Teka VTN DC User manual

INSTALLATION AND MAINTENANCE MANUAL
CERAMIC HOBS
ANLEITUNG FÜR EINBAU UND INSTANDHALTUNG
GLASKERAMIK-KOCHFELDER
MANUELD’INSTALLATION ETD’ENTRETIEN
CERAMIC HOBS
VTN DC –VS U–VT CM –VT DUAL.1 –VT HDC2
VTCHDC2 –VTCB–VTCDC –VR 622 –TS 600
TR 640 –TR 620 –VT TC60.3 –VT TC 60 PH
TT 620 –TZ 640 –TZ 620 –VT CM INOX HALOGEN
TT 630 –TT 600 –TC620 –TB 600 –TT 640
TZ 640 –TR 600 –TR 735 AB

2
Contents/Inhalt /Table desMatières
Introduction
User Guide
Installation
Positioning the hobs
Positioning the oven
or the control panel
Fixing the hob
Connecting the gas
(Model VTDUAL. 1)
Connecting the electricity
Joining the hob to the oven
or control panel
Gas conversion
(Model VTDUAL. 1)
Technical information
Dimensions and power
Technical details
Use and Maintenance
Requirementsbefore first use
Touch control user instructions
Double or Triple circuit hotplate
Blocking the hob’ssensor
Disconnection for safety
purposes
Remote cooking
Timer function
The clock as countdown
Power surges
Operating the glass ceramic
hotplates
Advice on using the glass ceramic
hotplates effectively
Cleaning and care
Anti-accidental turn system
on gas controls
Igniting the burners
(Model VTDUAL. 1)
Suggestions on using the burners
effectively (Model VTDUAL. 1)
Cleaning and looking after
the burners (Model VTDUAL.1)
Mantaining the VT DUAL.1
If something fails to work
Page 4
14
15
15
16
16
17
18
18
19
20
20
22
23
23
23
25
26
26
27
28
30
31
31
32
33
34
35
35
36
36
38
GB DE
Einführung
Hinweise zum Gebrauch
Einbau
Einbauortfür die Kochfelder
Einbauortfür den Ofen oder
das Bedienfeld
Verankerung des Kochfelds
Gasanschluss
(Modell VT DUAL.1)
Elektrischer Anschluss
Anschluss des Kochfeldes an den
Backofen oder an das Bedienfeld
Umstellung auf andere Gasart
(Modell VT DUAL.1)
Technische Information
Abmessungen und Leistungsmerkmale
Technische Daten
Gebrauch und Instandhaltung
Voraussetzungen für die
Inbetriebnahme
Gebrauchsanweisung für die
Berührungssensoren
Zweikreis oder
Dreikreis-Kochzonen
Verriegelung der Berührungs-
sensoren für das Kochfeld
Sicherheits-Abschaltung
Elektronische Ankochautomatik
Timerfunktion
Verwendung der Uhrals
Stoppuhr für Countdown
Überspannungen im Stromnetz
Funktionsweise der
Glaskeramik-Kochzonen
Tippsfür den korrekten Gebrauch
der VT-Kochzonen
Reinigung und Pflege
Schutz gegen versehentliches
Drehen der Gasregler
Anzünden der Gasbrenner
Tippsfür den korrekten Gebrauch
der Brenner
Reinigung und Pflege der Brenner
Instandhaltung des Modells
Im Störungsfall
Seite 4
41
42
42
43
44
44
45
45
46
48
48
50
51
51
51
53
54
55
55
56
59
59
60
61
62
64
64
65
65
66
67

3
FR
Présentation
Guide d’utilisation
Installation
Logement des tables de cuisson
Logement du four ou du tableau
de commandes
Fixation des tables de cuisson
Raccordement au gaz
(Modèle VT DUAL.1)
Branchementélectrique
Raccordement de la table de
cuisson au four ou au bandeau
de commandes
Adaptation du gaz
(Modèle VT DUAL.1)
Informations techniques
Dimensions et puissances
Données techniques
Utilisation etentretien
Conditions de mise en service
Instructions d’utilisation de
la commande sensitive
Plaques àdouble et triple foyer
Blocage des Touches sensitives
de la table de cuisson
Déconnexion de sécurité
Coup de cuisson
Fonction minuteur
L’Horloge en tant que chronométre
de compte àrebours
Surtensions sur la ligne
Fonctionnement des plaques
vitrocéramiques
Recommandations pour une
bonne utilisation des plaques VT
Nettoyage et stockage
Système de blocage de
commandes de gaz
Allumage des brûleurs
(Modèle VT DUAL.1)
Recommandations pour une
bonne utilisation des brûleurs
(Modèle VT DUAL.1)
Nettoyage et entretien des
brûleurs (Modèle VT DUAL.1)
Entretien de la VT DUAL.1
Si quelque chose ne fonctionne pas
Page 4
69
70
70
71
71
72
73
73
74
75
75
77
78
78
78
80
81
82
82
83
85
86
87
88
88
90
90
91
92
92
93

