Tesco VCU10P User manual

UprightVacuum Cleaner
USER GUIDE
VCU10P

VCU10P Vacuum Cleaner User Guide
Page 2Page 2
IMPORTANT SAFETY INFORMATION $There are no user serviceable parts in this appliance.
Unauthorised dismantling or servicing will void the warranty.
To reduce the risk of fire, electrical shock, or injury:
$If the supply cord is damaged, it must be replaced by the
$Read all the instructions carefully before using your
manufacturer or its service agent or a similarly qualified
appliance and keep them for future reference. If you pass
person in order to avoid a hazard
the product on to a third party, include this manual.
$Refer all servicing which involves the taking or putting on of
$Unplug the appliance from the mains supply when not in
parts (other than those specifically referred to in this manual),
use, removing or attaching filters, accessories, the dust cup
to a qualified repair person or approved service centre.
and before cleaning any part of the appliance.
$Do not use attachments or accessories which are not
$When unplugging, hold the plug top, not the power cord.
recommended by the manufacturer. They may cause
$Do not immerse the body of the cleaner or the electrical malfunction or injury.
cord or plug in water or liquids.
$Do not use harsh abrasives, or caustic cleaners when
$Never leave the cleaner unattended when it is connected to cleaning this appliance.
the electricity supply.
$Store the appliance away from direct sunlight, with all
$Do not use outdoors in damp or wet weather accessories detached and out of the reach of children.
$Do not use your appliance indoors in damp or wet
conditions. Electrical Information
$Do not use attachments or accessories not recommended Before using this appliance ensure that the voltage of your
by the manufacturer. electricity supply is the same as that indicated on the rating
$Close supervision is necessary when an appliance is used plate of the appliance.
near children. Children should not operate this appliance.
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not
play with the appliance. Class II construction double insulated. This product
$This appliance is for household use. Do not use for any must not be connected to earth.
purpose not expressly specified in this manual.
$
$
SPECIFICATIONS
Model: VCU10P
Voltage: 220-240 V AC 50Hz
Power: 1800W (max) 1600W (nom)
Net Weight: 7.5 kg
When operating your cleaner:
$Do NOT use the vacuum cleaner if it has been dropped, $Use only on dry, indoor surfaces.
damaged, left outdoors, or dropped into water. $Do NOT put any objects into openings.
$Do NOT pull or carry the cleaner by the cord, close a door $Do NOT use with any filters blocked.
on the cord, or pull the cord around sharp edges or corners. $Do NOT use without all the filters in place.
$Use the handle to carry and move the cleaner. Before use check that the dust cup is empty and empty it
$Do NOT run the appliance over the power cord. frequently during use.
$Do NOT handle the mains plug or cleaner with wet hands. $Switch the cleaner off before plugging or unplugging the
$Do NOT use the vacuum cleaner to pick up large objects vacuum cleaner into the mains supply.
or objects that are likely to damage the vacuum cleaner. $Use extra care when vacuuming on stairs.
Do NOT attempt to vacuum long hair, string, pieces of $Keep all vents openings and attachments free of dust,
cloth, etc. when vacuuming carpets or floors. These may lint, hair and anything else that may reduce air flow.
clog the vacuum cleaner. $Keep the end of the hose and all attachments away from
$Keep hair, loose clothing, jewellery, fingers, feet and all your face and body.
parts of your body away from openings and moving parts. $If the appliance becomes clogged, switch off and unplug
$Do NOT vacuum hot items; e.g. cigarettes, matches, ashes. the power cord before clearing the obstruction.
$Do NOT vacuum hard or metal objects, nails pins, etc. $NEVER leave the cleaner unattended while it is plugged
$Do NOT pick up toxic, or flammable materials or use in into the mains
the presence of explosive or toxic dust, liquids or vapour.
$
$
!
IMPORTANT NOTICE - PLEASE READ BEFORE USING THIS PRODUCT!
THIS CLEANER WORKS BY SUCKING AIR AT HIGH PRESSURE THROUGH A POWERFUL MOTOR. FOR
EFFICIENT AND SAFE OPERATION IT IS ESSENTIAL THAT ALL THE AIRWAYS AND FILTERS ARE CLEANED
AT REGULAR INTERVALS AND THAT THE DUST IS EMPTIED BEFORE THE DUST CUP IS FULL. DO NOT
USE THE CLEANER WHEN THE DUST BAG FULL INDICATOR IS ON.
FAILURE TO CLEAN THE FILTERS AND EMPTY THE DUST CUP IN GOOD TIME WILL RESTRICT THE
AIRFLOW AND RESULT IN POOR CLEANER PERFORMANCE.
LONG TERM NEGLECT WILL BLOCK THE AIRFLOW AND MAY DAMAGE THE CLEANER BEYOND
REPAIR. DAMAGE CAUSED BY FAILURE TO AND TO
AS SPECIFIED IN THESE INSTRUCTIONS WILL NOT BE COVERED BY THE WARRANTY.
REPLACE THE DUST CUP CLEAN THE FILTERS, AND
AIRWAYS
!

Your Vacuum Cleaner and its accessories.
Mains ON/OFF
Switch
Dust Cup
Release Button
Dust Cup Handle
Exhaust
Filter Cover
Dust Cup
Carpet Height
Adjustor
2 Piece Tube
Flexible Hose
Handle
Power
Cord Hook
Flexible Hose
Power Cord
Carrying
Handle
Upper Power
Cord Cleat
Handle
Release
Upholstery
Brush
Lower Power
Cord Cleat
VCU10P Vacuum Cleaner User Guide
Crevice Tool
(stored in tube)
Dust Trap
Unpacking and Assembly
Unpack the appliance and accessories. Retain the
packaging. If you dispose of it, do so obey recycling
regulations. Identify the cleaner components from
the illustrations. If items are missing or damaged,
contact your nearest Tesco store for assistance.
Please have your receipt ready when you call.
1. Press the upper handle release and raise the
handle vertically until it clicks into place.
2. Assemble the two piece tube and crevice tool as
shown. Insert this into the rear retaining boss.
3. Press the release at the top of the Dust Cup and
lift the dust cup out slightly. Replace the cup and
ensure it clicks firmly into position.
4: The Turbo brush is in a holder. Clip this holder
onto the handle ensuring the slots in the holder latch
firmly onto the raised bosses in the handle.
5. Coil the hose around the cleaner as shown in the
top RH picture and insert the hose handle into the
front retaining boss.
5. Raise both the Upper and Lower Power Cord
cleats vertical and coil the cable round the cleats.
Your cleaner is now ready for use.
Page 3
Adjustable
Upper Handle
Upper
Handle Release
Hose Guide
Turbo Brush
RAISE
LOWER
PRESS
CREVICE
TOOL
2
3
1
HEPA Filter Brush
(packed separately)
4

2. ANGLE
ADJUSTING THE CLEANER ANGLE
1. PRESS
Operating the Cleaner
Before u s i n g your
cleaner: Set the cleaner
fully upright.
Slide the Mains ON/OFF
switch on the cleaner
handle up to switch the
cleaner OFF.
Turn the quick release cord holders through 180º and release
the power cord.
For greater convenience, both upper and
lower cord holders are quick release.
Uncoil the power cord fully.
Plug the power cord into the electrical
outlet.
Switch on at the mains point.
Switch on your cleaner: When you wish to move the cleaner or take a break:
Slide the Mains ON/OFF switch on the cleaner handle down Switch off. Return the cleaner to the upright position and
to switch the cleaner. ON.ensure it locks in place. This raises the brush clear of the floor.
Set the cleaner height: NEVER leave the cleaner in a lowered position and
With your foot, depress the handle release pedal as shown switched on as the brush could scratch the floor surface.
For convenience, you may hook the cable over the cable hook
on the rear of the handle. This will help
stop the cable snagging.
The cleaner can now be angled for normal operation and for
low level cleaning.
To get the cleaner to lie flat, press the release pedal once,
partially lower the handle and then depress the pedal again.
Vacuuming Carpets and Hard Floors
Set the vacuuming height before commencing cleaning.
Always check the carpet or floor covering manufacturer's
recommended cleaning instructions before vacuuming.
CAUTION: Setting the vacuuming height should only be
done when the cleaner is switched off at the mains.
Stand the cleaner fully upright.
Turn the carpet height adjustment knob to the desired setting.
Suggested Pile Height Settings: You may need to raise the
brush height for easier access to scatter rugs, etc.
Long pile, deep scatter rugs.
CAUTION. Do not attempt to vacuum rubber bands, long
Medium to long pile. hair, string, pieces of cloth, etc. These will snag in the
Short to medium pile. bristles and may even stop the brush rotating altogether.
If this happens, switch the cleaner off immediately. Invert the
Short pile.
cleaner and completely remove all obstructions from the brush
Hard floors. before switching the cleaner on again.
SHORT
PILE
MEDIUM
PILE
HARD
FLOOR
LONG
PILE
Page 4
Using your Vacuum Cleaner
VCU10P Vacuum Cleaner User Guide
BRUSH
CONTROL

