Team C TC02C EVO User manual

尺寸：
TC02C EVO
Length …………………………………………………………………………410mm
Width …………………………………………………………………………250mm
Height …………………………………………………………………………150mm
長度
寬度
高度
Dimensions
Instruction manual
www.teamcracing.net
1:10 SCALE RADIO CONTROLLED ELECTRIC
POWERED 2wd RACING BUGGY

9
8
7
610
11
12
13
14
電池蓋
調整遙控器
在遙控器的底部打開電池蓋子,安裝電池。
跟隨電池的指示在電池盒裡面指定。
AA 堿性電池
遙控器電池安裝
Transmitter Preparation
AA
Alkaling Batteries
4X
Open battery cover at the bottom of transmitter.
Install batteries. Follow the direction of batteries
designated in the inside of battery box.
Transmitter Battery Installation
Battery Cover
1 Control Panel
2 Steering Wheel
3 Throttle Trigger
4 Battery Compartment
5 Charging Jack
6 Sterring Servo Reverse
7 Power LED
8 Steering Trim
9 Bind Button
10 Throttle Servo Reverse
11 Battery Voltage
12 Steering Dual Rate
13 Power Switch
14 Throttle Trim
GLG20
2.4GHz
1
5
3
4
2
控制面板
轉向輪
油門板扣
電池盒
充電接口
轉向正逆轉開關
電源指示燈
轉向调節
設定按扭
油門正逆轉開關
電池電壓
轉向大小微調
電源開關
油門微調

调整遥控器
Transmitter Preparation
组裝需要的工具
Tools required
Needie Nose Pllers Awl Grease
润滑油
Screw Cement
螺丝胶水
瞬间胶水
Instant Glue
Hex Wrench
六角扳手
Differential Grease
差速油
Molybdenum Grease(Black)
钼油(黑)
锥
尖嘴钳
Hex Wrench
十字套筒
Body Reamer
车壳绞刀
No need to pre-drill precise holes
(1mm to 15mm)can be drilled
可以对预钻的孔准确的钻1mm-15mm
Wire Cutters
钢丝钳
Sharp Hobby knife
美工刀
ROUND CUTTER
剪刀
For trimming bodies!
用于修剪車壳！
H154
H162
H096
Battery Charger
(Not Included)
Battery
Servo
Motor
Electronic Speed
Controller / Switch
Receiver
Note: When done driving Turn Off the
ESC and THEN Transmitter
Install Transmitter Batteries1.
Connect Battery to ESC2.
Switch on Transmitter First3.
Switch on ESC Second4.
安裝發射電池
連接電池到電調
首先接通發射機
其次接通電調
注意：當停止駕駛首先要關掉電調
其次再關掉發射機
電池
充電器（不包括）
馬達
伺服
接收機
電子變速器

1
2
Front Suspension
前悬吊系统
Front Suspension
前悬吊系统
1
M3x3螺丝
M3x3 Screw
TU0222OR
M3x15螺丝
M3x15 Screw
FS315
前底盤
Front Chassis Plate
T02008
前防撞板
Front Bumper
T02185
球头-长
Ball Stud-Long
TS4042
前上摆臂座
Front Upper Suspension Arm Mount
T02015
前下摆臂座
Front Arm Mount
TU0222OR
前下摆臂
Front Lower Arm
T02016
2.3 E扣
2.3 E-ring
T02056
前摆臂固定片
Front Hinge Pin Brace
TU0226OR
3x34.5前摆臂轴-内
3x34.5 Hinge Pin Front-Inner
T02056
..............................................2
...............2
................................................4
M3x3螺丝
TU0222OR M3x3 Screw
2.3 E扣
T02056 2.3 E-ing
3x34.5前摆臂轴-内
T02056 3x34.5 Hinge Pin Front-Inner
........4
.................2
M3x15螺丝
FS315 M3x15 Screw
球头-长
TS4042 Ball Stud-Long
Bag-A
Bag-A
LR
LR
Assemble both Left and Right
組裝左和右