Introduction /Einführung /Présentation
Model VTN DC
11,200 watt hotplate.
21,800 watt hotplate.
3700/2,100 watt double circuit hotplate.
41,800 watt hotplate.
5Residual heat indicator lights.
*Maximum electric power: 6,900 watts.
Modell VTNDC
1Kochzone 1200 W
2Kochzone 1800 W
3Zweikreis-Kochzone mit 700/2100 W
4Kochzone 1800 W
5Kontrollleuchten zur Restwärme-Anzeige
*Maximale elektrische Leistung: 6900 W
Modèle VTN DC
1Plaque de 1.200 Watts.
2Plaque de 1.800 Watts.
3Plaque àdouble foyer de 700/2.100 Watts.
4Plaque de 1.800 Watts.
5 Témoins de chaleur résiduelle.
*Puissance électrique maximale: 6.900 Watts.
Model VS U
11,200 watt hotplate.
21,800 watt hotplate.
31,800 watt hotplate.
41,200 watt hotplate.
5Residual heat indicator lights.
*Maximum electric power: 6,000 watts.
Modell VS U
1Kochzone 1200 W
2Kochzone 1800 W
3Kochzone 1800 W
4Kochzone 1200 W
5Kontrollleuchten zur Restwärme-Anzeige
*Maximale elektrische Leistung: 6000 W
Modèle VS U
1Plaque de 1.200 Watts.
2Plaque de 1.800 Watts.
3Plaque de 1.800 Watts.
4Plaque de 1.200 Watts.
5 Témoins de chaleur résiduelle.
*Puissance électrique maximale: 6.000 watts
GB
DE
FR
GB
DE
FR
12
34
5
12
34
5
4

5
Model VTC HDC2
11,200 watt hotplate.
2700/1,700 watt double circuit hotplate.
31,400/2,000 watt doublecircuithotplate.
41,800 watt halogen hotplate.
5Residual heat indicator lights.
*Maximum electric power: 6,700 watts.
Modell VTCHDC2
1Kochzone 1200 W
2Zweikreis-Kochzone mit 700/1700 W
3Zweikreis-Kochzone mit 1400/2000 W
4Halogen-Kochzone 1800 W
5Kontrollleuchten zur Restwärme-Anzeige
*Maximale elektrische Leistung: 6700 W
Modèle VTC HDC2
1Plaque de 1.200 Watts.
2Plaque àdouble foyer de 700/1.700 Watts.
3Plaque àdouble foyer de 1.400/2.000 Watts.
4Plaque halogène de 1.800 Watts.
5 Témoins de chaleur résiduelle.
*Puissance électrique maximale: 6.700 Watts.
Model VTHDC2
11,200 watt hotplate.
2700/1,700 watt double circuit hotplate.
31,400/2,000 watt double circuit hotplate.
41,800 watt halogen hotplate.
5Residual heat indicator lights.
*Maximum electric power: 6,700 watts.
Modell VT HDC2
1Kochzone 1200 W
2Zweikreis-Kochzone mit700/1700 W
3Zweikreis-Kochzone mit1400/2000 W
4Halogen-Kochzone 1800 W
5Kontrollleuchten zur Restwärme-Anzeige
*Maximale elektrische Leistung: 6700 W
Modèle VTHDC2
1Plaque de 1.200 Watts.
2Plaque àdouble foyer de 700/1.700 Watts.
3Plaque àdouble foyer de 1.400/2.000 Watts.
4Plaque halogène de 1.800 Watts.
5 Témoins de chaleur résiduelle.
*Puissance électrique maximale: 6.700 Watts.
GB
DE
FR
GB
DE
FR
12
34
5
12
34
5

