TESTO Smart Probes 905i User manual

testo · Smart Probes
Instruction manual
[e-mail] www.Testo-Direct.com

1 Contents
3
1Contents
1Contents ...................................................................................................3
2Safety and the environment....................................................................5
2.1. About this document........................................................................5
2.2. Ensure safety...................................................................................6
2.2.1. Safety and the testo 510i ....................................................................................6
2.2.2. Safety and the testo 549i ....................................................................................6
2.2.3. Safety and the testo 805i ....................................................................................6
2.3. Protecting the environment..............................................................7
3Specifications ..........................................................................................7
4Product description.................................................................................7
4.1. Overview of Smart Probes...............................................................7
4.2. LED status.......................................................................................8
5First steps ................................................................................................8
5.1. Switching on/off ...............................................................................8
5.1.1. Switching on........................................................................................................8
5.1.2. Switching off........................................................................................................9
5.2. Establishing Bluetooth®connection .................................................9
5.3. Transmitting readings ......................................................................9
6Using the App ........................................................................................10
6.1. Overview of operating controls ......................................................10
6.2. App options....................................................................................10
6.2.1. Set “Language” .................................................................................................10
6.2.2. Display Tutorial .................................................................................................11
6.2.3. Show help .........................................................................................................11
6.2.4. Display testo website ........................................................................................11
6.2.5. Display App Info ................................................................................................11
6.3. Application menus .........................................................................11
6.3.1. Selecting the application menu.........................................................................11
6.3.2. Setting favourites ..............................................................................................12
6.3.3. Displaying information about an application .....................................................12
6.4. Displaying Smart Probe details......................................................12
6.5. List, graphic diagram and table view .............................................12
6.6. Settings view .................................................................................13
6.7. Retaining readings.........................................................................13
6.8. Exporting readings.........................................................................13
6.8.1. Excel (CSV) Export ...........................................................................................13
6.8.2. PDF Export........................................................................................................14
6.8.3. Exporting a graph..............................................................................................14
7Maintaining the product ........................................................................14
[e-mail] www.Testo-Direct.com

1 Contents
4
7.1. Maintaining Smart Probes............................................................. 14
7.2. Smart Probes App......................................................................... 15
8Tips and assistance.............................................................................. 15
8.1. Questions and answers ................................................................ 15
8.2. Accessories and spare parts......................................................... 16
9Technical data ....................................................................................... 16
9.1. Bluetooth module .......................................................................... 16
9.2. General technical data .................................................................. 17
9.2.1. testo 905i ..........................................................................................................17
9.2.2. testo 410i ..........................................................................................................18
9.2.3. testo 405i ..........................................................................................................19
9.2.4. testo 549i ..........................................................................................................19
9.2.5. testo 805i ..........................................................................................................20
9.2.6. testo 605i ..........................................................................................................21
9.2.7. testo 510i ..........................................................................................................22
9.2.8. testo 115i ..........................................................................................................23
10 EC Declaration of Conformity .............................................................. 24
[e-mail] www.Testo-Direct.com

2 Safety and the environment
5
2Safety and the environment
2.1. About this document
Use
> Please read this documentation through carefully and
familiarize yourself with the product before putting it to use. Pay
particular attention to the safety instructions and warning advice
in order to prevent injuries and damage to the products.
> Keep this document to hand so that you can refer to it when
necessary.
> Hand this documentation on to any subsequent users of the
product.
Symbols and writing standards
Representation
Explanation
Warning advice, risk level according to the signal word:
Warning! Serious physical injury may occur.
Caution! Slight physical injury or damage to the
equipment may occur.
> Implement the specified precautionary measures.
Note: Basic or further information.
1. ...
2. ...
Action: more steps, the sequence must be followed.
> ... Action: a step or an optional step.
- ... Result of an action.
Menu Elements of the instrument, the instrument display or the
program interface.
[OK] Control keys of the instrument or buttons of the program
interface.
... | ... Functions/paths within a menu.
“...” Example entries
[e-mail] www.Testo-Direct.com