4
33
1
2
Buffer
缓冲
Buffer
缓冲
4.0mm
1
2
4
3
5
6
11
7
8
9
10
2
3x6x2.5轴承
3x6x2.5 Ball Bearing
B0306025
3x6x2.5轴承
3x6x2.5 Ball Bearing
B0306025
3x6x2.5轴承
3x6x2.5 Ball Bearing
B0306025
3x6x2.5轴承
3x6x2.5 Ball Bearing
B0306025
缓冲调解螺帽
Buffer Nut
T02043OR
缓冲弹簧
Buffer Spring
T02043OR
球头-银色
Ball Stud-Silver
T02061
球头-短
Ball Stud-Short
TS4043
缓冲连接片
Steering Rack
T02024
轴套
Block Carrier
T02044
3x7x0.8垫片
3x7x0.8 Washer
T02044
M3x10螺丝
M3x10 Screw
T02044
缓冲臂上
Servo Saver Upper
T02023
缓冲臂-L
Servo Saver-L
T02023
缓冲臂下
Servo Saver Lower
T02023
转向缓冲器-A
Buffer Column-A
T02043OR
转向缓冲器-B
Buffer Column-B
T02043OR
4.0 E扣
4.0 E-ring
T02043OR
…………….............4
…………….............1
球头-银色
T02061 Ball Stud-Silver
……………............2
………...2
…………….......2
…………….2
轴套
T02044 Block Carrier
M3x10螺丝
T02044 M3x10 Screw
球头-短
TS4043 Ball Stud-Short
3x7x0.8垫片
T02044 3x7x0.8 Washer
…………….................1
4.0 E扣
T02043OR 4.0 E-ring
B0306025 3x6x2.5 Ball Bearing
3x6x2.5轴承
Bag-A
Bag-A

6Front Suspension
5Front Suspension
前悬吊系统
前悬吊系统
3
Apply threadlocker(screw cement)
打螺丝胶水
Screw
Cement
M3x10螺丝
M3x10 Screw
BS310
M3x25螺丝
M3x25 Screw
FS325
前支撐座
Front Brace Mount
T02019
...............................2
..........1
M3x10螺丝
BS310 M3x10 Screw
M3x25螺丝
FS325 M3x25 Screw
Bag-A
Bag-A
……………8
………….2
………2
2.3 E 扣
T02054 2.3 E-ring
4.0 E 扣
T02042 4.0 E-ring
2x9.8钢针
T02042 2x9.8 Pin
………............4
…………............................4
前摆臂销-外
T02054 3X27.5 Hinge Pin Front-Outer
球头-短
TS4043 Ball Stud-Short
………...........................4
B051004 5x10x4 Ball Bearing
5x10x4轴承
TS4043
Ball Stud-Short
球头-短
C型座-L
C-Type Holder-L
T02011
转向臂-L
Steering Block-L
T02012
六角座
Hex Mount
T02245
前轮轴
Front Wheel Axle
T02042
3X27.5前摆臂销-外
3X27.5 Hinge Pin Front-Outer
T02054
M2x5螺丝
M2x5 Screw
T02245
2x9.8钢针
2x9.8 Pin
T02042
2.3 E 扣
2.3 E-ring
T02054
4.0 E 扣
4.0 E-ring
T02042
5x10x4轴承
5x10x4 Ball Bearing
B051004

7
8
Turnbuckle
Front Suspension
前悬吊系统
approx.28mm
大约28mm
approx.28mm
大约28mm
approx 24mm
大约24mm
拉杆
4
▲Projection.Note direction
注意方向
▲Projection.Note direction
注意方向
▲Projection.Note direction
注意方向
3x45拉杆
3x45 Turnbuckle
T04107
4.8mm球头座-长
4.8mm Ball End-Long
T04014
4mm
Front Upper-L
前上拉杆-左
1:1 x1
Front Upper-R
前上拉杆-右
1:1 x1
Steering Tip
转向拉杆
1:1 x2
...................4
3x45拉杆
T04107 3x45 Turnbuckle
..................................8
4.8mm球头座-长
T04014 4.8mm Ball End-Long
Assemble as many times as specified
需組裝數量
x1 Assemble as many times as specified
需組裝數量
x2
Ture-to-scale diagram
圖形比例
1:1
Bag-A
Bag-A

