Teka TM 601 Manual

INSTALLATION AND MAINTENANCE MANUAL
CERAMIC HOBS
ANLEITUNG FÜR EINBAU UND INSTANDHALTUNG
GLASKERAMIK-KOCHFELDER
MANUELD’INSTALLATION ETD’ENTRETIEN
CERAMIC HOBS
IINSTRUKCJA OBS£UGI IMONTA¯U
P£YTY CERAMICZNE
VTN DC –VT CM–VT DUAL.1 –VTCB–VTCDC
TR 640 –TR 620 –VT TC60.3 –VR 622 –TT 620
VT CM INOX HALOGEN –TT 600 –TT 630 –TC620
TB 600 –TT 640 –TR 600 –TR 735 AB –TM 620
TR 641 –TM 601

2
Contents/Inhalt /Table des Matières / Spis treœci
Page 4
13
14
14
15
16
16
16
16
17
17
18
19
19
21
22
22
22
24
25
26
26
27
29
30
31
32
32
32
33
33
34
34
35
37
GB DE
EINFÜHRUNG
Hinweise zum Gebrauch
EINBAU
Einbauortfür die Kochfelder
Verankerung des Kochfelds
Elektrischer Anschluss
Einbauortfür den Ofen
Glasmeramik-kochfelder mit
bedienelementen:
Anschluss des Kochfeldes an den
Backofen oder an das Bedienfeld
Modell VT DUAL.1:
Gasanschluss
Umstellung aufandere Gasart
TECHNISCHE INFORMATION
Abmessungen und Leistungsmerkmale
Technische Daten
GEBRAUCH UND INSTANDHALTUNG
Voraussetzungen für die
Inbetriebnahme
Gebrauchsanweisung für die
Berührungssensoren:
Zweikreis oder
Dreikreis-Kochzonen
Verriegelung der Berührungs-
sensoren für das Kochfeld
Sicherheits-Abschaltung
Elektronische Ankochautomatik
Timerfunktion
Verwendung der Uhrals
Stoppuhr für Countdown
Überspannungen im Stromnetz
Funktionsweise der
Glaskeramik-Kochzonen mit
bedienelementen
Model VT DUAL. 1:
Schutz gegen versehentliches
Drehen der Gasregler
Anzünden der Gasbrenner
Tipps für den korrekten Gebrauch
der Brenner
Reinigung und Pflege der Brenner
Instandhaltung VT DUAL.1
Tippsfür den korrekten Gebrauch
der VT-Kochzonen
Reinigung und Pflege
Im Störungsfall
Seite 4
39
40
40
41
42
42
43
43
44
44
44
46
46
48
49
49
49
51
52
53
53
54
57
58
59
60
60
60
61
62
62
62
63
66
INTRODUCTION
User Guide
INSTALLATION
Positioning the hobs
Fixing the hob
Connecting the electricity
Positioning the oven
Ceramic hobs with controls:
Joining the hob to the oven
or control panel
Model VT DUAL. 1:
Connecting the gas
Gas conversion
TECHNICALINFORMATION
Dimensions and power
Technical details
USE AND MAINTENANCE
Requirementsbefore first use
Touch control user instructions:
Double or Triple circuit hotplate
Locking the hob’ssensor
Safety disconnection
Heat-up function
Timer function
The clock as countdown timer
Power surges
Ceramic hobs with controls
instructions
Model VT DUAL. 1:
Anti-accidental turn system
on gas controls
Igniting the burners
Suggestions on using the
burners effectively
Cleaning and care the burners
Mantaining the VT DUAL.1
Advice on using the glass ceramic
hotplates effectively
Cleaning and care
If something doesn’t work

3
FR
PRÉSENTATION
Guide d’utilisation
INSTALLATION
Logement des tables de cuisson
Fixation des tables de cuisson
Branchement électrique
Logement du four
Vitroceramique acommande:
Raccordementde la table de
cuisson au four ou au bandeau
de commandes
Modèle VT DUAL.1:
Raccordementau gaz
Adaptation du gaz
INFORMATIONSTECHNIQUES
Dimensions et puissances
Données techniques
UTILISATION ET ENTRETIEN
Conditions de mise en service
Instructions d’utilisation de
la commande sensitive:
Plaques àdouble et triple foyer
Blocage des Touches sensitives
de la table de cuisson
Déconnexion de sécurité
Coup de cuisson
Fonction minuteur
L’Horloge en tant que chronométre
de compte àrebours
Surtensions sur la ligne
Fonctionnement des plaques
vitrocéramiques acommande
Modèle VT DUAL.1:
Système de blocage de
commandes de gaz
Allumage des brûleurs
Recommandations pour une
bonne utilisation des brûleurs
Nettoyage et entretien des
brûleurs
Entretien de la VT DUAL.1
Recommandations pour une
bonne utilisation des plaques VT
Nettoyage etstockage
Si quelque chose ne fonctionne pas
Page 4
68
69
69
70
71
71
71
71
72
72
73
74
74
76
77
77
77
79
80
81
81
82
85
86
86
88
88
88
89
89
90
90
90
93
PL
OPIS URZ¥DZENIA
Przed pierwszym u¿yciem
INSTALACJA
Monta¿
Monta¿ p³yty
Po³¹czenie elektryczne
Monta¿ piekarnika
Pod³¹czenie p³ytydo piekarnika
Model VT DUAL. 1:
Pod³¹czenie do instalacji gazowej
Zmiana ciœnienia i/lub rodzaju gazu
INFORMACJE TECHNICZNE
Tabela wymiarówidanych technicznych
Dane techniczne
OBS£UGA URZ¥DZENIA
Sensorowy panel steruj¹cy
Potrójne/podwójne pole grzejne
Blokada nastawieñ
Wy³¹cznik bezpieczeñstwa
Funkcja szybkiego zagotowania
Timer
Minutnik
Zabezpieczenie przed przegrzaniem
P³yty ceramiczne ze sterowaniem
pokrêt³ami
Model VT DUAL. 1:
Zabezpieczenie przed przypadkowym
w³¹czeniem palników gazowych
Zapalenie palników
Zalecenia dotycz¹ce u¿ywania
palnikówgazowych
Czyszczenie ipielêgnacja palników
Konserwacja p³ytyVTDUAL.1
Wskazówki izalecenia dotycz¹ce
korzystania zpól grzejnych
Czyszczenie ikonserwacja
Przed wezwaniem serwisu
Strona 4
95
96
96
97
98
98
98
99
99
100
101
101
103
104
104
106
107
107
108
109
111
111
112
113
113
113
114
114
115
115
115
118

