Texas Instruments AFE722 Series User manual

TSW1200
TSW3100
6V Power
Input
ADC Input for
ChA and ChB
DAC Outputs
for ChA and ChB
IQ Modulator
Output LO Input
Power Supply Jumpers
for LDO/DCDC, iQ Mod
and CDCE72010
Clock
Inputs
USB
AUX ADC and
DAC
User's Guide
SLOU330–December 2011
EVM Description
The AFE722x EVM includes a great level of flexibility to enable the user to test it in a more system like
environment. The individual power rails can be generated through LDOs or DC/DC converters from a 6 V
power source and the EVM clock architecture allows for external clock input as well as clock generation
using a low jitter PLL in combination with a VCXO. On the transmit side the EVM provides the option of
connecting directly to the DAC outputs or perform up-conversion via on board IQ modulator.
On the digital side the EVM provides a seamless interface to the TSW1200 capture card in order to
evaluate received data directly on a PC. The TSW3100 pattern generation card can be used to provide
data to the dual DAC of the AFE722x and the on board CDCE72010 generates the appropriate clock for
the TSW3100 for synchronous operation. Both AFE722x and CDCE72010 can be programmed via SPI
conveniently through the USB connection.
1
SLOU330–December 2011 EVM Description
Submit Documentation Feedback Copyright ©2011, Texas Instruments Incorporated

Software Installation www.ti.com
Contents
1 Software Installation ........................................................................................................ 2
2 AFE722x.ini file for TSW1200 ............................................................................................. 3
3 AFE722x EVM Software - SPI Control ................................................................................... 3
4 Initial EVM Setup and Basic Test Procedure ............................................................................ 4
4.1 CDCE72010 Configuration ....................................................................................... 4
4.2 RX Path Using TSW1200 ......................................................................................... 5
4.3 TX Path Using TSW3100 ......................................................................................... 6
5 Power Supply Options ...................................................................................................... 9
6 Clocking Configuration ..................................................................................................... 9
6.1 Non-VCXO Option (default) ..................................................................................... 10
6.2 System Level ...................................................................................................... 11
6.3 RX Only ............................................................................................................ 11
6.4 RX and TX Independent Clocking .............................................................................. 11
6.5 Interpolation on the DAC ........................................................................................ 11
6.6 Decimation on the ADC .......................................................................................... 12
7 RX Setup ................................................................................................................... 12
8 TX Setup .................................................................................................................... 13
9 Trouble Shooting of the EVM Setup .................................................................................... 15
List of Figures
List of Tables
1 Control Registers............................................................................................................ 6
2 Clock Delays for Listed DAC Sampling Rates .......................................................................... 7
3 IP Address Digit Selection Using SW2 ................................................................................. 17
1 Software Installation
1. Open folder named AFE722x_Installer_vxpx (xpx represents the latest version)
2. Run Setup.exe
3. Follow the on-screen instructions
4. Once installed, launch by clicking on the AFE722x_GUI_vxpx program in Start >Texas Instruments
ADCs.
5. When plugging in the USB cable for the first time, the user will be prompted to install the USB drivers
for ‘USB Serial Converter’and ‘USB Serial Port’(see ).
(a) Follow the on-screen instructions to install the USB drivers.
(b) If needed, you can access the drivers directly in the install directory
2EVM Description SLOU330–December 2011
Submit Documentation Feedback
Copyright ©2011, Texas Instruments Incorporated

Tabs to control basic
setup, RX and TX
& SYNC registers as
well as CDCE72010
Individual control
registers
Control to send or read all registers
(AFE722x and CDCE72010) as well
as load or save register files.
Reset USB port on FTDI
chip – required after power
up of AFE722x EVM.
Summary of current registers being written showing 12bit
address & 8bit data in hex format as well as 8bit in binary format.
Warning indication that USB
communication is not established.
www.ti.com AFE722x.ini file for TSW1200
2 AFE722x.ini file for TSW1200
The AFE722x software package comes with a new ini file for the TSW1200. This AFE722x.ini file should
be placed manually into the following directory in order for the TSW1200 to recognize it: C:\Program
Files\Texas Instruments\TSW1200\ADC Files
3 AFE722x EVM Software - SPI Control
The AFE722x EVM software controls the AFE722x and CDCE72010 on the EVM via SPI register writes
through a USB connection with the PC. Below is a snapshot of the GUI front panel highlighting the various
tabs to control the setup of AFE722x as well as CDCE72010.
It is required to perform a USB reset after applying power to the EVM to establish proper connection with
the PC. A warning sign on the bottom right will flash otherwise indicating USB communication failure.
The EVM software also provides the option to save all registers to a file or to load registers from a file.
3
SLOU330–December 2011 EVM Description
Submit Documentation Feedback Copyright ©2011, Texas Instruments Incorporated