10 Differential
9Front Suspension
前悬吊系统
差速器
5
前避震器架
Front Shock Tower
T02020
M3x10螺丝
M3x10 Screw
BS310
避震盖球头
Shock Cap Ball
TU0250-6
M3x22螺丝
M3x22 Screw
BS322
差速齿轮轴
Diff Gear Shaft
T02157
14T齿轮
14T Gear
T02154
...................4
...................2
...........................2
......2
M3x10螺丝
BS310 M3x10 Screw
Bag-A
3.1x5.5x2.0铝垫片
3.1x5.5x2.0 Aluminium Washer
TU0250-6
避震盖球头
TU0250-6 Shock Cap Ball
M3x22螺丝
BS322 M3x22 Screw
Aluminium Washer
TU0250-6 3.1x5.5x2
3.1x5.5x2铝垫片
Bag-B
52T差速齿轮
52T Diff Gear
T02152
28T齿轮
28T Gear
T02154
差速接杯
Diff Connecting Cup
T02155
10x15x4轴承
10x15x4 Ball Bearing
B101504
4.8x1.6 O环
4.8x1.6 O-ring
T02156
2x8.8钢针
2x8.8 Pin
T02154
5.1x13x0.2垫片
5.1x13x0.2 Washer
T02154
.........................1
............................1
............................1
..................1
..................2
5.1x13x0.2垫片
T02154 5.1x13x0.2 Washer
10x15x4轴承
B101504 10x15x4 Ball Bearing
10x12x0.2垫片
W101202 10x12x0.2 Washer
2x8.8钢针
T02154 2x8.8 Pin
4.8x1.6 O环
T02156 4.8x1.6 O-ring
10x12x0.2垫片
10x12x0.2 Washer
W101202

12 Transmission
差速箱
XMust be purchased separately
需另购物品 6
齿轮箱-右
Gear Box-R
T02251
齿轮箱-左
Gear Box-L
T02251
M2.5x8螺丝
M2.5x8 Screw
T02152
M3x12螺丝
M3x12 Screw
BS312
5x10x4轴承
5x10x4 Ball Bearing
B051004 衬套
Top Shaft Spacer
T02041
入力齿-20T
Gear-20T
T02052
28T减速齿-铝
28T Spur Gear-Alumimum
TU0258
减速齿轮轴
Idler Gear Shaft
T02051
.........................1
................1
....................2
....................1
....................6
............................1
............................1
..................1
.......................4
5.1x13x0.2垫片
T02154 5.1x13x0.2 Washer
10x15x4轴承
B101504 10x15x4 Ball Bearing
2x8.8钢针
T02154 2x8.8 Pin
M2.5x8螺丝
T02152 M2.5x8 Screw
4.8x1.6 O环
T02156 4.8x1.6 O-ring
1000#
高抓地力：
建議使用1500#-2000#差速油；
低抓地力：
建議使用500#-700#差速油。
High grip:
Suggest using 1500#-2000#
differential oil;
Low grip:
Suggest using 500#-700#
differential oil.
52T差速齿轮盖
52T Diff Gear Cover
T02152
差速垫片
Diff Pads
T02153
28T齿轮
28T Gear
T02154
4.8x1.6 O环
4.8x1.6 O-ring
T02156
2x8.8钢针
2x8.8 Pin
T02154
5.1x13x0.2垫片
5.1x13x0.2 Washer
T02154
11 Differential
差速器
Bag-B
5x10x4轴承
B051004 5x10x4 Ball Bearing
减速齿轮轴
T02051 Idler Gear Shaft
衬套
T02041 Top Shaft Spacer
M3x12螺丝
BS312 M3x12 Screw
Bag-B
差速接杯
Diff Connecting Cup
T02155
10x15x4轴承
10x15x4 Ball Bearing
B101504
10x12x0.2垫片
10x12x0.2 Washer
W101202
..................2
10x12x0.2垫片
W101202 10x12x0.2 Washer