6
Model VT CM
11,200 watt hotplate.
21,800 watt hotplate.
31,800 watt hotplate.
41,200 watt hotplate.
5Residual heat indicator lights.
*Maximum electric power: 6,000 watts.
Modell VT CM
1Kochzone 1200 W
2Kochzone 1800 W
3Kochzone 1800 W
4Kochzone 1200 W
5Kontrollleuchten zur Restwärme-Anzeige
*Maximale elektrische Leistung: 6000 W
Modèle VT CM
1Plaque de 1.200 Watts.
2Plaque de 1.800 Watts.
3Plaque de 1.800 Watts.
4Plaque de 1.200 Watts.
5 Témoins de chaleur résiduelle.
*Puissance électrique maximale: 6.000
Watts.
Model VTCB
11,200 watt hotplate.
21,800 watt hotplate.
32,100 watt hotplate.
41,200 watt hotplate.
5Residual heat indicator lights.
*Maximum electric power: 6,300 watts.
Modell VTC B
1Kochzone 1200 W
2Kochzone 1800 W
3Kochzone 2100 W
4Kochzone 1200 W
5Kontrollleuchten zur Restwärme-Anzeige
*Maximale elektrische Leistung: 6300 W
Modèle VTCB
1Plaque de 1.200 Watts.
2Plaque de 1.800 Watts.
3Plaque de 2.100 Watts.
4Plaque de 1.200 Watts.
5 Témoins de chaleur résiduelle.
*Puissance électrique maximale: 6.300
Watts.
GB
DE
FR
GB
DE
FR
12
34
5
12
34
5

7
Model VTCM INOX HALOGEN
11,200 watt hotplate.
21,800 watt halogen hotplate.
31,800 watt hotplate.
41,200 watt hotplate.
5Residual heat indicator lights.
*Maximum electric power: 6,000 watts.
Modell VT CM
1Kochzone 1200 W
2Halogen-Kochzone 1800 W
3Kochzone 1800 W
4Kochzone 1200 W
5Kontrollleuchten zur Restwärme-Anzeige
*Maximale elektrische Leistung: 6000 W
Modèle VTCM
1Plaque de 1.200 Watts.
2Plaque halogène de 1.800 Watts.
3Plaque de 1.800 Watts.
4Plaque de 1.200 Watts.
5 Témoins de chaleur résiduelle.
*Puissance électrique maximale: 6.000
Watts.
GB
DE
FR
12
34
5
Model VTDUAL.1
1700/2,100 watt double circuit hotplate.
2Semi-rapid burner 1,500 Kcal/h -1.75 kW.
31200 watt hotplate.
4Rapid burner 2,580 Kcal/h -3 kW.
5Grids.
6Residual heat indicator lights.
*Maximum electric power: 3,300 watts.
*Maximum calorificpower: 4,080 Kcal/h -
4.75 kW/h.
Modell VT DUAL.1
1Zweikreis-Kochzone mit700/2100 W
2Mittel-Brenner mit 1500 kcal/h -1,75 kW
3Kochzone 1200 W
4Stark-Brenner mit 2580 kcal/h -3kW
5Stellroste
6Kontrollleuchten zur Restwärme-Anzeige
*Maximale elektrische Leistung: 3300 W
*Maximale Wärmeleistung: 4080 Kcal/h -
4,75 kW/h
Modèle VTDUAL.1
1Plaque àdouble foyer de 700/2.100 Watts.
2Brûleur semi-rapide de 1.500 Kcal/h -
1,75 kW.
3Plaque de 1.200 Watts.
4Brûleur rapide de 2.580 Kcal/h -3kW.
5Grilles.
6 Témoins de chaleur résiduelle.
*Puissance électrique maximale: 3.300
Watts.
*Puissance calorifique maximale: 4.080
Kcal/h -4,75 kW.
GB
DE
FR
12
34
5
5
6

8
Model VTC DC
11,200 watt hotplate.
21,800 watt hotplate.
3700/2,100 watt double circuit hotplate.
41,800 watt hotplate.
5Residualheat indicator lights.
*Maximum electric power: 6,900 watts.
Modell VTC DC
1Kochzone 1200 W
2Kochzone 1800 W
3Zweikreis-Kochzone mit 700/2100 W
4Kochzone 1800 W
5Kontrollleuchten zur Restwärme-Anzeige
*Maximale elektrische Leistung: 6900 W
Modèle VTC DC
1Plaque de 1.200 Watts.
2Plaque de 1.800 Watts.
3Plaque àdoublefoyer de 700/2.100 Watts.
4Plaque de 1.800 Watts.
5 Témoins de chaleur résiduelle.
*Puissance électrique maximale: 6.900
Watts.
Model VR 622
11,500 watt hotplate.
21,400/2,000 watt double circuit hotplate.
3700/2,100 watt doublecircuithotplate.
41,500 watt hotplate.
5Residual heat indicator lights.
*Maximum electric power: 7,100 watts.
Modell VR 622
1Kochzone 1500 W
2Zweikreis-Kochzone mit 1400/2000 W
3Zweikreis-Kochzone mit 700/2100 W
4Kochzone 1500 W
5Kontrollleuchten zur Restwärme-Anzeige
*Maximale elektrische Leistung: 7100 W
Modèle VR 622
1Plaque de 1.500 Watts.
2Plaque àdouble foyer de 1.400/2.000 Watts.
3Plaque àdouble foyer de 700/2.100 Watts.
4Plaque de 1.500 Watts.
5 Témoins de chaleur résiduelle.
*Puissance électrique maximale: 7.100 watts.
GB
DE
FR
GB
DE
FR
12
34
5
12
34
5

