Televes TOX Series User manual

HDTV ENCODER/MODULATOR - Quad Composite to QAM
HDTV ENCODER/MODULATOR - Quad Composite to QAM (EAS)
EN
Refs. 563802, 563821
QUICK
INSTALLATION GUIDE
www.televes.com

Responsible party: Televes USA LLC. 16596 E. 2nd Avenue Aurora, CO 80011 USA Telephone: [phone] [e-mail]
Manufacturer: Televes S.A.U. Rúa B. de Conxo, 17 - 15706 Santiago de Compostela, A Coruña. Spain www.televes.com
Safety instructions
Caution Statements
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including ampliers)
that produce heat.
9. Only use attachments/accessories specied by the
manufacturer.
10. Use only with the cart, stand, tripod, bracket, or table
specied by the manufacturer, or sold with the apparatus.
When a cart is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.
11. Refer all servicing to qualied service personnel. Servicing
is required when the apparatus has been damaged in any
way, liquid has been spilled or objects have fallen into
the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.
Warning
Apparatus shall not be exposed to dripping or splashing and
no objects lled with liquids, such as vases, shall be placed
on the apparatus.
Safe operation
Should any liquid or object fall into the equipment, please
refer to qualied personnel for service.
Safe installation
Ambient temperature should not be higher than 113°F.
Do not place the equipment near heat sources or in a highly
humid environment.
Do not place the equipment in a place where it can suer
vibrations or shocks.
Please allow air circulation around the equipment.
Do not place naked ames, such as lighted candles on or
near the product.
Simbology
Equipment designed for indoor use.
The equipment complies with the CE mark
requirements.



















Description of connectors
Front view Rear view
1.- ASI input
2.- ASI output
3.- Power connectors
4.- Ethernet connector
5.- Ethernet connector
6.- Programmer connector
7.- RF loop through input
8.- RF output
1.- CVBS input (Video/Closed Caption). Channel 1
2.- Analog (L/R) audio input. Channel 1
3.- CVBS input (Video/Closed Caption). Channel 2
4.- Analog (L/R) audio input. Channel 2
5.- EAS CVBS input (563821 only)
6.- EAS L/R analog audio input (563821 only)
7.- EAS control (563821 only)
8.- CVBS input (Video/Closed Caption). Channel 3
9.- Analog (L/R) audio input. Channel 3
10.- CVBS input (Video/Closed Caption). Channel 4
11.- Analog (L/R) audio input. Channel 4
563802 563802563821
(EAS)
563821
(EAS)
LED indicators
Front
LED alarms
TEMP
Color Internal temp Comment
Solid green Normal Safe
Slow blink orange High Warning
Fast blink red Very High Danger
EAS
Color EAS status Comment
Solid green ON An alarm has been triggered and the system is broadcasting common EAS audio and video.
O OFF No alarm present. Each encoder in the system is broadcasting its own content.
CH1/CH2 – CH3/CH4
Color Channel status Comment
O Disabled / EAS Channels disabled or unit in EAS mode.
Solid green Lock Inputs locked and unit encoding audio/video.
Solid red Unlock Inputs unlocked and unit not encoding audio/video.
Blinking red Boot Unit starting up.
Solid yellow Partial lock Only one of the two inputs is locked and encoding audio/video.
QAM
Color Output mode Comment
Solid green Normal Output RF channel is ON, broadcasting audio/video (normal mode).
Slow blinking green Carrier wave, null or muted Output RF channel is OFF or in an alternate signal mode.
LOOP
Color Output loop status Comment
Solid green ON Output loop-through enabled. Units may be daisy-chained using the internal combiner.
O OFF Output loop-through disabled. Units must be combined using an external combiner.

Installation
1. Install all units in the rack and connect them as shown in Figure 1.
Figure 1
2. The audio and video input signals connect to the back of the
modules.
Figure 2
3. If a network is available that provides IP addresses through DHCP,
connect the encoders to the network as shown in Figure 3. If such a
network is not available, then a computer will need to be connected
as shown in Figure 4.



Figure 3 - Rack with DHCP server.
4. Power on the units.
Figure 4 - Rack without DHCP server.
5. Connect the programmer to each unit and set a unique number in
the “# ID” eld according to the order of installation of the units in
the rack.




Figure 5 - Set a # number dierent for each unit.
6. Connect the programmer to a unit, usually the rst one, and read
the IP address.
Each unit can work as a master controller for the other units. All units
can be congured by connecting to only one.




