Teledyne PS200 Series Manual

64171, Rev. 11/December 2019
WARNING: ALL INDIVIDUALS WHO HAVE OR WILL HAVE RESPONSIBILITY FOR
USING, MAINTAINING, OR SERVICING THIS PRODUCT MUST READ
THIS ENTIRE MANUAL CAREFULLY. FAILURE TO USE THIS
EQUIPMENT PROPERLY COULD RESULT IN SERIOUS INJURY OR
DEATH.
PORTABLE GAS MONITOR
OPERATIONS & MAINTENANCE MANUAL 64171, Rev. 11
PS200

64171, Rev. 11/December 2019
PS200
PORTABLE GAS MONITOR
OPERATIONS & MAINTENANCE MANUAL
ii
Copyright © Teledyne Gas Measurement Instruments Ltd, December 2019
REVISION HISTORY
Rev.
No. Revision Date Reason
10 May 2019 Reformatted and revised entire manual.
11 December 2019 Updated manual with Teledyne brand & logo throughout.

64171, Rev. 11/December 2019
PS200
PORTABLE GAS MONITOR
LEGAL STATEMENT
iii
LEGAL STATEMENT
Teledyne, the Teledyne Logo, Gas Measurement Instruments, GMI, and PS200 are registered
and/or unregistered marks of Teledyne Gas Measurement Instruments Ltd, also referred to as “the
Company.”
All rights reserved. No part of this documentation may be reproduced in any form or by any means
or used to make any derivative work (such as translation, transformation, or adaptation) without
written permission from the Company.
Microsoft, Windows, Windows 2000, Windows Me, Windows XP, Windows NT, Windows Vista,
Windows 7, Internet Explorer and MS-DOS are either trademarks or registered trademarks of Mic-
rosoft Corporation in the United States and other countries. Solaris and JAVA are either trademarks
or registered trademarks of Sun Microsystems, Inc. All other products or service names are the
property of their respective owners.
DESCRIPTION
This Operations & Maintenance (O&M) Manual provides information for use only with the PS200
Portable Gas Monitor (or “the monitor”).
LIABILITY
Every care has been taken in the preparation of this O&M manual, but the Company does not
accept any responsibility for errors or omissions and their consequences. Information in this O&M
manual is subject to change without notice. This O&M manual does not constitute a specification or
basis for a contract.
MODIFICATION NOTICES
The Company aims to notify customers of relevant changes in the product operation and maintain
this O&M manual up to date. Due to continuous product improvement, there may be operational
differences between the latest product and this O&M manual.
This O&M manual is an important part of the monitor, and it should be referred to for the life of the
product.
SOFTWARE
Any software supplied must only be used in this product and may not be copied without the written
permission of the Company. Reproduction or disassembly of such embodied programs or algo-
rithms is prohibited. Ownership of such software is not transferable, and the Company does not
warrant that the operation of the software will be error free or that the software will meet the cus-
tomer’s requirements.
DISPOSAL ADVICE
Dispose of the monitor carefully and with respect for the environment. the Company will dispose of
the monitor without charge if the monitor is returned to the Company .
AREAS OF USE
Exposure to certain chemicals can result in a loss of sensitivity of the flammable sensor. Where
such environments are known or suspected it is recommended that more frequent response
checks are carried out. Chemical compounds that can cause loss of sensitivity include silicones,
lead, halogens and sulphur.
Do not use the monitor in potentially hazardous atmospheres containing greater than 21% oxygen.

64171, Rev. 11/December 2019
PS200
PORTABLE GAS MONITOR
SPECIAL CONDITIONS OF USE
iv
SPECIAL CONDITIONS OF USE
The monitor is designed for use in harsh environments. The monitor is sealed to IP67 and, if not
subjected to misuse or malicious damage, will provide many years of reliable service.
The monitor may contain electrochemical sensors. Under conditions of prolonged storage, these
sensors should be removed. These sensors contain potentially corrosive liquid and care should be
taken when handling or disposing, particularly when a leak is suspected.

