Technics ST-HD501 User manual

ORDERNO.AD9902016C2
Tuner
ST-HD501
Colour
(N)...................GoldType
Area
E.....................Europe, East Europeand Russia.
System:SC-HD501
SPECIFICATIONS
1

1. BeforeRepair
Thisequipment(ST-HD501), whichisacomponentofthesystem, issuppliedwithpowerfrom
theamplifier(SE-HD501).Whenrepairing thisequipmentor checking operation ofthesystem, be
suretoconnecttheamplifierwithit.
Powersupplyand operation check inthestateofitas asingleequipmenetareimpracticable.
2. Operating Instructions
3. About the Self-DiagnosticMode
Thisunitisepuippedwithaself-diagnosticfunction which, intheeventofamalfunction,
automaticallydisplays acodeindicating thenatureofthemalfunctions.Use thisself-diagnostic
function whenservicing theunit.
4. PowerSource ON/OFF and Signal Check
TooperatethisunitST-HD501 normally, itisnecessaryfor connecting totheunitSE-HD501.
Whenoperating theunitST-HD501, besuretoconnecttheunitSE-HD501 withincluded
connection cable.
1. Shortthesection betweenthejumper(J210), TP302 (A.GND)and
(J212)(D.GND), and as well as thesection betweenthejumper
(J403), TP303(CT)and (J212)(D.GND).(Asshownin Fig.1.)
2. Connect withtheAmplifier(SE-HD501).(Asshownin Fig.1.)
3. Connect theACmainsleadtoAmplifier(SE-HD501).(Asshownin
Fig.1.)
4. Connect thespeakerstospeakerinputterminal.(AsshowninFig.1.)
5. Turnon thepoweroftheAmplifier(SE-HD501).
6. Press INPUTSELECTORtoselect theexternal souce (EXT/MD)of
theAmplifier(SE-HD501).
7. Inputasound signal toexternal inputterminal ofTuner(ST-
HD501), and confirm tobeoutputtedfromthespeaker.
Fig.1
2

5. Operation Checks and Component Replacement
Procedures
3

4

6. Wiring Connection Diagram
7. Block Diagram
8. SchematicDiagramNotes
8.1. SchematicDiagramNotes
-Thisschematicdiagrammaybemodifiedat anytimewith
developmentofnew technology.
5

Notes:
-S601:Band select (FM/AM)switch.
-S602:Displaymodeselect (RDSDISPLAYMODE)switch.
-S603:FMmodeselect (AUTO/MONO)switch.
-S604:Tuning mode(TURN MODE)switch.
-S605:Tuning/timeadjust ( )switch.
-S606:Tuning/timeadjust ( )switch.
-S607:Set (SET)switch.
-S608:Clock/timer, demo(CLOCK/TIMER/-DEMO)switch.
-S609:Recordtimer( REC)switch.
-S610:Playtimer( PLAY)switch.
-Indicatedvoltagevalues arethestandardvalues fortheunit
measuredbytheDC electroniccircuittester(high-impedance) with
thechassistakenas standard. Therefore, theremayexist some
errorsinthevoltagevalues, depending on theinternal impedance
oftheDC circuittester. /
Nomark:FMmode
(): AMmode
Importantsafetynotice:
Componentsidentifiedbymarkhave special characteristics impotantfor safety.
Furthermore, special partswhichhave purpose offire-retardant(resistors), high-qualitysound
(capacitors), low-noise (resistors), etc. areused. Whenreplacing anyofcomponents, besureto
use onlymanufacturer’sspecifiedpartsshowninthepartslist.
Caution!
ICand LSIaresensitive tostaticelectricity.
Secondarytroublecanbepreventedbytaking careduring repair.
Coverthepartsboxes madeofplastics withaluminum foil.
Ground thesoldering iron.
Putaconductive maton theworktable.
DonottouchthelegsofICor LSIwiththefingersdirectly.
Voltageand signal line
6

