TechniSat HDFS User manual

TechniSat HDFS
Award Winning freesat HD Digital Box
www.technisat.co.uk
Interfaces
RF - Input, F-Type Female, IEC 169-24
SCART - TV (RGB, CVBS, S-Video)
- VCR (CVBS, S-Video)
HDMI - 1.2a, HDCP
RCA - CVBS Out
RCA - Analogue audio L/R
RCA - Digital audio out (SPDIF)
Toslink - Optical digital audio out
USB - USB 2.0 host (front & rear)
- mass storage device support
- WiFi adaptor support
CompactFlash - CompactFlash card slot
Memory Card - MS/SD/MMC card slot
RJ45 - Ethernet 10/100
- support for streaming services
Power Supply
Supply -HigheciencySMPS
- 180V – 264V
Consumption -Displayo:0.25W
 -Displayon(clock):1.5W
 -Operating:15W
Accessories
Remote Control
Mains Lead
HDMI Cable
Owner’s Manual
Quick Start Guide
Guarantee Card
Audio/Video
Video - MPEG2 (up to MP@ML)
- MPEG4 (H.264 up to HP)
Audio - MPEG1 & 2 Layer I, II, III (MP3)
- Dolby Digital (Stereo downmix)
- Dolby Digital Plus (Stereo downmix)
- VCR (CVBS, S-Video)
MediaPlayback -Pictures:JPEG
 -Music:MP2,MP3
 -Movies:MPEG,VOB
- Access from USB mass storage
- Access from PC, NAS
Home Network - Connection to network devices
- via Ethernet or WiFi adaptor
- CIFS protocol support for PC/NAS
Physical Specification
Housing - Metal, Black
Display - VFD, 16 character, 5x7 dots
Front Panel Switch - Standby, Navigation, OK
Dimensions - 310mm x 200mm x 52 mm
Weight - 1.56Kg
Contact
TechniSat Digital UK Ltd
45 Sunningdale House
Caldecotte Lake Drive
Milton Keynes, MK7 8LF
Tel:01908362650
Fax:01908362651
Specification

TechniSat HDFS
Award Winning freesat HD Digital Box
www.technisat.co.uk
Made in Germany
• Thechoiceofover140digitalchannelsandservices
• ReceptionofallFreesatHDandSDchannels
• Nosubscription
• 8-dayElectronicProgrammeGuide(EPG)
• PauseliveTV,Timeshiftandrecordtoexternalharddrive
• Playbackofmusic,pictures&moviesfromUSB,cardreaderornetworkedPC
• WiFisupportforwirelessconnectivity(additionalTechniSatWLANantennarequired)
• SupportforBBCiPlayer–whenavailable.
• Ultra-lowstandbypower:0.25watts
• Full3yearmanufacturer’sguarantee
• Ultra-lowstandbypower:0.25W
• USBports–front&rear
• Cardreaders–SD/MS/MMC&CompactFlash
• TechniSatmodeoeringDiSEqC1.2functionalitywithmotorcontrolformulti-satellitereception
• Scrollingalphanumericdisplay
• EasyrsttimeinstallationwithAutoInstall
• Extensiveon-screenhelp
• HDMIleadincluded
• DedicatedHelpline
TechniSat HDFS
January 2010
