Techni Mobili RTA-1305 User manual

Imported By
Thank you for purchasing one of our products.
Please read carefully the assembly instructions before the installation.
Do not discard this manual or any of the packaging material until the unit
has been completely assembled.
MODEL RTA-1305
ASSEMBLY INSTRUCTIONS
Cabinet and metal frame are interchangeable:

Small drawer left
slider
Small drawer right
slider
File drawer left
slider
File drawer right
slider
Small drawer left
panel
Small drawer back
panel
Small drawer right
panel
Drawers bottom
panel
Small drawer front
panel
File drawer left
panel
File drawer back
panel
File drawer right
panel
Hanging files tubes
(Set of 2 pcs)
File drawer front
panel
Left panel Right panel
Back panel Horizontal panel Cabinet top panel Bottom panel
MAIN PARTS LIST
①
x2 ②
x2 ③
x1 ④ x1
⑤
x2 ⑥
x2 ⑦
x2 ⑧ x3
⑨
x2 ⑩ x1 ⑪ x1 ⑫ x1
⑬
x1
SET
⑭
x1 ⑮ x1 ⑯ x1
⑰
x1 ⑱ x2 ⑲ x1 ⑳ x1
P.2
RTA-1305
P.2
NOTE: Parts 1 and 2 are interchangeable NOTE: Parts 3 and 4 are interchangeable

M5x60mm Cam lock Cam bolt M4x12mm ⌀6x30mm
Cabinet studs M6x12mm Frame studs M6x30mm Allen wrench
Main panel Metal frame Support tube
MAIN PARTS LIST
㉑
x1 ㉒
x1 ㉓ x2
🅕
x4 🅖
x16 🅗 x2 🅘 x2
P.3
RTA-1305
P.3
HARDWARE/SCREWS LIST:
MAIN PARTS LAYOUT (FOR REFERENCE):
🅐
x16 🅑
x24 🅒 x24 🅓 x24
🅙
x1
🅔
x12
21
17 14
9
19
15
23
22 20
16
9
NOTE: You will need for the assembly a Phillips screwdriver and mallet/hammer (not included).

☛This unit uses cam bolts and locks. The following explains how to use them.
This is not an assembly step; it is a guide for when you are actually doing the assembly using this
kind of hardware.
1. Screw the bolt into the
corresponding panel.
2. In the other panel, insert the
cam lock and align it so it can
properly receive the bolt, then join
both panels (the cam locks might
come pre-installed in this unit).
3. The panels might have a very
small gap which is normal; turn the
cam lock clockwise to lock the
parts together and the gap will also
close.
Cam Bolt Cam Lock
ALIGNMENT
DIRECTION
BEFORE YOU START THE ASSEMBLY, PLEASE READ THE FOLLOWING TIPS AND WARNINGS.
•Do a quick inventory to make sure the product contains all the parts and hardware.
•Missing, damaged and defective parts can be replaced at no cost to you. Please refer to the CONTACT card
included with the product.
•The replacement parts service is limited to the continental United States. If you reside in Hawaii, Puerto Rico,
U.S. Dependencies or other countries, please contact the supplier from where the unit was purchased.
•
If during assembly you find an issue or need clarification, please contact our Customer Service for assistance.
Please refer to the CONTACT card included with the product.
•On each step read the instructions and analyze the illustrations thoroughly before proceeding to do the
assembly.
•Make sure you understand which hardware will be used on each step. Using the wrong size of screw, bolt or
pin might strip the threads or cause damage to the part in which it is being used.
•To avoid misalignments, always leave the screws loose and tighten them until all pieces are positioned
correctly.
•Do not overtighten or force the screws as they might break, strip, damage the threads of the holes or get
stuck inside the part.
•Sometimes the laminate might cover partially or entirely the hole on a panel, but the hole should still be
located under the laminate.
•If there is no visible hole for the screw, pass and press the tip of your finger over the area where the hole
should be located to feel the indentation, and once found, carefully pierce the laminate to reveal the hole
underneath.
•If the hole seems too small for the screw, first make sure you are using the correct size of screw and that it’s
been installed in the correct hole. If the hole still appears to be too small, carefully pierce the laminate to
reveal the hole’s actual size.
P.4
RTA-1305
P.4

ASSEMBLY STEPS
Assemble the small drawer back panel ⑥to the side panels ⑤and ⑦using screws Ⓐ
as shown.
STEP 2
P.5
RTA-1305
P.5
STEP 1
Hardware/Tools:
🅐
4
Pcs
STEP 3
Hardware/Tools:
🅑
4
Pcs
🅒
4
Pcs
(NOT INCLUDED)
Assemble the drawer front panel ⑨to the side panels ⑤and ⑦using cam locks Ⓑand
cam bolts Ⓒas shown and explained in page 4.
Please refer to page 4.
REPEAT STEPS 1, 2 AND 3 TO ASSEMBLE THE SECOND SMALL DRAWER.
(Front)
⑤
⑥⑦
Insert the drawer bottom panel ⑧in between the groves of panels ⑤, ⑥and ⑦as
shown.
☛Tip: The laminate might be covering the groves, if this is the case, pierce first with the tip
of a pen or screwdriver.
⑤
⑥⑦
⑧
⑤
⑦
⑨

