Texas Instruments TA5704EVM User manual

TA5704EVM 4-Channel Digital Audio PowerAmplifier with Hardware Control
User's Guide
Literature Number: SLOU224April 2008

2 SLOU224 – April 2008Submit Documentation Feedback

Contents
Preface ........................................................................................................................................ 51 Overview ............................................................................................................................. 71.1 TAS5704EVM Features .................................................................................................. 81.2 Basic Tools for Initial Board Power up ................................................................................. 92 System Interfaces ................................................................................................................ 92.1 PSU Interface .............................................................................................................. 92.2 PSC Connector .......................................................................................................... 102.3 Loudspeaker and Subwoofer Connectors (2-Channel BTL Configuration) ...................................... 102.4 Digital Audio Interface SPDIF (J1/OPTO) ............................................................................ 102.5 ADC Interface ............................................................................................................ 112.6 Board Power up General Guidelines .................................................................................. 113 Jumpers and Control Utilities .............................................................................................. 113.1 Clock Frequency Change Jumper ..................................................................................... 113.2 SPDIF/PSIA Utilization Jumpers ....................................................................................... 113.3 Data Routing Jumpers .................................................................................................. 113.4 GAIN Jumpers ........................................................................................................... 123.5 Data Format Jumpers ................................................................................................... 123.6 CONFIG Jumpers ....................................................................................................... 123.7 Switches .................................................................................................................. 134 Board Layout, Bill of Material, and Schematics ...................................................................... 144.1 TAS5704EVM Board Layout, Top Composite View ................................................................ 144.2 TAS5704EVM Board Layout, Top Layer View ....................................................................... 154.3 TAS5704EVM Board Layout, Bottom Layer View ................................................................... 164.4 Bill of Materials ........................................................................................................... 174.5 Schematic ................................................................................................................ 19
Important Notices ............................................................................................................... 20
SLOU224 – April 2008 Table of Contents 3Submit Documentation Feedback

www.ti.com
List of Figures
1 2-Channel (BTL) Configuration with External Subwoofer EVM (TAS5601EVM2) .................................. 72 2-Channel (SE) + 1-Channel (BTL) Configuration ...................................................................... 83 4-Channel (SE) Configuration .............................................................................................. 84 Top Composite View of TAS5704EVM ................................................................................... 95 Top Layer Composite ...................................................................................................... 146 Top Layer .................................................................................................................... 157 Bottom Layer ................................................................................................................ 16
List of Tables
1 Recommended Power Supplies .......................................................................................... 102 TAS5704 SDINx Data Source ............................................................................................ 113 TAS5704 Gain Configuration ............................................................................................. 124 TAS5704 Data Format ..................................................................................................... 125 DIR9001 SPDIF Output Data Format .................................................................................... 126 TAS5704 Output Configuration ........................................................................................... 137 Bill of Materials for TAS5704EVM ....................................................................................... 17
4List of Figures SLOU224 – April 2008Submit Documentation Feedback

Preface
SLOU224 – April 2008
Read This First
About This Manual
This manual describes the operation of the TAS5704EVM evaluation module from Texas Instruments.
How to Use this ManualThis document contains the following chapters•Chapter 1 – Overview•Chapter 2 – System Interfaces•Chapter 3 – Jumpers and Control Utilities on TAS5704•Chapter 4 – TAS5704EVM Layout
Information About Cautions and WarningsThis manual may contain cautions and warnings.
CAUTION
This is an example of a caution statement.
A caution statement describes a situation that could potentially damage yoursoftware or equipment.
WARNINGThis is an example of a warning statement.
A warning statement describes a situation that could potentiallycause harm to you
The information in a caution or a warning is provided for your protection. Please read each caution andwarning carefully.
Related Documentation from Texas InstrumentsThe following table contains a list of data manuals that have detailed descriptions of the integrated circuitsused in the design of the TAS5704EVM. The data manuals can be obtained at the URL http://www.ti.com .Part Number Literature Number
TAS5704 Data Sheet SLOS563DIR9001PW SLES198PCM1808PW SLES177 ATPS76733QD SLVS2081TAS5601 SLAS585
SLOU224 – April 2008 Preface 5Submit Documentation Feedback

Additional Documentation www.ti.com
Additional Documentation
•General Application Notes
EVM Warnings / Restrictions and FCC WarningSee the Evaluation Board/Kit Warnings and Restrictions page towards the end of this User's Guide.
6Read This First SLOU224 – April 2008Submit Documentation Feedback