Introduction /Einführung /Présentation / Opis urz¹dzenia
Model VTN DC
11,200 watt hotplate.
21,800 watt hotplate.
3700/2,100 watt double circuit hotplate.
41,800 watt hotplate.
5Residual heat indicator lights.
*Maximum electric power: 6,900 watts.
Modell VTNDC
1Kochzone 1200 W
2Kochzone 1800 W
3Zweikreis-Kochzone mit 700/2100 W
4Kochzone 1800 W
5Kontrollleuchten zur Restwärme-Anzeige
*Maximale elektrische Leistung: 6900 W
Modèle VTN DC
1Plaque de 1.200 Watts.
2Plaque de 1.800 Watts.
3Plaque àdouble foyer de 700/2.100 Watts.
4Plaque de 1.800 Watts.
5 Témoins de chaleur résiduelle.
*Puissance électrique maximale: 6.900 Watts.
ModelVTN DC
1Pole grzejne omocy 1.200 W
2Pole grzejne omocy 1.800 W
3Pole grzejne podwójneomocy 700 /2.100 W
4Pole grzejne omocy 1.800 W
5Wska¿niki zalegania ciep³a
*Maksymalnypobór mocy 6.900 W
GB
DE
FR
12
34
5
4
Model VT CM
11,200 watt hotplate.
21,800 watt hotplate.
31,800 watt hotplate.
41,200 watt hotplate.
5Residual heat indicator lights.
*Maximum electric power: 6,000 watts.
Modell VT CM
1Kochzone 1200 W
2Kochzone 1800 W
3Kochzone 1800 W
4Kochzone 1200 W
5Kontrollleuchten zur Restwärme-Anzeige
*Maximale elektrische Leistung: 6000 W
Modèle VT CM
1Plaque de 1.200 Watts.
2Plaque de 1.800 Watts.
3Plaque de 1.800 Watts.
4Plaque de 1.200 Watts.
5Témoins de chaleur résiduelle.
*Puissance électrique maximale: 6.000
Watts.
Model VT CM
1Pole grzejne omocy 1.200 W
2Pole grzejne omocy 1.800 W
3Pole grzejne omocy 1.800 W
4Pole grzejne omocy 1.200 W
5Wska¿niki zalegania ciep³a
*Maksymalny pobór mocy 6.000 W
GB
DE
FR
12
34
5
PL PL

5
Model VT CM INOX HALOGEN
11,200 watt hotplate.
21,800 watt halogen hotplate.
31,800 watt hotplate.
41,200 watt hotplate.
5Residualheat indicator lights.
*Maximum electric power: 6,000 watts.
Modell VT CM
1Kochzone 1200 W
2Halogen-Kochzone 1800 W
3Kochzone 1800 W
4Kochzone 1200 W
5Kontrollleuchten zur Restwärme-Anzeige
*Maximale elektrische Leistung: 6000 W
Modèle VT CM
1Plaque de 1.200 Watts.
2Plaque halogène de 1.800 Watts.
3Plaque de 1.800 Watts.
4Plaque de 1.200 Watts.
5 Témoins de chaleur résiduelle.
*Puissance électrique maximale: 6.000
Watts.
Model VTCM INOX HALOGEN
1Polegrzejne omocy 1.200 W
2Polegrzejne omocy 1.800 W
3Polegrzejne omocy 1.800 W
4Polegrzejne omocy 1.200 W
5Wska¿niki zalegania ciep³a
*Maksymalnypobór mocy 6.000 W
GB
DE
FR
12
34
5
Model VT DUAL.1
1700/2,100 watt double circuit hotplate.
2Semi-rapid burner 1,500 Kcal/h -1.75 kW.
31200 watt hotplate.
4Rapid burner 2,580 Kcal/h -3 kW.
5Grids.
6Residual heat indicator lights.
*Maximum electric power: 3,300 watts.
*Maximum calorific power: 4,080 Kcal/h -4.75
kW/h.
Modell VT DUAL.1
1Zweikreis-Kochzone mit 700/2100 W
2Mittel-Brenner mit 1500 kcal/h -1,75 kW
3Kochzone 1200 W
4Stark-Brenner mit2580 kcal/h -3kW
5Stellroste
6Kontrollleuchten zur Restwärme-Anzeige
*Maximale elektrische Leistung: 3300 W
*Maximale Wärmeleistung: 4080 Kcal/h -
4,75 kW/h
Modèle VT DUAL.1
1Plaque àdoublefoyer de 700/2.100 Watts.
2Brûleur semi-rapide de 1.500 Kcal/h -
1,75 kW.
3Plaque de 1.200 Watts.
4Brûleur rapide de 2.580 Kcal/h -3kW.
5Grilles.
6Témoins de chaleur résiduelle.
*Puissance électrique maximale: 3.300
Watts.
*Puissance calorifique maximale: 4.080
Kcal/h -4,75 kW.
Model VT DUAL.1
1Polegrzejne podwójne omocy 700 /2.100 W
2Palnik gazowy omocy 1.750 W
3Polegrzejne omocy 1.200 W
4Palnik gazowy omocy 3.000 W
5Ruszty
6Wska¿nikizalegania ciep³a
*Maksymalny pobór mocy 3.300 W
*Maksymalna moc grzejna (gaz) 4.750 W/h
GB
DE
FR
12
34
5
5
6
PL
PL

