RSA7100A Real-Time Spectrum Analyzer
Application Programming Interface (API)
ZZZ
Programmer Manual
*P077149600*
077-1496-00

RSA7100A Real-Time Spectrum Analyzer
Application Programming Interface (API)
ZZZ
Programmer Manual
xx
www.tek.com
077-1496-00

Copyright © Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries or suppliers, and are
protected by national copyright laws and international treaty provisions.
Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication supersedes that in all
previously published material. Specifications and price change privileges reserved.
TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.
Contacting Tektronix
Tektronix, Inc.
14150 SW Karl Braun Drive
P.O. Box 500
Beaverton, OR 97077
USA
For product information, sales, service, and technical support:
In North America, call 1-800-833-9200.
Worldwide, visit www.tek.com to find contacts in your area.

Table of Contents
Table of Contents
Preface................................................................................................................................. ii
Function calls .......................................................................................................................... 1
Index
DRAFT—23 August 2018
RSA7100A API Programmer Manual i

Preface
Preface
In the typical API scenario, the custom user program calls functions from the API to fetch data. This is known as a “pull”
model. The user’s program must “pull” the data from the instrument. This is not the case with the RSA7100A IQFlow™
streaming API.
The RSA7100A IQFlow™ streaming API uses a “push” model to “push” the data to the user’s code by calling user supplied
callback functions. These callback functions have immediate access the latest acquired data and can then use it however
the user has programmed.
IQ data is structured as an array of 16-bit signed integer pairs and needs to be scaled by multiplying it with a scaling factor.
The AuxData structure returned by the USERDATA_GetAuxData() function contains this scaling factor.
DRAFT—23 August 2018
ii RSA7100A API Programmer Manual

Function calls
Function calls
dataCallbackFxn Type definition for the user’s data callback function. Called automatically by
the API when new data is available.
Declaration: dataCallbackFxn(IQDataPtr data, size_t size, size_t startOfBlockSample, bool
streamOverload, double sampleRate, double centerFreq);
Parameters:
data IQDataPtr structure. Provides the IQ pair data block.
size size_t of the IQ pair data block.
startofBlockSample size_t sample number of the first sample in the IQ data block.
streamOverload bool. True indicates an IQ data block was missed. False indicates no skipped
IQ data block.
sampleRate double of the sample rate for the current acquisition.
centerFreq double of the center frequency for the current acquisition.
triggerCallbackFxn Type definition for the user’s trigger callback function. Called automatically by
the API when the RSA is triggered.
Declaration: triggerCallbackFxn(size_t triggerSample);
Parameters:
Triggersample size_t of the sample number for the current trigger event.
USERDATA_Connect() Connects the user’s callback functions to the IQFlow™ streaming API.
Declaration: ReturnStatus USERDATA_Connect(size_t &dataSize, dataCallbackFxn
dCbFxn, triggerCallbackFxn tCbFxn);
Parameters:
dataSize size_t passed by reference. Sets the buffer size of the IQ pair data block. This
value is bound between 221 to 228.
dCbFxn dataCallbackFxn. Sets the user supplied callback function to be called by the
API each time a new data block is available. Can be set to null if real-time
IQ data is not required.
tCbFxn triggerCallbackFxn. Sets the user supplied callback function to be called by the
API each time a trigger event occurs. Can be set to null if trigger timestamp is
not required.
Return values:
noError The function completed successfully.
errorBufferTooSmall The buffer size specified is too small.
errorBufferTooLarge The buffer size specified is too large.
USERDATA_Disconnect() Disconnects the user’s callback functions from the SignalVu-PC streaming API.
Declaration: USERDATA_Disconnect();
Return values:
noError The function completed successfully.
DRAFT—23 August 2018
RSA7100A API Programmer Manual 1

