TESTO 480 User manual

testo 480 · Climate measuring instrument
Instruction manual

2

1 Contents
3
1Contents
1Contents ...................................................................................................3
2Safety and the environment....................................................................5
2.1. About this document........................................................................5
2.2. Ensure safety...................................................................................6
2.3. Protecting the environment..............................................................7
3Specifications ..........................................................................................7
3.1. Use ..................................................................................................7
3.2. Technical data .................................................................................8
4Product description...............................................................................11
4.1. Overview .......................................................................................11
4.1.1. Hand instrument................................................................................................11
4.1.2. Instrument connections and interfaces .............................................................12
4.1.3. Controls .............................................................................................................13
4.1.4. Display...............................................................................................................14
5First steps ..............................................................................................16
5.1. Commissioning..............................................................................16
5.2. Getting to know the product...........................................................18
5.2.1. Navigating in the menu .....................................................................................18
5.2.2. Calling up a function .........................................................................................19
5.2.3. Exit the menu ....................................................................................................19
5.2.4. Switching to another tab ...................................................................................19
5.2.5. Entering values .................................................................................................19
5.2.6. Saving values ....................................................................................................20
6Using the product..................................................................................20
6.1. Performing settings........................................................................20
6.2. Setting the measurement display ..................................................22
6.2.1. Calculated measurement parameters ..............................................................23
6.3. Favourites tab................................................................................25
6.4. Probe menu...................................................................................25
6.5. Explorer menu ...............................................................................27
6.6. Measurements & Measuring programs..........................................30
6.6.1. Retaining (“holding”) measurement values.......................................................30
6.6.2. Quick back-up ...................................................................................................30
6.6.3. Measuring program ...........................................................................................31
6.6.4. Grid measurement ............................................................................................32
6.6.5. Turbulence measurement .................................................................................37
6.6.6. Pitot tube measurement....................................................................................38
6.6.7. Measurement with the funnel............................................................................39
6.6.8. Pressure measurement.....................................................................................40
6.6.9. Determination of volume flow using differential pressure and k factor.............41
6.6.10. CO2measurement ............................................................................................43

1 Contents
4
6.6.11. WBGT measurement ........................................................................................44
6.6.12. PMV/PPD measurement ..................................................................................45
6.6.1. Calculating the normal effective temperature (NET) ........................................49
6.6.2. Saving measurement values ............................................................................51
6.6.3. Printing measurement values ...........................................................................52
6.6.4. Display measuring values graphically ..............................................................52
6.6.5. Transferring measurement values....................................................................53
7Maintaining the product ....................................................................... 54
7.1.1. Battery care ......................................................................................................54
7.1.2. Carrying out humidity adjustment .....................................................................54
7.1.3. Carrying out a firmware update ........................................................................55
8Tips and assistance.............................................................................. 56
8.1. Questions and answers ................................................................ 56
8.2. Accessories and spare parts......................................................... 57

2 Safety and the environment
5
2Safety and the environment
2.1. About this document
Symbols and writing standards
Representation Explanation
Warning advice, risk level according to the
signal word:
Warning! Serious physical injury may occur.
Caution! Slight physical injury or damage to
the equipment may occur.
> Implement the specified precautionary
measures.
Note: Basic or further information.
1. ...
2. ...
Action: more steps, the sequence must be
followed.
> ... Action: a step or an optional step.
- ... Result of an action.
Menu Elements of the instrument, the instrument
display or the program interface.
[OK] Control keys of the instrument or buttons of
the program interface.
... | ...
Functions/paths within a menu.
“...” Example entries
Warnings
Always pay attention to information that is marked by the following
warnings with warning pictograms. Implement the specified
precautionary measures.
Representation Explanation
NOTICE indicates circumstances that may lead to
damage to the products
CAUTION
indicates potential minor injuries

