Tektronix 80E07 User manual

User Manual
80E07, 80E08, 80E09, and 80E10
Electrical Sampling Remote Modules
071-2038-01
This document applies to firmware version 2.5X
and above.
www.tektronix.com

Copyright ©Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries or
suppliers, and are protected by national copyright laws and international treaty provisions.
Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication supercedes
that in all previously published material. Specifications and price change privileges reserved.
TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.
Contacting Tektronix
Tektronix, Inc.
14200 SW Karl Braun Drive
P.O. Box 500
Beaverton, OR 97077
USA
For product information, sales, service, and technical support:
HIn North America, call 1-800-833-9200.
HWorldwide, visit www.tektronix.com to find contacts in your area.

Warranty 2
Tektronix warrants that this product will be free from defects in materials and workmanship for a period of one (1)
year from the date of shipment. If any such product proves defective during this warranty period, Tektronix, at its
option, either will repair the defective product without charge for parts and labor, or will provide a replacement in
exchange for the defective product. Parts, modules and replacement products used by Tektronix for warranty work
may be new or reconditioned to like new performance. All replaced parts, modules and products become the
property of Tektronix.
In order to obtain service under this warranty, Customer must notify Tektronix of the defect before the expiration
of the warranty period and make suitable arrangements for the performance of service. Customer shall be
responsible for packaging and shipping the defective product to the service center designated by Tektronix, with
shipping charges prepaid. Tektronix shall pay for the return of the product to Customer if the shipment is to a
location within the country in which the Tektronix service center is located. Customer shall be responsible for
paying all shipping charges, duties, taxes, and any other charges for products returned to any other locations.
This warranty shall not apply to any defect, failure or damage caused by improper use or improper or inadequate
maintenance and care. Tektronix shall not be obligated to furnish service under this warranty a) to repair damage
resulting from attempts by personnel other than Tektronix representatives to install, repair or service the product;
b) to repair damage resulting from improper use or connection to incompatible equipment; c) to repair any
damage or malfunction caused by the use of non-Tektronix supplies; or d) to service a product that has been
modified or integrated with other products when the effect of such modification or integration increases the time
or difficulty of servicing the product.
THIS WARRANTY IS GIVEN BY TEKTRONIX WITH RESPECT TO THE PRODUCT IN LIEU OF ANY
OTHER WARRANTIES, EXPRESS OR IMPLIED. TEKTRONIX AND ITS VENDORS DISCLAIM ANY
IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
TEKTRONIX’ RESPONSIBILITY TO REPAIR OR REPLACE DEFECTIVE PRODUCTS IS THE SOLE AND
EXCLUSIVE REMEDY PROVIDED TO THE CUSTOMER FOR BREACH OF THIS WARRANTY.
TEKTRONIX AND ITS VENDORS WILL NOT BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL,
OR CONSEQUENTIAL DAMAGES IRRESPECTIVE OF WHETHER TEKTRONIX OR THE VENDOR HAS
ADVANCE NOTICE OF THE POSSIBILITY OF SUCH DAMAGES.

80E07, 80E08, 80E09, and 80E10 User Manual i
Table of Contents
General Safety Summary v...................................
Environmental Considerations vii...............................
Preface ix...................................................
Manual Structure ix................................................
Related Manuals x.................................................
Getting Started 1............................................
Product Description 2..............................................
Accessories and Options 4...........................................
Standard Accessories 4..........................................
Optional Accessories 4..........................................
Options 5.....................................................
Installation 6.....................................................
Electrostatic Discharge 8........................................
Static Controlled Workstation 9...................................
Compensation 9...............................................
Operating Basics 11..........................................
Usage 11.........................................................
Controls 12........................................................
Signal Connector 12.............................................
Channel Selection 13............................................
TekProbe Connector 13..........................................
TDR On Indicator 13............................................
System Interaction 13...............................................
Commands From the Main Instrument Front Panel 14......................
Programmer Interface Commands 15...................................
User Adjustments 15................................................
Cleaning 16.......................................................
Reference 17.................................................
Taking TDR Measurements 17........................................
TDR Measurements Background 28....................................
Finding the Velocity of Propagation and Locating Mismatches 31.........
TDR Measurement Units 31.......................................
Making Accurate TDR Measurements 33............................
Taking Differential and Common-Mode TDR Measurements 33.............
Connector and Adapter Care Requirements 41...........................
Visual Inspection 41.............................................
Cleaning Connectors 42..........................................
Assembly and Torquing 44........................................
Detecting Damaged Inputs 46.........................................
EOS (Electrical Overstress) Prevention 46...............................
Specifications 49.............................................
Glossary 55.................................................
Index 57....................................................

Table of Contents
ii 80E07, 80E08, 80E09, and 80E10 User Manual
List of Figures
Figure 1: Sampling main module and remote module,
80E10 shown 2..........................................
Figure 2: Sampling module block diagram 3.....................
Figure 3: Sampling module compartments 6.....................
Figure 4: Guide rails 7.......................................
Figure 5: Sampling module, 80E10 shown 12.....................
Figure 6: Vertical Setup dialog box 14...........................
Figure 7: TDR Setup dialog box 15..............................
Figure 8: Simplified schematic diagram of step
generator - positive polarity 18..............................
Figure 9: Step generator with a shorted output 19.................
Figure 10: Step generation with a 50 Ωload 19....................
Figure 11: Step generation with an open circuit 19.................
Figure 12: TDR displays for typical loads 21......................
Figure 13: Microstrip discontinuities 28..........................
Figure 14: TDR waveform of microstrip in Figure 13 29............
Figure 15: TDR step and reflection (short) 30.....................
Figure 16: TDR step and reflection (50 Ωline terminated
in 75 Ω)32...............................................
Figure 17: TDR step of undamaged sampling module 46............
Figure 18: First example of EOS error 48........................
Figure 19: Second example of EOS error showing
cumulative effect 48.......................................

Table of Contents
80E07, 80E08, 80E09, and 80E10 User Manual iii
List of Tables
Table 1: Sampling module features 3...........................
Table 2: Standard accessories 4...............................
Table 3: Optional accessories 4................................
Table 4: Torque wrench information 45.........................
Table 5: Electrical sampling modules -- Signal acquisition 49.......
Table 6: Electrical sampling module -- TDR system
(80E08 and 80E10) 52.....................................
Table 7: Electrical sampling modules -- Timebase system 53........
Table 8: Electrical sampling modules -- Mechanical 53.............

Table of Contents
iv 80E07, 80E08, 80E09, and 80E10 User Manual

80E07, 80E08, 80E09, and 80E10 User Manual v
General Safety Summary
Review the following safety precautions to avoid injury and prevent damage to
this product or any products connected to it.
To avoid potential hazards, use this product only as specified.
Only qualified personnel should perform service procedures.
While using this product, you may need to access other parts of a larger system.
Read the safety sections of the other component manuals for warnings and
cautions related to operating the system.
Connect and Disconnect Properly. Do not connect or disconnect probes or test
leads while they are connected to a voltage source.
Ground the Product. This product is indirectly grounded through the grounding
conductor of the mainframe power cord. To avoid electric shock, the grounding
conductor must be connected to earth ground. Before making connections to the
input or output terminals of the product, ensure that the product is properly
grounded.
Observe All Terminal Ratings. To avoid fire or shock hazard, observe all ratings
and markings on the product. Consult the product manual for further ratings
information before making connections to the product.
Do not apply a potential to any terminal, including the common terminal, that
exceeds the maximum rating of that terminal.
Do Not Operate Without Covers. Do not operate this product with covers or panels
removed.
Do Not Operate With Suspected Failures. If you suspect there is damage to this
product, have it inspected by qualified service personnel.
Avoid Exposed Circuitry. Do not touch exposed connections and components
when power is present.
Wear Eye Protection. Wear eye protection if exposure to high-intensity rays or
laser radiation exists.
Do Not Operate in Wet/Damp Conditions.
Do Not Operate in an Explosive Atmosphere.
Keep Product Surfaces Clean and Dry.
ToAvoidFireor
Personal Injury

General Safety Summary
vi 80E07, 80E08, 80E09, and 80E10 User Manual
These terms may appear in this manual:
WARNING. Warning statements identify conditions or practices that could result
in injury or loss of life.
CAUTION. Caution statements identify conditions or practices that could result in
damage to this product or other property.
These terms may appear on the product:
HDANGER indicates an injury hazard immediately accessible as you read the
marking.
HWARNING indicates an injury hazard not immediately accessible as you
read the marking.
HCAUTION indicates a hazard to property including the product.
The following symbol(s) may appear on the product:
CAUTION
Refer to Manual
WARNING
High Voltage
Protective Ground
(Earth) Terminal
Terms in this Manual
Symbols and Terms
on the Product

80E07, 80E08, 80E09, and 80E10 User Manual vii
Environmental Considerations
This section provides information about the environmental impact of the
product.
Observe the following guidelines when recycling an instrument or component:
Equipment Recycling. Production of this equipment required the extraction and
use of natural resources. The equipment may contain substances that could be
harmful to the environment or human health if improperly handled at the
product’s end of life. In order to avoid release of such substances into the
environment and to reduce the use of natural resources, we encourage you to
recycle this product in an appropriate system that will ensure that most of the
materials are reused or recycled appropriately.
The symbol shown to the left indicates that this product
complies with the European Union’s requirements
according to Directive 2002/96/EC on waste electrical and
electronic equipment (WEEE). For information about
recycling options, check the Support/Service section of the
Tektronix Web site (www.tektronix.com).
This product has been classified as Monitoring and Control equipment, and is
outside the scope of the 2002/95/EC RoHS Directive. This product is known to
contain lead, cadmium, and hexavalent chromium.
Restriction of Hazardous
Substances

Environmental Considerations
viii 80E07, 80E08, 80E09, and 80E10 User Manual

80E07, 80E08, 80E09, and 80E10 User Manual ix
Preface
This is the user manual for the 80E07, 80E08, 80E09, and 80E10 remote
sampling modules. It covers the following information:
HDescription of the capabilities of the sampling modules and how to install
them
HExplanation of how to operate the sampling modules: how to control
acquisition, processing, and input/output of information
HList of the specifications of the sampling modules
You may want to visit the Tektronix Website at http://www.tektronix.com for the
latest revision of the user documentation. Select the Manuals link, then enter the
part number or product name to locate the document.
A printed version of this manual is also orderable (see Optional Accessories on
page 4).
NOTE. Using the 80E07, 80E08, 80E09, or 80E10 modules in a main instrument
that is not using product software version 2.5 or greater may cause the applica-
tiontofailtostart.
To display the version installed, select About from the Help menu of the main
instrument.
Manual Structure
This manual is composed of the following chapters:
HGetting Started shows you how to configure and install your sampling
module.
HOperating Basics describes controlling the sampling module using the front
panel and the instrument user interface.
HReference provides additional TDR information.
HSpecifications provide a list of guaranteed and typical specifications.

Preface
x80E07, 80E08, 80E09, and 80E10 User Manual
Related Manuals
For information of the main instrument in which the sampling module is used,
refer to the documents and online help provided with your main instrument. The
programming commands for these modules are listed in the programmer guide
for the main instrument.

80E07, 80E08, 80E09, and 80E10 User Manual 1
Getting Started
The Tektronix 80E07, 80E08, 80E09, and 80E10 remote sampling modules are
high-performance sampling modules that can be installed in the following
instruments:
HDSA8200 Digital Serial Analyzer
HCSA8000, CSA800B, and CSA8200 Communications Signal Analyzers
HTDS8000, TDS8000B, and TDS8200 Digital Sampling Oscilloscopes
Proper operation of the electrical sampling modules requires that product
software version 2.5 or greater be installed on the main instrument.
NOTE. The main instrument may not boot properly if an 80E07, 80E08, 80E09,
or 80E10 module is installed into a main instrument that is using product
software version 2.4 or earlier.
To display the version installed, select About from the Help menu of the main
instrument.
CAUTION. To prevent electrostatic damage to the instrument and sampling
modules, follow the precautions described in this manual and the manuals
accompanying your instrument. (See Electrostatic Discharge on page 8.)

Getting Started
280E07, 80E08, 80E09, and 80E10 User Manual
Product Description
The electrical sampling modules are high-bandwidth sampling acquisition
modules or sampling TDR modules suitable for use in a variety of test and
measurement applications and systems.
Key features include:
HTwo channels of mid-to-high bandwidth sampling acquisition.
HRemote channel modules are attached to the main unit through cables,
allowing placement of the sampler or sampler/TDR closer to the unit under
test.
HUser-selectable bandwidth.
HIndependent channel delay.
HDifferential and common-mode TDR with independently controllable
polarity and step deskew on each channel (80E08 and 80E10 modules only).
HFast TDR step speeds (80E08 and 80E10 modules only).
TDR
on indicator
(80E08, 80E10)
Cable to remote
module
Left channel Right channel
Hold-down screw
SELECT channel button TekProbe connector
Channel indicator
light
SELECT channel button
+
TDR on indicator
light
(80E08, 80E10)
Channel indicator
light
Figure 1: Sampling main module and remote module, 80E10 shown

Getting Started
80E07, 80E08, 80E09, and 80E10 User Manual 3
The sampling modules provide the features shown in Table 1.
Table 1: Sampling module features
Feature 80E07 80E08 80E09 80E10
Number of independent channels 2222
Number of TDR channels N.A. 2N.A. 2
Bandwidth 130 GHz 30 GHz 60 GHz 50 GHz
Selectable bandwidths 20 GHz, 30 GHz 20 GHz, 30 GHz 40 GHz, 30 GHz,
60 GHz
40 GHz, 30 GHz,
50 GHz
Vertical sensitivity, full scale 1 mV per div (min)
100 mV per div (max)
1 mV per div (min)
100 mV per div (max)
1 mV per div (min)
100 mV per div (max)
1 mV per div (min)
100 mV per div (max)
Signal connectors 2.92 mm (K) female 2.92 mm (K) female 1.85 mm (V) female 1.85 mm (V) female
1Refer to the specification section for complete details on risetime, bandwidth, and noise.
The 80E07, 80E08, 80E09, and 80E10 remote sampling modules have two
independent channels, each with its own acquisition circuitry.
The strobe drive signal from the instrument controls the timing of the strobe
assertion to each acquisition system. This guarantees sampling coincidence
between the two channels of a sampling module.
Sampler
Sampler
Strobe
Generator
Strobe drive
50 Ω
From main instrument
50 Ω
To main instrument
To main instrument
Figure 2: Sampling module block diagram

Getting Started
480E07, 80E08, 80E09, and 80E10 User Manual
Accessories and Options
This section lists the standard and optional accessories available for the sampling
modules, as well as the product options.
The accessories in Table 2 are shipped with the module. Visit the Tektronix web
site or a current Tektronix catalog for additions, changes, and details.
Table 2: Standard accessories
Item Part number
Certificate of Traceable Calibration for product at initial shipment Not Orderable
SMA male 50 Ωtermination with beaded chain (2, one per channel) 011-0176-xx
Guide rail kit (2 guide rails, 4 flathead 4--40 screws) 650-4986-xx
2.4 mm/1.85 mm S male to 2.92 mm K female adapters (2)
(80E09 and 80E10 only)
011-0157-xx
Transit case with anti-static foam 024-0053-xx
(MaxTek part number)
Product documentation CD-ROM (includes cd, instructions, cable
markers)
020-2543-xx
The accessories in Table 3 are orderable for use with the sampling module at the
time this manual was originally published. Visit the Tektronix Web site or a
current Tektronix catalog for additions, changes, and details.
Table 3: Optional accessories
Item Part number
2X attenuator (SMA male-to-female) 015-1001-xx
5X attenuator (male-to-female) 015-1002-xx
Power divider 015-0565-xx
SMA accessory kit 020-1693-xx
3.5maleto3.5femaleSMA 015-0552-xx
Slip-on SMA connector 015-0553-xx
3.5 mm 50 Ωconnector (SMA male-to-female) 015-0549-xx
BNC female 75 Ωto 50 Ωtype N minimum loss attenuator 131-0112-xx
Terminator, ECL 015-0558-xx
Standard Accessories
Optional Accessories

Getting Started
80E07, 80E08, 80E09, and 80E10 User Manual 5
Table 3: Optional accessories (cont.)
Item Part number
Connector saver, 3.5 mm SMA 015-0549-xx
80E07, 80E08, 80E09, and 80E10 Remote Sampling Module User
Manual (printed)
071-2038-xx
The following options can be ordered for the module:
HOption C3: Three years of calibration services
HOption C5: Five years of calibration services
HOption D3: Test Data for calibration services in Option C3
HOption D5: Test Data for calibration services in Option C5
HOption R3: Repair warranty extended to cover three years
HOption R5: Repair warranty extended to cover five years
Options

Getting Started
680E07, 80E08, 80E09, and 80E10 User Manual
Installation
The sampling modules fit into the front panel of any of the main instruments
listed Getting Started on page 1.
To install a module, first turn off the instrument using the front-panel On/Stand-
by switch. Then place the module in a compartment and slowly push it in with
firm pressure. Once seated, turn the hold-down screw to tighten the module into
place. See Figure 3.
CAUTION. To prevent damage to the module or instrument, never install or
remove a module when the instrument is on or when input connectors are
unprotected.
NOTE. When removing your sampling module, first loosen the hold-down screw,
and then use the module ejector on the main instrument to eject the module.
Large modules
Small modules Module ejectors
Hold-down screw
Figure 3: Sampling module compartments
At least one sampling module must be installed in an instrument to sample
signals.