Motor Mount
马达座
Rear Chassis
后底盘
14
13
7
.........3
M3x28螺丝
BS328 M3x28 Screw
M3x12螺丝
M3x12 Screw
FS312
后底盘
Rear Chassis
T02250
M3x28螺丝
M3x28 Screw
BS328
马达座
Motor Mount
T02252
...............4
M3x12螺丝
FS312 M3x12 Screw
Bag-B
Bag-B

后悬吊系统
Rear Suspension
16
8
Spur Gear
减速齿轮
15
Bag-B
M4带边尼龙螺母
M4 Flanged Nylon Nut
T02084
扭限弹簧
Slipper Spring
T02040
扭限座
Slipper Hub
T02039
扭限座
Slipper Hub
T02039
减速齿-80T
Spur Gear-80T
T02001
扭限摩擦片
Slipper Pad
T02038
扭限摩擦片
Slipper Pad
T02038
轴套
5x7 Top Shaft Spacer
T02211
..........................1
M4带边尼龙螺母
T02084 M4 Flanged Nylon Nut
18
M3x8螺丝
M3x8 Screw
FS308
M3x14螺丝
M3x14 Screw
FS314
后避震架固定座
Rear Shock Tower Mount
T02254
球头-长
Ball Stud-Long
TS4042
摆臂固定座-RR
Arm Mount-RR
T02204
3x48后摆臂销-内
3x48 Hinge Pin Rear-Inner
T02055
后下摆臂-右
Rear Lower Arm-R
T04008
.........................2
3x48后摆臂轴-内
T02055 3x48 Hinge Pin Rear-Inner
.........................2
M3x8螺丝
FS308 M3x8 Screw
.....................2
M3x14螺丝
FS314 M3x14 Screw
球头-长
TS4042 Ball Stud-Long
…………..2
Bag-C

Rear Suspension
后悬吊系统
Rear Shock Tower
后避震架
18
17
9
M3x22螺丝
M3x22 Screw
BS322
M3x15螺丝
M3x15 Screw
BS315
M3x10螺丝
M3x10 Screw
BS310
避震盖球头
Shock Cap Ball
TU0250-6
尾翼架
Wing Bracket
T04012
3.1x5.5x2.0铝垫片
3.1x5.5x2.0 Aluminium Washer
TU0250-6
后避震器架
Rear Shock Tower
T02257
...................2
...................2
...........................2
......2
M3x10螺丝
BS310 M3x10 Screw
避震盖球头
TU0250-6 Shock Cap Ball
M3x22螺丝
BS322 M3x22 Screw
......2
M3x15螺丝
BS315 M3x15 Screw
Aluminium Washer
TU0250-6 3.1x5.5x2
3.1x5.5x2铝垫片
Bag-C
M3x10螺丝
M3x10 Screw
BS310
..............6
M3x10螺丝
BS310 M3x10 Screw
Bag-C

Rear Hub Carrier
后轮座
Rear Suspension
后悬吊系统
20
19
10
65mm后CVD
65mm Rear CVD
T02263
球头-长
Ball Stud-Long
TS4042
后轮座-左
Rear Hub-L
TR4011
后轮轴套
Rear Bearing Collar
T02183
< R >
................2
......................2
..............2
.....................4
后轮轴套
T02183 Rear Bearing Collar
1.7x11钢针
T02262 1.7x11 Pin
球头-长
TS4042 Ball Stud-Long
5x10x4轴承
B051004 5x10x4 Ball Bearing
5x10x4轴承
5x10x4 Ball Bearing
B051004
1.7x11钢针
1.7x11 Pin
T02262
后六角座
Rear Hex Mount
T02173
LR
Assemble both Left and Right
組裝左和右
Bag-C
LR
M2.5x4螺丝
M2.5x4 Screw
BS2504
2.5x30摆臂轴
2.5x30 Arm Pin
TR4046
2.5x6x1垫片
2.5x6x1 Washer
TR4011
......................4
......................2
......................2
M2.5x4螺丝
BS2504 M2.5x4 Screw
2.5x6x1垫片
TR4011 2.5x6x1 Washer
2.5x30摆臂轴
TR4046 2.5x30 Arm Pin
Bag-C