6
Model VTCB
11,200 watt hotplate.
21,800 watt hotplate.
32,100 watt hotplate.
41,200 watt hotplate.
5Residual heat indicator lights.
*Maximum electric power: 6,300 watts.
Modell VTC B
1Kochzone 1200 W
2Kochzone 1800 W
3Kochzone 2100 W
4Kochzone 1200 W
5Kontrollleuchten zur Restwärme-Anzeige
*Maximale elektrische Leistung: 6300 W
Modèle VTCB
1Plaque de 1.200 Watts.
2Plaque de 1.800 Watts.
3Plaque de 2.100 Watts.
4Plaque de 1.200 Watts.
5 Témoins de chaleur résiduelle.
*Puissance électrique maximale: 6.300
Watts.
Model VTC B
1Pole grzejneomocy 1.200 W
2Pole grzejneomocy 1.800 W
3Pole grzejneomocy 2.100 W
4Pole grzejneomocy 1.200 W
5Wska¿niki zalegania ciep³a
*Maksymalny pobór mocy 6.300 W
GB
DE
FR
12
34
5
Model VTC DC
11,200 watt hotplate.
21,800 watt hotplate.
3700/2,100 watt double circuit hotplate.
41,800 watt hotplate.
5Residual heat indicator lights.
*Maximum electricpower: 6,900 watts.
Modell VTC DC
1Kochzone 1200 W
2Kochzone 1800 W
3Zweikreis-Kochzone mit700/2100 W
4Kochzone 1800 W
5Kontrollleuchten zur Restwärme-Anzeige
*Maximaleelektrische Leistung: 6900 W
Modèle VTC DC
1Plaque de 1.200 Watts.
2Plaque de 1.800 Watts.
3Plaque àdouble foyer de 700/2.100 Watts.
4Plaque de 1.800 Watts.
5 Témoins de chaleur résiduelle.
*Puissance électrique maximale: 6.900
Watts.
Model VTC DC
1Pole grzejne omocy 1.200 W
2Pole grzejne omocy 1.800 W
3Pole grzejne podwójne omocy 700 /2.100 W
4Pole grzejne omocy 1.800 W
5Wska¿niki zalegania ciep³a
*Maksymalnypobórmocy 6.900 W
GB
DE
FR
12
34
5
PL PL

7
Model VR 622
11,500 watt hotplate.
21,400/2,000 watt double circuit hotplate.
3700/2,100 watt doublecircuithotplate.
41,500 watt hotplate.
5Residual heat indicator lights.
*Maximum electric power: 7,100 watts.
Modell VR 622
1Kochzone 1500 W
2Zweikreis-Kochzone mit 1400/2000 W
3Zweikreis-Kochzone mit 700/2100 W
4Kochzone 1500 W
5Kontrollleuchten zur Restwärme-Anzeige
*Maximale elektrische Leistung: 7100 W
Modèle VR 622
1Plaque de 1.500 Watts.
2Plaque àdouble foyer de 1.400/2.000 Watts.
3Plaque àdouble foyer de 700/2.100 Watts.
4Plaque de 1.500 Watts.
5Témoins de chaleur résiduelle.
*Puissance électrique maximale: 7.100 watts.
Model VR 622
1Pole grzejne omocy 1.500 W
21.400/2.000 watt double circuit hotplate.
3Pole grzejne podwójne omocy 700 /2.100 W
4Pole grzejne omocy 1.500 W
5Wska¿niki zalegania ciep³a
*Maksymalny pobór mocy 7.100 W
GB
DE
FR
12
34
5
Model TT620
11,400/2,000 watt doublecircuit hotplate.
21,800 watt hotplate.
31,200 watt hotplate.
41,500 watt hotplate.
*Residualheat indicator.( H )
*Maximum electric power: 6,500 watts.
Modell TT 620
1Zweikreis-Kochzone mit 1400/2000 W
2Kochzone 1800 W
3Kochzone 1200 W
4Kochzone 1500 W
*Restwärme-Anzeige ( H )
*Maximale elektrische Leistung: 6500 W
Modèle TT620
1Plaque àdouble foyer de 1.400/2.000 Watts.
2Plaque de 1.800 Watts.
3Plaque de 1.200 Watts.
4Plaque de 1.500 Watts.
* Témoin de chaleur résiduelle. ( H )
*Puissance électrique maximale: 6.500 Watts.
ModelTT 620
11.400/2.000 watt double circuit hotplate.
2Pole grzejne omocy 1.800 W
3Pole grzejne omocy 1.200 W
4Pole grzejne omocy 1.500 W
*Wska¿niki zalegania ciep³a (H)
*Maksymalnypobór mocy 6.500 W
GB
DE
FR
12
34
PL PL

