Tews Technologies TIP866-TM-10 User manual

The Embedded I/O Company
TIP866-TM-10
Transition Module for TIP866/TIP867
with 8 DB25 Connectors
Version 1.0
User Manual
Issue 1.5
July 2007
D75866851
TEWS TECHNOLOGIES GmbH TEWS TECHNOLOGIES LLC
Am Bahnhof 7
25469 Halstenbek, Germany
www.tews.com
Phone: [phone]
Fax: [phone]
e-mail: [email protected]
9190 Double Diamond Parkway,
Suite 127, Reno, NV 89521, USA
www.tews.com
Phone: [phone]
Fax: [phone]
e-mail: [email protected]
Downloaded from Arrow.com.

TIP866-TM-10 User Manual Issue 1.5 Page 2 of 13
TIP866-TM-10
Transition Module for TIP866 and TIP867 with 8
DB25 Connectors
This document contains information, which is
proprietary to TEWS TECHNOLOGIES GmbH. Any
reproduction without written permission is forbidden.
TEWS TECHNOLOGIES GmbH has made any
effort to ensure that this manual is accurate and
complete. However TEWS TECHNOLOGIES GmbH
reserves the right to change the product described
in this document at any time without notice.
TEWS TECHNOLOGIES GmbH is not liable for any
damage arising out of the application or use of the
device described herein.
Style Conventions
Hexadecimal characters are specified with prefix 0x,
i.e. 0x029E (that means hexadecimal value 029E).
For signals on hardware products, an ‚Active Low’ is
represented by the signal name with # following, i.e.
IP_RESET#.
©1998-2007 by TEWS TECHNOLOGIES GmbH
All trademarks mentioned are property of their respective owners.
Downloaded from Arrow.com.Downloaded from Arrow.com.

TIP866-TM-10 User Manual Issue 1.5 Page 3 of 13
Issue Description Date
1.0 First Issue September 1997
1.1 Redesign January 1998
1.2 Add cable TA106-10 June 2002
1.3 Completion “Technical Specification” April 2003
1.4 New address TEWS LLC September 2006
1.5 Added details for Jumper Configuration July 2007
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

TIP866-TM-10 User Manual Issue 1.5 Page 4 of 13
Table of Contents
1PRODUCT DESCRIPTION.........................................................................................6
2TECHNICAL SPECIFICATION...................................................................................7
3CONNECTOR X1 PIN ASSIGNMENT........................................................................8
4DB25 PIN ASSIGNMENT.........................................................................................10
5CONNECTOR X9 PIN ASSIGNMENT......................................................................11
6JUMPER CONFIGURATION....................................................................................12
7ASSEMBLY DRAWING............................................................................................13
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

TIP866-TM-10 User Manual Issue 1.5 Page 5 of 13
Table of Figures
FIGURE 2-1 : TECHNICAL SPECIFICATION....................................................................................................7
FIGURE 3-1 : CONNECTOR X1 PIN ASSIGNMENT........................................................................................9
FIGURE 4-1 : PIN ASSIGNMENT OF DB25 CONNECTOR TIP866-TM-10 CHANNEL 1 AND 2..................10
FIGURE 4-2 : PIN ASSIGNMENT OF DB25 CONNECTOR TIP866-TM-10 CHANNEL 3 TO 8.....................10
FIGURE 5-1 : PIN ASSIGNMENT OF X9 SCREW TERMINAL.......................................................................11
FIGURE 6-1 : JUMPER FIELD JN5.................................................................................................................12
FIGURE 7-1 : ASSEMBLY DRAWING.............................................................................................................13
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