2 Safety and the environment
6
2.2. Ensure safety
> Do not operate the instrument if there are signs of damage at
the housing, mains unit or feed lines.
> Do not perform contact measurements on non-insulated, live
parts.
> Do not store the product together with solvents. Do not use any
desiccants.
> Carry out only the maintenance and repair work on this
instrument that is described in the documentation. Follow the
prescribed steps exactly. Use only original spare parts
from Testo.
> Dangers may also arise from the systems being measured or
the measuring environment: Note the safety regulations valid in
your area when performing the measurements.
2.2.1. Safety and the testo 510i
•Magnetic field
•May be harmful to those with pacemakers.
> Keep a minimum distance of 10 cm between pacemaker and
instrument.
2.2.2. Safety and the testo 549i
•Risk of injury due to pressurized, hot, cold or toxic
refrigerants/media!
> Only to be used by qualified staff.
> Wear protective goggles and safety gloves.
> Before applying pressure to the measuring instrument: always
fix the instrument tightly onto the pressure connection
> Comply with the permissible measuring range (0 to 60 bar). Pay
particular attention to this in systems with R744 refrigerant,
since these are frequently operated at higher pressures!
2.2.3. Safety and the testo 805i
•Laser radiation! Class 2 laser
> Do not look into the laser beam!
[e-mail] www.Testo-Direct.com

4 Product description
7
2.3. Protecting the environment
> Dispose of faulty rechargeable batteries/spent batteries in
accordance with the valid legal specifications.
> At the end of its useful life, send the product to the separate
collection for electric and electronic devices (observe local
regulations) or return the product to Testo for disposal.
3Specifications
Testo Smart Probes are different hand-held measuring instruments
for various applications that communicate with your mobile terminal
devices by means of an app. The respective Smart Probe performs
the measurement and is operated by your mobile terminal device.
The various Smart Probes allow you to measure the temperature,
humidity, flow, and volume flow at the outlet, or perform pressure,
differential pressure, and non-contact temperature measurements
in the duct.
4Product description
4.1. Overview of Smart Probes
[e-mail] www.Testo-Direct.com

5 First steps
8
1 Measuring unit
2 LED
3 Key
4 Battery compartment (at the back)
5 Direction of flow testo 405i / testo 410i (not shown)
(An arrow on the top of the housing displays the direction of
flow in which the measuring instrument has been calibrated and
which achieves the best measurement results. Please note the
direction of flow during usage.)
4.2. LED status
LED status Meaning
Flashing red Low battery status
Flashing yellow •Smart Probe is switched on.
•Smart Probe is searching for a BT connection, but is
not connected.
Flashing green •Smart Probe is switched on.
•Bluetooth is connected.
5First steps
5.1. Switching on/off
testo 549i
5.1.1. Switching on
1. Pull the film out of the battery compartment.
2. Press the button on your Smart Probe.
- The Smart Probe switches on.
[e-mail] www.Testo-Direct.com

5 First steps
9
5.1.2. Switching off
1. Press and hold the button on your Smart Probe.
- The Smart Probe switches off.
5.2. Establishing Bluetooth®connection
You need a tablet or smartphone with the testo Smart Probes App
already installed on it to be able to establish a Bluetooth connection.
You can get the App for iOS instruments in the App Store or for
Android instruments in the Play Store.
Compatibility:
•requires iOS 8.3 or later/Android 4.3 or later
•requires Bluetooth 4.0
•Tested with the following smartphones/tablets:
www.testo.com/smartprobesmanuals.html
✓The testo App Smart Probe is installed on your terminal device
and ready for use.
1. Press the button on the Smart Probe.
- The Smart Probe switches on.
- The LED flashes yellow while connecting via Bluetooth and
then flashes green once the connection is established.
- The connection between the Smart Probe and your mobile
terminal device is established.
5.3. Transmitting readings
✓The Smart Probe is switched on and connected to your mobile
terminal device via Bluetooth.
- The current readings are automatically displayed in the App.
[e-mail] www.Testo-Direct.com