The Turbo Brush
Using the accessories
The turbo brush iis a smaller version of the rotating brush in
Switch the cleaner OFF at your upright vacuum cleaner. It is designed to be used with an
the mains switch on the extension tube fitted to the hose. A powerful impeller action
handle. rotates the turbo brush at high speed and this gives a powerful
Place the cleaner fully in the cleaning action. It is ideal for deep cleaning small floor mats
upright position to lift the and for difficult carpeted areas where the normal vacuum
brush clear of the floor. cleaner cannot reach.
Set the Brush Control knob To fit the turbo brush: Switch the Vacuum cleaner OFF.
to Long Pile. Remove the brush from the cradle. Push the brush firmly on to
Lift out the hose and free it the extension tube.
from the retaining clip at
the side of the cleaner.
If you wish to use the
e x t e n s i o n t u b e s a n d
accessories, lift the tube
assembly out and attach it to
the hose.
Accessory Brush
The tool can be used Using the Turbo Brush.
in two ways:
Place the brush on the surface to be cleaned and then switch
As a dusting brush the cleaner on. Keep your feet well behind the brush when
for furniture and vacuuming. After cleaning, switch off before lifting the brush
small objects. off, removing it from the extension tube and replacing it in the
As an upholstery tool cradle.
for soft furniture. It is
an excellent tool for
removing unwanted
pet hair.
Do not use it on
delicate fabrics that
may snag or on
polished wooden
surfaces which may
scratch.
General Do's and Don'ts
Never attach or remove accessories when the vacuum
cleaner is switched on.
Do NOT pull the vacuum cleaner around the room by the hose
as it could tip over and cause damage.
Do NOT over extend the hose. Trying to reach beyond the
hose length could cause the vacuum to tip over.
Do NOT pull or carry the cleaner by the cord, close a door on
the cord, or pull the cord around sharp edges or corners.
Use the carry handle when lifting or moving the cleaner
between different locations.
Extension Tubes NEVER lift the cleaner with the upper handle only. It could
You can use the handle on its own, or in combination with one release and cause injury.
or both tubes. Be especially careful on stairs.
Crevice Tool If you are moving the cleaner a long
Use the crevice tool for radiators, crevices, between cushions, way or up a flight of stairs, switch off,
joins in stair treads, etc. Store the crevice tool on the accessory fold the upper handle down, wind the
brush holder when you are using the accessory brush, power cord and stow the hose and
accessories.
VCU10P Vacuum Cleaner User Guide
Page 5
Hold the brush as shown
Push the brush head out with your thumb
Remove the brush to use the upholstery tool.
Reverse the procedure to re-assemble the brush.
Yo u c a n u s e t h e
accessory attachments
w i t h t h e h a n d l e
extended or folded
down - this position is
useful for cleaning
stairs etc.

