Teletek electronics CA824 User manual

User Manual
CA824
Alarm System
CA824CA824
Alarm System

CA824 Alarm System
User Manual
May 2003
Disclaimer:
The manufacturer reserves the right to change the specifications of the equipment
described in this manual without notice
This document contains information proprietary to the manufacturer. No part of this
publication may be reproduced, photocopied, stored on a retrieval system or
transmitted, without prior written permission of the manufacturer.
While every effort has been made to ensure that the information in this manual is
accurate and complete, no liability can be accepted for any errors or omissions

CA824 Alarm System User Manual 3
Contents:
GENERAL INFORMATION 4
Limited Warranty 4
Warnings 4
DESCRIPTION 5
Overview 5
LCD Keyboard 5
Sound indication 5
LED Indication 6
LCD Display 6
Keypad 7
OPERATION 9
Arming 9
Full Arming 9
Stay Arming 9
Force Arming 9
Instant Arming 9
Disarming 17
Troubles Review 18
Event Memory Review 19
Bypassing 22
Programming 23
User Codes 23
User Limitations 24
Changing own user code 25
Changing User Names, Codes, Permissions and Attributes by a Manager 27
Adding and Setting a Proxy Card 32
Removing a Proxy Card 35
Date and Time Setting 37
Chime Switching 38
Display Setting 39
Private Display 41
Changing the logo 43
Stopping the Alarm and Clearing the Memory Indication 45
Special Key Combinations 46
APPENDIX 47
Service Messages on the LCD 47
Complete Menu Map 48

4 CA824 Alarm System User Manual
General Information
Limited Warranty
The manufacturer warrants that for period of 12 months from the date of purchase,
the product shall be free of defects in material and workmanship under normal use
and that in fulfillment of any breach of such warranty, the manufacturer shall, at its
opinion, repair or replace the defective equipment upon return of the equipment to its
factory. This warranty applies only to defects in parts and workmanship and not to
damage incurred in shipping or handling, or damage due to causes beyond the
control of the manufacturer such as lightning, excessive voltage, mechanical shock,
or damage arising out of abuse, alternation or improper application of the equipment.
The foregoing warranty shall apply only to the original buyer, and is and shall be in
lieu of any and all other warranties, whether expressed or implied and of all other
obligations or liabilities on the part of the manufacturer. This warranty contains the
entire warranty. The manufacturer neither assumes, nor authorizes any other
warranty or liability concerning this product.
In no event shall the manufacturer be liable for any direct or indirect or consequential
damage, loss of anticipated profits, loss of time or any other losses incurred by the
buyer in connection with the purchase, installation or operation or failure of this
product.
The manufacturer recommends that the entire system be completely tested on a
regular basis. However, despite frequent testing, and due to, but not limited to,
criminal tampering or electrical disruption, it is possible for this product to fail to
perform as expected.
Warnings
Before using the CA824, please ensure that you have read and understood the
following instructions. Always ensure that the CA824 is operated correctly.
Do not attempt to disassemble or alter any part of the equipment that is not expressly
described in this guide. Internal inspections, alterations and repairs should be
conducted by qualified service personnel only.
Do not use substances containing alcohol, benzene, thinners or other flammable
substances to clean or maintain the equipment. The use of these substances may
lead to fire.
Do not allow liquids to enter the interior. The equipment is not waterproof.

CA824 Alarm System User Manual 5
Description
Overview
This manual provides information for the daily operation of the CA824 Alarm System.
CA824 is modular system that can be split in up to eight areas and supports up to 31
separate user codes.
The CA824 Alarm System is operated through a keyboard with an LED and/or an
LCD indication.
LCD Keyboard
2
5
8
0
CLR ENT
PRG
ARM
BPS
TRBL
MEM
13
46
79
DISARM
Keypad
LCD display
LED indication
Keypad door
(opened)
Figure 1. LCD Keyboard Front View
Sound indication
There are eight different sound combinations that indicate seven different conditions:

6 CA824 Alarm System User Manual
Symbol Description

Click Single short beep indicating button pressing

Confirm
One long and three short beeps indicating the system
confirmation to executed operation (arming, disarming,
settings change, etc.)

Reject Single long beep indicating incorrectly executed operation

Entrance
time
Continuous sound indicating intrusion into the entrance
zones

Exit time
Short beeps indicating the system is armed and the user is
required to leave the zone. Ten seconds before the exit time
is over beeps frequency is increased.

Trouble Two short beeps indicating problem with the system (battery
low, no supply voltage, etc.)