PS200
PORTABLE GAS MONITOR
TABLE OF CONTENTS
64171, Rev. 11/December 2019 v
TABLE OF CONTENTS
Sect. # Section Title Page #
1. ABOUT THIS GUIDE .................................................................................................... 1-1
1.1. Guide Conventions........................................................................................................ 1-1
1.2. Certifications and Approvals.......................................................................................... 1-2
1.3. General Safety Information ........................................................................................... 1-4
1.4. Additional Safety Details - CSA ONLY .......................................................................... 1-4
2. INTRODUCTION........................................................................................................... 2-1
2.1. General Description ...................................................................................................... 2-1
2.2. Features........................................................................................................................ 2-3
2.3. Datalogging................................................................................................................... 2-3
2.4. Filters ............................................................................................................................ 2-3
3. OPERATION ................................................................................................................. 3-1
3.1. Operating Procedure..................................................................................................... 3-1
3.2. Quick Configuration Display.......................................................................................... 3-2
3.3. Switching the Monitor On.............................................................................................. 3-2
3.4. Switch the Display Backlight On/Off.............................................................................. 3-7
3.5. View MAX/MIN/STEL/LTEL........................................................................................... 3-7
3.6. Manual Datalog............................................................................................................. 3-8
3.7. Alarms Reset or Acknowledge ...................................................................................... 3-8
3.8. Sample Line Connection and Use................................................................................. 3-8
3.9. Self Test ........................................................................................................................ 3-9
3.10 Switch the monitor OFF .............................................................................................. 3-10
4. ALARMS ....................................................................................................................... 4-1
4.1. Gas Alarms.................................................................................................................... 4-1
4.2. Acknowledge Gas Alarms ............................................................................................. 4-2
4.3. Mute Alarms .................................................................................................................. 4-2
4.4. High Flammable Gas Over-range Alarm ....................................................................... 4-2
5. WARNINGS & FAULTS................................................................................................. 5-1
5.1. Low Battery ................................................................................................................... 5-1
5.2. Bat Fault........................................................................................................................ 5-1
5.3. Zero Fault...................................................................................................................... 5-1
5.4. Sensor Faults................................................................................................................ 5-3
5.5. Flow Fault (Pumped Monitors Only).............................................................................. 5-3
5.6. Memory Fault ................................................................................................................ 5-4
5.7. Calibration Required ..................................................................................................... 5-4
6. MANUAL BUMP TEST OPTIONS................................................................................. 6-1
6.1. Bump Testing ................................................................................................................ 6-1
6.2. Initiating a Manual Bump Test ....................................................................................... 6-1
6.3. Applying Test Gas ......................................................................................................... 6-3

64171, Rev. 11/December 2019
vi
PS200
PORTABLE GAS MONITOR
TABLE OF CONTENTS
Sect. # Section Title Page #
6.4. Quick/Full Bump Test.....................................................................................................6-3
6.5. Confirm Alarms..............................................................................................................6-4
7. RECHARGING THE BATTERIES .................................................................................7-1
7.1. General..........................................................................................................................7-1
7.2. Recharge Monitor Using the Charging / Comms Clip....................................................7-1
8. OPERATOR MAINTENANCE .......................................................................................8-1
8.1. Cleaning ........................................................................................................................8-1
8.2. Replace Filters...............................................................................................................8-1
9. CALIBRATION ...............................................................................................................9-1
9.1. General Description.......................................................................................................9-1
9.2. Quick Calibration ...........................................................................................................9-2
9.3. Calibration Validity .........................................................................................................9-4
10. ACCESSORIES* .........................................................................................................10-1
A. OPERATING PARAMETERS & SENSOR TYPES....................................................... A-1
A.1. Typical Operating Parameters...................................................................................... A-1
A.2. LEL Sensor Types ........................................................................................................ A-2
B. TECHNICAL SUPPORT ............................................................................................... B-1

PS200
PORTABLE GAS MONITOR
LIST OF FIGURES
64171, Rev. 11/December 2019 vii
LIST OF FIGURES
Fig. # Figure Title Page #
2-1 PS200 Portable Gas Detector....................................................................................... 2-1
2-2 Display Example (4-Gas) .............................................................................................. 2-2
2-3 Display Examples.......................................................................................................... 2-2
2-4 OK Display Example (4-Gas)........................................................................................ 2-2
3-1 Function Buttons ........................................................................................................... 3-1
3-2 Quick Configuration Display.......................................................................................... 3-2
3-3 Flash Screen................................................................................................................. 3-3
3-4 Monitor Identification Display ........................................................................................ 3-3
3-5 User Name.................................................................................................................... 3-3
3-6 Date and Time............................................................................................................... 3-4
3-7 Bump Due Date............................................................................................................. 3-4
3-8 Bump Overdue.............................................................................................................. 3-4
3-9 Calibration Due Date..................................................................................................... 3-5
3-10 Service Due Date.......................................................................................................... 3-5
3-11 Cal Gas Selection ......................................................................................................... 3-6
3-12 Sensor Check Displays................................................................................................. 3-6
3-13 4-Gas Normal Operating Display .................................................................................. 3-7
3-14 MAX/MIN/STEL/LTEL Gas Values ................................................................................ 3-7
3-15 Manual Datalog............................................................................................................. 3-8
3-16 Sample Line Connection............................................................................................... 3-9
3-17 Pump Symbol................................................................................................................ 3-9
3-18 Self Test ...................................................................................................................... 3-10
3-19 Switch OFF ................................................................................................................. 3-10
4-1 O2 LOLO Alarm ............................................................................................................. 4-1
4-2 LEL HIHI Alarm ............................................................................................................. 4-2
4-3 Over Range Alarm......................................................................................................... 4-3
4-4 GET OUT/HIGH GAS Timer.......................................................................................... 4-3
5-1 LOW BATTERY Warning .............................................................................................. 5-1
5-2 BAT FAULT Warning ..................................................................................................... 5-1
5-3 LEL ZERO Fail .............................................................................................................. 5-2
5-4 LEL ZERO FAULT......................................................................................................... 5-2
5-5 ZERO FAULT – Switch OFF ......................................................................................... 5-2
5-6 LEL SENSOR FAULT.................................................................................................... 5-3
5-7 CO/H2S SENSOR FAULT ............................................................................................. 5-3
5-8 FLOW FAULT................................................................................................................ 5-4
5-9 Memory Fault ................................................................................................................ 5-4
5-10 Calibration Overdue ...................................................................................................... 5-4
5-11 CAL EXPIRED .............................................................................................................. 5-5

64171, Rev. 11/December 2019
viii
PS200
PORTABLE GAS MONITOR
LIST OF FIGURES
Fig. # Figure Title Page #
5-12 Calibration Required......................................................................................................5-5
6-1 BUMP TEST Confirmation Screen ................................................................................6-1
6-2 Apply Gas Screen (4-Gas Model)..................................................................................6-2
6-3 Regulator Valve Choice.................................................................................................6-2
6-4 Bump Test Kit ................................................................................................................6-3
6-5 Confirm Alarms..............................................................................................................6-4
6-6 Bump Test Pass.............................................................................................................6-4
6-7 Confirm Alarms - Fail.....................................................................................................6-4
6-8 Bump Test Fail - Switch Monitor OFF............................................................................6-5
7-1 Charging / Comms Clip Connection ..............................................................................7-1
7-2 Connect Cable to Charging / Comms Clip.....................................................................7-2
7-3 Connect Cable to USB Power Adapter..........................................................................7-2
8-1 Hydrophobic Filter Replacement ...................................................................................8-1
8-2 Sample Inlet (Dust) Filter Replacement.........................................................................8-2
9-1 PS200 Auto/Bump Calibration Station...........................................................................9-1
9-2 ZERO CALIBRATION Screen .......................................................................................9-2
9-3 SPAN CALIBRATION Screen........................................................................................9-2
9-4 APPLY GAS Screen ......................................................................................................9-3
9-5 APPLY GAS Screen ......................................................................................................9-3
9-6 CAL COMPLETE/SAVE RESULTS Screen...................................................................9-3

PS200
PORTABLE GAS MONITOR
LIST OF TABLES
64171, Rev. 11/December 2019 ix
LIST OF TABLES
Table # Table Title Page #
1-1 Certifications and Approvals.......................................................................................... 1-2
10-1 Supplied Accessories.................................................................................................. 10-1
10-2 Optional Accessories................................................................................................... 10-1
10-3 Charging Accessories ................................................................................................. 10-1
10-4 Manual Bump & Field Calibration Kit .......................................................................... 10-1
10-5 Automatic Bump & Calibration Accessory (ABC)........................................................ 10-2
A-1 Typical Operating Parameters.......................................................................................A-1
A-2 LEL Sensor Types.........................................................................................................A-2

64171, Rev. 11/December 2019
x
PS200
PORTABLE GAS MONITOR
LIST OF TABLES
This page is intentionally left blank.

PS200
PORTABLE GAS MONITOR
ABOUT THIS GUIDE
64171, Rev. 11/December 2019 1-1
1. ABOUT THIS GUIDE
This guide instructs gas detection personnel on the features and usage of the PS200 Portable Gas
Monitor (or “the monitor”), including information on operation, configuration, maintenance, specifi-
cations and troubleshooting.
This user guide assumes the reader has a basic knowledge of gas detection procedures.
The user guide is divided into the following topics:
•2. INTRODUCTION
•3. OPERATION
•4. ALARMS
•5. WARNINGS & FAULTS
•6. MANUAL BUMP TEST OPTIONS
•7. RECHARGING THE BATTERIES
•8. OPERATOR MAINTENANCE
•9. CALIBRATION
•10. ACCESSORIES*
•APPENDIX A. OPERATING PARAMETERS & SENSOR TYPES
•APPENDIX B. TECHNICAL SUPPORT
1.1. Guide Conventions
The following visual elements are used throughout this guide, where applicable:
WARNING: THIS ICON AND TEXT INDICATE A POTENTIALLY HAZARDOUS
SITUATION, WHICH, IF NOT AVOIDED, COULD RESULT IN DEATH OR
INJURY.
CAUTION: This icon and text indicate an action or situation, which, if not avoided,
could result in damage to the equipment.
NOTE: This icon and text designates information of special note.
WARNING: READ, UNDERSTAND AND FOLLOW THE ENTIRE CONTENT OF THIS
GUIDE PRIOR TO USE. FAILURE TO DO SO MAY RESULT IN SERIOUS
INJURY OR DEATH.

PS200
PORTABLE GAS MONITOR
ABOUT THIS GUIDE
64171, Rev. 11/December 2019
1-2
1.2. Certifications and Approvals
The monitor has the following approvals available:
Table 1-1: Certifications and Approvals
Mark
ATEX II 2G Ex ia d IIC T4 Gb (Ta = -20ºC to +50ºC)
IECEx Ex ia d IIC T4 Gb (Ta = -20ºC to +50ºC) or
ATEX II 1G Ex ia IIC T4 Ga (Ta = -20ºC to +50ºC)
IECEx Ex ia IIC T4 Ga (Ta = -20ºC to +50ºC)
(when fitted with the SGX VQ548MP sensor)
Combustible Instruments:
Class I, Div.1 Groups A, B, C and D T4
Class I, Zone 1 AEx ia d IIC T4 Gb Ex ia d IIC T4 Gb
or
Class I, Div.1 Groups C and D T4
Class I, Zone 0 AEx ia IIB T4 Ga Ex ia IIB T4 Ga
(when fitted with the SGX VQ548MP sensor)
Non-combustible Instruments:
Class I, Div.1 Groups A, B, C and D T4
Class I, Zone 0 AEx ia IIC T4 Ga Ex ia IIC T4 Ga
MED (Marine Equipment Directive) - A.1 / 3.30 (Module B&E)
European Mark of Conformity
ATENÇÃO: NÃO RECARREGAR
EM AREA CLASSIFICADA
DNV 16.0082 XU
14-AV4BO-0010
Ex ia d IIC T4 Gb (Ta = -20ºC to +50ºC)
IECEx SIR11.0019

PS200
PORTABLE GAS MONITOR
ABOUT THIS GUIDE
64171, Rev. 11/December 2019 1-3
1.2.1. LABEL
Always refer to the rear label for the actual certification of your monitor (see Figure 1-1: Identifica-
tion Label).
Figure 1-1: Identification Label
The label also lists the monitor’s serial number, e.g. 241000.
1.2.2. PERFORMANCE
This monitor complies with:
EN60079-29-1 (Flammable)*
IEC60079-29-1 (Flammable)*
EN50104:2010 (Oxygen)** – Marine instruments.
ANSI / ISA S12.13.01 – 2000 (Combustible)*
C22.2 No.152 – M1984 (Combustible)*.
* excludes IR sensor option.
** 2yr O2 sensor only
TP TC 012/2011
TP TC 020/2
Table 1-1: Certifications and Approvals
Mark

