5500/5520
607551
Rev. 00 (11-99)
Automatic Scrubber
Fregadora Automática
Model No.:
607550 – 5500 Pac
607549 – 5500
607563 – 5520 Pac
607562 – 5520
Operator and Parts Manual
Manual de Operación y de Piezas
FAX: [phone]
CUSTOMER SERVICE: 1–800-982-7658
TENNANT COMPANY
Commercial Products
12875 RANSOM STREET
HOLLAND MI 49424 U.S.A.
Home
Find...
Go To..

PARTS LIST
LISTA DE PIEZAS
Tennant 5500/5520 (10–97)
34
SOLUTION TANK GROUP
GRUPE DEL DEPÓSITO DE DISOLUCIÓN
26
2
3
5
6
7
8
9
11
10 12 13
14
15
16
18
19
11
12 17
20
21
22
27
23
24
25
23
31
30
29
28
32
33
34
35
36
35
37
40
39
38
1
4
41
42
43
44
42 44
45
Home
Find...
Go To..

PARTS LIST
LISTA DE PIEZAS
Tennant 5500/5520 (06–99) 35
SOLUTION TANK GROUP
GRUPE DEL DEPÓSITO DE DISOLUCIÓN
REF PART # DESCRIPTION QTY.
∇1607982 ASM., SOLUTION TANK COVER, TEAL 1
2607515 COVER, TANK, TEAL 1
3140706 RIVET, POP 7
4230626 HINGE, COVER 1
5603233 DECAL, BATTERY RECHARGE 1
6100151 GASKET, TUBE ADAPTER 1
7230664 ADAPTER, TUBE 1
8140424 SPRING, TUBE ADAPTER 1
9602878 WASHER 1
10 602847 BRACKET, VAC TUBE 1
11 140027 WASHER, FLAT 3
12 140015 WASHER, LOCK 3
13 200 031 488 SCREW, M8X1.25X20MM 2
14 600476 STRAP, PLUG REAR FILL 1
15 140011 WASHER, FLAT 1
16 140350 SCREW, #10X1/2 1
17 200 031 488 SCREW, M8X1.25X20MM 1
18 230925 SUPPORT, RECOVERY TANK 1
19 140116 BUSHING 1
20 600649 DECAL, SOLUTION LEVER CE 1
21 600650 DECAL, SQUEEGEE LEVER CE 1
22 607552 TANK, SOLUTION, TEAL 1
23 150529 HOSE BARB 2
REF PART # DESCRIPTION QTY.
24 160229 TUBING 2 ft
25 630369 CLAMP 1
26 N/A DECAL, 2
27 608118 DECAL, "5500" 2
608119 DECAL, "5520" 2
28 630002 CASTER, 4" 2
29 140025 WASHER, FLAT 8
30 140333 WASHER, LOCK 8
31 140276 SCREW, M10X1.5X16MM 8
32 578 141 000 SCREW, M5X10MM 2
33 140018 WASHER, FLAT 2
34 600298 SHIELD, LIGHT 1
35 26578 GASKET 2.5 ft
36 130023 LIGHT, SAFETY 1
37 120192 DECAL, TENNANT LOGO 1
38 140826 SCREW, #6X3/4 2
39 140032 WASHER, FLAT 2
40 602529 SCREEN, FILL 1
41 130040 WIRE TIE 4
42 140310 CLAMP 2
43 12712 TUBING 1.48 ft
44 150419 ELBOW, 1/4MX3/8H 902
45 621324 PLUG, EXPANSION 1
∇Assembly
Included in Assembly
Recommended Stock Item
Home
Find...
Go To..

PARTS LIST
LISTA DE PIEZAS
Tennant 5500/5520 (10–97)
36
RECOVERY TANK GROUP
CONJUNTO DEPOSITO RECUPERAR
1
2
30
12
3
4
5
611
9
10
13
15 14
16
20
21
25
24
29
28
27
26
28 29
27
8
7
23
33
34
32
31
18
19
22
17
Home
Find...
Go To..