:Positive voltageline
:FMsignal line
:AMsignal line
:Negative voltageline
:FMOSCsignal line
:AMOSCsignal line
8.2. TypeIllustration ofTransistorsand Diodes
8.3. Diagram
9. Printed Circuit BoardDiagram
10. Terminal Function of IC’s
-IC302 (M62433AFP):DIGITALSOUND CONTROL
7

Pin
No. Mark I/O/ Division Function
1PS-IN O R/Loutputterminal for
surround
2PS+IN I Phase shift filterinput
terminal for surround (Not
used, open)
3KIN1 O Key control adaptor output
terminal (Notused, open)
4KOUT1 I Key control adaptor input
terminal / (Notused,
connectedtoGND)
5TAPEREC1 O Rec signal outputterminal
from / surround mixamp.
terminal
6MDREC1 O Selectcommon outputrec
signal / outputterminal
7EXT
OUT1
8DPL1 I Tonesignal inputterminal
(Notused, connectedto
GND)
9F1F1 I Resonance impedance
connect/ terminal (Not
used, open)
10 F1O1 O Resonance bufferamp
outputterminal / (Notused,
open)
11 FIN1 I Resonance bufferamp
inputterminal / (Notused,
open)
12 F2F1 I Resonance impedance
connect/ terminal
13 F2O1 O Resonance bufferamp
outputterminal
14 F2IN1 I Resonance bufferamp
inputterminal
15 F3F1 I Resonance impedance
connect/ terminal
16 F3O1 O Resonance bufferamp
outputterminal
17 F3IN1 I Resonance bufferamp
inputterminal
18 F4F1 I Resonance impedance
connect/ terminal
19 F4O1 O Resonance bufferamp
outputterminal
8

Pin
No. Mark I/O/ Division Function
20 F4IN1 I Resonance bufferamp
inputterminal
21 F5F1 I Band pass filterconnect
terminal / (Connectedto
GND through capacitor)
22 GEQOUT1 O Tonesignal outputterminal
23 VOLIN1 I R laddervolumeinput
terminal
24 VOLOUT1 ORladdervolumeoutput
terminal
25 BB1 — Bass boostcapacity
connection / terminal(Not
used, connectedtoGND)
26 BUFIN I Bass boostamp(+)input
terminal
27 BUFNF1 I Bass boostamp(-) input
terminal
28 BUFOUT1 OBass boostampoutput
terminal
29 PORTA O PortAoutputterminal (Not
used, open)
30 PORTB O PortBoutputterminal
31 DVDD IPowersupplyterminal
32 CLK I Clock inputterminal for
serial datatransfer
33 DATA I Control datainputterminal
34 LATCH I Latchsignal inputterminal
35 DGND — GND terminal
36 AVDD IPowersupplyterminal
37 BUFOUT2 OBass boostampoutput
terminal
38 BUFNF2 I Bass boostamp(-) input
terminal
39 BUFIN2 I Bass boostamp(+)input
terminal
40 BB2 I Bass boostcapacity
connection / terminal(Not
used, connectedtoGND)
41 VOLOUT2 ORladdervolumeoutput
terminal
42 VOLIN2 I R laddervolumeinput
terminal
43 GEQOUT2 O Tonesignal outputterminal
9

Pin
No. Mark I/O/ Division Function
44 F5F2 I Band pass filterconnect
terminal / (Connectedto
GND through capacitor)
45 F4IN2 I Resonance bufferamp
inputterminal
46 F4O2 O Resonance bufferamp
outputterminal
47 F4F2 I Resonance impedance
connect/ terminal
48 F3IN2 I Resonance bufferamp
inputterminal
49 F3O2 O Resonance bufferamp
outputterminal
50 F3F2 I Resonance impedance
connect/ terminal
51 F2IN2 I Resonance bufferamp
inputterminal
52 F2O2 O Resonance bufferamp
outputterminal
53 F2F2 I Resonance impedance
connect/ terminal
54 F1IN2 I Resonance bufferamp
inputterminal / (Notused,
open)
55 F1O2 O Resonance bufferamp
outputterminal / (Notused,
open)
56 F1F2 I Resonance impedance
connect/ terminal (Not
used, open)
57 DPL2 I Tonesignal inputterminal /
(Notused, connectedto
GND)
58 EXT
OUT2 OSelectcommon outputrec signal / outputterminal
59 MD
REC2 O
60 TAPE
REC2 O Rec signal outputterminal from / surround mixamp.
terminal
61 MICIN I Micsignal inputterminal /
(Notused, connectedto
GND)
10