Inlet Tube Blockage Upper Hose Blockage
At the base of the cleaner there is a clear area of tube. Check If the inlet tube is clear and there is still a blockage:
this visually. If there is a blockage, undo the four screws, 1. Lift out the extension tubes
remove the cover plate and clear all debris. Replace the tube 2.Lift the hose handle out at the lower port
carefully in the duct, then replace the cover and fasten the 3. Press the two tabs at either side of the hose where it enters
screws tightly. the upper inlet port of the cleaner.
4. Lift the hose out at the upper inlet port
5. Examine the tube and both ports and clear any blockage.
9.Now replace the hose and extension tubes.
VCU10P Vacuum Cleaner User Guide
When you have finished Vacuuming:
Set the cleaner fully upright.
Switch the cleaner off at the handle.
Unplug from the mains.
Set the cleats vertical and rewind the cord around the upper and
lower cleats.
Re-assemble the hose and attachments if necessary.
Fold the upper handle down fully.
Empty the dust cup and clean the dust cup filters (see Pages 7 & 8)
Wipe the cleaner body with a damp cloth and dry thoroughly.
Store the cleaner safely out of the reach if children and pets.
If the cleaner loses suction and the dust in the dust cup is below the MAX mark, this may be due to clogged filters or a blockage. DO NOT
operate the cleaner if the suction is impaired.
If you suspect a blockage:
$Set the cleaner upright, switch off and unplug immediately. Empty the dust, check all the filters and clean them.
If this does not remove the blockage:
$Check the extension tubes and accessories visually and remove any blockage with a stick or broom handle.
$Invert the cleaner, inspect the brush area, and remove any obstruction from the bristles or the brush roller.
Clearing a Blockage
Cover Plate removed
showing tube
Page 6
IMPORTANT-Motor Thermostat
If the vacuum cleaner should overheat, the protective thermostat will automatically turn the unit off.
If this occurs: Switch off and unplug. Check and clear any blockage and clean/replace the filters.
Wait at least 45 minutes before attempting to reuse the cleaner. After the cleaner has cooled down plug in and
switch on. The vacuum should now start.
If the vacuum does not start: contact the help line on 0845 601 2549.
12
33
4

Emptying the Dust Cup
Set the cleaner upright, switch
off and unplug.
Empty the dust cup regularly to
m a i n t a i n t h e e f f i c i e n t
performance of the cleaner.
The maximum dirt level is
marked on the Dust Cup.
You must empty the Dust Cup
before the dirt reaches the
MAX mark.
Failure to do this may impair the
efficiency of the cleaner.
Hold the Dust up
by the handle and
press the dust cUp
r e l e a s e c a t c h
down.
Hinge the cup out of its cradle.
Carefully remove the dust cup from the cleaner, keeping it
vertical.
Invert the dust cup over a bin. Press the catch on the lid which
will pop open. Shake and tap the dust cup lightly to remove as
much dust as possible. Close the lid.
If you are still vacuuming, replace the cup.
When you have finished cleaning you must clean the two
filters in the cup after emptying it. This is essential. Refer to
the next page for details.
Cleaning and Replacing the Filters
It is essential to inspect clean the filters regularly. The period between inspections will depend on how often and for how long you
use the cleaner. The filter in the dust cup should be cleaned whenever you empty the dust. The motor inlet and exhaust
filters should be checked after every three cleaning sessions.
If the cleaner shows any sign of losing suction, switch off, check and clean the filters and if necessary, clear any blockage.
NEVER operate the cleaner with clogged filters, you could damage the cleaner motor.
Before you examine or clean the filters, Set the cleaner fully upright. Switch off and unplug from the mains.
Filter Locations
Debris Screen
Pre-Motor Filter
Exhaust Filter
(behind cover)
HEPA Filter
(Inside Dust Cup Lid)
The HEPA Filter stops nearly all dust
particles and airborne allergens from
re-entering the air you breathe.
Clean this filter every time you use
the cleaner. Failure to do this will
impair performance and may
damage the cleaner motor.
You should also check and clean the
debris screen regularly.
VCU10P Vacuum Cleaner User Guide
Page 7
1. Press to Open
2. Tap and shake
to remove dust