PARTS LIST
LISTA DE PIEZAS
Tennant 5500/5520 (06–99) 37
RECOVERY TANK GROUP
CONJUNTO DEPOSITO RECUPERAR
REF PART # DESCRIPTION QTY.
1701103 ASM.,STANDPIPE 1
2180613 FLOAT, SHUT-OFF 1
3230187 NIPPLE 1
4101714 GASKET 1
5210240 NUT, FLANGED 1
∇6100102 ASM.,LID CLEAR W/STANDARD HOLE 1
7100105 LID, CENTER CLEAR ONLY 1
8100109 LID, OUTER RING ONLY 1
9140826 SCREW, #6X3/4 6
10 3701.6 SCREW, #6X3/8 2
11 230513 CHAIN 1
12 607554 TANK, RECOVERY, TEAL 1
13 578 187 000 SCREW, M06X1.0X12MM 1
14 140052 WASHER, 1/4 EXT 1
15 140000 WASHER, FLAT 1
16 140960 CABLE 1
17 140308 CLAMP 1
REF PART # DESCRIPTION QTY.
18 140015 WASHER, LOCK 1
19 200 031 488 SCREW, M8X1.25X20MM 1
20 0174..10 SEAT, NEOPRENE 1
∇21 130477 MOTOR, VAC 5.7 /3 STAGE 24 VDC 1
22 190163 CARBON BRUSH 2/PK 2
23 130096 TERMINAL, MALE DISCONNECT 2
24 140284 NUT 3
25 140000 WASHER, FLAT 3
26 140353 STUD 3
27 578 187 000 SCREW, M06X1.0X12MM 11
28 140052 WASHER, LOCK 11
29 140000 WASHER, FLAT 11
30 600311 HINGE, RECOVERY TANK 1
31 621324 PLUG, EXPANSION 2
32 578441 STRAP, DRAINHOSE 1
33 630394 SLEEVE, DRAINHOSE 1
34 630068 HOSE, DRAIN 1
∇Assembly
Included in Assembly
Recommended Stock Item
Home
Find...
Go To..

PARTS LIST
LISTA DE PIEZAS
Tennant 5500/5520 (10–97)
38
DRIVE GROUP
GRUPO DE TRANMISIÓN
1
27
23
4
5
25
67
8
9
10
11
12
13
14
15
16
21
19
20
26
28
29
30
31
35
23
22
32
33
32
34
36
28
18
12
17
24
19
20
14
28
27
37
18
28
28
38
Home
Find...
Go To..

PARTS LIST
LISTA DE PIEZAS
Tennant 5500/5520 (10–97) 39
DRIVE GROUP
GRUPO DE TRANMISIÓN
REF PART # DESCRIPTION QTY.
1600288 PLATE, BASE TRANSAXLE 1
2140236 SCREW, 1/2-13X1 1/4 2
3600292 BRACKET, ACTUATOR 1
4140548 NUT 2
5140314 CLAMP, INSULATED 3/4 ID 1
6140015 WASHER, LOCK 4
7200 031 494 SCREW, M8X1.25X30 4
8621235 BUSHING, CABLE 1
9630157 BRACKET, CABLE GUIDE 1
10 200 031 432 SCREW, M6X1/0X10 2
11 140052 WASHER, 1/4 EXT 2
12 140000 WASHER, FLAT 10
13 621 236 000 RING, RETAINING 1
14 140027 WASHER, FLAT 4
15 240191 KNOB, 5/16-18X2 1
16 600952 ACUTATOR 1
17 281 004 001 TERMINAL, QC 2
18 140276 SCREW, M10X1.5X16MM 2
19 604076 PIN, CLEVIS 2
REF PART # DESCRIPTION QTY.
20 578421 PIN, COTTER 2
∇21 630126 TRANSAXLE 20" 1
22 630503 CAP 2
23 630504 CARBON BRUSH 2
24 600606 END BELL, TRANSAXLE MOTOR 1
25 640013 WHEEL, 8" 2
26 630268 NUT 8
27 612 255 000 SCREW, M10X35MM 3
28 140333 WASHER, LOCK 6
29 602881 BRACKET, TRANSAXLE MOUNT 2
30 600304 SPACER, AXLE 4
31 602883 SPACER 2
32 140045 WASHER, FLAT 4
33 602882 BUSHING 2
34 140516 NUT 2
35 600290 BRACKET, LIFT DUAL MOTOR 1
36 140028 WASHER, FLAT 2
37 601 094 000 SCREW, M10X45MM 1
38 603466 GUARD, TRANSAXLE 1
∇Assembly
Included in Assembly
Recommended Stock Item
Home
Find...
Go To..

