Technogym Synchro Forma User manual

SYNCHRO FORMA
User manual

SYNCHRO FORMA 2
Contents
Contents...........................................................................................................2
Important safety instruction.........................................................................3
Personal safety ...............................................................................................5
Manufacturer and equipment identication................................................7
Technical data..................................................................................................8
Description of the equipment........................................................................9
Safety devices and warnings......................................................................10
Place of usage ...............................................................................................11
Moving the equipment .................................................................................12
Levelling.........................................................................................................13
Electrical connection....................................................................................14
Switching on and o.....................................................................................15
Maintenance..................................................................................................16
Changing the fuses.......................................................................................18
Easily solved problems ................................................................................19
Technical Support Service............................................................................ 21
Storage ...........................................................................................................22
Scrapping .......................................................................................................22
Monitoring the heart rate.............................................................................23
Using Synchro Forma...................................................................................25

SYNCHRO FORMA 3
Important safety instruction
You should always consult with a qualied and licensed medical professional or healthcare practitioner before starting any nutritional, diet, stretching or exercise
program. You are advised to investigate and inform yourself about any health related actions and choices you make.
Synchro Forma is intended for commercial use.
Please read all instructions before using the equipment. These instructions were written to ensure your safety and to protect the unit.
When using an electrical appliance, basic precautions should be always followed, including the following.
D
To reduce the risk of electric shock, always unplug the unit from the electrical outlet immediately after using and before cleaning or
performing any maintenance tasks.
To reduce the risk of burns, re, electric shock or injury to person, take the following precautions.
- The equipment should never be left unattended when plugged in. Unplug from outlet when not in use, before cleaning it, and before putting on or taking o
electrical parts.
- Do not allow children unsupervised access to the equipment; parents and guardians must assume responsibility for the children in their care and avoid the
occurrence of situations or usage for which the equipment was not designed. Children must be closely supervised when using the equipment, with careful
attention paid to their mental and physical development. The equipment must under no circumstances be adapted or used as a toy.
- Close supervision by qualied personnel is necessary when the equipment is used by or near invalids or disabled persons.
- Use the equipment only for its intended use as described in the user manual. Only perform the exercises for which the equipment has been designed,
following the instructions given in the manual. Any other use is to be considered improper and therefore dangerous.
- Do not use attachments not recommended by Technogym.
- Never operate the equipment if it has a damaged cord or plug, if it is not working properly, if it has been dropped or damaged, or dropped into water. In this
case, contact the Technogym Technical Support service.
- Do not carry the equipment by supply cord or use cord as handle.

SYNCHRO FORMA 4
Important safety instruction
- Keep the cord away from heated surfaces.
- Keep hands away from moving parts.
- Never drop or insert any object into any opening.
- Do not use outdoors. Do not leave the appliance outdoors, exposed to the elements (rain, sun, wind, etc.). Do not expose the appliance to water jets.
- Do not operate where aerosol (spray) products are being used or where oxygen is being administered.
- To disconnect, turn all controls to the o position, then remove plug from outlet.
W
Connect the equipment to a properly grounded outlet only. See grounding instructions.
SAVE THESE INSTRUCTIONS

