Tecnoalarm TP8-96 User guide

TP8-96 VIDEO
864 ZONES
CONTROL PANEL
8 TO 96 ZONES EXPANDIBLE
CONTROL PANEL
WITH INTEGRATED
ETHERNET SWITCH
EN60950
EN50130-4
EN50081-1
INSTALLER
MANUAL
Release: 1.1
Update: October2012
Language: English
FWversion: 0.7.05

II InstallerManual-TP8-96VIDEO
Theproductfeaturescanbesubjecttochangewithoutnotice.Unauthorizedreproductionordistributionofthis
manual, or any portion of it, on any device and in any form, is prohibited. The contents of this manual may be
subject to change without notice

III
TP8-96VIDEO-InstallerManual
CONFORMITY
Hereby,Tecnoalarm srl declaresthat the presentequipment is incompliance with theessential requirements and
otherrelevantprovisionsoftheR&TTE1999/05/ECdirective.
Thedeclarationofconformityisavailableonthewebsite:www.tecnoalarm.com.

IV InstallerManual-TP8-96VIDEO

TP8-96VIDEO-InstallerManual Index 1
INDEX
1. INTRODUCTION
1.1 PROGRAMMINGMENU 1-1
1.2 HARDWARECONFIGURATION-AVAILABLEMODULES 1-7
2. ZONE CONFIGURATION
2.1 ZONECONFIGURATION 2-1
2.1.1 Association of the logic zone to the physical zone 2-1
2.1.2 Zone-functionassociation 2-14
2.1.3 Zone-programassociation 2-15
2.1.4 Consoles 2-16
2.1.5 Keypoints 2-18
2.1.6 Options 2-19
2.1.7 Outputs 2-22
2.1.8 Bus sirens 2-24
3. TELEPHONE SECTION CONFIGURATION
3.1 TELEPHONEPARAMETERCONFIGURATION 3-1
3.1.1 Telephonechannelsandstandardtelephoneparameters 3-1
3.1.2 GSMmodule 3-4
3.1.3 Tecnocell 3-6
3.1.4 Ethernet 3-8
3.1.5 Reportcodes 3-10
3.1.6 Openingmessage-vocabulary 3-11
3.1.7 Remotecontrols 3-13
3.2 EXPLANATORYNOTES 3-14
4. TIME PARAMETER CONFIGURATION
4.1 TIMESETTINGS 4-1
4.2 TIMERS 4-3
4.3 ACCESSPERIODS 4-5
4.4 CUSTOMIZATIONOFTHECALENDAR 4-7
4.5 EXPLANATORYNOTES 4-9
5. ACCESS CONFIGURATION
5.1 PROGRAMMINGOFTHECODES 5-1
5.2 PROGRAMMINGOFTHEKEYS 5-4
5.3 PROGRAMMINGOFTHEWIRELESSKEYS 5-6
5.4 EXPLANATORYNOTES 5-8
6. WIRELESS DEVICE CONFIGURATION
6.1 PROGRAMMINGOFTHEWIRELESSSIRENS 6-1
6.2 PROGRAMMINGOFTHEWIRELESSCONSOLES 6-3
7. HARDWARE CONFIGURATION
7.1 HARDWARECONFIGURATIONWITHAUTOMATICWIRING 7-1
7.2 HARDWARECONFIGURATIONWITHOUTAUTOMATICWIRING 7-5

Index InstallerManual-TP8-96VIDEO
2
8. RS485 SERIAL BUS ANALYSIS
8.1 SERIALBUSANALYSIS 8-1
A. APPENDIX A - SPECIAL PROCEDURES
A.1 RESETOFTHECODES A-3
A.2 DELETIONOFTHEENTIRESYSTEMCONFIGURATION(RESETOFDEFAULTSETTINGS) A-4
A.3 BACKUP-RESTOREOFTHEWIRELESSCONFIGURATION A-5
A.4 LOCALFIRMWAREUPGRADE A-7
ADDITIONALPAGES
Electronicboard A-11
Terminals A-12
System A-13
Cameraconnection A-14
Supply by terminals A-15
Supply by cables + splitter A-16