Grab all the sliders ①, ②, ③and ④and detach the smaller part ⓑon all of them by
pressing up or down the lever as shown. Parts ⓑwill be used on steps 5 and 9, while
parts ⓐwill be used on step 10.
☛Tip: Make sure the sliders are completely opened, and press hard by the thickest part of
the lever, not the tip.
STEP 4
P.6
RTA-1305
P.6
Assemble the rails ①ⓑand ②ⓑto the side panels ⑤and ⑦using screws Ⓓas
shown.
☛Tip: Both rails are exactly the same.
STEP 5
Hardware/Tools:
🅓
4
Pcs
(NOT INCLUDED)
REPEAT THIS STEP FOR THE
SECOND SMALL DRAWER.
PAY ATTENTION TO THE
ORIENTATION OF THE SLIDERS
(Front)
⑤
⑦
①ⓑ
②ⓑ

Insert the drawer bottom panel ⑧in between the groves of panels ⑩, ⑪and ⑫.
☛Tip: The laminate might be covering the groves, and if this is the case,
pierce first with the tip of a pen or screwdriver.
STEP 7
P.7
RTA-1305
P.7
Using screws Ⓐassemble the left panel ⑩and the right panel ⑫to the back panel ⑪
with the file tubes ⑬inserted in between the panels ⑩and ⑫as shown.
☛Tip: This drawer is for archiving Letter-size files only, but it can also be used
for regular storage if you leave it without the tubes ⑬.
STEP 6
Hardware/Tools:
🅐
4
Pcs
(Front)
⑪
⑩
⑫
⑬
⑬
⑩
⑪⑫
(Back)
⑧
(Front)

Assemble the sliders ③ⓑand ④ⓑto the side panels ⑩and ⑫using screws Ⓓas
shown.
☛Tip: Both rails are exactly the same.
STEP 9
Hardware/Tools:
🅓
4
Pcs
(NOT INCLUDED)
P.8
RTA-1305
P.8
Assemble the drawer front panel ⑭to the side panels ⑩and ⑫using cam locks Ⓑand
cam bolts Ⓒas shown and explained in page 4.
STEP 8
Hardware/Tools:
🅑
4
Pcs
🅒
4
Pcs
(NOT INCLUDED)
Please refer to page 4.
⑩
⑫
(Front)
⑭
⑩
⑫
③ⓑ
④ⓑ
PAY ATTENTION TO THE
ORIENTATION OF THE SLIDERS
(Front)

P.9
RTA-1305
P.9
With the panels ⑮and ⑯positioned as shown, use screws Ⓓto assemble the sliders
①ⓐand ②ⓐto the 2 top sets of holes for the smaller drawers, and the sliders ③ⓐ
and ④ⓐto the bottom set of holes for the file drawer as shown.
☛Tip: Rails ①ⓐand ②ⓐare the same; ③ⓐand ④ⓐare the same.
☛Assembly tip: Open the slider, attach first on the back, then close the slider and move
away the ball bearings to screw on the front through the opening as shown.
First place the panels ⑮and ⑯oriented as shown below
(Front)
STEP 10
Hardware/Tools:
🅓
12
Pcs
(NOT INCLUDED)
(Front)
(Back)
(Back)
The front has
4 holes near
the edge
Then assemble the sliders: ①ⓐand ②ⓐfor the 2 top sets
of holes, ③ⓐand ④ⓐfor the bottom set of holes.
⑮⑯
(Back)
⑮⑯
③ⓐ
②ⓐ
④ⓐ
①ⓐ
①ⓐ
(Front)
The sliders open
towards the front
②ⓐ

P.10
RTA-1305
P.10
First attach the cam bolts Ⓒto the back holes of panels ⑮and ⑯, then for the sets of
holes at the front, attach the bolts Ⓒto the top holes and insert the wooden pins Ⓔinto the
bottom holes as shown.
Insert the cam locks Ⓑinto back panel ⑰and into both panels ⑱and assemble these
panels in between the left panel ⑮and the right panel ⑯as shown and explained in
page 4.
STEP 12
Hardware/Tools:
🅑
8
Pcs
(NOT INCLUDED)
STEP 11
Hardware/Tools:
🅒
8
Pcs
🅔
4
Pcs
(NOT INCLUDED)
(Front)
⑮ ⑯
Ⓒ
Ⓔ
Ⓒon top
hole; Ⓔon
bottom
Please refer to page 4.
⑮
⑯
⑰
⑱
⑱
(Front)