2 Safety and the environment
6
2.2. Ensure safety
> Only operate the product properly, for its intended purpose and
within the parameters specified in the technical data. Do not
use any force.
> Dangers may also arise from the systems being measured or
the measuring environment: Note the safety regulations valid in
your area when performing the measurements.
> Do not perform contact measurements on non-insulated, live
parts.
> Do not store the product together with solvents. Do not use any
desiccants.
> Carry out only the maintenance and repair work on this
instrument that is described in the documentation. Follow the
prescribed steps exactly. Use only original spare parts
from Testo.
> Temperatures given on probes relate only to the measuring
range of the sensors. Do not expose handles and feed lines to
temperatures in excess of 40 °C (104 °F), unless they are
expressly permitted for higher temperatures.
> After the final measurement, allow probes and probe shafts to
cool down sufficiently in order to avoid burns from the hot
sensor tip or the probe shaft.
> Improper use of rechargeable batteries can lead to destruction
or injuries by means of current surges, fire or escaping
chemicals. The following instructions must be observed to avoid
such hazards:
• Only use in accordance with the directions in the instruction
manual.
• Do not short, take apart or modify.
• Do not expose to heavy impacts, water, fire or temperatures
above 60 °C.
• Do not store in the proximity of metal objects.
• Do not use leaky or damaged rechargeable batteries. In the
event of contact with battery acid: Thoroughly wash affected
area with water and consult a doctor, if necessary.
• Only charge in the instrument or the recommended charging
station.
• Immediately stop the charging process if this is not
completed in the given time.

3 Specifications
7
• In the event of improper function or signs of overheating,
immediately remove the rechargeable battery from the
measuring instrument/charging station. Caution:
Rechargeable battery may be hot!
Use
> Please read this documentation through carefully and
familiarize yourself with the product before putting it to use. Pay
particular attention to the safety instructions and warning advice
in order to prevent injuries and damage to the products.
> Keep this document to hand so that you can refer to it when
necessary.
> Hand this documentation on to any subsequent users of the
product.
2.3. Protecting the environment
> Dispose of faulty rechargeable batteries/spent batteries in
accordance with the valid legal specifications.
> At the end of its useful life, send the product to the separate
collection for electric and electronic devices (observe local
regulations) or return the product to Testo for disposal.
3Specifications
3.1. Use
The testo 480 is a measuring instrument for measuring climate-
related parameters. The testo 480 is ideal for comfort level
measurements for the workplace evaluation and flow
measurements in and at ventilation and air-conditioning systems.
The instrument is only to be used by qualified expert personnel.
Then product must not be used in explosive environments!

3 Specifications
8
3.2. Technical data
Hand-held instrument
Feature Values
Measurement
parameters
• Temperature (°C, °F, difference-°C,
difference-°F)
• Humidity (%RH, td°C, td°F, wet bulb °C,
wet bulb °F, g/m3, g/ft3, g/kg, g/lb, kJ/kg,
BTU/lb, ppm, Vol%)
• Flow velocity (m/s, ft/m)
• Pressure (Pa, hPa, mbar, kPa, bar, psi,
inH2O, inHg, mmH2O, Torr)
• CO2 (ppm, Vol%)
• Lux (Lux, footcandle)
Sensor connections • 2x temperature (TC type K)
• 1x differential pressure
• 3x digital probes (flow, humidity,
temperature, CO2, Lux, absolute
pressure)
Interfaces • Mini USB
• Infrared for testo report printer
• SD card
• Mains connection
Internal memory
capacity
1.8 GB (approx. 60,000,000 measuring
values)
Rechargeable battery
life
Approx. 17 h (hand instrument without
probe with 50% display brightness)
Measuring cycle 0.5 s
Operating
temperature
0 to +40 °C
Storage temperature -20 to +60 °C
Dimensions 81 mm x 235 mm x 39 mm
Housing material ABS, TPE, PMMA
Weight Approx. 435 g
IP protection class
30 (with connected probes)

3 Specifications
9
Integrated measurement (at 22 °C, ±1 digit)
Feature Values
Temperature (TC
type K; internal
reference point
measurement:
measuring range 0 to
+40 °C, accuracy
±0.5 °C)
Measuring range: -200.0 to +1370.0 °C
Accuracy: ±(0.3 °C + 0.1 % of meas. val.)
Resolution: 0.1 °C
The accuracy information applies in
an adjusted, stable temperature
state. Plugging in the mains unit,
charging the battery or adding
digital probes can distort this
temporarily, and additional errors
may occur.
Differential pressure Measuring range: -100 to +100 hPa
Accuracy1: 0...+25 hPa:
±(0,3 Pa + 1% of meas. val.)
+25.001 to +100hPa:
±(0,1 hPa + 1.5% of meas. val.)
Resolution: 0.001 hPa
The accuracy specification applies
immediately after zeroing of the
sensor. For long-term
measurements, mains operation
with fully-charged battery is
recommended.
Temperature coefficient: <0.01%
FS/K typical
Absolute pressure Measuring range: +700 to +1100 hPa
Accuracy: ±3 hPa
Resolution: 0.1 hPa
1Only with positive pressures

