TEXA eLight ONE User manual

eLight ONE
eLight ONED
Rev.01

ENGLISH..................................................................51
NORWEGIAN..........................................................375
en
nb

SUMMARY
REVISION OF THE MANUAL........................................................................51
INTRODUCTION............................................................................................52
1 LEGEND OF THE SYMBOLS USED........................................................53
2 GENERAL SAFETY REGULATIONS.......................................................54
2.1 Glossary.........................................................................................................54
2.2 Operator Safety Regulations.........................................................................54
2.2.1 General Safety Regulations.................................................................................54
2.2.2 Risk of Asphyxiation............................................................................................54
2.2.3 Risk of Impact and Crushing...............................................................................54
2.2.4 Hazards Caused by Moving Parts.......................................................................55
2.2.5 Risk of Burning or Scalding.................................................................................55
2.2.6 Fire and Explosion Hazard..................................................................................55
2.2.7 Noise Hazard.......................................................................................................56
2.2.8 High Voltage Hazard...........................................................................................56
2.2.9 Poisoning Hazard................................................................................................56
2.3 General User and Maintenance Warnings.....................................................57
3SPECIFIC SAFETY RULES FOR USING eLIGHT ONE AND eLIGHT ONED
.......................................................................................................................58
3.1 Glossary.........................................................................................................58
3.2 General Rules................................................................................................58
3.3 Operator Safety.............................................................................................58
3.4 Device Safety.................................................................................................60
4 ENVIRONMENTAL INFORMATION.........................................................61
5 OPERATION OF THE RADIO DEVICES..................................................62
6 REGULATORY INFORMATION...............................................................63
7 eLIGHT ONE / eLIGHT ONED...................................................................64
7.1 eLIGHT ONE.................................................................................................66
7.2 eLIGHT ONED................................................................................................67
8 DESCRIPTION..........................................................................................68
9 TECHNICAL FEATURES..........................................................................70
9.1 Measurement.................................................................................................73
10 PREPARING FOR USE..........................................................................74
49
en

10.1 Assembly.....................................................................................................74
11 POWER SUPPLY AND RECHARGE......................................................77
12 POWER ON/OFF....................................................................................79
12.1 Reset...........................................................................................................80
13 COMMUNICATION.................................................................................81
13.1 Wi-Fi............................................................................................................82
13.2 Bluetooth......................................................................................................83
14 PRELIMINARY OPERATIONS...............................................................84
14.1 Work Surface...............................................................................................85
14.2 Vehicle Preparation.....................................................................................86
14.3 Device Preparation......................................................................................87
14.4 Device Positioning.......................................................................................88
14.5 Alignment with the Vehicle...........................................................................89
15 PHOTOMETRIC ANALYSIS...................................................................90
16 MAINTENANCE......................................................................................92
16.1 Adjustable Laser Pointer Battery Replacement...........................................93
17 LEGAL NOTICES....................................................................................94
50

ELIGHT ONE / ELIGHT ONE-D TECHNICAL MANUAL
REVISION OF THE MANUAL
This document is revision01 of the TEXA S.p.A. eLIGHT ONE / eLIGHT ONEDtechnical
manual.
Issue date: 10/11/2019
51
en

INTRODUCTION
Dear Customer,
We would like to thank you for choosing a TEXA product for your workshop.
We are certain that you will get the greatest satisfaction from it and receive a great deal of
help in your work.
Please read through the instructions in this manual carefully and keep it for future reference.
Reading and understanding the following manual will help you to avoid damage or personal
injury caused by improper use of the product to which it refers.
TEXA S.p.A reserves the right to make any changes deemed necessary to improve the
manual for any technical or marketing requirement; the company may do so at any time
without prior notice.
This product is intended for use by technicians specialized in the automotive field only.
Reading and understanding the information in this manual cannot replace adequate
specialized training in this field.
The sole purpose of the manual is to illustrate the operation of the product sold. It is not
intended to offer technical training of any kind and technicians will therefore carry out any
interventions under their own responsibility and will be accountable for any damage or
personal injury caused by negligence, carelessness, or inexperience, regardless of the fact
that a TEXA S.p.A. tool has been used based on the information within this manual.
Any additions to this manual, useful in describing the new versions of the program and new
functions associated to it, may be sent to you through our TEXA technical bulletin service.
This manual should be considered an integral part of the product to which it refers. In the
case it is resold the original buyer is therefore required to forward the manual to the new
owner.
Reproduction, whole or in part, of this manual in any form whatsoever without written
authorization from the producer is strictly forbidden.
The original manual was written in Italian, every other language is a translation of the original
manual.
© copyright and database rights 2019. The material contained in this publication is
protected by copyright and database rights. All rights are reserved by law and under
international conventions.
52