Assemble the cabinet top panel ⑲to panels ⑮and ⑯using cam locks Ⓑas shown
and explained in page 4.
P.11
RTA-1305
P.11
With the cabinet top panel ⑲upside-down, attach the cam bolts Ⓒto the exterior holes
and insert the wooden pins Ⓔinto the interior holes as shown.
STEP 13
Hardware/Tools:
🅒
4
Pcs
🅔
4
Pcs
(NOT INCLUDED)
STEP 14
Hardware/Tools:
🅑
4
Pcs
(NOT INCLUDED)
Please refer to page 4.
(Bottom surface)
⑲
Ⓒon exterior hole;
Ⓔon interior
Ⓒ
Ⓔ
⑮
⑯
(Top surface)
(Front)
⑲

Place the parts assembled in step 14 upside-down, and assemble the bottom panel ⑳to
panels ⑮AND ⑯using screws Ⓐas shown.
P.12
RTA-1305
P.12
First attach the cabinet studs Ⓕto the bottom surface of bottom panel ⑳, then insert the
pins Ⓔinto the interior holes on the top surface as shown.
☛Make sure to install the pins into the interior holes, as the exterior holes are for screws on
the next step.
STEP 15
Hardware/Tools:
🅔
4
Pcs
🅕
4
Pcs
(Not included)
STEP 16
Hardware/Tools:
🅐
4
Pcs
(NOT INCLUDED)
(Top surface)
⑳
THESE ARE THE
STUDS WITH SHORT
THREADED RODS
⑮
⑯
(Bottom Surface)
⑳
CABINET SHOWN UPSIDE-DOWN

P.13
RTA-1305
P.13
With the main panel ㉑upside-down, first assemble the frame ㉒and the support tubes ㉓
using screws Ⓖ, then attach the studs Ⓗto the structure ㉒as shown.
STEP 17
Hardware/Tools:
🅖
16
Pcs
🅗
2
Pcs
THESE ARE THE
STUDS WITH LONG
THREADED RODS
Next you will have 2 assembly options:
A) Assemble with the drawers on the right side;
B) Assemble with the drawers on the left side.
Choose your preference and proceed to step 18.
🅐🅑
㉑
(Bottom surface)
The sets of holes for
the frame are closer to
the edge than the
holes for the tubes.
㉒
㉓
㉓

First make sure that the ball bearings on all the sliders inside the cabinet are all the way to
the front, then insert the drawers very slowly, making sure their rails engage into the black
plastic guide of the sliders on both sides.
☛Assembly tip: First insert the bottom drawer, then the middle, and the top last.
P.14
RTA-1305
P.14
Place the top parts assembled in step 17 over the cabinet assembled in step 16, making the
holes of the support tubes ㉓align with the holes on panel ⑲, and assemble them from
inside the cabinet using screws Ⓘas shown.
☛Assembly tip: First screw loosely on the back support tube, then screw on the front
support tube, and finally proceed to tighten both screws.
STEP 19
STEP 18
Hardware/Tools:
🅘
2
Pcs
OR:
㉓
⑲
㉑
OR:
⑭
⑨
⑨

AFTER THE ASSEMBLY IS DONE, PLEASE READ CAREFULLY THE FOLLOWING
CARE AND MAINTENANCE WARNINGS:
•Do not exceed the indicated weight limits.
•Do not expose the surfaces to direct sunlight or to extreme environmental conditions.
•Clean the surfaces preferable with a clean cloth damped in a solution of mild soap and water, then dry with a
clean towel.
•Do not use solvents or abrasive materials to clean the unit.
•If you decide to use a cleaning agent, test first on an area hidden from view such as underneath the tabletop.
•Do not seat on the unit or lean against it.
•Do not allow small children to play under or over the unit.
•Do not allow small children to reach inside the drawers without your supervision.
•Do not drag the table to move it. It must be handled and lifted by at least 2 persons when moving in the same
or adjacent rooms.
•Before moving the unit, make sure to remove any object that is heavy or might fall off.
•When lifting the unit, use both hands and bend your knees, not your backs.
•
When transporting the unit to places far away, protect and secure the unit to avoid damage in transit. You may
also disassemble it partially by following steps 18 and 19 in reverse order.
•Shall any part of the unit become defective during the warranty period, replacement parts might be available
to you at no charge. Please refer to the WARRANTY card included with the product.
•The warranty does not extend to regular wear and tear, nor t
he manufacturer assumes liability for damages or
consequences due to accidents, incorrect assembly, negligence, improper use, modifications, or not heeding
the above warnings.
•The warranty is limited to the continental United States. If you reside in Hawaii, Puerto Rico, U.S.
Dependencies or other countries, please contact the supplier from where the unit was purchased.
P.15
RTA-1305
P.15
11 Lbs. (5 Kg)
110 Lbs. (50 Kg)
11 Lbs. (5 Kg)
11 Lbs. (5 Kg)
WEIGHT LIMITS