3 Specifications
10
Standards, tests, warranty
Feature
Values
EU Directive 2014/30/EC
Vibration IEC 60068-2-6
Mains unit (0554 8808) for continuous measurements and
battery charging
Feature Values
Output voltage 5 V / 4 A
Lithium battery
Feature Values
Charging option In instrument
Charge time Approx. 8 h
Battery life Approx. 17 h (hand instrument without
probe with 50% display brightness)
Ambient temperature 0 – 40 °C / 32 – 104 °F
Long-term storage
temperature
<23 °C / <73 °F

4 Product description
11
4Product description
4.1. Overview
4.1.1. Hand instrument
1 Display
2 Mini USB interface (right-hand side of instrument)
3 Control buttons and trackpad (navigation field)
4 SD card slot (right-hand side of instrument)

4 Product description
12
5 Magnetic holder (on back)
WARNING
Magnetic field
May be harmful to those with pacemakers.
> Keep a minimum distance of 15 cm between
pacemaker and instrument.
ATTENTION
Magnetic field
Damage to other devices!
>Keep a safe distance away from products which could
be damaged by the effects of magnetism (e.g. monitors,
computers or credit cards).
4.1.2. Instrument connections and interfaces
Top
1 Probe sockets for digital probes
2 IR interface for printouts with testo report printer (art. no. 0554
0549)
CAUTION
Risk of injury from infrared beam!
> Do not direct infrared beam at human eyes!

4 Product description
13
Bottom
1 TC connection for temperature probe type K
2 Connections for differential pressure (+/- sign on the instrument)
3 Mains socket
4 Status LED, mains socket
Status Explanation
LED off Rechargeable battery is not charging
LED on,
lights up
Rechargeable battery is charging
LED on,
flashes
slowly
Rechargeable battery is not charging,
instrument/battery temperature too high
LED on,
flashes
quickly
Rechargeable battery is not charging, battery
faulty
4.1.3. Controls
Button
Functions
[ ] Switch measuring instrument on / off
[ ]
The following symbols are used to operate the trackpad.
see Navigating in the menu, page 18.
Move your finger on the trackpad to scroll up or down
on the screen.
[ ] Move your finger smoothly over the trackpad
from top to bottom: scrolls down.
Move your finger smoothly over the trackpad
from bottom to top: scrolls up.
[ ] Move your finger smoothly over the trackpad
from left to right: scrolls right.
Move your finger smoothly over the trackpad
from right to left: scrolls left.

4 Product description
14
Button Functions
[ ] Briefly touch the trackpad with your finger to
confirm the selection. When confirming, you
should notice a click similarly to pressing a
button.
[Esc] Back, cancel function
[ ] Open main menu, save settings
[–]
Configurable button for quick access to a frequently
used function. The button is not preassigned at the
factory. Configure button, see Performing settings, page
20.
[ ]
Explorer is opened, see Explorer menu, page 27.
4.1.4. Display
Status line and tabs
1 Status bar (dark grey background):
Icon Explanation
There is no SD card in the instrument
Printing
Date and time
Battery operation
Indication of remaining capacity of the rech. batt.
by the colour and fill level of the battery symbol
(green = 5-100%, red = < 5%)
Mains operation
Indication of remaining capacity of rech. batt:
see above
2 Tabs:

4 Product description
15
Tab name Explanation
(Favourites tab) The Favourites tab is the actual work
area for the instrument see
Favourites
tab, page 25.
Here, measurement values of various
probes can be combined into one
measurement, and measuring
programs can be run, saved and
printed.
Int Measurement values of the internal
sensors and connected TC probes
are displayed.
-881 (Example; the last
three digits of the serial
number of the probe
are displayed. The full
serial number of the
probe is shown on a
label on the probe.)
An additional tab is displayed for each
connected probe with the
measurement values of the probe and
the calculated parameters. The tabs
are displayed in the order in which the
probes were connected to the
instrument.
3 Info field of register tabs: display of the selected measuring
location/measuring point. The displayed measuring point can be
selected in Explorer, see Explorer menu, page 27.
Measuring view
1 Line number
2 Indication that the reading is also displayed in the Favourites
tab.
3 Reading
4 Measurement parameter
5 Probe designation
6 Unit
The measuring view can be changed individually for each tab, see
Setting the measurement display, page 22.

