. This warranty only applies to the original purchaser
and cannot be transferred.
2. The benets to the consumer given by this Warranty are in addion to other rights and
remedies of the consumer under a law in relaon to goods or services to which the warranty
relates, being the Australian Consumer Law.
3. Refund or replacement via your TEAC Authorised Retailer is available for a period of 14 days
aer purchase for goods that have been inspected and determined to have a major failure.
Refund and exchange is not applicable for change of mind.
4. Subject to the terms herein, this warranty eecvely covers TEAC products under the 12
Month Replacement Warranty Scheme, 12 months from the date of original purchase.
5. The warranty is void and warranty claims may be refused, subject to the Australian Consumer
Law, if:
a) The product was not transported, installed, operated or maintained according to manufacturer
instrucon, or
b) The product was abused, damaged, tampered, altered or repaired by any unauthorised
persons,
or
c) Product failure is due to accidents during use, installaon or transit, power surges, use of
defecve or incompable external devices, exposure to abnormal condions such as excessive
temperatures or humidity, or entry of liquids, objects or creatures into the product, cockroach
infestaons, or
d) The customer is unable to provide proof of purchase of the product for vericaon, or
e) The serial number of the product is missing or has been tampered with.
6. No one is authorised to assume any liability on behalf of TEAC or impose any obligaon on it,
in connecon with the sale of any equipment other than as stated in this warranty and outlined
above.
7. TEAC and/or its Authorised Service Centres reserve the right to inspect and verify whether the
product is exhibing a major failure as claimed by customers/retailers.