CDC
AUX IN
/3
/4
CDCE72010
AFE722x
TSW3100
368.64MHz
122.88MHz
92.16MHz
Initial EVM Setup and Basic Test Procedure www.ti.com
4 Initial EVM Setup and Basic Test Procedure
The fastest way to get the AFE722x EVM up and running is to follow this operating procedure:
•Two signal generators should be connected to the clock and data input of the EVM - preferably with
band pass filter and 10MHz reference locked for coherency.
•Clock input should be connected to ‘CDC AUX IN’input for AUX clock setup and the clock generator
amplitude should be set to ~10-13dBm.
•TSW1200 (RX) capture card should be plugged in AFE722x EVM and connected to the PC via USB.
•TSW3100 (TX) pattern generation card plugged into AFE722x EVM and connected to PC via Ethernet
cable.
•All appropriate power supplies should be connected –blue LED (D2) on AFE722x EVM indicating
power good status.
•After performing USB reset in AFE722x EVM software, the flashing USB warning sign should
disappear indicating successful USB communication.
4.1 CDCE72010 Configuration
The initial EVM setup is configured so that the AFE722x can be operated at any desired sampling rate.
Since the TSW3100 requires an external clock at ¾of the AFE clock rate (see clocking section) the
external clock applied to the ‘CDC AUX IN’connector needs to be 3x the AFE sampling rate (e.g.
368.64MHz for 122.88MHz operation). Loading a preconfigured register file (‘AUX IN - div3 AFE div4
TSW.txt’) to the CDCE72010, it then sets the dividers so that a /3 copy of the input clock is routed to the
AFE722x clock input and a /4 copy to the TSW3100.
4EVM Description SLOU330–December 2011
Submit Documentation Feedback
Copyright ©2011, Texas Instruments Incorporated

The section controls the setup of the digital
interface as well as test modes and digital
features such as decimation and loopback
The general setup tab includes
controls for the digital RX interface
www.ti.com Initial EVM Setup and Basic Test Procedure
4.2 RX Path Using TSW1200
First the AFE722x digital interface needs to be configured to match the serial LVDS interface that the
TSW1200 is expecting. The following control registers need to be set in the ‘General Setup’tab of the
AFE722x programming software. Also the USB communication warning sign should be monitored after the
USB reset to ensure proper communication with the AFE722x EVM.
Register Bit Setting
Interface Serial LVDS
Master Override Enabled
Format Offset Binary
Serial LVDS 2 Wire
Data Orientation MSB First
SDR Mode Disabled
Wordwise Output Disabled
Bitwise RX Disabled
Halfrx in 2wire Disabled
In the TSW1200 software, the AFE722x should be selected as the ADC. Next the sampling rate and ADC
input frequency need to be entered and the TSW1200 software will calculate the coherent frequency.
Performing a capture should yield:
Fs=122.88Msps
Fin= 9.98625MHz
5
SLOU330–December 2011 EVM Description
Submit Documentation Feedback Copyright ©2011, Texas Instruments Incorporated

Select AFE722x
for ADC
Perform FFT
capture
Enter ADC
sampling rate
Enter desired
input frequency
DCLK
Data
Initial EVM Setup and Basic Test Procedure www.ti.com
4.3 TX Path Using TSW3100
First the AFE722x digital interface needs to be configured to match the serial LVDS interface from the
TSW3100.
The following control registers need to be set in the ‘General Setup’tab of the AFE722x programming
software. Also the USB communication warning sign should be monitored after the USB reset to ensure
proper communication with the AFE722x EVM.
Table 1. Control Registers
Register Bit Setting
Interface Serial LVDS
Master Override Enabled
Serial LVDS 2 Wire
Data Orientation MSB first
Format 2s Complement
Clock Delay Enabled
Clock Delay 300ps
Frame Clock Delay Disabled
Frame Clock Delay 0ps
The data coming from the TSW3100 is edge aligned while the AFE722x expects the serial LVDS data to
arrive edge centered. Here the programmable clock delay inside the AFE722x can be used to delay the
edge aligned clock closer towards the center of the data.
The table below shows clock delays for listed DAC sampling rates that showed proper operation.
6EVM Description SLOU330–December 2011
Submit Documentation Feedback
Copyright ©2011, Texas Instruments Incorporated

The general setup tab includes
controls for the digital TX interface This section controls the setup of the digital
interface as well as the TX interpolation
www.ti.com Initial EVM Setup and Basic Test Procedure
Table 2. Clock Delays for Listed DAC Sampling Rates
DAC Sampling Rate Suitable Clock Delay
130Msps 0ps to 900ps
122.88Msps 0ps to 900ps
100Msps 0ps to 1.2ns
80Msps 0ps to 1.8ns
65Msps 0ps to 2.1ns
40Msps 0ps to 2.1ns
For TX the output data of the TSW3100 needs to be properly configured for 6x serialization using Matlab.
1. Install Matlab runtime engine (MCRInstaller.exe)
2. Open one of the executable (.exe) TSW3100 GUIs – ‘TSW3100_MultitonePattern_v2p7.exe
3. Enter DAC sampling rate
4. Enter tone frequencies
7
SLOU330–December 2011 EVM Description
Submit Documentation Feedback Copyright ©2011, Texas Instruments Incorporated