Function calls
USERDATA_GetAuxData() Fetches a data structure containing metadata for the acquired data.
Declaration: ReturnStatus USERDATA_GetAuxData(AuxData &auxData);
Parameters:
AuxData structure defined as follows:
Float version Version of structure
bool skippedFrame: True indicates a skipped frame. False indicates no
skipped frame.
bool adcOverrange: True indicates adc over range occurred. False
indicates no adc overrange.
bool refFreqUnlock: —
bool ifPowerOverloadStartAcq; IF power overload occurred during instrument
initialization.
bool ifPowerOverloadRuntime; IF power overload occurred during run time.
bool dmaOverflow; True indicates dma overflow occurred. False
indicates no dma overflow.
bool gpsStatus; True indicates GPS is on. False indicates GPS is off.
double gpsLat; Returns GPS latitude if GPS status is true.
double gpsLong; Returns GPS longitude if GPS status is true.
double gpsAlt; Returns GPS altitude if GPS status is true.
bool validTimeRef; Time source used is valid.
uint64_t seconds; Returns time of IQ data block in seconds (based off
posix time) if GPS status is true.
uint64_t nSeconds; Nanosecond resolution of current IQ data block.
uint64_t timestamp; Returns the timestamp of the first IQ pair in data
block.
uint64_t timeRefTimestamp; Returns the current time reference source timestamp
associated with time.
double sampleRate; Returns the sample rate of the current acquisition.
double cf; Returns the center frequency of the current
acquisition.
double scalingFactor; Returns the scaling factor for the IQ data. Multiply
the signed 16-bit integer values by this to scale the
data factor.
Return Values:
noError: The function completed successfully.
errorInvalidShared-
Memory:
No data found in auxiliary data.
errorTimedOut: The function timed out.
errorNotConnected: The function had no valid connection to SignalVu-PC.
Additional Detail: GFRM_OFF (0) is returned when GNSS source is not selected.
DRAFT—23 August 2018
2RSA7100A API Programmer Manual

Function calls
USERDATA_GetData () Fetches the latest IQ data using a traditional pull method.
Declaration: ReturnStatus USERDATA_GetData(IQDataPtr data, size_t size, size_t
&startofBlockSample, bool &streamOverload, double &sampleRate, double
&centerFreq);
Parameters:
data IQDataPtr structure. Provides the IQ pair data block.
size size_t of the number of samples in the IQ pair data block.
startofBlockSample size_t sample number of the first sample in IQ data block.
streamOverload bool. True indicates an IQ data block was missed. False indicates no skipped
IQ data block.
sampleRate double of the sample rate for the current acquisition.
centerFreq double of the center frequency for the current acquisition.
Return values:
noError The function completed successfully.
errorBufferTooSmall The buffer size specified is too small.
errorBufferTooLarge The buffer size specified is too large.
USERDATA_FindData () Searches for the sample number passed to it in the API’s local circular buffer
and returns a data set containing the requested sample, if it can be found.
Declaration: ReturnStatus USERDATA_FindData(IQDataPtr data, size_t size, size_t
findSample, size_t &startofBlockSample, bool &sreamOverlaod, double
&sampleRate, double &centerFreq);
Parameters:
dataIQDataPtr structure. Provides the IQ pair data block.
sizesize_t of the number of samples in the IQ pair data block.
findSample —
startofBlockSample size_t sample number of the first sample in the IQ data block.
streamOverload bool. True indicates an IQ data block was missed. False indicates no skipped
IQ data block.
sampleRate double of the sample rate for the current acquisition.
centerFreq double of the center frequency for the current acquisition.
Return values:
noError The function completed successfully.
errorInvalidSize The function parameter size is 0.
errorInvalidDataRate The function parameter sampleRate is 0 or negative.
errorStaleTrigger The function failed to acquire the trigger since the data has already passed.
errorTimedOut The function timed out while looking for a trigger.
unknownError The function received an unknown error.
DRAFT—23 August 2018
RSA7100A API Programmer Manual 3

Function calls
DRAFT—23 August 2018
4RSA7100A API Programmer Manual