9
Model VTTC60.3
11,200 watt hotplate.
2700/1,700 watt double circuit hotplate.
31,400/2,000 watt double circuit hotplate.
41,200 watt hotplate.
*Residual heat indicator.( H )
*Maximum electric power: 6,100 watts.
Modell VT TC 60.3
1Kochzone 1200 W
2Zweikreis-Kochzone mit700/1700 W
3Zweikreis-Kochzone mit1400/2000 W
4Kochzone 1200 W
*Restwärme-Anzeige ( H )
*Maximale elektrische Leistung: 6100 W
Modèle VTTC60.3
1Plaque de 1.200 Watts.
2Plaque àdouble foyer de 700/1.700 Watts.
3Plaque àdouble foyer de 1.400/2.000 Watts.
4Plaque de 1.200 Watts.
* Témoinde chaleur résiduelle. ( H )
*Puissance électrique maximale: 6.100
Watts.
GB
DE
FR
12
34
Model TT 620
11,400/2,000 watt double circuit hotplate.
21,800 watt hotplate.
31,200 watt hotplate.
41,500 watt hotplate.
*Residual heat indicator.( H )
*Maximum electric power: 6,500 watts.
Modell TT620
1Zweikreis-Kochzone mit 1400/2000 W
2Kochzone 1800 W
3Kochzone 1200 W
4Kochzone 1500 W
*Restwärme-Anzeige ( H )
*Maximale elektrische Leistung: 6500 W
Modèle TT 620
1Plaque àdouble foyer de 1.400/2.000 Watts.
2Plaque de 1.800 Watts.
3Plaque de 1.200 Watts.
4Plaque de 1.500 Watts.
* Témoin de chaleur résiduelle. ( H )
*Puissance électrique maximale: 6.500 Watts.
GB
DE
FR
12
34

10
Model VT TC 60 PH
11,200 watt hotplate.
21,800 watt halogen hotplate.
31,400/2,000 watt double circuithotplate.
41,200 watt hotplate.
*Residual heat indicator.( H )
*Maximum electric power: 6,200 watts.
Modell VT TC60 PH
1Kochzone 1200 W
2Halogen-Kochzone 1800 W
3Zweikreis-Kochzone mit 1400/2000 W
4Kochzone 1200 W
*Restwärme-Anzeige ( H )
*Maximale elektrische Leistung: 6200 W
Modèle VT TC 60 PH
1Plaque de 1.200 Watts.
2Plaque halogène de 1.800 Watts.
3Plaque àdouble foyer de 1.400/2.000
Watts.
4Plaque de 1.200 Watts.
*Témoin de chaleur résiduelle. ( H )
*Puissance électrique maximale: 6.200
Watts.
Model TS 600
12,100 watt hotplate.
21,800 watt hotplate.
31,200 watt hotplate.
41,200 watt hotplate.
*Residual heat indicator.( H )
*Maximum electric power: 6,300 watts.
Modell TS600
1Kochzone 2100 W
2Kochzone 1800 W
3Kochzone 1200 W
4Kochzone 1200 W
*Restwärme-Anzeige ( H )
*Maximale elektrische Leistung: 6300 W
Modèle VTS600
1Plaque de 2.100 Watts.
2Plaque de 1.800 Watts.
3Plaque de 1.200 Watts.
4Plaque de 1.200 Watts.
* Témoin de chaleur résiduelle. ( H )
*Puissance électrique maximale: 6.300 Watts.
GB
DE
FR
GB
DE
FR
12
34
12
34

