Tesco VCBL1411 User manual

Bagless Cylinder
Vacuum Cleaner
USER GUIDE
VCBL1411

IMPORTANT SAFETY INFORMATION
To reduce the risk of fire, electrical shock, or injury:
$
$
$
$
$
$
$
$
$
$
$
$
$
$
$
$
$
Read all the instructions carefully before using your
appliance and keep them for future reference. If you pass
the product on to a third party, include this manual.
Unplug the appliance from the mains supply when not in
use, removing or attaching filters, accessories, the dust cup
and before cleaning any part of the appliance.
When unplugging, hold the plug top, not the power cord.
Do not immerse the body of the cleaner or the electrical
cord or plug in water or liquids.
Never leave the cleaner unattended when it is connected to
the electricity supply.
Do not use outdoors in damp or wet weather
Do not use your appliance indoors in damp or wet
conditions.
Do not use attachments or accessories not recommended
by the manufacturer.
Close supervision is necessary when an appliance is used
near children. Children should not operate this appliance.
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
use of the appliance by a person responsible for their
safety.
Children should be supervised to ensure that they do not
play with the appliance.
This appliance is for household use. Do not use for any
purpose not expressly specified in this manual.
There are no user serviceable parts in this appliance.
Unauthorised dismantling or servicing will void the warranty.
If the supply cord is damaged, it must be replaced by the
manufacturer or its service agent or a similarly qualified
person in order to avoid a hazard
Refer all servicing which involves the taking or putting on of
parts (other than those specifically referred to in this manual),
to a qualified repair person or approved service centre.
Do not use attachments or accessories which are not
recommended by the manufacturer. They may cause
malfunction or injury.
Do not use harsh abrasives, or caustic cleaners when
cleaning this appliance.
Store the appliance away from direct sunlight, with all
accessories detached and out of the reach of children.
Before using this appliance ensure that the voltage of your
electricity supply is the same as that indicated on the rating
plate of the appliance.
Class II construction double insulated. This product
must not be connected to earth.
$
Electrical Information
.
VCBL1411
220-240 V AC 50Hz
1200W (nom):1400W( max)
SPECIFICATIONS
Model:
Voltage:
Power:
Net Weight: 4.0 Kg
VCBL1411 Vacuum Cleaner User Guide
Page 2
When operating your cleaner:
$
$
$
$
$
$
$
$
$
$
$
$
$
$
$
$
$
$
$
$
$
$
Do NOT
Do NOT
Do NOT
Do NOT
Do NOT
Do NOT
Do NOT
Do NOT
Do NOT
Use only on dry, indoor surfaces.
Do NOT
Do NOT
Do NOT
Keep all vents openings and attachments free of dust,
lint, hair and anything else that may reduce air flow.
before
NEVER
use the vacuum cleaner if it has been dropped,
damaged, left outdoors, or dropped into water.
pull or carry the cleaner by the cord, close a door
on the cord, or pull the cord around sharp edges or corners.
Use the handle to carry and move the cleaner.
run the appliance over the power cord.
handle the mains plug or cleaner with wet hands.
use the vacuum cleaner to pick up large objects
or objects that are likely to damage the vacuum cleaner.
attempt to vacuum long hair, string, pieces of
cloth, etc. when vacuuming carpets or floors. These may
clog the vacuum cleaner.
Keep hair, loose clothing, jewellery, fingers, feet and all
parts of your body away from openings and moving parts.
vacuum hot items; e.g. cigarettes, matches, ashes.
vacuum hard or metal objects, nails pins, etc.
pick up toxic, or flammable materials or use in
the presence of explosive or toxic dust, liquids or vapour.
put any objects into openings.
use with any filters blocked.
use without all the filters in place.
Empty the Dust Cup before it reaches the MAX level.
Switch the cleaner off before plugging or unplugging the
vacuum cleaner into the mains supply.
Use extra care when vacuuming on stairs.
Keep the end of the hose and all attachments away from
your face and body.
If the appliance becomes clogged, switch off and unplug
the power cord clearing the obstruction.
leave the cleaner unattended while it is plugged
into the mains
!
IMPORTANT NOTICE - PLEASE READ BEFORE USING THIS PRODUCT!
THIS CLEANER WORKS BY SUCKING AIR AT HIGH PRESSURE THROUGH A POWERFUL MOTOR. FOR
EFFICIENT AND SAFE OPERATION IT IS ESSENTIAL THAT ALL THE AIRWAYS AND FILTERS ARE CLEANED
AT REGULAR INTERVALS AND THAT THE DUST IS EMPTIED THE DUST CONTAINER IS FULL
AND AFTER EVERY USE OF THE APPLIANCE.
FAILURE TO CLEAN THE FILTERS AND EMPTY THE DUST CONTAINER WILL RESTRICT THE AIRFLOW.
THIS WILL RESULT IN POOR CLEANER PERFORMANCE.
ANY DAMAGE CAUSED BY FAILURE TO CLEAN THE FILTERS, AIRWAYS AND DUST CONTAINER
AS SPECIFIED IN THESE INSTRUCTIONS WILL NOT BE COVERED BY THE WARRANTY.
BEFORE
LONG TERM NEGLECT WILL BLOCK THE AIRFLOW AND MAY DAMAGE THE CLEANER BEYOND
REPAIR.
!