PARTS LIST
LISTA DE PIEZAS
Tennant 5500/5520 (10–97)
40
BRUSH GROUP
CONJUNTO IMPULSO DE CEPILLO
37
3
2
29
41
40
1
5
8
9
10
33
12
13
14
24
15
16
17
18
39
38
39
36
35
34
30
31
5
32
28
23
21
22
19
19
21 20
25
27
11
6
626
9
10
4
7
11
42
Home
Find...
Go To..

PARTS LIST
LISTA DE PIEZAS
Tennant 5500/5520 (06–99) 41
BRUSH GROUP
CONJUNTO IMPULSO DE CEPILLO
REF PART # DESCRIPTION QTY.
∇1130491 MOTOR & GEAR BOX, BRUSH 2
2630609 ASM., GEAR BOX 1
2190741 ASM., BRUSH CARD 1
2190970 BRUSH, CARBON 4
2140632 KEY, 1/4X1 1
2130163 TERMINAL RING (NEGATIVE) LEFT MOTOR 1
130109 TERMINAL RING (POSITIVE) LEFT MOTOR 1
3130163 TERMINAL RING (NEGATIVE) RIGHT MO
TOR
1
130192 TERMINAL RING (POSITIVE) RIGHT MO
TOR
1
4100764 COVER, BRUSH MOTOR 2
5600300 PLATE, GUIDE 2
6140003 WASHER, FENDER 8
7140016 WASHER, LOCK 4
8140272 SCREW, M6X1.0X16MM 4
912712 TUBING 2.08 ft
10 140310 CLAMP 2
11 140618 PIN, ROLL 4
12 140028 WASHER, FLAT 8
13 140017 WASHER, LOCK 8
14 140202 SCREW, 3/8-16X1 8
15 230672 PLATE, DRIVER 2
16 25732 WASHER, FLAT 4
17 140015 WASHER, LOCK 2
18 140219 SCREW, 5/16-18X1 2
REF PART # DESCRIPTION QTY.
19 140417 CLIP, SPRING 2
20 230651 CLAMP, BRUSH PLATE 2
21 140018 WASHER, LOCK 4
22 230697 STOP, DRIVER RELEASE 1
23 140887 SCREW, 10-24X3/8 4
∇24 240262 PAD DRIVER, 12" PK/2 (5500) 1
602928 PAD DRIVER, 13" PK/2 (5520) 1
25 240238 LUGS, W/SCREWS (SET OF 3) 1
26 100106 PLATE, PAD DRIVER BASE 2
27 100107 RING, PAD RETAINER SNAP-IN 2
28 200 031 488 SCREW, M08X1.25X20MM 4
29 140015 WASHER, LOCK 4
30 140272 SCREW, 1/2-13X3 1
31 140016 WASHER, LOCK 1
32 600299 SKIRT, FRONT LIP 1
33 600289 BRACKET, MOTOR MOUNT 1
34 602558 BRACKET, SPRING MOUNT 1
35 602930 BUSHING 1
36 578 298 000 WASHER, FLAT 8
37 602555 SPRING 1
38 600200 NUT 1
39 140028 WASHER, FLAT 2
40 602556 BRACKET, SPRING 1
41 140225 SCREW, 3/8-16X2 1
42 100058 TAPE, ACRYLIC .50 ft
∇Assembly
Included in Assembly
Recommended Stock Item
Home
Find...
Go To..
222615
X
X