Chime Chime-like sound beeps indicating intrusion into a zone with
a “Chime“ option activated (usually the entrance door)

Alarm
LED Indication
LED Indication description
Mains Power Supply LED (Green). Lit at 220V mains power supply.
Trouble LED (Yellow). Lit at system trouble.
The trouble type is displayed in the troubles list.
Alarm LED (Red). Lit at system alarm status or alarm memory.
Fire alarm LED (Red). Lit at system fire alarm status or fire alarm memory
Service LED (Red). Lit at system programming by service technician.
LCD Display
The keyboard is equipped with a 2-row 16-colomn matrix LCD providing different
system trouble and event memory alpha-numerical messages.

CA824 Alarm System User Manual 7
TeleTek CA824
Wed. 09/05 11:52
Figure 2. LCD
Keypad
2
5
8
0
CLR ENT
PRG
ARM
BPS
TRBL
MEM
13
46
79
DISARM
Figure 3. Keypad
Ke
y
A
ction Ke
y
A
ction
ARM
Arms the system
CLR
Clears entered data or transfers
to a higher menu level
DISARM
Disarms the system
ENT
Confirms entered data or
transfers to a lower menu level
BPS
Bypasses certain
zone(s)
Scrolls right the cursor in a field
or scrolls to the next menu item in
the same level
TRBL
Reviews the system
troubles
Scrolls left the cursor in a field or
scrolls to the previous menu item
in the same level
MEM
Reviews the event
memory Enters user codes or other data

8 CA824 Alarm System User Manual
Ke
y
A
ction Ke
y
A
ction
PRG
Activates the
programming mode
2
5
8
0
13
46
79
The key pad can be used to enter also Latin and Cyrillic letters and special symbols.
See the table bellow for the correspondence between the number of the pressings of
a certain key and the character displayed on the LCD:
Number of pressings
Key 1 2 3 4 5 6 7 8
0
0.,:!<>
1
1-=+$%@/
2
2ABCÁÂÃÄ
3
3DEFÆÇÈÉ
4
4GHIÊËÌÍ
5
5JKLÎÏÐÑ
6
6MNOÒÓÔÕ
7
7PQRSÖ×Ø
8
8TUVÙÚÜÛ
9
9WXYZÝÞß

CA824 Alarm System User Manual 9
Operation
Arming
Full Arming
Full arming means all zones are secured. Anyone coming into the entrance zone is
required to enter a code. Otherwise the alarm is started after the entrance time is
over.
After the arming procedure is completed, short beeps indicate the exit time and the
user is required to leave the zone. Ten seconds before the exit time is over beeps
frequency is increased.
There are three methods to Full arm the system:
Method1
This is a standard method, applied when the user has the permission to arm the
system in more than one of the four ways (Full, Stay, Force and Instant).
The arming sequence is described by Figure 4 on Page 11.
Method 2
This method is applied when the user is permitted to only Full arm the system.
The arming sequence is described by Figure 5 on Page 12.
Method 3
This fast method is applied when a certain area can be armed without entering a user
code. The only possible way to arm the system is Full.
The arming sequence is described by Figure 6 on Page 13.
Stay Arming
Stay arming means the user is allowed to stay in certain zone(s), but the entrance
zone is secured.
Anyone coming into an Entry zone is required to enter a code. Otherwise the alarm is
started after the entrance time is over.
The arming sequence is described by Figure 7 on Page 14.
Force Arming
Force arming means the system is armed despite that in certain zone(s) there may
be a presence or a trouble. All such zones will be bypassed automatically at the
system arming, if they are allowed.
The arming sequence is described by Figure 8 on Page 15.
Instant Arming
Instant arming means the user is allowed to stay in certain zone(s) marked as Stay
zones, but the entrance zone is secured.

10 CA824 Alarm System User Manual
The Entry zones are armed immediately (without exit time). The difference with the
Stay arming is that the Entry zones are armed immediately (without exit time) and an
intrusion into the Entry zones immediately starts the alarm.
The arming sequence is described by Figure 9 on Page 16.
In the following figures:
XX stays for the area number
ZZ stays for the zone number
Sstays for the respective area status. It can be:
-– the area is not armed and is in normal state
+– the area is not armed and has an active zone
f– the area is Full armed
p– the area is Stay armed
s– the area is Instant armed
o– exit time is running out
M– the area is Stay armed
A– the area is in an Alarm state
F– the area is in an Fire alarm state
– the area is not supported by the respective keyboard or not used

