Teka CGC 4G AI AL Manual

Installation and maintenance manual
CRISTAL-GAS HOBS CG.1 4G / CG.1 3G. 1P
CG Lux-60 4G. / CG Lux-70 4G. / CG Lux-70 4G AI AL
CG Lux-70 5G. / CG Lux-60 4G. Al AL / CG Lux-70 5G. Al AL
CG Lux-70 5G AI TR AL / CG Lux-70 5G TR / CGC 4G / CGC 4G AI AL
CG Lux-75 2G AI TR AL / CG Lux-86 3G AI TR AL
CG Lux-60 4G AI / CG Lux-70 4G AI / CG Lux-70 5G AI
CG Lux-70 5G AI TR / CG Lux-75 2G AI TR / CG Lux-86 3G AI TR
Bedienungsanleitung und Pflegehinweise
GASKOCHFELDER TEMPERGLAS CG.1 4G / CG.1 3G. 1P
CG Lux-60 4G. / CG Lux-70 4G. / CG Lux-70 4G AI AL
CG Lux-70 5G. / CG Lux-60 4G. Al AL / CG Lux-70 5G. Al AL
CG Lux-70 5G AI TR AL / CG Lux-70 5G TR / CGC 4G / CGC 4G AI AL
CG Lux-75 2G AI TR AL / CG Lux-86 3G AI TR AL
CG Lux-60 4G AI / CG Lux-70 4G AI / CG Lux-70 5G AI
CG Lux-70 5G AI TR / CG Lux-75 2G AI TR / CG Lux-86 3G AI TR
Instructions de montage et conseils d’entretien
PLAQUES DE CUISSON CRISTAL-GAZ CG.1 4G / CG.1 3G. 1P
CG Lux-60 4G. / CG Lux-70 4G. / CG Lux-70 4G AI AL
CG Lux-70 5G. / CG Lux-60 4G. Al AL / CG Lux-70 5G. Al AL
CG Lux-70 5G AI TR AL / CG Lux-70 5G TR / CGC 4G / CGC 4G AI AL
CG Lux-75 2G AI TR AL / CG Lux-86 3G AI TR AL
CG Lux-60 4G AI / CG Lux-70 4G AI / CG Lux-70 5G AI
CG Lux-70 5G AI TR / CG Lux-75 2G AI TR / CG Lux-86 3G AI TR
61401134/329 ingles 18/7/03 16:55 Página 1

Dear Customer,
Thank you for choosing a TEKA hob.
We are sure that our product will fully satisfy
your requirements.
This modern, functional and practical applian-
ce has been built using top quality materials
which are subjected to strict quality controls
throughout the manufacturing process.
Before installing or using our product, we
recommend you to carefully read this manual
and to follow its instructions step by step in
order to obtain the best possible results.
Keep this instruction manual in a safe place
so that you can consult it whenever necessary
and comply with the warranty requirements.
To benefit from our Warranty you must pre-
sent proof of purchase together with the
warranty certificate.
Safety Instructions
Before using your hob for the first time, please
read the installation and connection instruc-
tions.
These hob models can be installed in the
same kitchen units asTEKA ovens and control
panels.
N.B. To avoid the risk of burns, keep children
away from the hob during or after its opera-
tion.
We recommend you to follow our instructions
and that the installation of our hobs be carried
out by our Technical Service personnel only.
If you detect any breakage or craking in the
hob glass, switch all the burner controls to
the off position (‘0’), turn off the gas connec-
tion and disconnect the electricity supply.
User’s Guide to this Instruction Manual
2
61401134/329 ingles 18/7/03 16:55 Página 2

Introduction Página 4
Description of the Appliance 4
Installation 9
Positioning of the hobs 9
Positioning of the oven 10
Anchoring of the hob 10
Connecting the hob to the oven or the
control panel 11
Gas Connection 12
Electrical Connection 13
Gas transformation 14
Technical Information 16
Dimensions and powers 16
Technical Data 18
Rating Plates 20
Use and Maintenance 24
Special requirements before first use 24
Component Parts of Gas Burners 24
Lighting of Burners 24
Switching on Electric Hotplates 26
Components of a Safety System 27
Using your Hob 28
Hints for the Correct Usage of Burners 29
Hints for the Correct Usage of Electric
Hotplates 29
Reminder 30
Cleaning and Conservation 31
Electric Hotplates (MOD. CG.1 3G. 1P) 32
Maintenance 32
If Something Doesn’t Work 33
Contents
3
61401134/329 ingles 18/7/03 16:55 Página 3

