Technogym Excite Synchro User manual

EXCITE
Synchro
User manual

2
Synchro Excite
Contents
Manufacturer and equipment identification .............................................. 3
Description of the equipment.................................................................... 5
Technical data ......................................................................................... 15
Accessories ............................................................................................. 18
Safety devices and notices ..................................................................... 19
Place of installation ................................................................................. 21
Unpacking ............................................................................................... 22
Moving the equipment ............................................................................ 23
Levelling .................................................................................................. 24
Electrical connection (700 and 500 versions).......................................... 25
Connection to another device ................................................................. 27
Routine maintenance ............................................................................. 29
Changing the fuses (700 and 500 versions) ............................................ 31
Recharging the battery (700 SP and 500 SP versions) ........................... 32
Troubleshooting....................................................................................... 33
Technical assistance ............................................................................... 36
Storage.................................................................................................... 37
Disposing of the equipment .................................................................... 38
Switching on and off ............................................................................... 39
Monitoring the heart rate......................................................................... 41
Ergonomic positioning on the equipment ............................................... 44

3
Synchro Excite
D
B HA
G
C
IE I F
C
Manufacturer and equipment identication
A- Manufacturer’s name and address
B- Description of product
C- Electrical specifications and type of fuses
(700 and 500 versions)
D- Equipment classification
E- CE Mark
F- Serial number and date of manufacture
G- Certification mark for the USA and
Canada
H- Product code
I- Tells you to consult the User manual
The values stated in the illustration are purely indicative; refer to the label attached to the equipment or the data in Technical
data section for the correct information.

4
Synchro Excite
Manufacturer and equipment identication
Equipment with codes DA52M..., DA53M..., DA58M..., DA59M... are intended for medical use and have been designed and
built for use in outpatient clinics, hospitals, clinics and sport centres, for muscular therapy and rehabilitation.
Equipment with codes DA52M..., DA53M..., DA58M..., DA59M... can be used by or close to children, invalids, disabled persons
or people with evident physical problems only under close supervision of a doctor or a qualified professional.

5
Synchro Excite
Description of the equipment
Control panel
Levers
Fast Track Control
Sensors
Fixed handles
Pedals
Bases
Reading stand
Tray
TGS key reader
Control panel: controls all available functions, from setting up workout programs to viewing messages and related workout
information.

6
Synchro Excite
Description of the equipment
Control panel
Levers
Fast Track Control
Sensors
Fixed handles
Pedals
Bases
Reading stand
Tray
TGS key reader
Levers: these can be grasped by the user to perform the exercise with arm movements. The 700 and 700 SP versions have
sensors for monitoring the heart rate (hand sensor) and the Fast Track Control to change the effort level.

7
Synchro Excite
Description of the equipment
Control panel
Levers
Fast Track Control
Sensors
Fixed handles
Pedals
Bases
Reading stand
Tray
TGS key reader
Levers: these can be grasped by the user to perform the exercise with arm movements. The 700 and 700 SP versions have
sensors for monitoring the heat rate (hand sensor) and the Fast Track Control to change the effort level.

8
Synchro Excite
Description of the equipment
Control panel
Levers
Fast Track Control
Sensors
Fixed handles
Pedals
Bases
Reading stand
Tray
TGS key reader
Sensors: levers and fixed handles have sensors for monitoring the heat rate (hand sensor), in the 700 and 700 SP versions
of the equipment.

9
Synchro Excite
Description of the equipment
Control panel
Levers
Fast Track Control
Sensors
Fixed handles
Pedals
Bases
Reading stand
Tray
TGS key reader
Fixed handles: these can be grasped by the user during the workout. The 700 and 700 SP versions have sensors for
monitoring the heart rate (hand sensor).

10
Synchro Excite
Description of the equipment
Control panel
Levers
Fast Track Control
Sensors
Fixed handles
Pedals
Bases
Reading stand
Tray
TGS key reader
Pedals: the special configuration of the pedals permit the ankles to work under optimum conditions.

11
Synchro Excite
Description of the equipment
Control panel
Levers
Fast Track Control
Sensors
Fixed handles
Pedals
Bases
Reading stand
Tray
TGS key reader
Bases: support the equipment frame and components.

12
Synchro Excite
Description of the equipment
Control panel
Levers
Fast Track Control
Sensors
Fixed handles
Pedals
Bases
Reading stand
Tray
TGS key reader
Reading stand: for standing magazines or books on.

13
Synchro Excite
Description of the equipment
Control panel
Levers
Fast Track Control
Sensors
Fixed handles
Pedals
Bases
Reading stand
Tray
TGS key reader
Tray: for standing the water bottle or other useful items on during the workout.

14
Synchro Excite
Description of the equipment
Control panel
Levers
Fast Track Control
Sensors
Fixed handles
Pedals
Bases
Reading stand
Tray
TGS key reader
TGS key reader: for the TGS key (optional).

cont.segue
Technical data
Synchro 700 and 500
Power supply 100÷240 Vac ±10% 50/60 Hz
Maximum braking power 500 W at 120 spm
Minimum braking power 20 W at 60 spm
Mains power input 65 VA max (160 VA max with Unity)
Fuses 2 x 3.15A (F)
Weight of equipment 148 kg (326 lb)
Maximum user weight 180 kg (397 lb)
User heigh for which 155 cm÷205 cm (6"÷8")
performance indicated is guaranteed
Time 0÷999 min ± 1%
Distance 0÷99.99 km ± 5% (0÷99.99 mls ± 5%)
Protection grade IP 20
Electric isolation class Class I
Marks and Certificates CE - UL(*)
(*) Only if the symbol is present on the equipment identification label.

cont.segue
Technical data
Synchro 700 SP and 500 SP
Maximum braking power 500 W at 120 spm
Minimum braking power 45 W at 60 spm
Weight of equipment 150 kg (331 lb)
Maximum user weight 180 kg (397 lb)
User heigh for which 155 cm÷205 cm (6"÷8")
performance indicated is guaranteed
Time 0÷999 min ± 1%
Distance 0÷99.99 km ± 5% (0÷99.99 mls ± 5%)
Protection grade IP 20
Electric isolation class Class II
Marks and Certificates CE - UL(*)
(*) Only if the symbol is present on the equipment identification label.

17
Synchro Excite
2042 mm
(80")
1609 mm
(63")
752 mm
(30")
Technical data

18
Synchro Excite
A
B
D
E
F
C
Accessories
ASet of wrenches
BUser manual
CWarranty certificate
DCEE Power Supply cable with SH socket (700 and 500 versions)
ETwo replacement fuses (3.15A (F) (700 and 500 versions)
FChest band with transmitter for heart rate monitor (optional)

19
Synchro Excite
B C
A
Safety devices and notices
A Fixed guard: guards against access to the inside of the equipment.
B Main switch: turns the equipment’s power on and off (700 and 500 versions).
C Fuses: they protect the equipment’s electrical parts (700 and 500 versions). When the current reaches an excessive value,
the fuses melt thus protecting the internal electronics.

20
Synchro Excite
E
F
G
Safety devices and notices
Warning
Please read the adhesive labels on the equipment, which provide information about possible risks and hazards.
In the 700 and 500 versions:
EThe label affixed to the frame under the control panel states the
electrical specifications.
FThe label, which can be affixed close to the main switch, states safety
indications.
GThe label which can be affixed to the power supply cable states the
electrical specifications for the cable.
CAUTION: do not connect a device with load
exceeding 7 A
CAUTION: do not connect to a circuit operating
at more than 150V to ground
CAUTION: risk of electric shock. Do not
disconnect under load