SYNCHRO FORMA 5
Personal safety
Before starting any exercise you are advised to read the whole manual thoroughly and get to know the equipment’s controls.
Synchro Forma can be used only after having a medical check-up for the specic type of exercise to be carried out and in compliance with Technogym’s stated
use conditions.
Before starting a workout program, consult a doctor for advice on any limits to observe when using the equipment.
Persons with specic physical complaints may use the equipment only under the strict supervision of a doctor specialised in that particular area.
If you feel ill during the workout (dizziness, chest pains, etc.), stop exercising immediately and consult a doctor.
If the message “HIGH HEART RATE” appears during the exercise, your heart rate is too high and you should slow the exercise down.
At the beginning of each exercise, make sure you are in the correct position, and that none of the parts of the equipment are in your way.
Choose suitable exercises for your physical characteristics and state of health, starting out with light loads.
Do not overexert yourself or work to exhaustion. Incorrect or excessive exercise may cause serious physical harm or even death. If you feel any pain or abnormal
symptoms, stop your workout immediately and consult your physician.
Wear proper exercise clothing and shoes during a workout, no loose clothing. Tie long hair back. Keep garments or towels away from moving parts.
During use people must remain at a safe distance.
Do not use the equipment in presence of small children or pets.
Completely assemble the equipment before using it. Check the unit before each use. Do not continue to operate the equipment when it is not working properly.
Assemble and operate the equipment on a solid, level surface.
Keep all electrical components, such as the power cable and I/0 switch, away from liquids to prevent shock.
Maintain the equipment in good working condition. If there are signs of wear, contact the Technogym Technical Support service.
Do not attempt to service the equipment yourself other than the maintenance instructions found in the manual.

SYNCHRO FORMA 6
Personal safety
Do not set anything on the casing or control panel.
The equipment must not be placed close to heat sources or close to sources of electromagnetic waves (e.g. televisions, electrical motors, aerials, cellphones,
etc.).
Although the equipment has been designed and built in accordance with health and safety requirements, there are some zones in which there are unseen
hazards. You must be very careful about possible upper and lower limb crushing hazards.
W
Technogym s.p.a. will be held responsible for its equipment only if the following precautions are observed:
- the equipment must be used as specied;
- the User manual must be read thoroughly throughout;
- the place of installation must meet the requirements stated in the User manual;
- the electrical system must conform to the standards and legal requirements in the country of use;
- the installation, maintenance and setting must be done by qualied Technogym sta or persons authorised by Technogym;
- suitable clothing must be worn;
- towels and other items must not be put on the equipment.
Technogym is not responsible for any damages due to any failures or damage caused by unauthorized service, misuse, accident, negligence, improper assembly
or installation, debris resulting from any construction activities in the product’s environment, rust or corrosion as a result of the product's location, alterations
or modications without Technogym's written authorization or for failure on your part to use, operate and maintain the products as set out in this User Manual.

SYNCHRO FORMA
Technogym S.p.A.-Cesena (FC)
SYNCHRO FORMA Model no. DBK0EB
Maximum User’s Weight: 180kg
Electric Class: I
EN957 - 1/5 Class: HB
S/N DBK0EB 13000001 05/12
Made in Italy
7
Manufacturer and equipment identication
The equipment identity label gives the present information:
- Manufacturer’s name and address
- Place of manufacture
- Description of product
- Electrical specications
- Tells you to consult the User manual
- Serial number and date of manufacture
- Product model

SYNCHRO FORMA 8
780 mm (31")
1640 mm (65")
2040 mm(80")
Technical data
Synchro Forma
Power supply 100÷240 Vac 50/60 Hz
Power input 65 VA max
Fuses 2 x 3.15 A (F)
Weight of equipment 148 kg (326 lb)
Maximum user weight 160 kg (353 lb)
User heigh for which performance
indicated is guaranteed 155 cm÷205 cm (6"÷8")
Time 0÷999 min ± 1%
Distance 0÷99,99 km ± 5% (0÷99,99 mi ± 5%)
Maximum braking power 440 W at 200 spm
Minimum braking power 23 W at 80 spm
Protection grade IP 20
Operating temperature from +5°C to +35°C
Electrical isolation class Class I
Manufacturer Technogym s.p.a.
via Calcinaro 2861 - 47522 Cesena FC
Ordinary appliance, not waterproofed.