1 LEGEND OF THE SYMBOLS USED
The symbols used in the manual are described in this chapter.
Asphyxiation Risk
Explosion Risk
High Voltage Hazard
Fire / Burn risk
Poisoning Hazard
Corrosive Substances Risk
Noise Hazard
Moving Parts Risk
Crushing Risk
Risk of Stumbling
Laser Radiation Hazard
General Risk
Important information
53
en

2 GENERAL SAFETY REGULATIONS
2.1 Glossary
•Operator: qualified person in charge of using the device.
•Device: the purchased product.
•Workplace: the place where the operator must carry out her/his work.
2.2 Operator Safety Regulations
2.2.1 General Safety Regulations
•The operator must be completely clear-headed and sober when using the device; taking
drugs or alcohol before or when operating the device is strictly forbidden.
•The operator must not smoke during device operation.
•The operator must carefully read all the information and instructions in the technical
documents provided with the device.
•The operator must follow all the instructions provided in the technical documents.
•The operator must make sure she/he is working in environment which is suitable for the
operations that must be carried out.
•The operator must report any faults or potentially hazardous situation in connection with
the workplace and the device.
•The operator must carefully follow the safety regulations required for the workplace in
which she/he is working and required by the operations she/he has been asked to carry
out.
2.2.2 Risk of Asphyxiation
Exhaust gas from internal combustion engines, whether they may be petrol or
diesel, are hazardous to your health and can cause serious harm to your body.
Safety Precautions:
•The workplace must be equipped with an adeguate ventilation and air extraction system
and must be in compliance with standards according to current national laws.
•Always activate the air extraction system when working in closed environments.
2.2.3 Risk of Impact and Crushing
Theoperatorisexposedtotheriskofinjurywhenservicingandtestingthevehicles.
54

Safety Precautions:
•Always make sure that the vehicle is in neutral gear (or that it is set in parking position
in case of a vehicle equipped with automatic transmission).
•Always activate the hand brake or parking brake on the vehicle.
•Always block the vehicle's wheels using specific mechanical blocks.
2.2.4 Hazards Caused by Moving Parts
Vehicle engines include parts that move, both while running and not running (eg:
the cooling fan is controlled by a thermal switch in connection with the coolant
temperature and become activated even when the vehicle is off), that can injure
the operator.
Safety Precautions:
•Keep hands away from moving parts.
•Disconnect the engine cooling fan each time the engine you are working on is still hot.
This will avoid the fan from becoming activated unexpectedly even when the engine is
off.
•Do not wear ties, loose clothes, wrist jewellery or watches when working on a vehicle.
•Keep connection cables, probes and similar devices away from the moving parts of the
engine.
2.2.5 Risk of Burning or Scalding
The parts that are exposed to high temperatures in engines that are moving or
have just stopped could burn the operator.
Remember that catalytic mufflers reach very high temperatures, able to cause
serious burns or even start fires.
Acid in the vehicle batteries is another potential hazard.
Safety Precautions:
•Protect your face, hands, and feet by using suitable protection.
•Avoid contact with hot surfaces, such as spark plugs, exhaust pipes, radiators and
connections within the cooling system.
•Make sure there are no oil stains, rags, paper or other inflammable material near the
muffler.
•Avoid splashing electrolyte onto your skin, eyes and clothes, as it is a corrosive and
highly toxic compound.
2.2.6 Fire and Explosion Hazard
The following are potential fires and / or explosion hazards:
•The types of fuel used by the vehicle and the vapours released by these fuels.
•The refrigerants used by the A/C system.
•The acid in the vehicle batteries.
55
en