11
Models TR 620 and TZ620
1700/2,100 watt doublecircuithotplate.
21,800 watt hotplate.
31,500 watt hotplate.
41,200 watt hotplate.
*Residual heat indicator.( H )
*Maximum electric power: 6,600 watts.
Modelle TR620 und TZ 620
1Zweikreis-Kochzone mit 700/2100 W
2Kochzone 1800 W
3Kochzone 1500 W
4Kochzone 1200 W
*Restwärme-Anzeige ( H )
*Maximale elektrische Leistung: 6600 W
Modèles TR 620 et TZ620
1Plaque àdouble foyer de 700/2.100 Watts.
2Plaque de 1.800 Watts.
3Plaque de 1.500 Watts.
4Plaque de 1.200 Watts.
* Témoin de chaleur résiduelle. ( H )
*Puissance électrique maximale: 6.600
Watts.
Models TR 640, TT 640 andTZ640
1700/1,700 watt double circuit hotplate.
21,500/2,400 watt double circuit hotplate.
31,200 watt hotplate.
*Residual heat indicator.( H )
*Maximum electricpower: 5,300 watts.
Modelle TR 640, TT640 undTZ640
1Zweikreis-Kochzone mit700/1700 W
2Zweikreis-Kochzone mit1500/2400 W
3Kochzone 1200 W
*Restwärme-Anzeige ( H )
*Maximaleelektrische Leistung: 5300 W
Modèles TR 640, TT 640 et TZ 640
1Plaque àdouble foyer de 700/1.700 Watts.
2Plaque àdouble foyer de 1.500/2.400 Watts.
3Plaque de 1.200 Watts.
* Témoin de chaleur résiduelle. ( H )
*Puissance électrique maximale: 5.300 Watts.
GB
DE
FR
GB
DE
FR
12
34
1
2
3

12
Model TT630
11,800 watt hotplate.
21,500/2,400 watt doublecircuithotplate.
31,200 watt hotplate.
*Residualheat indicator.( H )
*Maximum electric power: 5,400 watts.
Modelle TT 630
1Kochzone 1800 W
2Zweikreis-Kochzone mit 1500/2400 W
3Kochzone 1200 W
*Restwärme-Anzeige ( H )
*Maximale elektrische Leistung: 5400 W
Modèle TT630
1Plaque de 1.800 Watts.
2Plaque àdouble foyer de 1.500/2.400
Watts.
3Plaque de 1.200 Watts.
* Témoin de chaleur résiduelle. ( H )
*Puissance électrique maximale: 5.400
Watts.
12
3
GB
DE
FR
Model TT 600, TR 600 and TB 600
12,100 watt hotplate.
21,800 watt hotplate.
31,200 watt hotplate.
41,200 watt hotplate.
*Residual heat indicator.( H )
*Maximum electric power: 6,300 watts.
Modell TT600, TR600 und TB 600
1Kochzone 2100 W
2Kochzone 1800 W
3Kochzone 1200 W
4Kochzone 1200 W
*Restwärme-Anzeige ( H )
*Maximale elektrische Leistung: 6300 W
Modèle TT 600, TR 600 et TB600
1Plaque de 2.100 Watts.
2Plaque de 1.800 Watts.
3Plaque de 1.800 Watts.
4Plaque de 1.200 Watts.
* Témoinde chaleur résiduelle. ( H )
*Puissance électrique maximale: 6.300
Watts.
12
34
GB
DE
FR

13
Model TC 620
11,400/2,000 watt double circuit hotplate.
21,800 watt hotplate.
31,200 watt hotplate.
41,500 watt hotplate.
*Residual heat indicator.( H )
*Maximum electric power: 6,500 watts.
Modelle TC 620
1Zweikreis-Kochzone mit 1400/2000 W
2Kochzone 1800 W
3Kochzone 1200 W
4Kochzone 1500 W
*Restwärme-Anzeige ( H )
*Maximale elektrische Leistung: 6500 W
Modèle TC 620
1Plaque àdouble foyer de 1.400/2.000 Watts.
2Plaque de 1.800 Watts.
3Plaque de 1.200 Watts.
4Plaque de 1.500 Watts.
* Témoin de chaleur résiduelle. ( H )
*Puissance électrique maximale: 6.500 Watts.
12
34
GB
DE
FR
1
3
Model TR 735 AB
11,800 watt hotplate.
2 900 /1,950 /2,700 watt hotplate.
31,200 watt hotplate.
*Residual heat indicator.( H )
*Maximum electricpower: 5,700 watts.
Modell TR 735AB
1Kochzone 1800 W
2Kochzone 900/1950/2700 W
3Kochzone 1200 W
*Restwärme-Anzeige ( H )
*Maximaleelektrische Leistung: 5700 W
Modèle TR 735 AB
1Plaque de 1800 Watts.
2Plaque de 900/1.950/2.700 Watts.
3Plaque de 1.200 Watts.
* Témoin de chaleur résiduelle. ( H )
*Puissance électrique maximale: 5.700
Watts.
GB
DE
FR
2