1 Overview
SPDIF/
Optical, Coax
2CH Analog Input
from Other Source/
Digital Out
TAS5704
TAS5601EVM2
Subwofer
PWM out
Left
Right
I2S
User's GuideSLOU224 – April 2008
TA5704EVM 4-Channel Digital Audio Power Amplifier withHardware Control
TAS5704 customer evaluation module (EVM) demonstrates the integrated circuit (IC) TAS5704 fromTexas Instruments (TI).
TAS5704 is a 4-channel device with an I2S/RJ/LJ digital audio stream input and amplified PWM signalout. The subwoofer PWM signal is provided to an external class D power stage (TAS5601), which uses aLC demodulation filter to drive a subwoofer. For detail information about the TAS5704 device review thedevice data sheet, document number SLOS563 .
TAS5704 is designed to drive two 8- Ωloudspeakers up to 20W per channel (10%THD+N) in a BTLconfiguration. The TAS5704EVM can also be configured to drive four, 4- Ωspeakers in a single-ended(SE) configuration. Finally, the TAS5704EVM can be configured to drive 2 single-ended speakers plus 1bridge-tied speaker (2.1 mode). Review the board schematic, and TAS5601 documents for additionalinformation and more specific application information on the subwoofer daughter card and connector.
TAS5704EVM, together with other TI components on this board, is a complete 4 channel digital audioamplifier system, which includes digital input (SPDIF), analog inputs via ADC, and other features likemute, power down, output configuration control, format control, and gain control.
Figure 1. 2-Channel (BTL) Configuration with External Subwoofer EVM (TAS5601EVM2)
SLOU224 – April 2008 TA5704EVM 4-Channel Digital Audio Power Amplifier with Hardware Control 7Submit Documentation Feedback

SPDIF/
Optical, Coax
2CH Analog Input
from Other Source/
Digital Out
TAS5704
Left
Right
I2S
Sub
LC +
Cap
LC +
Cap
LC
SPDIF/
Optical, Coax
2CH Analog Input
from Other Source/
Digital Out
TAS5704
LFront
RFront
I2S
LC +
Cap
LC +
Cap
LRear
RRear
LC +
Cap
LC +
Cap
1.1 TAS5704EVM Features
Overview www.ti.com
Figure 2. 2-Channel (SE) + 1-Channel (BTL) Configuration
Figure 3. 4-Channel (SE) Configuration
•Self-contained protection systems and control pins•Standard I
2
S data input using optical or RCA inputs•Analog input through analog to digital converter•Subwoofer connection. PWM terminal to provide signal and power to an external subwoofer board(TAS5601EVM2)
•Double-sided plated-through PCB layout, 2oz copper, 2mm.•Access to control signal gain, output configuration, and data format on the EVM board using jumpers
8TA5704EVM 4-Channel Digital Audio Power Amplifier with Hardware Control SLOU224 – April 2008Submit Documentation Feedback

1.2 Basic Tools for Initial Board Power up
2 System Interfaces
2.1 PSU Interface
www.ti.com System Interfaces
Figure 4. Top Composite View of TAS5704EVM
•Up to 26V, 3A power supply (PVCC)•5V, 500mA power supply (VIN)•Banana cables for power supplies and speakers•Optical or coaxial cable for SPDIF interface based on signal source•Two 8 Ωspeakers (BTL) or 4 Ωspeakers (SE). Resistive loads can also be used•Optional: TAS5601EVM2 (for subwoofer connection when using BTL configuration)
This chapter describes the TAS5704EVM board in regards to power supply (PSU) and system interfaces.
The TAS5704EVM module is powered using two power supply sources a 10–26V (PVCC) power supplyand a 5V (VIN) power supply. The 3.3V voltage levels are generated on the board using voltage regulatorsfrom VIN supply.
Note: The length of power supply cable must be minimized. Increasing length of PSU cable isequal to increasing the distortion for the amplifier at high output levels and low frequencies.
Maximum output stage supply voltage depends on the speaker load resistance. Check the recommendedmaximum supply voltage in the TAS5704 data sheet (SLOS563 ).
SLOU224 – April 2008 TA5704EVM 4-Channel Digital Audio Power Amplifier with Hardware Control 9Submit Documentation Feedback

