User's Guide
SWCU093C–August 2011–Revised May 2013
TPS65910Ax User's Guide For AM335x Processors
This user's guide can be used as a reference for connectivity between the TPS65910Ax power-
management integrated circuit (PMIC) and the AM335x processor.
1 Introduction
This user's guide can be used as a reference for connectivity between the TPS65910Ax PMIC and the
AM335x processor. The TPS65910AA1 device is to support the AM335x processor with DDR2.
TPS65910A3A1 and TPS65910A31A1 devices are to support the AM335x processor with DDR3. This
user's guide does not provide details about the power resources or the functionality of the device. For
such information, refer to the full specification document, TPS65910 Data Manual.
Table 1 compares TPS65910Ax devices
Table 1. TPS65910Ax comparison
TPS65910A TPS65910A3 TPS65910A31
DDR2 DDR3 DDR3
Memory (VIO=1.8V) (VIO=1.5V) (VIO=1.5V)
Low power mode Low power mode
VRTC power mode Full power mode
(VRTC_REG.VRTC_OFFMASK (VRTC_REG.VRTC_OFFMA
in OFF state (VRTC_REG.VRTC_OFFMASK=1)
=0) SK=0)
2 Connection Diagram and TPS65910Ax EEPROM Definition
Figure 1 shows the connection diagram between the processor and the TPS65910A or TPS65910A3.
Figure 2 shows the connection diagram between the processor and TPS65910A31.
Notes for connection diagram:
• To support the processor power-up sequence, connect BOOT0 to ground and BOOT 1 to VRTC to
select EEPROM boot mode.
• The TPS65910Ax digital control signal level is defined by the VDDIO connection.
• VAUX2 can support up to 300 mA for the specific case of a 3.3-V output level.
• The VDD1 and VDD2 connections shown in Figure 1 and Figure 2 is valid for processor version ZCZ
(15 x 15). In ZCE (13 x 13), VDD_MPU and VDD_CORE are shorted internally. For ZCE, connect
VDD1 to VDD_MPU; VDD2 is free for system use.
5
SWCU093C–August 2011–Revised May 2013 TPS65910Ax User's Guide For AM335x Processors
Submit Documentation Feedback Copyright © 2011–2013, Texas Instruments Incorporated

VFB2
SW2
VFBIO
2.2 PH
SWIO
2.2 PF
VDIG2
VCC1
VBAT
10 PFVFB1
2.2 PH
SW1
VCC2
VCCIO
VDIG1
VDDIO
VAUX2
VAUX1
VMMC
VAUX33
VPLL
VDAC
VRTC
VRTC
20 mA
VCC6
4.7 PF
VCC4
VCC3
VCC5
VCC7
VBACKUP
5 to 2000 mF
VREF
REFGND
100 nF
GND2
GND1
GNDIO
INT1
PWRON
SLEEP
NRESPWRON
GPIO_CKSYNC
(available)
TESTV
(not connected)
SW3
VFB3
VDD3
100 mA
10 K
VDD3 is a boost supplying 5 V. 4.7 PHVBAT
10 PF
10 PF
10 PF
4.7 PF
4.7 PF
4.7 PF
4.7 PF
10 PF
2.2 PH
10 PF
10 PF
2.2 PF
2.2 PF
2.2 PF
2.2 PF
2.2 PF
2.2 PF
2.2 PF
2.2 PF
VBAT
TPS65910A
TPS65910A3
VDDS_DDR
VDDSHVx
VDDS_PLL_xx
VDDS_OSC,
VDDS_SRAM_CORE_BG,
VDDS_SRAM_MPU_BB
1.8/3.3V based on system I/O level
VDD3
100 mA
VDD1
1500 mA
VPLL
50 mA
VDAC
150 mA
VRTC
20 mA
PowerPadTM
VDD2
1500 mA
VIO
1000 mA
VDIG1
300 mA
VDIG2
300 mA
VAUX1
150 mA
VAUX2
150 mA
VAUX33
150 mA
VMMC
300 mA
VDD3 is a boost supplying 5 V.