TP8-96VIDEO-Installermanual IntroductiontotheTP8-96VIDEOsystem 1-1
1.1 PROGRAMMING MENU
Descriptionoftheprogrammingmenus.
zAdvanced:Enablingordisablingoftheadvancedprogramminglevel.
N.B.Itispossibleto enable the advanced programming levelonlyifyouhavethe
correspondinglicense.
zAutomatic wiring:Enabling or disabling of the automatic wiring function.
N.B. All the other items of the programming options menu are disabled.
zZones: Association of the logical zones to the physical zones - Alphanumeric
description-Enablingandprogrammingofvoicemessageusingthevocabulary-
Zone type - Alarm cycles - Contact type - Configuration of the detector - Zone filter
andsensitivity
zZones-Functions:Associationof the functions: siren,PGM,by-pass,coinciding
zone, chime, non excludable zone, common zone
zZones-Programs:Associationof thezonestotheprograms- Alphanumeric
description-Enablingandprogrammingofthevoicemessageusingthevocablary
zConsoles: Associationof the LED to the programs -Enabling ofquick arming/
disarming, panic alarm, quick menu, chime - Audio settings - Message scheduling
zKeypoints:AssociationofRFID/transponderreadersandbiometricreaderstothe
programs
zOptions: Functioning of Buzzer, wireless section - Voice report - Key zone
functioning-Enablingofsinglearmingmode-Enabling/disablingtamper-
Antimasking control - Association of the siren/outputs
zOutputs:Programmingofpolarity
zBus sirens: Association of the sirens to the programs - After blinking - Volume
setting - Siren mode - Sound type - Functioning mode - Enabling/disabling of the
antifoamandantidrillingprotection
PROGRAMMINGOPTIONS
ZONECONFIGURATION
1. INTRODUCTION
PROGRAMMINGOPTIONS

IntroductiontotheTP8-96VIDEO system Installermanual-TP8-96VIDEO
1-2
TELEPHONE SECTIONCONFIGURATION
zTelephone interface: Programming of the channels from A to H - Call-back
function- Communicatorblock-Generalsettings
zGSM: Enabling of the GSM interface - Answering mode - Rings - Airtime request -
SMS heading - GPRS settings - Commands by SMS - Password - White list
zTecnocell: Enabling of the external GSM communicator - Answering mode -
Emergency phone number - Association of the messages - Emergency SMS -
Enablingoftheguidedmenu and of the data channel
zEthernet: Configurationofthe integrated 8 portsEthernetswitch- IP address -
Subnet mask - Gateway - Programming of the communication port for the Local
ServerTecnoalarm,RemoteServerTecnoalarm,TecnoserverTecnoalarm,
Tecno_Out
zReport codes: Association of theevents to the channels - Programming ofthe
reportcodes ofall263transmittableevents
zOpeningmessage-Vocabulary:Test/recording/loadingofthe opening message -
Loadingandupdateofthevocabulary
zRemotecontrol: Enablingandprogrammingofthemessageusingthevocabulary-
Alphanumericdescription-Programmingoftheactivationtime
zTime settings: Entry time 1 and 2 - Exit time - Disarming confirmation time - Delay
ofchannel andsirenactivation-Delay ofantimaskingandpowerfailure alarm-
Alarm, tamper, technical and hold-up alarm time - End of by-pass and automatic
armingwarning-Maximumdurationofby-pass-Supervisioninterval
zTimers:Frequencyofactivationindays/hoursforarming(normal,conditioned,
forced,conditionedforced),beginning/endofbypass,activation/deactivationof
remotecontrol-ProgrammingofServerTestCall
zAccessperiods:Frequencyofactivationindays/hoursforbeginning/endofdelay
access period - Association of the access periods to the codes, keys/
transponders/RFIDcardsandremotecontrols
zCalendarcustomization (1styear): Calendarprogramming-Customizationofthe
workingdays, holidays andholiday eves (importantfor timers andaccess periods) -
Programmingofwinterandsummertime - Viewing of the scheduled messageon
theconsole
zCalendar customization (2nd year): Programming is the same as for the first
year
TIMEPARAMETERCONFIGURATION