2.2 PSC Connector
2.3 Loudspeaker and Subwoofer Connectors (2-Channel BTL Configuration)
2.4 Digital Audio Interface SPDIF (J1/OPTO)
System Interfaces www.ti.com
Table 1. Recommended Power Supplies
Description Voltage Limitations Current Recommendations(8 Ωload)
System power supply 5 V 500 mAOutput power stage supply 10 – 26 V 3A
(1)
(1)
The rated current correspond to 2 channels at 20W per channel.
•Connect the positive node of the 5V (VIN) power supply to the red binding post marked VIN.•Connect the GND node of the 5V power supply to the black binding post marked GND•Connect the positive node of the high voltage power supply (PVCC) to the red binding post markedPVCC.
•Connect the negative node of the high voltage power supply (PGND) to the black binding post markedPGND.
There is no specific power up sequence for TAS5704, but it is recommended to power up the VINsupply first while reset is kept low for at least 1ms and then power up the PVCC.
CAUTION
Both positive and negative speaker outputs are floating and may not beconnected to ground (e.g. through an oscilloscope).
•Connect the positive (+) and negative (–) nodes of the left speaker to the corresponding metal bindingpost marked OUTA and OUTB on TAS5704EVM board.•Connect the positive (+) and negative (–) nodes of the right speaker to the corresponding metalbinding post marked OUTC and OUTD on TAS5704EVM board.•Install jumpers JP3–JP6 and JP7–JP10 for BTL configuration•The subwoofer is an option on this EVM, which is provided through connecting TAS5601EVM2 to theTAS5704EVM using connector J1. Connector J1 provides the power and corresponding PWMs to theTAS5601EVM2 (subwoofer amplifier). TAS5601EVM2 is configured in PBTL and is able to provide40W to an 8- Ωspeaker. Connect the subwoofer positive and negative nodes to the correspondingmetal binding posts on the TAS5601EVM2.
The Digital Audio Interface contains digital audio signal data (I2S). See TAS5704 Data sheet (SLOS563 )for signal timing and details not explained in this document.
RCA connector and OPTO connector are the two SPDIF interfaces. The switch S1 is used to togglebetween OPTO and RCA connector based on available signal source. Once the RCA cable or opticalcable is connected and the signal source is powered up, please verify the SPDIF lock indicator (blueLED3) to make sure there is viable signal available to the device.
The format of the DIR9001 SPDIF receiver can be changed using jumpers FMT0 and FMT1. Jumpersinstalled = 0. Jumpers removed = 1. The description of possible modes is printed on the EVM.
See the schematic of TAS5704EVM and the DIR9001 device for detail information on method by whichthe data and clocks are provided to TAS5704.
TA5704EVM 4-Channel Digital Audio Power Amplifier with Hardware Control10 SLOU224 – April 2008Submit Documentation Feedback

2.5 ADC Interface
2.6 Board Power up General Guidelines
3 Jumpers and Control Utilities
3.1 Clock Frequency Change Jumper
3.2 SPDIF/PSIA Utilization Jumpers
3.3 Data Routing Jumpers
www.ti.com Jumpers and Control Utilities
In the absence of digital signal source ADC (PCM1808) may be used to convert an analog audio signal todigital signal and provide it to TAS5704. DIR9001 still provides clocks to ADC in this process. Thefrequency of the oscillator selected for DIR 9001determinse the sampling frequency in the absence ofdigital signal. If the OSC is 24MHz the sampling frequency will be set at 96kHz and if the OSC is selectedto be 12MHz the sampling frequency will be defaulted to 48kHz when there is no signal on SPDIF inputterminals. ADC is an additional feature to this board to provide flexibility in sourcing audio signal toTAS5704. Please review the datasheet of PCM1808 for detail description of the ADC on this EVM.
After connecting the loud speakers (loads), power supply, and data line, power up the VIN power supply.Then power up the PVCC power supply. It is recommended to set the PVCC level to 10 volts and thenramp it up to 20 volts to verify the cable connection functionality. It is recommended to set the gain to–3dB at start by having both GAIN ( GAIN0 and GAIN1) jumpers inserted. Note that the gain settingsmarked on the EVM are not correct. Please see Table 3 on the next page for the correct settings. Havingjumpers FM0 and FM1 inserted and FM2 removed sets the data format for the device to I2S format. Makesure the SPDIF format jumpers, FMT0 and FMT1 are removed to set the receiver format to I2S. It isimportant to note that a device RESET (S2 on the top of the board labeled MASTER RESET) needs to beapplied after each gain, format, or configuration change in order for the device to latch in the new settings.Finally, install jumpers CFG1 and CFG2 in the Config Control to select 2-CH-BTL-AD mode.
JP1: In the presence of a valid digital signal input, when SPDIF lock occurs, the user may use JP1 tochange LR clock and BIT clock. When a shunt is inserted, the SCKO = 512Fs and when the shunt isremoved the SCKO = 256Fs. Default is SCKO = 256Fs.
In the absence of a valid digital signal DIR9001 clock outputs switch to the frequency of crystal (Y1). If thecrystal is chosen to be 24MHz the LR clock will be 96KHz and if the crystal is chosen to be 12MHz the LRclock will be 48kHz.
The jumpers MCLK, LRCK, SCLK, SDATA allow the user to switch between the internal clock and datasources and external clock and data sources for instance PSIA (from AP instrument). The defaultconfiguration of these jumpers is SPDIF as it is marked on the EVM with a white arrow. PSIA outputs maybe utilized using pins 2 and 3 of the jumpers. Keep in mind that pin 3 of each jumper is connected toGND. Thus, the user must pay attention to the polarity of the PSIA output cables at the time of insertion.
Jumpers SDIN1, SDIN2: These jumpers enable the user to assign a data source to TAS5704 SDIN1 andSDIN2 pins. See Table 2 .
Table 2. TAS5704 SDINx Data Source
Jumper JP15:SDIN1 Jumper JP16:SDIN2 SDIN1 Source SDIN2 SourcePosition Position
1-2 1-2 ADC ADC1-2 2-3 SPDIF/PSIA SPDIF/PSIA2-3 1-2 SPDIF/PSIA ADC2-3 2-3 SPDIF/PSIA SPDIF/PSIA
SLOU224 – April 2008 TA5704EVM 4-Channel Digital Audio Power Amplifier with Hardware Control 11Submit Documentation Feedback