TIP866-TM-10 User Manual Issue 1.5 Page 6 of 13
1 Product Description
The TIP866-TM-10 is a complete interface solution for the TIP866-10 (8 serial channels RS232), the
TIP866-20 (8 serial channels RS422) and the TIP867-10 (8 serial channels RS485). The TIP866-TM-
10 comes with a TA106-10 cable (0.8m ribbon cable with 50 pin ribbon cable connectors).
The 8 serial ports of the TIP866-10/-20 or the TIP867-10 are routed to 8 DB25 connectors located in
the 6U/8TE front panel of the TIP866-TM-10.
Jumper fields are provided for each channel to select the port configuration (DTE / DCE) for RS232
(Jn1 / Jn2) or RS422 (Jn3 / Jn4) and to select termination for the RS422 receiver (Jn5: 5-6, 7-8) or
RS485 (Jn5: 1-2, 3-4).
A two pin screw terminal (X9) can be used to provide +5V to pin 9 of the DB25 connectors of channel
1 to 8 and to supply the on board termination for RS422 and RS485. The +5V can be individually
selected by jumper for each of the channels 1 to 8 (Jn5: 9-10).
TXD, RXD, RTS, CTS and GND are supported for each of the 8 serial channels of the TIP866-10
(RS232). Additionally DCD, DTR, RI and DSR are supported for channel 1 and 2.
TXD+/-, RXD+/- and GND are supported for the TIP866-20 (RS422) and DX+/- and GND are
supported for the TIP867-10 (RS485).
This transition module can also be used with the IP-Octals. If the TIP866-TM-10 is used with the IP-
Octal RS232: do not connect jumpers on J11, J12, J21, J22: 9-10, 11-12, 13-14 and 15-16 because
the IP-Octal RS232 does not support DCD, DTR, RI and DSR on serial channel 1 and 2.
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

TIP866-TM-10 User Manual Issue 1.5 Page 7 of 13
2 Technical Specification
Board Size 233 mm x 80 mm
Front panel 6U / 8TE front panel with 8 DB25 connectors
Interface to IP Connector for 50 conductor flat cable
Cable TA106-10 (0.8m ribbon cable with 50 pin ribbon
cable connectors)
Power Supply +5V / GND by 2 pin screw terminal
Power only required to supply on board
termination or to provide +5V to pin 9 of the
DB25 connectors of channel 1 to 8.
Fuse protected by a 1A Multifuse.
MTBF 301749h
Figure 2-1 : Technical Specification
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

TIP866-TM-10 User Manual Issue 1.5 Page 8 of 13
3 Connector X1 Pin Assignment
X1
Pin TIP866-10 ( RS232 ) TIP866-20 ( RS422 ) TIP867-10 ( RS485)
1 GND GND GND
2 TXD1 TXD1- DX1-
3 RXD1 TXD1+ DX1+
4 RTS1 RXD1- nc
5 CTS1 RXD1+ nc
6 GND GND GND
7 TXD2 TXD2- DX2-
8 RXD2 TXD2+ DX2+
9 RTS2 RXD2- nc
10 CTS2 RXD2+ nc
11 GND GND GND
12 TXD3 TXD3- DX3-
13 RXD3 TXD3+ DX3+
14 RTS3 RXD3- nc
15 CTS3 RXD3+ nc
16 GND GND GND
17 TXD4 TXD4- DX4-
18 RXD4 TXD4+ DX4+
19 RTS4 RXD4- nc
20 CTS4 RXD4+ nc
21 GND GND GND
22 TXD5 TXD5- DX5-
23 RXD5 TXD5+ DX5+
24 RTS5 RXD5- nc
25 CTS5 RXD5+ nc
26 GND GND GND
27 TXD6 TXD6- DX6-
28 RXD6 TXD6+ DX6+
29 RTS6 RXD6- nc
30 CTS6 RXD6+ nc
31 GND GND GND
32 TXD7 TXD7- DX7-
33 RXD7 TXD7+ DX7+
34 RTS7 RXD7- nc
35 CTS7 RXD7+ nc
36 GND GND GND
37 TXD8 TXD8- DX8-
38 RXD8 TXD8+ DX8+
39 RTS8 RXD8- nc
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

TIP866-TM-10 User Manual Issue 1.5 Page 9 of 13
X1
Pin TIP866-10 ( RS232 ) TIP866-20 ( RS422 ) TIP867-10 ( RS485)
40 CTS8 RXD8+ nc
41 nc nc nc
42 nc nc nc
43 DCD1 nc nc
44 DTR1 nc nc
45 RI1 nc nc
46 DSR1 nc nc
47 DCD2 nc nc
48 DTR2 nc nc
49 RI2 nc nc
50 DSR2 nc nc
nc = not connected on the TIP866-TM-10
Figure 3-1 : Connector X1 Pin Assignment
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