8
Model TR620
1700/2,100 watt double circuit hotplate.
21,800 watt hotplate.
31,500 watt hotplate.
41,200 watt hotplate.
*Residualheat indicator.( H )
*Maximum electric power: 6,600 watts.
Modell TR 620
1Zweikreis-Kochzone mit 700/2100 W
2Kochzone 1800 W
3Kochzone 1500 W
4Kochzone 1200 W
*Restwärme-Anzeige ( H )
*Maximale elektrische Leistung: 6600 W
Modèle TR620
1Plaque àdouble foyer de 700/2.100 Watts.
2Plaque de 1.800 Watts.
3Plaque de 1.500 Watts.
4Plaque de 1.200 Watts.
* Témoin de chaleur résiduelle. ( H )
*Puissance électrique maximale: 6.600
Watts.
ModelTR 620
1Polegrzejne podwójneomocy 700 /2.100 W
2Polegrzejne omocy 1.800 W
3Polegrzejne omocy 1.500 W
4Polegrzejne omocy 1.200 W
*Wska¿niki zalegania ciep³a (H)
*Maksymalnypobór mocy 6.600 W
GB
DE
FR
12
34
Model VTTC60.3
11,200 watt hotplate.
2700/1,700 watt doublecircuithotplate.
31,400/2,000 watt double circuit hotplate.
41,200 watt hotplate.
*Residual heat indicator.( H )
*Maximum electric power: 6,100 watts.
Modell VT TC 60.3
1Kochzone 1200 W
2Zweikreis-Kochzone mit 700/1700 W
3Zweikreis-Kochzone mit 1400/2000 W
4Kochzone 1200 W
*Restwärme-Anzeige ( H )
*Maximale elektrische Leistung: 6100 W
Modèle VTTC 60.3
1Plaque de 1.200 Watts.
2Plaque àdouble foyer de 700/1.700 Watts.
3Plaque àdouble foyer de 1.400/2.000 Watts.
4Plaque de 1.200 Watts.
* Témoin de chaleur résiduelle. ( H )
*Puissance électrique maximale: 6.100
Watts.
Model VT TC 60.3
1Pole grzejneomocy 1.200 W
2Pole grzejnepodwójne omocy 700 /1.700 W
3Pole grzejnepodwójne omocy 1.400 /2.000 W
4Pole grzejneomocy 1.200 W
*Wska¿niki zalegania ciep³a(H)
*Maksymalny pobór mocy 6.100 W
GB
DE
FR
12
34
PL PL

9
Models TR 640 andTT640
1700/1,700 watt double circuit hotplate.
21,800/2,700 (or 1,500/2,400 Watts, according
to the model) watt double circuit hotplate.
31,200 watt hotplate.
*Residual heat indicator.( H )
*Maximum electricpower: 5,300 (or 5,600)
watts.
Modelle TR 640 und TT640
1Zweikreis-Kochzone mit700/1700 W
2Zweikreis-Kochzone mit1800/2700 (oder
1.500/2.400 W,jenach Modell) W
3Kochzone 1200 W
*Restwärme-Anzeige ( H )
*Maximaleelektrische Leistung: 5300 (oder
5,600) W
Modèles TR 640 et TT640
1Plaque àdouble foyer de 700/1.700 Watts.
2Plaque àdouble foyer de 1.800/2.700
(1.500/2.400 Watts, selon le modèle) Watts.
3Plaque de 1.200 Watts.
* Témoin de chaleur résiduelle. ( H )
*Puissance électrique maximale: 5.300 (ou
5,600) Watts.
ModeleTR 640 and TT 640
1Pole grzejne podwójne omocy 700 /1.700 W
2 Pole grzejne podwójne omocy 1.800 /2.700
W(lub 1.800 /2.700 W–wzale¿noœci od
modelu)
3Pole grzejne omocy 1.200 W
*Wska¿nik zalegania ciep³a (H)
*Maksymalnypobórmocy 5.300 (lub 5.600) W
GB
DE
FR
1
2
3
Model TT630
11,800 watt hotplate.
21,500/2,400 watt doublecircuithotplate.
31,200 watt hotplate.
*Residualheat indicator.( H )
*Maximum electric power: 5,400 watts.
Modelle TT 630
1Kochzone 1800 W
2Zweikreis-Kochzone mit 1500/2400 W
3Kochzone 1200 W
*Restwärme-Anzeige ( H )
*Maximale elektrische Leistung: 5400 W
Modèle TT630
1Plaque de 1.800 Watts.
2Plaque àdouble foyer de 1.500/2.400
Watts.
3Plaque de 1.200 Watts.
* Témoin de chaleur résiduelle. ( H )
*Puissance électrique maximale: 5.400
Watts.
ModelTT 630
1Pole grzejne omocy 1.800 W
2Pole grzejne podwójneomocy 1.500 /
2.400 W
3Pole grzejne omocy 1.200 W
*Wska¿nikizalegania ciep³a (H)
*Maksymalnypobór mocy 5.400 W
12
3
GB
DE
FR
PL
PL