TP8-96VIDEO-Installermanual IntroductiontotheTP8-96VIDEOsystem 1-3
ACCESSCONFIGURATION
zCodes:Programmingof thenameandthelength ofthecode-Programming of
arming/disarming or by-pass function - Association to the programs -Programming
oftheattributes
zTransponders: Programmingofthename-Programmingof arming/disarming
function or by-pass function - Association to the programs - Programming of the
attributes
zWireless keys: Programming of the name - Association of the function keys to the
programsorthe functions -Programmingoftheattributes
zWireless sirens: Alarm time - Activation siren delay - Flashing time - Volume
setting-Functioningmode as outdoor/indoor siren-Activationmodeforalarm,
technicalalarmandsignaling
zWireless consoles: Association of the LED to the programs -Programmingofthe
attributes
Warning: In order to use the advanced programming, it is necessary to enabled it into the “Ver.” Menu.
zEvents: Whena specific event happens, the control panelexecutes a specific
operationassociatedto the event, e.g.:
• What kind of event? Arming
•Whicharming?Remotearming
• By whom? User 1
•Whichprogram?Program2
•How? By telephone
zOperations:Creation/modification/deletionofanoperation
zTelephone directory: Programmingof the telephone numbersassociated to one
orseveraloperations
WIRELESSDEVICECONFIGURATION
ADVANCEDPROGRAMMING

IntroductiontotheTP8-96VIDEO system Installermanual-TP8-96VIDEO
1-4
EVENTLOG
Viewing/consultation,printingandsavingasatextfile(TXT)oftheeventlogofthecontrolpanel.Theeventsareviewed
with indication of date and time. You can sort the event filter by date and time or type.
zN.(Eventnumber):Consultation inorderofrecording
zDate and time: Consultation by date and time - Viewing of the events of a
determinedperiodoftime
zDescription:Consultationbytypeofevents
Hardwareconfigurationofthesystem.
Thismenupermitstheadditionand/ordeletionofthedevices to/from the system configuration.
zAdd: Permitstheaddition of the devices
zDelete: Permits the deletion of the devices
zModules available: List of the available devices
Warning: In order to use this function, it is necessary to disabled automatic wiring it into the “Ver.” Menu.
This menu allows to create and to manage the floor plans associated to the system.
Thismenuisonly enabled if you have thecorrespondingTecnoalarmlicenseand the automatic wiring optionis
disabled.
zAdd detector: Permits the selection of the elements necessary to create the
floorplan.
Forviewingspecificcommandsareavailable.
zSymbolsavailable:List ofavailableelementsforfloor planconfiguration
HARDWARECONFIGURATION
FLOORPLANCONFIGURATION

TP8-96VIDEO-Installermanual IntroductiontotheTP8-96VIDEOsystem 1-5
RFMONITOR
RF Monitor is an analyzing instrument which permits the graphic presentation of the wireless data transmission.
It also permits measuring of the background noise in the place the control panel is installed.
This function is available only if you are connected to the control panel.
zRadio rx: Selection of the receiver to be controlled
zCh.:Selection of the frequency channelto be controlled
Itpermits viewing ofa virtual consoleto communicate withthe control panel.
The console can only be viewed if you are connected to the control panel.
Thismenu allows to backupand restore the configurationof the wireless device.
This function is available only if the control panel is connected.
zReceive (backup): Reception from the control panel and storage in the PC of a
copyofthe dataregardingthewirelessdevices
zSend(restore):Transmissionto the controlpaneloftheprogrammingdata
regardingthewirelessdevicesprevioulsysavedonthePC(Restoreofthedata)
zLast backup: Date and time of the last backup
VIRTUALCONSOLE
BACKUP-RESTOREOFTHEWIRELESSCONFIGURATION

IntroductiontotheTP8-96VIDEO system Installermanual-TP8-96VIDEO
1-6
OPENINGMESSAGE
Thismenu allows to sendtheopening message, whichhasbeen programmed inthetelephone configuration table, to
the control panel. This function is available only if you are connected to the control panel.
zSend: Transmission(andstorage)ofthe opening message to the
controlpanel.
zVerify:Reproduction(listening)oftherecordedopeningmessage.
Thismenu allows to upgradethe firmware and thevocabulary of the system(onlyfor those deviceswhichpermit this).
This function is available only if you are connected to the control panel.
zControl panel: Allows to view the firmware version of the control
panelandupgradeit.
zVocabulary:Allowstoviewandupgradethevocabularyversionand
upgradeit.
zModule:Allowstoviewandupgradethefirmwareandhardware
versionoftheconnectedinput expansionsandupgradethefirmware.
Permits the analysis of the RS485 serial bus communication.
This function is available only if you are connected to the control panel.
zDip:Logicaladdressofthe device
zTOT:Totalnumberoftransmissions
zERROR:Numberofcommunicationerrors
Thismenu allowstocheckthecoherence betweentheprogrammeddevices andtheactuallyinstalledhardware. The
softwareautomatically scans all theinstalled devices, verifies thecoherence with programmingandit signals any
possibleincoherence.
This function is available only if you are connected to the control panel.
FIRMWAREANDVOCABULARYUPDATE
RS485SERIALBUSANALYSIS
HARDWARECOHERENCECONTROL