Turnbuckle
拉杆
Rear Suspension
后悬吊系统
22
21
11
3x40拉杆
3x40 Turnbuckle
T02255
4.8mm球头座-长
4.8mm Ball End-Long
T04014
4mm
▲Projection.Note direction
注意方向
Rear Upper-L
后上拉杆-左
1:1 x1
▲Projection.Note direction
注意方向
Rear Upper-R
后上拉杆-右
1:1 x1
approx 17.5mm
大约17.5mm
approx 17.5mm
大约17.5mm
...................2
3x40拉杆
T02255 3x40 Turnbuckle
..................................4
4.8mm球头座-长
T04014 4.8mm Ball End-Long
Ture-to-scale diagram
圖形比例
1:1
Assemble as many times as specified
需組裝數量
x1
Bag-C
Bag-C

Rear Swaybar
后防倾杆
24
Rear Swaybar
后防倾杆
23
12
Bag-C
M3x10螺丝
M3x10 Screw
T04150
x2
4.8mm球头座-短
4.8mm Ball End-Short
T04150
防倾杆球头
Swaybar Ball Stud
T04109
Assemble as many times as specified
需組裝數量
x2
Bag-C
M2.5x10螺丝
M2.5x10 Screw
T02259
防倾杆座上
Swaybar Mount Upper
T02259
防倾杆座下
Swaybar Mount Lower
T02259
防倾杆-1.2
Swaybar-1.2
T04152
M3x3螺丝
M3x3 Screw
T02259
M3x3螺丝
M3x3 Screw
T04109
...................2
................................4
M3x3螺丝
T02259/T04109 M3x3 Screw
M2.5x10螺丝
T02259 M2.5x10 Screw

Shock Absorber
避震器
26
13
Bag-D
Shock Absorber
避震器
25
弹簧
Spring
TU0250-8
1mm压垫-黑色
1mm Washer-Black
TU0250-8
1mm压垫-白色
1mm Washer-White
TU0250-8
2.5mm压垫-白色
2.5mm Washer-White
TU0250-8
2.8x1.9 O环
2.8x1.9 O-ring
TU0250-8
2.8x1.9 O环
2.8x1.9 O-ring
TU0250-8
9x1 O环
9x1 O-ring
TU0250-8
避震下盖
Shock Below Cover
TU4160
9x1 O环
TU0250-8 9x1 O-ring
2.8x1.9 O环
TU0250-8 2.8x1.9 O-ring
2.5mm压垫-白色
TU0250-8 2.5mm Washer-White
1mm压垫-白色
TU0250-8 1mm Washer-White
1mm压垫-黑色
TU0250-8 1mm Washer-Black
弹簧
TU0250-8
Spring
...........…………...4
...........…………..4
...........…………..4
...........……….....8
...........………...8
...........…………......4
x2
FR
前避震器筒身-短
Front Shock Absorber Body-Short
T04158
后避震器筒身-长
Rear Shock Absorber Body-Long
T04159
Bag-D
Assemble both front and rear
組裝前面和後面
FR
Assemble as many times as specified
需組裝數量
x2
前面用短
Front For Short
后面用长
Rear For Long
前面用短
Front For Short
后面用长
Rear For Long
前避震器轴
Front Shock Absorber Shaft
TU0250-1
后避震器轴
Rear Shock Absorber Shaft
TU0250-2
2.3 E扣
2.3 E-ring
Rear Piston-White
TU0250-1/TU0250-2
12x1 O环
12x1 O-ring
TU0250-8
5.8球头
5.8 Ball stud
T02062
5.8球头座
5.8 Ball stud
T02187
2.3 E扣
2.3 E-ring
TU0250-1/TU0250-2
前活塞-黑色
后活塞-白色
Front Piston-Black
TU0250-7
..................................8
.........................2
.........................2
.........................4
............................4
......................................4
2.3 E扣
TU0250-1/TU0250-2 2.3 E-ring
前活塞-黑色
TU0250-7 Front Piston-Black
后活塞-白色
TU0250-7 Rear Piston-White
5.8球头座
T02187 5.8 Ball End
5.8球头
T02062 5.8 Ball Stud
12x1 O环
TU0250-8 12x1 O-ring
x2
FR