CG. 1 4G (See drawing 1)
1Auxiliary burner of 860 Kcal/h - 1 kW.
2Semi fast burner of 1,500 Kcal/h -
1.75 kW.
3Fast burner of 2,580 Kcal/h - 3 kW
4Semi fast burner of 1,500 Kcal/h -
1.75 kW.
• All burners incorporate a pan support.
• Maximum calorific power: 6,400 Kcal/h -
7.5 kW.
CG.1 3G. 1P. (See drawing 2)
1Auxiliary burner of 860 Kcal/h - 1 kW.
2High-power hotplate of 1,500 W,
Ø 145 mm.
3Semi fast burner of 1,500 Kcal/h -
1.75 kW.
4Fast burner of 2,580 Kcal/h - 3 kW.
• All burners incorporate a pan support.
• Maximum calorific power: 4,900 Kcal/h -
5.75 kW.
• Maximum electric power: 1,500 Watts.
Introduction
4
Description of the Appliance
12
4 3
12
3 4
Drawing 1 Drawing 2
61401134/329 ingles 18/7/03 16:55 Página 4

CG-Lux-60 4G, CG Lux-60 4G Al AL
and CG Lux-60 4G AI (See drawing 3)
1Fast burner of 2,580 Kcal/h - 3 kW.
2Semi fast burner of 1,500 Kcal/h -
1.75 kW.
3Semi fast burner of 1,500 Kcal/h -
1.75 kW.
4Auxiliary burner of 860 Kcal/h - 1 kW.
5Burner controls.
• All burners incorporate a pan support.
• Maximum calorific power: 6,450 Kcal/h -
7.5 kW.
CGC 4G and CGC 4G AI AL (See drawing 4)
1Fast burner of 2,580 Kcal/h - 3 kW.
2Semi fast burner of 1,500 Kcal/h -
1.75 kW.
3Semi fast burner of 1,500 Kcal/h -
1.75 kW.
4Auxiliary burner of 860 Kcal/h - 1 kW.
• All burners incorporate a pan support.
• Maximum calorific power: 6,450 Kcal/h -
7.5 kW.
5
21
3 4
3
5
1
2 4
Drawing 3 Drawing 4
61401134/329 ingles 18/7/03 16:55 Página 5

CG-Lux-70 5G., CG Lux-70 5G Al AL
and CG Lux -70 5G AI (See drawing 5)
1Fast burner of 2,580 Kcal/h - 3 kW.
2Fast burner of 2,580 Kcal/h - 3 kW.
3Semi fast burner of 1,500 Kcal/h -
1.75 kW.
4Semi fast burner of 1,500 Kcal/h -
1.75 kW.
5Auxiliary burner of 860 Kcal/h - 1 kW.
6Burner controls.
• All burners incorporate a pan support.
• Maximum calorific power: 9,020 Kcal/h -
10.5 kW.
CG-Lux-70 5G TR , CG Lux-70 5G AI TR AL
and CG Lux -70 5G AI TR (See drawing 6)
1Fast burner of 2,580 Kcal/h - 3 kW.
2Triple ring burner of 3,000 Kcal/h -
3.5 kW.
3Semi fast burner of 1,500 Kcal/h -
1.75 kW.
4Semi fast burner of 1, 500 Kcal/h -
1.75 kW.
5Auxiliary burner of 860 Kcal/h - 1 kW.
6Burner controls.
• All burners incorporate a pan support.
• Maximum calorific power: 9,450 Kcal/h -
11 kW.
6
1 2
4
3
56
1 2
4
3
56
Drawing 5 Drawing 6
61401134/329 ingles 18/7/03 16:55 Página 6

7
CG-Lux-70 4G, CG-Lux-70 4G AI AL
and CG Lux -70 4G AI (See drawing 7)
1Fast burner of 2,580 Kcal/h - 3 kW.
2Semi fast burner of 1,500 Kcal/h -
1.75 kW.
3Semi fast burner of 1,500 Kcal/h -
1.75 kW.
4Auxiliary burner of 860 Kcal/h - 1 kW.
5Burner controls.
• All burners incorporate a pan support.
• Maximum calorific power: 6,450 Kcal/h -
7.5 kW.
CG-Lux-75 2G AI TR ALand CG Lux-75 2G AI TR
(See drawing 8)
1Triple ring burner of 3,010 Kcal/h -
3.5 kW.
2Triple ring burner of 3,010 Kcal/h -
3.5 kW.
3Burner controls.
• All burners incorporate a pan support.
• Maximum calorific power: 6,020 Kcal/h -
7 kW.
1
2
3
45
1 2
3
Drawing 7 Drawing 8
61401134/329 ingles 18/7/03 16:55 Página 7