Safety Precautions:
•Let the engine cool.
•Do NOT smoke near the vehicle.
•Do NOT expose the vehicle to open flames.
•Make sure that the electrical connections are all well insulated and firmly in place.
•Collect any fuel that might have spilled.
•Collect any refrigerant that might have spilled.
•Make sure you are always working in an environment equipped with a good ventilation
and air extraction system.
•Always activate the air extraction system when working in closed environments.
•Avoid causing sparks when connecting cables to the battery.
2.2.7 Noise Hazard
Loud noises that may occur within the workplace, especially during service
operations may damage the operator's hearing.
Safety Precautions:
•Protect your ears with suitable protective ear wear.
2.2.8 High Voltage Hazard
The voltage supply from the mains that powers the devices in the workplace and
the voltage within the vehicle starter system is a potential shock hazard to the
operator.
Safety Precautions:
•Make sure the electrical system in the workplace is compliant to current national
standards.
•Make sure the device being used is connected to ground.
•Cut off the power supply voltage before connecting or disconnecting cables.
•Do NOT touch the high voltage cables when the engine is on.
•Make sure you are well insulated from the ground when handling/operating the tools.
•Work with dry hands only.
•Keep conductive liquids away from the engine while working.
•Never leave tools on the battery in order to avoid accidental contacts.
2.2.9 Poisoning Hazard
The hoses used to extract the refrigerants can release toxic gases, dangerous to
the operator if exposed to temperatures higher than 250 °C or in case of a fire.
Safety Precautions:
•Contact a doctor immediately should you inhale these gases.
•Use neoprene or PVC gloves when eliminating combustion deposits.
56

2.3 General User and Maintenance Warnings
When using the device and carrying out ordinary maintenance on it, carefully follow the
information provided below:
•Do not remove or damage the labels and the warnings on the device; do not in any case
make them illegible.
•Do not remove or block any safety devices the product is equipped with.
•Do not open or disassemble the device.
57
en

3SPECIFIC SAFETY RULES FOR USING eLIGHT ONE AND
eLIGHT ONED
The technology used for the design and manufacturing control of eLIGHT ONE / eLIGHT
ONED makes it a reliable, simple and safe device to use.
The personnel in charge of using the diagnostic and measuring tools is required to follow the
general safety rules and to use the eLIGHT ONE /eLIGHT ONEDdevice for its intended use
only. Furthermore, they are required to carry out the maintenance as described in this
manual.
3.1 Glossary
Operator: a qualified person responsible for using the diagnostic tool.
device: any eLIGHT ONE / eLIGHT ONEDdevice
3.2 General Rules
•The operator must have basic knowledge of mechanics, automotive engineering, car
repair and of the potential dangers that may arise during self-diagnosis and
measurement operations.
•Theoperatormusthavecarefullyreadalltheinformationandinstructionsinthetechnical
documents provided with the tool.
3.3 Operator Safety
The device was designed and built to be stable and solid once installed correctly.
Severe impacts may compromise its stability other than its functionality.
Safety Measures:
•Move the device only as indicated in this manual.
•Do not move the device on rough or uneven floors.
•Avoid moving the device on excessive slopes as much as possible.
The device was designed and built so as to minimise the possibility of crushing
due to moving parts.
Unsuitable clothing for the work environment and carelessness when using the
device may put the operator at risk of injury.
Safety Measures:
•Use the necessary safety equipment.
•Always wear appropriate clothing for the work environment.
•Be careful when adjusting the moving parts of the device.
The base of the device may be an obstacle that could cause you to stumble.
Safety Measures:
58