3.4 GAIN Jumpers
3.5 Data Format Jumpers
3.6 CONFIG Jumpers
Jumpers and Control Utilities www.ti.com
GAIN0 and GAIN1 jumpers enable the user to change the gain of the device. It is important to assertRESET (S2 labeled MASTER RESET) after each gain change in order for the device to recognize the newgain configuration. The truth table is shown below and also it is marked on the EVM board. However, thegain settings are WRONG on the EVM silkscreen. Refer to Table 3 for the correct gain settings.
Table 3. TAS5704 Gain Configuration
Jumper GAIN1 Jumper GAIN0 GAIN (dB)Shunt IN = 0 Shunt OUT = 1
0 0 –30131091 1 12
FM0, FM1, and FM2 are used to change the data format by which TAS5704 operates. FMT0 and FMT1jumpers associated with DIR9001 in SPDIF interface enables the user to change the data format ofDIR9001 so that the data format is in sync with TAS5704 data format. Both TAS5704 and DIR9001 areset by default to operate at 24-bit I2S format. It is important to assert RESET after each format change inorder for the device to recognize the format change. The truth tables below indicate the jumperconfiguration and the data format of TAS5704 and DIR9001 (SPDIF).
Table 4. TAS5704 Data Format
FM2
(1)
FM1
(1)
FM0
(1)
DATA FORMAT
0 0 0 16BIT RJ0 0 1 18BIT RJ0 1 0 20BIT RJ0 1 1 24BIT RJ1 0 0 16 - 24BIT I2S (Default)1 0 1 16 – 24bit RJ1 1 0 RESERVED1 1 1 TEST MODE
(1)
SHUNT IN = 0, SHUNT OUT = 1 (see schematics for details)
Table 5. DIR9001 SPDIF Output Data Format
FMT1
(1)
FMT0
(1)
DATA FORMAT
0 0 16BIT0 1 24BIT RJ1 0 24BIT LJ1 1 24BIT I2S (Default)
(1)
SHUNT IN = 0, SHUNT OUT = 1 (See schematic for details)
CFG1 and CFG2 jumpers are used to select the output configuration between single-ended outputs andbridge-tied outputs or a combination of the two options. See Table 6 for summary of possible settings.
TA5704EVM 4-Channel Digital Audio Power Amplifier with Hardware Control12 SLOU224 – April 2008Submit Documentation Feedback

3.7 Switches
www.ti.com Jumpers and Control Utilities
Table 6. TAS5704 Output Configuration
Jumper CFG2 Jumper CFG1
GAIN (dB)Shunt IN = 0 Shunt IN = 0
2-Channel BTL Mode (AD Modulation). Connect speakers across OUTA/OUTB and0 0
OUTC/OUTD.
2-Channel BTL Mode (BD Modulation). Connect speakers across OUTA/OUTB and0 1
OUTC/OUTD.
2-Channel SE Mode AND 1-Channel BTL Mode (AD Modulation). Connect Left/Rightspeakers across OUTA/Center terminal (+ side of speaker connected to OUTA) and1 0
OUTB/Center terminal (+ side of speaker connected to Center terminal). Connect Subwooferacross OUTC/D. Remove jumpers JP3 – JP6.4-Channel SE Mode (AD Modulation). Connect Speakers across OUTA/Center,OUTB/Center and OUTC/Center, OUTD/Center. OUTB and OUTD are inverted1 1
internally ….connect “+” side of speaker to center terminal (GND) so that OUTB and OUTDwill be in phase with OUTA and OUTC. Remove jumpers JP3 – JP6 and JP7 – JP10.
RESET is an active low function. Pressing master reset switch (S2) resets TAS5704 and DIR9001.Releasing the switch will take the devices out of reset.
POWER DOWN function is an active low function. Pressing the power-down switch (S3) powers downTAS5704 (outputs remain switching at 50% duty cycle). Releasing the switch will take the device out ofpower down.
MUTE is an active low function. Pressing the mute switch (S4) mutes TAS5704. Releasing the switch willtake the device out of mute.
SLOU224 – April 2008 TA5704EVM 4-Channel Digital Audio Power Amplifier with Hardware Control 13Submit Documentation Feedback