5 V
VDDS_CORE
VDD_MPU
VDDSHVx
VDDS
VDDSHV
VDDA3P3V_USB0/1
VDDA1P8V_USB00/1
VDDA_ADC
VDDS_RTC
1K 2
VDDIO
1K 2
SCL_SCK
SDA_SDI
SDASR_EN2
SCLSR_EN1
CLK32KOUT
BOOT0
BOOT1
VRTC
OSC32KIN
OSC32KOUT
GPIO1_9
I2C0_SDA
I2C0_SCL
PORZ
PMIC_PWR_EN
SPIO_D1
SPIO_CS0
GPIO1_8
PWRHOLD
Processor
0.6 to 1.5 V, DVS
12.5-mV steps
Default ON 1.1 V
0.6 to 1.5 V, DVS
12.5-mV steps
Default ON 1.1 V
1.5/1.8/2.5/3.3 V
1.2/1.5/1.8/2.7 V
Default ON 1.8 V
1.0/1.1/1.2/1.8 V
Default ON 1.8 V
1.8/2.5/2.8/2.85 V
Default ON 1.8 V
1.8/2.8/2.9/3.3 V
Default ON 3.3 V
1.8/2.0/2.8/3.3 V
Default ON 3.3 V
1.8/2.8/3.0/3.3 V
Default ON 3.3 V
1.8/2.6/2.8/2.85 V
Default ON 1.8 V
1.0/1.1/1.8/2.5 V
Default ON 1.8 V
SWCU093_Block_Diagram
External Buck
Connection Diagram and TPS65910Ax EEPROM Definition www.ti.com
Figure 1. AM335x Power Supply Connections with TPS65910A and TPS65910A3
6TPS65910Ax User's Guide For AM335x Processors SWCU093C–August 2011–Revised May 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated

VFB2
SW2
VFBIO
2.2 PH
SWIO
2.2 PF
VDIG2
VCC1
VBAT
10 PFVFB1
2.2 PH
SW1
VCC2
VCCIO
VDIG1
VDDIO
VAUX2
VAUX1
VMMC
VAUX33
VPLL
VDAC
VRTC
VRTC
20 mA
VCC6
4.7 PF
VCC4
VCC3
VCC5
VCC7
VBACKUP
5 to 2000 mF
VREF
REFGND
100 nF
GND2
GND1
GNDIO
INT1
PWRON
SLEEP
NRESPWRON
GPIO_CKSYNC
(available)
TESTV
(not connected)
SW3
VFB3
VDD3
100 mA
10 K
VDD3 is a boost supplying 5 V. 4.7 PHVBAT
10 PF
10 PF
10 PF
4.7 PF
4.7 PF
4.7 PF
4.7 PF
10 PF
2.2 PH
10 PF
10 PF
2.2 PF
2.2 PF
2.2 PF
2.2 PF
2.2 PF
2.2 PF
2.2 PF
2.2 PF
VBAT
VDD3
100 mA
VDD1
1500 mA
VPLL
50 mA
VDAC
150 mA
VRTC
20 mA
PowerPadTM
VDD2
1500 mA
VIO
1000 mA
VDIG1
300 mA
VDIG2
300 mA
VAUX1
150 mA
VAUX2
150 mA
VAUX33
150 mA
VMMC
300 mA
SDASR_EN2
SCLSR_EN1
OSC32KIN
OSC32KOUT
BOOT0
BOOT1
VRTC
PWRHOLD
PMIC_PWR_EN
SWCU093_Block_Diagram
CLK32KOUT
GPIO1_9
I2C0_SDA
I2C0_SCL
PORZ
SPIO_D1
SPIO_CS0
GPIO1_8
1K 2
VDDIO
1K 2
SCL_SCK
SDA_SDI
VDDS_RTC
VDDS_DDR
VDDSHVx
VDDS_PLL_xx
VDDS_OSC,
VDDS_SRAM_CORE_BG,
VDDS_SRAM_MPU_BB
VDDSHVx
VDDS
VDDSHV
VDDA3P3V_USB0/1
VDDA1P8V_USB00/1
VDDA_ADC
1.8/3.3V based on system I/O level
1.2/1.5/1.8/2.7 V
Default ON 1.8 V
1.0/1.1/1.2/1.8 V
Default ON 1.8 V
1.8/2.5/2.8/2.85 V
Default ON 1.8 V
1.8/2.8/2.9/3.3 V
Default ON 3.3 V
1.8/2.0/2.8/3.3 V
Default ON 3.3 V
1.8/2.8/3.0/3.3 V
Default ON 3.3 V
1.8/2.6/2.8/2.85 V
Default ON 1.8 V
1.0/1.1/1.8/2.5 V
Default ON 1.8 V
VDDS_CORE
VDD_MPU
Processor
0.6 to 1.5 V, DVS
12.5-mV steps
Default ON 1.1 V
0.6 to 1.5 V, DVS
12.5-mV steps
Default ON 1.1 V
1.5/1.8/2.5/3.3 V
VDD3 is a boost supplying 5 V.