10
Model TT600, TR 600 and TB 600
12,100 watt hotplate.
21,800 watt hotplate.
31,200 watt hotplate.
41,200 watt hotplate.
*Residual heat indicator.( H )
*Maximum electricpower: 6,300 watts.
Modell TT 600, TR 600 undTB 600
1Kochzone 2100 W
2Kochzone 1800 W
3Kochzone 1200 W
4Kochzone 1200 W
*Restwärme-Anzeige ( H )
*Maximaleelektrische Leistung: 6300 W
Modèle TT600, TR 600 et TB 600
1Plaque de 2.100 Watts.
2Plaque de 1.800 Watts.
3Plaque de 1.200 Watts.
4Plaque de 1.200 Watts.
* Témoin de chaleur résiduelle. ( H )
*Puissance électrique maximale: 6.300
Watts.
Model TT 600,TR 600 andTB600
1Pole grzejne omocy 2.100 W
2Pole grzejne omocy 1.800 W
3Pole grzejne omocy 1.200 W
4Pole grzejne omocy 1.200 W
*Wska¿niki zalegania ciep³a (H)
*Maksymalnypobórmocy 6.300 W
12
34
GB
DE
FR
Model TC 620
11,400/2,000 watt double circuit hotplate.
21,800 watt hotplate.
31,200 watt hotplate.
41,500 watt hotplate.
*Residual heat indicator.( H )
*Maximum electricpower: 6,500 watts.
Modelle TC620
1Zweikreis-Kochzone mit1400/2000 W
2Kochzone 1800 W
3Kochzone 1200 W
4Kochzone 1500 W
*Restwärme-Anzeige ( H )
*Maximaleelektrische Leistung: 6500 W
Modèle TC 620
1Plaque àdouble foyer de 1.400/2.000 Watts.
2Plaque de 1.800 Watts.
3Plaque de 1.200 Watts.
4Plaque de 1.500 Watts.
* Témoin de chaleur résiduelle. ( H )
*Puissance électrique maximale: 6.500 Watts.
Model TC 620
1Pole grzejne podwójne omocy 1.400 /2.000 W
2Pole grzejne omocy 1.800 W
3Pole grzejne omocy 1.200 W
4Pole grzejne omocy 1.500 W
*Wska¿niki zalegania ciep³a (H)
*Maksymalnypobórmocy 6.500 W
12
34
GB
DE
FR
PL PL

11
1
3
Model TR 735 AB
11,800 watt hotplate.
2 1050 /1,950 /2,700 watt hotplate.
31,200 watt hotplate.
*Residual heat indicator.( H )
*Maximum electric power: 5,700 watts.
Modell TR 735AB
1Kochzone 1800 W
2Kochzone 1050 /1950/2700 W
3Kochzone 1200 W
*Restwärme-Anzeige ( H )
*Maximaleelektrische Leistung: 5700 W
Modèle TR 735 AB
1Plaque de 1800 Watts.
2Plaque de 1.050 /1.950/2.700 Watts.
3Plaque de 1.200 Watts.
* Témoin de chaleur résiduelle. ( H )
*Puissance électrique maximale: 5.700
Watts.
Model TR 735AB
1Pole grzejne omocy 1.800 W
2 Pole grzejnepotrójne omocy
1.050 /1.950 /2.700 W
3Pole grzejne omocy 1.200 W
*Wska¿niki zalegania ciep³a (H)
*Maksymalnypobór mocy 5.700 W
GB
DE
FR
2
GB
DE
FR
Model TM620
1700/2,100 watt double circuit hotplate.
21,800 watt hotplate.
31,500 watt hotplate.
41,200 watt hotplate.
*Residual heat indicator.( H )
*Maximum electric power: 6,600 watts.
Modell TM 620
1Zweikreis-Kochzone mit 700/2100 W
2Kochzone 1800 W
3Kochzone 1500 W
4Kochzone 1200 W
*Restwärme-Anzeige ( H )
*Maximale elektrische Leistung: 6600 W
Modèle TM 620
1Plaque àdouble foyer de 700/2.100 Watts.
2Plaque de 1.800 Watts.
3Plaque de 1.500 Watts.
4Plaque de 1.200 Watts.
* Témoin de chaleur résiduelle. ( H )
*Puissance électrique maximale: 6.600
Watts.
ModelTM 620
1Pole grzejne podwójne omocy 700 /2.100 W
2Pole grzejne omocy 1.800 W
3Pole grzejne omocy 1.500 W
4Pole grzejne omocy 1.200 W
*Wska¿niki zalegania ciep³a (H)
*Maksymalnypobór mocy 6.600 W
12
34
PL
PL