CA824 Alarm System User Manual 11
User Menu
ARMing
User
code
ARM
CA824
Wed. 09/05 11:52
ARMing
3)Full arming
3)Full arming
A. XX S AreaXX
3
CA824
Access denied
3)Full arming
Access denied
3)Full arming
Access denied
A. XX - AreaXX
armed
ENT
Area
No or
2
1
1
2
3
3
3
3
A. XX - AreaXX
armed
2 5
Invalid user code entered
User is not permitted to arm the system
User is not permitted to Full arm the system
User is permitted to operate one area only
and the keyboard supports this area
or the keyboard supports one area only
and the user is permitted to operate this area
5
Area is not ready to be
armed (open zones)
A. XX S AreaXX
Area isn’t ready
A. XX S AreaXX
ZZ ZoneZZ
Open zones are
listed
User is not permitted
to operate the area
A. XX S AreaXX
Access denied
A. XX S AreaXX
First disarm
T area ishe already
armed
or or
6
Figure 4. Full Arming Method 1

12 CA824 Alarm System User Manual
User Menu
ARMing
User
code
ARM
CA824
Wed. 09/05 11:52
3)Full arming
A. XX S AreaXX
CA824
Access denied
3)Full arming
Access denied
2
1
3
3
A. XX - AreaXX
armed
2 5
Invalid user code entered
User is not permitted to arm the system
User is permitted to operate one area only
and the keyboard supports this area
or the keyboard supports one area only
and the user is permitted to operate this area
A. XX - AreaXX
armed
ENT
Area
No or
2
3
5
Area is not ready to be
armed (open zones)
A. XX S AreaXX
Area isn’t ready
A. XX S AreaXX
ZZ ZoneZZ
Open zones are
listed
User is not permitted
to operate the area
A. XX S AreaXX
Access denied
A. XX S AreaXX
First disarm
T area ishe already
armed
or or
6
Figure 5. Full Arming Method 2

CA824 Alarm System User Manual 13
ARM
CA824
Wed. 09/05 11:52
3)Full arming
A. XX S AreaXX
1
A. XX - AreaXX
armed
2 5
The keyboard supports one area only
A. XX - AreaXX
armed
ENT
Area
No or
2
3
5
Area is not ready to be
armed (open zones)
A. XX S AreaXX
Area isn’t ready
A. XX S AreaXX
ZZ ZoneZZ
Open zones are
listed
User is not permitted
to operate the area
A. XX S AreaXX
Access denied
A. XX S AreaXX
First disarm
T area ishe already
armed
or or
6
Figure 6. Full Arming Method 3

14 CA824 Alarm System User Manual
User Menu
ARMing
User
code
ARM
CA824
Wed. 09/05 11:52
ARMing
3)Full arming
4)Stay arming
A. XX S AreaXX
CA824
Access denied
3)Full arming
Access denied
4)Stay arming
Access denied
2
1
1
3
3
3
A. XX - AreaXX
armed
2 5
Invalid user code entered
User is not permitted to arm the system
User is not permitted to Stay arm the system
User is permitted to operate one area only
and the keyboard supports this area
or the keyboard supports one area only
and the user is permitted to operate this area
4
A. XX - AreaXX
armed
ENT
Area
No or
2
3
5
Area is not ready to be
armed (open zones)
A. XX S AreaXX
Area isn’t ready
A. XX S AreaXX
ZZ ZoneZZ
Open zones are
listed
User is not permitted
to operate the area
A. XX S AreaXX
Access denied
A. XX S AreaXX
First disarm
T area ishe already
armed
or or
6
Figure 7. Stay Arming

CA824 Alarm System User Manual 15
5
User Menu
ARMing
User
code
ARM
CA824
Wed. 09/05 11:52
ARMing
3)Full arming
5)Force arming
A. XX S AreaXX
CA824
Access denied
3)Full arming
Access denied
5)Force arming
Access denied
2
1
1
3
3
3
A. XX - AreaXX
armed
2 5
Invalid user code entered
User is not permitted to arm the system
User is not permitted to Stay arm the system
User is permitted to operate one area only
and the keyboard supports this area
or the keyboard supports one area only
and the user is permitted to operate this area
A. XX - AreaXX
armed
ENT
Area
No or
2
3
5
Area is not ready to be
armed (open zones)
A. XX S AreaXX
Area isn’t ready
A. XX S AreaXX
ZZ ZoneZZ
Open zones are
listed
User is not permitted
to operate the area
A. XX S AreaXX
Access denied
A. XX S AreaXX
First disarm
T area ishe already
armed
or or
6
Figure 8. Force Arming