4 Board Layout, Bill of Material, and Schematics
4.1 TAS5704EVM Board Layout, Top Composite View
Board Layout, Bill of Material, and Schematics www.ti.com
Figure 5. Top Layer Composite
TA5704EVM 4-Channel Digital Audio Power Amplifier with Hardware Control14 SLOU224 – April 2008Submit Documentation Feedback

4.2 TAS5704EVM Board Layout, Top Layer View
www.ti.com Board Layout, Bill of Material, and Schematics
Figure 6. Top Layer
SLOU224 – April 2008 TA5704EVM 4-Channel Digital Audio Power Amplifier with Hardware Control 15Submit Documentation Feedback

4.3 TAS5704EVM Board Layout, Bottom Layer View
Board Layout, Bill of Material, and Schematics www.ti.com
Figure 7. Bottom Layer
TA5704EVM 4-Channel Digital Audio Power Amplifier with Hardware Control16 SLOU224 – April 2008Submit Documentation Feedback

4.4 Bill of Materials
www.ti.com Board Layout, Bill of Material, and Schematics
Table 7. Bill of Materials for TAS5704EVMDescription RefDes QTY MFR MFR:Part No. Vendor Vendor Part No. ALT Part No.
TI-SEMICONDUCTORS
Modulator/HBRIDGE U1 1 Texas Instruments TAS5704PAP Texas TAS5704PAP No ALT Part No.TQFP64-PAP Instruments
Single Inverter Gate, SOT23-DBV5 INV1, INV2 2 Texas Instruments SN74AHC1GU04DBVR Digi-Key 296-1095-2 296-1095-1
Single 2 to 1 MUX W/Common Strobe, MUX 1 Texas Instruments SN74LVC2G157DCTR Digi-Key 296-13266-2 296-13266-1TSSOP8-DCT
Processor Supervisor Circuit, 3.3V U3 1 Texas Instruments TPS3825-33DBVT Digi-Key 296-2636-2 296-2636-1
Voltage Regulator, LDO Fast Trans. VR1 1 Texas Instruments TPS76733QD Digi-Key 296-2738-5 No ALT Part No.3.3Vdc 1.0A, SOP8-D
S-Ended ANA-IN 24BIT 96kHz Stereo ADC 1 Texas Instruments PCM1808PW Digi-Key 296-19773 No ALT Part No.ADC, TSSOP14-PW
Digital Audio interface receiver U2 1 TI - Burr Brown DIR9001PW Digi-Key 296-21389-5 No ALT Part No.TSSOP28-PW
SEMICONDUCTORS
Optical receiver, 3.3V, PCB-RA ROHS OPTO 1 Toshiba TORX147LFT Digi-Key TORX147LFT TORX141
Crystal, 12.288MHz, HC49US Y1 1 ECS ECS-122.8-S-4 Digi-Key X174 No ALT Part No.
Transistor NPN 50V PreBiased/4.7K Q3 1 Diodes Inc. DDTC143TCA-7 Digi-Key DDTC143TCADITR DDTC143TCADICT100mA SOT23-DBV3
Transistor PNP 50V PreBiased/4.7K Q1, Q2, Q4–Q6 5 Diodes Inc. DDTA143TCA-7 Digi-Key DDTA143TCADITR DDTA143TCADICT100mA SOT23-DBV3
LED, Green 2.0V SMD0805 LED1, LED2, 5 Lumex Optical SML-LXT0805GW-TR Digi-Key 67-1553-2 67-1553-1LED4, LED5,LED7
LED, Red 2.0V SMD0805 LED9 1 Lumex Optical SML-LXT0805IW-TR Digi-Key 67-1552-2 67-1552-1
LED, Yellow 2.0V SMD0805 LED6, LED8, 3 Lumex Optical SML-LXT0805YW-TR Digi-Key 67-1554-2 67-1554-1LED10
LED, Blue SM1206 LED3 1 Avago HSMR-C150 Digi-Key 516-1436-2 516-1436-1Technologies
CAPACITORS
CAP 33pF 50V CERM 0603 NPO C64, C65 2 Panasonic ECJ-1VC1H330J Digi-Key PCC330ACVTR PCC330ACVCT
CAP 4700pF 50V CERM 0603 X7R C42, C43, C61 3 Panasonic ECJ-1VB1H472K Digi-Key PCC1780TR PCC1780CT
CAP 0.01 µF 16V CERM 0603 X7R C78, C91 2 Murata Electronics GRM188R71C103KA01D Digi-Key 490-1525-2 490-1525-1
CAP 0.01 µF 50V CERM 0603 X7R C7 1 Panasonic ECU-V1H103KBV Digi-Key PCC103BVTR PCC103BVCT
CAP 0.047 µF 16V CERM 0603 X7R C10, C41, C88, 4 Panasonic ECJ-1VB1C473K Digi-Key PCC1758TR PCC1758CTC89
CAP 0.068 µF 16V CERM 0603 X7R C63 1 Panasonic ECJ-1VB1C683K Digi-Key PCC1760TR PCC1760CT
CAP 0.1 µF 16V CERM 0603 X7R C5, C8, C11, 17 Panasonic ECJ-1VB1C104K DIGI-KEY PCC1762TR PCC1762CTC25, C55,C66–C68, C70,C71, C73,C80–C83, C90,C93
CAP 0.1 µF 50V CERM 0603 X7R C9, C47 2 Murata GRM188R71H104KA93D Digi-Key 490-1519-2 490-1519-1
CAP 0.22 µF 25V CERM 0603 X7R C1, C16, C23, 4 Murata Electronics GRM188R71E224KA88D Digi-Key 490-3290-2 490-3290-1C26
CAP 1.0 µF 25V CERM 0603 X5R C2, C18, C24 3 Panasonic ECJ-1VB1E105K Digi-Key PCC2422TR PCC2422CT
CAP 4.7 µF 6.3V CERM 0603 X5R C13 1 TDK Corp. C1608X5R0J475M Digi-Key 445-1417-2 445-1417-1
CAP 0.1 µF50V CERM 0805 X7R C15, C29, C35, 4 Panasonic ECJ-2YB1H104K Digi-Key PCC1840TR PCC1840CTC44
CAP 1.0 µF 50V CERM 0805 Y5V 0 Taiyo Yuden UMK212F105ZG-T Digi-Key 587-1308-2 587-1308-1
CAP 1.0 µF 50V METAL Polyester film C48–C50, C79 4 EPCOS B32529C5105J Digi-Key 495-1087 B32529C105JMKT
CAP 1 µF 50V RAD ALUM ELEC FC C86, C87 2 Panasonic EEU-FC1H1R0 Digi-Key P10312 No ALT Part No.
CAP 10 µF 16V RAD ALUM ELEC KGA C46, C53, C54, 11 Panasonic ECE-A1CKG100 Digi-Key P910 No ALT Part No.C57, C69, C72,C74, C76, C84,C85, C92
CAP 15 µF 50V RAD ALUM ELEC FC C37 1 Panasonic EEU-FC1H150 Digi-Key P10317 No ALT Part No.
CAP 22 µF 10V RAD ALUM ELEC KGA C6, C60 2 Panasonic ECE-A1AKG220 Digi-Key P905 No ALT Part No.
CAP 47 µF 16V RAD ALUM ELEC FC C4 1 Panasonic EEU-FC1C470 Digi-Key P11196 No ALT Part No.
CAP 220 µF 50V RAD ALUM ELEC FC C3, C28, C36, 4 Panasonic EEU-FC1H221 Digi-Key P10325 No ALT Part No.C38
CAP 470 µF 50V RAD ALUM ELEC FC C58, C59 2 Panasonic EEU-FC1H471L Digi-Key P11260 No ALT Part No.
SLOU224 – April 2008 TA5704EVM 4-Channel Digital Audio Power Amplifier with Hardware Control 17Submit Documentation Feedback