Your Vacuum Cleaner and its accessories
Page 3
Flexible Hose
Handle
Unpacking The Cleaner
Remove all packaging from the appliance and accessories. Retain the packaging. If you dispose of it, do so according to any
recycling regulations.
Identify the cleaner components from the illus-trations. If any items are missing or damaged, contact your nearest Tesco store for
assistance. Please have your receipt ready when you call.
VCBL1411 Vacuum Cleaner User Guide
Floor
Brush
Extension Tubes
Flexible Hose
Hose Collar
Dust Cup Filter
Hose Inlet
Dust Cup Release Mains ON/OFF
Switch
Dust Cup
Cord Storage
Compartment
Air Outlet
Filter Cover
Carry
Handle Cord Rewind Switch
(under Handle)
Furniture Tool
Storage Hook

Page 4
Attaching and Removing the Flexible Hose
To Attach: To Remove:
Push the collar firmly into the Hose Inlet and check that the
collar snaps into place.
Press the spring latch in and remove the hose.
V
Assembling your Vacuum Cleaner
Never attach or remove accessories when the vacuum cleaner is switched on.
VCBL1411 Vacuum Cleaner User Guide
Attaching the Hose Extensions
You can use the cleaner using only the hose or with one
or both extension tube/s fitted.
Attach the handle to one tube
Attach the second tube similarly as required
Attach the Floor Brush
(if required)
Parking the Attachments Carrying the Cleaner
You can park the floor brush
when you are not using it on
the Storage Hook located at
the rear of the cleaner.
You can also store the cleaner
with the tube/s connected to
the floor brush which is in turn
attached to the hook.
Always carry the cleaner by the handle.
Attach the Furniture Tool
in the same way.

1:`To extend the power cord:
yellow
red
Never extend the cord
beyond the red mark or you
may damage the cord
winding mechanism.
2: To rewind the cord:
Make sure the dust cup is empty!
Setting the Suction Power
Floor Brush
Bare Floors:
Carpets:
Furniture Tool
Do NOT
Do NOT
Do NOT
Do NOT
MAX
If you suspect a blockage:
If this does not remove the blockage:
Gently pull the cord from the
recess located in the rear of the
cleaner. The cord has two marks.
The mark shows the
maximum safe length to which
you can extend the cord. If you
can see the mark the cord
has been lengthened too much.
Unplug the cord. The handle
incorporates the Cord Release. Press the handle down. Gently
guide the cord back by hand into the cleaner until it is fully
rewound. Do not let the cord return unaided or it may whip and
cause damage or injury.
(see Page 6)
Fit the appropriate attachments. Extend the power cord to a
usable length. Plug the mains plug into the mains point.
Press the Mains ON/OFF switch to switch the power ON.
(Press again to switch the power OFF)
.
The suction power can be increased or decreased by operating
the airflow slider in the hose grip.
Use a low setting for curtains and delicate fabrics.Use a
medium setting for long pile and velour carpets or soft textile
flooring tiles.
Use a high setting for rough short pile carpets, coir matting and
rugs, and hard bare floors.
Move the vacuum head back and forth over the surface. Use
even strokes.
The is adjustable for use on carpets or bare floors.
Press the
lever showing the Brush
Symbol. The brush will
appear.
Press the lever
showing the Floor symbol
to retract the floor brush.
The is a dual-purpose tool. Use it to vacuum
cushions, etc. The tool can be used with the brush on or it can
be removed if required removed for greater versatility.
attach or remove accessories when the vacuum
cleaner is switched on.
pull the cleaner around the room by the hose.
over extend the hose. Trying to reach beyond the
hose length could cause an accident.
Be especially careful on stairs.
pull or carry the cleaner by the cord, close a door on
the cord, or pull the cord around sharp edges or corners. Do
not over extend the cord. Switch the cleaner off and move it to a
closer power point. Use just enough cord to do the job.
Use the carry handle to lift or move the cleaner.
If you are moving the cleaner a long way or up a flight of stairs,
switch off, rewind the power cord and park the accessories.
(See Page 6).
Switch off and unplug the appliance.
Rewind the power cord.
Disconnect the accessories and store the cleaner in the
vertical position or place the cleaner normally with the
accessories in the parked position.
If the cleaner loses suction and the dust in the dust cup is below
the mark, this may be due to clogged filters or a
blockage.
Switch off and unplug
immediately. Empty the dust, check and clean the filters.
Check the
extension tubes and accessories visually and remove any
blockage with a stick or broom handle.
Using the Appliance
When vacuuming:
Using the Accessories
General Do's and Don'ts
Do not press- let the cleaner do the work.
Examine the dust level and empty the dust cup regularly.
NEVER let the dust exceed the MAX level
When you have finished vacuuming:
Empty the dust cup and clean the dust cup filters.
DO NOT operate if the suction is impaired.
$
$
$
$
(See Storage)
Clearing a Blockage
$
$
Page 5
Operating your Vacuum Cleaner
VCBL1411 Vacuum Cleaner User Guide
1
2
Slide on/off as required

Page 6
Empty the dust cup regularly to maintain the efficient
performance of the cleaner.
The maximum dirt
level is marked on the
Dust Cup.
Failure to do this will impair the efficiency of the
cleaner.
Press the lid release down and lift the lid up
Carefully remove the dust cup from the cleaner.
Invert the dust cup over a bin. Press the catch on the lid which
will pop open. Shake and tap the dust cup lightly to remove as
much dust as possible. Close the lid. If you are still vacuuming,
replace the cup.
You must empty the Dust Cup before the dirt reaches the
MAX mark.
Switch the cleaner off and unplug it.
Cleaning the Dust Cup Filter
The HEPA Filter stops nearly all dust particles and airborne
allergens from re-entering the air you breathe.
The HEPA Filter stops nearly all dust particles and airborne
allergens from re-entering the air you breathe.
Open the Dust Cup. Hold the funnel tube of the filter assembly.
Rotate the tube to the left (anti-clockwise) to unlock it. Lift the
filter assembly out.
Tap the filter on the edge of a bin to shake off any excess dust.
Brush out the HEPA filter with a soft brush. If the filter is soiled,
wash it under running water until it is thoroughly clean.
Allow the filter to dry and then re insert it into the Dust Cup.
When you have finished vacuuming you must clean the
dust cup filter. This is essential
NEVER replace a filter if it is damp.
VCBL1411 Vacuum Cleaner User Guide
UNLOCK
LOCK
Emptying the Dust Cup and Cleaning the Dust Cup Filters
UNLOCK
LOCK

Page 7
Cleaning the Inlet Filter
The Inlet filter is inside the cleaner. Whenever you remove
the Dust Cup, you should inspect this filter and clean it.
This filter should be cleaned regularly, and whenever it shows
any signs of dirt.
Lift the filter out, brush it thoroughly and if necessary wash it
under running water. Allow to dry fully.
If there is any dirt around the inlet cavity carefully brush it out.
This will help keep the internal airways clean and maintain top
cleaner performance.
When the filter is thoroughly dry replace it in the inlet. Press the
filter firmly in to ensure it is firmly trapped in place by the two
tetaining tabs in the inlet cavity.
NEVER replace a filter when it is wet or even damp.
The Exhaust filter is located at the rear of the cleaner,
This filter should be cleaned regularly, and whenever it shows
any signs of dirt.
Press down on the filter cover. Hinge it out and remove it
Lift the filter out , and wash it under running water. Allow to dry
fully.
Brush the outlet cavity out. This will help keep the internal
airways clean and maintain cleaner performance.
When the filter is dry, replace it in the cage.
The filter is a a two-part unit. When replacing the filter the
smooth side should be facing out.
NEVER replace a filter when it is wet or even damp.
Cleaning the Exhaust Filter
It is essential to inspect clean the filters regularly. The period between inspections will depend on how often and for how long you
use the cleaner. The motor inlet and exhaust
filters should be checked after every three cleaning sessions.
If the cleaner shows any sign of losing suction, switch off, check and clean the filters and if necessary, clear any blockage.
If a filter shows any sign of wear or damage, or clogging that ordinary cleaning cannot remove it should be replaced. Contact
the Tesco helpline number on the last page of this manual for assistance.
The filter in the dust cup should be cleaned whenever you empty the dust.
NEVER operate the cleaner with clogged filters, you could damage the cleaner motor.
VCBL1411 Vacuum Cleaner User Guide

Page 6
Tesco Stores Ltd,
Delamare Road, Cheshunt, Herts, EN8 9SL
Helpline: 0845 456 6767 (Calls cost up to 4p per minute from a BT landline, other providers may vary)
Service and spares
If you have difficulty obtaining replacement spares, filters
Your appliance is covered by a warranty for 12 months from
the date of purchase. If a fault develops during this period,
please return the unit to your nearest Tesco store together with
the original receipt as proof of purchase. This warranty in no
way affects your consumer rights
Waste electrical products should not be
disposed of with household waste.
e for details.
Produced after 13th August 2005. Waste
electrical products should not be disposed of with
household waste. Please recycle where facilities
exist. Check with your Local Authority or retailer for
recycling advice.
UK:
ROI:
, etc.
contact the TESCO electrical help line on 0845 456 6767.
Please have your purchase receipt with you when you call.
Separate
disposal facilities exist, for your nearest facilities see
www.recycle-more.co.uk or in-stor
Warranty
This appliance is intended only for household use. It must be
properly installed and operated in accordance with these
instructions. Failure to do this will invalidate the warranty.
Page 8
OPERATING CAUTIONS
$
$
$
NEVER
If an obstruction occurs during cleaning:
operate the cleaner with damaged filters or with a filter missing
Use approved filters and regularly clean and replace them.
Turn the cleaner OFF and unplug. Check the dust level. Empty the dust cup. Check
the hose and the tubes for blockage and clear these manually following the instructions previously given..
When you have finished Vacuuming:
Switch the cleaner off and unplug from the mains.
Empty the dust cup and clean the dust cup filters
Wipe the cleaner body with a damp cloth and dry thoroughly. Do NOT allow water or liquids to penetrate the vacuum cleaner.
This could be dangerous.
Store the cleaner safely out of the reach of children and pets.
The cleaner can be stored upright on its base with the hose and accessories disconnected and separately stored. Although the
cleaner may be stored fully assembled with the brush in the parked position this is not recommended.
VCBL1411 Vacuum Cleaner User Guide
AUTOMATIC SHUT-OFF SWITCH
There is a safety switch inside the cleaner to prevent the unit from being run with too high a vacuum rate. If the airways or filters get
clogged the pressure in the cleaner will be excessive and the safety switch will be turned on. The cleaner then will stop working to
protect the motor from overheating.
If this happens switch off and unplug the cleaner Allow the motor to cool down for one hour and clean the airways and
filters thoroughly. Plug the cleaner in again and switch on: the cleaner should now operate normally.
immediately.
NOTE: Repeated and excessive use of the cleaner in a blocked or semi-blocked state may cause the motor to fail
permanently.