Pin
No. Mark I/O/ Division Function
62 KOUT2 I Key control adaptor input
terminal / (Notused,
connectedtoGND)
63 KIN2 O Key control adaptor output
terminal (Notused, open)
64 BPOUT O Band pass filterampoutput
terminal for vocal cancel
65 BPIN I Band pass filterampinput
terminal for vocal cancel
66 CD I Inputterminal for Rch
67 TUNER
68 MD
69 TAPE
70 AUXH
71 AUXL
72 AVSS O Powersupplyterminal
73 AGND — GND terminal
74 AUXL I Inputterminal for Lch
75 AUXH
76 TAPE
77 MD
78 TAPE
79 CD
80 DELIN I R/Linputterminal for
surround
-IC701 (M30218MAA103):FL DRIVE/ SYSTEMCONTROL
11

Pin
No. Mark I/O/ Division Function
1P97/
CLKOUT I/O Communication clock
velocityterminal / (“H”:
nomal, “L”:CD-TEXT)
2P96/DA1/
SCLK22
OClock outputterminal for
serial datatransfer
3P95/
SCLK21 ICD &Tapecommunication
clock inputterminal
4P94/
SOUT2 OCD &Tapecommunication
dataoutputterminal
5P93/SIN2 I CD &Tapecommunication
datainputterminal
6P92/ /
SSTB2 I CD &Tapecommunication response inputterminal
7P91/ /
SBUSY2 OCD communication request output/ terminal
8P90/ /
SRDY2 OTapecommunication requestoutputterminal
9CNVSS —GND terminal
10 P87/
XCIN ICrystal oscillator connection terminal / (f=
32kHz)
11 P86/ /
XCOUT O
12 /RESET I Resetinputterminal
(“L”:Micon reset)
13 XOUT O Mainclock ceramic
oscillator outputterminal (f=
10MHz)
14 VSS — GND teminal
15 XIN I Mainclock ceramic
oscillator input/ terminal (f=
10MHz)
16 VCC I Powersupplyterminal
17 P85/INT5 I Powerfailuredetection
inputterminal
18 P84/INT4 I/O CR timerterminal for watch
backup
19 P83/INT3 O Latchoutputterminal to
IC302 (M62433AFP)
20 P82/INT2 I Remotecontrol datainput
terminal
12

Pin
No. Mark I/O/ Division Function
21 P81/INT1 — ConnectedtoGND
22 P80/INT0
23 P77/
TA4IN/
TA2OUT/
CLK1
24 P76/
TA3IN/
TA1OUT/
CLK1
25 P75/
TA2IN/
TA0OUT/
RXD1
I
26 P74/
TA1IN/
YA4OUT/
TXD1
—
27 P73/
TA0IN
/TA3OUT
I
28 P72/
TB2IN —
13

Pin
No. Mark I/O/ Division Function
29 P71/
TB1IN ITunerreception detect inputterminal
30 P70/
TB0IN OChipenablesignal output terminal toIC501
(LC72722PMTLM)
31 P47/
CST0
/RST0
OChipenablesignal output
terminal toIC102
(LC72131MDTLM)
32 P46/
CXL0 OClock outputterminal to IC501 (LC72722PMTLM)
33 P45/
RXD0 IStereoinputterminal from IC102 (LC72131MDTLM)
34 P44/
TXD0 O Dataoutputterminal from IC102 (LC72131MDTLM)
35 P43/
FLD51 ITunersignal detection input terminal from IC101
(LA1833MN-TLM)
36 P42/
FLD50 IChipselectinputterminal
37
~
40
P41/
FLD49 /
~/ P36/
FLD46
I/O FL segmentcontrol in/
outputterminal
41
~
54
P35/
FLD45
~
P20/
FLD32
OFL segmentcontrol output
terminal
55
~
62
P17/
FLD31
~
P10/
FLD24
63 VCC I Powersupplyterminal
64 P70/
FLD23 OFL segmentcontrol output terminal
65 VSS — GND teminal
66
~
72
P06/
FLD22
~
P00/
FLD16
OFL segmentcontrol output
terminal
73 P57/
FLD15 OFL segmentcontrol output terminal
14