6 Using the App
10
6Using the App
6.1. Overview of operating controls
1 Choice of applications.
2 Display of connected Smart Probes.
3 Switch between the views (list, graphic diagram, table)
4 Measurement settings. (The menu changes depending on
the Smart Probe connected and the application selected)
5 Restarts the measuring value recording in graph and table
format.
6 Export the readings.
7 Options menu
6.2. App options
6.2.1. Set “Language”
1. Tap -> Settings -> Language.
- A selection list is displayed.
2. Tap the required language.
- The selected language receives a green check mark.
3. Tap ◄ several times until the measurement view is displayed.
- The language has been changed.
[e-mail] www.Testo-Direct.com

6 Using the App
11
6.2.2. Display Tutorial
The Tutorial guides you through the first steps when operating the
testo Smart Probes App.
1. Tap -> Tutorial
- The Tutorial is displayed. In Tutorial, swipe to display the next
page.
2. Tap X to close the Tutorial.
6.2.3. Show help
An internet connection is required to display the testo website.
1. Tap -> Help
- The page www.testo.com/smartprobesmanuals.html is
displayed.
6.2.4. Display testo website
An internet connection is required to display the testo website.
1. Tap -> About/Link -> Testo
- The page www.testo-international.com is displayed.
6.2.5. Display App Info
In App Info you can find the version number of the installed App.
1. Tap -> About/Link -> Info
- The App’s version number is displayed, as well as the ID.
2. Tap ◄ several times until the measurement view is displayed.
6.3. Application menus
6.3.1. Selecting the application menu
1. Press .
- A selection of menus for various applications is displayed.
2. Select the required application.
- The selection disappears and your selected application is
displayed.
[e-mail] www.Testo-Direct.com

6 Using the App
12
6.3.2. Setting favourites
1. Press .
- A selection of applications is displayed.
2. Press next to the application that you would like to
designate as a favourite.
- The asterisk is displayed in orange , and the selected
application is listed under Show Favorites.
6.3.3. Displaying information about an application
1. Press .
- A selection of applications is displayed.
2. Press .
- The information about an application is displayed.
6.4. Displaying Smart Probe details
✓One or more Smart Probes are connected to your mobile
terminal device via Bluetooth.
1. Press .
- All connected Smart Probes are displayed in this list.
2. Select the Smart Probe to display the details you would like to
see.
- A list appears with the details for the Smart Probe.
3. Press Close to exit the detailed view.
6.5. List, graphic diagram and table view
The available readings can be displayed in different ways in the
various views.
•List view
Displays the readings transmitted by the Smart Probe in the
form of a list. Readings from all connected Smart Probes are
displayed here.
•Graphic diagram view
The graphical progression of up to four different readings can
be displayed. Tap on a reading above the diagram to select the
readings to be displayed.
[e-mail] www.Testo-Direct.com

6 Using the App
13
•Table view
In the Table view, all readings are displayed in sequence
according to date and time. The different readings from the
individual Smart Probes can be selected by pressing ◄►.
6.6. Settings view
1. Press and select Edit View.
- An overview of all Smart Probes and their measurement
parameters is displayed.
2. Move the required reading up or down to the position it should
be.
3. Press to hide a Smart Probe reading.
4. Press ▼to select the unit for a reading.
5. Press OK to confirm your settings
6.7. Retaining readings
Readings are retained in the “List” view; in the “Trend” and “Table”
view, the current readings are still displayed.
✓The Smart Probe is switched on, connected to your mobile
terminal device via Bluetooth, and readings are transmitted.
1. Press the button on your Smart Probe.
- The current reading is retained.
2. Press the key again.
- The instrument again displays the current readings.
6.8. Exporting readings
6.8.1. Excel (CSV) Export
1. Press .
- A selection of export options appears.
2. Press Export Excel (CSV).
- A list of readings is displayed.
3. Press .
- A selection of sending/export options appears.
4. Select your required sending/export options.
[e-mail] www.Testo-Direct.com

7 Maintaining the product
14
6.8.2. PDF Export
1. Press .
- A selection of export options appears.
2. Press Export PDF.
- A PDF is created and saved on your mobile terminal device
(Android only) or sent via e-mail (iOS and Android).
3. Press Done to exit the detailed view.
6.8.3. Exporting a graph
1. Press .
- A selection of export options appears.
2. Press Export Graph.
- An image file of the trend display is created.
3. Press .
- A selection of sending/export options is displayed.
4. Tap on the sending/export option you need.
7Maintaining the product
7.1. Maintaining Smart Probes
Cleaning the instrument
> Do not use any aggressive cleaning agents or solvents!
> Mild household cleaning agents or soap suds may be used.
> If the housing of the instrument is dirty, clean it with a damp
cloth.
Keeping connections clean
> Keep connections clean and free of grease and other deposits,
clean with a damp cloth as required.
Ensuring measuring accuracy
> Testo Customer Service would be glad to further assist you if
you so wish.
> Keep within the permissible measuring range!
> Calibrate instrument regularly (recommendation: once a year).
[e-mail] www.Testo-Direct.com

8 Tips and assistance
15
7.2. Smart Probes App
The testo Smart Probes App is kept updated via the Play Store for
Android devices and the App Store for iOS devices. Please update
the App as soon as a new update is available. We therefore
recommend that you do not disable automatic notifications when
new updates are available.
8Tips and assistance
8.1. Questions and answers
Question Answer
LED flashes red •Batteries are almost spent.
•Change batteries.
The instrument switches
itself off
Remaining battery capacity insufficient
> Change the batteries.
--- lights up instead of
the measurement
parameter display
•Outside the permissible measuring range.
> Keep within the permissible measuring range.
or
•Sensor is defective
> Contact your testo Service department.
The App cannot be
found in the store
•No correct search terms were entered.
> Enter an unambiguous search term, e.g.: “testo
Smart Probes” or use the link on the testo website.
or
•Your mobile terminal device does not meet the
technical requirements (iOS 8.3 or later, Android
4.3 or later / Bluetooth 4.0 (Low Energy))
> Please check the technical data for your mobile
terminal device
[e-mail] www.Testo-Direct.com

9 Technical data
16
8.2. Accessories and spare parts
Designation Item number
testo Smart Case (Refrigeration) for storing and transporting
2 × testo 115i and 2 × testo 549i, dimensions 250 × 180 ×
70 mm
0516 0240
testo Smart Case (Heating) for storing and transporting
testo 115i, testo 410i, testo 510i, testo 549i and testo 805i,
dimensions 250 × 180 × 70 mm
0516 0270
testo Smart Case (VAC) for storing and transporting
testo 405i, testo 410i, testo 510i, testo 605i testo 805i and
testo 905i, dimensions 270 × 190 × 60 mm
0516 0250
9Technical data
9.1. Bluetooth module
The use of the wireless module is subject to the regulations and
stipulations of the respective country of use, and the module may only
be used in each case in countries for which a country certification has
been granted.
The user and every owner undertake to adhere to these regulations
and prerequisites for use, and acknowledge that the re-sale, export,
import, etc. in particular in, to or from countries without wireless
permits, is their responsibility.
Feature Values
Bluetooth Range 15 m (free field)
(Varies depending on the capability of the mobile
terminal device used.)
Bluetooth type LSD Science & Technology Co., Ltd
L Series BLE module (08 May 2013) based on TI
CC254X chip
Qualified Design ID B016552
Bluetooth radio class Class 3
Bluetooth company 10274
[e-mail] www.Testo-Direct.com

9 Technical data
17
Certification
Austria, Belgium, Bulgaria, Croatia, Czech Republic, Denmark,
Estonia, Finland, France, Germany, Greece, Hungary, Ireland,
Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Poland,
Portugal, Republic of Cyprus, Romania, Slovakia, Slovenia, Spain,
Sweden, United Kingdom
EFTA countries
Iceland, Liechtenstein, Norway and Switzerland
Other countries
USA, Canada, Turkey, Hong Kong
Information from the FCC (Federal Communications Commission)
This instrument complies with part 15 of the FCC Rules. Its
commissioning is subject to the following two conditions: (1) This
instrument may not cause harmful interference and (2) this
instrument must be able to accept interference, even if this could
have undesired effects on the operation.
Changes
The FCC demands that the user be informed that any changes or
modifications to the instrument that have not been explicitly
approved by Testo AG may void the user's right to use this
instrument.
9.2. General technical data
All accuracy specifications apply at a nominal temperature of 22 °C.
9.2.1. testo 905i
Feature Values
Measuring range -50 to 150 °C / -58 to 302 °F
Accuracy ± 1 digit ± 1 °C / ± 1.8 °F
Resolution 0.1 °C / 0.1 °F
Measurement rate 1/sec
Available units of
measurement
°C, °F
Storage temperature -20 °C to 60 °C / -4 to 140 °F
[e-mail] www.Testo-Direct.com

9 Technical data
18
Feature Values
Operating temperature -20 °C to +50 °C / -4 to 122 °F
Battery type 3 micro batteries AAA
Battery life 250 hrs
Dimensions 222 mm × 30 mm × 24 mm
Probe shaft length 100 mm
Probe shaft diameter 4 mm
Directives, standards
and tests
EU guideline: 2014/30/EU
Warranty Duration: 2 years
Warranty terms: see website www.testo.com/warranty
9.2.2. testo 410i
Feature Values
Measuring range 0.4 to 30 m/s / 80 to 5,900 fpm
-20 to 60 °C / -4 to 140 °F
Accuracy ± 1 digit ± (0.2 m/s + 2% of m.v.) (0.4 to 20 m/s)
± (40 fpm + 2% of m.v.) (80 to 4,000 fpm)
± 0.5 °C / ±0.9 °F
Resolution 0.1 °C / 0.1 °F
0.1 m/s / 1 fpm
Measurement rate 1/sec
Available units of
measurement
°C, °F, m/s, fpm, m³/h, cfm, l/s
Storage temperature -20 °C to 60 °C / -4 to 140 °F
Operating temperature -20 °C to +50 °C / -4 to 122 °F
Battery type 3 micro batteries AAA
Battery life 200 hrs
Dimensions 154 mm × 43 mm × 21 mm
40 mm vane diameter
Directives, standards
and tests
EU guideline: 2014/30/EU
Warranty Duration: 2 years
Warranty terms: see website www.testo.com/warranty
[e-mail] www.Testo-Direct.com