TP8-96VIDEO-Installermanual IntroductiontotheTP8-96VIDEOsystem 1-7
1.2 HARDWARE CONFIGURATION
AVAILABLE MODULES
CENTRALTP8-96VIDEO
8 zone inputs expandible via RS485 bus until 96 (maximum 64 wireless zones) - 6
programmableoutputs- 1 RS485serialbusport(communicationspeed 38,400 Baud)-
1 Siren Bus port - GSM module - 8 ports LAN Ethernet switch - 6.2A power supply
INPUT EXPANSIONS - MAX. 15
zSPEED ALM8 PLUS Input expansions with power supply - 4 Sensor Bus
inputsfor 8 RSC devices- 4 programmableoutputs - 1
Siren Bus port for 8 sirens - 1.8A power supply
zSPEED 8 PLUS Input expansions - 2 Sensor Bus inputs for 8 RSC
devices-2 programmableoutputs
zSPEED 4 PLUS Input expansions - 1 Sensor Bus input for 4 RSC
devices-4zoneinputs - 1 programmable output
zSPEED ALM8 PL Inputexpansions- 8 zone inputs-4programmable
outputs - 1.8A power supply
zSPEED 8 Inputexpansions- 8 zone inputs-2programmable
output
zSPEED 8 STD Input expansions - 8 zone inputs
zSPEED 4 Inputexpansions- 4 zone inputs-1programmable
output
CONSOLE- MAX.15
zLCD300/S LCD display with 2 lines of 16 characters - 32 signaling
LED - 16 keys - Integrated speaker for voice synthesis

IntroductiontotheTP8-96VIDEO system Installermanual-TP8-96VIDEO
1-8
WIRELESSEXTENSIONS- MAX. 2
zRX300/433868 Dualfrequencywirelessreceiver(433MHz/868MHz)-
ManagementoftheLCD300WL wirelessconsolesand
the SAEL 2000 WL wireless sirens
zRTX200/433868 Dualfrequencywirelessreceiver-transmitter(433MHz/
868MHz)-BidirectionalmanagementoftheLCD300WL
wireless consoles and the SAEL 2000 WL wireless
sirens
zLCD300WL Bidirectionaldualfrequencywirelessconsole-LCD
display with 2 lines of 16 characters - 16 keys - 1 NC
alarminput
zSAEL 2000 WL Bidirectionaldualfrequencywirelesssiren
zTX240-3 Wireless key with 3 programmable function keys
CONTROLUNITS-MAX. 15
zTPSDN Electronic keypad - 12 keys - 18 signaling LED -
Managementofmaximum4programs
zTPSK6N Transponderreaderwithminikeypad-10signaling
LED-Managementofmaximum6programs
zTPSKN Interfaceforthemanagementoftransponderreaders.
Eachtransponderreadermanagesmaximum3programs
GSMCOMMUNICATOR-MAX.1
zTECNOCELL-PROPL ExternalGSMcommunicator-Transmission via GSM
network-TransmissionofSMSmessagesandofvoice
messages.
Thedevicehasnoaddress.
ACCESSORIES
zSPEEDRS485 Serial bus extension - Allows to increase the length of
the serial bus by 1km.
Thedevicehasnoaddress.
zSTARRS485 Serial bus extension - Permits star-shaped connections -
3 RS485 loops - 6 lines.
Thedevicehasnoaddress.
zSAEL2000PROBUSL Self-poweredoutdoorsirenwithRSCtechnology.
Max. 8 sirens can be connected to the Siren Bus.

TP8-96VIDEO-Installermanual IntroductiontotheTP8-96VIDEOsystem 1-9
OUTPUTEXTENSIONS-MAX.16

IntroductiontotheTP8-96VIDEO system Installermanual-TP8-96VIDEO
1-10

TP8-96VIDEO-Installermanual IntroductiontotheTP8-96VIDEOsystem 1-11

IntroductiontotheTP8-96VIDEO system Installermanual-TP8-96VIDEO
1-12
N.B.:Thefree(i.e.undefined)outputs/signalingareavailableforadvancedprogramming.