FLD15
terminal
Pin
No. Mark I/O/ Division Function
74
~
80
P56/
FLD14
~
P50/
FLD8
OFL gridcontrol output
teminal
81
~
86
P67/
FLD7
~
P62/
FLD2
OFL gridcontrol output
terminal
87 P61/
FLD1 OFL gridcontrol output terminal
(Notused, open)
88 P60/
FLD0 OFL gridcontrol output terminal
89 VEE I Powersupplytermianl
90
~
92
P107/
AN7
~
P105/
AN5
— ConnectedtoGND
93 P104/
AN4 OMuting outputterminal
(“H”:OFF, “L”:ON)
94
~
96
P103/
AN3
~
P101/
AN1
IAmplfierinputterminal
97 AVSS — ConnectedtoGND
98 P100/
AN0 I Key switchinputterminal
99 VREF I Powersupplyterminal
100 AVCC
11. Replacement PartsList
Note:
*Importantsafetynotice:
Componentsidentifiedbymarkhave special characteristics importantfor safety.
Furthermore, special partswhichhave purposes offireretardant(resistors), high-qualitysound
(capacitors), low-noise (resistors), ets. areused.
Whenreplacing anyofcomponents, besuretouse onlymanufacture’sspecifiedpartsshownin
thepartslist.
*TheparenthesizedindicationsintheRemarks columnsspecifytheareas.
15

Partswithoutthese indicationscanbeusedfor all areas.
*Capacityvalues areinmicrofarads(uF)unless specifiedotherwise, P=Pico-farads(pF)F=Farads
(F)
*Resistance values areinohms, unless specifiedotherwise, 1K=1,000 (OHM), 1M=1,000k (OHM)
Ref. No. PartNo. PartName& Description Pcs Remarks
1RHD30073-K SCREW 4
2RKM0398-S CABINET 1
3XTB3+8JFZ SCREW 1
4REZ1120 FLATCABLE(14P) 2
5RKA0076-N2 FOOT 4
5-1 RKA0083-K CUSHION 4
6XTB3+6G SCREW 4
7RMN0195 FL HOLD PIECE 2
8RGK1138-N SIDEORNAMENT(L) 1
9RGK1139-N SIDEORNAMENT(R) 1
10 RGU1394B-S BUTTON 1
11 XTBS26+8J SCREW 9
12 XTBS3+8JFZ1 SCREW 9
13 XTB3+12JFZ SCREW 4
14 RFKGTHD501EN FRONTPANELASS’Y 1
15 RGK0817-1M SIDEPANEL(L) 1
16 RGK0818-1M SIDEPANEL(R) 1
C101 ECBT1C103NS5 16V0.01U 1
C102 ECEA1CKS101 16V100U 1
C103 ECBT1C103NS5 16V0.01U 1
C104,05 ECBT1H102KB5 50V1000P 2
C106 ECBT1C103NS5 16V0.01U 1
C107 ECBT1H473ZF5 50V0.047U 1
C108 ECBT1H8R2KC5 50V8.2P 1
C109 ECBT1H102KB5 50V1000P 1
C110 ECBT1C103NS5 16V0.01U 1
C111 ECEA1EKS4R7 25V4.7U 1
C112 ECBT1C103NS5 16V0.01U 1
C113 ECBT1H102KB5 50V1000P 1
C114 RCE1HKA3R3BG 50V3.3U 1
C115 ECEA1EKS4R7 25V4.7U 1
C116 ECFR1C333KR 16V0.033U 1
C117,18 ECFR1C183KR 16V0.018U 2
C119 ECQP1391JZ 100V390P 1
C120 RCE1CKA100BG 16V10U 1
C121 RCE1HKAR47BG 50V0.47U 1
C122,23 ECEA1HKS010 50V1U 2
C124 ECBT1H101KB5 50V100P 1
C125 ECEA1CKS220 16V22U 1
C126 ECBT1H473ZF5 50V0.047U 1
C127 ECEA1CKS220 16V22U 1
C129,30 ECEA0JKS101 6.3V100U 2
C131 ECBT1H101KB5 50V100P 1
C132 ECBT1H102KB5 50V1000P 1
C133,34 ECBT1H270JU5 50V27P 2
C136 ECBT1H102KB5 50V1000P 1
16

