TEFAL ZE610D65 User manual

Easy Fruit Juice Extractor
www.tefal.com
TH
ID
MS
ZH
EN
VN

B
C
D
M
N
I
G
A
E
F
J
K
H
L
1
2
123
456
7 8

B
C
D
M
N
I
G
A
E
F
J
K
H
L
1
2
123
456
7 8

4
CAUTION: the safety precautions are part of the appliance. Read
them carefully before using your new appliance for the first time. Keep
them in a place where you can find and refer to them later on.
DESCRIPTION
A Pusher
B Feed tube
C Cover
D Sieve
E Juice collector
F Pouring spout
G Pulp collector
H Safety clamp
I Control knob (2 speeds)
J Drive shaft
K Motor unit
L Juice jug
M Cleaning brush
N Foam separator
SAFETY SYSTEM
This appliance is fitted with a safety mechanism. To start the juice
machine, the cover (C) must be properly secured by the safety clamp (H).
Opening the safety clamp (H) will stop the juice machine. At the end of
a cycle, place the control knob (I) to 0 and wait until the sieve (D) stops
completely before removing the cover.
BEFORE FIRST USE
• We recommend that you wash all the removable parts (A, B, C, D, E, G,
L) in warm soapy water (see paragraph “Cleaning”). Rinse and dry them
carefully.
• Unpack the appliance and place it on a clean, dry stable flat work
surface away from water splashes.
• Ensure that all packaging has been removed before starting the
appliance.
USING THE APPLIANCE
• Place the juice collector (E) on the body of the appliance (see Fig. 1).
• Place the sieve (D) in the juice collector (E). Ensure that the sieve is
properly clipped onto the drive shaft (J) (see Fig. 2).
• Fit the pulp collector (G) on the rear of the appliance (see Fig. 3).
• Fit the cover (C) on the appliance, spout to the rear (see Fig. 4).

EN
5
• Push the safety clamp (H) to the rear until it locks into place. You will
hear an audible “click” (see Fig. 5).
• Slide the pusher (A) into the feed tube (B) aligning the groove on the
pusher with the small ridge in the feed tube (see Fig. 5).
• The juice jug (L) has a foam separator (N) that keeps the foam in the
jug when you pour the juice into a glass. If you do not want to separate
the foam, remove the foam separator (N).
• Place the juice jug (L) under the pouring spout in front of the appliance
(see Fig. 6).
• Plug in the appliance.
• To start the appliance, use the control knob (I).
• Insert the fruits or vegetables through the feed tube (B).
• The fruits and vegetables must be inserted only while the motor is
running.
• Do not press too hard on the pusher (A). Do not use any other utensil.
NEVER push with your fingers.
• When you have finished, stop the appliance by turning the control knob
(I) to 0 and wait until the sieve (D) stops completely.
• When the pulp collector (G) is full, or the juice flow slows down, empty
the pulp collector and clean the sieve and the cover.
• Remove the “juice collector + sieve” assembly by pulling vertically
using both hands (see Fig. 7 and 8).
WHICH SPEED TO USE?
Ingredients Speed Approx. weight (in kg) Quantity of juice
obtained in ml (*)
Apples 2 1 650
Pears 2 1 600
Carrots 2 1 600
Cucumbers 1 1 (about 2 cucumbers) 600
Grapes 1 1 450
Tomatoes 1 1.5 900
Celery 2 1.5 350
Orange 2 1 650
Choosing the wrong speed may cause the appliance to vibrate abnormally.

6
It is recommended that you use the appliance for no more than 2 minutes
continuously.
* The quality and quantity of juice varies greatly according to the freshness when harvested and the particular
variety of fruit or vegetable. The quantities of juice indicated above are therefore approximate.
PRACTICAL TIPS
• Wash the fruit carefully before stoning.
• In general, you do not need to remove the skin or peel. You only need to
peel fruit with thick and bitter skin, like lemon, orange, grapefruit.
• It is difficult to extract juice from bananas, avocados, blackberries, figs,
aubergines and strawberries.
• Choose fresh, ripe fruit and vegetables, they will yield more juice. This
appliance is suitable for such fruits as apples, pears, oranges, grapes,
pomegranates and such vegetables as carrots, cucumbers, tomatoes,
beetroot and celery.
• If you use overripe fruits, the sieve will get clogged more quickly and less
juice will be extracted.
• Important: All juice must be consumed immediately. On contact with
air, it is very quickly oxidised, which can change its taste, colour and
nutritional value. Apple and pear juices quickly turn brown. Add a few
drops of lemon juice to slow this discoloration.
CLEANING
• All removable parts (A, B, C, D, G and L) may be cleaned in the
dishwasher, except for the juice collector (E). The juice collector (E) must
be cleaned straight after use in soapy water.
• This appliance is easier to clean immediately after use.
• Do not use abrasive sponge, acetone, alcohol (white spirit), etc. to clean
the appliance.
• Use the cleaning brush (M) for the sieve.
• The sieve must be handled with care. Avoid any mishandling that may
affect the performance of the appliance.
NOTE: You MUST replace your sieve at the first sign of wear or damage.
• Clean the motor unit with a damp cloth. Dry carefully.
• Never immerse the motor unit under water or any other liquid.

EN
7
WHAT TO DO IF YOUR APPLIANCE DOES NOT WORK?
PROBLEMS CAUSES SOLUTIONS
The appliance does not
work.
The plug is not inserted
correctly; the control knob
(I) is neither on “1” nor
on “2”.
Plug the appliance into
a socket with the correct
voltage. Turn the control
knob to speed “1” or “2”.
The cover (C) is not properly
secured.
Check that the cover (C)
is properly secured by
the safety clamp (H) and
positioned correctly in the
grooves.
The appliance is giving off a
smell or is very hot to touch,
is making an abnormal
noise or smoking.
The sieve (D) is not properly
fitted.
Check that the sieve (D)
is fitted properly onto the
drive shaft (J).
The quantity of fruit or
vegetables being processed
is too great.
Allow the appliance to
cool down and reduce
the amount of fruit or
vegetables being processed.
The flow of juice decreases. The sieve (D) is blocked. Turn off the appliance,
clean the feed tube (B) and
the sieve (D).
For any other problem or fault, please contact your approved Service centre.