SYNCHRO FORMA 9
5
1
2
6
8
7
3
4
6
Description of the equipment
Control panel (1): controls all available functions, from setting up workout
programmes to viewing messages and related workout information.
Please see the control panel's manual to see how it works.
Fixed handgrips (2): they are gripped when working out only with legs.
Hand sensor (3): themetal plate sensors permit constantheart ratemonitoring.
Levers (4): they are gripped during the exercise to combine training of legs
and arms.
Pedals (5): the special conguration of the pedals permit the ankles to work
under optimum conditions.
Bases (6): support the equipment frame and components.
Water bottle holder (7): where you can place water bottles during workout.
Object holder (8): for placing magazines, books or tablets and other electronic
devices. Tablets can be rmly xed as shown in the gure.

SYNCHRO FORMA 10
D
B
C
A
Safety devices and warnings
A- Fixed guard: guards against access to the inside of the equipment.
B- Fuses: protect the equipment’s electrical parts. When the current reaches
an excessive value, the fuses melt thus protecting the internal electronics.
C- Main switch: turns the equipment’s power on and o.
D- The label for attachment to the power supply cable states the electrical
specications for the cable.

SYNCHRO FORMA 11
Place of usage
To ensure that exercising with the equipment is easy, safe and eective, the place where it is used should comply with certain specic requirements; in particular,
before choosing the place where the equipment will be installed, please ensure that the following conditions are satised:
- the temperature is between +10°C and +25°C;
- enough air is circulating to keep humidity during exercise to between 20% and 90%;
- the lighting is good enough to make the area safe and relaxing place to exercise in;
- free space of at least 60 cm around the entire perimeter of each product;
- that the oor is at, stable and vibration-free, and strong enough to bear the weight of the equipment plus user.
The place of installation must comply with all the suitability requirements laid down in current legislation on this matter.
Do not expose the equipment to direct sunlight.
Do not install the equipment in areas with high humidity levels, for example close to swimming pools, whirlpools or saunas.

SYNCHRO FORMA 12
Moving the equipment
W
Move the equipment with great care to avoid it tipping over.
After moving the equipment always check that it is level in order
to guarantee the correct working.
The equipment has two xed rear wheels. To move the equipment, lift it up slightly,
as shown in the illustration, and push it forwards and backwards.
Given the weight of the equipment, we recommend that more than one person be
involved in lifting it.
When lifting or moving the equipment, do not take hold of the platforms, levers
or the control panel as hand holds.

SYNCHRO FORMA 13
B
A
A
Levelling
Before use, check that the unit is level.
Use the two front feet and the central foot to level the equipment:
- loosen the lock nut (B);
- screw the front feet (A) in or out until the frame is in a stable position;
- tighten up the lock nut (B) after adjusting.

SYNCHRO FORMA
05149018
14
Electrical connection
Before connecting the equipment to the mains power supply, ensure that the electrical installation complies to binding regulations. Check the mains power
supply specications on the equipment identity label.
The product must be grounded. If it should malfunction or breakdown, grounding provides a path of least resistance for electric current to reduce the risk of
electric shock. The product is equipped with a cord having an equipment-grounding conductor and a grounding plug. The plug must be plugged into an appropriate
outlet that is properly installed and grounded in accordance with all local codes and ordinances.
W
The power supply socket must be grounded . If not, a ground connection must be installed by a qualied electrician before connecting
the equipment to the electricity mains.
Improper connection of the equipment-grounding conductor can result in a risk of electrical shock. Check with a qualied electrician or
serviceman if you are in doubt as to whether the product is properly grounded. Do not modify the plug provided with the product; if it will
not t in the outlet, have a proper outlet installed by a qualied electrician.
W
The wall socket must be located in a place where the plugging and
unplugging can be done easily and safely.
When plugging in, the main switch on the equipment must be in the
0 position (i.e. the equipment must be switched o).
Check the state of the power supply cable periodically.
The power cable is supplied with the product.
Plug the power cable rst into the equipment socket and then into the wall socket.