PARTS LIST
LISTA DE PIEZAS
Tennant 5500/5520 (06–99)
42
BRUSH SKIRT GROUP
CONJUNTO JUEGO DE CEPILLO
12
15
9
1
19
2
4
5
3
21
20
20
18
14
11 10
8
13
6
17
16
19
18
1
12
11
10
5
8
9
21
7
6
Home
Find...
Go To..

PARTS LIST
LISTA DE PIEZAS
Tennant 5500/5520 (06–99) 43
BRUSH SKIRT GROUP
CONJUNTO JUEGO DE CEPILLO
REF PART # DESCRIPTION QTY.
1607558 SKIRT LEFT SIDE, TEAL, 5500 1
607564 SKIRT LEFT SIDE, TEAL, 5520 1
607560 SKIRT RIGHT SIDE, TEAL, 5500 1
607566 SKIRT RIGHT SIDE, TEAL, 5520 1
2603154 SCREW 2
3578 144 000 SCREW, M5X16MM 10
4630450 WHEEL, RUBBER 2
5230943 PIN, SKIRT 2
6600301 BRACKET, SKIRT MOUNT 2
7140293 SCREW, M5X0.8X30MM 6
8140015 WASHER, LOCK 4
9578 237 000 SCREW, M8X18 4
10 578237000 SCREW, M8X18 4
11 140015 WASHER, LOCK 4
REF PART # DESCRIPTION QTY.
12 607951 BRACKET, SKIRT MOUNT, LH 1
607952 BRACKET, SKIRT MOUNT, RH 1
13 140283 NUT 6
14 140011 WASHER, FLAT 6
15 140932 LATCH, HOOD 1
16 200 070 340 SCREW, M4X.7X8MM 4
17 140023 WASHER, LOCK 4
18 600295 SPLASH GUARD 5500 2
600294 SPLASH GUARD 5520 2
19 600297 STRAP, SPLASH GUARD 5500 2
600296 STRAP, SPLASH GUARD 5520 2
20 140011 WASHER, FLAT 16
21 140018 WASHER, LOCK 16
Recommended Stock Item
Home
Find...
Go To..

PARTS LIST
LISTA DE PIEZAS
Tennant 5500/5520 (10–97)
44
SOLUTION CONTROL GROUP
CONJUNTO DE PALANCAS SOLUCIÓN
15
29
1
4
2
3
5
9
4
3
10
8
14
6
12
12
16
14
24
17
18
35
23
36
33
18
11 12
21
34
31
30
23
37
19
22
23
20
21
28
27
25
26
23
23
23
38
32
7
13
13
12
11
Home
Find...
Go To..