9 Technical data
19
9.2.3. testo 405i
Feature Values
Measuring range
1
0 to 30 m/s / 0 to 5,900 fpm
-20 to 60 °C / -4 to 140 °F
Accuracy ± 1 digit ± (0.1 m/s + 5% of m.v.) (0 to +2 m/s)
± (0.3 m/s + 5% of m.v.) (2 to +15 m/s)
± (20 fpm + 5% of m.v.) (0 to +394 fpm)
± (59 fpm + 5% of m.v.) (394 to +3,000 m/s)
± 0.5 °C / ±0.9 °F
Resolution 0.01 m/s / 1 fpm
0.1 °C / 0.1 °F
Measurement rate 1/sec
Available units of
measurement
°C, °F, m/s, fpm, m³/h, cfm, l/s
Storage temperature -20 °C to 60 °C / -4 to 140 °F
Operating temperature -20 °C to +50 °C / -4 to 122 °F
Battery type 3 micro batteries AAA
Battery life 15 hrs
Dimensions 200 mm × 30 mm × 41 mm
Extendible telescope 400 mm
Probe shaft diameter 12 mm
Probe tip diameter 9 mm
Directives, standards
and tests
EU guideline: 2014/30/EU
Warranty Duration: 2 years
Warranty terms: see website www.testo.com/warranty
9.2.4. testo 549i
Feature Values
Measuring range 0 to 60 bar (rel) / 0 to 870 psi (rel)
Overpressure 65 bar
Accuracy ± 1 digit 0.5% of final value of measuring range
1Please switch on the Smart Probe in the following ambient conditions: > 10 °C,
air velocity 0 m/s = protective cap closed to enable the sensor to heat up.
[e-mail] www.Testo-Direct.com

9 Technical data
20
Feature Values
Resolution 0.01 bar / 0.1 psi
Measurement rate 2/sec
Available units of
measurement
bar, psi, MPa, kPa
Connection 1× 7/16" UNF / 1/4" SAE connection
Overload rel. 65 bar
Storage temperature -20 °C to 60 °C / -4 to 140 °F
Operating temperature -20 °C to +50 °C / -4 to 122 °F
Battery type 3 micro batteries AAA
Battery life 150 hrs
Measurable media CFC, HFC, HCFC, N, H20, CO2
Dimensions 125 mm × 32 mm × 31 mm
Directives, standards
and tests
EU guideline: 2014/30/EU
Warranty Duration: 2 years
Warranty terms: see website www.testo.com/warranty
9.2.5. testo 805i
Feature Values
Measuring range -30 °C to 250 °C / -22 to 482 °F
Accuracy ± 1 digit ± 1.5 °C or ± 1.5% of m.v. (0 to 250 °C)
± 2.0 °C (-20.0 to -0.1 °C)
± 2.5 °C (-30.0 to -20.1 °C)
± 2.7 °F or ± 1.5% of m.v. (32 to 482 °F)
± 3.6 °F (-4 to 32 °F)
± 4.5 °F (-22 to -4 °F)
Resolution 0.1 °C / 0.1 °F
Measurement rate 2/sec
Available units of
measurement
°C, °F
Connection 7/16“ – UNF
Storage temperature -20 °C to 60 °C / -4 to 140 °F
[e-mail] www.Testo-Direct.com

9 Technical data
21
Feature Values
Operating temperature -10 °C to +50 °C / 14 to 122 °F
Battery type 3 micro batteries AAA
Battery life 30 hrs
Optics 10:1
Laser marking Diffraction lens as laser marking (laser circle)
Dimensions 140 mm × 36 mm × 25 mm
Emission level Adjustable from 0.1 to 1.0
Directives, standards
and tests
EU guideline: 2014/30/EU
Warranty Duration: 2 years
Warranty terms: see website www.testo.com/warranty
9.2.6. testo 605i
Feature Values
Measuring range -20 to 60 °C, -4 to 140 °F, 0 to 100% RH
Accuracy ± 1 digit ± 1.8% RH + 3% of m.v. at +25 °C (5 to 80% RH)
± 0.03% RH / K (0 to 60 °C)
± 0.8 °C (-20 to 0 °C) / ± 1.44 °F (-4 to 32 °F)
± 0.5 °C (0 to +60 °C) / ± 0.9 °F (32 to 140 °F)
Resolution 0.1 °F / 0.1 °C
0.1% RH
Measurement rate 1/sec
Available units of
measurement
°C, °F, %RH, °Ctd, °Ftd, wetbulb °C, wetbulb °F
Storage temperature -20 °C to 60 °C / -4 to 140 °F
Operating temperature -20 °C to +50 °C / -4 to 122 °F
[e-mail] www.Testo-Direct.com