TP8-96VIDEO-InstallerManual Zoneconfiguration 2-1
2. ZONECONFIGURATION
Select the Configuration table.
Onthescreenis viewed:
Thezoneconfigurationtablespermittoprogramthefollowingparameters:
zListof zones controlled bythe control panel,freelyselectable among themodules connected and programmingof
thezoneparameters
zZone-functionassociation
zZone-program association
zAssociation of the programs to the consoles
zAssociation of the programs to the secondary control units (key points)
zSystem options
zLogicoutputparameters
zBussirenparameters
2.1 ZONE CONFIGURATION
2.1.1 ASSOCIATION OF THE LOGIC ZONE TO THE PHYSICAL ZONE
The TP8-96 VIDEO can control max. 96 zones. The zones can be associated to the zone inputs of the installed
hardware. The system configuration may provide more inputs than the control panel can control. It is for this raison, that
you have to choose the inputs to be controlled from those provided by the modules and draw up a zone list.
zA Logic zone. Viewing of list of the logic zones managed by
thecontrol panel.
zB Module (device). Select thedevicefromthedrop-down
menu. The list is composed of: Not associated (no device
associated to the logic zone), Control panel, Wireless exp.
(wirelesszone),modulesfrom1to15(hard-wiredzone
expansions).
zC Zone of the module (device). Viewing of the list of the
availablephysicalinputsfortheselecteddevice.
The logic zone must be associated to the physical zone to
view the configuration table and program the zone.
AB C

Zoneconfiguration InstallerManual-TP8-96VIDEO
2-2
Once logic/physic zone association has been completed, the following items which caracterise the zones are viewed.
DESCRIPTION
It is possible to associate an individual description to the zone that will replace the zone number and identify the
programineveryprocess.The zone description will be viewedonthedisplayand announced by the speaker ofthe
console.
zACheck Voice message item A to enable it.
zBThevoice message can becomposed of max. 4words selectable among thoseincluded in the vocabulary.
Afterenabling,4itemsareviewed,oneforeachword.
Click on the arrow of each item to scroll the vocabulary and select the word.
zCAt the end, click on the Validation arrow key (C) to memorize and play the message.
The words are copied into the description line. It is possible to program the description manually writing it directly
in the description line.
Remember that the display of the console is able to view descriptions of maximum 16 characters.
All further characters will be cut off.
After the association of the description, programming of the zone continue according to the technology and
type of the selected detector. Each detector has specific programming parameters.
DECTECTORCATEGORIES
Detectorsare divided into four categoriesaccording to the kind ofconnection with thecontrol panel, which is identified
by the contact type.
Eachcategoryhasdifferentfunctioningcharacteristics,i.e.differentprogrammingfacilities.
Examplesof all thedifferent detectors are illustratedin the followingpages.
zGroup1 Hard-wired zones with standardwiring - Contacttype:NC, NO, EOL resistor,DEOL resistor (traditional
movementdetectorsanddetectorswithRDVtechnology)
zGroup2 Wireless zones - Contact type: Wireless (Tecnoalarm detectors only)
zGroup3 Hard-wired zones with zone buswiring - Contacttype: ZONE BUS (WINBEAM/S andDOORBEAM/S
barriers)
zGroup4 Wired zones with sensor bus wiring - Contact type: SENSOR BUS (detectors with RSC technology:
DUALTECNOBUS10,DUALMASKBUS05,TWINTEC BUS, TWINTEC MASK BUS,
EXPLORERBUS,BEAMTOWER,TRIREDBUS).
BA C
Other manuals for TP8-96
2
Other Tecnoalarm Control Panel manuals
Popular Control Panel manuals by other brands

GFS
GFS Deluxe Operator's manual

Siemens
Siemens SINUMERIK 840D sl operating manual

HEIDENHAIN
HEIDENHAIN ND 1100 - V2.15.0 GUIDE Quick reference guide

GE
GE NetworX NX-6V2 installation instructions

Bentel Security
Bentel Security KYO 320 installation manual

NSI
NSI LUMA-NET 400CP Installation and operation guide