Ref. No. PartNo. PartName& Description Pcs Remarks
C137 ECFR1E472KR 25V4700P 1
C138 ECBT1C103KS5 16V0.01U 1
C139 ECFR1E472KR 25V4700P 1
C141,42 ECEA1HKS010 50V1U 2
C143,44 ECBT1C472KR5 16V4700P 2
C147 ECBT1H102KB5 50V1000P 1
C148 ECBT1C103NS5 16V0.01U 1
C149 ECBT1H104ZF5 50V0.1U 1
C201-06 ECBT1H101KB5 50V100P 6
C209 ECBT1H102KB5 50V1000P 1
C301,02 RCE1CKA100BG 16V10U 2
C303,04 ECBT1H330J5 50V33P 2
C305,06 ECBT1H102KB5 50V1000P 2
C307,08 ECBT1E103ZF 25V0.01U 2
C309-13 RCE1CKA100BG 16V10U 5
C314 ECBT1H104ZF5 50V0.1U 1
C315-17 ECBT1H470J5 50V47P 3
C318 ECBT1H104ZF5 50V0.1U 1
C321,22 ECBT1H471KB5 50V470P 2
C323,24 ECBT1H102KB5 50V1000P 2
C325,26 RCE1CKA100BG 16V10U 2
C327,28 ECBT1H331KB5 50V330P 2
C329,30 RCE1CKA100BG 16V10U 2
C331,32 ECBT1H331KB5 50V330P 2
C333,34 ECBT1C332KR5 16V3300P 2
C335-38 ECQB1H103JZ 50V0.01U 4
C339-42 ECQV1H473JM3 50V0.047U 4
C343,44 ECQV1H224JM3 50V0.22U 2
C345,46 ECQB1H333JF3 50V0.033U 2
C351 ECBT1H104ZF5 50V0.1U 1
C353-62 ECBT1H101KB5 50V100P 10
C401,02 ECA1EM101 25V100U 2
C403,04 ECBT1E103ZF 25V0.01U 2
C405,06 RCE1AKA470BG 10V47U 2
C407,08 ECEA1CKS101 16V100U 2
C409,10 ECBT1E103ZF 25V0.01U 2
C411 ECEA1CKS101 16V100U 1
C413 ECA1EM101 25V100U 1
C414 ECEA0JKS101 6.3V100U 1
C415 ECBT1E103ZF 25V0.01U 1
C471,72 ECBT1H473ZF5 50V0.01U 2
C481 ECBT1C105ZF5 16V1U 1
C482 ECBT1H104ZF5 50V0.1U 1
C483,84 ECBT1H473ZF5 50V0.01U 2
C491,92 ECBT1H101KB5 50V100P 2
C493 ECEA1VKS470 35V47U 1
C501 ECEA0JKS101 6.3V100U 1
C502 ECBT1E103ZF 25V0.01U 1
C503,04 ECBT1H470J5 50V47P 2
C505 ECBT1H561KB5 50V560P 1
C506 ECBT1E103ZF 25V0.01U 1
C507 ECEA0JKS101 6.3V100U 1
C508 ECBT1H331KB5 50V330P 1
C509 RCE1CKA100BG 16V10U 1
17