PARTS LIST
LISTA DE PIEZAS
Tennant 5500/5520 (10–97) 45
SOLUTION CONTROL GROUP
CONJUNTO DE PALANCAS SOLUCIÓN
REF PART # DESCRIPTION QTY.
1230661 PLATE, LOCK CONTROL HOUSING 1
2200 031 488 SCREW, M8X1.25X20MM 1
3140015 WASHER, LOCK 2
4140027 WASHER, FLAT 2
5600280.BK WELDMENT, DRAIN HOSE HANGER 1
6230735 BUSHING 2
7140060 WASHER, WAVE 2
8200816 GRIP, HANDLE 1
9602884 HANDLE, SOLUTION VALVE 1
10 200 031 496 SCREW, M8X1.25X35 1
11 140208 SCREW, 1/4-20X1 2
12 140000 WASHER, FLAT 4
13 140134 BUSHING 2
14 140501 NUT 2
15 230718 LEVER, SOLUTION VALVE 1
16 230657 ARM, VALVE 1
17 140616 PIN, ROLL 1
18 150406 ELBOW, STREET 1/4 902
19 210259 VALVE, 3-WAY 5/16 PORTS 1
REF PART # DESCRIPTION QTY.
20 140283 NUT 2
21 140011 WASHER, FLAT 4
22 28303 HOSE BARB 1
23 140310 CLAMP 6
24 12712 TUBING 2.08 ft
25 069 762 303 NUT 4
26 140272 SCREW, M6X1.0X16MM 4
27 602879 PLATE, SOLENOID MOUNT 1
28 603310 VALVE, SOLENOID 24 VDC 1
29 600350 TUBING, CLEAR .167 ft
30 150410 ELBOW, 1/4X5/8 1
31 140272 SCREW, M06X1.0X16MM 2
32 140016 WASHER, LOCK 2
33 600303 BRACKET, VALVE 1
34 578 144 000 SCREW, M5X16MM 2
35 150516 HOSE BARB 1
36 12712 TUBING 2.08 ft
37 600350 TUBING, CLEAR .25 ft
38 602929 FILTER, SOLUTION TANK 1
Recommended Stock Item
Home
Find...
Go To..

PARTS LIST
LISTA DE PIEZAS
Tennant 5500/5520 (04–98)
46
SQUEEGEE CONTROL GROUP
CONJUNTO DE PALETA PLANCAS
20
1
2
3
2
4
5
6
7
86
9
6
10
11
3
13
6
12
19
18
24
23
22
17
18
19
16
15
14
25
26 27
21
REF PART # DESCRIPTION QTY.
1160613 HOSE, VAC 1.5X30" W/CUFFS 1
2630156 CABLE, SQUEEGEE LIFT 2
3140501 NUT 2
4602981 SCREW, 1/2-13X5 1/2 2
5140024 WASHER, LOCK 6
6140045 WASHER, FLAT 2
7140139 BUSHING 1
8612 091 000 NUT 1
9600293 PIVOT, SQUEEGEE MOUNT 1
10 230730.BK BRACKET, SQUEEGEE MOUNT 2
11 140516 NUT 1
12 069 767 158 SCREW, 1/2-20X6 2
13 27257 KNOB, 5/16-18 2
14 069 762 303 NUT 2
REF PART # DESCRIPTION QTY.
15 140272 SCREW, M6X1.0X16MM 2
16 602880 PLATE, SQUEEGEE CABLE LINK 2
17 200 031 496 SCREW, M08X35 1
18 140015 WASHER, LOCK 4
19 140027 WASHER, FLAT 4
20 602885 HANDLE, SQUEEGEE LIFT 1
21 200816 GRIP, HANDLE 1
22 604358 BUSHING SPACER 1
23 230661 PLATE, LOCK CONTROL HOUSING 1
24 200 031 488 SCREW, M8X1.25X20MM 1
25 140268 SCREW, M5X.8X12MM 2
26 140031 WASHER, LOCK 2
27 230712 PLATE, SQUEEGEE LOCK 1
Recommended Stock Item
Home
Find...
Go To..

PARTS LIST
LISTA DE PIEZAS
Tennant 5500/5520 (06–99) 47
SQUEEGEE GROUP
CONJUNTO PALETA
1
2
4
5
37
812
13
14
6
9
10
11
10
9
REF PART # DESCRIPTION QTY.
∇603262 ASSEMBLY, SQUEEGEE, CURVED (5500) 1
603263 ASSEMBLY, SQUEEGEE, CURVED (5520) 1
1 140799 SCREW, 5/16-18 X 1-1/2 2
2 630450 WHEEL, 76 DIA X 22 WD RUBBER 2
3602958 SQUEEGEE WELDMENT, 5500 1