5 V
TPS65910A31A1
www.ti.com Connection Diagram and TPS65910Ax EEPROM Definition
Figure 2. AM335x Power Supply Connections with TPS65910A31
7
SWCU093C–August 2011–Revised May 2013 TPS65910Ax User's Guide For AM335x Processors
Submit Documentation Feedback Copyright © 2011–2013, Texas Instruments Incorporated

Connection Diagram and TPS65910Ax EEPROM Definition www.ti.com
Table 2 lists the EEPROM definition of the TPS65910Ax and Figure 3 shows the corresponding power-up
sequence.
Table 2. EEPROM Configuration for TPS65910Ax
Register Bit Description Option Selected
VDD1_OP_REG SEL VDD1 voltage level selection for boot 1.1
VDD1_REG VGAIN_SEL VDD1 gain selection, x1 or x2 x1
EEPROM VDD1 time slot selection 6
DCDCCTRL_REG VDD1_PSKIP VDD1 pulse skip mode enable Skip enabled
VDD2_OP_REG / SEL VDD2 voltage level selection for boot 1.1
VDD2_SR_REG
VDD2_REG VGAIN_SEL VDD2 gain selection, x1 or x3 x1
EEPROM VDD2 time slot selection 7
DCDCCTRL_REG VDD2_PSKIP VDD2 pulse skip mode enable Skip enabled
TPS65910AA1 1.8V
(DDR2)
TPS65910A3A1 1.5V
VIO_REG SEL VIO voltage selection (DDR3)
TPS65910A31A1 1.5V
(DDR3)
EEPROM VIO time slot selection 4
DCDCCTRL_REG VIO_PSKIP VIO pulse skip mode enable Skip enabled
EEPROM VDD3 time slot OFF
VDIG1_REG SEL LDO voltage selection 1.8
EEPROM LDO time slot 2
VDIG2_REG SEL LDO voltage selection 1.8
EEPROM LDO time slot 2
VDAC_REG SEL LDO voltage selection 1.8
EEPROM LDO time slot 1
VPLL_REG SEL LDO voltage selection 1.8
EEPROM LDO time slot 3
VAUX1_REG SEL LDO voltage selection 1.8
EEPROM LDO time slot 3
VMMC_REG SEL LDO voltage selection 3.3
EEPROM LDO time slot 5
VAUX33_REG SEL LDO voltage selection 3.3
EEPROM LDO time slot 5
VAUX2_REG SEL LDO voltage selection 3.3
EEPROM LDO time slot 5
CLK32KOUT pin CLK32KOUT time slot 7
NRESPWRON pin NRESPWRON time slot 7 + 1
TPS65910AA1 Low-
0 = VRTC LDO will be in low-power mode during power mode
OFF state. TPS65910A3A1 Low-
VRTC_REG VRTC_OFFMASK 1 = VRC LDO will be in full-power mode during power mode
OFF state. TPS65910A31A1 High-
power mode
0 = RTC in normal-power mode
DEVCTRL_REG RTC_PWDN 1 = Clock gating of RTC register and logic, low- 1
power mode
0 = Clock source is crystal/external clock.
DEVCTRL_REG CK32K_CTRL RC
1 = Clock source is internal RC oscillator.