Board Layout, Bill of Material, and Schematics www.ti.com
Table 7. Bill of Materials for TAS5704EVM (continued)Description RefDes QTY MFR MFR:Part No. Vendor Vendor Part No. ALT Part No.
CAP 1000 µF 35V RAD ALUM ELEC FC C51, C52, C62, 4 Panasonic EEU-FC1V102 Digi-Key P10305 No ALT Part No.C75
RESISTORS
RES 0.0 Ω1/16W 5% SMD 0603 R29, R32, R35 3 Panasonic ERJ-3GEY0R00V Digi-Key P0.0GTR P0.0GCT
RES 3.3 Ω1/16W 5% SMD 0603 R11, R13–R15 4 Yageo 9C06031A3R30JLHFT Digi-Key 311-3.3GTR 311-3.3GCT
RES 47 Ω1/16W 5% SMD 0603 R8, R16, R30, 8 Yageo 9C06031A47R0JLHFT Digi-Key 311-47GTR 311-47GCTR43, R44, R47,R48, R57
RES 75.0 Ω1/16W 1% SMD 0603 R49 1 Panasonic ERJ-3EKF75R0V Digi-Key P75.0HTR P75.0HCT
RES 100 Ω1/16W 5% SMD 0603 R58, R59, R64, 4 Yageo 9C06031A1000JLHFT Digi-Key 311-100GTR 311-100GCTR65
RES 470 Ω1/10W 5% SMD 0603 R7, R9, R40 3 Panasonic ERJ-3GEYJ471V Digi-Key P470GTR P470GCT
RES 332 Ω1/16W 1% SMD 0603 R4, R5, R26, 5 Panasonic ERJ-3EKF3320V Digi-Key P332HTR P332HCTR55, R56
RES 392 Ω1/10W 1% SMD 0603 R3, R45, R70 3 Panasonic ERJ-3EKF3920V Digi-Key P392HTR P392HCT
RES 510 Ω1/10W 5% SMD 0603 R28 1 Yageo 9C06031A5100JLHFT Digi-Key 311-510GTR 311-510GCT
RES 680 Ω1/10W 5% SMD 0603 R42 1 Yageo 9C06031A6800JLHFT Digi-Key 311-680GTR 311-680GCT
RES 1k Ω1/16W 5% SMD 0603 R54 1 Yageo 9C06031A1001JLHFT Digi-Key 311-1.0KGTR 311-1.0KGCT
RES 2.00k Ω1/16W 1% SMD 0603 R67 1 Panasonic ERJ-3EKF2001V Digi-Key P2.00KHTR P2.00KHCT
RES 2.49k Ω1/16W 1% SMD 0603 R62 1 Panasonic ERJ-3EKF2491V Digi-Key P2.49KHTR P2.49KHCT
RES 4.99k Ω1/16W 1% SMD 0603 R31, R39, R41, 5 Panasonic ERJ-3EKF4991V Digi-Key P4.99KHTR P4.99KHCTR46, R63, R1,R2, R12, R38
RES 7.50k Ω1/16W 1% SMD 0603 R68 1 Panasonic ERJ-3EKF7501V Digi-Key P7.50KHTR P7.50KHCT
RES 10k Ω1/16W 5% SMD 0603 R18–R25, R27, 15 Panasonic 9C06031A1002JLHFT Digi-Key 311-10KGTR 311-10KGCTR36, R50–R53,
R69
RES 18.2k Ω1/10W 1% SMD 0603 R17 1 Yageo 9C06031A1822FKHFT Digi-Key 311-18.2KHTR 311-18.2KHCT
RES 249k Ω1/16W 1% SMD 0603 R61 1 Panasonic ERJ-3EKF2493V Digi-Key P249KHTR P249KHCT
RES 1.00M Ω1/16W 1% SMD 0603 R66 1 Panasonic ERJ-3EKF1004V Digi-Key P1.00MHTR P1.00MHCT
RES 0.0 Ω1/10W 5% SMD 0805 R10, R60 2 Panasonic ERJ-GEY0R00V Digi-Key P0.0ATR P0.0ACT
RES 3.3 Ω1/10W 5% SMD 0805 R34 1 Panasonic ERJ-6RQJ3R3V Digi-Key P3.3BTR P3.3BCT
RES 100k Ω1/10W 1% SMD 0805 0 Panasonic ERJ-6ENF1003V Digi-Key P100KCTR P100KCCT
RES 0.0 Ω1/8W 5% SMD 1206 R37 1 Panasonic ERJ-8GEY0R00V Digi-Key P0.0ETR P0.0ECT
RES 3.3 Ω1/4W 5% SMD 1206 R6 1 Panasonic ERJ-8RQJ3R3V Digi-Key P3.3PTR P3.3PCT
RES 4.7 Ω1/8W 5% SMD 1206 R33 1 Panasonic ERJ-8RQJ4R7V Digi-Key P4.7PTR P4.7PCT
FERRITES AND INDUCTORS
Inductor, series 11RHBP, 15UH L1–L4 4 Toko America A7503AY-150M Toko A7503AY-150M No ALT Part No.America
HEADERS AND JACKS
Header, 2 Pin Male, Straight, Gold JP1–JP10, Sullins PZC02SAAN Digi-Key S1011-02 No ALT Part No.CFG1
CFG2, FM0, 19 Sullins PZC02SAAN Digi-Key S1011-02 No ALT Part No.FM1, FMT0,
FMT1, FM2,GAIN0, GAIN1
Header, 3 Pin Male, Straight, Gold JP11–JP16 6 Sullins PZC03SAAN Digi-Key S1011-03 No ALT Part No.
Socket header, 2x8 Pin Female Gold J1 1 Samtec SSW-108-02-G-D-RA Samtec SSW-108-02-G-D-RA No ALT Part No.PCB-RA
JACK, RCA, PCB-RA, ECONO All-metal RCA 1 CUI Stack RCJ-017 Digi-Key CP-1466 No ALT Part No.
Jack, RCA, PCB-Vertical, Black LIN, RIN 2 CUI Stack RCJ-051 Digi-Key CP-1424 No ALT Part No.
SHUNTS
Shunt, Black AU Flash 0.100 JP2, 11 Sullins SPC02SYAN Digi-Key S9001 No ALT Part No.JP11(1-2),
JP12(1-2),
JP13(1-2),
JP14(1-2)
JP15(2-3),
JP16(2-3),
GAIN0, GAIN1,FM0, FM1
TESTPOINTS AND SWITCHES
PC Testpoint, Orange BKNDERR, Keystone 5003 Digi-Key 5003K No ALT Part No.LRCLK, MCLK, ElectronicsMUTE, PDN,RESET, SCLK
18 TA5704EVM 4-Channel Digital Audio Power Amplifier with Hardware Control SLOU224 – April 2008Submit Documentation Feedback