Ref. No. PartNo. PartName& Description Pcs Remarks
C541 RCE1HKA3R3BG 50V3.3U 1
C601 ECUV1E103ZFN 25V0.01U 1
C702 ECUV1H180JCN 50V18P 1
C703 ECUV1H200JCN 50V20P 1
C704 ECEA1HKS2R2 50V2.2U 1
C705,06 ECUV1E104ZFN 25V0.1U 2
C707 RCE0JRC102BG 6.3V1000U 1
C708 ECUV1E103ZFN 25V0.01U 1
C709 RCE1CKA100BG 16V10U 1
C710 ECUV1E103ZFN 25V0.01U 1
C711,12 ECUV1E104ZFN 25V0.1U 2
C713 ECEA1HKS100 50V10U 1
C715,16 ECUV1E104ZFN 25V0.1U 2
C717,18 ECUV1E103ZFN 25V0.01U 2
C781,82 ECEA1HKS010 50V1U 2
C792 ECEA0JKS101 6.3V100U 1
CF201 RLFFETNGD01L CERAMIC FILTER 1
CF202 RLFFETMGD01L CERAMIC FILTER 1
CN101A RJT100W07 CONNECTOR(7P) 1
CN101B RJU100W07 CONNECTOR(7P) 1
CN102A RJT100W07 CONNECTOR(7P) 1
CN102B RJU100W07 CONNECTOR(7P) 1
CN103A RJT057W007-1 CONNECTOR(7P) 1
CN103B RJU057W007 CONNECTOR(7P) 1
CN104A RJT057W007-1 CONNECTOR(7P) 1
CN104B RJU057W007 CONNECTOR(7P) 1
CN105A RJT057W007-1 CONNECTOR(7P) 1
CN105B RJU057W007 CONNECTOR(7P) 1
CN701A RJS1A6814 CONNECTOR(14P) 1
CN701B RJS1A6214-1 CONNECTOR(14P) 1
CN702A RJS1A6814 CONNECTOR(14P) 1
CN702B RJS1A6214-1 CONNECTOR(14P) 1
CN703A RJT066H05A CONNECTOR(5P) 1
CN703B RJU066H05 CONNECTOR(5P) 1
D101 MA4051M D10DE 1
D301 MA4051M D10DE 1
D401,02 MA4075HTA D10DE 2
D403 MA4082LTA D10DE 1
D404 MA185TA DIODE 1
D481-84 MA719TA DIODE 4
D491 MA4043M DIODE 1
D492 MA4051M DIODE 1
D541,42 MA165 DIODE 2
D701 MA111TX DIODE 1
D703,04 1SS380TE-17 DIODE 2
D705 MA111TX DIODE 1
D706 1SS380TE-17 DIODE 1
18

Ref. No. PartNo. PartName& Description Pcs Remarks
D711 MA111TX DIODE 1
D713,14 MA111TX DIODE 2
FL701 RSL0273-F FL 1
IC101 LA1833MN-TLM IC 1
IC102 LC72131MDTLM IC 1
IC301 M5218AFPE3 IC 1
IC302 M62433AFP IC 1
IC501 LC72722PMTLM IC 1
IC701 M30218MAA103 IC 1
JK101 RJH5210M JACK ANTENNA 1
JK201 SJF3069-20N EXT/MD 1
JK401 RJT065K20 SYSTEMCONNECTOR(20P) 1
JK402 RJT065K19 SYSTEMCONNECTOR(19P) 1
L101,02 ELESNR68MA COIL 2
L103 ELEXTR47MA9 COIL 1
L501,02 RLQA100JT-Y COIL 2
L541,42 RLQA100JT-Y COIL 2
L701 RLBN300AV-W COIL 1
L702-04 RLBN601V-W COIL 3
L706 RLBN601V-W COIL 1
L707 RLBN300AV-W COIL 1
Q101,02 2SC2787FK TRANSISTOR 2
Q106 UN4111 TRANSISTOR 1
Q110 2SC3311AR TRANSISTOR 1
Q301,02 2SC3311ATA TRANSISTOR 2
Q303 UN4115 TRANSISTOR 1
Q401 2SD2137PQTA TRAMSISTOR 1
Q402 2SB1417PQTA TRANSISTOR 1
Q403 2SC3940AQSTA TRANSISTOR 1
Q405 DTB123YSTP TRANSISTOR 1
Q406 DTC114ESTP TRANSISTOR 1
Q407 2SC3311ATA TRANSISTOR 1
Q541,42 2SC3311ATA TRANSISTOR 2
Q543 DTC143XSTP TRANSISTOR 1
Q701 UN5214TX TRANSISTOR 1
Q702 2SD1819ATX TRANSISTOR 1
R102 ERDS2FJ472 1/4W4.7K 1
R103 ERDS2FJ101 1/4W100 1
R104 ERDS2FJ103 1/4W10K 1
R105 ERDS2FJ471 1/4W470 1
R106 ERDS2FJ474 1/4W470K 1
R107 ERDS2FJ331 1/4W330 1
R108 ERDS2FJ474 1/4W470K 1
R109 ERDS2FJ331 1/4W330 1
19