5 First steps
16
5First steps
5.1. Commissioning
Initial charging of rechargeable battery
The testo 480 is delivered with a partially charged battery. Charge
the battery fully before using it for the first time.
1. Connect the mains unit to the mains socket (3).
2. Connect the mains plug to a power socket.
- Battery charging is started: status LED (4) lights up.
- The battery is fully charged: status LED (4) is off.
3. Disconnect instrument from the mains unit.
- After initial charging of the rech. battery, the instrument is ready
for use.
Switching on
1. Switch the instrument on with [ ].
- The start screen appears.
For initial commissioning or after a factory reset, the Initial
operation menu is opened automatically. Set the required menu
language:
> Call up the required selection list with [ ].
2. Select the language with [ ] and confirm with [ ].
- Instrument language is changed.
3. Set the date and time with [ ] and [ ] and confirm with [
].
4. Select ISO/US units with [ ] and confirm with [ ].
The setting only relates to the measured values and can
be individually adjusted for each measurement value if
required.
5. [ ] → Save and close.

5 First steps
17
- The current measurement values are displayed. The instrument
is now operational.
Switching off
Unsaved measurement values are lost when the
instrument is switched off.
> Switch the instrument off with [ ].
Connecting probes / sensors
Probes are detected automatically by the instrument.
Make sure the connections are secure, but do not use force!
> Insert the probe connector into the probe socket:
• Bottom of the instrument: TC probe (type K)
• Top of the instrument: digital probe:
Push/pull plug-in connections protect digital probes from
being unintentionally disconnected from the instrument.
> Connect pressure tubes to +and -.
Caution! Danger of injury caused by the pressure tube
jumping away from the connection socket!
> Ensure correct connection.
Removing probes
Thermocouple (TC) probe:
> Unplug connector from the socket.
Digital probe:
1. Pull back outer sleeve to release the push/pull plug-in
connection.
2. Unplug connector from the socket.

5 First steps
18
Connecting the mains unit
If the mains unit is connected, the instrument is powered
automatically via the mains unit.
When power is supplied via the mains unit, the instrument
may heat up. This may increase the measurement
uncertainty during TC measurement.
1. Plug the mains unit instrument connector (art. no. 0554 8808)
into the mains socket on the bottom of the instrument.
2. Plug the mains unit plug into a mains socket.
- The instrument is supplied with power via the mains unit and
battery charging begins automatically.
5.2. Getting to know the product
5.2.1. Navigating in the menu
1. Press [ ].
- The Options menu is opened. Selected function is highlighted
white.
2. Select navigation/function:
• [ ] Move the trackpad down to select the menu item.
• [ ] Briefly touch the trackpad with your finger to confirm
the selection.
• Press [Esc] to cancel the action and switch to measuring
mode.
Short form
This document uses a short form for describing operating steps
(e.g. calling up a function).
Example: calling up Min/Max function
Short form
[ ]
→Display →
Min/Max.
Steps
required
1. Open Main
menu: [ ].
2. Select
Display
menu: [ ].
3. Confirm
selection:
[ ].
4. Select
Min/Max
menu: [ ].
5. Confirm
selection:
[ ].

5 First steps
19
5.2.2. Calling up a function
1. Select function: [ ].
- A box appears around the selected function.
2. Confirm selection: [ ].
- The selected function is opened.
5.2.3. Exit the menu
> Press [Esc].
Before the entered data or measurement data
may be lost,
a confirmation prompt always appears, which must be
confirmed with [ ].
Or
> [ ] → Save and close.
5.2.4. Switching to another tab
> Select the required tab: [ ].
- Required tab is activated and all other tabs are greyed out.
5.2.5. Entering values
Some functions require values (numbers, units, characters) to be
entered. Depending on the function that is chosen, the values are
entered via either a list field or an input editor.
List field
1. Select the value to be changed (numerical value, unit): [ ],[
] (depending on the selected function).
2. Press [ ].
3. Set value: [ ],[ ] (depending on the selected function).
4. Confirm the entry: [ ].
5. Repeat steps 1 and 4 as required.
6. Save the entry: [ ] → Save and close.

6 Using the product
20
Input editor
1. Select the value to be changed (character): [ ],[ ].
2. Accept value: [ ].
Options:
> Toggle between upper / lower case characters:
Select
> Toggle between characters and numbers: select or
.
> Insert space: select
.
> Delete character in front of cursor:
select .
3. Repeat steps 1 and 2 as required.
4. Save the entry: select .
5.2.6. Saving values
> [ ] → Save and close.
6Using the product
6.1. Performing settings
1. Press [ ].
- The Options configuration menu is opened.
2. Select Settings and set parameters:
