TESTO 535 User manual

Instruction manual en
testo 535
www.GlobalTestSupply.com
Quality Testo Products Online at: [e-mail]

Technical data - testo 535
Sensor: 2 channel infrared
absorption principle
Measuring range: 0 to 9,999 ppm CO2
(0 to 0,999 vol.% CO2)
Accuracy: 0 to 5000 ppm:
(at 23 °C *) ± (75 ppm +3 % of m.v.)
5000 to 9,999 ppm:
±(150 ppm +5 % of m.v.)
Resolution: 1 ppm or 0.001 vol.%
Ambient
temperature: 0 to +50°C
Storage temp.: -20 to +50 °C
Battery lifetime: >4h (9 V block, Al-Mn)
Switchover: ppm / vol. %
Display: LCD (11 mm digit height)
Housing: ABS
Dimensions: 190 x 57 x 42 mm
Weight: Approx. 300 g
Ambient humidity: 0 to 99 %RH
not subjected to
condensation
Please read prior to operation
-Never measure on live parts
-Observe sensor measuring ranges!
Overheating may destroy probes.
-Observe storage and transport temperature as
well as the max. operating temperature
(e.g. protect measuring instrument from direct
sunlight).
-Inexpert handling or use of force cancel your
warranty claims!
-If there is a change in the ambient temperature
(change of location, e.g. inner/outer
temperature) the measuring instrument will
need an adaptation phase of several minutes.
- The CO2probe contains optical components.
Please treat the probe like your camera.
Strong vibrationa may chenge the manufac-
turer´s calibration. Check the readings in
fresh air: 350 to 450 ppm. It is recommended
that the instrument is sent to a Testo service
point for adjustment purpose.
- The CO2probe is permanently attached to
the measuring instrument. Probes can only be
changed at Testo service points.
- Ensure the probe does not come into frequent
contact with water otherwise the long-term
stability will be affected.
- If the level of high frequency is high, there may
be deviation from the required
2 line display
Mains connection (mains unit no. 0554.0088)
recommended for long-term measuring.
Hold/Max/Min
MEAN button
START/STOP
ON/OFF
button
PRINT button
Screw-off
battery
compartment
Operation
Switch on instrument. After the
instrument is switched on a short
display and function test follows and
the sensor has a warm-up phase of approx. 30
s. The instrument is then ready to operate. The
CO2concentration in the sensor needs approx.
1 minute to adapt to ambient conditions. This
adaptation time can be shortened by swinging
the probe gently back and forth. If the probe is
subjected to condensation, this can lead to
uncreased mesured values.
Changing the battery
If“Bat“ appears in the display, the
battery will last approx. 1 hour
out of a total lifetime of 4 hours, if
referring to an alkali-manganese
battery. The instrument will switch
off automatically if there is not enough power.
Unscrew the battery compartment, remove
the used battery and put in new battery, type
9V (IEC 6 F 22). (Observe polarisation). User
settings remain intact if the instrument is not
longer than 3 minutes without power.
If the Auto-Off function is activated
the instrument switches itself off auto-
matically after 10 minutes of inactivity
(except in the case of HOLD) and
timed mean calculation.
The probe should be held as far as
possible from your body so as to
eliminate the influences caused by the
CO2in your breath.
Auto-Off function
Warranty
testo 535 meas. instr................2 years
Probe.........................................1 year
The conformity certificate
confirms that this product
fulfills the guidelines in accor-
dance with 2004/108/EEC.
2
Instructions for disposal:
Only empty batteries should be disposed. The
batteries should be placed in plastic bags to
prevent short-circuits.
* Temp. coefficient: ± (1 ppm + 0,4 % of meas.) / °C
www.GlobalTestSupply.com
Quality Testo Products Online at: [e-mail]

Pressure compensation
Please note that the CO2reading depends on the absolute air pressure.
This effect is compensated in the instrument. To do this, enter the correct air pressure (See
Changing the settings - Configuration). The air pressure depends on the height of the location above
mean sea level (See the “Barometric height formula” table on the next page) and weather influences.
Example:
You are located at a height of 800 m above sea level where you have a mean annual air pressure of
920 hPa. According to the barometer (1003 hPa) and the height correction of the barometer (to 1013
hPa) the mean annual air pressure has to be reduced by 10 (910 hPa air pressure).
Memory function for current, maximum and minimum values
The following displays appear when this button is pressed again and again:
1st press: HOLD - Readings are frozen in display
2nd press: MAX - Displays saved max. values
3rd press: MIN - Displays saved min. values
4th press: MEAN - Multi-point mean calculation
5th press: MEAN -Timed mean calculation
6th press: MEAN- Return to measuring mode
Important note:
The min/max values are measured from the time the instrument is switched on. The values are reset if
the instrument is switched off and then on again.
Changing the settings - Configuration
“START/STOP” button: keep pressed when switching on.
The following settings can be changed:
Printout
A printout of the reading with date and time can be activated by pressing the PRINT button.
The max, min and mean values also appear on the printout of a multi-point or timed mean cal-
culation. If a reading was frozen at a certain point in the display via the HOLD button, this rea-
ding appears in the printout with the time and date when the reading was frozen.
3
Auto ON BAT
Battery in
instrument
Rechargeable
battery in inst-
rument
Date
Next
position
Set value Set value
Set value
Next
position
Next
position
Time Air pressure
Auto OFF
Meas-
uring
mode
1013
hPa
1013
hPa
ppm
Vol%
▲
00:00
00:00
01:01
1998
01:01
1998
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
ACCU
▲
Auto-OFF
function
activated
Auto-OFF
function
not activated
www.GlobalTestSupply.com
Quality Testo Products Online at: [e-mail]

Table: barometric height formula
Mean calculation
The clock starts to run in the display. Once
the measurement has run for as long as
required, press the Start/Stop button.
The duration of the measurement can be
extended by further Start/Stop intervals
lasting up to a total of 99 hours and 59
minutes.
The mean of the readings are taken over
a certain period of time. The mean and
duration are shown.
Call up reading by pressing button.
Save required readings by
pressing button.
Timed mean calculation
4x
Multi-point mean calculation
1310
0
MEAN
▲▲
MEAN
▲▲▲
MEAN
▲
MEAN
▲▲
MEAN
▲▲▲ ▲
1:25 1:25
MEAN
▲▲▲
Return to measuring mode
This procedure can be repeated 999 times.
The number of readings saved is counted in the display.
00:00
▲
1310 1450
1450
037 037
1310 1310
4
Height above
mean sea level
Height above
mean sea level
Height above
mean sea level
Height above
mean sea level
Air pressure
(hPa)
Air pressure
(hPa)
Air pressure
(hPa)
Air pressure
(hPa)
www.GlobalTestSupply.com
Quality Testo Products Online at: [e-mail]

Ordering data
5
Error messages
Error message Cause Remedy
in display
Probe out of order Please contact
the Testo
service point
Measuring range Measuring range
is exceeded. is exceeded.
The readings Does not damage
lie outside the probe.
maximum measuring range
testo 535 measuring instrument and accessories Part no.
testo 535, CO2 measuring instrument for measuring the quality of ambient air,
with securely attached probe, instruction manual, batteries
and calibration protocol 0560.5350
TopSafe (indestructible protection case) with bench stand and
belt clip, to protect instrument from impact, dirt... 0516.0183
9 V rechargeable battery, instead of battery 0515.0025
Recharger for 9 V rechargable battery, for external recharging of 0515.0025 battery 0554.0025
Plug-in mains unit for mains operation 0554.1143
Plastic case for storing measuring instrument, accessories, probes
Testo log printer and accessories 0516.3250
Printer and accessories Part no.
Testo log printer, prints measured data with date and time
0554.0545
Recharger with 4 NC rechargeable batteries for the Testo log printer,
rechargeable batteries are recharged externally 0554.0110
Printer paper for Testo log printer (6 rolls) 0554.0569
www.GlobalTestSupply.com
Quality Testo Products Online at: [e-mail]

www.GlobalTestSupply.com
Quality Testo Products Online at: [e-mail]

www.GlobalTestSupply.com
Quality Testo Products Online at: [e-mail]

0973 5350 en 03 V01.80
