Techni Mobili RTA-M101 User manual

ASSEMBLY INSTRUCTIONS FOR CHAIR MODEL
RTA-M101
PARTS LIST
ATTENTION: Before you begin the assembly, make sure
that all parts are included in good condition.
ATTENTION:
⚠Follow the instructions step by step.
⚠To avoid misalignments, leave the screws loose and do not tighten them until all are in their respective places.
⚠Do not overtighten or force the screws as they could break, strip, or damage the threads of the holes.
⚠Using the wrong size of screws on a part could result in damage to the screw or the part.
6
ABackrest, x1
BSeat, x1
C
Backrest
Support, x1
DMechanism,
x1
EHydraulic
Gas Lift, x1
F
Covers for
Gas Lift,
x1 set
G
Star Base,
x1
H
Caster, x5
16x16mm,
x4
26x25mm,
x2
3
3B: Metal Bracket
4Screw Knob
x1
58x20mm
x1
6Allen
wrench, x1
STEP 1
Insert the casters (F) into the legs of the
base (C) using pressure, then place
the gas lift (E) in the middle of the base,
and cover it with (H) as shown.
STEP 2
With the seat positioned as shown,
assemble the mechanism (D) to the seat
(B) using screws (1) as shown. The handle
will be located on the RIGHT when the
chair is finished.
STEP 3
Assemble the support (G) to the
backrest (A) using the cover set (3)
and screws (2) as shown.
STEP 4
Secure the support (G) to the
mechanism (D) using screw knob (4)
and screw (5) as shown.
STEP 5
Place the top over the base, making
sure the tip of the gas lift enters into
the hole of the mechanism.
Make sure that
all the screws
are tightened
before you sit
on the chair for
the first time.
Back cover,
x1 SET
3A: Plastic cover
1
D
B
A
G
3B
2
NOTE:
3A
3B
G

CHAIR’S FUNCTIONS:
To raise or lower the chair’s height, pull UP the lever that is under the seat. The chair goes down while
sitting on it, or up if you lift your body.
NOTE: This chair does not recline.
WARNINGS:
•Do not stand up on the chair or use it as ladder.
•Use the chair to seat only one person at a time.
•Do not use the chair if parts are damaged or if screws are loose or missing.
•Do not seat near the edge of the seat and always sit properly on the chair to avoid going beyond your balance point and fall off the chair.
•The chair is intended for teenagers and adults. If small children are using the chair, please keep close observation on them.
•Do not allow small children to play with the chair.
•Not paying attention to these warnings could result in severe injuries.
CARE AND MAINTENANCE:
•To clean the chair it is recommended to use a soft cloth lightly damped in a solution of smooth soap and water, then dry with a clean towel.
•Do not use solvents or abrasive materials to clean any part of the chair.
•Before applying a cleaning agent, test on a small hidden area of the chair, like underneath the seat.
•Do not expose the product to direct sunlight or to extreme environmental conditions.
•Every 4 months, inspect the chair completely and make sure that all screws are tighten.