PS200
PORTABLE GAS MONITOR
ABOUT THIS GUIDE
64171, Rev. 11/December 2019
1-4
1.3. General Safety Information
The Company takes no responsibility for use of its equipment if it is not used in accordance with
these instructions. If further operational or maintenance details are required but not provided in this
guide, contact the Company or their agent. The Company shall not be liable for any incidental or
consequential damages in connection with any modifications, errors or omissions in this guide.
Always observe the latest pertinent state, regional, and local safety regulations when using and dis-
posing of the monitor. For reasons of safety and to assure regulatory compliance, only the manu-
facturer should perform repairs.
Fully trained personnel must regularly service and calibrate the monitor in a safe area.
Only use replacement parts approved by the Company.
Re-charge the monitor only in a safe area (refer to Section 7. RECHARGING THE BATTERIES).
If the monitor detects gas, follow your organization’s procedures and operational guidelines.
Any right of claim relating to product liability or consequential damage to any third party against the
Company is removed if the above warnings are not observed.
1.4. Additional Safety Details - CSA ONLY
WARNING: ALL INDIVIDUALS WHO HAVE OR WILL HAVE RESPONSIBILITY FOR
USING OR TESTING THIS PRODUCT MUST READ AND UNDERSTAND
THE CONTENTS OF THIS MANUAL. THE PRODUCT WILL PERFORM AS
DESIGNED ONLY IF USED AND TESTED IN ACCORDANCE WITH THE
MANUFACTURER'S INSTRUCTIONS. FAILURE TO FOLLOW
MANUFACTURER'S INSTRUCTIONS WILL RENDER THE WARRANTY
AND APPROVALS NULL AND VOID. FAILURE TO FOLLOW THESE
INSTRUCTIONS MAY ALSO RESULT IN SERIOUS INJURY OR DEATH.
CAUTION: BEFORE EACH DAYS USAGE, TEST ON A KNOWN CONCENTRATION OF
METHANE, EQUIVALENT TO 25% – 50% OF FULL-SCALE
CONCENTRATION. ACCURACY MUST BE WITHIN 0 TO +20% OF
ACTUAL. ACCURACY MAY BE CORRECTED BY CALIBRATION (REFER
TO Section 9. CALIBRATION.
ATTENTION: AVANT CHAQUE UTILISATION JOURNALIÈRE, TESTEZ LA RÉACTION
DE L’APPAREIL EN UTILISANT UNE CONCENTRATION CONNUE EN
MÉTHANE, CORRESPONDANT À 25% – 50% DE LA VALEUR RÉELLE.
LA PRÉCISION DOIT SE SITUER ENTRE 0 ET + 20% DE LA VALEUR
RÉELLE. LA PRÉCISION PEUT SE CORRIGER EN ÉTALONNANT
L’APPAREIL (VOIR Section 9. CALIBRATION).
CAUTION: ANY RAPID UP-SCALE READINGS FOLLOWED BY A DECLINING OR
ERRATIC READING MAY INDICATE A GAS CONCENTRATION BEYOND
THE UPPER SCALE LIMIT, WHICH MAY BE HAZARDOUS.

PS200
PORTABLE GAS MONITOR
ABOUT THIS GUIDE
64171, Rev. 11/December 2019 1-5
ATTENTION: TOUT LECTURE DÈPASSANT RAPIDEMENT LE MAXIMUM DE
L’ÊCHELLE ET SUIVIE PAR UNE DIMINUTION OU UNE LECTURE
ERRONÉE, INDIQUE UNE CONCETRATION DE GAZ SUPÉRIEURE À
LA VALEUR MAXIMALE DE CETTE ÉCHELLE. CETTE LECTURE N’EST
PASSIGNIFICATIVE.
CAUTION: SUBSTITUTION OF COMPONENTS MAY IMPAIR INTRINSIC SAFETY.
ATTENTION: LE REPLACEMENT D’UN COMPOSANT PEUT PORTER ATTEINT À LA
SÉCURITÉ INTRINSÈQUE DE PRODUIT.
CAUTION: DO NOT CHARGE IN A HAZARDOUS AREA. Um = 6V.
ATTENTION: NE PAS CHARGER EN ZONE DANGEREUSE. UM = 6V.
NOTE: CSA have only assessed the LEL combustible gas detection portion of this monitor
for performance.
NOTE: CSA a seulement évalué la partie LIE pour la mesure des performances en détec-
tion de gaz inflammables.