12
12
34
12
34
GB
DE
FR
Model TM 601
12,100 watt hotplate.
21,800 watt hotplate.
31,200 watt hotplate.
41,200 watt hotplate.
*Residual heat indicator.( H )
*Maximum electricpower: 6,300 watts.
Modell TM601
1Kochzone 2100 W
2Kochzone 1800 W
3Kochzone 1200 W
4Kochzone 1200 W
*Restwärme-Anzeige ( H )
*Maximale elektrische Leistung: 6300 W
Modèle TM 601
1Plaque de 2.100 Watts.
2Plaque de 1.800 Watts.
3Plaque de 1.200 Watts.
4Plaque de 1.200 Watts.
* Témoinde chaleur résiduelle. ( H )
*Puissance électrique maximale: 6.300
Watts.
Model TM 601
1Pole grzejne omocy 2.100 W
2Pole grzejne omocy 1.800 W
3Pole grzejne omocy 1.200 W
4Pole grzejne omocy 1.200 W
*Wska¿niki zalegania ciep³a (H)
*Maksymalnypobór mocy 6.300 W
PL
GB
DE
FR
Model TR 641
11,400/2,000 watt double circuit hotplate.
21,800 watt hotplate.
31,200 watt hotplate.
41,200 watt hotplate.
*Residual heat indicator.( H )
*Maximum electricpower: 6,200 watts.
Modell TR 641
1Zweikreis-Kochzone mit1400/2000 W
2Kochzone 1800 W
3Kochzone 1200 W
4Kochzone 1200 W
*Restwärme-Anzeige ( H )
*Maximale elektrische Leistung: 6200 W
Modèle TR 641
1Plaque àdouble foyer de 1.400/2.000 Watts.
2Plaque de 1.800 Watts.
3Plaque de 1.200 Watts.
4Plaque de 1.200 Watts.
* Témoinde chaleur résiduelle. ( H )
*Puissance électrique maximale: 6.200
Watts.
Model TR 641
1Pole grzejne podwójne omocy 1.400 /2.100 W
2Pole grzejne omocy 1.800 W
3Pole grzejne omocy 1.200 W
4Pole grzejne omocy 1.200 W
*Wska¿niki zalegania ciep³a (H)
*Maksymalnypobór mocy 6.200 W
PL

GB
13
Guide to Using theInstructions Booklet
Dear customer,
Weare delighted that you have put your
trust in us.
Weare confident that the new hob that
you have purchased will fully satisfy your
needs.
Thismodern, functionalandpractical
model has been manufactured using top-
qualitymaterialsthathaveundergone
strict quality controls throughoutthe ma-
nufacturing process.
Before installing and using it,we would
ask that you read this Manual carefully
and follow the instructions closely,as this
will guarantee better resultswhen using
the appliance.
Keep thisInstruction Manual in asafeplace
sothatyou can refertoiteasily and thus
abide by theguarantee conditions.
Inordertobenefit fromthisGuarantee,itis
essential thatyousubmitthepurchasere-
ceipttogether with theGuaranteecertificate.
You should keep the Guarantee
Certificate or,where relevant,the tech-
nical datasheet, together with the Ins-
truction Manual for the duration of the
useful life of the appliance.It has im-
portant technical information about the
appliance.
Safety instructions
Before first use, you should carefully read
the installation and connection instruc-
tions.
These hob models may be installed in the
samekitchenfurniture unitsas TEKA
brand ovens.
For your safety,installation should be ca-
rried out by an authorised technician and
should comply with existing installation
standards.Likewise, any internal work on
the hob should only be done by TEKA’s
technical staff, including the change of the
flexible supply cable of the appliance.
Please note:
When the hotplates are in opera-
tion or have recently been in operation,
some areas willbe hot and can burn.
Children shouldbe kept wellaway.
Ifthe glass ceramicbreaks or
cracks, the hob should immediately be
disconnected from the electric current
in order to avoid the risk of electric
shock.
When the halogen heating ele-
mentsare in operation, you should not
look directly at them in case damage is
caused.

GB
14
Important
INSTALLATION ANDSETUPSHOULD
BE CARRIED OUT BYAN AUTHORISED
TECHNICIAN INLINE WITH CURRENT
INSTALLATION STANDARDS.
Positioning the hobs
Depending on the model to be installed,an
opening with the dimensions shown in fi-
gure 2will be cut into the unit’s worktop.
The system for fixing the hob is intended
for use with kitchen unitswith athickness
of 20, 30 and 40 mm. In the packaging of
the models VTN DC and TC 620, there is
atemplate included that is for use in sizing
the space for these glass ceramic hob mo-
dels.
See the fiting hole’sdimensions for each
model on the “dimensions and characteris-
tics” table of this manual. The minimum
distance between the surface supporting
the cooking pans and the lower part ofthe
kitchen unit or the hood located above the
hob should be 650 mm. If the hood’sins-
tallation instructions recommend that the
gap is greater than this, you should follow
this advice.
The hobs described in this manual can
only be installed with Teka ovens. Models
with no control knobs are only to be insta-
lled with Teka ovens and/or Teka control
panels.
The unit where the hob and oven will be lo-
cated will be suitably fixed.
INSTALLATION WITH ACUTLERY DRA-
WERORLOW CUPBOARD(TOUCH
CONTROL MODELS)
If you wish tohave acupboard or cutlery
drawer beneath the hob, you should install
a panel to separate them. This will prevent
accidental contactwith the hot surface of
the body of the appliance.
The board should be installed 20 mm
below the bottom of the hob and an empty
Installation
fig. 1
Minimum distances
to walls
Minimumventilation
distances
OVEN
minimun 40 mm
minimun 40 mm
minimun 40 mm
OVEN