CG-Lux-86 3G AI TR AL and CG Lux-86 3G AI TR
(See drawing 9)
1Triple ring burner of 3,010 Kcal/h -
3.5 kW.
2Triple ring burner of 3,010 Kcal/h -
3.5 kW.
3Semi fast burner of 1,500 Kcal/h -
1.75 kW.
4Burner controls.
• All burners incorporate a pan support.
• Maximum calorific power: 7,520 Kcal/h -
8.75 kW.
8
1 3 2
4
Drawing 9
61401134/329 ingles 18/7/03 16:55 Página 8

9
Important
INSTALLATION AND ADJUSTMENT MUST BE
CARRIED OUT BY AUTHORISED TECHNICAL
PERSONNEL ACCORDING TO THE APPLICABLE
INSTALLATION REGULATIONS.
Depending on the model to be installed an
aperture will be made in the worktop, of the
dimensions specified in the drawing 10. A
template is included in the packaging of
models CG.1 4G. and CG.1 3G. 1P. for the
correct sizing of the aperture for these two
hob models.
Warning: If the hob is assembled on any part
of the furniture (drawers, cupboards, etc.) an
intermediate separation must be placed bet-
ween both at a minimum distance of 100 mm.
from the lower part of the plate to avoid any
involuntary direct contact. This intermediate
separation must be permanent and only remo-
ved with tools.
For hobs with controls, its location must inclu-
de a ventilation slot at the front, of 110 cm2.
In this case the minimum distance between
the lower part of the hob and the upper part of
the furniture below the hob will be 20 mm. If
there is no front ventilation slot, the minimum
distance between the hob and the upper part
of the furniture must be 130 mm.
The minimum vertical distance of the lower
part of the piece of furniture placed above the
hob will be 600 mm.
The piece of furniture where the hob with oven
is to be placed will be properly fixed.
* In the case of the granite hob the measu-
rement can be 580 mm.
Mod.: CG Lux-60 y CGC 4G
Mod.: CG.1 3G. 1P. y CG.1 4G.
Mod.: CG Lux-70
Mod.: CG Lux-75
Mod.: CG Lux-86
Installation
Positioning of the hobs
A
B
C
D
E
Drawing 10
61401134/329 ingles 18/7/03 16:55 Página 9

See th applicable manual.
Once the hob position has been dimensioned,
the seal (J) must be affixed to the lower part
of the cooker. This is fastened by means of
four clamps (G), each of which has two tabs
(P) which are inserted in the apertures (O) in
the hob until they click into place. To secure
the clamp, open the tab (S) outwards a little
as indicated in the figure. Once the seal and
the clamps have been positioned the applian-
ce may be installed in its position.
Use a screwdriver to tighten the screws (T) on
the four clamps and the hob will be perfectly
secured in place. (See drawing 11).
N.B. It is imperative to install the seal under
the brim of the worktop. Failure to install this
may cause the worktop to be exposed to high
temperatures.
In the cases of the models CG.1 4G and CG.1
3G 1P, the clamps must be fitted as shown in
the picture 12 depending on the thickness of
the furniture.
For worktops 30 mm thick or less, use the M5
screws supplied as complementary fixation by
introducing them into the circular hole of the
clamp. A fillet shall form in this hole as the
screw is introduced in it. This operation should
be done before fastening the clamps to thehob.
To install hob model CGC 4G AI AL, insert the
quick-fix nuts in the screw housings (see dra-
wing 13), connect the clip which corres
ponds with the height measurement of the
hob unit (20, 30 and 40 mm) and tighten the
screws until they are well secure.
Seal Work top Screw
Fastening clip Quick-fix nut
10
Positioning of the oven
Anchoring of the hob
J
O
S
O
PG
T
Drawing 11
A B
CD E
20 mm. 30 mm.40 mm.
AC
D E
B
Drawing 13
Self-tapping screw for
worktops of 20 and 30
mm. wide
Drawing 12
20/30 mm.
40mm.