602960 SQUEEGEE WELDMENT, 5520 1
427257 KNOB, 5/16-18 THREAD - BLACK 2
5 603260 GASKET, SQUEEGEE CURVED 1
6 140221 SCREW, 5/16-18 X 1-1/4 2
7 140226 SCREW, 5/16-18 X 5/8 2
REF PART # DESCRIPTION QTY.
8 140015 WASHER, 5/16 SPLITLOCK 2
9 605975 SCREW, 10-24 X 1/2" 24-28
10 602962 PLATE, SQUEEGEE RETAINING 5500 2

602963 PLATE, SQUEEGEE RETAINING 5520 2
11 603660 BLADE, SQUEEGEE 34" (5500) 2

603661 BLADE, SQUEEGEE 40" (5520) 2
∇700844 ASM., SQUEEGEE ROLLER 2
12 230474.BK BRACKET, SQUEEGEE ROLLER 2
13 26548 ROLLER 2
14 140710 RIVET, AXLE 3/8 X 1.6 2
=RECOMMENDED STOCK ITEMS/PIEZAS RECOMENDADAS EN ALMACÉN
∇=ASSEMBLY / CONJUNTO
=INCLUDED IN ASSEMBLY / INCLUIDO A CONJUNTA
Home
Find...
Go To..
31"
34"

PARTS LIST
LISTA DE PIEZAS
Tennant 5500/5520 (10–97)
48
CONSOLE GROUP
CONJUNTO CONSOLA DE CONTROLES
27
1
2
3
4
5
6
7
8
9
10
65
12
13
11
12
14
1
15
38
36
20
18
19
21
16
17
26
23 22
24
25
30
35
31
32
33
34
29
37
36
40
41
43
42
28
Wire Harnesses
44
35
46
39
45
Home
Find...
Go To..

PARTS LIST
LISTA DE PIEZAS
Tennant 5500/5520 (10–97) 49
CONSOLE GROUP
CONJUNTO CONSOLA DE CONTROLES
REF PART # DESCRIPTION QTY.
1200823 GRIP, HANDLE TUBE 2
227099 BUSHING 1
3603050 HANDLE, TUBE 1
4602903 GAUGE, BRUSH PRESSURE 1
5578 141 000 SCREW, M5X10MM 8
6140018 WASHER, LOCK 8
7602560 PANEL, SWITCH 1
8603399 SWITCH, DPDT MOM. ON/OFF/MOM. ON 1
9601107 SWITCH, LIGHTED ROCKER 3
10 130015 METER, BATTERY VOLTAGE 24V 1
11 630104 SPEED CONTROL, PMB, 55 AMP 1
12 200 160 014 NUT 4
13 630261 SPACER 2
14 630128 HEAT SINK 1
15 607556 HOUSING, CONTROL, TEAL 1
16 601108 SWITCH, TOGGLE 1
17 130753 BOOT, SWITCH 1
18 130776 POTIENTIOMETER, 50K 1
19 130775 POTIENTIOMETER, 50K LOCKABLE 1
20 140351 SCREW, M12X1.75X70MM 2
21 630304 SCREW, M4X35MM 2
22 230715 TUBE, HANDLE ADJUSTMENT 1
23 230649 PIN, HANDLE ADJUSTMENT 2
24 230710 PIN, HANDLE LOCK 2
REF PART # DESCRIPTION QTY.
25 140415 SPRING, LOCK PIN 1
26 140155 BUSHING 2
27 601110 KNOB, SPEED CONTROL 1
28 603007 BUSHING, SNAP 1
29 602886 PIN, SPRING RETURN 1
30 601118 SPRING, EXPANSION 1
31 140829 SCREW, 6-32X1 2
32 140019 WASHER, LOCK 2
33 27098 BRACKET, SWITCH 1
34 130729 SWITCH, ROLL 1
35 140552 NUT 2
36 140000 WASHER, FLAT 2
37 25671 MOUNT, SWITCH 1
38 140890 SCREW. 10-24X1/2 1
39 140900 SCREW, 10-24X3/4 TRSPHL 2
40 578 321 000 SCREW, M6X16MM 2
41 069 762 303 NUT 2
42 3148.816 WASHER, FLAT 2
43 140024 WASHER, LOCK 2
44 602873 HARNESS CONSOLE W/POT. (NOT SHOWN) 1
602874 HARNESS MAIN/SWITCH/CONSOLE (NOT
SHOWN)
1
45 603830 PLATE, GUARD SWITCH 1
46 26561 CABLE TIE 1
Recommended Stock Item
Home
Find...
Go To..