4.5 Schematic
www.ti.com Board Layout, Bill of Material, and Schematics
Table 7. Bill of Materials for TAS5704EVM (continued)Description RefDes QTY MFR MFR:Part No. Vendor Vendor Part No. ALT Part No.
SHUTDOWN, 11 Keystone 5003 Digi-Key 5003K No ALT Part No.SUBM, SUBP, ElectronicsVALID
Switch, Momentary SMT-Short, Black S2–S4 3 Panasonic EVQ-PPBA25 Digi-Key P8086STR P8086SCTTab, 160g
Switch, SPST, VERT-PCB ROHS S1 1 NKK Switches G12AP-RO Digi-Key 360-1758 360-1701
NON-INSULATED WIRE GROUND LOOPS
Non-insulated bus wire, 10MM Length, PGND, PGND 2 Belden CDT 8019000100 Mouser 566-8019 No ALT Part No.18 AWG
Bend the wire lengths into a 'U' shape and solder to the board. Leave a gap of around 0.3 inch between the board and the wire.
BINDING POSTS
Binding post, 15A, uninsulated OUTA, OUTB, 6 Johnson 111-2223-001 Digi-Key J587 No ALT Part No.OUTC, OUTD, ComponentsGND, GND
Binding post, Red, 15A ECONO PVCC, VIN 2 Keystone 7006 Digi-Key 7006K No ALT Part No.Electronics
Binding post, Black, 15A ECONO PGND, 2 Keystone 7007 Digi-Key 7007K No ALT Part No.GND(PGND) Electronics
STANDOFFS AND HARDWARE
Standoff 4-40 Threaded M/F 0.75 in. HW1–HW6 6 Keystone 8403K Digi-Key 8403K No ALT Part No.ALUM-HEX Electronics
Hex Nut, 4-40, Zinc/Steel HW1–HW6 6 Building Fasteners HNZ440 Digi-Key H216 No ALT Part No.
Component Count: 262
COMPONENTS NOT ASSEMBLED
C77, C14, C32, C39, C40, C30, C45, C56, C31, C33, C12, C19, C27, C34, C17, C20, C21, C22, R11, R13, R14, R15
The schematics are appended to this document.
SLOU224 – April 2008 TA5704EVM 4-Channel Digital Audio Power Amplifier with Hardware Control 19Submit Documentation Feedback