Boot sequence time slot duration:
DEVCTRL2_REG TSLOT_LENGTH 0 = 0.5 ms 2 ms
1 = 2 ms
8TPS65910Ax User's Guide For AM335x Processors SWCU093C–August 2011–Revised May 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated

VDDA3P3V_USB0/1, USB_VUSB0/1
Processor/System signal
TPS65910
signal
Vbat/5 V supply VCC7
VRTC
PMIC start-up r ason PWRHOLD
VDDS VDAC 1.8 V
VDDS_PLL_xx, VDDS_OSC,
VDDS__SRAM_CORE/MPU_BG VDIG2 1.8 V
VDDSHVx VDIG1 1.8 V
VDDA1P8V_USB0/1 VAUX1 1.8 V
VDDA_ADC VPLL 1.8 V
VDDS_DDR VIO 1.8V (DDR2)
1.5V (DDR3)
VDDSHVx VAUX2 3.3 V
VDDSHVx VMMC 3.3 V
VAUX33 3.3 V
VDD_MPU VDD1 1.1 V
VDD_CORE VDD2 1.1 V
CLK32KOUT
PORZ NRESPWRON
Switch-on s qu nc Switch-off s qu nc
Slot number: 0 1 2 3 4 5 6 7
www.ti.com Connection Diagram and TPS65910Ax EEPROM Definition
Table 2. EEPROM Configuration for TPS65910Ax (continued)
Register Bit Description Option Selected
0 = INT1 signal will be active low.
DEVCTRL2_REG IT_POL Active high
1 = INT1 signal will be active high.
0 = Device automatically switches on at NO
INT_MSK_REG VMBHI_IT_MSK SUPPLY-to-OFF or BACKUP-to-OFF transition. 1
1 = Start-up reason is required before switch-on.
Select threshold for main battery comparator
VMBCH_REG VMBCH_SEL[1:0] 3 V
threshold VMBCH.
Figure 3. Power-Up and Power-Down Timing Diagram
9
SWCU093C–August 2011–Revised May 2013 TPS65910Ax User's Guide For AM335x Processors
Submit Documentation Feedback Copyright © 2011–2013, Texas Instruments Incorporated

First Initialization www.ti.com
3 First Initialization
3.1 I/O Polarity/Muxing Configuration
Program DEVCTRL2_REG.SLEEPSIG_POL according to the GPIO level setting on the processor. This
can be set to active low or active high for SLEEP transitions. Software configuration allows specific power
resources to enter a low consumption state.
Set DEVCTRL_REG.DEV_SLP = 1 to allow SLEEP transitions when requested.
Update the GPIO0 configuration (GPIO0_REG) based on your needs.
3.2 Define Wake-Up/Interrupt Event (SLEEP or OFF)
Select the appropriate bits in the INT_MSK_REG and INT_MSK2_REG registers to activate an interrupt to
the processor on the INT1 line.
3.3 Backup Battery Configuration
If a backup battery is used, enable backup battery charging by setting the BBCH_REG.BBCHEN bit to 1.
The maximum charge voltage can be set based on the backup battery specifications by using the BBSEL
bits.
3.4 DCDC and Voltage Scaling Resource Configuration
If the SmarReflex interface is not used for viltage scaling (power saving), these pins can be used to
control the power resources.
Configure two operating voltages for DCDC1 and DCDC2
• VDDx_OP_REG.SEL= Roof voltage (ENx ball high)
• VDDx_SR_REG.SEL = Floor voltage (ENx ball low)
Assign control for DCDC1 to SCLSR_EN1 and DCDC2 to SCLSR_EN2:
• Set EN1_SMPS_ASS_REG.VDD1_EN1 = 1
• Set EN2_SMPS_ASS_REG.VDD2_EN1 = 2
• Set SLEEP_KEEP_RES_ON_REG.VDD1_KEEPON = 1 (allow low-power mode)
• Set SLEEP_KEEP_RES_ON_REG.VDD2_KEEPON = 1 (allow low-power mode)
3.5 Sleep Platform Configuration
Configure the state of the LDOs when the SLEEP signal is used (by default all resources go into SLEEP
state; in SLEEP state the LDO voltage is maintained but transient and load capability are reduced).
Resources that must provide full load capability must be set in the SLEEP_KEEP_LDO_ON_REG register.
Resources that can be set off in SLEEP state to optimize power consumption must be set in the
SLEEP_SET_LDO_OFF_REG register.
10 TPS65910Ax User's Guide For AM335x Processors SWCU093C–August 2011–Revised May 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