Ref. No. PartNo. PartName& Description Pcs Remarks
R110 ERDS2FJ102 1/4W1K 1
R111 ERDS2FJ391 1/4W390 1
R112 ERDS2FJ104 1/4W100K 1
R113 ERDS2FJ103 1/4W10K 1
R114 ERDS2FJ562 1/4W5.6K 1
R115 ERDS2FJ561 1/4W560 1
R116 ERDS2FJ102 1/4W1K 1
R117 ERDS2FJ683 1/4W68K 1
R118 ERDS2FJ332 1/4W3.3K 1
R119 ERDS2FJ103 1/4W10K 1
R120 ERDS2FJ473 1/4W47K 1
R121 ERDS2FJ223 1/4W22K 1
R122 ERDS2FJ272 1/4W2.7K 1
R123 ERDS2FJ683 1/4W68K 1
R124 ERDS2FJ271 1/4W270 1
R125,26 ERDS2FJ152 1/4W1.5K 2
R127 ERDS2FJ471 1/4W470 1
R128 ERDS2FJ820 1/4W82 1
R129 ERDS2FJ273 1/4W27K 1
R130 ERDS2FJ103 1/4W10K 1
R131 ERDS2FJ680 1/4W68 1
R132 ERDS2FJ103 1/4W10K 1
R133-37 ERDS2FJ102 1/4W1K 5
R138 ERDS2FJ103 1/4W10K 1
R139 ERDS2FJ332 1/4W3.3K 1
R140 ERDS2FJ472 1/4W4.7K 1
R141,42 ERDS2FJ102 1/4W1K 2
R143 ERDS2FJ223 1/4W22K 1
R145,46 ERDS2FJ104 1/4W100K 2
R201,02 ERDS2FJ102 1/4W1K 2
R203,04 ERDS2FJ104 1/4W100K 2
R205,06 ERDS2FJ102 1/4W1K 2
R207,08 ERDS2FJ104 1/4W100K 2
R301-04 ERDS2FJ471 1/4W470 4
R305,06 ERDS2FJ473 1/4W47K 2
R307,08 ERDS2FJ103 1/4W10K 2
R309,10 ERD16TJ000T 1/4W0 2
R313,14 ERDS2FJ102 1/4W1K 2
R315,16 ERDS2FJ223 1/4W22K 2
R317,18 ERDS2FJ102 1/4W1K 2
R319,20 ERDS2FJ332 1/4W3.3K 2
R321 ERDS2FJ105 1/4W1M 1
R322 ERDS2FJ104 1/4W100K 1
R323 ERDS2FJ102 1/4W1K 1
R324 ERDS2FJ222 1/4W2.2K 1
R325 ERDS2FJ102 1/4W1K 1
R326 ERDS2FJ103 1/4W10K 1
R329-32 ERDS2FJ472 1/4W4.7K 4
R333,34 ERDS2FJ332 1/4W3.3K 2
R335,36 ERDS2FJ104 1/4W100K 2
R337,38 ERDS2FJ223 1/4W22K 2
R339,40 ERDS2FJ103 1/4W10K 2
R341,42 ERDS2FJ102 1/4W1K 2
R343,44 ERDS2FJ103 1/4W10K 2
20