of
Filename:
Mod: PCB Rev: Sheet
Save Date:
CX
Schematic Rev:
Design Team:
Drawn By:
TI Print Date
PROJECT:
of
Filename:
Mod: PCB Rev: Sheet
Save Date:
CX
Schematic Rev:
Design Team:
Drawn By:
TI Print Date
PROJECT:
L
L
H
H
INPUT
COAX
OPTO
L
H
L
H
FMT1
RYAN KEHR
NC
JULY 10, 2007
NC 1
LDN
1-2:
2-3:
INPUT
INPUT
SPDIF
SELECT
OPTO INPUT
DECOUPLING
JP1 IN: SCKO = 512 Fs
JP1 OUT: SCKO = 256 Fs
DECOUPLING
16Bit/MSB/RJ
24Bit/MSB/RJ
24Bit/MSB/LJ
24Bit/MSB/I2S
SHUNTS IN = 0
DATA FORMAT FMT0
SPDIF FORMAT
6NC
Tue Jul 10, 2007
TO
ADC
(LRCLK)
(SCLK)
TO
(MCLK) TAS5704
SPDIF
OPTO INPUT
COAX INPUT
SHUNTS OUT = 1
(SDATA)
LOCK
U2
DIR9001PW
(DEFAULT)
FROM MASTER RESET
RCA INPUT
TAS5704EVM.SCH
JUMPER NOTES
1-2: SPDIF CLOCKS/DATA (DEFAULT)
1-2: SPDIF CLOCKS/DATA
2-3: CLOCKS/DATA = PSIA
JUMPER NOTES
2-3: CLOCKS/DATA = PSIA
TAS5704 EVALUTION MODULE
SPDIF RECEIVER ENGINEERING EVALUATION ONLY