SYNCHRO FORMA 15
Switching on and o
To turn the equipment on, switch the main switch to the “I” position (on) .
After a quick system check (reset), the equipment is ready for use.
To turn the equipment o, switch the main switch to the “0” position (o).
The equipment must be switched o only at the end of the exercise, when in
standby.
If the equipment is not expected to be used for a long time, as well as turning it o
you should also pull the plug out of the wall socket.
W
The switch is for turning the equipment on and o but does not
isolate it completely from the mains voltage, even in the “0”
position (o). For complete isolation you must unplug the power
supply plug.

SYNCHRO FORMA 16
Maintenance
W
The safety of the equipment is assured only on the condition that it is carefully inspected every two weeks for any signs of damage and/
or wear.
Replace defective and worn components immediately, or alternatively remove the equipment from service.
For maintenance actions not described in this manual, call in the Technogym Technical Service.
Cleaning and looking after the equipment
The equipment should always be kept clean and free of dust, in accordance with normal hygiene and sanitary rules.
To clean the control panel, proceed as follows:
- turn the equipment o by switching the switch to 0;
- unplug the equipment power cable from the wall socket;
- clean the control panel with a damp, but not wet, cloth.
Every week, clean the equipment completely:
- turn the equipment o by switching the switch to the 0position;
- unplug the equipment power cable from the wall socket;
- clean the external parts with a damp sponge;
- move the equipment to one side so that you can vacuum clean underneath it.
Do not use chemicals or solvents. Do not use abrasive products on polished parts.
Do not rub too hard on the control panel.

SYNCHRO FORMA 17
A
B
B
Maintenance
Checks
W
The routine maintenance, adjustment and lubrication jobs must be
performed by the Technogym Technical Support Service.
Before starting any job, turn the equipment o by switching the switch to
the "0" position and unplug the power cable from the wall socket.
Description Type of intervention Frequency
ATransmission belt Check state of wear Six-month
BPedals Check play Six-month
CLevers Check play Six-month

SYNCHRO FORMA 18
Changing the fuses
W
The fuses must be changed by the Technogym Technical Support
Service.
Before changing the fuses, switch the equipment o by switching
the switch to 0 and unplug the power cable plug from the wall
socket.
Remove the fuse holder, to the right of the switch, by pushing the lever.
Replace the blown fuse with the new one, as supplied.
Fit the fuse holder back into its housing, making sure it clicks in properly.
W
If no more of the supplied fuses are available, use a certied fuse
with identical electrical specications for the replacement.

SYNCHRO FORMA 19
Easily solved problems
Below is a list of problems that may arise during normal use of the equipment. If the described remedies do not solve the problem, contact the Technical Support
Service. f
Problem Cause Remedy
Equipment doesn’t switch on
Mains power failure Check the power supply at the wall socket used by the equipment
by plugging in an appliance that denitely works.
Power supply cable damaged Contact the Technogym Technical Support Service.
Installation problems with the power supply cable Check the connection.
Burnt-out fuses To replace the blown fuse with a spare contact Technogym
Technical Support Service.
The main switch is o. Switch on the main switch
Too noisy Equipment not properly levelled.Check the position and level the adjustment feet.
Damaged bearings.Contact the Technogym Technical Support Service.
Worn belt.Contact the Technogym Technical Support Service.
Data incorrect or unreliable with
equipment running
Equipment next to source of radio interference (e.g. electrical
domestic appliances).
Move the equipment to another place or move the domestic
appliances.

SYNCHRO FORMA 20
Easily solved problems
Problem Cause Remedy
Problems in monitoring heart rate
with the chest band
Other transmitters situated nearby.Move the equipment far enough away to stop signal interference
(minimum distance between two units 80 cm).
Strong interference sources nearby. Find the interference source (e.g. an electrical domestic
appliance) and move it away, or move the equipment.
Worn heart rate monitor chest band.Change the chest band.
Chest band transmitter not making proper skin contact.Dampen the inside of the chest band with water.
Damaged transmitter.Change the chest band.
W
There are high voltages inside the motor compartment, therefore the guard must be removed by authorised personnel only; only authorised
personnel can carry out internal repairs.