GB
14
Dear customer,
Weare delighted that you have put your
trust in us.
Weare confident that the new hob that
you have purchased will fully satisfy your
needs.
Thismodern, functionalandpractical
model has been manufactured using top-
qualitymaterialsthat haveundergone
strict quality controls throughoutthe manu-
facturing process.
Before installing and using it,we would
ask that you read this Manual carefully
and follow the instructions closely,as this
will guarantee better resultswhen using
the appliance.
Keep thisInstruction Manualin asafeplace
sothatyou can refertoiteasily and thus
abide by the guarantee conditions.
In order to benefit from this Guarantee,it is
essential that you submitthe purchase
receipt together with the Guarantee certifi-
cate.
You should keep the Guarantee
Certificate or,where relevant,the tech-
nical datasheet, together with the Ins-
truction Manualfor the duration of the
useful life of the appliance. It has
important technicalinformation about
the appliance.
Safety instructions
Before first use, you should carefully read
the installation and connection instruc-
tions.
These hob models may be installed in the
samekitchenfurniture unitsas TEKA
brand ovens.
Foryour safety,installation should be
carried outby an authorised technician
and should comply with existing installa-
tion standards. Likewise, any internal work
on the hob should only be done by TEKA’s
technical staff.
Please note:
When the hotplates are in opera-
tion or have recently been in operation,
some areas willbe hot and can burn.
Children shouldbe kept wellaway.
Ifthe glass ceramicbreaks or
cracks, the hob should immediately be
disconnected from the electric current
in order to avoid the risk of electric
shock.
When the halogen heating ele-
mentsare in operation, you should not
look directly at them in case damage is
caused.
Guide to Using theInstructions Booklet

GB
15
Important
INSTALLATIONAND SETUPSHOULD
BE CARRIEDOUTBYAN AUTHORISED
TECHNICIAN IN LINE WITH CURRENT
INSTALLATION STANDARDS.
Positioning the hobs
Depending on the model to be installed, an
opening with the dimensions shown in
figure 2will be cut into the unit’sworktop.
The system for fixing the hob is intended
for use with kitchen unitswith athickness
of 20, 30 and 40 mm. In the packaging of
the models VTN DC, VTHDC2 and TC
620, there is atemplate included that is for
use in sizing the space for these glass
ceramic hob models.
Toposition the VS U and TS 600 hobs into
the kitchen unit, the gap will need to be of
the following size: length -between 560
and 580 mm; and width-between 480 and
492 mm.See the fiting hole’sdimensions
for each model on the “dimensions and
characteristics” table of this manual.
The minimum distance between the surfa-
ce supporting the cooking pans and the
lower part of the kitchen unit or the hood
located above the hob should be 650 mm.
Ifthehood’sinstallation instructions
recommend thatthe gap is greater than
this, you should follow this advice.
The hobs described in this manual can
only be installed withTeka ovens. Models
with no control knobs are only to be insta-
lled withTeka ovens and/or Teka control
panels.
The unit where the hob and oven will be
located will be suitably fixed.
INSTALLATION WITH A CUTLERYDRA-
WER OR LOW CUPBOARD
If you wish to have acupboard or cutlery
drawer beneath the hob, you should install
a panel to separate them. This will prevent
accidental contact withthe hot surface of
the body ofthe appliance.
The board should be installed 20 mm
Installation
fig. 1
Minimumdistances
to walls
Minimum ventilation
distances
OVEN
minimun 40 mm
minimun 40 mm
minimun 40 mm
OVEN