VCU10P Vacuum Cleaner User Guide
Debris Screen
Cleaning the Dust Cup Filters
Empty the Dust
Open the base of the cup over a
bin.
Shake out as much dust as
possible.
HEPA Filter Hold the dust cup firmly with one hand. Place your other hand
inside the cup and take hold of the debris screen tube.
Rotate the cup lid to
the right to the Rotate the debris screen firmly to the right to unlock it and then
UNLOCK position carefully withdraw the screen from the tube.
and lift the lid off.
Rotate the
filter to the
left to unlock
the filter from
the cup lid.
Remove the
filter.
Rinse the debris screen under the tap in lukewarm water to
remove any dust. The dust cup and dust cup cover can also be
washed in lukewarm water.
Do not use strong detergents. DO NOT place any part in a
dishwasher. Allow all parts to fully dry.
To replace the screen:
Thread the screen over the
vanes in the black inner
tube. Align the three lugs
with the slots in the cup and
turn fully anticlockwise to
lock firmly.
Replace the dust cup cover
on the dust cup and replace the assembled dust cup in the
At least once a month or when you notice a decrease in vacuum cleaner.
suction, wash the HEPA filter by running it under the tap. Run
the water on the dirty side until it runs clear. After washing allow
the HEPA Filter to fully air dry. (This may take up to 24 hours.)
Only when the filter is dry should you replace it in the Dust Cup.
The HEPA filter should be replaced at least every six months
(and ideally three) to keep your cleaner in peak condition.
Page 8
Hold the HEPA filter
over a bin.
Tap the hard plastic
underside of the filter
on the edge of a bin to
shake off any excess
dust. Use the supplied
cleaning brush to
remove all traces of
dust and debris from
the pleats of the filter.
UNLOCK
LOCK
LOCK
UNLOCK
LOCK
UNLOCK

VCU10P Vacuum Cleaner User Guide
Lift out
to clean
Cleaning Pre-Motor & Exhaust Filters
Check these filters whenever you remove the dust cup for
emptying and clean them when necessary.
A
B. Exhaust Filter
Press down on the tab and lift the cover off.
Lift the filter insert out from the cover.
Rinse in lukewarm water. A very soiled filter should be
thoroughly washed with fresh tepid water. with a drop of mild
detergent. Rinse well. Let the filter air dry for 24 hours.
Now re-install the filter insert in the cover and replace the cover
in the cleaner.
A. Pre-Motor Filter
Remove the dust cup. Lift the pre-motor filter insert out. Rinse in
lukewarm water. A very soiled filter should be thoroughly
washed with fresh tepid water. with a drop of mild detergent.
Rinse well. Let the filter air dry for 24 hours before re-installing.
B
Page 9
IMPORTANT NOTICE
If at any time you notice that the brush speed is slow and/or there is a loss of suction, this may be
caused by the brush getting clogged.
If this happens, switch the cleaner off and unplug it from the mains. Clean the brush area fully and
remove all obstructions before continuing to use the cleaner.
Prompt action will maintain cleaner performance and avoid any potential problems of belt slippage.

Changing the Brush Roller and Drive Belt
Sluggish speed and loss of suction may be caused by a worn or slack belt. If the cleaner does not pick up on carpets but is OK when
using the attachments this indicates a worn brush roller. These components are user replaceable.
DO NOT replace these components yourself unless you are confident that you can carry out this procedure satisfactorily.
Make sure the cleaner is switched off and unplugged from the mains before you start work. Protect the work surface if
necessary. You need a No2 Phillips screwdriver, and a small flat bladed screwdriver to carry out this procedure.
VCU10P Vacuum Cleaner User Guide
Stage 1. Remove the Deflector Plate
Slide the belt off the motor spindle.
If you are not replacing the belt, clean it carefully
with a dry cloth to remove any residue.
When you are removing or replacing the belt, twist
the belt on its side and slide the edge of the belt
around the end of the spindle.
Stage 3. Slide the Belt off the Motor
Page 10
Press the handle release twice to release the handle and lay it flat on the floor. Turn the cleaner over.
With a Phillips No. 2 screw driver remove the 3 screws on the plate as identified by the arrows.
Remove the deflector plate and lay it aside.
Deflector
Plate
Stage 2. Remove the Brush
With a small flat bladed screwdriver,
ease the Right end of the brush partially
out of its bearings.
Repeat for the Left edge.
Now lift out the brush with both hands.
Be careful as the belt is still under
tension. Pull out the brush from the belt.
MOTOR SPINDLE
BELT