16 CA824 Alarm System User Manual
User Menu
ARMing
User
code
ARM
CA824
Wed. 09/05 11:52
ARMing
3)Full arming
6)Instant arming
A. XX S AreaXX
CA824
Access denied
3)Full arming
Access denied
6)Instant arming
Access denied
2
1
1
3
3
3
A. XX - AreaXX
armed
2 5
Invalid user code entered
User is not permitted to arm the system
User is not permitted to Stay arm the system
User is permitted to operate one area only
and the keyboard supports this area
or the keyboard supports one area only
and the user is permitted to operate this area
6
A. XX - AreaXX
armed
ENT
Area
No or
2
3
5
Area is not ready to be
armed (open zones)
A. XX S AreaXX
Area isn’t ready
A. XX S AreaXX
ZZ ZoneZZ
Open zones are
listed
User is not permitted
to operate the area
A. XX S AreaXX
Access denied
A. XX S AreaXX
First disarm
T area ishe already
armed
or or
6
Figure 9. Instant Arming

CA824 Alarm System User Manual 17
Disarming
Coming into the entrance zone, the user is required to enter a personal code. A
continuous sound indicates the entrance time.
If the system is not disarmed within the entrance time, the alarm is activated.
Certain users may not be allowed to disarm the system.
The arming sequence is described by Figure 10.
User Menu
ARMing
User
code
CA824
Wed. 09/05 11:52
DISARMing
A. XX S AreaXX
CA824
Access denied
DISARMing
Access denied
A. XX S AreaXX
disarmed
ENT
Area
No or
2
1
2
3
3
3
A. XX S AreaXX
disarmed
2
Invalid user code entered
User is not permitted to disarm the system
User is permitted to operate one area only
and the keyboard supports this area
or the keyboard supports one area only
and the usre is permitted to operate this area
4
DISARM
6
6
or
A. XX S AreaXX
Already disarmed
T area is
dis
he already
armed
6
A. XX S AreaXX
Access denied
User is not permitted
to operate the area
Figure 10. Disarming

18 CA824 Alarm System User Manual
Troubles Review
The troubles review sequence is described by Figure 11. When a trouble occurs, call
your technical support service.
User Menu
ARMing
User
code
CA824
Wed. 09/05 11:52
TRBL (troubles)
trouble message
CA824
Access denied
2
1
3
Invalid user code entered
TRBL
User Menu
TRBL (troubles)
6
All current system troubles are
listed here one after the other
Figure 11. Troubles Review
All trouble messages and their meanings are shown bellow:
Message Meaning
ACC loss 220V mains power loss
AUX Power Failed Blown AUX fuse of the main module
Batt Loss Low or no battery or blown system battery fuse
Buss Error Connection with the module has failed along the bus
PGM Power Failed Blown PGM fuse of the main module
TelFailure Communication failure in the build-in communicator
TL Fault Telephone line failure

CA824 Alarm System User Manual 19
Event Memory Review
The CA824 Alarm System has a memory that stores all events that have taken place
during the system operation.
Only users that have permission can review the event memory.
The event memory review sequence is described by Figure 12.
User Menu
ARMing
User
code
CA824
Wed. 09/05 11:52
RXXX Cnn Message
A.XX dd/mm hh:mm
CA824
Access denied
User Menu
MEMory(Log file)
Long Message
A.XX Cause
ENT
2
1
1
1
3
Invalid user code entered
User is not permitted to review the event memory
MEM
ENT ENT
Figure 12. Event Memory Review

20 CA824 Alarm System User Manual
In the above figure:
Rindicates the event is restoring
XXX is the event sequential number
Cstands for the event cause. It can be:
d– for device
u– for user
z– for zone
A.XX displays the number of the area, where the event has taken place
dd/mm is the date (day/month), when the event has taken place
hh:mm is the time (hour:minutes), when the event has taken place
All short and long messages and their meanings are shown bellow:
Message Long message Meaning
Medical Medical alarm
Medical type zone ZZ has been activated or a
Medical signal has been manually triggered off
from keyboard/device DD
Fire Fire alram
Fire type zone ZZ has been activated or a Fire
signal has been manually triggered off from
keyboard/device DD
Panic Panic alram
Panic type zone ZZ has been activated or a
Panic signal has been manually triggered off
from keyboard/device DD
Duress Duress A UU code has been entered for duress
Alarm Burglary alarm An Entry Delay, Follow or Instant type zone ZZ
has been activated
Alarm 24 hour alarm A 24h Burglary type zone ZZ has been
activated
Tamper Tamper A tamper type zone ZZ has been activated
ExpFail Exp. module fail Connection with module DD has failed along
the bus
SenrTmp Sensor tamper A self-arming zone ZZ sensor has been
activated
Exp.Tmp Exp. module tmp. A self-arming module DD has been activated
24h nB 24h non-burglary A 24h non-burglary zone ZZ has been activated
SystTrb System trouble A PGM or AUX fuse of the main module has
failed
AC loss AC loss 220V mains power loss
Battlow Low system Batt. Low system battery voltage