•Be careful when operating near the device.
For a correct positioning of the device, for the purpose of the photometric analysis,
specific laser pointers must be used.
Looking directly at the laser beam is not dangerous as long as the blink reflex is
maintained, which allows limiting the cornea exposure to a time below 0.25
seconds.
Taking medications or alcohol may delay the blink reflex response, exposing the
eye to irreversible damage.
Safety Measures:
•Use laser protection glasses if you are undergoing treatment with medications.
•Do not consume alcohol before or while using the device.
•Do not look directly at the laser beam, not even while wearing protective glasses.
The accessible laser radiation is harmless to the eye as long as no optical tools
(e.g.magnifyingglasses,lenses,telescopes)areusedinfrontofthelaseropening.
An optical tool positioned in front of the laser opening reduces the cross-section
of the laser beam, making the accessible radiation harmful to the eye.
Safety Measures:
•Do not position any type of optical tool in front of the laser opening.
•Do not point the laser beam towards people, especially the face and eyes
•Do not point the laser beam towards reflecting surfaces.
•If possible, cover or eliminate any possible reflecting surfaces near the laser beam.
The beam of a Class 2 laser product may cause: dazzle, flash blindness and
afterimages, particularly in poor ambient lighting conditions.
This may cause indirect consequences on general safety, which result in
temporary visual impairment or reactions of fear / surprise.
Laser:
Safety Measures:
•Do not point the laser beam towards people, especially the face and eyes
•Do not look directly at the laser beam, not even while wearing protective glasses.
59
en

3.4 Device Safety
The device was designed to be used in the environmental conditions indicated in
the Technical Features chapter.
Using the device in environments with temperatures and humidity that differ from
those specified, may impair its efficiency.
Safety measures:
•Always place the device in a dry area.
•Keep the device at a minimum distance of 1 metre from the walls.
•Do not expose or use the device close to heat sources.
•Do not use corrosive chemicals, solvents or harsh detergents to clean the device.
Thetoolwasdesignedtobemechanicallytoughandsuitableforuseinaworkshop.
Careless use and excessive mechanical strain may impair its efficiency.
Safety measures:
•Do not drop, shake or knock the device.
•Do not carry out any type of intervention that may damage the device.
•Do not open or disassemble the device.
•The device must be moved on its own wheels only.
•Adjust the position of the optical box only through the specific handle.
•Do not use the optical box as a supporting surface.
•Pay the utmost attention not to damage the Fresnel lens in any way.
The device was manufactured to be electrically safe and to work with specific
supply voltage levels.
Failure to comply with the specifications related to the power supply may impair
the device's efficiency.
Safety measures:
•Do not wet the device with water or other liquids.
•The device's power supply must always be connected following the indications provided
in this manual.
•Do not use an external batteries to supply the device.
The electromagnetic compatibility tests carried out on the device guarantee that it
can be adapted to the technologies normally used on vehicles (ex.: engine control,
ABS, etc.). Nevertheless, if malfunctions occur, contact the vehicle's dealer.
60

4 ENVIRONMENTAL INFORMATION
Do not dispose of this product with other undifferentiated solid waste.
For information regarding the disposal of this product please see the pamphlet
supplied.
61
en

5 OPERATION OF THE RADIO DEVICES
Wireless connection with Bluetooth and WiFi technology
The wireless connectivity with Bluetooth and WiFi technology supplies a standard and
reliablemethod toexchangeinformation betweendifferentdevices,using radiowaves.Other
than TEXA products, even products such as cellular phones, portable devices, computers,
printers, cameras, Pocket PCs, etc. use this type of technology.
The Bluetooth and WiFi interfaces look for compatible electronic devices according to the
radio signal they emit and establish a connection between them. TEXA tools select and only
prompt you with compatible TEXA devices. This does not exclude the presence of other
sources of communication or disturbance.
THE EFFICIENCY AND THE QUALITY OF THE BLUETOOTH AND WiFi
COMMUNICATIONS MAY BE INFLUENCED BY THE PRESENCE OF RADIO
DISTURBANCE SOURCES. THE COMMUNICATION PROTOCOL HAS BEEN
DEVELOPED TO MANAGE THESE TYPES OF ERRORS; HOWEVER, IN THESE CASES
COMMUNICATION MAY BECOME DIFFICULT AND CONNECTION MAY REQUIRE
SEVERAL ATTEMPTS.
SHOULDTHEWIRELESSCONNECTIONBECRITICALANDCOMPROMISEAREGULAR
COMMUNICATION, THE SOURCE OF THE ENVIRONMENTAL ELECTROMAGNETIC
DISTURBANCE MUST BE IDENTIFIED AND ITS INTENSITY MUST BE REDUCED.
Position the tool so that the radio devices it is equipped with can work properly. In particular,
do not cover it with any shielding materials or with any metallic materials in general.
62