VCU10P Vacuum Cleaner User Guide
Manoeuvre the belt over the spindle,
straighten it out and lay the belt flat on the
spindle.
Thread the brush through the belt.
Position the belt over the convex section of
the brush . Make sure the belt is not twisted
Stage 4. Replace the belt
Stage 5. Replace the Brush
A. Hold the brush in both hands. Pull the brush towards you
and partially insert the left hand side bearing of the brush into
its socket with your thumb. (This will place the belt under
tension, so you may have to use moderate pulling force.)
B. Slide your free hand to the right. Position the right hand side
bearing of the brush over its socket.
C. Press the Right hand bearing partially into the socket
D. Finally press both sides of the brush fully home.
Page 11
A
B
C
D
Stage 5. Re-assembly
Rotate the brush by hand to ensure that the mechanism moves freely and that the belt does not foul the guides and is central on the
motor spindle.
Now replace the deflection plate - see Stage 1 for details.
Before using the cleaner, switch it on and confirm that the brush rotates freely and that the brush height mechanism operates properly.

Tesco Stores Ltd,
Delamare Road, Cheshunt, Herts, EN8 9SL
UK: Waste electrical products should not be
Cleaning and storage disposed of with household waste.
e for details.
ROI: Produced after 13th August 2005. Waste
electrical products should not be disposed of with
household waste. Please recycle where facilities
exist. Check with your Local Authority or retailer for
recycling advice.
Your appliance is covered by a warranty for 12 months from
the date of purchase. If a fault develops during this period,
please return the unit to your nearest Tesco store together with
the original receipt as proof of purchase. This warranty in no
way affects your consumer rights
$The plastic outer body shell and the exterior surfaces of the
attachments may be cleaned with a barely damp cloth and
then dried thoroughly.
$Do NOT allow water or liquids to penetrate the vacuum
cleaner. This could be dangerous.
$Detach all accessories and store the appliance away from
direct sunlight, and out of the reach of children.
Warranty
This appliance is intended only for household use. It must be
properly installed and operated in accordance with these
instructions. Failure to do this will invalidate the warranty.
Separate
disposal facilities exist, for your nearest facilities see
www.recycle-more.co.uk or in-stor
OPERATING CAUTIONS
$NEVER operate the cleaner with damaged filters or with a filter missing
$Use approved filters and regularly clean and replace them.
$Wind the cord around the cleats after use.
If an obstruction occurs during cleaning: Turn the cleaner OFF and unplug. Check the dust level. Empty the dust cup. Check the
hose and the tubes for blockage and clear these manually following the instructions on Page 6.
If the vacuum cleaner should overheat, the protective thermostat will automatically turn the unit off.
If this occurs: Switch off and unplug. Check and clear any blockage and clean/replace the filters.
Wait at least 45 minutes before attempting to reuse the cleaner. After the cleaner has cooled down plug in and switch
on. The vacuum should now start.
After Use
Set the cleaner fully upright.
Switch the cleaner off at the handle.
Unplug from the mains.
Set the cleats vertical and rewind the cord around the upper and lower cleats.
Re-assemble the hose and attachments if necessary.
Fold the upper handle down fully.
Empty the dust cup and clean the dust cup filters (see Pages 7 & 8)
Wipe the cleaner body with a damp cloth and dry thoroughly.
Store the cleaner safely out of the reach if children and pets.
VCU10P Vacuum Cleaner User Guide