14
28
27 Shock Absorber
避震器
Front Suspension
前悬吊系统
Bag-D
避震上盖
Shock Upper Cover
前面用短
Front For Short
后面用长
Rear For Long
前面用短
Front For Short
后面用长
Rear For Long
TU0266-7
.....................4
14x1.5 O环
TU0250-8 14x1.5 O-ring
14x1.5 O环
14x1.5 O-ring
TU0250-8
弹簧下座
Below Spring Mount End
TU0266-7
弹簧调节座
Spring Adjuster
T04161
前避震器弹簧-中
Front Shock Absorber Spring-Medium
TU0250-12F
后避震器弹簧-中
Rear Shock Absorber Spring-Medium
TU0250-10R
400#
400#
x2
FR
M2.5x4螺丝
M2.5x4 Screw
TU0266-7
M2.5x4螺丝
M2.5x4 Screw
将螺丝锁紧。
Please locking the screw.
TU0266-7
……………............4
M2.5x4螺丝
TU0266-7 M2.5x4 Screw
将螺丝松开。
Please loosing the screw.
Assemble both front and rear
組裝前面和後面
FR
Assemble as many times as specified
需組裝數量
x2
M3x15螺丝
M3x15 Screw
BS315
M3尼龙螺母
M3 Nylon Nut
T02084
.........................2
M3x15螺丝
BS315 M3x15 Screw
.........................................2
M3尼龙螺母
T02084 M3 Nylon Nut
Bag-D

15
30 Front Suspension
前悬吊系统
29 Rear Suspension
后悬吊系统
M3x12螺丝
M3x12 Screw
BS312
M3尼龙螺母
M3 Nylon Nut
T02084
..............................2
M3x12螺丝
BS312 M3x12 Screw
.........................................2
M3尼龙螺母
T02084 M3 Nylon Nut
Bag-D
Assemble both Left and Right
组装左和右
LR
M3x10螺丝
M3x10 Screw
BS310
主底盘
Main Chassis
T02249
......................6
M3x10螺丝
BS310 M3x10 Screw
Bag-E

31 Rear Suspension
后悬吊系统
32 Motor
马达
16
M3x10螺丝
M3x10 Screw
FS310
..........6
M3x10螺丝
FS310 M3x10 Screw
Bag-E
M3x5螺丝
M3x5 Screw
BS305
齿轮盖塞
Gear Cover Button
T02005
马达齿-21T
Pinion Gear-21T
T02053
M3x8螺丝
M3x8 Screw
CS308
M3x3螺丝
M3x3 Screw
T02053
齿轮盖
Gear Cover
T02005
Tighten the screws with one sheet of paper
inserted between both gears.
两齿轮之间的间隙大约为一张普通纸的厚度。
3x7x0.8垫片
3x7x0.8 Washer
W3708
马达
Motor
X
......................2
..............................2
....................2
..............................1
M3x5螺丝
BS305 M3x5 Screw
M3x8螺丝
CS308 M3x8 Screw
M3x3螺丝
T02053 M3x3 Screw
3x7x0.8垫片
W3708 3x7x0.8 Washer
Bag-E

17
Steering Servo-H(24T) Steering Servo-S(23T)
转向伺服臂H(24T) 转向伺服臂S(23T)
Select for your servo
根据伺服器选择
3x7x0.8垫片
3x7x0.8 Washer
W3708
球头-银色
Ball Stud-Silver
T02061
M3x8螺丝
M3x8 Screw
BS308
伺服机
Servo
X
球头座-短
T02030 4.8 Ball End-Short
球头-银色
T02061 Ball Stud-Silver
.....................1
.................2
................5
M3x8螺丝
BS308 M3x8 Screw
....................4
3x7x0.8垫片
W3708 3x7x0.8 Washer
................1
M3x10螺丝
T02030 M3x10 Screw
SANWA
T02035
Sanwa servo
T02028
T02030
Steering Servo
转向伺服系统
33
Bag-E
Steering Servo
转向伺服系统
34
Bag-E
M3x8螺丝
M3x8 Screw
FS308
................2
M3x8螺丝
FS308 M3x8 Screw
XMust be purchased separately
需另購物品