6 REGULATORY INFORMATION
Simplified EU Declaration of Conformity
The manufacturer, TEXA S.p.A., declares that the type of radio equipment
eLIGHT ONE / eLIGHT ONEDis compliant with the following directives:
•EMC 2014/30/EU
•LVD 2014/35/EU
•ROHS 2011/65/EU
ThecompletetextoftheEUdeclarationofconformityisavailableatthefollowing
Internet address: http://www.texa.com
63
en

7 eLIGHT ONE / eLIGHT ONED
The eLIGHT headlight testers are tools specifically designed to optimise the photometric
analysis and headlight adjustment on all types of vehicles.
Use of the Bluetooth and Wi-Fi technologies allows these devices to integrate the functions
of a normal headlight tester with the potentials of a diagnostic tool.
Connection with a diagnostic tool (Vehicle Communication Interface) allows selectively
activating the headlight to test and, if allowed by the vehicle manufacturer, setting the
headlight control unit in "adjustment" mode.
The eLIGHT range is composed of the following models:
•eLIGHTONE<enfasi-non-traducibiledex-child-pos='1'stile='grassetto'>eLIGHTONE</
enfasi-non-traducibile>
•eLIGHT ONED<enfasi-non-traducibile dex-child-pos='1' stile='grassetto'>eLIGHT
ONED</enfasi-non-traducibile>
eLIGHT ONE<enfasi-non-traducibile
dex-child-pos='1'
stile='grassetto'>eLIGHT ONE</enfasi-
non-traducibile>
eLIGHT ONED<enfasi-non-traducibile dex-child-
pos='1' stile='grassetto'>eLIGHT ONED</enfasi-
non-traducibile>
Both models are equipped with a solid and lightweight aluminium frame that allows easily
and safely moving the headlight tester on its rubber wheels.
The headlight tester can also be installed as a fixed photometric station, with longitudinal
movement on rail.
The column on which the optical box is installed can rotate by approximately 15° for better
alignment with the vehicle.
The optical box can be adjusted in height thanks to a sliding system based on rollers that
allows positioning it at the desired height.
64

Thelarge Fresnel lens allows carryingout correct analyses even onlarge, irregularly-shaped
headlights.
65
en

7.1 eLIGHT ONE
eLIGHT ONE is designed for use in combination with the following display units:
•AXONE Nemo<enfasi-non-traducibile dex-child-pos='1' stile='grassetto'>AXONE
Nemo</enfasi-non-traducibile>
•AXONE Nemo 2<enfasi-non-traducibile dex-child-pos='1' stile='grassetto'>AXONE
Nemo 2</enfasi-non-traducibile>
•AXONE 5<enfasi-non-traducibile dex-child-pos='1' stile='grassetto'>AXONE 5</enfasi-
non-traducibile>
•PC (equipped with specific diagnostic software)
These display units allow using the specific software to carry out a complete and precise
photometric analysis.
The connection between the device and display unit is established via Wi-Fi.
eLIGHT ONE can be connected to a diagnostic tool via Bluetooth:
•NAVIGATOR NANO S<enfasi-non-traducibile dex-child-pos='1'
stile='grassetto'>NAVIGATOR NANO S</enfasi-non-traducibile>
•NAVIGATOR TXTs<enfasi-non-traducibile dex-child-pos='1'>NAVIGATOR TXTs</
enfasi-non-traducibile>
The diagnostic tool allows selectively activating the headlight to test and, if allowed by the
vehicle manufacturer, carrying out the headlight adjustment via software.
66