TIP866-TM-10 User Manual Issue 1.5 Page 10 of 13
4 DB25 Pin Assignment
Pin No.
DB25 RS232 DTE ( Jn1 ) RS232 DCE ( Jn2 ) RS422 DTE ( Jn3 ) RS422 DCE ( Jn4 ) RS485 ( Jn3 )
2 TXD RXD TXD- RXD- DX-
3 RXD TXD RXD- TXD-
4 RTS CTS
5 CTS RTS
6 DSR Pulled High
7 GND GND GND GND GND
8 DCD DTR
9 ( +5V ) ( +5V) ( +5V) ( +5V) ( +5V)
14 TXD+ RXD+ DX+
16 RXD+ TXD+
20 DTR DCD
22 RI
Figure 4-1 : Pin Assignment of DB25 Connector TIP866-TM-10 Channel 1 and 2
Pin No.
DB25 RS232 DTE ( Jn1 ) RS232 DCE ( Jn2 ) RS422 DTE ( Jn3 ) RS422 DCE ( Jn4 ) RS485 ( Jn3 )
2 TXD RXD TXD- RXD- DX-
3 RXD TXD RXD- TXD-
4 RTS CTS
5 CTS RTS
7 GND GND GND GND GND
9 ( +5V ) ( +5V) ( +5V) ( +5V) ( +5V)
14 TXD+ RXD+ DX+
16 RXD+ TXD+
Figure 4-2 : Pin Assignment of DB25 Connector TIP866-TM-10 Channel 3 to 8
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

TIP866-TM-10 User Manual Issue 1.5 Page 11 of 13
5 Connector X9 Pin Assignment
Pin Signal
1 GND
2 +5V
Figure 5-1 : Pin Assignment of X9 Screw Terminal
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

TIP866-TM-10 User Manual Issue 1.5 Page 12 of 13
6 Jumper Configuration
Position Function
1-2
3-4
Installed: 120R On Board Termination
for RS485 Mode active
Open: No On Board Termination for
RS485 Mode
5-6
7-8
Installed: 120R On Board Termination
for RS422 Modes active
Open: No On Board Termination for
RS422 Modes
9-10 Connection X9 Pin 2 Power Supply to
DB25 Pin 9
Figure 6-1 : Jumper Field Jn5
Jumper Configuration Notes:
There are 5 jumper fields per serial channel n (Jn1 to Jn5) (n = Serial Channel 1 to 8).
Jn1 to Jn4 are used to select the desired DB25 pin assignment and function as shown in the
DB25 pin assignment tables.
Only one jumper field of Jn1 to Jn4 must be installed at a time. A jumper field Jn1 to Jn4 is
installed by plugging all jumpers of the jumper field. Remove all jumpers from the other jumper
fields of the Jn1 to Jn4 group.
Channel 1 and 2 of the TIP866-TM-10 additionally support DCD, DTR, RI and DSR for the
TIP866-10.
Default configuration for TIP866-TM-10: all jumpers installed on Jn1 => RS232 DTE.
Jn5 is used for enabling an on board 120R termination resistor for the RS422 and RS485
modes.
If on board termination is desired, only one termination block of jumper field Jn5 must be
installed at a time. Either 1-2, 3-4 for the RS485 mode or 5-6, 7-8 for the RS422 modes. If RS232
modes are selected or on board termination is not desired, leave Jn5 1-2, 3-4, 5-6, 7-8 open.
Using the on board termination feature requires a +5V power supply at the X9 connector (2 pin
screw terminal).
Do not use the on board termination feature of the TIP866-TM-10 when connecting a TIP866-20
(RS422) because there are termination resistors on the TIP866-20 !
Support of +5V at pin 9 of the DB25 connector for channel 1 to 8 is jumper selectable (Jn5: 9-
10) and requires a +5V power supply at the X9 connector (2 pin screw terminal).
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

TIP866-TM-10 User Manual Issue 1.5 Page 13 of 13
7 Assembly Drawing
Figure 7-1 : Assembly Drawing
