Tektronix AFG31000 Series Installation and maintenance instructions

AFG31000 Series Arbitrary Function Generator
Declassification and Security Instructions
www.tek.com
*P077149100*
077-149-100

Copyright © Tektronix. All rights reserved. Licensed software products are owned by
Tektronix or its subsidiaries or suppliers, and are protected by national copyright laws and
international treaty provisions.
Tektronix products are covered by U.S. and foreign patents, issued and pending. Information
in this publication supersedes that in all previously published material. Specifications and
price change privileges reserved.
TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.
Contacting Tektronix, Inc.
Tektronix, Inc.
14150 SW Karl Braun Drive
P.O. Box 500
Beaverton, OR 97077
USA
For product information, sales, service, and technical support:
-In North America, call 1-800-833-9200.
-Worldwide, visit www.tek.com (www.tek.com) to find contacts in your area.

AFG31000 Series Arbitrary Function Generator Declassification and Security Instructions iii
Preface.......................................................................................................................................5
Reference..............................................................................................................................................5
Charges.................................................................................................................................................5
Terms used in this document................................................................................................................6
Products................................................................................................................................................7
Clear or sanitize a non-functional instrument ........................................................................9
Clear or sanitize a non-functional instrument........................................................................................9
External memory devices......................................................................................................................9
Built-in security features........................................................................................................................9
Security feature functionality.................................................................................................................9
Memory devices......................................................................................................................11
Volatile memory devices.....................................................................................................................11
Nonvolative memory devices..............................................................................................................12
Clear user memory .................................................................................................................13
Nonvolatile clear procedures ..............................................................................................................13
Recover from nonvolatile clear or sanitize..........................................................................................13
Media and data export devices...........................................................................................................13
Table of Contents

AFG31000 Series Arbitrary Function Generator Declassification and Security Instructions 5
Reference
This document helps customers with data security concerns to sanitize or remove memory devices
from the Tektronix AFG31000 Series Arbitrary Function Generator.
These products have data storage (memory) devices and data output devices. These instructions tell
how to clear or sanitize the memory devices and disable the data output devices. The instructions
also tell how to declassify an instrument that is not functioning.
The procedures in this document are written to meet the requirements specified in:
NISPOM, DoD 5220.22–M, Chapter 8
ISFO Process Manual for Certification & Accreditation of Classified Systems under NISPOM
Charges
Replacement of any missing hardware will be charged according to the rate at the time of
replacement.
Preface

Preface
6 AFG31000 Series Arbitrary Function Generator Declassification and Security Instructions
Terms used in this document
The following terms are used when filling out the tables of volatile and nonvolatile memory devices for
your instrument.
Describe the types of data:
User data: Describes the information, such as waveforms or measurement data that are
stored in the device.
User settings: Describes the information, that you can change that is stored in the
instrument.
Both: Use this term when you are discussing user data and user settings that are stored.
None: Use this term if you are not storing any information.
Describe how you modify the data:
Directly: You can modify the data.
Indirectly: The instrument modifies the data.
The following terms may be used in this document:
Clear. This removes data on media/memory before reusing it in a secured area. All reusable
memory is cleared to deny access to previously stored information by standard means of
access.
Erase. This is equivalent to clear.
Instrument Declassification. A term that refers to procedures that must be undertaken
before an instrument can be removed from a secure environment. Declassification
procedures include memory sanitization and memory removal, and sometimes both.
Media storage/data export device. Any of several devices that can be used to store or
export data from the instrument, such as a USB port.
Nonvolatile memory. Data is retained when the instrument is powered off.
Power off. Some instruments have a "Standby" mode, in which power is still supplied to the
instrument. For the purpose of clearing data, putting the instrument in Standby mode does
not qualify as powering off. For these products, you will need to either press a rear-panel OFF
switch or remove the power source from the instrument.
Remove. This is a physical means to clear the data by removing the memory device from the
instrument.
Sanitize. This eradicates the data from media/memory so that the data cannot be recovered
by other means or technology. This is typically used when the device will be moved
(temporarily or permanently) from a secured area to a non-secured area.
Scrub. This is equivalent to sanitize.
User Accessible. User is able to directly retrieve the memory device contents.
User-modifiable. User can write to the memory device during normal instrument operation,
using the instrument interface or remote control.
Volatile memory. Data is lost when the instrument is powered off.

Preface
AFG31000 Series Arbitrary Function Generator Declassification and Security Instructions 7
Products
The Tektronix AFG31000 Series Arbitrary Function Generator is covered by this document.
List of products within the AFG31000 Series Arbitrary Function Generator
AFG31021
AFG31022, AFG31022GSA
AFG31051
AFG31052, AFG31052GSA
AFG31101
AFG31102, AFG31102GSA
AFG31151
AFG31152, AFG31152GSA
AFG31251
AFG31252, AFG31252GSA

AFG31000 Series Arbitrary Function Generator Declassification and Security Instructions 9
Clear or sanitize a non-functional instrument
To erase confidential data from the instrument, do the following:
1. Turn on the instrument and select Utility.
2. Select System.
3. Select Factory Default/Reset.
4. In the warning message that appears, select OK. A wait cursor appears and it takes several
minutes to complete the operation.
5. When the operation completes, the nonfunctional instrument is erased.
Refer to your company's internal policies regarding handling or disposal of the instrument. When
returning the instrument to Tektronix for repair, describe the initial problem with the product. Tektronix
will install replacement parts and then repair and return the instrument.
External memory devices
Remove any USB flash drives or external hard drives from the instrument.
Refer to your company's internal policies regarding handling or disposal of the external memory
device.
Built-in security features
The AFG31000 Series Arbitrary Function Generator is equipped with a built-in security feature.
Security feature functionality
To erase confidential data from the instrument, do the following:
1. Turn on the instrument and select Utility.
2. Select System.
3. Select Factory Default Reset.
4. In the warning message that appears, select OK.
This feature completes the following:
There is one file in the flash memory that stores all user settings files and saved waveforms.
When you select the Factory Default Reset, all of this data is erased.
Section 1
Clear or sanitize a non-functional instrument

AFG31000 Series Arbitrary Function Generator Declassification and Security Instructions 11
Volatile memory devices
Type and
minimum
size
Function Type of
user
info
stored
Backed
up by
battery?
Method of
modification Data Input method Location User accessible To clear
To sanitize
SDRAM
1Gbit cache User data No Indirectly Firmware operations CPU
board
U3310,U
3302
No Remove
power from
the
instrument
for at least
1 second.
Remove
power from
the
instrument
for at least
second.
FPGA
74K bits
SRAM
cache
User
data
No
Indirectly
Firmware
operations
CPU
board
U1401
No
Remove
power from
the
instrument
for at least
1 second.
Remove
power from
the
instrument
for at least
second.
Microcontr
oller
8K BYTES
SRAM
cache
User
data
No
Indirectly
Firmware
operations
FP board
U1
No
Remove
power from
the
instrument
for at least
1 second.
Remove
power from
the
instrument
for at least
second.
FPGA
16020K
bits SRAM
cache
User
data
No
Indirectly
Firmware
operations
SG board
U2001
U2002
No
Remove
power from
the
instrument
for at least
1 second.
Remove
power from
the
instrument
for at least
second.
DDR
256M
BYTES
SRAM
cache
User
data
No
Indirectly
Firmware
operations
SG board
U2401
U2501
U2602
U31 U32
U33
No
Remove
power from
the
instrument
for at least
1 second.
Remove
power from
the
instrument
for at least
second.
Section 2
Memory devices

Memory devices
12 AFG31000 Series Arbitrary Function Generator Declassification and Security Instructions
Nonvolative memory devices
Nonvolatile memory devices
Type and
minimum size Function Type of user info stored Method of modification Data Input method Location User accessible
Microcontroller
32 KB on chip
flash memory
Front panel
firmware
None
Indirectly
Firmware
operations
Front panel
board U1
No
FPGA 80 KB on
chip flash
memory
FPGA
binary code None Indirectly Firmware operations CPU board U1401 No
EMMC 4 GB CPU board
FW,
APP, HW
license key,
User data
Waveform, data. Directly Firmware
operations,
write, copy,
read from front
panel USB port
CPU board
U3401 yes

AFG31000 Series Arbitrary Function Generator Declassification and Security Instructions 13
Nonvolatile clear procedures
1. Turn on the instrument and select Utility.
2. Select System.
3. Select Factory Default Reset.
4. In the warning message that appears, select OK.
5. Wait a minimum of eight minutes.
NOTE: This procedure does not erase or change factory calibration constants.
Recover from nonvolatile clear or sanitize
1. Select Default (this is a key in Setup).
2. Select OK.
3. Wait for several seconds to recover to the default settings.
NOTE: This procedure does not erase or change factory calibration constants.
Media and data export devices
Type Function Method of
modification Data input method Location User accessible Process to disable.
Ethernet
connector
Transfer
data
directly Remote
control
Rear panel. Unable to
disabled
USB
Transfer
data
directly
Front/rear
panel
Unable to
disabled
Section 3
Clear user memory