below the bottom ofthe hob and an empty
space ofat least 20 mm should be left at
the back of the cupboard. As an alternati-
ve to this type of panel, you can install a
detachable protective cover tothe bottom
of the hob, which can be obtained from our
Technical Services using the reference
indicated.
When hobs are handled before
being installed, care should be taken in
case there is any protruding part or
sharp edge which could cause injury.
When installing unitsor applian-
ces above the hob, the hob shouldbe
protected by aboard so that the glass
cannotbedamaged byaccidental
blows or heavy weights.
The glues used in manufacturing
the kitchen unit and in the adhesive on
the decorative laminate of the worktop
surface should be made to tolerate tem-
peratures of up to 100ºC.
TEKAassumes no responsibility
for any malfunction or damage caused
by faulty installation.
PLEASE REMEMBER THATTHE GUA-
RANTEEDOESNOTCOVER THE
GLASS IFITSUFFERSAVIOLENT
BLOW OR IF ITIS USED IMPROPERLY.
Positioning the oven or the
control panel
See the corresponding manual.
The oven’splacement should be as shown
in your instruction manual, and the manual
should also be referred to when connec-
ting the electricity.Before accessing the
inside of the appliance,theappliance
should be disconnected from the power.
Fixing the hob
(see figs. 3and4)
When thegaphasbeenproperlysized, the
sealingwasher should beput onthelower
partofthe cooker.WithmodelsVR 622,TR
620, TZ 620,TR640,TT 640,TZ640, TT
600, TB 600, TR 600,TT 630andTR 735AB
GB
16
VTN DC, VTHDC2 and TC 620.
TR 735 AB
VS U*, VT CM,VTDUAL.1, VTC HDC2, VTC B, VTC DC,
VR 622, TS600*, TR 640, TR 620, VTTC 60.3, VT TC 60
PH, TT 620, TZ 640, TZ 620, VT CM INOX HALOGEN, TT
630, TT 600, TB 600, TT 640, TZ 640 and TR 600
fig. 2
Fitting holes
maximun575
maximun575
Ref. Models
81253177 TS 600, TT600, TB 600, TR
640, TZ 640, TT 640, TZ 620,
TR 620, TZ 640, TT630, TR
600 and TR 735 AB
81253176 VTTC 60.3, VTTC 60 PH, TT
620 and TC 620
Protective cover
maximun575

GB
17
the washer will bestucktothelower faceof
the glass.
Silicone should notbe applied between
the glass and the unitworktop because
ifitbecomes necessary toremove the
cooker from itsposition,the glass could
break when trying to detach it.
Position the clips as shown in the diagram,
fastening them to the openings in the
lower part of the body using the metal thre-
aded screws provided (Ø 4,2 mm).
For worktop thicknesses of 30 mm. or less,
use the self-tapping screws (M5) that are
provided as afastening accessory -put
them into the clip’sround hole. This hole
will be threaded as the screw is inserted
into it, and this should be done before
fixing the clip to the worktop.
The clips and the sealing washer are pro-
vided, and can be found in the packaging.
Connecting the gas
Model VT DUAL.1
Connecting the hob to the gas mains
should be done in compliance with the
current installation standards and/or regu-
lations.
Ventilation slotsshould also be made at
the site in compliance with current norms.
The hob is provided withathreaded con-
nection 1/2” in diameter,in line withISO
228-1. AØ10/12 mm. copper pipe is pro-
vided as an accessory for welding the gas
inlet pipe.
Wheneverthe gas connection nut is remo-
ved,itswasher should be changed.
In order that the hob is notdamaged by
tightening the nut on the gas connection
pipe, amaximum torque of 300 Kgf*cm
should be applied.
When the gas connection has been made,
the installation should be checked to ensu-
re that it is completely sealed. If the check
is done using air,care should be taken that
the test pressure is no more than 200
g./cm2.Where air is not available, soapy
water should be applied to ensure that
there are no leaks in the connections. Tes-
ting should never be done using a
flame.
When the hob has been installed, check
that the burner minimums are properly
adjusted. Todo this,light the burners and
check that they do not go out if you switch
quickly from the maximum tothe mini-
mum.
40 mm
20/30 mm
Self-tapping screw for 20
and 30 mm thick worktops
40 mm
20/30 mm
Self-tapping screw for 20
and 30 mm thickworktops
Sealing washer
Sealing washer
fig. 3
fig. 4

GB
18
Connecting the electricity
Before connecting the hob to the electric
mains, check that the voltage and fre-
quency of the mains matches what is
shown on the hob’srating plate,which is
located lower down, and on the guarantee
certificate or,where appropriate, the tech-
nical datasheet supplied, which should be
kepttogether with this manual.
The electric connection is made via an
omnipolar switch or plug where accessi-
ble, which is suitable for the intensity to be
tolerated and which has a minimum gap of
3mm between itscontacts, which will
ensure disconnection in case of emer-
gency or when cleaning the hob.
The connection should include correctear-
thing, in compliance withcurrentnorms.
Iftheflexiblesupplycablefitted to the VT CM
hob model ever needsto bechanged, it
should bereplaced byTEKA’s officialservice.
The input cable should not be in contact
either with the body of the hob or with the
body of the oven, if the oven is installed in
the same unit.
Joining the hob to the oven
or the control panel.
For this purpose, four cardan telescopic
shaftsare included with the hob. (See fig.
5). The way to join them is as follows:
1Turn offthe electricity.
2Detach the cardan telescopic shaftsby
pressing on the retention clip (A),where
it says PUSH, with aslim screwdriver,
and pull the extension out afew centi-
metres.
3Remove the four pins from the ends (B).
4Put the oven part-way intoitsspace,
taking care not to drag the cardan teles-
copic shaftscoming from the hob,and
leaving enough space to put in the other
ends of the telescopic shaftsinto the
shaftsin the rear part ofthe control
panel, and then replace the pins. (See
fig. 5)
5Tomake the electric connection betwe-
en the two appliances, attach the hob’s
connector to oven’sconnector.
6Complete the definitive positioning of
the oven, ensuring that the cardan teles-
copic shaftsare firmly in position and
that the telescopic pipes are well-alig-
ned when inserted so that sliding is
quitesimple.
7Position the controls on the front of the
oven.
8Tooperate the control knobs, they first
have to be pressed in, and then turned
in order to release the safety device.
fig. 5
Retention clips
Pins

