5Operating Instructions
Switching on and off:
The probe measures radon concentration autonomously and communicates in wireless network only if
the switch is in position „I“( switch on). The switching on is signalized by LED diode „STAT“ according chart
below.
If the switch is in position „0“ (switch off) the probe doesn´t measure radon concentration and doesn´t
communicate in wireless network. In switching off mode the probe only keeps running real time for correct
date and time of records in case of switch it on again. By switching off the probe doesn´t lose previous
records of measurement. The switching on is signalized by LED diode „STAT“ according chart below.
It is possible to download data from probe over USB in both position of switch.
LED diode „STAT“:
It signalizes status radon probe according to following chart:
Antenna installation:
Supplied antenna is screwed on antenna connector. When installing antenna, hold antenna by knurled
end.
Power supply:
According to operation method the radon probe can be supplied:
1) By internal accumulator for portable use –Radon probe includes internal accumulator which is
able to ensure autonomous operation of probe for more than 12 months without charging.
Depends on frequency of wireless data downloading from probe. Accumulator is charged with USB
port and provided USB cable. The USB cable is possible to connect to PC or to delivered power
adapter. Status of accumulator and charging process are described in paragraph ´Basic
Maintenance/Accumulator charging´
2) By mains power supply 230V/50Hz for stationary use –Radon probe is permanently supplied by
delivered power adapter. Power adapter is connected to probe via provided USB cable. In case of
blackout internal accumulator ensures UPS function.
Configuration:
Setting and configuration is different according to operation way of radon probe.
If the probe is used for autonomous measurement and data downloading via USB interface then the
setting and configuration are realized by usbRADONview application. UsbRADONview application, drivers
and user manual with detail configuration description are free downloaded on website:
http://www.tesla.cz/.
If the probe is used for wireless measurement and wireless data downloading then setting and
configuration of probe and whole measuring system is realized by Central Unit connected to PC and
TERAview application. Central Unit is not included with package of probe and it is sold and delivered extra;
see http://www.tesla.cz/. TERAview application, drivers and user manual with detail configuration
description are free downloaded on website: http://www.tesla.cz/. For successful probe configuration in
measuring system is essential to know probe radio channel number (communication wireless channel) and
P2P address (identification in wireless net). Both parameters are printed out on probe serial number plate.
Probe radio channel number is possible to change by TERAview application and it must be identical to
central unit radio channel number. P2P address is permanent and it can occur in one big wireless net only
once. Central Unit P2P address can be identical to P2P address of other elements in network.