Specify DAC
sampling rate
Set tone output
frequency
Press ‘Create and
Save/Run
TSW3100’ to load
data into TSW3100
Specify serial LVDS
as data format
Ensure match on data format with
AFE722x setup (e.g. 2s complement) Select ‘Load and
Run’ option
Initial EVM Setup and Basic Test Procedure www.ti.com
The DAC output should show something like this on the spectrum analyzer (example with sample rate =
122.88 MSPS, input tone = 10 MHz).
8EVM Description SLOU330–December 2011
Submit Documentation Feedback
Copyright ©2011, Texas Instruments Incorporated

LDO
TPS7A4501
6V Input 5V
LDO
TPS79633
CDCE72010
DC/DC
TPS62291
3.3V
LDO
TPS79518
1.8V
6V
JP10
JP19
JP11
JP12
JP18
JP20
JP14
JP13
JP4
DC/DC
TPS62231
TRF3703
I/Q Mod
VCXO
AFE722x
AFE7225
TSW3100
Pattern Generator
Serialized LVDS
6x DAC Rate
Synchronous Clock
@ 1/8 DAC Rate
www.ti.com Power Supply Options
5 Power Supply Options
The AFE722x EVM is designed to operate from an external 6 V wall wart supply. A LDO generates a 5V
rail for the TRF3703 IQ modulator as well as for the low noise LDOs which are generating a 3.3 V and 1.8
V rail for the AFE722x and the CDCE72010. Alternatively the 3.3 V and 1.8 V rails can be generated using
DC/DC converters which operate directly from the 6 V input for maximum power efficiency.
The EVM provides options to disable unused circuits by means of pin headers. These headers can also
be used for accurate power measurements where external power supplies can be directly connected to
them.
Three pin headers allow a convenient change between powering the AFE722x and CDCE72010 either
from DC/DC converter or low noise LDO.
6 Clocking Configuration
The AFE722x EVM offers 3 different options for
providing the clock to the AFE722x as well as the
supporting circuitry. The biggest challenge arises
when using the DAC with the TSW3100 because
the TSW3100 expects an input clock at 1/8 of the
DAC input data rate. However since the AFE722x
is designed for the serial LVDS interface, the DAC
data rate is 6x the actual AFE722x clock frequency.
Hence the clock to the TSW3100 needs to 6/8 =
3/4x the AFE722x clock frequency.
9
SLOU330–December 2011 EVM Description
Submit Documentation Feedback Copyright ©2011, Texas Instruments Incorporated

CDCE72010
SMA
Connector R112 0S
CLK IN
AFE722x
Clk In
DNI DNI
BPF DNI
Y0P Y1P Y1N
SMA
Connector
CDC AUX
IN AUX
SMA
Connector
REF IN Pri Ref TCXO
19.2 MHz
Sec Ref
PLL Lock
SMA
Connector
CLK IN-N
DNI
PLL Lock
Y2P
TSW3100
C70 22pF
DNI
C71 22pF
DNI
R74 0S
R76 0S
R144
0S
R72
0S
R79
0
DNI
S
R81
0
DNI
S
R86 0S
R161
0
DNI
S
Y2N
AUX IN
x3
/3
/4
CDCE72010
AFE722x
TSW3100
Opt. BPF
Clocking Configuration www.ti.com
The CDCE72010 clock buffer on the AFE722x is used to provide the clock to the TSW3100. Additional
dividers can be added to the clock output in order to divide the clock appropriately for optional
interpolation by 2x or 4x.
Preconfigured setup files:
AUX IN –INT2x –div3 AFE div8 TSW.txt ext 3x clock to CDC AUX IN (see 6.5)
AUX IN –div3 AFE div4 TSW.txt ext 3x clock to CDC AUX IN (see 6.1)
REF IN (10MHz) –div6 AFE div8 TSW.txt ext 10MHz clock on REF IN (see 6.2)
REF IN (10MHz) –INT2x –div6 AFE div16 TSW.txt ext 10MHz clock on REF IN (see 6.2/6.5)
REF IN (122.88MHz) –div6 AFE div8 TSW.txt ext 122.88MHz clock on REF IN (see 6.2)
6.1 Non-VCXO Option (default)
This setup is the default configuration and provides the
option to operate AFE722x and TSW3100 synchronous at
any arbitrary sampling rate without the use of a VCXO.
This setup is useful for testing the AFE722x at clock
frequencies where a VCXO is not immediately available.
10 EVM Description SLOU330–December 2011
Submit Documentation Feedback
Copyright ©2011, Texas Instruments Incorporated