GB
19
Rear view of the Control Panel:
If the cardan telescopic shaftsare too
short, extensions can be added (notprovi-
ded,butavailable as anaccessory).
These are added by pressing, and they
are fixed by the cover thatis included.
Gas conversion
Model VT Dual. 1
Important!
Any alteration that isto be made to the
appliance to convert itto adifferent
type of gas should only be carried out
by aqualified technician.
Information for Technical Assis-
tance: whenever the type of gas or the
appliance’spressure is changed, the new
regulation plate should be placed on top of
the old one so that the new features can
be seen after the change.
The tasks involved in conversion are:
*Replace the injectors.
*Adjust the taps’minimums.
The injectors required for each gas type
are shown in table 1.
Toreplace the injectors, follow these ins-
tructions:
1Remove the grids and upper partsof the
burner so that the injector can be seen.
2Using anumber 7pipe spanner,remove
the injectorsand replace them withthe
new ones.Take caretopress the injector
downfirmly so that there is no leakage.
3Replace the grid and burners that were
previously removed.
When the injectors have been changed,
this is how to adjust the minimums:
1Take the oven or the control panel outso
that you can access the gas taps.
2Turn the burners on to their minimum.
3Use aslim, grooved screwdriver to turn
the screw located to the right or in the
centre of the gas tap’sshaft(the flame
increases when you turn tothe left and
decreases when you turn to the right).
4When properly adjusted, check that the
flame does notgo out when you turn the
knob quickly from maximum tominimum.
TEKAINDUSTRIAL,S.A. assumes no
responsibility for any hob malfunction ifthe
gas conversion or the adjustmentof the
burners’minimums has not been carried
outby TEKA’s official personnel.
Burner Family
Second Third
Group H Group E+ Group 3+
Rapid 116 116 85
Semi-rapid 97 97 66
Øinjector expressed in 1/100 mm.
Table 1
fig. 6
Flexible supplycable
Connector
Protective box for electrical assembly

GB
20
Technicalinformation
Dimensions andCharacteristics
Models VTN VS U VTC B VT VTC VTCM VR VTC VT VTC
DC HDC2 HDC2 622 DC DUAL.1 521
Hobdimensions
Height (mm) 120 120 120 120 120 85 120 120 163 120
Length (mm) 590 600 600 590 600 600 600 600 600 600
Width (mm) 510 510 510 510 510 510 510 510 510 510
Dimensionsof theplacementintheunit
Length (mm) 570 560 580 570 580 580 580 580 580 580
Width (mm) 492 480 492 492 492 492 492 492 492 492
Depth(mm) 115 113 115 115 115 60 115 115 117 115
Configuration
Double radiant hotplate
700/2100W circuit 1 1 1 1 1
Double radiant hotplate
700/1700W circuit 1 1
Double radiant hotplate
1400/2000W circuit 1 1
2100W radianthotplate 1 1
1800Whalogen
radianthotplate 1 1
1800W radiant hotplate 2 2 1 2 2 1
1500W radiant hotplate 2
1200Wradianthotplate 1 2 2 1 1 2 1 1 2
3kWrapid burner 1
1.75kWsemi-rapid
burner 1
Electrics
Nominal Power
(W)for 230 V* 6.900 6.000 6.300 6.700 6.700 6.000 7.100 6.900 3.300 6.300
Supply
voltage (V) SEE THE APPLIANCE’S RATINGPLATE
Frequency (Hz) 50-60 50-60 50-60 50-60 50-60 50-60 50-60 50-60 50-60 50-60
Gas
Power
Maximum (kW) 4,75
*For voltages other than 230 Vplease consult the appliance’srating plate