GB
15
space of at least 20 mm should be left at
the back of the cupboard. As an alternati-
ve to this type of panel,you can install a
detachable protective cover tothe bottom
of the hob, which can be obtained from our
Technical Services using the reference in-
dicated.
When hobs are handled before
being installed,care should be taken in
case there is any protruding part or
sharp edge which could cause injury.
When installing unitsor applian-
ces above the hob, the hob should be
protected by aboard so that the glass
cannotbedamaged byaccidental
blows or heavy weights.
The glues used in manufacturing
the kitchen unit and in the adhesive on
the decorative laminate of the worktop
surface should be made to tolerate tem-
peratures of up to 100ºC.
TEKAassumes no responsibility
for any malfunction or damage caused
by faulty installation.
PLEASE REMEMBER THATTHE GUA-
RANTEEDOESNOTCOVER THE
GLASS IFITSUFFERSAVIOLENT
BLOW OR IF ITIS USED IMPROPERLY.
Fixing the hob
(see figs. 3and 4)
When the gap has been properly sized,
the sealing washer should be put on the
lower partof the hob. With models VR 622,
TR 620, TR640, TT 640,TT600, TB 600,
TR 600, TT 630,TR 735 AB, TM 620, TR
641 and TM 601 the washer will be stuck
to the lower face of the glass.
Silicone shouldnotbe applied between
the glass and the unitworktop because
ifitbecomes necessaryto remove the
hob from itsposition,the glass could
break when trying to detach it.
Position theclipsas shownin the diagram,
fastening them tothe openings in the lower
part ofthe body using the screwsprovided.
For worktop thicknesses of 30 mm. or less,
use the self-tapping screws (M5) thatare
provided as afastening accessory -put
them into the clip’s round hole. This hole
will be threaded as the screw is inserted
into it, and this should be done before fi-
xing the clip to the worktop.
VTN DC and TC 620
Rest of the models The dimensions Land Ware
shownin the table"Dimensions and characteris-
tics" of the Technical Information section.
fig. 2
Fitting holes
maximun575
maximun575
Ref.Models
81253177 TT600, TB600, TR 640, TT
640, TR 620, TT630, TR600,
TR 735 AB, TM 620, TR 641
and TM 601
81253176 VTTC60.3, TT620 and
TC 620
Protective cover
W
L

GB
16
The clips and the sealing joint are provi-
ded, and can be found in the packaging.
Connecting the electricity
Before connecting the hob to the electric
mains, check that the voltage and fre-
quency ofthe mains matches what is
shown on the hob’srating plate, which is
located lower down, and on the guarantee
certificate or,where appropriate, the tech-
nical datasheet supplied,which should be
kept together withthis manual.
The electric connection is made via an om-
nipolar switch or plug where accessible,
which is suitable for the intensity tobe to-
lerated and which has a minimum gap of3
mm between itscontacts, which will ensu-
re disconnection in case ofemergency or
when cleaning the hob.
The connection should include correct ear-
thing,in compliance with current norms.
Ifthe flexible supplycablefitted to the VT CM
hob model ever needs to bechanged, it
should bereplaced byTEKA’s official service.
The input cable should not be in contact ei-
ther with the body ofthe hob or withthe
body of the oven, if the oven is installed in
the same unit.
Positioningthe oven
See the corresponding manual.
The oven’splacement should be as shown
in your instruction manual, and the manual
should also be referred to when connec-
ting the electricity.Before accessing the in-
side of the appliance, the appliance should
be disconnected from the power.
Ceramic hobs withcontrols
Joining the hob to the oven
or the control panel
For this purpose, four cardan telescopic
shaftsare included with the hob. (See fig.
5).The way tojoin them is as follows:
1Turn off the electricity.
2Detach the cardan telescopic shaftsby
pressing on the retention clip (A), where
itsays PUSH, with aslim screwdriver,
and pull the extension out afew centi-
metres.
3Remove the four pins from the ends (B).
4Put the oven part-way intoitsspace, ta-
king care not to drag the cardan teles-
copic shaftscoming from the hob, and
leaving enough space to put in the other
ends of the telescopic shaftsinto the
shaftsin the rear part of the control
panel, and then replace the pins. (See
fig. 5)
40 mm
20/30 mm
Self-tapping screw for 20
and 30 mmthickworktops
40 mm
20/30 mm
Self-tapping screw for 20
and 30 mmthick worktops
Sealing joint
Sealing joint
fig. 3
fig. 4

GB
17
5Tomake the electric connection betwe-
en the two appliances, attach the hob’s
connector to oven’sconnector.
6Complete the definitive positioning of
the oven, ensuring thatthe cardan teles-
copic shaftsare firmly in position and
that the telescopic pipes are well-alig-
ned when inserted so that sliding is
quite simple.
7Position the controls on the front of the
oven.
8Tooperate the control knobs, they first
have tobe pressed in, and then turned
in order to release the safety device.
Rear view of the ControlPanel:
If the cardan telescopic shaftsare too
short, extensions can be added (not provi-
ded,butavailableas anaccessory).
These are added by pressing,and they
are fixed by the cover that is included.
Model VT DUAL.1
Connecting the gas
Connecting the hob to the gas mains
should be done in compliance with the cu-
rrent installation standards and/or regula-
tions.
Ventilation slotsshould also be made at
the site in compliance withcurrent norms.
The hob is provided with athreaded con-
nection 1/2” in diameter,in line with ISO
228-1. AØ10/12 mm. copper pipe is pro-
vided as an accessory for welding the gas
inlet pipe.
Whenever the gas connection nutis remo-
ved, itsjoint should be changed.
In order that the hob is not damaged by
tightening the nut on the gas connection
fig. 5
Retention clips
Pins
fig. 6
Flexible supply cable
Connector
Protective box for electrical assembly

