TEXA Moto-Tech Diagnostics TXB Evolution User instructions

www.moto-tech.com.au [e-mail]
0405548757
Setting up your TXB Evolution.
TXB Evolution
USB HASP Key
SOFTWARE DVD
with Latest
version
AP01 Bike or AM01 Marine
cable and battery clips (or
connected to bike/vessel via
correct cable)
1Install your software. Insert your green usb hasp key when asked. If no DVD drive available, please see separate
instructions for Download Manager
2Once installed, you should be taken directly to the configuration
screen (go to part 3).
If not, to navigate to the configuration screen.
Click on Bike, then click on the gears icon on the next page, then
click on the wand icon to enter the
configuration page.

www.moto-tech.com.au [e-mail]
0405548757
3Fill out your details and add your logo if you would like this to be shown on
printed reports.
4 Connect your TXB to a battery using the relavent cable. If using Bluetooth, ensure this is
switched on in your computer, if using USB, connect the supplied usb cable to your pc and TXB,
then click on the forward arrow at the bottom right of the page.
5 The software will automatically search for your TXB. Once found, highlight the button to
the right of the tool displayed. The button will turn blue.

www.moto-tech.com.au [e-mail]
0405548757
Click the forward arrow and follow any further instructions.
Set up should now be complete and you will be taken to the home screen.
If not, click on the red X button.
6 On first connection to a system, the software will register itself via internet. If you have no internet you will need to
manually enter the warranty activation code into the window that shows on your screen. (contact us for this code)
Please see document Basic Texa Demo for an introduction to using the system
We also have videos on your You Tube channel: https://www.youtube.com/mototechdiagnostics/
Also, if you are a Facebook user, please like and follow our page for updates and information.
Facebook: https://www.facebook.com/MT.Diag
We recommend contacting us to arrange a suitable time and day to run through the software with you. We can connect
remotely with your permission using a program called team viewer. www.teamviewer.com. Navigate to that web site and
download the free for personal use version.
Ensure you have a suitable bike for connection and the correct cable.