PS200
PORTABLE GAS MONITOR
ABOUT THIS GUIDE
64171, Rev. 11/December 2019
1-6
This page is intentionally left blank.

PS200
PORTABLE GAS MONITOR
INTRODUCTION
64171, Rev. 11/December 2019 2-1
2. INTRODUCTION
2.1. General Description
The PS200 Portable Gas Monitor series combines quality, ruggedness and advanced technology in
a user friendly, portable gas detector. It is compact, lightweight, water resistant, extremely robust,
and is suitably certified to recognized International Standards.
The monitor is suitable for wide range of personal monitoring and confined space applications. If
gas levels exceed configured threshold limits, or if the monitor develops a fault, users will be
alerted by audible, visible, and vibratory alarms.
The monitor is available as either a pumped or diffusion model and is powered by a fast-charging
internal Li-ion (lithium ion) battery.
The monitor is simple to use and is operated via two buttons (refer to Figure 2-1: PS200 Portable
Gas Detector).
Figure 2-1: PS200 Portable Gas Detector
The monitor can detect up to 4 of the following gases simultaneously:
• LEL Hydrocarbons
• Oxygen (O2)
• Carbon Monoxide (CO)

PS200
PORTABLE GAS MONITOR
INTRODUCTION
64171, Rev. 11/December 2019
2-2
• Hydrogen Sulphide (H2S)
All gases being monitored are displayed. A 4-gas monitor display is illustrated in Figure 2-2: Dis-
play Example (4-Gas).
Figure 2-2: Display Example (4-Gas)
Figure 2-3: Display Examples
Instead of displaying current gas readings, the monitor can be configured to display OK, as illus-
trated in Figure 2-4: OK Display Example (4-Gas).
Figure 2-4: OK Display Example (4-Gas)
NOTE: Character size increases if fewer sensors are configured, as illustrated in
Figure 2-3: Display Examples.
NOTE: This manual describes the operation of a default 4-gas monitor. Configurable
options are available and are detailed in italic text, where applicable.

PS200
PORTABLE GAS MONITOR
INTRODUCTION
64171, Rev. 11/December 2019 2-3
2.2. Features
• Compact, lightweight and robust.
• Measurement and display of up to 4 gases.
• Simple 2 button operation.
• Audible, visual (hi-viz) flashing LED’s and vibrating alarms.
• Audible and visual confidence signal (configurable), confirming monitor operation to the user.
• Green display during normal operation and red during alarm condition.
• Internal pump (optional).
• Manual and automatic data logging.
• Internal Li-Ion (Lithium Ion) rechargeable battery.
• Maximum recharge time of 4 hours.
• Robust clip to allow fitting to belt, pocket, etc.
• Communications interface to allow downloading of stored data.
• Fully certified to international standards.
• Comprehensive range of accessories .
• Quick Configuration Display allows the configuration to be viewed without fully switching the
monitor ON.
Typical operating parameters are detailed in Section APPENDIX A. OPERATING PARAMETERS &
SENSOR TYPES of this manual.
2.3. Datalogging
Datalogging allows gas measurements, event logs, bump tests, and calibration details to be stored
for downloading to a PC / Laptop via a USB connection. Typically, the monitor can store up to 6
months of data (refer to Section APPENDIX A. OPERATING PARAMETERS & SENSOR TYPES).
2.3.1. ACCESSING LOGGED DATA
Download data from the monitor to a PC/Laptop using the standard charging / comms cable and
additional software. Contact Technical Support (refer to Section B. TECHNICAL SUPPORT) for fur-
ther details.
2.4. Filters
Filters protect the monitor from water and dust ingress. Check filters regularly and replace as nec-
essary (refer to Section 8.2. Replace Filters).

PS200
PORTABLE GAS MONITOR
INTRODUCTION
64171, Rev. 11/December 2019
2-4
This page is intentionally left blank.