PARTS LIST
LISTA DE PIEZAS
Tennant 5500/5520 (10–97)
50
ELECTRICAL / BATTERY GROUP
GRUPO DEL ELÉCTRICO/BATERÍA
1
2
5
4
6
8
9
10
8
13
16
17
32
31
30
18
19
20
24
17
8
21
23
2
25
26
10
28
26
25
10 9
13
11
12
34
33
3
7
13
12
11
910
14 15
22
27
29
35
Home
Find...
Go To..

PARTS LIST
LISTA DE PIEZAS
Tennant 5500/5520 (10–97) 51
ELECTRICAL / BATTERY GROUP
GRUPO DEL ELÉCTRICO/BATERÍA
REF PART # DESCRIPTION QTY.
1602559 PANEL, CONTROL HOUSING 1
2222519 PLUG 1
3069 764 626 PLUG, HOLE 012.7 1
4130161 PLUG, DOME .850 1
5130175 PLUG, DOME .750 1
6120649 DECAL, WARNING BATTERY 1
7582150 PLUG, ACCESSORY SWITCH 2
8578 321 000 SCREW, M6X16MM 6
9140284 NUT, M6X1.O NYLOCK 4
10 140000 WASHER, FLAT 4
11 130423 DIODE, 400V 3
12 130125 RING, TERMINAL 6
13 130218 SOLENOID, 24V 3
14 130021 FLASHER, 24VDC 1
15 100058 TAPE, ACRYLIC .08 ft
16 130737 BREAKER, CIRCUIT BRUSH 10 AMP 1
17 602951 BREAKER, CIRCUIT 35 AMP 3
18 140829 SCREW, 6-32X1 2
REF PART # DESCRIPTION QTY.
19 140019 WASHER, LOCK 2
20 27833 CONNECTOR, RED 50A W/O CONTACTS 1
21 578 321 000 SCREW, M6X16MM 1
22 140018 WASHER, LOCK 2
23 130698 BUSHING, SNAP 4
24 602887 BRACKET 1
25 140553 SCREW, 1/4-20X1/2 2
26 140016 WASHER, LOCK 1
27 602871 CABLE, BATTERY #6 BLACKX20" 1
28 578427 STANDOFF 1
29 602872 CABLE, BATTERY #6 REDX28" 1
30 630121 CHARGER, 115V 60HZ 20 AMP 1
31 601991 TRAY, BATTERY 1
32 600394 BATTERY, 12V 215A 2
33 130364 CABLE, BATTERY #6 BLACKX15" 1
34 140539 NUT, 6-32 KEP 2
35 603224 O-RING .929 ID X .996 OD 1
Recommended Stock Item
OPTIONS (Not Shown)
OPCIONES (No Se Muestran)
REF PART # DESCRIPTION QTY.
N/S 602993 KIT, KEY SWITCH 1
N/S 604357 KIT, AIR–FILLED TIRE 1
N/S 604259 KIT, FOAM–FILLED TIRE 1
N/S 602999 KIT, HOUR METER 1
N/S 603074 KIT, LOW VOLTAGE CUTOFF 1
N/S 602995 KIT, EMERGENCY STOP 1
N/S 602898 KIT, 5500 CONVERSION 1
N/S 602899 KIT, 5520 CONVERSION 1
Home
Find...
Go To..