Figure 6 - Read the IP address of one unit.
7. If a network was connected in Step 3 then proceed to step 8. If not,
set the address of you computer as follows:
IP value = 172.20.0.2
netmask = 255.0.0.0
gateway = 172.20.0.3
NOTE: The default factory conguration of the units has an IP address in
this range (it should be dierent for each unit). If a unit was ever
provided an address before, manually or through DHCP, this unique
address may no longer exist. Resetting to IP factory defaults, will
return the original unique private address though.
8. In your web browser, enter the IP address from Step 6 as the URL.
A login prompt will appear. By default the parameters are:
Login: encoder
Password: encoder

The Status > Summary page should appear as the rst page.
This provides a summary of all the units installed in the network and the
units will be sorted by the number entered in Step 5.
The “Change Password” option only changes the password of the encoder
currently logged in to. To change the password for the remaining modules,
each one will need to be logged into with its unique IP address and the
change made for each.
Figure 8 shows an example of a detailed status page.
9. Congure all units:
Select “CONFIGURATION”. This page has 4 options, INPUT, TRANSPORT,
OUTPUT, and NETWORK, shown in Figures 9, 10, 11, and 12 respectively.
For each conguration page, the last column is“Select”. Any changes made,
will be saved only to the units with this associated “Select” box checked
when “Apply Selected“ is clicked. This applies to all 4 of the sections under
the Conguration Menu.
10. Change conguration of one unit:
Select “CONFIGURATION”. Click on the Model name of the desired unit
and the page below will be shown. From this page you can change any
parameter of the conguration of the desired unit.
Figure 7 - Status > Summary tab.
Figure 8 - Status > Detailed tab.
Figure 9 - Conguration > Input tab.
Figure 13 - Conguration > Advanced conguration
Some items have an automatic conguration option, such as “Automatic
channel numbering”shown in gure 10.
The network conguration page allows a change to the Number assigned in
Step 5. This option also has an “Auto”assignment feature.
The“Auto”option will ask for conrmation since it will overwrite the settings
of all units set in Step 5 and the ordering will likely not be as the units were
placed in the rack.
Figure 10 - Conguration > Transport tab.
Figure 11 - Conguration > Output tab.
Figure 12 - Conguration > Network tab.



































































 
 




























 

















 



 



































Menu ow chart
For programming Unit operation
Enable edit mode /
Position cursor
(in edit mode) /
Disable edit mode.
Change section /
Save parameters
(press and hold
for 3 sec.)
Change menu /
Modify value
(in edit mode)

Technical specications
References 563802, 563821*
INPUTS
VIDEO Connectors 4 sets - 1x RCA for Video (CVBS)
AUDIO Connectors 4 sets - 2x RCA for Analog Audio (L, R)
CLOSED CAPTIONING Connectors 4 sets - 1x RCA for Video (Same as CVBS in)
EAS*
Connectors 3x RCA (CVBS, L, R)
Trigger Vdc 5-12 ( Dry Contact Closure)
ASI
Connectors 1x BNC
Format DVB-ASI
Standard ETSI EN 50083-9
QAM Connectors “F” Female (loop-through combiner input)
ENCODING
PROFILE
VIDEO
Output Format MPEG-2 / H.264
Resolution 480i & 576i
Supports auto-scan for input resolution
Aspect Ratio 4:3, 16:9 and pass through
GOP 10, 12, 15, 16, 18, 20, 24 or 30
Transport rate Variable
Video bit rate Variable
AUDIO
Output format Dolby® Digital AC-3 or MPEG1 Layer 2
Sampling rate kHz 48
Output bitrate Variable
CLOSED CAPTIONING Format EIA-608
OUTPUT
QAM
Connectors 1x “F” Female
Modulation standards
ITU-A: 16, 32, 64, 128, 256, 512, 1024 QAM
ITU-B: 64, 256 QAM
Frecuency Range MHz 5 - 1002 (supports return path applications)
Channel plans CATV STD, T_CHANNELS, Broadcast, Frequency
Max output level dBmV +50 (+40 with loop-through)
MER dB >40 (typ)
Spurious dBc -60
Impedance Ω 75
I/Q Phase Error º <1
I/Q Amplitude Imbalance % <1
ASI
Connectors 1x BNC
Format DVB-ASI
ALARMS / MONITORING / CONTROL
Local control Full conguration with LCD handheld programmer
Local monitoring
EAS status LED
LOOP status LED
QAM status LED
TEMP status LED
CH1/CH2 - CH3/CH4 status LEDs
Ethernet status LEDs
Remote monitoring Centralized web based remote control, management, alarms, and software upgrades
Control Daisy-chain integrated ethernet switch
GENERAL
Power supply Vdc 24
Power disipation W <16
Operating Temperature ºF / ºC 32 to 113 / 0 to 45