GB
18
pipe, amaximum torque of 300 Kgf *cm
should be applied.
When the gas connection has been made,
the installation should be checked to ensu-
re that it is completely sealed. If the check
is done using air,care should be taken that
the test pressure is no more than 200
g./cm2.Where air is not available, soapy
water should be applied toensure that
there are no leaks in the connections. Tes-
ting should never be done using a
flame.
When the hob has been installed, check
that the burnerminimums areproperly ad-
justed.Todo this, lightthe burners and
check thatthey do not go out ifyou switch
quickly from the maximum to the minimum.
Gas conversion
Important!
Any alteration that is to be made to the
appliance to convert it to adifferent
type of gas should onlybe carried out
by aqualified technician.
Information for Technical Assis-
tance: whenever the type of gas or the ap-
pliance’s pressure is changed, the new re-
gulation plate should be placed on top of
the old one so that the new features can
be seen after the change.
The tasks involved in conversion are:
*Replace the injectors.
*Adjust the taps’minimums.
The injectors required for each gas type
are shown in table 1.
Toreplace the injectors, followthese ins-
tructions:
1Remove the grids and upper partsof the
burner so thatthe injector can be seen.
2Using anumber7pipe spanner,remove
the injectors and replace them withthe
new ones.Take caretopress the injector
down firmly so thatthere is no leakage.
3Replace the grid and burners that were
previously removed.
When the injectors have been changed,
this is how to adjust the minimums:
1Take the oven or the control panel out so
thatyou can access the gas taps.
2Turn the burners on to their minimum.
3Use aslim, grooved screwdriver to turn
the screw located to the right or in the
centre of the gas tap’s shaft(the flame
increases when you turn to the leftand
decreases when you turn tothe right).
4When properly adjusted, check thatthe
flame does not go outwhen you turn the
knob quickly from maximum to minimum.
TEKAINDUSTRIAL, S.A. assumes no
responsibilityfor any hob malfunction if the
gas conversion or the adjustment ofthe
burners’minimums has not been carried
out by TEKA’sofficial personnel.
Burner Family
Second Third
Group H Group E+ Group 3+
Rapid 116 Y 116 Y 85
Semi-rapid 97 Z 97 Z 66
Øinjector expressed in 1/100 mm.
Table 1

GB
19
Technical information
Dimensionsand Characteristics
TT VTTC
Models 620 60.3
Hobdimensions
Height (mm) 65 65 67 65
Length (mm) 600 600 600 600
Width (mm) 510 510 510 510
Dimensions oftheplacement in theunit
Length (mm) (L) 560 560 580 580
Width (mm) (W) 490 490 492 492
Depth (mm) 61 61 63 60
Configuration
Double radianthotplate
1800/2700 Wcircuit 1
Triple radiant hotplate
1050/1950/2700W circuit
Double radiant hotplate
700/2100Wcircuit 1
Double radiant hotplate
700/1700Wcircuit 1 1
Double radiant hotplate
1400/2000W circuit 1 1
2100W radiant hotplate
1800W halogen
radiant hotplate
1800W radiant hotplate 1 1
1200W radiant hotplate 1 1 1 2
1500W radiant hotplate 1 1
Electrics
Nominal Power
(W) for 230 V* 5.600 6.600 6.500 6.100
Supply
voltage (V)
Frequency (Hz) 50-60 50-60 50-60 50-60
*For voltages other than 230 Vplease consult the rating plate
TR 640
TT640 TT 600
TR600
TB 600
TM 601
TT
630
VT CM
INOX
HALO-
GEN
65
600
510
65
600
510
85
600
510
560
490
61
560
490
61
580
492
60
1
1
1
2
1
1
1
2
1
50-60 50-60 50-60
6.300 5.400 6.000
SEE THE APPLIANCE’SRATING PLATE
TC
620
65
590
510
570
492
60
1
1
1
1
6.500
50-60 50-60
TR735
AB
65
700
540
560
490
61
1
1
1
5.700
TR 620
TM620

GB
20
Models VTN VT VTC B VTCM VR VTC
DC DUAL.1 622 DC
Hobdimensions
Height(mm) 120 163 120 85 120 120
Length (mm) 590 600 600 600 600 600
Width (mm) 510 510 510 510 510 510
Dimensionsof theplacementintheunit
Length (mm) (L) 570 580 580 580 580 580
Width (mm) (W) 492 492 492 492 492 492
Depth (mm) 115 117 115 60 115 115
Configuration
Double radiant hotplate
700/2100W circuit 1 1 1 1
Double radiant hotplate
700/1700W circuit
Double radiant hotplate
1400/2000Wcircuit
2100W radianthotplate 1 1
1800Whalogen
radianthotplate
1800Wradiant hotplate 2 1 2 2
1500Wradiant hotplate 2
1200W radianthotplate 1 1 2 2 1
3kWrapid burner 1
1.75 kWsemi-rapid 1
burner
Electrics
Nominal Power
(W)for 230 V* 6.900 3.300 6.300 6.000 6.700 6.900
Supply
voltage (V) SEE THE APPLIANCE’S RATING PLATE
Frequency (Hz) 50-60 50-60 50-60 50-60 50-60 50-60
Gas
Power
Maximum (kW) 4,75
*Forvoltages other than 230 Vplease consult the appliance’srating plate
TR
641
65
600
510
560
490
61
1
2
1
50-60
6.200
